EVIE - AN EVENT BROKERING LANGUAGE FOR THE

COMPOSITION OF COLLABORATIVE BUSINESS PROCESSES

Tony O’Hagan

, Shazia Sadiq

and Wasim Sadiq

School of Information Technology and Electrical Engineering

The University of Queensland, St Lucia, QLD 4072

Brisbane, Australia

SAP Research Centre

133 Mary Street, QLD 4000

Brisbane, Australia

Keywords: Business Process Management, Enterprise Application Integration, Service Oriented Computing.

Abstract: Technologies that facilitate the management of collaborative processes are high on the agenda for enterprise

software developers. One of the greatest difficulties in this respect is achieving a streamlined pipeline from

business modelling to execution infrastructures. In this paper we present Evie - an approach for rapid design

and deployment of event driven collaborative processes based on significant language extensions to Java

that are characterized by abstract and succinct constructs. The new language is positioned within an overall

framework that provides a bridge between a high level modelling tool and the underlying deployment

environment.

1 INTRODUCTION

Process enablement is firmly grounded as a key

objective in enterprise systems. However, with

current business trends towards outsourcing and

virtual alliances, the importance of business process

integration has strongly emerged. Business process

integration (BPI), understood as the controlled

sharing of data and applications within and across an

enterprise boundary, is considered to be one of the

main strategies of many organizations. BPI offers

new business opportunities, benefits of maximizing

operational productivity, improved business resource

utilization, and supports businesses in gaining

competitive advantages through customer and

supplier satisfaction.

Process enactment systems traditionally rely on

the control flow defined within the process model to

drive the process. This approach has been highly

successful in coordinative processes. However, this

approach becomes arguable for Collaborative

Business Processes (CBPs) that are characterized by

asynchronous and highly dynamic business activity.

In collaborative processes, it is expected that

independent specialized application components

both within and across organizational boundaries

will be capable of detecting and responding to the

events that dictate subsequent process flow. These

events can be many, can arise at any time during the

overall process and their (time of) occurrence cannot

be anticipated by dependent components.

Modelling a collaborative process through the

exchange of event data rather than through a rigid

control flow between its activities is a significantly

different albeit more natural way of capturing the

logic behind collaborative processes. Thus, business

activity takes place within application components,

however the context for the business activity is

provided by the event data. How the business

activity deals with the data is not the question,

instead capturing which business activity may need

to be informed about a particular event, and when, is

the question at hand.

The critical factor is that the process

enforcement system be empowered with sufficient

intelligence so that the appropriate action can be

taken when a particular event notification arrives.

This action basically consists of communicating the

relevant data to the right process participant such as,

an application component, a business activity

372

O’Hagan T., Sadiqand S. and Sadiq W. (2007).

EVIE - AN EVENT BROKERING LANGUAGE FOR THE COMPOSITION OF COLLABORATIVE BUSINESS PROCESSES.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 372-377

DOI: 10.5220/0002363403720377

 SciTePress

performer, or a workflow management system, at the

right time.

In this paper, we present an approach that

attempts to capture the dynamics of CBPs and the

underlying event dependencies through a scripting

language. Difficulties in providing visual models

and toolkits for business analysts to capture CBPs

are well known. The premise of our programming

approach is that CBP setups are mostly undertaken

by technical teams often software engineers, where

high level models of limited or tedious functionality

may prove unproductive. Without compromising on

the importance of a model-driven approach, the Java

language extensions are intended to provide the

power of a programming style language, but at a

sufficiently high level of abstraction. The developed

program is intended to serve two objectives: to serve

as a source for setting up an execution environment;

and to serve as a target for a high level model (if

available).

We first discuss the motivation and background

architecture for Evie. We then present features of the

Evie language with the help of an example. Section

4 elaborates on the position of this work in current

technology developments. Conclusions and main

contributions are summarized in section 5.

2 EVIE FRAMEWORK

The Evie language is motivated by the need for rapid

but reliable development of services that act as

message brokers or gateways providing routing,

transport and encoding mappings between disparate

legacy and business partner servers.

There is significant evidence that such

infrastructures are featuring prominently in current

enterprise systems (see SAP Exchange

Infrastructure, IBM WebSphere, BEA AquaLogic,

Oracle Integration and Microsoft Biztalk).

Consequently, the need to provide tools for rapid

development, testing and deployment for broker and

gateway services has increased manifold. The Evie

language targets this aspect by delivering an abstract

and succinct means of expressing broker business

logic. Compiled Evie programs are deployed within

an execution framework API and user interface tools

that support rapid systems integration development

and simulation testing.

The overall process for design and deployment

of Evie applications can be summarized as: (1) A

high level collaboration process is prepared by a

business analyst using a model design tool that

creates a set of graphical design artefacts. (2) A

model compiler translates these into a skeleton Evie

rule script that is augmented by a software engineer

into a complete set of executable rules. (3) Finally,

an Evie compiler translates Evie rules into Java

components to be deployed and executed inside the

Evie Execution Framework.

2.1 Execution Framework

The Evie execution framework is a Java API class

library from which a standalone broker or gateway

service is constructed. Its architecture is composed

of four tiers that control external communications,

event routing, rule execution, and data persistence..

CBP partner organizations each agree that they

will expose services that can be characterized by

specific event behaviour. The behavioural contract

between these services will include agreement on

event message types, and rules governing message

exchange. The behavioural contract of a service is

referred to as its service type and typically

corresponds to a business role. A service instance is

any partner service that exhibits the corresponding

service type (role) behaviour. An Evie framework

server can implement multiple service instances for

multiple partners.

The first tier implements communications to

external services. Evie developers can defer until

deployment decisions such as service end point

addresses, channel multiplexing of service instances,

transport protocols and event message encoding.

In the second tier, input and output events are

routed between external channels and internal

service instances. This isolation ensures that

developers describe interactions with abstract event

and service types and thus focus on conceptual

business logic rather than communications wiring.

The core third tier manages the Evie scripts

consisting of ECA rules containing event conditions

and corresponding actions (discussed in the next

section). Compiled event conditions subscribe to

specific input events. As each input event arrives it

is matched to a set of persistent event subscriptions

corresponding to active rule instances. Each

matching subscription activates a compiler generated

event procedure corresponding to either the rule

action or a partial evaluation of a complex event

condition. Evie supports persistent threads

containing Java context variables. When an event

procedure is fired, it is passed a reference to the

persistent thread that created the original event

subscription thus restoring the execution context of a

rule instance. Context variables are used to compose

and send output messages and compose and activate

new rules.

The fourth tier employs a transactional object-

relational mapping engine to efficiently persist and

EVIE - AN EVENT BROKERING LANGUAGE FOR THE COMPOSITION OF COLLABORATIVE BUSINESS

PROCESSES

373

query the state of service instances, events, event

subscriptions and persistent threads.

3 EVIE LANGUAGE

The Evie language defines a notation for event

processing based on event-condition-action (ECA)

rules (Dayal et al., 1988).

Events: Evie defines an event as a CBP state

change message observable at a given point in time.

Event are communicated between partner services

through messaging infrastructures. For collaborative

business processes, they provide the impetus for

process progression. Event types identify primitive

CBP events.

Event Conditions: An Evie event condition is a

rule precondition that defines when a rule action

executes. Simple event conditions observe a single

event type. Complex conditions use logical and

temporal operators to express conditions requiring

multiple events occurring over a period of time.

Conditions may reference attributes of the event

type (Payment) or sender’s service type (Customer):

receive Payment p from Customer c

where c.status = ’approved’

AND p.amount < = c.maxPayment

AND NOT delay(+days(3))

Actions: Evie Actions can compose and send

output messages, read or update context variables

and, interestingly, dynamically compose and activate

new rule instances. They may also execute any other

arbitrary Java statements.

3.1 A Request for Quote Example

Consider the following Request for Quote (RFQ)

CPB example, with three participant roles: RFQ

Manager, Requester and Supplier. The Requester

issues a RFQ document requesting quotes for supply

of a given product from a set of Suppliers. The RFQ

Manager supervises the tender process..Fig. 1 below

summarizes the event flow between participant

roles.

Figure 1: The Request for Quote Event Flows.

We commence the design process by identifying

the service and message types in the collaboration

(Example 1a)

The rules that represent the behaviour of a

participant role are then coded against the

corresponding service type definition. Rules for the

RFQ Manager broker are illustrated in Example 1b.

Rules for Requester and Supplier can also be

implemented in Evie in order to simulate the

behaviour of these external services. Simulation

rules allow a developer to prototype interaction with

external service types, and can also be used to assist

in acceptance testing of an Evie broker or its

application services.

We observe that an RFQ process can be

decomposed into a sequence of phases that exhibit

different response behaviour. Rule instances bound

to the initial RFQ event are dynamically activated

and deactivated as these behavioural phases

progress.

A.1 package evie.rfq;

A.2 message RFQ {

A.3 string (50) description;

A.4 string (50) product;

A.5 }

A.6 message RFQ_Expired { }

A.7 message RFQ_Complete { }

A.8 message Quote { money bidPrice; }

A.9 message QuoteSuccess { Quote quote; }

A.10 message QuoteFailure {

A.11 string (80) reason;

A.12 }

A.13 abstract service Organization {

A.14 string (50) companyName;

A.15 accepts QuoteSuccess from RFQ_Manager;

A.16 }

A.17 service Requester extends Organization{}

A.18 service Supplier extends Organization {

A.19 money maxPrice;

A.20 int maxDelay;

A.21 accepts RFQ from RFQ_Manager;

A.22 accepts QuoteFailure from RFQ_Manager;

A.23 }

A.24 service RFQ_Manager {

A.25 accepts RFQ from Requester;

A.26 accepts Quote from Supplier;

A.27 accepts RFQ_Expired, RFQ_Completed

A.28 from self;

A.29 }

Example 1a: Service types and Event message types.

Phase I: The Requester initiates a new thread by

sending a RFQ event to the RFQ_Manager (B.2 in

Example 1b). The RFQ specifies the single product

required and a Quote submission deadline. Future

events must be correlated (B.6) with the RFQ event

to indicate that they are part of this process. The

RFQ Manager then forwards the RFQ to all

Suppliers (B.9) and waits for response Quotes

(B.13). The lowest bid Quote is recorded (B.15-18).

Requester

RFQ

Manager

Supplier

RFQ

{Quote}

4. RFQ

ired

5a. QuoteSuccess

6. QuoteFailure

5b. QuoteSuccess

7. RFQ

Com

leted

ICEIS 2007 - International Conference on Enterprise Information Systems

374

All state changes resulting from arrival of an RFQ

message will be atomically persisted.

Phase II: The RFQ Manager schedules an

abstracted RFQ_Expired event to be sent to itself

when the RFQ deadline expires (B.10-12). Once this

event occurs (B.20), the RFQ process enters a new

phase and consequently the RFQ Manager behavior

and rules change. The then when

construct

(B.20) causes threads and active rule instances in the

previous phase (B.8 – B.19) to be terminated before

executing actions in the new phase (B.21 – B.38).

Phase III: The RFQ Manager then notifies the

successful Supplier and Requester (B.24-25) and

with a QuoteSuccess event that contains an

embedded Quote event. Late Quotes are now

rejected with a QuoteFailure reply (B.33-38).

In order to clean up the remaining event Quote

subscription, after a 30 day period the final phase

terminates with an RFQ_Completed event (B.31,

B.39) (final phase) after which time all RFQ

correlated rule instances are terminated. Any input

events that are not matched to an active rule instance

will then be bounced back to their sender by the

framework as an exception.

3.2 Additional Language Features

The example above highlights some of the features

of Evie which provide an effective means to satisfy

particular requirements of event driven CBPs.

However, the Evie language supports several other

features and characteristics which are briefly

summarized below:

Type Inheritance and Aggregation. Service and

event types support type inheritance. Event types

may be imported from other collaborations so that

inter-collaboration scenarios are supported and

industry standard types (e.g. UBL at www.oasis-

open.org) can be reused.

Event types can contain references to other

events (A.9) or service instances. Events may also

contain event and service instance collections (lists,

sets and maps).

A service type can contain attributes used to

query a set of service instances or configure service

rule behaviour.

Event correlation. Evie

receive event conditions

and

send statements can apply an arbitrary message

correlation constraint on input events conditions or

set a correlation property on output events (B.37). It

can be an arbitrary computed string value or (more

commonly) an event instance.

The correlate statement (B.4) sets a default

correlation value for all receive and delay

conditions and send statements within its scope.

A correlation scope effectively partitions all

input and output events into groups of execution

threads related to an initiating event instance (e.g.

RFQ event B.6). This partitioning is similar to a

workflow process instance. However, unlike

workflow processes, nested event conditions

(receive) and event compositions (send) can

elect to regroup events under a different correlation

value or event. This allows us to perform event

grouping and batch operations on related events.

Aggregate Conditions. An Evie receive event

condition can group events into a collection and

specify aggregate conditions on that collection. The

into clause in a receive condition collects a set

of messages of the same type. For example the

following condition collects the next three events of

type A with field A.x = 1 into the list aList.

when (receive A a into List<A> aList

where a.x = 1 AND count(aList) >= 3) { …

}

This feature is used in conjunction with either an

AND or SEQ operators. When used with the AND

operator, the receive condition is evaluated as

immediately true, however, it continues to collect

messages until the value of the event condition

cond

is known.

receive A into List<A> aList AND (cond

)

Similarly, when used with the SEQ operator, the

receive condition is again immediately evaluated

as true but in this case only collects messages until

the first message arrives that is used by

cond

receive A into List<A> aList SEQ (cond

)

Nested Rule Overriding. Event subscriptions

resulting from nested child rules may override the

consumption of events by parent rule instances. This

supports a common business case where we need to

initiate a new execution thread (using a repeat

rule) whenever an input message of a known type

arrives containing a previously unobserved key

value. The outer rule creates new threads, while an

inner nested rule can consume messages of the same

type and key as a prior initiating message.

Consumption overriding can also occur within the

evaluation of complex conditions involving multiple

events.

repeat when (receive A firstA) {

repeat when (receive A a correlate firstA) {

// Process A events correlated with firstA.

// that arrives within 30 minutes.

} then when (delay(mins(30)) {

// terminate

}

Mutually Exclusive Rules. A list of Evie rules that

are activated together can be identified as mutually

exclusive. When one of these rules fires, others in

the same persistent thread are automatically

EVIE - AN EVENT BROKERING LANGUAGE FOR THE COMPOSITION OF COLLABORATIVE BUSINESS

PROCESSES

375

deactivated. If more than one fires concurrently then

the first rule has precedence.

A repeat exclusive rule can be used when a

CBP cyclically toggles between mutually exclusive

phases.

Multidimensional and Dynamic Conversations.

Complex CBPs may be multidimensional involving

any number of service types and instances. New

service instances may be dynamically registered and

deregistered within an active CBP.

B.1 package evie.rfq;

B.2

B.3 service input rules RFQ_Manager {

B.4 repeat when (receive RFQ rfq // Phase I

B.5 from Requester requester) {

B.6 correlate (rfq) {

B.7 Quote bestQuote = null;

B.8 when (true) {

B.9 send rfq to role Supplier;

B.10 when (delay(rfq.deadline)) {

B.11 send new RFQ_Expired() to self;

B.12 } // when

B.13 repeat when (receive Quote quote

B.14 from Supplier) {

B.15 if (bestQuote == null ||

B.16 bestQuote.bidPrice >

quote.bidPrice) {

B.17 bestQuote = quote;

B.18 } // if

B.19 } // when

B.20 } then when (receive RFQ_Expired from

self) { // Phase II

B.21 log.info("Expired RFQ: "

B.22 + rfq.description);

B.23 if (bestQuote != null) {

B.24 send new QuoteSuccess(

quote := bestQuote)

B.25 to requester, bestQuote.sender;

B.26 } else {

B.27 send new QuoteFailure(reason :=

B.28 "No Quotes received before

deadline") to requester;

B.29 }

B.30 send new RFQ_Completed()

B.31 to self delay +days(30);

B.32 repeat when (receive Quote quote

B.33 from Supplier) {

B.34 send new QuoteFailure(reason :=

B.35 "Quote not received before

deadline")

to quote.sender

correlate quote;

B.36 } // repeat when

B.37 }then when (receive RFQ_Completed

from self){ // Phase III

B.38 log.info("Completed RFQ: "

B.39 + rfq.description);

B.40 }

B.41 }

B.42 }

B.43 }

B.44 }

Example 1b: RFQ Manager Rules.

Fine-grained Dynamic Access Control. Evie rules

not only describe what the event must contain but

also and when the event may be sent or received and

who may send or receive it. Rules that govern these

constraint dimensions can be dynamically composed

and correlated based on past observed events.

Persistent Context Variables. An Evie rule binds a

condition to an action. When an event condition

matches an input event sequence, these events (and

related sender services) are bound to persistent

context variables declared as part of the condition.

The rule action or nested rules may then reference

these newly bound context variables.

Threads and Transactional Memory. In Example

1b, a repeating rule captures an RFQ event (B.4) and

creates a new persistent thread containing the

context variable bestQuote (B.7).

Child threads spawned by a nested repeat rule

(B.13), read and update data from shared parent

threads (B.17). The framework employs optimistic

locking to detect and retry transactions when

concurrent update conflicts occur with persistent

threads. The Evie compiler detects reads (B.15-16)

and updates (B.17) to shared variables and emits

code to ensure that the optimistic locking occurs.

The implied transactional memory model (Shavit

et al, 1995) significantly alters the semantics of

context variables. It delivers a simple, transparent

and scalable solution. It also significantly reduces

the code complexity normally associated with

concurrent state management.

4 RELATED TECHNOLOGIES

During the past several years, as enterprise software

has evolved, there has been extensive research on

enterprise architectures in pursuit of the evasive

business-IT alignment.

From the technology perspective, the most

significant development in the recent past impacting

on enterprise architectures has been through service

oriented architectures or SOA (Alonso et al., 2004).

Even though an essential stepping stone for service

enablement of enterprise applications, web services

standards do not provide the complete solution for

CBPs.

Achieving communication between disparate

enterprise applications through messaging is well

established in message oriented middleware

(middleware.org), with recent trends towards

solutions that can scale beyond the traditional hub-

and-spoke message broker. The extended

functionality of the Enterprise Service Bus (ESB)

ICEIS 2007 - International Conference on Enterprise Information Systems

376

(Chappell, 2004) is currently a dominant approach in

this respect, providing the ability to store messages

and establishing streamlined service communication.

Recent developments from business software

vendors have identified the need for solutions that

go beyond service enablement and communication

capability. These provide a development

environment that allows multiple services both

within and across enterprise systems to be collated

into value added composite applications (see ESA &

CAF from sap.com).

We observe that a critical aspect of current

enterprise architectures based on the above

approaches is the management of the rules for

service interaction (serviceinterationpatterns.com).

This functionality would naturally reside in

middleware components and is the main driver for

the approach presented in this paper. While there

have been significant developments within the first

two phases of service enablement and

communication, the last phase of managing service

interaction still holds many challenges.

Difficulties in modelling service interactions

through typical control flow constructs as found in

workflow modelling languages (workflowpatterns.

com) are known to be ineffective in the CBP

scenario due to the scale of options. Instead,

approaches that utilize event processing have

emerged as a more promising alternative (Luckham,

2002). Some operators and related event algebras

can be found in: HiPAC (Dayal et al., 1988),

Compose (Gehani et al., 1992), Snoop (Charavarthy

et al., 1994), RAPIDE (Luckham, 2002), TriGS

(Retschitzegger, 1998), (Cao et al. 2006).

5 CONCLUSIONS

The primary purpose of the Evie approach is to

inter-connect the high level business models with

underlying execution infrastructures within the

context of event based CBPs.

In this paper we have presented an approach that

provides the capability to setup an executable

environment for event based CBPs through a rather

slim specification. The Evie framework is well

aligned with current trends towards event based

architectures for large scale integration systems.

However, the proposed approach is distinguished in

three respects:

− providing simple and uniform language

constructs that allow the specification of diverse

service interaction patterns

− ability to provide a level of abstraction from the

execution details due to the compilation phase

that generates the requisite objects and code for

execution

− utilization of an execution model based on event

subscription, that provides the ability to cater for

high volume and long duration processes with

minimal impact on system performance and

response latency

An important aspect of this approach is the

ability to generate an Evie program from a high level

modelling tool. This aspect has not been considered

in this paper, but is part of our future work.

REFERENCES

Alonso, G., Casati, F., Kuno, H., Machiraju, V (2004)

Web Services Concepts, Architectures and

Applications. Springer Verlag

Chakravarthy, S., Krishnaprasad, V., Anwar, E., & Kim,

S.-K. (1994). Composite Events for Active Databases:

Semantics, Contexts and Detection. Paper presented at

the Proceedings of 20th International Conference on

Very Large Data Bases (VLDB' 94), Santiago, Chile.

Chappell, D. A. (2004). Enterprise Service Bus (1st ed.).

Sebastopol, California: O'Reilly Media, Inc.

DatMa Cao, Maria E. Orlowska, Shazia W. Sadiq. (2006)

Formal Considerations of Rule-Based Messaging for

Business Process Integration, Special Issue of

Cybernetics and Systems: An International Journal,

Vol 37/2 (Feb/March 2006).

Dayal, U., Blaustein, B. T., Buchmann, A. P.,

Chakravarthy, U. S., Hsu, M., Ladin, R., et al. (1988).

The HiPAC Project: Combining Active Databases and

Timing Constraints. ACM's Special Interest Group on

Management Of Data (SIGMOD), 17(1), 51-70.

Gehani, N. H., Jagadish, H. V., & Shmueli, O. (1992).

Event specification in an active object-oriented

database. Proceedings of the 1992 ACM Special

Interest Group on Management Of Data international

conference on Management of Data (SIGMOD'92),

San Diego, California, United States.

Luckham, D. C. (2002). The power of events: an

introduction to complex event processing in

distributed enterprise systems. Boston, USA: Addison-

Wesley.

Retschitzegger, W. (1998). Composite Event Management

in TriGS - Concepts and Implementation. Paper

presented at the Proceedings of the 9th International

Conference on Database and Expert Systems

Applications (DEXA '98), Vienna, Austria.

Nir Shavit and Dan Touitou. Software Transactional

Memory. Proceedings of the 14th ACM Symposium

on Principles of Distributed Computing, pp.204–213.

August 1995.

EVIE - AN EVENT BROKERING LANGUAGE FOR THE COMPOSITION OF COLLABORATIVE BUSINESS

PROCESSES

377
