USING RULE-BASED ENGINE TO SUPPORT TEST

VALIDATION MANAGEMENT OF COMPLEX

SAFETY-CRITICAL SYSTEMS

Valentina Accili, Giovanni Cantone

Dip. di Informatica, Sistemi e Produzione, Università di Roma Tor Vergata, Via del Politecnico 1, 00133, Rome, Italy

Christian Di Biagio, Guido Pennella

MBDA-Italy spa, Via Tiburtina km 12,400, 00131 Rome, Italy

Fabrizio Gori

Eisys S.p.A., via Torre Rigata 5, 00131 Rome, Italy

Keywords: Automatic Validation, Validation Rule, Automatic Software Test, Distributed and parallel systems.

Abstract: Testing and validating software components in distributed architecture environments are critical activities

for our reference company, where those activities have been performed in a non-automatic way up to now,

so spending time and human resources. As a consequence, we were charged to design and construct a

flexible system, the Automated Test Manager (ATM), for the automatic software testing and automatic

validation of test results. In this paper we focus on the subsystem ATM-Console that handles the validation

aspect of the ATM system. This subsystem reuses an Open Source Rule-based Engine, which is able to meet

our purposes. Based on results from a case study, the paper reports that introducing the ATM-Console in

field could very significantly improve the efficiency of test validation.

1 INTRODUCTION

The reference company for this paper develops

safety-critical systems. We have are involved with

the need of that company to improve the correctness,

completeness, consistency, security, and quality of

the software part of those systems.

Because the architecture utilized company-wide

is based on multiple distributed and parallel

subsystems, the test and validation process could be

not deterministic and involve very heavy jobs,

especially if testing is accomplished and managed

without automatic supports.

Automated Test Manager (ATM) is our answer

to some of those needs. ATM is a distributed

software system designed and developed to

automatically test and validate real distributed

systems. ATM is built on two main subsystems, as

in the followings:

• ATM - Common Core (Grillo, 2007), which

aims to test automatically the interactions

that occur between the real components of

the system by simulating the behavior of

some of those components.

• ATM - Console, which is in the focus for

this paper. This subsystem takes care of the

remote control of automated test sessions,

and validation management. ATM-Console

provides the function of an at-once

validation configuration: through a user-

friendly GUI it is possible to edit the Rules

that will train the validation process, which

a Rule-based Engine will execute (JBoss,

2006).

Based on the needs placed by the enactors of the

current non-automatic software validation process,

the goals of this paper are twofold: (i) To sketch on

the subsystem ATM - Console, as developed to

perform an automatic software test validation, and

136

Accili V., Cantone G., Di Biagio C., Pennella G. and Gori F. (2007).

USING RULE-BASED ENGINE TO SUPPORT TEST VALIDATION MANAGEMENT OF COMPLEX SAFETY-CRITICAL SYSTEMS.

In Proceedings of the Second International Conference on Software and Data Technologies - PL/DPS/KE/WsMUSE, pages 136-143

DOI: 10.5220/0001349901360143

 SciTePress

(ii) To provide a remote control for the other ATM

component, which is in the responsibility of

performing the test.

In the remaining of the present paper, Section 2

analyzes previous work on automatic software

validation, Section 3 describes the adopted method

to perform automatic validation, Section 4 presents

the architecture and the functionalities of the ATM-

Console. Section 5 shows results from a case study,

which involved the ATM-Console. Some final

remarks and forward to future work conclude the

paper.

2 RELATED WORK

Such as other authors (Liu, Yang, Wang, 2005)

(Min, Yang, Wang, 2006), we propose an automatic

expert system-like validation subsystem: the

validation activity is based on a Validation

Knowledge Base, which is divided in three parts:

• Validation Data Knowledge Base, which is

built by parsing test results. Knowledge is

arranged as an object-oriented knowledge

representation (S. Walczak, 1998) (Liu,

Yang, Wang, 2005).

• Validation Rules Knowledge Base, which is

composed by validation rules as provided

by end-users.

• Validation Techniques Knowledge Base,

which is in the responsibility of

determining whether the validation activity

was or was not successful.

Our approach substantially differs from the

others known from the literature (Liu, Yang, Wang,

2005) (Min, Yang, Wang, 2006). We perform

automatic test and validation on real distributed and

parallel systems to verify if their components run

properly. Instead those other approaches validate

distributed simulation systems, i.e. they test the

credibility of their simulation model; in fact, they

also provide an automatic tool, but use it to compare

the outputs from a simulator with the corresponding

outputs from the real system.

The originality of this paper consists in the

novelty of using a Rule-based Engine as the

“Validator” (Liu, Yang, Z. Wang, 2005): given the

Validation Data Base and the Validation Rules Base,

our ATM-Console is able to detect which validation

rules are actually verified by matching the given

Validation Rules with Validation Data.

3 A RULE-BASED ENGINE FOR

AUTOMATED VALIDATION

It involves complex verifications, like checking the

periodical transmission of a message, to enact

automated validation of functional tests in

distributed, interactive, and real time systems. So

our decision was to use a Rule-based Engine to

achieve the automatic validation activity.

A Rule Engine can be viewed as a sophisticated

interpreter of logical implications: in fact, it

evaluates and executes rules that are expressed in

terms of if-then statements.

The power of those rules lies both in their ability

to separate knowledge from its implementation

logic, and in the fact that we can change those rules

without having to act on artifacts in source code.

It dictates a Java runtime API for rule engines,

the specification for the Java Rule Engine API (JSR

94) (Sun, 2005), as developed by the Java

Community Process (JCP) program. In fact, such an

API provides a simple means to access a rule engine

from an up to date Java Platform.

Drools (JBoss, 2006), Fair Isaac Blaze Advisor

(Fair Isaac, 2007), ILOG JRules (ILOG, 2007), and

Jess (Sandia, 2007) are instances of JSR 94

compliant rule engines. ATM-Console adopts JBoss'

Drools (Dynamic Rule Object-Oriented Language

System) rule engine (JBoss, 2006), because it is a

solid inference engine, completely Open Source,

well documented, and with an Eclipse plug-in,

which is useful for debugging.

Drools uses the Rule Based approach to

implement an Expert System; more correctly, it is

classified as a Production Rule System, which

focuses on knowledge representation to express

propositional and first order logic in a concise, non-

ambiguous, and declarative manner. The “brain”

(JBoss, 2007) of such a Production Rules System is

an Inference Engine. In order to infer conclusions,

which result in actions, this inference engine

matches facts, the data, against the Production Rules

(also called Productions or just Rules in the

followings). A Rule, in Drools, is a twofold structure

with Left (LHS) and Right (RHS) Hand Sides.

The syntax for a rule is:

when

then

<action>;

When the condition is met, the action is

executed. As already mentioned, first order logic is

USING RULE-BASED ENGINE TO SUPPORT TEST VALIDATION MANAGEMENT OF COMPLEX

SAFETY-CRITICAL SYSTEMS

137

used for representing a c ondi ti on . Multiple

conditions (and/or actions) can be utilized in a

when

construct (and its

then part).

The inference engine performs Pattern Matching,

i.e. the process of matching new or existing facts

against rules. There is a number of algorithms that

inference engines can use for pattern matching,

including: Rete (Forgy, 1982), Treat (Miranker,

1990), Leaps (Don Batory, 1994). The Drools tool

implements both Leaps and Rete, but ATM-Console

is based on the latter (Forgy, 1982).

The Production Memory stores the rules, and the

Working Memory stores the facts that the inference

engine matches against. Facts are asserted into the

Working Memory where they may then be modified

or retracted.

The reference environment supports a large

number of rules and facts, and conflicting rules

could occur. Agenda is the name that Rete gives to

the component that manages the execution order of

the conflicting rules, if any is active, by using a

Conflict Resolution Strategy. When a Rule is

activated, it is placed onto the Agenda for potential

future execution. It is called the Consequence of a

rule, the set of actions that the rule’s RHS includes.

The engine operates recursively in a 2-phases

mode:

• Working Memory Actions, which define

where most of the work takes place. There

are two loci for such an Action: the main

Java application process, and the

Consequence set. Once a Consequence has

finished or the main Java application

process invokes the method

fireA ll Ru les () , the engine switches to

the next phase.

• Agenda Evaluation, which attempts to

select a rule to fire, whether such a rule is

not found yet, but it might still exit;

otherwise it switches the phase back to

Working Memory Actions, and the process

begins again and proceeds until the Agenda

is empty.

As effect of a Working Memory Action, some

rules may become fully matched and eligible for

execution; a single Working Memory Action can

result in multiple eligible rules. When a rule is fully

matched, an Activation is created and placed onto

the Agenda. Such an Activation keeps its references

with that rule and the matched facts.

Conflict resolution is required when there are

multiple rules on the agenda. As firing a rule may

have side effects on the Working Memory, the rule

engine needs to know in what order the rules should

fire (for instance, firing rule A may cause rule B to

be removed from the agenda).

The Drools engine supports two types of conflict

resolution strategies: Salience and LIFO.

Salience is a subtype of the Natural numbers. It

allows end-users to specify that a certain rule has

higher priority than other ones. In a selection, higher

salience rules are always preferred to lower priority

rules. LIFO strategy is then applied to rules with the

same priority.

The LIFO strategy enacts a last in, first out

policy. It is based on the value of a counter, which

Working Memory Actions assign to rules. Multiple

rules, which receive the same counter value, are

placed in a common Agenda Group if and only if the

same Action created them. In case, they are

randomly selected for execution.

The ATM-Console subsystem allows end-users

to edit the LHS part of Validation Rules through a

Java based Graphical User Interface. An end-user

can both enter these Rules from the scratch, at every

validation session, by editing the ATM-Console's

Validation Rules Editing Form, and/or load them

from an XML repository.

Every time an end-user edits a new rule, this

enters the XML Rules Repository. As already

mentioned, it is possible to define validation logic

without affecting artifacts at the source level code,

which makes dynamic and flexible the validation

logic, in the user view.

Parsing files where the interactions between

components are stored, as a result of a test, creates

facts, which constitute the Working Memory.

In order to perform a Validation, the Rule Set and

Facts are the only inputs needed by the Rule Engine.

4 ATM - CONSOLE

ATM – Console is a software subsystem which

provides: (i) an instrument to remotely configure and

control the ATM – Common Core: the emulating

subsystem; (ii) a flexible and easy-to-use

environment to configure a validation session for

test results.

4.1 Architecture

The ATM-Console system consists of four macro-

units:

1. Test Configuration: Manages the test

configuration activity, by: (i) providing the

end-user with the simulation configuration

files, as available in the ATM-CC, (ii)

ICSOFT 2007 - International Conference on Software and Data Technologies

138

getting the files this user selects, and (iii)

sending this selection to the ATM-CC.

2. Test Control: Manages the test phase,

displays information concerning test

progress, and shows operator-consent

requests to end-user.

3. Validation Configuration: Manages the

validation configuration activity during

which the end-user edits the Validation

Rules and/or selects them from the XML

repository.

4. Validation Control: Builds both the

Working Memory by parsing test results,

and the Production Memory by utilizing the

DRL (Drools Rule Language) session file,

as written by the previous macro-unit; it

also manages the validation task by running

the Rule Engine.

4.2 Remote Control

An ad-hoc, RPC-based protocol allows the ATM-

Console to remotely communicate with the ATM-

CC subsystem. A proper interface exposes the

ATM-Console’s responsibilities, which consist in:

• Getting connection with the remote ATM-

CC subsystem.

• Asking ATM-CC for the XML

configuration file by specifying the

involved ATM-CC’s configuration

directory.

• Communicating the selected configuration

to the ATM-CC.

• Sending operator-commands (Start and

Stop Simulation) to the ATM-CC.

• Asking for information about the

progression of an ATM-CC simulation.

• Sending operator-consents, if any requested

by the ATM-CC to set the remaining of a

requested simulation.

• Asking the ATM-CC for, and getting test

results.

• Communicating results from a validation

session.

4.3 Usage for Test Validation

At the end of a test session, the operator can perform

the Validation Configuration; by such a use case, as

already mentioned, the ATM-Console allows the

operator to edit Validation Rules from the scratch

and/or load some of them from an XML Repository

in which all previously defined validation rules are

stored.

Rules that are present in the Repository are

shown in an easy-to-read Rule Repository Table.

As we want to validate distributed system tests,

objects of our validation are the interactions between

the constituting components. These interactions are

characterized by messages as exchanged between

components. An example of validation Rules is:

“Verify if the message X, with field constraints

F1,F2,...Fn, has been sent on the connection Y

within Z seconds.”

The end-user can set one or more test results

files, in order to verify the presence of every

expected message. All these files will be used to

build and populate the Validation Data Knowledge

Base, as the next section describes.

Additionally, the ATM-Console’s Rule Editing

Form gives end-users the possibility of binding

multiple rules, so composing complex rules.

Concerning this point, an example follows (where

the keyword “since” means to test for the

occurrence in the past):

“Verify if

the message X2, with field constraints set

to F21,F22,...F2n, has been sent on the connection

Y2 within Z2 ( = Z1 +

T2) seconds since the

message X1, with field constraints set to

F11,F12,...F1m, was sent on the connection Y1

within Z1 seconds.”

Every rule the user edits is added to the Rule

Set and finally the DRL rule is written.

4.4 Validation Data Knowledge Base

Let us focus now on the construction of the Drools’

Working Memory. As already mentioned, we

perform distributed systems test validation by

checking the exchange of messages between

system's components. The remote subsystem ATM-

CC stores these messages in some files, which the

ATM-Console gets from the ATM-CC at the

beginning of a Validation session. Based on the

contents of these files, the ATM-Console builds the

Validation Data Knowledge Base, i.e. the Working

Memory.

As JBoss Rule Engine requires, we model facts

as “beans”; they are asserted into the Working

Memory. Facts are thus Java objects of any kind,

which a rule can access together with their attributes

by proper access methods. The Rule Engine does not

clone facts at all; it just utilizes object references.

The ATM-Console creates objects by parsing test

result files, and asserts facts in the Working

Memory.

USING RULE-BASED ENGINE TO SUPPORT TEST VALIDATION MANAGEMENT OF COMPLEX

SAFETY-CRITICAL SYSTEMS

139

Because of the messages variety, it is variable

the number of fields in a message, thus the attribute

fi elds of the class Mes sage has been represented

as a Li st o f Fie lds; this to take advantage of some

features of the JBoss Rule Engine, as we will see in

the next section. So message’s fields are represented

as objects to assert in the Working Memory.

4.5 Validation Techniques Knowledge

Base

There are many methods to validate a test, including

subjective validation methods and statistical

validation methods. Subjective validation methods

include Turing testing (Turing, 1950), sensitivity

analysis (Archer, Saltelli, Sobol, 2006), and graph

methods (Bollobas, 1998) (Jungnickel, 2003); they

are easy to use, but depend on the subjectivity of the

person who performs in the role of analyzer.

Statistical validation methods include confidence

intervals, hypothesis testing, and time series (Archer,

Saltelli, Sobol, 2006); they are used to quantitatively

compare real outputs with human-generated or

simulation-generated outputs, and give “objective”

conclusions, in the limits established by the

statistical level of significance, and test power

obtained (Wohlin, Petersson, and Aurum, 2003). Of

course, our case takes in consideration real outputs

and simulation-generated outputs.

As already mentioned, it is in the context of

safety-critical distributed systems any of the

application that we have to test. Consequently, it is

strictly constrained the set of test validation criteria

that we can apply to test-results. In our approach, in

order to complete with success, a validation has to

meet all the defined rules, i.e. to verify each end-

user given rule, rather than statistical selected ones.

4.6 Knowledge Base for Validation

Rules

Let us consider now the construction of the

Production Memory, where Production Rules are

stored.

A Production Rule System's Inference Engine is

stateful and able to enforce truthfulness or “Truth

Maintenance” (JBoss, 2006): in practice, logical

expressions are declared to hold for actions, that is

the state of an action depends on the inferences that

still remain true; when it is no longer true the logical

dependant action is undone.

There are two exemplar modes of execution for a

Production Rule System: Forward Chaining, and

Backward Chaining.

Backward Chaining is goal-driven: we start by

providing a conclusion that the engine tries to

satisfy. If it can't, then it searches for limited

conclusions, i.e. sub-goals that help to satisfy an

unknown part of the current goal. The engine

continues to enact that process until either the initial

goal is proven or there are no more sub goals to

analyze. Prolog models a kind of a Backward

Chaining engine.

Forward Chaining is data-driven: facts are

asserted into the working memory, which results in

one or more rules being concurrently true and

scheduled for execution by the Agenda. The process

starts when a fact is provided; this fact propagates,

and the process ends in a conclusion. Drools is a

Forward Chaining engine.

A Drools’ Production Rule has the following

further attributes, many of which we already

mentioned above:

• sa li ence , which determines the priority of

the rule in execution.

• ag enda-group , which allows the user to

partition the A ge nd a, so enhancing on the

execution control: only rules in the focus

group are allowed to fire.

• au to -f oc us : when a rule is activated, if

the value of this attribute is true and the

rule's agenda-group does not have focus

then it is given focus to such a group,

allowing that rule to potentially fire.

• activation-group: rules that belong to

the same named activation-group will only

fire exclusively. In other words, it cancels

the activations of the remaining rules, so

removing their chances to fire, the first rule

that fires, in an activation-group.

• no -loop : when a fact is modified as a

consequence of a rule activation, it may

cause that rule to activate again, causing

recursion. This attribute helps in managing

such occurrences.

Rules are written in DRL files, the Drools

preferred file format. DRL files eventually are

simple text files in which multiple DRL rules,

functions etc. are stored.

When the user has finished with editing, the

Validation Configuration unit first converts rules

from the input format to DRL, and then writes these

DRL rules to a the Rule File for input to the Rule

Engine.

Example 1 presents some details about a Rule in

DRL language.

ICSOFT 2007 - International Conference on Software and Data Technologies

140

Example 1: A Rule in DRL language.

rule rule0

no-loop true

salience 103

when

f0: Field(key == "VALUE",

value == "REACHED")

m : Message(msgType == "AAAA",

fields contains f0)

r: Rule(ruleID == 1)

then

r.setVerified(true);

modify(r);

end

In order to achieve the result wanted for every

end-user given rule, the ATM-Console first creates a

Java object Rule, which contains the message

information that we want to verify, and then it builds

an entry for that information in the DRL file.

Apart from the facts coming from test output

files, the ATM-Console also asserts Rule objects in

the Working Memory. The subsystem uses those

objects to bind rules, so implementing dependence

relationships.

As Example 2 shows, when a rule has been

verified, the ATM-Console sets the isV er ified

object attribute to true, which propagates to linked

rules, so activating their checking.

Example 2: Rule binding.

rule rule3

no-loop true

salience 4

when

f0: Field(key == "VALUE",

value == "START")

m : Message(msgType == "AAAC",

fields contains f0)

r: Rule(times: receivedTimes,

ruleID == 8)

r0: Rule(ruleID == 2,

isVerified == true)

eval(r.verifyBoundRuleTime(

times, r0);

then

r.setVerified(true);

modify(r);

Additionally, concerning Rule’s programming

good practices, Example 2 shows that it should be as

lower the salie nc e of a rule as greater is the

number of binds of that rule: i.e. the greater a rule

depends on other rules, the lower should be its

priority. By the way, let us also note that, in order to

avoid recursion, the attribute no-loop was set to

true both in Example 1 and Example 2.

Moreover, those examples show that using the

following pattern, the ATM-Console can test

whether there is an object (o) of class Cla ss

in the

Working Memory, which attributes a1 and a2 are

set as x and y, respectively:

o:Class (a1 == x, a2 == y)

Furthermore, Example 2 shows another

important issue: based on the DRL, it is possible to

invoke Java functions indirectly by the eval

instruction, in case of LHS part of a rule, otherwise

directly (rule’s RHS).

Every change that can affect rules' checking has

to be notified to the Working Memory, which

contains all asserted facts, and this is made by

invoking the method modify( o) for the modified

object o.

If a fact isn’t yet true, it can be removed from the

Working Memory by calling the method

retract(o).

As already mentioned, fields are stored in

Message object as a variable List, and thanks to the

Drools' operator cont ai ns , the ATM-Console can

easily verify if any of the fields of a Message's

instance contains specified key and value.

5 CASE STUDY

This section describes a comparative study between

the execution’s modality of the validation activity,

as currently many industrial sites adopt, the

reference company for this paper included, and the

modality introduced by the sub-system ATM-

Console.

Because it is very high the complexity of the

systems that we are addressing, like Command and

Control systems or safety critical systems, many

loops are performed on development and testing in

the software life-cycle. In practice, testing and

validation are continually repeated until the system

satisfies all the defined requirements. Currently, the

reference company validation activities are manually

performed. Due to the confidential nature of data

object of this study, the reference company does not

allow to disclose details about the test results.

In case of manual validation, the effort of

validation activities depend on the following factors:

• Human Knowledge (HK): Validation

implies the knowledge of the problem

domain.

• Analysis of Results (AR): Validation always

implies an analysis on test results

Practically, analyzing and correlating many

thousands of complex messages are the activities to

USING RULE-BASED ENGINE TO SUPPORT TEST VALIDATION MANAGEMENT OF COMPLEX

SAFETY-CRITICAL SYSTEMS

141

perform for manual validation. Those messages are

stored and eventually distributed on many files.

Typically, each message has hundreds of fields to

check.

Vice versa, it is independent on HK and AT, the

automatic validation, as executed through the ATM-

Console system. In fact, it describes test cases and

procedures for qualification testing, the Software

Test Description (STD), as defined in the MIL 498

standard (DOD, 1994). In practice, the STD reports

on a list of indications, like:

• Do .... (Test object)

• Control... (Validation object), where such

a control is like Verify if X exists

after/before/within Y.

Let us note explicitly that a standard compliant

ATM end-user is in the only responsibility of

entering the STD information into the ATM GUI.

The STD document is arranged in a tree

structure. The root level defines a list of Formal

Qualification Testing (FQT); each FQT defines a set

of Tests Cases. Each Test Case includes many

Checks.

Referring to application systems as the industry

nowadays typically develops, and taking into

account average values, an STD contains 250

FQT(s), each FQT defines 20 test cases, each made

up on 10 Checks.

In case of manual validation, let each test case be

performed in the average period AT. This results

from the sum of two times, AT

and AT

• AT

: Localization of the Meaning

Information (e.g. e set of messages).

Typically, the end user has to locate, inside

the test result files (thousand of lines), the

information that is meaningful for the test

case.

• AT

: “Meaning Delay”. Time necessary to

check the detected meaningful information.

The following factors influence AT

• Total of the expected messages.

• Message throughput (average m/s).

• Duration test time.

• Triggers’ complexity (boundary place).

• Number of source files.

The following factors influence AT

• Verification difficulties.

• Number of field for each message.

• Message heterogeneity.

• Number of messages.

To the best of our knowledge, it is observed

that on average, for a single human resource, AT

5 minutes, and AT

is 10 minutes.

The overall time to manually perform a typical

STD verification activity follows:

ManMonths

ANANATATAT

TCFQTV

**)(

≅

where: AT

indicates the average time to complete a

validation activity, AN

FQT

is the average number of

the expected FQT for a validation activity, and AN

is the average number of expected Tests Cases for

every FQT.

In case of ATM-Console-based automatic

validation, only the time necessary to insert

validation rules affects the validation time. For such

insertion activity, we observed an average time of 10

minutes for every test case, which is made up on an

average of 10 Checks of medium difficulty, and with

several links between the various Checks.

As it has been previously mentioned, the

reference company’s software systems are subjected

to repeated validation activities. Thus, ATM-

Console introduces a remarkable improvement in

terms of saving both time and human resources: in

fact, starting from the second validation activity, in

which the whole Rule Set concerning the various

test cases is already available, we observed that the

execution validation time duration is 20 seconds for

each test case in the average.

Therefore, in case of automatic validation, it

shows:

ManMonthsANANAT

ANANATAT

TCFQTTC

FQTTCinsVAUT

5)**(

)**(

≅+

where: AT

ins

=10 minutes is the average time for

inserting the test case in the GUI form, and

=20, AN

FQT

=250. Additionally, AT

=20

seconds indicates the average time to execute the

automatic validation of such a test case.

Rather, for the subsequent validation activities, it

disappears the last equation’s first addend, which

represents the insertion time of the Checks’

characteristics, thanks to the ATM-Console’s feature

to hold the history of any test case. Therefore, it

shows:

ManHours

ANANATAT

TCFQTTCVAUT

)**(

≅

This outstanding result concerns just the

validation activities, without taking care of the time

for inserting rules, and reports a 97,8%

improvement. Also taking in count the insertion of

the validation rules, it registers a 25% improvement

the time spent for automatic validation compared to

the manual validation.

ICSOFT 2007 - International Conference on Software and Data Technologies

142

Because the considerations above result from a

case study, their validity is threaten and they need

confirmation by extensive accreditation in field.

6 CONCLUSIONS AND FUTURE

WORK

In order to configure the validation rules and execute

the validation process of medium/large safety-

critical systems by utilizing the power offered by an

open-source Rule Based Engine, this paper

presented the concept and architecture of a novel

flexible subsystem that we designed and developed

to remotely control the simulation of some

application system components (one simulated

component in the present version of the subsystem)

and their interactions with the remaining real

distributed components for failure identification.

Results from an industrial case study shows that

the presented subsystem could provide great support

in performing distributed systems testing, saving

management and execution efforts that relate to

tedious complex operations, and assuring a very

interesting return on investment.

Using rule engines to perform test validation of

safety-critical systems could have a large exploit in

future, such as is happening in the application

domain of business management. In such a scenario,

it could deliver significant benefits the improvement

of the presented subsystem by including validation

criteria for test configuration and providing features

to select the criterion to apply from a given set of

those criteria.

ACKNOWLEDGEMENTS

Authors would like to thank people in the Division

of Applied Software Research of the MBDA-Italy

Spa for the support provided in analysis, design, and

realization of the ATM-Console subsystem.

REFERENCES

Archer G., Saltelli A., Sobol I. M., 1997 Journal of

Statistical Computation and Simulation. Taylor &

Francis.

Bollobas B., 1998. Modern Graph Theory, Springer

Verlag.

DOD, 1994. Software Test Description,

http://www2.umassd.edu/swpi/DOD/MIL-STD-

498/STD-DID.PDF.

Fair Isaac, 2007. Blaze Advisor Online Documentation.

http://www.fairisaac.com/fic/en/product-

service/product-index/blaze-advisor/, 29 March 2007.

Forgy C. L., 1982. Rete: A Fast Algorithm for the Many

Pattern/Many Object Pattern Match Problem. Artificial

Intelligence, North Holland Conference, pp. 17 – 37.

Grillo A., Cantone G, Di Biagio C., Pennella G., 2007.

Automatic Test Management of Safety Critical

Software: The Common Core - Behavioral Emulation

of Hard-Soft Components, Proceedings of ICSOFT

2007 (to appear).

ILOG, 2007. JRules Online Documentation.

http://www.ilog.com/products/jrules/, 29 March 2007.

JBoss, 2007 JBoss Rules Online Documentation

http://labs.jboss.com/portal/jbossrules/docs.

Jungnickel D., 2003. Graphs, Network and Algorithms,

Springer.

Liu F., M. Yang, Z. W.-S. Wang, 2005. Design and

development of an expert system-like validation tool

for distributed simulation systems., In Fifth IEEE IC

on Machine Learning and Cybernetics, CS Press.

Min F.-Y., Yang M., Wang Z.-C., 2006. An intelligent

validation system of simulation models. In Fifth IEEE

International Conference on Machine Learning and

Cybernetics.

Miranker D.P., 1990. TREAT: A New and Efficient Match

Algorithm for AI Production Systems. In Research

Notes in Artifical Intelligence. Pitman Publishing Ltd.

Don Batory, 1994. The LEAPS Algorithms. In

Technical Report 94-28, Department of Computer

Sciences, University of Texas at Austin.

Sandia Lab., 2007. Jess Online Documentation.

http://herzberg.ca.sandia.gov/jess, 29 March 2007.

Sun, 2007. Getting Started With the Java Rule Engine API

(JSR 94): Toward Rule-Based Applications.

http://java.sun.com/developer/technicalArticles/J2SE/J

avaRule.html.

Turing A., 1950 Computing machinery and intelligence. In

Mind, vol. LIX, no. 236, pp. 433-460.

Walczak S., 1998. Knowledge Acquisition and

Knowledge Representation with Class: the Object-

oriented Paradigm. In Expert Systems with

Applications, No. 15, pp.235 - 244.

Wohlin, C., Petersson, H., and Aurum, A., 2003.

Combining data from reading experiments in Software

Inspections. In Juristo, N. and Moreno, A. (eds.)

Lecture Notes on Empirical Software Engineering,

World Scientific Publishing.

USING RULE-BASED ENGINE TO SUPPORT TEST VALIDATION MANAGEMENT OF COMPLEX

SAFETY-CRITICAL SYSTEMS

143
