A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING
Youssef Bououlid Idrissi and Julie Vachon
DIRO, University of Montreal
Montreal, Quebec, H3C 3J7, Canada
Keywords:
Context analysis, semantic alignment, linguistic matching, data source integration.
Abstract:
As currently implemented by most data mapping systems, linguistic matching often boils down to string
comparison or to a synonym look-up in a dictionary. But these solutions have proved to be inefficient for
dealing with highly heterogeneous data sources. To cope with data source heterogeneity more efficiently, we
introduce INDIGO, a system which computes semantic matching by taking into account data sources’ context.
The distinctive feature of INDIGO consists in enriching data sources with semantic information extracted
from their individual development artifacts before mapping them. As explained in this article, experiments
conducted on two case studies proved the relevance of this approach.
1 INTRODUCTION
Considering their omnipresence in matching solutions
(Noy and Musen, 2001; Hu et al., 2006; J. Madhavan
and Rahm, 2001; Euzenat and et. al, 2004), linguistic
matching strategies deserve to be further developed
and improved. Current strategies commonly resort
to two main evaluation techniques: (1) string com-
parison metrics and (2) lexical similarity functions.
String metrics compare concept names according to
their string characteristics (e.g. number of shared
characters, similar string lengths, etc.). As for lexi-
cal functions, they assess similarity between concept
names rather by comparing their respective meanings.
Hence, each concept name is looked up in some exter-
nal dictionary (e.g. WordNet) in order to extract the
set of words that are semantically related to it (e.g. by
synonymy, hyponymy, etc.). But in practice, unfortu-
nately, neither string metrics nor lexical-based func-
tions prove to be robust matching techniques when
data sources to be aligned are very heterogeneous. In
particular, lexical-based functions rarely perform well
since general dictionaries on which they rely do not
consider domain specificities and can even muddle up
matching with irrelevant synonyms or homonyms. A
reference to the context is often mandatory to clear
up ambiguities. Hence, this article introduces IN-
DIGO
1
, a system which implements an innovative so-
lution based on the exploration of the data sources’
informational context. The informational context of
a data source is composed of all the available textual
and formal artifacts documenting, specifying, imple-
menting this data source. It therefore conceals pre-
cious supplementary information which can provide
useful insights about the semantics of data sources’
concepts.
INDIGO distinguishes two main sets of documents
in the informational context (cf. (Bououlid and Va-
chon, 2005)). The first set, called the descriptive con-
text, gathers all the available data source specification
and documentation files produced during the different
development stages. The second set is called the op-
erational context. It is composed of formal artifacts
such as programs, forms or XML files. To get con-
textual semantic information, INDIGO focuses on the
first set of documents i.e. the descriptive context
2
.
Given their descriptive nature, these documents are
more likely to reveal concept names semantically re-
lated to the ones found in the data sources. INDIGO
explores the descriptive context to extract the words
1
INteroperability and Data InteGratiOn
2
The operational context is explored for other purposes,
such as for elaborating complex matching (Bououlid and
Vachon, 2007).
197
Bououlid Idrissi Y. and Vachon J. (2007).
A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING.
In Proceedings of the Second International Conference on Software and Data Technologies - Volume ISDM/WsEHST/DC, pages 197-202
DOI: 10.5220/0001345601970202
Copyright
c
SciTePress
found in the vicinity of some data source concept
name found within a phrase in a document. These
neighboring words will be useful to evaluate similar-
ity between concepts. Extracted words are integrated
and related to their corresponding concept in the data
source. In INDIGO, this enhancement of a data source
with information gathered from its context is called
data source enrichment.
To show the benefits of data source enrichment,
INDIGO was compared to two well-known matching
approaches, that is Similarity Flooding (Melnik et al.,
2002) and V-Doc (Y. Qu and Cheng, 2006). The ex-
periment consisted in applying each matching sys-
tem over the two following case studies: (1) Match-
ing of two database schemas taken from two open-
source e-commerce applications: Java Pet Store (Mi-
crosystems, 2005) and eStore (McUmber, 2003) and
(2) Matching of two real data sources describing
courses taught at Cornell University and at the Uni-
versity of Washington.
The rest of the paper is organized as follows. Sec-
tion 2 surveys recent work on linguistic matching.
Section 3 describes the current implementation of IN-
DIGOs Context Analyzer and Mapper modules. Ex-
perimental results of our two case studies are pre-
sented and commented in Section 4. Concluding re-
marks and comments on future work are given in Sec-
tion 5.
2 RELATED WORK
As pointed out in section 1, there are essentially
two categories of techniques for linguistic matching:
string comparison metrics and lexical-based match-
ing methods. Concerning string metrics, the most
popular are certainly the following (Euzenat and et.
al, 2004): Levenstein, Needleman-Wunsch, Smith-
Waterman, Jaro-Winkler and Q-Gram. As for lexical-
based metrics, they were mostly developed within
the framework of specific mapping systems such as
ASCO (B.T. Le and Gandon, 2004) and HCONE-
merge (K. Kotis and Stergiou, 2004) to serve their
own application objectives. Both of these systems
resort to WordNet to collect additional semantic in-
formation (sets of words) about the concept to be
matched. For instance, ASCO searches for synonyms
while HCONE-merge looks for hyponyms.
Among the numerous linguistic matching solu-
tions mentioned in the literature, we had a closer
look at two systems frequently cited by researchers
for their performances and which were available on
the net: Similarity Flooding (SF)(Melnik et al., 2002)
and V-Doc (Y. Qu and Cheng, 2006). We selected
those two applications to experimentally compare
them with our own system INDIGO.
Similarity Flooding (SF) is a generic algorithm
used to match different kinds of data structures
called models. Models can be composed of data
schemas, data instances or a combination of both.
The SF algorithm converts both source and tar-
get models into some proprietary labeled directed
graph representation (G
1
and G
2
). It then applies
an iterative fixed point based procedure over these
two graphs to discover matches between their re-
spective nodes.
V-Doc is the linguistic matching module of Falcon-
AO (Hu et al., 2006), a matching system for on-
tologies. V-Doc constructs for each entity in the
ontologies to be aligned, a virtual document con-
sisting in a set of words extracted from the name,
label and comment fields of the entity and of its
neighbors within the ontology. It then compares
virtual documents using the well-known TF/IDF
3
technique.
INDIGO aims at the same objectives as the above
systems. From a conceptual standpoint, it belongs to
the category of systems relying on multiple strategic
matchers (A. Doan and Halevy, 2003; Do and Rahm,
2002). It distinguishes itself by taking into account
the informational context of data sources in its align-
ment process.
3 INDIGO’S ARCHITECTURE
To handle both context analysis and semantic match-
ing, INDIGO presents an architecture composed of
two main modules: a Context Analyzer and a Map-
per module. The Context Analyzer module takes the
data sources to be matched along with related context
documents and proceeds to their enrichment before
delivering them to the Mapper module for their effec-
tive matching.
3.1 Context Analyzer
The role of the Context analyzer consists in parsing
the artifacts related to a data source with the aim to
extract pertinent semantic information and to enrich
this data source with it. Our implementation targets
two types of enrichment: (1) enhancement of a data
source with complex concepts
4
and (2) enhancement
3
Term frequency/Inverted Document frequency.
4
This kind of enhancement will not be discussed in this
article because it is not directly involved in linguistic match-
ing (c.f. (Bououlid and Vachon, 2007) for details).
ICSOFT 2007 - International Conference on Software and Data Technologies
198
of a data source with related concept names. To be
more specific about the semantics of a given concept,
the descriptive context is searched for entities which
may relate to this concept. The following heuristics
is proposed to identify these relations: ”Two concepts
that are often brought up one near the other are likely
to be closely related.
Name
Product
PetStore
Supplier
Order
Figure 1: Graph of dependencies between concepts of the
Pet Store application.
In the Pet Store application (our first case study),
the database model reveals that name is an attribute
of the product entity. In other respects, documen-
tation files clearly show that order and supplier are
concepts frequently appearing in the vicinity of the
product concept. For each concept referenced by path
s in the XML data source, a graph is constructed to
trace presumed dependencies between concepts. We
call such a graph a concept dependency graph (CDG).
Let s be the XML path of a concept in the data source
and let Concepts(s) be the set of concepts composing
s. A CDG for s is a graph that
1. links each c Concepts(s) to its successor c
in s
(with c
Concepts(s)). The position of a concept
in the list thus obtained is called its level.
2. links each c Concepts(s) to a list elist(c)
of enrichment concepts extracted from the data
source’s context. The position of a concept in
elist(c) is called its rank.
Figure 1 shows a CDG stressing the connection
of the product concept with its name attribute and the
Pet Store database to which it belongs. These con-
cepts are vertically ordered on the figure. The CDG
also shows the relation of product with two enriching
concepts, order and supplier, which were often found
close by in the data source’s context. These concepts
appear horizontally ordered.
The design of INDIGOs Context Analyzer (Fig-
ure 2) comprises two main modules, each being spe-
cialized in a specific type of information extraction.
To be specific, it is composed of a Concept Name Col-
lector and a Complex Concept Extractor, providing
the necessary support for the two kinds of enhance-
ment mentioned previously.
enhancer
Concept name
Context
generatorpreprocessor
Context
Complex concept
collector
Concept name
analyzer
Meta−
extractor
Figure 2: Architecture of the Context Analyzer.
As illustrated on Figure 2, these two analyzer
modules are headed by a meta-analyzer which coor-
dinates their respective tasks. At the lowest level, the
architecture provides utility modules to pre-process,
generate and enrich data sources with context infor-
mation.
3.1.1 Meta-analyzer
This module explores the set of documents constitut-
ing the informational context of the data source. It
classifies each of them into either the formal or infor-
mal category. Then it addresses formal documents to
the Complex Concept Extractor and informal ones to
the Concept Name Collector.
3.1.2 Concept Name Collector
Given a concept name of a data source, the Collec-
tor gathers from the descriptive context all names fre-
quently surrounding it. The Collector chooses then
the closest ones to enrich the concept name with them.
Actually, the Collector executes the data source en-
richment process in two main stages: a context pre-
processing step followed by a data source enhance-
ment procedure.
Context preprocessing. The Collector relies on
two internal modules respectively named Context
Preprocessor and Context Generator to generate what
we called the contextualized concept file of a data
source (abbreviated CC-file). This file is written in
XML. For each concept name in the data source, it
gathers a set of nouns surrounding the concept in the
data source’s context documents. These nouns are
saved by the CC-file in some normalized form which
prevents that a single concept appearing in different
guises (e.g. inventory and inventories) be considered
as two distinct nouns. Let us consider the Pet Store
application for example, whose database contains a
table named SKU (i.e. Stock Keeping Unit). The
Context Preprocessor will thus parse the set of doc-
uments it was addressed and will gather all sentences
A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING
199
containing the concept name SKU. Sentences are then
filtered by the Context Generator to keep noun-type
words in their normalized form. The order in which a
word first appears in a sentence is of course preserved.
SKU inventory item...
...store instance SKU inventory...
...item SKU.
1
K=2
PetStore
SKU
1
1
2
2
1
Inventory
Item
Figure 3: Enhancement of the SKU concept (generation of
the corresponding part of the CDG).
Data source enhancement. The CC-file elaborated
during the previous step is used by a third internal
module of the Collector, called Concept Name En-
hancer, to generate a CDG for each data source con-
cept. Let us consider the enhancement of the SKU
concept. Over each sentence of the CC-file relating
to SKU, the Concept Name Enhancer applies a po-
sition marker which tags each name surrounding the
SKU word with a distance value. This value indicates
how many names separate the tagged name from the
word SKU, be it on the left or on the right. The left
part of Figure 3 shows the tagging process. From
there on, each tagged name is collected together with
its distance tag and its frequency rate. Tagged names
are sorted in descending order of frequency rates and
proximity to SKU. Best candidates are retained to en-
rich the SKU concept. A threshold value is used to
limit the number of enriching concepts to be kept.
In the previous example, given a threshold K=2, the
names item and inventory are retained to enrich the
SKU concept and are thus added to SKUs CDG.
3.2 Mapper Module
After the enhancement of data sources with the newly
extracted information, the Mapper module proceeds
to the matching phase. Allowing for multiple match-
ing strategies, its architecture is organized as a hier-
archy of modules where internal nodes are called co-
ordinators and where leaves represent aligners. Each
aligner implements a specific matching strategy based
on a particular similarity measure. For instance, a
name-based aligner can be used to compute matches
between concepts according to the similarity of their
names. As for coordinators, they combine predic-
tions of their respective children to elaborate their
own matching proposal.
3.3 Context-based Alignment
Context-based alignment is executed as follows. First,
a mapping is computed between two given data
sources without considering their context. Then,
for each pair of concepts a context similarity factor
(CSF) is assessed by comparing their respective CDG
(cf. Section 3.1). The CSF is a normalized value be-
tween 0 and 1 which is used to rate the augmentation
of concepts’ similarity by taking into account the sim-
ilarity of their respective context.
To show how a CSF is calculated, let us consider
the respective CDG of a source and of a target con-
cept, SN and TN, as illustratred on Figure 4. SN
ij
(resp. TN
ij
) denotes the concept occupying level i
and enrichment rank j in the CDG of the source con-
cept (resp. target concept). Each row of a CDG
denotes a context level, while each column denotes
a concept ranking regarding relevance to the context
(recall that rank 1 denotes the most relevant concept).
The evaluation of the CSF between SN and TN is as
follows.
First, we split up equally each list of enrichment
concepts into some predefined number of subsets.
Figure 5 depicts the splitting, into w boxes, of the en-
richment concepts in a CDG. On a same level, boxes
should contain almost the same number of enrichment
concepts. Considering there are p
i
concepts on level i
and that p
i
= wk
i
+r
i
, the first r
i
boxes will therefore
contain k
i
+ 1 =
p
i
/w
concepts while the follow-
ing w r
i
others will have k
i
of these. Let SB
i
, with
i {1, ...,w}, denote the i
th
box in a source concept’s
CDG. SB
i, j
thus corresponds to the set of enrichment
concepts of level j in box SB
i
. Note that the CDG
of the target concept, illustrated on Figure 4, has been
splitted up exactly the same way as the CDG of the
source concept. Then, similarity between boxes SB
i
s
and TB
i
t
, where i
s
,i
t
{1,..., w}, is given by the fol-
lowing formula:
BoxSim(SB
i
s
,TB
i
t
) =
min(n,m)
l=1
λ
l
Inter(SB
i
s
,nl+1
,TB
i
t
,ml+1
)
min(n,m)
l=1
λ
l
Inter(SB
i
s
,nl+1
,TB
i
t
,ml+1
) is a function return-
ing 0 if SB
i
s
,nl+1
TB
i
t
,ml+1
is empty, and returning
1 otherwise. λ is a positive constant, superior to one,
which is empirically settled.
Finally, the context similarity factor (CSF) evalu-
ated between the respective CDG of a source and of
a target concept is given by the following formula:
CSF =
w
i=1
α
w−|in(i)|
BoxSim(SB
i
,TB
n(i)
)
wα
w
where n(i) is the nearest target box index to i such as
BoxSim(SB
i
,TB
n(i)
) 6= 0.
ICSOFT 2007 - International Conference on Software and Data Technologies
200
SN
SN
SN
SN
...
...
...
...
SN
n 1
n−1 1
1 1
n 2
n−1 p
n
n p
SN
n−1
SN
1 p
1
SN
n−1 2
SN
1 2
TN
TN
TN
TN
TN
TN
...
...
...
...
TN
m 1
m−1 1
1 1
m 2
m−1 2
1 2
m q
m
TN
m−1 q
m−1
1
1 q
TN
Figure 4: CDG of a source and of a target name.
SN
SN
SN
SN
SN
SN
SN
SN
SN
SN
SN
n−1 1
n 1 n 2
n−1 2
n
n−1
n−1 2*k
n−1 (w−1)*k+2
n (w−1)*k+2
n p
SN
n−1 k
SN
n k
SN
n−1 k +1
n−1
n
SN
n k +1
SN
n k +2
n
SN
n−1 k +2
n−1
n
n 2*k
n−1
SN
n−1 p
n−1
n
n−1 (w−1)*k+1
n
n (w−1)*k+1
n−1
n
n−1
...
...
...
...
...
...
...
...
...
SN SN
SN
SN
SN
SN
SN
SN
1 1
1 2
1 k+1
1 (w−1)*k+2
1 p
1 (w−1)*k+1
1 k
1 1
SN
1 k +2
1
1 2*k
1
1
1 1
...
...
...
...
Figure 5: Splitting of a concept name’s CDG.
4 TESTS AND EVALUATION
Two types of tests have been targeted: (1) the impact
of contextualization on linguistic matching and (2) the
comparison of INDIGO with the state of the art.
4.1 Impact of Contextualization
For this experiment, the Mapper was configured with
ve name-based aligners, that is one for each of the
ve well-known string metrics (i.e. Jaro-Winkler,
Smith-Waterman, Levenshtein, Needleman- Wunch
and Q-Gram) mentioned in section 2. Each aligner
was individually tested on the first case study, i.e. the
mapping of the PetStores data source over eStores,
with and without contextualization being taken into
account. Table 1 describes the results obtained when
fixing the enrichment threshold to K = 30 and the
context splitting parameter to w = 5. The two con-
stants λ and α were respectively set to 4 and 2. Re-
sults show that data sources contextualizing has a pos-
itive impact on the performance of name-based align-
ers. In the case of the QGram distance, the f-measure
of the alignment process increased by 127%.
4.2 Comparison with Other Semantic
Matching Systems
INDIGO was confronted with both the Similarity
Flooding algorithm and the V-Doc System. For this
experiment, the Mapper module was configured with
a single matching strategy, namely a sole aligner
based on the JaroWinkler metric. Each system was
executed over the two case studies thus computing:
(1) the mapping of the PetStores data source over eS-
tores and (2) the mapping of course data source of
Cornell university over the one of Washington uni-
versity. To be precise, two versions of the second
case study were experimented on: a version over re-
duced course data sources and the original one. Cor-
responding test results are summarized in Table 2. In
particular, the two last rows present the results ob-
tained with INDIGO for both (1) non context-based
and (2) context-based alignments.
In all alignment tests, INDIGO succeeded in im-
proving its performance thanks to contextual data
source enrichment. It did not globally surpass all the
other systems but managed to get very close to the
best one (i.e. SF) thanks to data source contextualiza-
tion. Indeed, INDIGOs global performance was in-
creased by 14% with contextualization, what brought
it close to SF’s results by less than 1.8%. Finally, it
is worth noting that INDIGO did surpass all the other
systems in the PetStore/eStore case study thanks to
data source contextualization. This proves that IN-
DIGOs context-based approach is particularly use-
ful for matching data sources that are very heteroge-
neous.
A CONTEXT-BASED APPROACH FOR LINGUISTIC MATCHING
201
Table 1: Performance variations due to data source contextualization observed in the mapping of PetStores data source over
eStores using INDIGO.
Non context-based Context-based Variation
prec. rec. f-m. prec. rec. f-m. prec. rec. f-m.
Jaro-Winkler 44.44 13.79 21.04 31.11 20.9 25 30% +51% +19%
Smith-Waterman 34.78 18.39 24.05 39.62 24.14 30.00 +14% +31% +25%
Levenshtein 48.15 14.94 22.80 53.85 16.09 24.77 +16% +7% +10%
Needleman-Wunch 43.75 8.05 13.59 23.91 12.64 16.53 45% +57% +22%
Q-Gram 66.67 9.20 16.17 60.53 26.44 36.80 9% +187% +127%
Table 2: Comparison of INDIGOs performance with Similarity Flooding and the V-Doc matching results.
PetStore/eStore mini-cornell/mini-washington cornell/washington average
prec. rec. f-m. prec. rec. f-m. prec. rec. f-m. prec. rec. f-m.
SF 41.66 14.92 21.97 1.0 79.41 88.52 60.0 72.22 65.54 34.22 55.51 58.67
V-Doc 66.66 2.98 5.71 65.62 61.76 63.63 17.36 46.29 25.25 49.88 37.01 31.53
Indigo(1) 44.44 13.79 21.04 83.87 78.79 81.85 34.51 73.58 46.99 54.27 55.38 49.96
Indigo(2) 31.11 20.9 25 84.38 81.82 83.08 58.06 67.92 62.61 57.85 56.88 56.9
5 CONCLUSIONS
This paper presents INDIGO, an innovative solution
to linguistic matching. INDIGO relies on an architec-
ture composed of two main modules: a Context An-
alyzer and a Mapper module. The Context Analyzer
enriches data sources with semantic information ex-
tracted from artifacts belonging to their respective en-
vironments before delivering them to the Mapper for
their effective alignment. Tests conducted over two
case studies proved that data source contextualizing
can improve the alignment process performance. In
particular, INDIGO was compared to two renowned
matching systems in the domain and outperformed
them in the case of data source candidates presenting
higher heterogeneity.
REFERENCES
A. Doan, P. D. andHalevy, A. (2003). Learning to match the
schemas of data sources : a multistrategy approach.
Journal of Machine Learning, 50(3):279–301.
Bououlid, I. and Vachon, J. (2005). Context analysis
for semantic mapping of data sources using a multi-
strategy machine learning approach. In Proc. of the In-
ternational Conf. on Enterprise Information Systems
(ICEIS05), pages 445–448, Miami.
Bououlid, I. and Vachon, J. (2007). A context-based ap-
proach for for complex semantic matching. In Proc.
of CAiSE-Forum, Trondheim, Norway.
B.T. Le, R. D.-K. and Gandon, F. (2004). On ontology
matching problems - for building a corporate seman-
tic web in a multi-communities organization. In Proc.
of the Int. Conf. on Enterprise Information Systems
(ICEIS), volume 4, pages 236–243.
Do, H. and Rahm, E. (2002). Coma: a system for flexible
combination of schema matching approaches. In Pro-
ceedings of the 28th Conf. on Very Large Databases.
Euzenat, J. and et. al (2004). State of the art on ontology
alignment. part of a research project funded by the
ist program of the commission of the european com-
munities. Technical Report project number IST-2004-
507482, Knowledge Web Consortium.
Hu, W., Cheng, G., Zheng, D., Zhong, X., and Qu, Y.
(2006). The results of falcon-ao in the oaei 2006 cam-
paign. In International Workshop on Ontology Match-
ing.
J. Madhavan, P. B. and Rahm, E. (2001). Generic schema
matching using cupid. In In Proceedings of the 27th
VLDB Conference, pages 48–58, Roma, Italy.
K. Kotis, G. V. and Stergiou, K. (2004). Capturing seman-
tics towards automatic coordination of domain ontolo-
gies. In Artificial Intelligence: Methodology, Systems,
and Applications, volume 3192 of LNCS, pages 22–
32.
McUmber, R. (2003). Developing pet store using rup and
xde. Web Site.
Melnik, S., Garcia-Molina, H., and Rahm, H. (2002). Sim-
ilarity flooding: a versatile graph matching algorithm
and its application to schema matching. In Proc. Inter-
national Conference on Data Engineering (ICDE’02),
pages 117–128.
Microsystems, S. (2005). Java petstore. Web Site.
Noy, N. and Musen, M. (2001). Anchor-prompt: Using
non-local context for semantic matching. In In Proc.
IJCAI 2001 workshop on ontology and information
sharing, pages 63–70, Seattle (WA US).
Y. Qu, W. H. and Cheng, G. (2006). Constructing virtual
documents for ontology matching. In Proceedings of
the 15th International World Wide Web Conference.
ICSOFT 2007 - International Conference on Software and Data Technologies
202
