DETECTING AND CLASSIFYING FRONTAL, BACK AND PROFILE

VIEWS OF HUMANS

Narayanan Chatapuram Krishnan, Baoxin Li and Sethuraman Panchanathan

Center for Cognitive and Ubiquitous Computing, Arizona State University, Tempe, USA

Keywords:

Human Detection, graph cut, shape context, SVM.

Abstract:

Detecting and estimating the presence and pose of a person in an image is a challenging problem. Literature

has dealt with this as two separate problems. In this paper, we propose a system that introduces novel steps to

segment the foreground object from the back ground and classiﬁes the pose of the detected human as frontal,

proﬁle or back view. We use this as a front end to an intelligent environment we are developing to assist

individuals who are blind in ofﬁce spaces. The traditional background subtraction often results in silhouettes

that are discontinuous, containing holes. We have incorporated the graph cut algorithm on top of background

subtraction result and have observed a signiﬁcant improvement in the performance of segmentation yielding

continuous silhouettes without any holes. We then extract shape context features from the silhouette for

training a classiﬁer to distinguish between proﬁle and nonproﬁle(frontal or back) views. Our system has

shown promising results by achieving an accuracy of 87.5% for classifying proﬁle and non proﬁle views using

an SVM on the real data sets that we have collected for our experiments.

1 INTRODUCTION

Detecting the presence of a human and estimating

his/her pose in a video sequence is a challenging prob-

lem and has been an active area of research,witnessing

a surge of interest in the recent years with widening

spectrum of applications. Our motivation behind this

problem is designing a system that can detect the pres-

ence of a human and also estimate the pose, that can

be used as an assistive device for individuals who are

blind in their ofﬁce spaces. We hope that such a sys-

tem would be useful in informing an individual who is

blind, if there are any people standing by the entrance

of their ofﬁce space. The requirement of such a sys-

tem makes it different from other systems for surveil-

lance.Apart from being accurate in detecting a person

at the entrance, information about the pose of the per-

son(frontal,back or proﬁle) is useful for the individual

who is blind to judge whether the person is waiting for

them to respond.

In our proposed system, background subtraction

is performed on the frames obained from a station-

ary video camera. On detection of signiﬁcant change,

the system localizes the change and performs a robust

segmentation to obtain the silhouette of the region that

has changed. This silhouette is then used to determine

whether the moving object is a human and to estimate

pose of the person. We envision conveying this in-

formation to the individual who is blind, through an

audio device. It is difﬁcult for individuals who are vi-

sually impaired to come to know if there are people

standing by their door side. We hope that such a sys-

tem will enhance the social interaction ability of the

individual by giving them cues about people who are

passing by and who are standing by their door.

We have divided this paper in the following man-

ner. Section 2 gives a summary of the related work on

human detection. The details about background sub-

traction and foreground segmentation are discussed in

section 3 and the classiﬁcation step in section 4.

Section 5 presents the results obtained at the vari-

ous stages and analyses them. Conclusions and future

work are presented in sections 6.

137

Chatapuram Krishnan N., Li B. and Panchanathan S. (2007).

DETECTING AND CLASSIFYING FRONTAL, BACK AND PROFILE VIEWS OF HUMANS.

In Proceedings of the Second International Conference on Computer Vision Theory and Applications - IU/MTSV, pages 137-142

 SciTePress

2 RELATED WORK

Background subtraction techniques for human de-

tection rely on the static background information or

on the motion information, to ﬁrst detect the regions

that have changed or moved. Beleznai etal (Beleznai

et al., 2004) perform a Mean shift clustering of the

subtracted image to identify regions of signiﬁcant

change. The clustered regions are then checked for

the presence of humans by ﬁtting a simple human

model in terms of three rectangles. Eng and etal (Eng

et al., 2004) propose a similar technique where the

local foregrond objects are detected using clustering,

and an elliptical model is used to represent the

humans. A Bayesian framework is then employed to

estimate the probability of the presence of a human

after ﬁtting the ellipses to a foreground object region.

Elzein and etal (Elzein et al., 2003) propose a vision

based technique for detecting humans in videos. A

localized optic ﬂow computation is performed to

compute the locations that have undergone signiﬁcant

amount of motion. Haar wavelet features at different

scales are extracted from these localised regions, and

matched against that of templates using a linear clas-

siﬁer. Lee and etal (Lee et al., 2004) use differential

motion analysis to subtract the current input image

from a reference image and thus extract the contour

of the moving object. A curve evolution technique

is then performed to remove the redundant points

and noise on the contour. The curve thus extracted

is matched against existing templates by calculating

the Euclidean distance of the turn angles at the points

describing the curve.

Dalal and etal (Dalal. Navneet and Schmid, 2006)

propose a technique for detecting the humans based

on oriented histrograms of ﬂow and appearance.

Optic ﬂow is computed between successive frames

and the direction of ﬂow is quantized. The histogram

constructed based on these directions of ﬂow, coupled

with the histograms of oriented gradients are used to

train a linear SVM to detect the presence of humans.

Bertozzi and etal (Bertozzi et al., 2005) describe a

system for pedestrian detection using stereo infrared

images. Warm areas from the images are detected

and segmented. An edge detection operation is

performed on the resulting regions, followed by a

morphological expansion operation. Different head

models are then used to validate the presence of

humans in the resulting images. Researchers have

proposed similar algorithms (Zhou and Hoang, 2005;

Han and Bhanu, 2005) to detect humans using either

motion information or static background information.

But all of these algorithms, have stopped at detecting

whether the moving object is a human or not. We go

a step further and also provide information about the

high level pose of the person by indicating whether

it is a frontal, back or proﬁle view of the person. As

mentioned before, estimating the pose of the person

will help an individual to decide if the person at the

door is waiting for them to respond or not.

We employ a background subtraction technique,

enhanced by graph cut algorithm to segment the fore-

ground regions. Silhouettes thus obtained are used

to extract features like shape context and fourier de-

scriptors. These are then used to train a classiﬁer to

distinguish between the proﬁle and non proﬁle views.

Though many researchers use synthetically generated

human silhouettes for testing the pose estimation al-

gorithms, we have used real segmented silhouettes for

evaluating our pose estimation algorithm.

3 SEGMENTATION

This section deals with the 3 stage process of ex-

tracting the silhouette of the foreground objects.

A running average model is based on technique

proposed by Wren etal in (Wren et al., 1997)pic-

cardi:04, where the background is independently

modeled at each pixel location is used to model the

background. A Gaussian probability density function

(pdf) that ﬁts the pixel’s last n values is computed.

A running average is computed to update the pdf.

Often, even with these models, the shadow regions

get misclassiﬁed as foreground. Assuming that the

illumination component of the pixel locations in the

shadow region undergo uniform change, we use the

derivatives at these locations to cancel out this unform

change. The derivatives of the pixel locations in the

shadow region for both the background model and

the current frame should be very similar. Thus the

difference in the derivatives can help in eliminating

to a certain extent the shadow regions.

Robust background subtraction can still result

in broken contours and blobs of the foreground

object. It is difﬁcult to detect whether the foreground

object is a human using these blobs. Ideally we

would like to have a continuous contour that can

be further processed. To obtain this continuous

contour we have used the extended version of graph

cut algorithm (Boykov and Jolly, 2001) proposed

by Rother etal (Rother et al., 2004) for color image

segmentation. Though this approach guarantees an

optimal segmentation solution, given the constraints,

the drawback is that the seed or the trimap(the initial

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

138

foreground, background and unknown regions) has to

be manually initialized. We have improved upon this

framework by automatically constructing the trimap

from the background subtracted mask obtained in

the previous step. We explain brieﬂy the graph cut

framework and refer the reader to (Boykov and Jolly,

2001; Rother et al., 2004) for the theoretical and

implementational details.

The trimap consists of three regions namely, back-

ground, foreground and unknown. Gaussian mix-

ture models (with K components) are computed for

the background and foreground pixel classes using

the minimum variance color quantization approach

proposed by Orchard and Boumann (Orchard and

Bouman, 1991). Each pixel in the foreground set

is assigned to the foreground GMM component that

has the highest likelihood of producing that color.

Similarly the background pixels are also assigned

to the most likely background gaussian component.

The Gaussian mixtures are then recomputed from the

newly created pixel sets. A graph is constructed as

described in (Boykov and Jolly, 2001). Every pixel

in the image is associated with a node in the graph

along with two other special nodes- the foreground

and the background node. These nodes are joined by

two types of links - N-links that connect every pixel

with its 8 neighbors and the T-links which connect ev-

ery pixel to the foreground node and the background

node. The N-link describes the penalty for placing

the segmentation boundary between neighboring pix-

els, which is set to be high in regions of low gradient

and low in regions of high gradient. The T-links de-

scribe the probability of each pixel belonging to the

foreground or to the background. The weight for the

N-link between pixel i and j is given by

(i, j) =

dist(i, j)

−β

−I

. (1)

where I

is the color of pixel i and dist(i, j) is the

Euclidean distance between pixel locations i and j.

(Rother et al., 2004; Boykov and Jolly, 2001) suggest

setting γ = 50 and β as given in equation 2 .

β =



−I



(2)

The T-link weights are computed as described in table

1,where L(i) = 8γ+1 and W (i) is the log likelihood of

a pixel belonging to either background or foreground

given by

W (i) = −log

∑

k=1

√

detΣ

(

−

−µ

]

−1

−µ

]

)

(3)

Table 1: Weights for the T-Links.

Pixel Type Background Foreground

i ∈ foreground 0 L(i)

i ∈ background L(i) 0

i ∈ unkown W

f ore

(i) W

back

(i)

Thus once the weights for all the links are computed,

the problem reduces to ﬁnding the cut, that maximises

the ﬂow from the foreground node to the background

node. This is performed by the fast mincut algorithm

implemented by (Boykov and Jolly, 2001).The ﬁnal

result of the segmentation process is an optimal

solution to this minimizing energy problem.

One of the main disadvantages of this technique

as pointed out by Kumar etal (Kumar et al., 2005) is

that this framework does not have a mechanism to

segment out natural shapes. Keeping this in mind,

we have formulated a simple way of generating the

trimap from the background subtracted mask. We pre-

serve the shape of the segmented mask,the foreground

region of the trimap, as much as possible along with

making the holes within the mask and a thin boundary

around the mask as unknown regions of the trimap.

4 SHAPE CLASSIFICATION

Our objective behind using shape classiﬁcation is

two fold - categorize the silhouette as a human

silhouette and to estimate whether it is the proﬁle

non proﬁle view of the person. As mentioned before

our objective is not to estimate the accurate pose of a

person, as dealt by others. We have used the shape

context feature proposed initially by Belongie and

etal (Belongie et al., 2002) for shape classiﬁcation

and later modiﬁed by Agarwal and Triggs (Agarwal

and Triggs, 2004) for pose estimation. The silhouette

is ﬁrst processed to select n contour points at equally

spaced intervals. The shape context at a point de-

scribes the spatial locations of the other n−1 sampled

points with respect to the point under consideration

in a histogram. The shape is encoded as a distribution

in the 60-D shape context space(12 angular bins and

5 radial bins). Belongie and etal (Belongie et al.,

2002) match the shape context vectors extracted

from two silhouettes, using a bipartite weighted

graph matching algorithm, while Agarwal and Triggs

(Agarwal and Triggs, 2004) compute another layer

of histogram before applying the relevance vector

regression for pose estimation. We have taken the

step of generating a second layer of histograms.The

distribution of all the points on a silhouette is reduced

DETECTING AND CLASSIFYING FRONTAL, BACK AND PROFILE VIEWS OF HUMANS

139

to 100-D histograms by vector-quantizing the shape

context space. The 100 center codebook is learnt us-

ing a K-means clustering algorithm over all the 60-D

shape context vectors in the training set. The 100-D

ﬁnal histogram is then constructed by allowing every

shape context vector of a silhouette to vote softly

using gaussian weights into the bins corresponding

to the top 5 nearest centers to them and subsequently

accumulating it over all the points in a silhouette.

Instead of using relevance vector regression as in

(Agarwal and Triggs, 2006) or having exemplars to

denote the different shapes (Poppe and Poel, 2006),

we experimented with training a support vector

machine (SVM), for distinguishing between different

views of a person. The SVM was trained with the

100-D histograms extracted out of the silhouettes

from the training set. It is intutive that the silhouette

of the frontal and the back view of a person are very

similar. Thus trying to distinguish between these

two views using silhouettes may be a futile effort.

However, the silhouettes of the proﬁle view are

signiﬁcantly different from the frontal or back. Thus

at this step, we have tried to differentiate between the

proﬁle view from the non-proﬂe view. The training

set consists of the feature vector extracted from the

frontal as well back views in one class and that of

the proﬁle view in another class. In the next step as

described in the following subsection, we classify

the non-proﬁle view as frontal or back based on the

image data.

Frontal Vs Back View distinction: As it is difﬁcult

to differentiate between the frontal and back view of

a person using the silhouette information, we revert

to the color information present in the image. We

have used a skin color detection algorithm, to com-

pute the number of pixels in the upper region of the

silhouette, corresponding to the head region, having

the skin color. If this number is greater than a thresh-

old, we classify the view as frontal else we label it as

back.

5 RESULTS AND DISCUSSION

Though there are existing synthetically generated

clean human silhouette databases (Agarwal and

Triggs, 2004),it is important to work with real data to

understand the problems and limitations, encountered

when a vision based system is deployed in a real

environment. We captured people entering, exiting

and passing by a cubicle in our lab using a sony

handycam. 10 second videos with a frame rate of

Figure 1: The results of the shadow removal step.

30 seconds of 15 individuals under varying lighting

conditions were captured. Individual frames from the

video sequence were then extracted and manually

labeled as either belonging to frontal, back or the

proﬁle view of the person. A total of 604 frontal, 297

back and 277 proﬁle view images, on an average of

40 frontal, 20 back and 20 proﬁle views per person

were thus collected and labelled. The ﬁrst row of

Figure 5 shows some of the sample frames.

Figure 5 presents the results obtained after the

shadow removal step. Column (a) contains the

images obtained after background subtraction and

column (b) is the result obtained after combining

(a) with the difference of the response to the LoG

operator. Some regions, in the image in the second

row that belonged to the foreground object also got

erased after the shadow removal step. However,

the graph cut algorithm in the next step, rectiﬁes

the segmentation by including these regions in the

foreground object as shown in the image in the last

row of column (e) in ﬁgure 5. This is possible

because, regions around foreground silhouette in

the image shown in 5(b) are considered as unkown

regions when constructing the trimap for the graph

cut algorithm.

Figure 5 illustrates the process of segmentation.

Each column contains the results obtained at the

different steps in the segmentation process of the

image shown in the ﬁrst row of the column. One

important observation about the ﬁnal segmentation

result(last row in ﬁgure 5), is that the end results

have no holes, and the silhouette is continuous, when

compared with the back ground subtracted image

shown in the second row. The third row depicts the

trimap that is created out of the image in the second

row. As it can be seen, the overall shape of the

silhouette is more or less preserved in the trimap. It

is evident from the results that adding the graph cut

step indeed improves the segmentation result, thereby

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

140

Table 2: Comparison of accuracies for different values of

the parameters - number of code vectors and number of

sample points.

Number of Code Vectors

50 100 150

Number of

Sample

Points

50 86.64% 85.45% 86.11%

100 86.54% 87.5% 86.93%

150 86.25% 87.5% 87.14%

Table 3: Comparison of the performance of Shape context

and Fourier descriptors as features for classifying the sil-

houette as proﬁle or non proﬁle.

Feature Vector Linear SVM Gaussian SVM

Shape Context 87.5% 83.1%

Fourier Descriptors 76.53% 73.6%

improving the classiﬁcation accuracy.

After the silhouettes are computed as shown in the

last row of ﬁgure 5, shape features are extracted from

it. We have experimented with two features described

in the literature - Shape Context and Fourier Descrip-

tors. The shape context features were implemented

by considering 100 equally spaced points on the sil-

houette boundary. The larger the number of sampled

points, the more accurate is the silhouette description.

However, the noise in the contour as a result of seg-

mentation process also gets encoded. Similarly, the

lesser the number of sample points, lesser is the ac-

curacy of the encoded silhouette. We experimented

with 50, 100 and 150 sample points for describing

the silhouettes. The classiﬁcation accuracies obtained

are shown in table 2. As mentioned before a sec-

ond layer of histogram is computed to further quan-

tize the shape context vector. The auhtors (Agarwal

and Triggs, 2004) cluster the training shape context

vectors in to 100 code vectors. We experimented with

different number of code vectors. In both the cases it

can be noted that there is no signiﬁcant change in the

performance.

Translational, rotational and scale invariant

fourier descriptors were computed as mentioned by

(Poppe and Poel, 2006). However instead of using

exemplars to compare the test silhouette, we trained

an SVM classiﬁer. The best performance with fourier

descriptors for classifying the silhouettes as proﬁle

or non-proﬁle view was around 76.53%, while an

accuracy of 87.5% was achieved using shape context

features. We have used the leave one out strategy,

where for every fold, images from one video was

considered as the test sequence and the remaining

were the training sequence. This clearly shows the

superiority of shape context features over fourier

descriptors in the current context. There was no

signiﬁcant change in the performance of the features

when a gaussian SVM was used instead of a linear

classiﬁer. These results are summarized in table 3.

We used the standard skin tone detection approach

to distinguish between the frontal and the back views.

Depending on the size of the silhouette, regions from

the top part of the silhouette were extracted for de-

tecting the presence of skin tone. A threshold was

determined for classiﬁcation. We were able to get an

accuracy of 71%. One of the reasons for getting a low

accuracy was that, regions other than the head region

also got included while computing the percentage of

skin color. We are working on techniques that would

consider only the elliptical head region to determine

the percentage of skin color.

6 CONCLUSION

We have proposed a system for detecting the pres-

ence of a human in an indoor environment and clas-

siﬁng the pose at a high level as frontal, back or pro-

ﬁle view. We have improved on the traditional back-

ground subtraction method, by adding a step that per-

forms graph cut. The results obtained after this step

show signiﬁcant improvement over the background

subtracted images. The silhouette thus extracted was

used for classiyﬁng the proﬁle and non proﬁle views

of the human. We experimented with two features

for this purpose - shape context and fourier descrip-

tors. We observed that shape context features perform

signiﬁcantly better(with an accuracy of 87.5%) than

the fourier descriptors(with an accuracy of 76.53%)

in classifying a silhouette as proﬁle or non proﬁle.

We further have used the percentage of skin color to

classify the non proﬁle view as either frontal or back,

achieving around 71% accuracy. We intend to use this

as a front end to an intelligent environment we are

developing to assist individuals who are visually im-

paired in their ofﬁce spaces.

DETECTING AND CLASSIFYING FRONTAL, BACK AND PROFILE VIEWS OF HUMANS

141
