A CONTINUOUS DATA INTEGRATION METHODOLOGY FOR

SUPPORTING REAL-TIME DATA WAREHOUSING

Ricardo Jorge Santos

(1)

and Jorge Bernardino

(1, 2)

(1)

CISUC – Centre of Informatics and Systems of the University of Coimbra - University of Coimbra

(2)

ISEC – Superior Engineering Institute of Coimbra – Polytechnic Institute of Coimbra

Keywords: Real-time and active data warehousing, continuous data integration, refreshment loading process.

Abstract: A data warehouse provides information for analytical processing, decision making and data mining tools.

As the concept of real-time enterprise evolves, the synchronism between transactional data and data

warehouses, statically implemented, has been reviewed. Traditional data warehouse systems have static

structures of their schemas and relationships between data, and therefore are not able to support any

dynamics in their structure and content. Their data is only periodically updated because they are not

prepared for continuous data integration. For these purposes, real-time data warehouses seem to be very

promising. In this paper we present a methodology on how to adapt data warehouse schemas and user-end

OLAP (On-Line Analytical Processing) queries for efficiently supporting real-time data integration. To

accomplish this, we use techniques such as table structure replication and query predicate restrictions for

selecting data, managing to enable continuous data integration in the data warehouse with minimum impact

in query execution time. We demonstrate the functionality of the method by analyzing its impact in query

performance using benchmark TPC-H executing query workloads while simultaneously performing

continuous data integration at various insertion time rates.

1 INTRODUCTION

A data warehouse (DW) collects data from multiple

heterogeneous operational source (OLTP – On-Line

Transaction Processing) systems and stores

integrated information in a central repository, used

by analytical applications (OLAP – On-Line

Analytical Processing) with different user

requirements. The common form of getting decision

making information is using OLAP tools

(Chaudhuri, 1997). The data source for these tools is

the DW data area, where records are updated

periodically using ETL (Extraction, Transformation

and Loading) tools. ETL processes identify and

extract relevant data from OLTP source systems,

cleaning and molding it into an adequate integrated

format and finally, loading the final formatted data

into the DW’s database (DB).

Executing this update periodically implies that

most recent OLTP source records are not included

into the data area, being excluded from the results

supplied by OLAP tools. It has been assumed that

data in the DW can lag at least a day if not a week or

a month behind the actual operational data in the

OLTP systems (Zurek, 2001). This has been based

on the notion that business decisions do not require

up-to-date information, but only the (recent) history.

This still holds for a wide range of traditional

businesses such as traditional retailing. However,

advents like e-business, online telecommunications

and health systems, for instance, information should

be delivered as fast as possible to knowledge

workers and decision systems which rely on it to

react in a near real-time manner, according to the

most recent data captured by an organization’s

information system (Inmon, 2001). In many health

systems, all new data must be analyzed and coped

with as a continuous data stream. It has to be

immediately processed in order to trigger responses

to knowledge workers and decision makers. In most

cases, update delays greater than a few seconds may

jeopardise the usefulness of the whole system. When

using DWs in this kind of systems, supporting real-

time data warehousing (RTDW) is a vital issue.

These scenarios suggest that the time between the

moment operational data is recorded and the

moment it is required for analytical purposes is

dramatically reduced, making RTDW support a

589

Jorge Santos R. and Bernardino J. (2007).

A CONTINUOUS DATA INTEGRATION METHODOLOGY FOR SUPPORTING REAL-TIME DATA WAREHOUSING.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 589-595

DOI: 10.5220/0002377205890595

 SciTePress

critical issue. Additionally, the real-time enterprise

requires data to be always up to date.

DW refreshment (integration of new data) is

traditionally performed in off-line fashion, implying

that while processes for updating the data area are

executed, OLAP users and applications cannot

access any data. This set of activities takes place in a

loading time window, usually during the night, in a

daily, weekly or even monthly basis, to avoid

overloading the operational OLTP source systems

with the extra workload of this workflow. Active

Data Warehousing refers a new trend where DWs

are updated as frequently as possible, due to high

demands of users for fresh data. Real-Time Data

Warehousing (RTDW) is also referred for that

reason in (White, 2002). The conclusions presented

from a knowledge exchange network formed by

major technological partners in Denmark (Pederson,

2004) refer that all partners agree real-time

enterprise and continuous data availability is

considered a short term priority for all business and

general data-based advents.

In a nutshell, accomplishing near zero latency

between OLTP and OLAP systems consists in

insuring continuous data integration from the first

type of systems to the other. To make this feasible,

several issues need to be taken under consideration:

(1) Operational OLTP systems are designed to meet

well-specified (short) response time requirements,

meaning that a RTDW scenario would have to cope

with the overhead implied in those OLTP systems;

(2) The DW tables directly related with transactional

records (commonly named as fact tables) are usually

huge in size, and therefore, addition of new data and

consequent operations such as index updating would

certainly have impact in OLAP systems’

performance and data availability. Our work focuses

on the DW perspective, presenting an efficient

methodology for continuous data integration ETL

loading process and techniques on how to adapt the

DW’s schemas for supporting continuous data

integration and adapting OLAP queries for using all

the integrated data.

The remainder of this paper is as follows. In

section 2, we refer background and related work in

real-time data warehousing. Section 3 explains our

methodology, and in section 4 we present an

experimental evaluation and demonstrate its

functionality. The final section contains concluding

remarks and future work.

2 RELATED WORK

The DW needs to be updated continuously to reflect

source data updates. DW users are often not only

interested in monitoring current information, but

also in analyzing the history to predict future trends.

Therefore, real-world DWs are often temporal, but

their temporal support is implemented in an ad doc

manner that is difficult to automate. In practice,

many operational source systems are nontemporal,

i.e., they store only the current state of their data, not

the complete history. So far, research has mostly

focused on the problem of maintaining the

warehouse in its traditional periodically update setup

(Yang, 2001B) (Labio, 2000). In a different line of

research, data streams (Abadi, 2003) (Babu, 2001)

(Lomet, 2003) (Srivastava, 2004) appear as a

potential solution. Nevertheless, research in data

streams has focused on topics concerning the front-

end, such as on-the-fly computation of queries

without a systematic treatment of the issues raised at

the back-end of a DW (Karakasidis, 2005). Much of

the recent work dedicated to RTDW is focused on

conceptual ETL modelling (Vassiliadis, 2001)

(Bruckner, 2002A) (Bouzeghoub, 1999) (Simitsis,

2005), lacking the presentation of specific

extraction, transformation and loading algorithms

along with their consequent OLTP and OLAP

performance issues. Our contribution is the

presentation of a methodology which efficiently

enables continuous data integration in the DW and

aims to minimize its negative impact in OLAP end

user query workload executions. The issues focused

in this paper concern the DW end of the system,

referring how to perform the loading processes of

ETL procedures and the DW’s data area usage for

efficiently supporting continuous data integration.

Extracting and transforming of operational (OLTP)

source systems data are not the focus of this paper.

In (Bouzeghoub, 1999) the authors describe an

approach which clearly separates the DW

refreshment process from its traditional handling as

a view maintenance or bulk loading process. They

provide a conceptual model of the process, treated as

a composite workflow, but they do not describe how

to efficiently propagate the date. In (Vassiliadis,

2001), authors describe ARKTOS ETL tool, capable

of modeling and executing practical ETL scenarios

by providing explicit primitives for capturing

common tasks (such as data cleaning, scheduling

and data transformations). ARKTOS uses a

declarative language, offering graphical and

declarative features for defining DW

transformations optimizes execution of complex

ICEIS 2007 - International Conference on Enterprise Information Systems

590

sequences for transformation and cleansing tasks.

Recently, (Kuhn, 2003) presents a zero-delay DW

with Gong, which assists in providing confidence in

the data available to every branch of the

organization. Gong, a Tecco product (Binder, 2003),

offers data uni/bi-directional replication between

homogeneous and heterogeneous distributed DBs.

Gong enables zero-delay business, assisting in daily

running and decision making in the organization.

3 OUR METHODOLOGY

The main problems in maximizing functionality of a

RTDW are related with ETL processes needed for

integrating new data. These processes lead to two

major problems: (1) a significant amount of

processing time is necessary for extracting and

transforming OLTP data, that affects the processing

speed and availability of the OLTP source systems;

(2) DW updating operations are complex and time

consuming, lowering its availability to OLAP

applications and end users. The major issue is how

to enable continuous data integration, assuring that it

minimizes negative impact in main characteristics of

the system, such as:

• OLAP analytical most recent data availability;

• OLAP analytical environments’ response time;

• OLTP operational systems’ response time.

Therefore, we are motivated by the following

requirements in real-time data warehousing:

• Maximizing the freshness of DW data by

efficiently and rapidly integrating most recent

OLTP data, preferably with continuous data

integration;

• Minimizing OLAP instructions response time

while simultaneously performing continuous

data integration;

From the DW side, updating huge tables and

related structures (such as indexes, materialized

views and other integrated components) makes

executing OLAP query workloads simultaneously

with continuous data integration a very difficult

task. Our methodology shows how to minimize the

processing time and workload required for update

processes. We also present how to adapt those

OLAP workloads in order to take advantage of all

the most recent data and minimize the impact caused

by its integration in its execution time. Finally, our

methodology allows to facilitate the DW off-line

update time window, because the extraction and

transformation issues are no longer present at that

moment, for the data already lies within the DW and

all ETL data extraction and/or transformation

routines have been executed during the continuous

data integration. Furthermore, the data structure of

the replicated tables is exactly the same as the

original DW schema. This minimizes the time

window for packing the data area, since its update

represents a one step process by resuming itself as a

cut-and-paste operation from the temporary tables to

the original ones, as we shall demonstrate further on.

Our methodology is focused on four major areas:

(1) data warehouse schema adaptation; (2) ETL

loading procedures; (3) OLAP query adaptation; and

(4) DW database packing and reoptimization.

3.1 Adapting the DW Schema

For the area concerning DW schema adaptation, we

adopt the method presented in Figure 1. By

supplying empty or small sized tables without any

kind of constraint or attached physical file related to

it for supporting the record insertion operations

inherent to continuous data integration, we

guarantee the simplest and fastest logical and

physical support for achieving our goals (Kimball,

2005). Transactional OLTP records should be

loaded into the DW sequentially. The unique

sequential identifier attribute present in each

temporary table will allow discarding the rows

which have been replaced for the identified OLTP

transaction, as we shall demonstrate further on.

Data warehouse schema adaptation method for

supporting real-time data warehousing: Creation of

an exact structural replica of all the tables of the data

warehouse that could eventually receive new data.

These tables (referred from now on as temporary

tables) are to be created empty of contents, with no

defined indexes, primary key, or constraints of any

kind, including referential integrity. For each table, an

extra attribute must be created, for storing a unique

sequential identifier related to the insertion of each row

within the temporary tables.

Figure 1: Method for adapting the data warehouse’s

schema for supporting our real-time methodology.

3.2 ETL Loading Procedures

To refresh the DW, once the ETL application has

extracted and transformed the OLTP data into the

correct format for loading the data area, it shall

proceed immediately in inserting that record as a

new row in the correspondent temporary table,

filling the unique sequential identifier attribute with

the autoincremented number. This number starts at 1

for the first record to insert in the DW after

executing the packing and reoptimizing technique

A CONTINUOUS DATA INTEGRATION METHODOLOGY FOR SUPPORTING REAL-TIME DATA

WAREHOUSING

591

(explained in section 3.4), and then autoincremented

by one unit for each record insertion. The algorithm

for continuous data integration by the ETL tool is

similar to Figure 2.

Trigger for each new record in OLTP system

Extract new record from OLTP system

Clean and transform the OLTP data, shaping it into

the data warehouse destination table’s format

Increment record insertion unique counter

Create a new record in the data warehouse

temporary destination table

Insert the data in the temporary destination table’s

new record, along with the value of the record

insertion unique counter

End_Trigger

Figure 2: Continuous data integration algo in ETL tool.

3.3 OLAP Query Adaptation

Suppose a sales data warehouse has the schema

illustrated in Figure 3, with two dimensional tables

(Store and Customer, representing business

descriptor entities) and one fact table (Sales, storing

business measures aggregated from transactions).

This DW stores sales value per store, per customer,

per day.

Figure 3: Sample sales data warehouse schema.

Consider the OLAP query presented in Figure 4,

used for calculating the total revenue per store in the

last seven days.

SELECT S_StoreKey,

Sum(S_Value) AS Last7DaysSaleVal

FROM Sales

WHERE S_Date>=Date()-7

GROUP BY S_StoreKey

Figure 4: OLAP query for calculating the total revenue per

store in last seven days.

The modified schema for supporting RTDW

based on our methodology is illustrated in Figure 5.

To take advantage of our schema modification

method and include most recent data in the OLAP

query response, the queries should be rewritten

taking under consideration the following rule: the

FROM clause should join all rows from the required

original and temporary tables with relevant data,

excluding all fixed restriction predicate values from

the WHERE clause whenever possible.

Figure 5: Sample sales data warehouse schema modified

for supporting real-time data warehousing.

The modification for the instruction presented in

Figure 4 is illustrated in Figure 6, respecting our

methods.

SELECT S_StoreKey,

Sum(S_Value) AS Last7DaysSaleVal

FROM (SELECT S_StoreKey,

S_Value FROM Sales

WHERE S_Date>=Date()-7)

UNION ALL

(SELECT STmp_StoreKey,

STmp_Value FROM SalesTmp

WHERE STmp_Date>=Date()-7)

GROUP BY S_StoreKey

Figure 6: OLAP query for calculating the total revenue per

store in last seven days.

It can be seen that the relevant rows from both

issue tables are joined for supplying OLAP query

answer, filtering the rows in the resulting dataset

according to its restrictions in the original

instruction.

3.4 Packing and Reoptimizing the DW

Since the data is integrated within tables without

access optimization of any kind that could speed up

querying, such as indexes, it is obvious that it

implies a decrease of performance. Due to the

volume of occupied physical space, after many

insertions the performance becomes too poor to be

considered acceptable. To regain performance

optimization it is necessary to execute a pack routine

for updating the original DW schema tables using

the records in the temporary tables, and recreate

those temporary tables empty of contents, along

with rebuilding original tables’ indexes and

materialized views, so maximum processing speed is

obtained once more.

Customer

C_CustKey

C_Name

C_Address

C_PostalCode

C_Phone

C_EMail

Sales

S_StoreKey

S_CustomerKey

S_Date

S_Value

Store

St_StoreKey

St_Description

St_Address

St_PostalCode

St_Phone

St_EMail

St_Manager

CustomerTmp

CTmp_CustKey

CTmp_Name

CTmp_Address

CTmp_PostalCode

CTmp_Phone

CTmp_EMail

CTmp_Counter

SalesTmp

STmp_StoreKey

STmp_CustomerKey

STmp_Date

STmp_Value

STmp_Counter

StoreTmp

StTmp_StoreKey

StTmp_Description

StTmp_Address

StTmp_PostalCode

StTmp_Phone

StTmp_EMail

StTmp_Manager

StTmp_Counter

Customer

C_CustKey

C_Name

C_Address

C_PostalCode

C_Phone

C_EMail

Sales

S_StoreKey

S_CustomerKey

S_Date

S_Value

Store

St_StoreKey

St_Description

St_Address

St_PostalCode

St_Phone

St_EMail

St_Manager

ICEIS 2007 - International Conference on Enterprise Information Systems

592

For updating the original DW tables, the rows in

the temporary tables should be aggregated according

to the original tables’ primary keys, maintaining the

rows with highest unique counter attribute value for

possible duplicate values, for they represent the

most recent records. The time needed for executing

these procedures represents the only period of time

in which the DW in unavailable to OLAP tools and

end users, for they need to be executed exclusively.

The appropriate moment for doing this may be

determined by the DW Administrator, or

automatically, considering parameters such as a

fixed number of records in temporary tables, the

amount of physically occupied space, or yet a

predefined period of time. The definition of this

moment is not object of discussion in this paper.

3.5 Final Remarks on Our

Methodology

Notice that only record insertions are used for

updating the DW for all related transactions in the

OLTP source systems. Since this operation does not

require record locking (except for the new appended

record itself) nor search operations for previously

stored data, the time required to do it is minimal.

The issue of record locking is strongly enforced by

the fact that the referred tables do not have any

indexes or primary keys, implying no record

locking, except for the appended record itself. Since

they do not have constraints of any sort, including

referential integrity and primary keys, there is no

need to execute time consuming tasks such as index

updating or referential integrity cross checks. This

allows us to state that the data update time window

is minimal for insertion of new data, maximizing its

availability, and contributing to increase the DW’s

global availability and minimize negative impact in

its performance.

The amount of “information buckets” which the

data passes through in the ETL Area is also

minimal, for temporary storage is almost not needed.

Instead of extracting a large amount of OLTP data,

what happens in “traditional” DW bulk loading, the

volume of extracted and transformed real-time data

is very reduced (few dozen bytes), since it consists

of only one transaction per execution cycle, so we

may assume that the extraction and transformation

phase will be cleaner and more time efficient.

4 EXPERIMENT EVALUATION

Recurring to TPC-H decision support benchmark

(TPC-H) we tested our methodology creating 5GB,

10GB and 20GB size DWs in ORACLE 10g

RDBMS (Oracle, 2005). We also tested the system’s

response executing 1, 2, 4, 8 and 16 simultaneous

query workloads to see how it reacted according to

the number of simultaneous users executing those

workloads. We used an Intel Celeron 2.8GHz with

2GB of SDRAM and a 7200rpm 160GB hard disk.

The modified schema according to our methodology

can be seen in Figure 7. Tables Region and Nation

are not included as temporary tables because they

are fixed-size and therefore do not receive new data.

Figure 7: TPC-H schema modified for supporting RTDW.

The selected query workloads, TPC-H queries 1,

8, 12 and 20 (TPC-H), were executed in random

order for each simultaneous user. The time interval

between transactions (Transac. Interval) for each

scenario is illustrated in tables 1 to 3. Each new

transaction represents insertion of an average of four

records in LineItemTmp and one row in each of the

other temporary tables, continuously integrated for a

period of 8 hours. Supporting RTDW capability in

all scenarios is somewhat between 6.9% and 28.6%

of query workload execution time, as shown in

figures 8 to 10, reporting percentage of workloads

execution overtime using RTDW, relatively to

execution against standard workload without

continuous integration.

CustomerTmp

CT_CustKey

CT_Name

CT_NationKey

Other Attributes

CT_Counter

SupplierTmp

ST_SuppKey

ST_Name

ST_NationKey

Other Attributes

ST_Counter

PartTmp

PT_PartKey

PT_Name

Other Attributes

PT_Counter

PartSuppTmp

PST_PartKey

PST_SuppKey

Other Attributes

PST_Counter

OrdersTmp

OT_OrderKey

OT_CustKey

Other Attributes

OT_Counter

LineItemTmp

LT_OrderKey

LT_LineNumber

LT_PartKey

LT_SuppKey

Other Attributes

LT_Counter

Customer

C_CustKey

C_Name

C_NationKey

Other Attributes

Supplier

S_SuppKey

S_Name

S_NationKey

Other Attributes

Part

P_PartKey

P_Name

Other Attributes

PartSupp

PS_PartKey

PS_SuppKey

Other Attributes

Nation

N_NationKey

N_Name

N_RegionKey

Other Attributes

Region

R_RegionKey

R_Name

Other Attributes

Orders

O_OrderKey

O_CustKey

Other Attributes

LineItem

L_OrderKey

L_LineNumber

L_PartKey

L_SuppKey

Other Attributes

A CONTINUOUS DATA INTEGRATION METHODOLOGY FOR SUPPORTING REAL-TIME DATA

WAREHOUSING

593

Table 1: TPC-H 5GB data warehouse transaction real-time

integration characteristics.

TPC-H 5GB Data Warehouse

Scenario

# Transactions 3.072 6.205 12.453

Transac. Interval 9,38 sec 4,64 sec 2,31 sec

Table 2: TPC-H 10GB data warehouse transaction real-

time integration characteristics.

TPC-H 10GB Data Warehouse

Scenario

# Transactions 6.192 12.592 25.067

Transac. Interval 4,65 sec 2,29 sec 1,15 sec

Table 3: TPC-H 20GB data warehouse transaction real-

time integration characteristics.

TPC-H 20GB Data Warehouse

Scenario

# Transactions 12.416 25.062 50.237

Transac. Interval 2,32 sec 1,15 sec 0,57 sec

TPC-H 10GB Data Warehouse

7,6

8,2

8,8

8,7

9,2

12,6

13,3

12,7

13,6

14,4

15,4

17,2

16,4

18,7

19,3

1 Us er 2 Us ers 4 Us ers 8 Us ers 16 Users

% RTDW Overti

Scenario A Scenario B Scenario C

Figure 8: TPC-H 5GB DW overtime percentages.

TPC-H 10GB Data Warehouse

9,2

9,7

9,9

9,7

10,1

14,2

16,1

15,2

15,4

15,9

18,7

17,4

21,3

20,6

22,7

1 Us er 2 Us ers 4 Us ers 8 Us ers 16 Users

% RTDW Overti

Scenario A Scenario B Scenario C

Figure 9: TPC-H 10GB DW overtime percentages.

TPC-H 5GB Data Warehouse

11,2

12,3

8,2

6,9 7

18,8

17,9

17,2

16,1

17,4

26,9

25,4

28,6

24,2

24,8

1 Us er 2 Us ers 4 Us ers 8 Us ers 16 Users

% RTDW Overti

Scenario A Scenario B Scenario C

Figure 10: TPC-H 20GB DW overtime percentages.

5 CONCLUSIONS

This paper refers the requirements for RTDW and

presents a methodology for supporting it by

enabling continuous data integration while

minimizing impact in query execution on the DW

end. This is done by data structure replication and

adapting query instructions to take advantage of the

new real-time data warehousing schemas.

We have shown its functionality, recurring to a

simulation using the TPC-H benchmark, performing

continuous data integration at various time rates

against the execution of various simultaneous query

workloads, for DWs with different scale sizes. All

scenarios show that it is possible to achieve real-

time data warehousing performance in exchange for

an average increase of ten to thirty percent in query

execution time. This should be considered the price

to pay for real-time capability within the DW.

As future work we intend to develop an ETL tool

integrating this methodology. There is also a huge

space of research for optimizing query instructions

used.

REREFENCES

Abadi, D. J., Carney, D., et al., 2003. “Aurora: A New

Model and Architecture for Data Stream

Management”, The VLDB Journal, 12(2), pp. 120-

139.

Babu, S., Widom, J., 2001. “Continuous Queries Over

Data Streams”, SIGMOD Record 30(3), pp. 109-120.

Binder, T., 2003. Gong User Manual, Tecco Software

Entwicklung AG.

Bouzeghoub, M., Fabret, F., Matulovic, M., 1999.

“Modeling Data Warehouse Refreshment Process as a

Workflow Application”, Intern. Workshop on Design

and Management of Data Warehouses (DMDW).

Bruckner, R. M., List, B., Schiefer, J., 2002 A. “Striving

Towards Near Real-Time Data Integration for Data

Warehouses”, International Conference on Data

Warehousing and Knowledge Discovery (DAWAK).

Chaudhuri, S., Dayal, U., 1997. “An Overview of Data

Warehousing and OLAP Technology”, SIGMOD

Record, Volume 26, Number 1, pp. 65-74.

Inmon, W. H., Terdeman, R. H., Norris-Montanari, J.,

Meers, D., 2001. Data Warehousing for E-Business, J.

Wiley & Sons.

Karakasidis, A., Vassiliadis, P., Pitoura, E., 2005. “ETL

Queues for Active Data Warehousing”, IQIS’05.

Kuhn, E., 2003. “The Zero-Delay Data Warehouse:

Mobilizing Heterogeneous Databases”, International

Conference on Very Large Data Bases (VLDB).

ICEIS 2007 - International Conference on Enterprise Information Systems

594

Labio, W., Yang, J., Cui, Y., Garcia-Molina, H., Widom,

J., 2000. “Performance Issues in Incremental

Warehouse Maintenance”, (VLDB).

Lomet, D., Gehrke, J., 2003. Special Issue on Data Stream

Processing, IEEE Data Eng. Bulletin, 26(1).

Oracle Corporation, 2005. www.oracle.com

Pedersen, T. N., 2004. “How is BI Used in Industry?”,

Int. Conf. on Data W. and Knowledge Discov.

(DAWAK).

Simitsis, A., Vassiliadis, P., Sellis, T., 2005. “Optimizing

ETL Processes in Data Warehouses”, International

Conference on Data Engineering (ICDE).

Srivastava, U., Widom, J., 2004. “Flexible Time

Management in Data Stream Systems”, PODS.

TPC-H decision support benchmark, Transaction

Processing Council, www.tpc.com.

Vassiliadis, P., Vagena, Z., Skiadopoulos, S.,

Karayannidis, N., Sellis, T., 2001. “ARKTOS:

Towards the Modelling, Design, Control and

Execution of ETL Processes”, Information Systems,

Vol. 26(8).

White, C., 2002. “Intelligent Business Strategies: Real-

Time Data Warehousing Heats Up”, DM Preview,

www.dmreview.com/article_sub_cfm?articleId=5570.

Yang, J., 2001. “Temporal Data Warehousing”, Ph.D.

Thesis, Dpt. Computer Science, Stanford University.

Yang, J., and Widom, J., 2001B. “Temporal View Self-

Maintenance”, 7

International Conference on

Extending Database Technology (EDBT).

Zurek, T., Kreplin, K., 2001. “SAP Business Information

Warehouse – From Data Warehousing to an E-

Business Platform”, (ICDE).

A CONTINUOUS DATA INTEGRATION METHODOLOGY FOR SUPPORTING REAL-TIME DATA

WAREHOUSING

595
