MEANING AND EFFICIENCY IN THE GESTALT-SYSTEM

An Approach to Automatic Image Description

E. Michaelsen, M. Arens, L. J. Doktorski, P. Ding

FGAN-FOM, Gutleuthausstrasse 1, 76275 Ettlingen, Germany

U. Stilla

Photogrammetry and Remote Sensing, Technical University of Munich, Arcisstr. 21, 80280 Munich, Germany

Keywords: Image understanding, pattern recognition, structural and syntactical approach, production systems.

Abstract: Knowledge-based image recognition and description systems have to balance soundness versus efficiency.

For mining purposes in particular a theory of meaning – i.e. formal semantic or ontology – has to be given.

However, efficiency is also most important for practicability. This contribution uses production systems.

The semantics are analysed by means of confluence. Productions are used in an accumulating way instead

of reductive. The interpretation scheme given allows breaking reasoning at any time with an approximate

interpretation as result. Two example systems using this interpreter are discussed.

1 INTRODUCTION

Image mining – if not performed with simple

features such as colour histograms – needs meaning,

i.e. semantics. In contrast to other recognition tasks

on pictorial data not only a class label is to be

assigned to an image. Instead, pictures need to be

described in a structural way and the nodes of this

structure need to revere to concepts about facts,

objects, etc. of the world. Thus automatic reasoning

is prerequisite to real image mining.

One classical syntactic way of automatic

generation and reduction of meaningful structure is

given through formal languages. A moderately sized

system of production rules can analyse huge input

data sets and reduce them to meaningful structures

(reduction trees). However, such systems though

being fast on strings tend to lead to unpredictable

computational effort on images or image sequences.

A common way to meet efficiency constraints

and still derive the structure of the input image is to

restrict the search space during production

application by means of an assessment measure for

the utility of single productions with respect to the

desired goal.

This contribution explores the possibility of

using production systems in an approximate way:

given assessment measures for the objects and

productions, the question arises to which point

production rules have to be applied to a given input

image in order to meet efficiency constraints and

still derive the meaning of that image.

2 RELATED WORK

Semantic networks have been proposed for

automatic image or video content analysis by

Niemann (1989) and his school. This work has led to

the creation of the ERNEST system (Sagerer, 1982).

The latter presumably ventured the deepest

investigation concerning the semantics. The

meaning possibilities for the productions used in our

work (e.g. in sections 3.2 and 4) have been

investigated by Sagerer with much more rigor as

admissible meanings of links in semantic nets. His

work culminated in proven soundness from the logic

level down to the epistemological level.

Matsuyama & Hwang (1990) constructed a

production system named SIGMA featuring

sophisticated control mechanisms – e.g. including

meta rules. Examples are given from automatic

www.fom.fgan.de

188

Michaelsen E., Arens M., J. Doktorski L., Ding P. and Stilla U. (2007).

MEANING AND EFFICIENCY IN THE GESTALT-SYSTEM - An Approach to Automatic Image Description.

In Proceedings of the Second International Conference on Computer Vision Theory and Applications, pages 188-193

DOI: 10.5220/0002070601880193

 SciTePress

understanding of aerial images. Work on and with

the similar SCHEMA system of Hanson and

Riseman (Draper et al., 1998) has been pursued for

decades by many researchers. Though being

conceptually closely related to our scheme these

systems were not intended to work efficiently albeit

still approximately correct on large data sets.

Recently, the field of image and image sequence

understanding has gained renewed attention under

the term Cognitive Vision as discussed, e.g., in the

Dagstuhl workshop (Christensen & Nagel, 2006).

3 STATE OF THE THEORY

In section 3.1 a brief overview on confluence in

transition operations on configurations of objects is

given. This is not a sufficient condition for sound

semantics, but it is a necessary one. Explicitly listing

admissible transitions is practically impossible.

Instead production systems are used. These are

introduced in section 3.2. Only productions of two

specific normal forms are permitted which also helps

to keep track of the meaning. Possible standard

interpretations are listed. In Section 3.3 an

interpreter system is given that can perform efficient

inference based on a given production system.

Usually, complete search is not feasible. So the

system has to be capable of providing approximate

solutions. Large parts of the theory are still missing

which is discussed in section 5.

3.1 Confluence on Sets of Objects

Let S denote a finite set of classes such as {line,

longline, angle, …,building}. Similar to object

oriented programming, each such class has a number

of methods containing at least one method

(constructor) that can construct objects of that class.

Usually, a method to present or draw the object is

compulsory, too.

A class is called primitive – and such is any

object of that class – if none of its constructors uses

information from any other object. Primitive objects

in the context of computer vision are usually

constructed by operations working directly on the

input data, e.g., by segmentation of images or image

sequences.

An object

o of one of the classes is denoted as a

pair (s,d) in the following, where s is a class name

and d is a structure of numerical attributes

containing the specific features of that object.

A configuration is a finite set C of objects. It

represents a state of semantic analysis. The set of all

possible configurations is called Ω. A transition

→∈ is a binary relation on Ω and defines

transition chains of the form

Such a transition is called confluent iff

If the transition is confluent and terminating –

i.e. all transition chains have finite length – this

guarantees that for any (start-)configuration

C a

unique final configuration

exists and can be

reached after a finite number of transition steps.

Without these properties, a transition cannot have

semantic meaning. The final configuration C

of a

confluent and terminating transition contains all its

possible meaning. For further reading on confluent

systems we refer to (Janzen, 1988).

3.2 Productions

For practical applications transitions are given by

productions. We restrict the formulation of

productions to the two forms given below. A

production

p can be defined as

:( , )

oo r

⎯

⎯→

with

),(

111

dso

, ),(

222

dso =

and

),(

dsr

where Ssss

∈,,

(3)

The other possible formulation of a production

p is

given by

: ( ,..., )

oo r

⎯

⎯→

with

),(:,...,1

dsoni =

∀

and

),(

dsr

where Sss

∈, .

(4)

In both cases,

π is a constraint formulated on the

attributes of the objects

o ,… involved on the left

hand side of the production and r denotes some

(resulting) object of a class within S, which is

created using the constructor method

ϕ. Note that in

(3), the two left hand side objects can be of different

class, whereas the arbitrary number of left hand side

objects in (4) all must be of the same class. It

follows, too, that r cannot be an object of a primitive

class in either case.

The meaning of productions of the form defined

in (3) can be threefold:

1) the two left hand side objects are parts of the

object r such as the two

longline objects in

CCCCC →→→=⎯→⎯ ...:

(1)

:,, Ω∈

∀

CBA

⇒⎯→⎯∧⎯→⎯ )(

CABA

DCDBD ⎯→⎯∧⎯→⎯Ω∈∃

(2)

MEANING AND EFFICIENCY IN THE GESTALT-SYSTEM - An Approach to Automatic Image Description

189

production p

1,3

are the two legs of the object angle

(see section 4.1),

2) one of the left hand side objects is interpreted

as being an object r provided that the other object is

given as context – such as in production p

1,6

the

longline object close to an object spot leads to the

assumption of an object

row with one element and

3) the two left hand side objects are

concretizations of the object r. An example is the

construction of a 3D-object from two 2D-view

objects. Such productions have been used in (Stilla

& Michaelsen, 1997). In this case

π resembles an

epipolar constraint and

ϕ implements a triangulation.

Concretization relies critically on external

knowledge, e.g., about the conditions while taking

the pictures – such as in the stereo case the internal

and external camera parameters.

The role of productions of the form defined in

(4) is that of combining evidence from multiple

measurements into a single hypothesis. Examples

are given by productions p

1,1

, p

1,2

, p

1,5

, p

2,2

, p

2,4

, p

2,6

Often the required linear and metric structure can

only be given in a local tangential linear space,

where

π is based on, e.g., Euclidean distance and ϕ

performs averaging or other forms of least squares

optimizations. Such an example is given in p

2,4

, p

2,6

Instead of averaging over the attribute values of the

direct predecessors it is often more exact to perform

the minimization on the attribute values of the

primitive predecessors. Sometimes these kinds of

productions resemble Hough-techniques or other

accumulator based methods – such as in p

1,1

A Production p can modify a given configuration

C in two different ways: a Reduction replaces left

hand side objects with the inferred right hand side

object within the configuration C:

reducep

⎯⎯⎯→⎯

with

{ ,..., } { }

DC o o r= U\

(5)

where

oo ,...,

denote the left hand side objects of

the production p and r being the right hand side

object of p. Accumulation instead leaves the left

hand side objects in C and just adds the right hand

side object to that configuration:

accumulatep

⎯⎯⎯⎯→⎯

with {}DC r= U .

(6)

The term ‘reduction’ has as antagonist ‘generation’.

Both directions can be used in a syntactic manner

either to parse configurations or to construct them –

i.e. for pattern recognition and for computer

graphics. Most structural recognition approaches –

such as the production systems SIGMA or

SCHEMA or contemporary work with PROLOG

rules or the semantic net methods – can be mapped

to reducing transitions. However, examples can be

given that have two different final reductive

interpretations – the well known picture puzzles.

Therefore confluence is not given in such systems.

There may be more than one final consistent

assignments of meaning, which jeopardizes the

meaning of such production system. Reduction has

obviously good halting properties – because with

each step the configuration is becoming smaller.

With Accumulation only possible hypotheses are

piled up. Decisions are avoided. Due to the

properties of set union transitions defined as

accumulation are confluent (Lütjen 2001). However,

this only gains sound meaning if the interpretation

rests on probability calculus. For each object

o a

special attribute is required that gives an assessment

for its probability. This assessment must be sound

with respect to the expectations of a statistical

model. So instead of speaking of objects it makes

more sense to speak of hypotheses or cues here.

There is uncertainty in this way of dealing with a

production system, but it leads to a unique final

interpretation where, e.g., the two different

meanings of a picture puzzle can coexist with their

probability attributes summing up to at most one.

3.3 A Production System Interpreter

Listing all admissible productions for a given

configuration C and a set of productions P is not

feasible in most cases. Instead hypotheses are

formed for each object

o∈C. Such a hypothesis has

the form of a triple h= (h

, h

) where 0

≤

1 is

an assessment of

o, h

is an index or pointer

allowing access to

o and h

∈P

∪

{nil} denotes an

index or pointer to a production (initially set to nil).

Based on this notation, the following interpretation

cycle can be formulated:

1) The hypotheses are ordered according to the

assessment h

in a queue. The best n hypotheses are

chosen. For each of these 2) is performed.

2a) If h

= nil then all those p∈P are chosen,

which contain an object of the same class as h

= o

on their left hand side. h is then replaced by clones

of it with the corresponding indices h

, where the

assessment of those newly introduced hypotheses

may be altered according to different importance of

different productions.

h is then called triggering

object of h.

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

190

2b) Else there is h

= p with a corresponding

right hand side object r. With this object there is a

construction method ϕ which takes the triggering

object

h as fixed. It queries the configuration C for

the missing parts of the left hand side of the

production h

which fulfil the constraint π. Thus, the

construction method ϕ may result in none, one or

even many possible objects r. For all of these

objects, new initial hypotheses are added to the

queue. Thus – while the number of objects in C is

always rising – the number of hypotheses in the

queue may rise or fall.

3) While the queue is not empty, one may

continue with step 1) or stop and return the current

configuration as result. This result will be identical

to the final unique solution, if the queue is empty.

Otherwise, the current configuration will only

resemble an approximate solution.

Lütjen (1986) published this interpreter 20 years

ago. Since then, work in this field has shown that the

success of the production system in terms of

reaching a meaningful configuration close to the

unique solution heavily depends on proper

assessment criteria. However, these are needed

anyway in the accumulating association scheme to

have a meaning at all – as discussed in section 3.2.

Moreover, the assessments have to be related to

probabilities. There has been work on this issue as

well (Michaelsen & Stilla, 2002).

There have been different implementation

projects – assembler-based VMS code supporting

special hardware, UNIX-based KBV derivates (an

offspring of the SCHEMA working group), and

simple machine independent MATLAB code.

Currently a new object oriented implementation

using Microsoft

.NET and C# is under way. For this

endeavour we use the acronym

GESTALT

(

Grouping Evidence System for Treatment of

Alternatives in Layered Task Solvers) which has

been mainly motivated by the example given in

section 4.1.

4 TWO EXAMPLE SYSTEMS

In order to show the scope of applicability of the

theory and system outlined in Section 3 we briefly

describe two quite different example systems. The

first example consists of a production system for the

detection of buildings in SAR-images. The second

system was designed to determine the mutual

geometry of image pairs, which is needed, e.g., for

image-based navigation of unmanned aerial

vehicles.

4.1 Building Recognition in SAR

Images

This production system has been constructed to

recognize man-made structures such as buildings in

high resolution SAR images and has been published

in (Michaelsen et al., 2006a). It consists of the

following seven productions:

⎯⎯⎯⎯→

1,1

1,2

1,3

sec

1, 4

1,5

: (line,...,line) longline

: (pixel,...,pixel) spot

: (longline,longline) angle

: (angle,angle) symmetry

:(sy

colinear

regression

adjacent

average

adjacent

inter t

symmetric

axis

p ⎯⎯⎯⎯→

⎯⎯⎯⎯→

1,6

1,7

mmetry,...,symmetry) cluster

: (longline,spot) row

:(row,spot) row

adjacent

average

adjacent

initialize

fitting

append

(7)

1,3

is the standard example for the normal form

given in (3). For a triggering object

longline search

areas around the end points of that line are

constructed and queried for other objects

longline

ending there which must have a different orientation.

Objects

angle inherit most attributes from the

predecessors, however, one new location is

computed by intersecting the two constituting lines.

1,2

is the standard example for the normal form

given in (4). For a triggering object

pixel a search

area around it is constructed and searched for other

objects

pixel. The resulting object spot is positioned

by averaging and thus has sub-pixel accuracy.

Note that this system contains a cyclic part-of

structure – production p

1,7

. A row can be a part of a

larger row. Such recursive structure is common for

string rewriting grammars. It allows generation or

reduction trees of arbitrary depth, and thus the

definition of an infinite language by finite means.

Here the production p

1,2

was the straight forward

way to capture the appearance of bright spots

arranged in long straight rows of equal spacing

where building facades are seen in high-resolution

SAR images.

1,4

captures another important property of

buildings – they tend to have some symmetric

structure. Often this is a non-local property – so that

building parts quite far apart from each other still

give the same symmetry axis. This is an important

cue for man-made architecture. The clustering of

symmetry axis by production p

1,5

requires an

MEANING AND EFFICIENCY IN THE GESTALT-SYSTEM - An Approach to Automatic Image Description

191

appropriate setting of the coordinate system in which

the axis equation attributes and the metric for it are

given. Locality has to be balanced against

orientation.

It is obvious that

pixel and line are the primitive

classes of this system. While

line objects can be

extracted using filter operations designed for

enhancement of contours or line-like image

structures,

pixel objects are found using a bright spot

filter based on inequality operations. The decision

whether such an object is present in a given image

location is based on the filtered image and a

threshold.

4.2 Search for Mutual Image Geometry

This production system for estimating the mutual

geometry of an image pair has been published in

(Michaelsen et al. 2006b). The internal camera

parameters are assumed to be known. It consists of

the following six productions:

∧

⎯⎯⎯⎯→

⎯⎯⎯⎯⎯⎯→

⎯⎯⎯⎯→

2,1

2,2

colinear

2,3

2,4

2,5

: (corresp,corresp) pair

: (pair,...,pair) similarity

: (pair,pair) quad

: (quad,...,quad) homography

:(c

adjacent

scale rot

adjacent

average

inhomogenous

adjacent

svd

⎯⎯⎯⎯⎯→

colinear

2,6

orresp,quad) quint

: (quint,...,quint) ematrix

Nister point

adjacent

Nister point

(8)

2,1

would be a standard example if the relation

adjacency were not negated. For high accuracy of a

similarity transform estimate the two objects

corresp should be far apart from each other. If the

expected number of objects fulfilling the relation

adjacency with respect to the triggering object is one

out of n the expectation for the opposite is n-1 out of

n. The same holds for productions p

2,3

and p

2,5

.This

production system implements a combinatorial

enumeration. If run to the final confluent

interpretation it will have constructed

O(n

) objects

quint where n is the number of primitive objects.

This is usually not feasible. The process has to be

terminated before - with an only approximate

solution. From experience this solution is good

enough and often better than a RASNAC solution

obtained with comparable effort.

Productions p

to p

2,6

contain state-of-the-art

computer vision geometry – namely the

inhomogeneous solution for a planar homography

from four point correspondences, singular value

decomposition, and the 5 point algorithm for

minimal and non-minimal samples of

correspondences as introduced by Nister (2004).

Note that adjacency in the space of homographies as

well as in the space of essential matrices requires

appropriate metrics – both are 3x3 matrices, but

none is a vector space. Homographies have eight

degrees of freedom, while essential matrices have

five. Note also that Nister’s algorithm solves a

polynomial of order ten – giving between zero and

ten solutions. Thus, production p

2,6

usually produces

more than one new object.

It is obvious that

corresp is the only primitive

class of this system. Such a pointwise

correspondence cue between image structures in an

image pair can be acquired by many different

methods – including various trackers and simple

other production systems. Correspondence only

makes sense at image locations where no aperture

problem occurs which is usually tested by squared

averaged gradient filters. A particular image

correspondence object can always be assessed by the

similarity of the appearance in the frames (i.e. some

correlation), the precision of its localization and a

priori knowledge coming e.g. from a Kalman filter

prediction.

5 DISCUSSION AND

CONCLUSIONS

A proper mathematical theory often consists of the

following parts: 1) Define the space of solutions and

prove the existence of a solution; 2) prove

uniqueness of the solution; 3) give a metric in the

space of solutions; 4) give an algorithm iterating to

the solution and prove convergence; 5) prove bounds

on the distance to the solution at a given iteration.

The theory of ‘piling up meaning’ for pictures or

videos outlined in this contribution is very

preliminary yet. There are some results concerning

steps 1) and 2). Most work has been spent on step 4).

Several examples of systems behaving well in

practice were built. However, with step 3) not being

completed we cannot expect that the work on the

applications and on step 4) rests on secure ground –

and step 5) though being very important for

applicability is in far distance.

There is still a severe problem with the meaning

of the accumulative use of productions: As pointed

out in section 3.2. we have to give evidence

attributes with each of our cue objects. They should

in fact be probabilities. This, however, requires

normalization to one. But the objects in a

configuration accumulated so far cannot contain or

reach information from other objects in this set that

VISAPP 2007 - International Conference on Computer Vision Theory and Applications

192

are not preceding them. Giving up this principle

would jeopardise the efficiency and thus

practicability.

We have presented two example systems solving

quite different tasks and operating in a different way.

This demonstrates exemplarily that the GESTALT

interpreter is a useful tool for a broad range of

recognition applications. However, it cannot solve

the problems alone.

Preliminary to its application iconic image

processing tools and segmentation procedures for

the primitives are required. It is hard to mend on the

interpretation level what has been missed and

spoiled in the processing chain before.

Moreover, for many tasks, a final or approximate

interpretation configuration is not sufficient as

result. Further processing and decisions are needed

after the interpretation has been terminated. This

may be quite simple, such as giving the best object

ematrix as result in the system presented in section

4.2. Or a little more complicated – such as giving a

threshold for the quality of the objects

ematrix and

in case there is no better one take the best object

homography. Such system may also interact with a

Kalman filter for flight control of an unmanned

aircraft in both directions – getting prior information

from it and handing measurements of epipole and

rotation to it.

The decision system following on top of the

saliency recognition system outlined in section 4.1.

may either be an AI-reasoning system or also a

human interpreter. Both require a sophisticated

interface.

REFERENCES

Christensen, H. I., Nagel, H.-H. (eds), 2006.Cognitive

Vision Systems, Springer, Berlin LNCS 3948, pp. 183-

198

Draper, B., Collins, R., Brolio, J., Hanson, A., Riseman,

E., 1989. The Schema System, IJCV, Vol. 2 pp. 209-

250.

Janzen, M., 1988. confluent String Rewriting, Springer,

Berlin.

Lütjen, K., 1986. Ein Blackboard-basiertes

Produktionssystem für die automatische

Bildauswertung. In: Hartmann, G. (ed.)

Mustererkennung 1986, DAGM 1986, Springer,

Berlin, Informatik Fachberichte 125, pp. 164-168.

Lütjen, K., 2001. Systeme und Verfahren für strukturelle

Musteranalysen mit Produktionsnetzen, Diss., Univ. of

Karlsruhe, institute for communications engineering,

ISSN: 1433-3821.

Matsuyama, T., Hwang, V. S.-S., 1990. Sigma a

Knowledge-based Image Understanding System,

Plenum Press, New York.

Michaelsen E., Stilla U., 2002. Probabilistic Decisions in

Production Nets: An Example from Vehicle

Recognition. In: Caelli T., Amin A., Duin R. P. W.,

Kamel M., Ridder D. de (eds). Structural, Syntactic

and Statistical Pattern Recognition SSPR/SPR 2002,

Springer, Berlin, LNCS 2396, pp. 225-233.

Michaelsen E., Soergel U., Thoennessen U., 2006a.

Perceptual Grouping in Automatic Detection of Man-

Made Structure in high resolution SAR data. Pattern

Recognition Letters, Vol. 27, No. 4, pp. 218-225.

Michaelsen, E., von Hansen, W., Kirchhof, M., Meidow,

J., Stilla U., 2006b. Estimating the Essential Matrix:

GOODSAC versus RANSAC. ISPRS Symposium on

Photogrammetric Computer Vision (PCV 2006).

Niemann, H., 1989. Pattern Analysis and Understanding,

Springer, Berlin.

Nister, D., 2004. An Efficient Solution to the Five Point

Relative Pose Problem, IEEE PAMI, vol. 26, no. 6,

pp. 756–769.

Sagerer, G., 1982. Darstellung und Nutzung von

Expertenwissen für ein Bildanalysesystem, Diss.,

Univ. of Erlangen-Nürnberg, Springer, Inormatik

Fachberichte 104, Berlin.

Stilla U., Michaelsen E., 1997. Semantic modelling of

man-made objects by production nets. In: Gruen A.,

Baltsavias EP., Henricsson O. (eds). Automatic

extraction of man-made objects fromaerial and space

images (II). Birkhäuser, Basel, pp. 43-52.

MEANING AND EFFICIENCY IN THE GESTALT-SYSTEM - An Approach to Automatic Image Description

193
