DESIGN STRATEGIES FOR WEB BASED ITS APPLICATIONS

A Proposed Architecture in Design of Intelligent Transport Systems Application

Andrea Sponziello

University of Salento, Lecce, Italy

Keywords: Mobile, scripting, web services, ITS, transportation.

Abstract: Modern ITS (Intelligent Transportation System) applications are designed on Web paradigm, exploiting

third-party web services for accessing, for instance, to geographic information and routine such as

cartography, route planning or weather condition services. This allows a customer to use the ITS platform as

an outsourcing service, due to the Web interface, reducing maintenance costs and improving the application

accessibility.The web technology creates only a basis for an easy SOA (Service Oriented Architecture)

integration. In order to have a full SOA compliant ITS application we have to adopt a new perspective for

the ITS applications design: from a monolithic and closed web application to open framework of services

and APIs capable of user customizations.In fact, a third-party application like an ERP (Enterprise Resource

Planning) can take many advantages by linking its vehicles, drivers, workers (and mobile resources in

general) directly with real-time and historical data of the ITS. In this paper we demonstrate that integrating

an ITS application developed on the Java platform with modern Scripting Engines and Languages such as

Groovy, JRuby or Mozilla Rhino greatly enhances the possibility of extending and integrating the

application itself with external applications.

1 INTRODUCTION

This study concerned the specific field of developing

Mobile Fleets Management (MFM) applications

used for monitoring a large number of mobile

resources on the territory using GPS devices that

transmits their positions with Over The Air

transmission protocols as GPRS/UMTS to a Data

Center.

This programmable devices are mounted on

Mobile resources as Cars or Trucks and transmits

GPS position and other stuff to a Data Center that

stores this informations for later use. The registered

data is used to show real-time position of resources

on Maps, generate reporting for data analysis or

generate alarms on events based on geographic

position of the resources (geofencing).

The aim of this work is to provide an ITS web

application with some extension points. An

extension point is a part of the application where the

user can introduce customized code, changing the

application behaviours in order to meet his needs.

In the context of this work we call User a Trusted

Developer of our application, Known by the

Application Administrator and able to plug the

application with new features, applying the

methodology that we describe in the following.

We worked on an existing ITS application called

Realtrack (www.realtrack.it) to introduce some of

the extension points that are the subjects of this

article. This application is completely developed in

Java language using many Open Source frameworks

like Jakarta Struts, JBoss, Postgres/PostGis and

other OS frameworks. We developed extensions

applying many refactorings to the application

architetcture in order to meet the new proposed

specifications.

2 DESIGN OF A WEB BASED ITS

APPLICATION

Here follows the main new specifications we

considered in the refactoring process of the web

based ITS application.

1. The application can publish a set of

predefined events (extension points) that

programmers can use to write their custom

actions when an event occurs. This set of

107

Sponziello A. (2007).

DESIGN STRATEGIES FOR WEB BASED ITS APPLICATIONS - A Proposed Architecture in Design of Intelligent Transport Systems Application.

In Proceedings of the Second International Conference on e-Business, pages 107-113

DOI: 10.5220/0002112201070113

 SciTePress

events is available in many parts of the

application, giving user the possibility to

highly customize the application basic

functionalities. We call this module Event

Handling Module (EHM)

2. The final user can write his own web

services to be embedded directly into the

application. In this way the application can

be easily extended with the introduction of

new services that can be served to some

external applications supplying some extra

functionality (ex. ERP applications). We

call this module Web Services Extension

Module (WSEM)

3. Allowing a sort of dynamic class-loading

(as in Java Language) we can give to the

user the possibility to plug/unplug parts of

the application modifying the standard

application behaviours simply by changing

in a text file (XML or properties file) a

class-name declaration (the extension

point) with another one. This can be easily

obtained using a Dependency Injection

Framework in Application Design like the

Spring Framework or the Jboss

Microcontainer if the application is written

in the Java language. We call this module

the Application Microcontainer

4. The application can be logically divided

into many services that can be

plugged/unplugged based on business

needs. For example the graphical user

interface (GUI) can be decoupled by the

low level services so that customers can use

only low level services to write their own,

customized, GUI. If the application is

designed as an aggregation of services also

the API framework used for writing the

application can be published to final users

that will use the APIs to interoperate with

the various services. For example a specific

service of the application can act himself

like a provider and can publish a set of

client-API that can be used by the GUI

framework to communicate with this

provider taking the information needed to

render a web page. In this case the entire

Service (like the GUI module) can be

considered an extension point because of

the possibility to plug it with a completely

new module written by the final user that

unplugs the original one shipped with the

application.

For the purpose of simplifying customized code

writing we built a Scripting Engine called SEE

(Scripting Embedded Engine) (Sponziello, 2006). It

is behind the scenes of many modules and gives

users the possibility to write custom code in the easy

way provided by scripting languages instead of

compiled ones (like Java). The primary script

languages used by our framework are basically

Groovy, JRuby and Javascript (see References).

They are directly supported and well integrated by

the Java platform. This script technologies easily

provide a simple way to write custom event

handlers, routines or Web Services without the need

of recompilation and with a more user-friendly

syntax. It is important to mention the MOP (Meta

Object Programming) capabilities of the Groovy and

JRuby languages that helps programmers to easily

write DSL (Domain Specific Languages) or the open

classes and duck typing features of either Groovy,

JRuby and Javascript that enhance flexibility of code

scripts giving some features unavailable to the Java

language that we used to write the application itself

(Freeman, 2006).

2.1 The Event Handling Module

(EHM)

The application we are considering supports a wide

set of events, such as:

Table 1: Main application Events.

Event Group Events

Communication OnNewPosition

CRUD

OnMobileNew,

OnMobileUpdate,

OnMobileDelete

GIS OnMapDraw, OnLayerDraw

GUI

OnLogin, OnPageRenderStart,

OnMenuRender

The application processes the arrival of a new GPS

position from the mobile resource in this way:

- stores the position into the database (latitude,

longitude, speed, direction, altitude, board signals,

sampled weather conditions etc.)

- updates related position information (vehicle

status for example)

- verifies some geofence (TODO: explain

Geofence) feature and eventually notifies that event

occurred with a standard message (sms and/or email)

to a set of user-defined addresses.

ICE-B 2007 - International Conference on e-Business

108

Some of the data used by this process was

previously defined by some user with the visual

interface of the application. This user-interface gives

a way for visual creation of Geofences with related

informations about SMS and/or email notifications.

2.1.1 Use Case 1: Custom Geofences

Now suppose that a user would change this standard

behaviour adding or extending the actions that

belongs to the event of a new position arrival

(OnNewPosition event). The framework

accomplishes this need providing the user with the

possibility to add a custom script that implements

the desired actions.

A simple Use Case illustrating the standard

application support for geofencing would be:

1 - the user graphically defines a geofence as a

circle geometry specifying a center and a radius

using the standard application GUI

2 - the system notifies via sms and/or email a

vehicle entering the geofence, communicating this

event with a standard message.

The user wants to extend the standard action related

to the previous event, sending a notification only if

this particular conditions occurs:

- the mobile resource (a vehicle i.e) entered or

exited the geofence (standard - provided by

application)

- the vehicle is over a maximum speed (i.e. 80

km/h) (user defined - not provided by the

application)

- the weather condition is "raining" (user defined

– not provided by the application)

This type of advanced notification is not provided by

the application standard framework that offers only

notifications about entering/exiting from the

geofence's boundary.

The user can so write his own script to handle the

customized event. He selects from the events' list the

preferred event to handle, in this case

onNewPosition. Then he writes and uploads a

simple text file containing the script. This script is

then registered by the System and will be executed

when every onNewPosition event occurs.

The event onNewPosition arises when a new

position is communicated by the vehicle's device.

For example the following script could be written to

handle this Use Case:

onNewPosition:

// the position built by the

framework

position = protContext.curr_position

weather =

service.ws.call("http://www.weatherserv

ice.com/ws", position.lat,

position.lon, new Date() )

geofence1 =

protContext.curr_geofences.my_geofence

if (geofence1 &&

position.speed > "80kmh"

weather.isRaining() ) {

geofence1.disable()

// removes standard actions

geofence1.removeSmsNotifications()

geofence1.removeEmailNotifications()

// a custom message to the driver's

mobile phone

geofence1.addSMSNotification("+39329352

9381", "DECREASE SPEED, PLEASE!")

// a custom message on the user

display

protocolContext.response.add("USER_MESS

AGE","DECREASE SPEED, IT'S RAINING!")

}

Script 1: Custom Geofences.

The application scripting framework provides the

injection of some context objects inside every event

handler script to allow the script author to use the

available system resources.

For example the injected object protocolContext

publishes a set of useful environment properties as

the current generated position

(protocolContext.current_position) or the current

active geofences on the mobile resource with

protocolContext.currentGeofences.

Another useful property published by

protocolContext is protocolContext.vars that is a

map of all raw variables arrived from the vehicle

device. Using these variables a user can adjust

coordinates in order to prevent systematic GPS

errors before storing the position into the database.

Another useful property available in the script is

protocolContext.response that can be used (as in

script 1) to modify the response sent to the client

device.

Other objects are injected by the framework inside

the script. For example the injected service object

that can be used to call remote web services

(service.ws, as in script 1)

DESIGN STRATEGIES FOR WEB BASED ITS APPLICATIONS - A Proposed Architecture in Design of Intelligent

Transport Systems Application

109

2.1.2 Use Case 2: Custom Data Warehouse

Creation

Another useful customization could be the creation

of an alternate positions' datawarehouse (i.e. for a

business intelligence integration) in a location

different from the ITS database. An example script

follows illustrating this possibility:

onNewPosition:

position =

protocolContext.current_position // the

position built by the framework

// invokes a remote WS to perform

geo-data ingestion to an external

datawarehouse

service.ws.call("http://wharehousesite.

com/ws",position.lat, position.lon,

position.speed)

Script 2: Custom Data Warehouse creation.

2.1.3 Use Case 3: Custom Notifications

Another task that can be accomplished with the

application scripting extensions are the notification

of the changed status of a vehicle as in the following

script:

onNewPosition:

previous_pos = position.mobile.pos2

// MOP method

if (previous_pos.status ==

position.ENGINE_OFF ||

position.status ==

position.ENGINE_ON ) {

service.ws.call("http://ws.site.org/ws"

, …)

}

Script 3: Custom notifications.

2.1.4 Script's User Profiling

Every script can be saved on a "per user" profile and

can also be called in chain mode (multiple scripts

per event) so that every event's script can manage

specific tasks and prepare the environment for the

next script.

In this way every application user can have its own

scripts handling its own tasks. For example the

administrator can write some scripts enhancing some

kind of events that are executed before others. Less

privileged users can write their script that are

executed after the administrator's one. Naturally, the

application administrator can disable scripting for

some users.

An example of a script chain is the following:

Figure 1: Script execution chain.

2.2 WSEM (Web Services Extension

Module)

The WSEM module allows the user to write and

publish custom Web Services directly embedded

into the platform. In this way the standard

application can be extended with the introduction of

new services that external applications can call to

retrive particular informations. Using this module

we can see the application itself as a service provider

for other applications and permits easy SOA

integration. To allow the user writing custom web

service we used the REST (Representational State

Transfer) methodology that simplifies the writing of

the Web Service letting the user to publish it using a

customized protocol (not SOAP) and a very simple

calling method. The REST approach really

simplifies the calling of a remote service relying on

the classical HTTP way instead of XML over HTTP

typical of the SOAP approach.

This permits to a Web Service to return not only

XML but also other kind of data as JSON (very

useful for AJAX calls) or Javascript, HTML (useful

to plug new GUI components) , plain text, YAML,

pdf etc.

To give the user the possibility for easily create a

Web Service we used a MVC architecture for the

WSEM module. In this architecture the actions and

views are stored inside the application DB in a

virtual File System instead of the real one so the

services can be created and tested directly from

inside the application itself in a multiuser fashion.

Every action is composed by a Controller

component and one ore more View components. As

for the EHM module some context objects are

automatically injected by the application inside

every controller action, and some of this objects

represents the Model component of the MVC

Pattern.

The controller scripts are written in the Groovy

(reference) language while the View components

are written in the Velocity (see References)

language. To realize this module we developed an

Event rises

Application event processing

Super-User script processing

Other users script processing

ICE-B 2007 - International Conference on e-Business

110

engine called JControl that we published on

sourceforge web site, (see References). The JControl

way of creating new end-user webservices is very

simple. The User that has permissions to create new

web services can enter a special zone of the web

application that acts as a mini IDE for writing web

services. The user have to choose a url route for the

new web service and then create a new Controller

component. This component is simply a Groovy

script that the framework will execute when the url

is called with an HTTP request. Into the script, as for

the case of the EHM module, some objects are

created directly by the framework. This objects are

used to communicate with the Model, use some

APIs to call external web services, save files on the

virtual File System etc. Here follows some use cases

that illustrate this kind of functionalities.

2.2.1 Use case 1: WS to get Mobile

Resources of a Particular Fleet

(XML and HTML)

As we said before every web service is built with 2

components: a controller component (the logic) and

a view component (the presentation). A web service

can present data in text format suitable to be

consumed by a machine (XML, JSON etc.) or by a

Web Browser (HTML). In the second case the web

service module can be used to build new GUI

components for the application. Before writing the

new Web Service the User must choose a new Url

for the web service itself. In the first Use Case the

user wrote a web service to get all the Mobile

Resources that belongs to a particular Fleet. This

web service will be called with an url like this:

http://site/custom/get_fleet_mobiles?id=12

URL: /custom/get_fleet_mobiles

Controller code (Groovy language):

fleet_id = http_request[“id”]

fleet = FleetManager.find(fleet_id)

mobiles = fleet.all_mobiles()

view.put(“fleet”, fleet)

view.put(“mobiles”, mobiles)

View code (Velocity language):

#if ($type==”xml”)

$request.setContentType(“text/xml”)

<fleet>

<name>$fleet.name</name>

<mobiles>$mobiles.size</mobiles>

</fleet>

#foreach ($mobile in $mobiles)

<name>$mobile.name</name>

<type>$mobile.type</type>

<id>$mobile.id</id>

<lat>$mobile.pos.lat</lat>

<lon>$mobile.pos.lon</lon>

<time>$mobile.pos.ts</time>

<speed>$mobile.pos.speed</speed>

<dir>$mobile.pos.direction</dir>

<weather>$mobile.pos.weather</weather>

</position>

</mobile>

#end

</document>

#else

$request.setContentType(“text/html”)

## similar but HTML instead of XML

## ...

#end

2.2.2 Use case 2: Get Last N GPS Data for a

Particular Mobile Resource in KML

Format

KML (Keyhole Markup Language) is the XML used

by Google Earth and Google Maps Applications to

display external GIS data. This Use case shows how

to use the WSEM to generate this kind of data.

An example URL for this Use case is:

http://site/custom/get_locations?id=67&pos_num=5

0&type=kml

URL: /custom/get_locations

Controller code (Groovy language):

mobile_id = http_request[“id”]

n = http_request[“pos_num”]

mobile = MobileManager.find(mobile_id)

// last_pos is an array of N elements

last_pos = mobile.las_pos(n)

view.put(“mobile”, mobile)

view.put(“last_pos”, last_pos)

View code (Velocity language):

#if ($type==”kml”)

$request.setContentType(“application/vn

d.google-earth.kml+xml”)

<?xml version="1.0" encoding="UTF-8"?>

<kml

xmlns="http://earth.google.com/kml/2.0"

#foreach ($mobile in $mobiles)

<name>$mobile.name</name>

DESIGN STRATEGIES FOR WEB BASED ITS APPLICATIONS - A Proposed Architecture in Design of Intelligent

Transport Systems Application

111

<![CDATA[$mobile.description]]>

</description>

<Point>

$mobile.position.lat,

$mobile.position.lon

</coordinates>

</Point>

</Placemark>

#end

</Document>

#end

</kml>

#else

## other types supported

## ...

#end

3 SECURITY ISSUES

Particular attention must be accomplished regarding

securing the User Script Extensions. Not every User

can use the same System Resources like reading or

writing Files on local Filesystem, Opening arbitrary

sockets on arbitrary machines over the Internet,

Writing arbitrary data into the Database. Because of

the java Technology, we can use, indipendently of

the language (Groovy, JRuby or Javascript), the Java

SecurityManager Technology to perform some

actions that prevents some users to access some

resources. The reliability of this approach (using

only the SecurityManager) has not still greatly

covered by our study but we reserve to do it later.

By now this is not a great problem because the user

base is not so wide, but the growing number of users

impose to consider the Security

a primary problem.

4 CONCLUSIONS

The proposed extensions give to the final users the

possibility to develop custom code to modify

system's behaviours without the knowledge of the

application source code, language or other complex

low level design details.

Moreover application's developers can delegate

to final users the addition of particular features.

There is no need to create and maintain new

software branches for user-specific customizations,

that is a very costly and complex work. The

Application's designers will focus on the

development of the main framework with integrated

customization capabilities due to EHM and WSEM

integration. If a customer needs some customization

a developer can solve the problem simply writing

some macro without modifying the source code of

the application creating a new branch for this

customer that needs to be maintained.

Because the application we used for

experimenting with the proposed extensions is a

Web application written with Java language, the

scripting technologies used for this work are Java

based scripting engines in particular Groovy JRuby

and Rhino. These are not the only Java supported

scripting languages but are the best suited for our

purposes because of their standardization inside Java

technology.

The users can write script macros that will be

executed in particular points of the application's

computational lifecycle. We call these extension

points and have the form of events that raise in

particular lifecycle steps. For example, the arrival to

the ITS server of a new position from the moving

vehicle might trigger an event named

onPositionNew. The user who wants to override the

standard application behaviour corresponding to the

arrival of a new position can write a macro that will

be executed by the system every time this event

occurs.

With macros the user can, for example, modify

the geographical coordinates before they are saved

to the Data Base or he can send the coordinates to a

third-party remote application in order to enrich a

Data Warehouse and to perform advanced Business

Intelligence features. Moreover the user can generate

custom notifications to particular users entering

particular geofences. The use of the WSEM module

allows easy publishing of application's data and

functionalities to external applications.

ACKNOWLEDGEMENTS

This work has been developed in the REALTRACK

industrial research project in collaboration within the

Center for Advanced Computational Technologies

of the University of Lecce (Italy) directed by the

Prof. Giovanni Aloisio. The project was partially

funded by the Regione Puglia (Italy) under the POR

2000-2006 measure 3.13. For further information,

please refer to the Web page http://www.realtrack.it.

REFERENCES

Freeman S., 2006. Embedded Domain Specific Language.

In OOPSLA’06, http://www.jmock.org/oopsla2006

ICE-B 2007 - International Conference on e-Business

112

Fernandez O., 2005. Working on the Rails Road, In Object

Technology User Group Meeting, Minneapolis, 2005

Sponziello A., 2006. Scripting Support Extensions for ITS

Applications, In FOSS4G'06,

http://www.foss4g2006.org/contributionDisplay.py?co

ntribId=174&sessionId=42&confId=1

Fensel D.,

Jcontrol, An MVC Framework for the Java language,

http://sourceforge.net/projects/jcontrol/

Groovy, A Scripting language for the java paltform,

http://groovy.codehaus.org/

Jruby, A Ruby implementation for the java platform,

http://jruby.codehaus.org/

Rhino, A Javascript implementation for the Java platform,

http://www.mozilla.org/rhino/

Velocity, A text templating engine,

http://velocity.apache.org

Cowan, Lucena, March 1995, "Abstract Data Views: An

Interface Specification Concept to Enhance Design for

Reuse", IEEE Transactions on Software Engineering,

Vol 21 No 3.

Krasner, Pope, 1988, "A Cookbook for Using the Model-

View-Controller User Interface Paradigm in

Smalltalk-80", Journal of Object Oriented

Programming, August/September.

Parr, Terence (2004) Enforcing Strict Model-View

Separation in Template Engines. In Proceedings

International WWW Conference, New York, USA.

http://wwwconf.ecs.soton.ac.uk/archive/00000578/01/

p224-parr.pdf

Krasner, G., Pope, S. (1988) A description of the model-

view-controller user interface paradigm in the

smalltalk-80 system. Journal of Object Oriented

Programming, issue 3, volume 1.

DESIGN STRATEGIES FOR WEB BASED ITS APPLICATIONS - A Proposed Architecture in Design of Intelligent

Transport Systems Application

113
