DISTRIBUTED PATH RESTORATION ALGORITHM FOR

ANONYMITY IN P2P FILE SHARING SYSTEMS

Pilar Manzanares-Lopez, Juan Pedro Mu

noz-Gea, Josemaria Malgosa-Sanahuja

Juan Carlos Sanchez-Aarnoutse and Joan Garcia-Haro

Department of Information Technologies and Communications

Polytechnic University of Cartagena

Campus Muralla del Mar, 30202, Cartagena, Spain

Keywords:

Peer-to-peer networks, anonymity, distributed systems.

Abstract:

In this paper, a new mechanism to achieve anonymity in peer-to-peer (P2P) ﬁle sharing systems is proposed.

As usual, the anonymity is obtained by means of connecting the source and destination peers through a set of

intermediate nodes, creating a multiple-hop path. The main paper contribution is a distributed algorithm able

to guarantee the anonymity even when a node in a path fails (voluntarily or not). The algorithm takes into

account the inherent costs associated with multiple-hop communications and tries to reach a well-balanced

solution between the anonymity degree and its associated costs. Some parameters are obtained analytically

but the main network performances are evaluated by simulation.

1 INTRODUCTION

Peer-to-peer networks are one of the most popular

architectures for ﬁle sharing. In some of these sce-

narios, users are also interested in keeping mutual

anonymity; that is, any node in the network should

not be able to know who is the exact origin or des-

tination of a message. Traditionally, due to the con-

nectionless nature of IP datagrams, the anonymity is

obtained by means of connecting the source and desti-

nation peers through a set of intermediate nodes, cre-

ating a multiple-hop path between the pairs of peers.

There are various existing anonymous mecha-

nisms with this operation, but the most important are

the mechanisms based in Onion Routing (Reed et al.,

1998) and the mechanisms based in Crowds (Reiter

and Rubin, 1999). The differences between them are

the following: In Onion, the initiator can determine

an anonymous path in advance to hide some identiﬁ-

cation information. When a user wants to establish an

anonymous communication, he will forward its mes-

sage to a Onion proxy. This Onion proxy will ran-

domly select some nodes in the network and will es-

tablish the complete route (called Onion) between the

initiator an the responder. This Onion, is a recursively

layered data structure that contains the information

about the route to be followed over a network. Every

node can only decrypt its corresponding layer with its

private key, therefore, the ﬁrst node will decrypt the

ﬁrst layer to see the information about next hop in the

route, and this process will continue until the message

reaches its destination. Tarzan (Freedman and Mor-

ris, 2002), Tor (Dingledine et al., 2004), SSMP (Han

et al., 2005) and (Xiao et al., 2003) are implemented

based on Onion Routing to provide anonymous ser-

vices.

On the other hand, in Crowds let middle nodes se-

lect the next hop on the path. A user who wants to

initiate a communication will ﬁrst send the message

to its node. This node node upon receiving the re-

quest will ﬂip a biased coin, to decide whether or not

to forward this request to another node. The coin de-

cides about forwarding the request based on probabil-

ity p. If the probability is to forward, then it will for-

ward to another node and the process continues. If the

probability is not to forward, then it will directly for-

ward the request to the ﬁnal destination. Each node

when forwarding to another node records the prede-

cessors information and in this way a path is built,

which is used for communication between the sender

and the receiver. There are several works (Levine

and Shields, 2002), (Mislove et al., 2004), (Lu et al.,

2004), based in the mechanism used by Crowds to

provide anonymity.

Manzanares-Lopez P., Pedro Muñoz-Gea J., Malgosa-Sanahuja J., Carlos Sanchez-Aarnoutse J. and Garcia-Haro J. (2007).

DISTRIBUTED PATH RESTORATION ALGORITHM FOR ANONYMITY IN P2P FILE SHARING SYSTEMS.

In Proceedings of the Second International Conference on Software and Data Technologies - PL/DPS/KE/WsMUSE, pages 88-95

DOI: 10.5220/0001338600880095

 SciTePress

The above procedure to reach anonymity has two

main drawbacks. The ﬁrst one is that the peer-to-

peer nature of the network is partially eliminated

since now, peers are not directly connected but there

is a path between them. Therefore, the cost of us-

ing multiple-hop path to provide anonymity is an ex-

tra bandwidth consumption and a additional terminal

(node) overhead.

In addition, as it is known, the peer-to-peer ele-

ments are prone to unpredictable disconnections. Al-

though this fact always affects negatively the system

performances, in an anonymous network it is a dis-

aster since the connection between a pair of peers

probably would fail although both peers are running.

Therefore, a mechanism to restore a path when an un-

predictable disconnection arises is needed but it also

adds an extra network overhead in terms of control

trafﬁc.

(Wright et al., 2002) presented a comparative

analysis about the anonymity and overhead of sev-

eral anonymous communication systems. This work

presents several results that show the inability of pro-

tocols to maintain high degrees of anonymity with

low overhead in the face of persistent attackers. In

(Sui et al., 2003), authors calculate the number of ap-

pearances that a host makes on all paths in a network

that uses multiple-hop paths to provide anonymity.

This study demonstrates that participant overhead is

determined by number of paths, probability distribu-

tion of the length of path, and number of hosts in the

anonymous communication system.

In this paper we propose an anonymity mecha-

nism for a hybrid P2P network presented in a previ-

ous work (Mu

noz-Gea et al., 2006) based on Crowds

to create the multiple-hops path. However, our mech-

anism introduce a maximum length limit in the path

creation algorithm used by Crowds, in order to retrict

the partipant overhead.

The main paper contribution is a distributed algo-

rithm to restore a path when a node fails (voluntarily

or not). The algorithm takes into account the three

costs outlined above in order to obtain an equilibrated

solution between the anonymity degree and its asso-

ciated costs. The parameters are obtained analytically

and by simulation.

The remainder of the paper is as follows: Section

2 summarizes the main characteristics of our hybrid

P2P architecture. Section 3 and 4 deeply describes the

mechanism to provide anonymity. Section 5 shows

the simulation results and ﬁnally, Section 6 concludes

the paper.

GENERAL OVERLAY NETWORK

MULTICAST GROUP

Figure 1: General architecture of the system.

2 A HYBRID P2P

ARCHITECTURE

In our proposal (Mu

noz-Gea et al., 2006), peers are

grouped into subgroups in an unstructured way. How-

ever, this topology is maintained by means of an struc-

tured lookup mechanism.

Every subgroup is managed by one of the sub-

group members, that we call “subgroup leader node”.

The subgroup leader is the node that has the best

features in terms of CPU, bandwidth and reliability.

When searching for a content, the user will send the

lookup parameters to its local subgroup leader. The

local subgroup leader will resolve the complex query,

obtaining the results of this query.

To allow the subgroup leaders to locate contents

placed in remote subgroups, all the leaders of the net-

work are going to be members of a multicast group.

The structured P2P network can be used to implement

an Application Level Multicast (ALM) service. CAN-

multicast (Ratnasamy et al., 2001b), Chord-multicast

(Ghodsi et al., 2003) and Scribe (Castro et al., 2002)

are ALM solutions based on the structured P2P net-

works CAN (Ratnasamy et al., 2001a), Chord (Sto-

ica et al., 2003) and Pastry (Rowstron and Druschel,

2001), respectively. Anyone of these methods pro-

vides an efﬁcient mechanism to send messages to all

the members of a multicast group.

To implement the structured-based maintenance

of the unstructured topology, all the nodes (peers)

must be immersed into a structured network. There-

fore, every node has an identiﬁer (NodeID), and they

have to contact with an existing node to join this net-

work. Figure 1 describes the general architecture of

the system.

The previous existing node also gives to the new

node the identiﬁer of the subgroup it belongs (Sub-

groupID), and using the structured lookup mechanism

DISTRIBUTED PATH RESTORATION ALGORITHM FOR ANONYMITY IN P2P FILE SHARING SYSTEMS

the new node will ﬁnd the leader of that subgroup.

This is possible because each time a node becomes a

subgroup leader, it must contact with the node which

NodeID ﬁts with the SubgroupID and sends it its own

IP address.

Initially, the new node will try to connect the same

subgroup than the existing node. To do that, the

new node must contact with the leader of this sub-

group, that will accept its union if the subgroup is not

full. However, if there is no room, the new node will

be asked to create a new (randomly generated) sub-

group or it will be asked to join the subgroup that the

resquested leader urged to create previously. The use

of different existing nodes allows the system to ﬁll

up incomplete subgroups. In addition, to avoid the

existence of very small subgroups, the nodes will be

requested by their leader to join another subgroup if

the subgroup size is less than a threshold value.

When a new node ﬁnds its subgroup leader, it no-

tiﬁes its resources of bandwidth and CPU. Thus, the

leader forms an ordered list of future leader candi-

dates: the longer a node remains connected (and the

better resources it has), the better candidate it be-

comes. This list is transmitted to all the members of

the subgroup.

3 PROVIDING ANONYMITY

In this section we propose a ﬁle sharing P2P appli-

cation built over the previous network architecture

which provides mutual anonymity. As it is deﬁned

in (Pﬁtzmann and Hansen, 2001), a P2P system pro-

vides mutual anonymity when any node in the net-

work, neither the requester node nor any participant

node, should not be able to know with complete cer-

tainty who is the exact origin and destination of a mes-

sage.

Our solution deﬁnes three different stages. On one

hand, all peers publish their contents within their local

subgroups (publishing). To maintain the anonymity

during this phase, a random walk proceduce will be

used. On the other hand, when a peer initiates a com-

plex query, a searching phase will be carried out ﬁrstly

(searching). Finally, once the requester peer knows

all the matching results, the downloading phase will

allow the download of the selected contents (down-

loading). In the following section these three stages

are described in detail.

3.1 Publishing the Contents

To maintain the anonymity, our solution deﬁnes a

routing table at each peer and makes use of a ran-

ALM Service

Publication Path

subgroup

leader

1−p

Figure 2: Publishing phase.

dom walk (RW) technique to establish a random path

from the content source to the subgroup leader. When

a node wants to publish its contents, ﬁrst of all it

must choose randomly a connection identiﬁer (great

enough to avoid collisions). This value will be used

each time this peer re-publishes a content or publishes

a new one.

Figure 2 describes the random path creation pro-

ces. The content owner (C) randomly chooses an-

other active peer (a peer knows all the subgroup mem-

bers, which are listed in the future leader candidate

list, see Section 2) and executes the RW algorithm to

determine the next peer in the RW path as follows.

The peer will send the publish message directly to

the subgroup leader with probability 1 − p, or to the

randomly chosen peer with probability p. This mes-

sage contains the connection identiﬁer associated to

the content owner and the published content metadata.

The content owner table entry associates the connec-

tion identiﬁer and the next peer in the RW path. Each

peer receiving a publish message follows the same

procedure. It stores an entry in its table, that asso-

ciates the connection identiﬁer, the last peer in the RW

path and the next node in the RW path (which will be

determined by the peer using the RW algorithm as it

is described before).

To prevent a message forwarding loop within the

subgroup, each initial publish message (that is gen-

erated by the content owner) is attached with a TTL

(Time To Live) value. A peer receiving a publish mes-

sage decrements the TTL by one. Then, if the re-

sulting TTL value is greater than 1, the peer executes

the RW algorithm. Otherwise, the message is sent di-

rectly to the subgroup leader. When the publish mes-

sage is received by the subgroup leader, it just stores

the adequate table entry that associates the connection

identiﬁer, the published content metadata and the last

peer in the RW path.

The probability that the RW has n hops is

P(n) =



n−1

(1− p) n < TTL,

TTL−1

n = TTL.

(1)

Therefore the mean length of a RW is

ICSOFT 2007 - International Conference on Software and Data Technologies

RW =

1− p

TTL

1− p

−−−→

p→1

TTL. (2)

Thanks to the publishing procedure, each sub-

group leader knows the metadata of the contents that

have been published into its subgroup. However, this

publishing procedure offers sender anonymity. Any

peer receiving a publish message knows who is the

previous node. However, it does not know if this pre-

vious peer is the content owner or just a simple mes-

sage forwarder.

The RW path distributely generated in the publish-

ing phase will be used during the searching and down-

loading phases, as it will be described later. There-

fore, it is necessary to keep updated the RW paths ac-

cording to the non-voluntary peer departures. From

this joint to the anonymous system, each peer main-

tains a timeout timer. When its timeout timer expires,

each peer will check the RW path information stored

in its table. For each entry, it will send a ping mes-

sage to the previous and the following peer. If a peer

detects a connection failure, it generates a RW failure

notiﬁcation that is issued peer by peer to the subgroup

leader (or to the content owner) using the RW path.

Each peer receiving a RW failure notiﬁcation deletes

the associate table entries (only one entry in interme-

diate peers and one entry for each published content

in the subgroup leader peer). In addition, the content

owner re-publishes all its contents. On the other hand,

if an intermmediate peer wants to leave the system in

a voluntary way, it will get in touch with the previous

and the following peer associated to each table entry

in order to updated their entries.

An additional veriﬁcation is carried out each time

a new content is going to be published. Before send-

ing the publish messages, the content owner peer

makes a totalPing (a ping sent to the subgroup leader

through the RW path). If the totalPing fails (any inter-

mediate peer is disconnected), the content owner peer

re-publishes all its contents initiating the creation of a

new distributed RW path. The intermediate peers be-

longing to the failed RW path will update their table

entries when their timeout expires.

3.2 Searching the Contents

The searching procedure to obtain requester

anonymity is described in this section. Figure 3

describes this procedure. When a requester (R) wants

to make a complex search, ﬁrst of all it must select

its connection identiﬁer. If the peer already chose

a connection identiﬁer during a publish phase, this

value is used. Otherwise, a connection identiﬁer is

last non−leader

peer

RW2

ALM Service

Publication Path

RW1

subgroup

leader

subgroup

leader

Lookup Path

Figure 3: Searching phase.

chosen

Then, the peer generates a new type of message

called lookup message. A lookup message, that en-

capsulates the metadata of the searched content and

the connection identiﬁer associated to the requester

peer (R), is forwarded towards the local subgroup

leader using the RW path associated to this connec-

tion identiﬁer (RW1). If the connection identiﬁer is

new, the RW1 path from the requester peer towards

the subgroup leader is generated, distributely stored,

and maintained as it was explained in the section be-

fore.

Once the lookup message has been received, the

local subgroup leader is able to locate the match-

ing results within its subgroup. On the other hand,

our system uses an ALM technique to distribute the

lookup messages to all the subgroup leader nodes.

Each subgroup leader with a positive matching re-

sult must answer the requester’s subgroup leader with

a lookup-response message. This message contains

the connection identiﬁer established by the requester

peer, the matching content metadata, the connection

identiﬁer established by the content owner peer and

the identity of the last non-leader peer in the RW path

(RW2) towards the content owner (C).

In fact, before sending the lookup-response mes-

sage, the subgroup leader will check the complete

RW2 path towards the content owner by means of a

totalPing. If the RW2 path fails, the subgroup leader

will send to all the peers in the subgroup a broadcast

message containing the associate connection identi-

ﬁer. The peer that established this connection will re-

publish all its contents (that is, it initiates the creation

of a new RW for the connection identiﬁer). Peers that

maintain a table entry associated to this connection

identiﬁer will delete it. The rest of peers will take no

notice of the message. Consequently, the subgroup

leader only sends a lookup-response message to the

requester subgroup leader after checking that the as-

sociate RW2 path is active.

Finally, the lookup-response message will be for-

warded through the requester subgroup towards the

requester peer using the adequate and distributed

Each peer is associated to only a connection identiﬁer.

DISTRIBUTED PATH RESTORATION ALGORITHM FOR ANONYMITY IN P2P FILE SHARING SYSTEMS

RW1 path stored in the tables.

3.3 Downloading the Contents

Once the requester peer receives the lookup-response

messages, it is able to select which contents it wants

to download. The anonymity is also important during

this third phase: both the requester peer and the con-

tent owner peer should keep anonymous to the rest of

peers in the system.

In the download phase (see Figure 4), the re-

quester peer (R) generates a download-request mes-

sage which initially encapsulates the required content

metadata, the connection identiﬁer established by it-

self, the connection identiﬁer established by the con-

tent owner (C) and the identity of the last non-leader

peer in the RW2 (in the content subgroup).

This message will be forwarded towards the sub-

group leader using the distributely stored RW1 path.

However, this message will not reach the subgroup

leader. The last non-leader peer in the RW1 path

(the previous to the leader) will be the responsible

for sending the download-request message to the last

non-leader peer in the RW2 (in the content subgroup).

Before sending the message to the content owner sub-

group, this peer (the last non-leader peer in RW1)

must encapsulate an additional value: its own identity.

The message will be forwarded through the content

owner subgroup using the distributely stored RW2

path until it reaches the content owner.

Finally, the content owner peer will start the con-

tent delivery. The download messages encapsulate

the requited content, the connection identiﬁer estab-

lished by the requester peer, the connection identiﬁer

established by itself and the identity of the last non-

leader peer in the RW1 (in the requester subgroup).

These messages will be forwarded towards the sub-

group leader using the adequate RW2 path. However,

they will not reach the subgroup leader. The last non-

leader peer in the RW2 path will be the responsible

for sending them to the node indicated in the message.

Once in the requester subgroup, the messages will be

forwarded using the RW1 path until they reach the

requester peer. Therefore, the mean length of a down-

load path (DP) is

DP = 2(RW − 1) + 1 = 2

1− p

TTL

1− p

− 1 (3)

last non−leader

peer

subgroup

leader

subgroup

leader

last non−leader

peer

RW2

ALM Service

Publication Path

Download Path

RW1

Figure 4: Download phase.

4 DYNAMIC ASPECTS OF THE

SYSTEM

The peer dynamism or churn is an inherent feature

of the P2P networks. Our solution exploits this prop-

erty to improve the anonymity behavior of the sys-

tem. As it has been described in the previous sec-

tion, each peer establishes a RW path towards its sub-

group leader during the publishing or the searching

phases. If there was no churn, these RW paths (which

are randomly established) would not change as the

time passes. However, due to the peer departures

and failures, the RW paths must be continously up-

dated. Consequently, the RW path information that

could be obtained by attackers will be obsolete as the

time passes.

The random election of each RW path is an-

other interesting feature of our proposal. The main

objective of this procedure is to reach the mutual

anonymity. However, there is another important con-

sequence. The ﬁrst non-leader peer (closest to the

leader) in each RW path changes from a RW to an-

other. Consequently, the remote peers involved in

the download process change depending on the con-

tent owner peer and the requester peer. As a conse-

quence, the downloading load is distributed among all

the peers. And something more important, the sub-

group leaders don’t participate during the download

process making lighter their processing load.

As it has been described in the previous sections,

the subgroup leaders have a key role during the pub-

lishing and the searching phases. Each subgroup

leader maintains a list of the published contents in its

subgroup that is used to solve the complex lookups.

The subgroup leader management is deﬁned by the

network architecture. However, there is no doubt that

the subgroup leader changes also affect the anony-

mous system. Each time a subgroup leader changes,

all the RW paths would be obtained again. To opti-

mize the system behaviour when a subgroup leader

changes we propose some actions. If a subgroup

leader changes voluntarily (another peer in the sub-

group has become a most suitable leader or the leader

decides to leave the system), it will send to the new

ICSOFT 2007 - International Conference on Software and Data Technologies

leader a copy of its table. On the other hand, to

solve the non-voluntary leader leaving, we propose to

replicate the table of the subgroup leader to the next

two peers in the future leader candidate list. Conse-

quently, when the subgroup leader fails, the new sub-

group leader will be able to update its table taking into

account the published contents.

5 SIMULATIONS

We have developed a discrete event simulator in C

language to evaluate our system. At the beginning,

the available contents are distributed in a random way

among all the nodes of the network. As it has been

mentioned before, the subgroup leaders share infor-

mation using an ALM procedure. The node life and

death times follow a Pareto distribution using α =

0.83 and β = 1560 sec. These paremeters have been

extracted from (Li et al., 2005). The time between

queries follows an exponential distribution with mean

3600 sec. (1 hour), and if a query fails the user makes

the same request for three times, with an empty inter-

val of 300 sec. among them. The timeout timer has a

value of 300 sec. Finally, the simulation results cor-

responds to a network with 12,800 different contents

and 6,400 nodes, with 128 subgroups.

We have proposed a mechanism to provide

anonymity to a hybrid P2P architecture. However,

this service has a cost in terms of bandwith con-

sumption and nodes overload. On the other hand,

our anonymity mechanism also works ﬁne under a

join/leave or failure scenario. This service is required

to maintain available paths along the time, but it in-

volves an extra control packet interchange. It is nec-

essary to quantify both costs.

Figure 5 represents the average number of hops in

a complete download path, from the content owner to

the requester node (download path length). This mea-

surement helps us in order to estimate the bandwith

consumption, since every hop in a path implies an ex-

tra bandwith consumption to carry out the download.

This ﬁgure represents the results in function of p and

TTL. We represent the results for 3 different TTL

values (10, 15 and 20). When p is less than 0.8 the

mean path length never exceeds 7, so the extra band-

with consumption is very limited. In addition, in this

case the TTL guarantees that in any case the number

of hops will be limited. If p is greater than 0.8 the

extra bandwith consumption tends to inﬁnity, but the

TTL limits it to a reasonable value.

This simulation result corresponds with the ana-

lytical expresssion presented in Equation 3. Addition-

naly, we represent the number of hops in a compelte

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Number of Hops

TTL = 10

TTL = 15

TTL = 20

Without TTL

Figure 5: Average number of hops in a complete download

path.

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Number of Connections

TTL = 10

TTL = 15

TTL = 20

Without TTL

Figure 6: Average numer of connections that a node routes.

download path without using a TTL limit. We ob-

serve than if p is greater than 0.9 the extra bandwith

goes up quickly.

Figure 6 represents the average number of con-

nections that a node routes in function of p and TTL.

With p = 0 the number of paths is 0, because the con-

nection is established directly between the owner and

the requester node. If the value of p increases, the

number of connections also increases. The inﬂuence

of TTL doesn’t appear until p = 0.8, as we observed

in Figure 5. When p > 0.8 the number of connections

a node routes does not tend to inﬁnity thanks to the

TTL.

This simulation result corresponds with the ana-

lytical expresssion presented in (Sui et al., 2003). Ad-

ditionnaly, we represent the the average number of

connections that a node routes without using a TTL

limit. We observe than if p is greater than 0.9 the

number of connections goes up quickly. As a con-

clusion, a value of p = 0.8 is a trade off solution

DISTRIBUTED PATH RESTORATION ALGORITHM FOR ANONYMITY IN P2P FILE SHARING SYSTEMS

0 20 40 60 80 100 120 140 160

2000

4000

6000

8000

10000

12000

Time (h)

Number of Errors by Hour

Figure 7: Number of request that cannot be carry out in an

hour because at least one node in the download path is out.

0 20 40 60 80 100 120 140 160

x 10

Time (h)

Number of Messages by Hour

Figure 8: Average number of control messages in function

of time.

between anonymity efﬁcience, extra bandwith con-

sumption and nodes overload.

In the results represented in Figure 7 our system

doesn’t implement the reliability mechanism. The

parameters used in the simulatons corresponds to a

typical scenario: TTL = 10 and p = 0.7. It shows

the number of requests that cannot be carry out in an

hour because, at least one node in the download path

is down when the download is performed. This re-

sult is represented in funcion of time (in hours). This

number ﬂuctuates around 11,000.

Therefore, it is clear than in a real anonymous P2P

network (with unpredictable node failures) it is nec-

essary to suply a mechanism to reconstruct efﬁciently

the paths, although it entails an extra network over-

head in terms of control packets.

In our network, a download process never fails

since it is a reliable anonymous P2P network, but this

feature involves an extra control trafﬁc. Figure 8 rep-

resents the average number of control messages in

function of time, in the previous scenario. Initially,

due to simulation constraints, the timeout timer ex-

pires simultaneously in a lot of nodes, but in steady

state the average number of control messages is under

40,000.

Usually, control messages have a small payload

(about 10 bytes) and a IP/TCP header (40 bytes). If

we suppose each control message has a length of 50

bytes, control trafﬁc supposes only a 4.4 kbps trafﬁc

rate.

6 CONCLUSION

In this paper, we have proposed anonymity mecha-

nisms for a hybrid P2P network presented in a pre-

vious work. Unfortunately, the mechanisms to pro-

vide anonymity entails extra bandwidth conssump-

tion, extra nodes overload and extra network overhead

in terms of control trafﬁc. The simulations tries to

evaluate the costs to provide anonymity in a real P2P

scenario (with unpredictable node failures). As a con-

clusion, our proposal achieves mutual anonymity only

with an extra bandwith consumption corresponding to

5 hops, 3 connections by node and a 4.4 kbps con-

trol trafﬁc rate (in a typical scenario TTL = 10 and

p = 0.7).

ACKNOWLEDGEMENTS

This work has been supported by the Spanish Researh

Council under project ARPaq (TEC2004-05622-C04-

02/TCM). Juan Pedro Mu

noz-Gea thanks the Spanish

MEC for a FPU (AP2006-01567) pre-doctoral fellow-

ship.

REFERENCES

Castro, M., Druschel, P., Kermarrec, A., and Row-

stron, A. (2002). Scribe: A large-scale and de-

centralized application-level multicast infrastructure.

IEEE Journal On Selected Areas in Communications,

20(8):100–110.

Dingledine, R., Mathewson, N., and Syverson, P. (2004).

Tor: The second-generation onion router. In Proceed-

ings of the 13th USENIX Security Symposium, San

Diego, CA, USA.

Freedman, M. and Morris, R. (2002). Tarzan: A peer-to-

peer anonymizing network layer. In Proceedings of

the 9th ACM Conference on Computer and Communi-

cations Security (CCS’02), Washington, DC, USA.

ICSOFT 2007 - International Conference on Software and Data Technologies

Ghodsi, A., Alima, L., El-Ansary, S., Brand, P., and Haridi,

S. (2003). Dks(n,k,f): A family of low communica-

tion, scalable and fault-tolerant infrastructures for p2p

applications. In Proceedings of the 3rd. International

Workshop on Global and P2P Computing on Large

Scale Distributed Systems (CCGRID 2003), Tokyo,

Japan.

Han, J., Liu, Y., Xiao, L., Xiao, R., and Ni, L. M. (2005). A

mutual anonymous peer-to-peer protocol design. In

Proceedings of the 19th International Parallel and

Distributed Processing Symposium (IPDPS’05), Den-

ver, CO, USA.

Levine, B. N. and Shields, C. (2002). Hordes: A multicast-

based protocol for anonymity. Journal of Computer

Security, 10(3):213–240.

Li, J., Stribling, J., Morris, R., and Kaashoek, M. F. (2005).

Bandwidth-efﬁcient management of dht routing ta-

bles. In Proceedings of the 2nd USENIX Sympo-

sium on Networked Systems Design and Implementa-

tion (NSDI’05), Boston, MA, USA.

Lu, T., Fang, B., Sun, Y., and Cheng, X. (2004). Wongoo:

A peer-to-peer protocol for anonymous communica-

tion. In Proceedings of the 2004 International Con-

ference on Parallel and Distributed Processing Tech-

niques and Appliations (PDPTA 2004), Las Vegas,

NE, USA.

Mislove, A., Oberoi, G., A. Post, C. R., and Druschel, P.

(2004). Ap3: Cooperative, decentralized anonymous

communication. In Proceedings of the 11th work-

shop on ACM SIGOPS European workshop: beyond

the PC, New York, NY, USA.

noz-Gea, J. P., Malgosa-Sanahuja, J., Manzanares-

Lopez, P., Sanchez-Aarnoutse, J. C., and Guirado-

Puerta, A. M. (2006). A hybrid topology architecture

for p2p ﬁle sharing systems. In Proceedings of the

First International Conference on Software and Data

Technologies (ICSOFT 2006), Set

ubal, Portugal.

Pﬁtzmann, A. and Hansen, M. (2001). Anonymity, unob-

servability and pseudomyity: a proposal for terminol-

ogy. In Proceedings of the Fourth International Infor-

mation Hiding Workshop, Pittsburgh, PE, USA.

Ratnasamy, S., Francis, P., Handley, M., Karp, R., and

Shenker, S. (2001a). A scalable content-addressable

network. In Proceedings of ACM SIGCOMM, San

Diego, CA, USA.

Ratnasamy, S., Handley, M., Karp, R., and Shenker, S.

(2001b). Application-level multicast using content-

addressable networks. In Proceedings of the 3rd. In-

ternational Workshop of Networked Group Communi-

cation (NGC), London, UK.

Reed, M. G., Syverson, P. F., and Goldshlag, D. M.

(1998). Anonymous connections and onion routing.

IEEE Journal on Selected Areas in Communications,

16(4):482–494.

Reiter, M. K. and Rubin, A. D. (1999). Crowds: Anonymity

for web transactions. Communications of the ACM,

42(2):32–48.

Rowstron, A. and Druschel, P. (2001). Pastry: Scalable,

decentralized object location and routing for large-

scale peer-to-peer systems. In Proceedings of the

IFIP/ACM International Conference on Distributed

Systems Platforms (Middleware), Heidelberg, Ger-

many.

Stoica, I., Morris, R., Liben-Nowell, D., and Karger, D.

(2003). Chord: A scalable peer-to-peer lookup proto-

col for internet applications. IEEE/ACM Transactions

on Networking, 11(1):17–32.

Sui, H., Chen, J., Che, S., and Wang, J. (2003). Pay-

load analysis of anonymous communication system

with host-based rerouting mechanism. In Proceed-

ings of the Eighth IEEE International Symposium on

Computers and Communications (ISCC’03), Kemer-

Antalya, Turkey.

Wright, M., Adler, M., Levine, B. N., and Shields, C.

(2002). An analysis of the degradation of anonymous

protocols. In Proceedings of the Network and Dis-

tributed Security Symposium (NDSS’02), San Diego,

CA, USA.

Xiao, L., Xu, Z., and Shang, X. (2003). Low-cost and reli-

able mutual anonymity protocols in peer-to-peer net-

works. IEEE Transactions on Parallel and Distributed

Systems, 14(9):829–840.

DISTRIBUTED PATH RESTORATION ALGORITHM FOR ANONYMITY IN P2P FILE SHARING SYSTEMS
