A XML-BASED QUALITY MODEL FOR WEB SERVICES

CERTIFICATION

J. Jorge Dias Jr., J. Adson O. G. da Cunha, Alexandre Álvaro

Roberto S. M. de Barros and Sílvio Meira

Informatics Center, Federal University of Pernambuco, Recife, Brazil

Keywords: Web Services Certification, Quality Model.

Abstract: Internet has made possible the development of software as services, consumed on demand and developed by

third parties. In this sense, a quality model is necessary to enable evaluation and, consequently, reuse of the

services by consumers. In this way, this paper proposes a quality model based on the ISO 9126 standard,

defining a set of attributes and metrics for an effective evaluation of Web services. A XML-based

representation model was created to support this quality model, and a security schema was proposed to

guarantee integrity and authenticity of the model.

1 INTRODUCTION

In the last decade, Component-Based Development

(CBD) has drawn great attention due to the

development of plug-and-play, reusable software

(Bertoa et al., 2002). Traditionally, software

components have been adopted, developed and

delivered as a product. However, the Internet has

created a recent surge of interest in developing

software as services, delivered and consumed on

demand. The benefit of this approach is seen in the

looser coupling between business problems and the

associated software solutions (Elfatatry, 2004).

Several works point out that Service-Oriented

Architectures (SOA) has influenced the development

of new systems. The Gartner Institute and other

authors claim that SOA proposes to be a CBD

evolution (McCoy et al., 2003)(Szyperski, 1998).

Hence, Web Services, a SOA-based technology

that has been used in industry in the last years, had

emerged in order to construct applications that reuse

services available in the network (Stal, 2002). Web

Services allows that services developed in different

languages and platforms communicate through open

and universal standards. In this way, distributed

applications development through the reused

services of the net becomes faster, increasing the

quality and decreasing product costs and delivery

time (Elfatatry, 2004).

Just as CBD model aims the use of artifacts

developed by third parties (Szyperski, 1998), the

service-oriented development aims the use of

services developed by third parties. In this sense, a

quality model is necessary in system development

through the services integration, in order to make

possible the evaluation and, consequently, the reuse

of services by consumers (developers and

designers).

There are some difficulties that must be

considered in the elaboration of such model, such as

(i) what characteristics and quality attributes must be

considered, (ii) how can we evaluate them and (iii)

who must be responsible for such evaluation (Alvaro

et al., 2005). Moreover, there is a lack of

information on the quality attributes provided by the

vendors that publish Web services, such as

StrikeIron (StrikeIron, 2006), Xignite (Xignite,

2006) and XWebServices (XWebServices, 2006).

The international standards of software product

quality specification, such as ISO 9126 (ISO/IEC

9126, 2001) and ISO 14598 (ISO/IEC 14598, 1998)

are very general, and, thus, it is difficult to apply

them in specific domains, such as Web services.

We can define certification as a set of regulated

and standardized procedures that result in the

certification or declaration expedition of specific

conformity for products or services of one

determined area (ISO, 2006). The benefits to

certificate products are numerous. Some of them are:

demonstration of quality promise, consumer trust,

288

Jorge Dias Jr. J., Adson O. G. da Cunha J., Álvaro A., S. M. de Barros R. and Meira S. (2007).

A XML-BASED QUALITY MODEL FOR WEB SERVICES CERTIFICATION.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 288-294

DOI: 10.5220/0002389402880294

 SciTePress

requirements conformance and to aggregate value to

the product. In this context, trust certifier entities

must analyze the Web services and emit a

certification for them with the evaluated data.

This paper proposes a quality model based on the

ISO 9126 standard (ISO/IEC 9126, 2001), defining a

set of attributes and respective metrics for an

effective evaluation of Web services. Moreover, a

XML-based representation was elaborated to support

the proposed quality model. A security schema is

also proposed in order to avoid that malicious

entities corrupt the certification data, or even that,

the same certification document is attached to

another services.

The remainder of this paper is organized as

follows: section 2 presents related work referring to

the existing quality models. Section 3 criticizes the

ISO 9126 model, showing the suitable

characteristics to the Web services context. Section

4 proposes the use of XML for attributes

documentation, as well as a security schema to

guarantee the authenticity and integrity of it. Then,

section 5 presents some concluding remarks.

2 RELATED WORK

Specifications have been proposed to provide

definitions and classifications of the quality

characteristics of software products, like the ISO

9126 International Standard.

Because it has a high level of abstraction, it does

not include in the specification a detailed set of

attributes and metrics, so many studies have been

realized towards a quality model for components, in

the last few years (Bertoa et al., 2002)(Bertoa et al.,

2003)(Alvaro et al., 2005), focusing the ISO 9126

model in the characteristics of such software.

However, due to the particularities of Web services,

it is necessary a new quality approach, that takes

into account the relevant characteristics for such

kind of software.

Many proposals have emerged towards Services

Level Agreement (SLAs) to improve the Web

services reuse by consumers (Tosic, 2004).

Generally, these agreements have dynamic service

information at QoS (Quality of Service) level, like

performance, availability and reliability, facilitating

their selection at runtime. On the other hand, as in

the CBD approach, services are selected at the

project life cycle. Therefore, other static quality

characteristics, inherited from CBD, are important to

facilitate the services selection, such as

documentation, support, business model, etc.

Two works proposed to evaluate the quality of

web services. One of them is the QMWS (Quality

Model for Web Services) specification, from OASIS

(OASIS, 2005), which provides a model to manage

the Web services quality at development process and

use of them. Nevertheless, there is only a conceptual

level draft, being necessary the definition of the

quality properties to be evaluated in accordance with

the Web services characteristics. Other work was

proposed by Ran (Ran, 2003) and it describes a

discovery model of Web services based on

functional and non-functional requirements of them.

In this model, the author considers a set of non-

functional attributes to evaluate the quality of Web

Services. But, unfortunately, it does not describe the

metrics used for such evaluation, nor its real

adequacy to the industry.

In this sense, this work complements such

proposals, elaborating a quality model with its

characteristics, sub-characteristics, attributes and

metrics for Web services, evaluating not only its

dynamic characteristics, but also its static

characteristics. A XML representation model is also

elaborated for supporting the proposed model.

3 QUALITY MODEL FOR WEB

SERVICES

In accordance with (ISO/IEC 9126, 2001), a quality

characteristic is a set of software product properties

through which its quality can be described and

evaluated, being such characteristics refined in sub-

characteristics.

An attribute is a property which a metric can be

associated, being metric a procedure to check a

product, giving a data that characterizes it.

A quality model, in turn, is a set of

characteristics and sub-characteristics, as well as the

relation among them, in order to provide the basis

for the specification of the quality requirements, and

its evaluation.

The idea proposed in this paper is to refine the

ISO 9126 quality model in order to accommodate

particular characteristics of the Web services,

defining attributes to be used by the Web services

vendors, making possible the services evaluation and

selection by the consumers.

Although the proposed model is based on the

ISO 9126 standard, some changes have been made

in order to develop a consistent model that can be

used to evaluate Web services. The main changes

made on ISO 9126 model are explained below.

A XML-BASED QUALITY MODEL FOR WEB SERVICES CERTIFICATION

289

 Functionality: It describes if the functions and

specific properties of the web service satisfy

the consumer necessities. The Interoperability

sub-characteristic was removed because was

considered unnecessary to the model, since the

Web services are accessed through known

Internet standards. The Compatibility sub-

characteristic was added in order to indicate if

one given version of the Web service is

compatible with its previous versions, as

considered by (Bertoa et al., 2002). The

meaning of the others sub-characteristics

remains the same.

 Reliability: It indicates if the Web service is

able to keep on performance level, throughout

the time, in the established conditions. The

sub-characteristics remain the same.

 Usability: It refers to the effort needed for

using the Web service by the consumers. The

meaning of the sub-characteristics remains the

same.

 Efficiency: It describes if the involved

resources and times are compatible with the

performance level required by the Web

service. Since the Web service is located in a

place of the Internet, there is no quantitative

concern of the system in relation to use

resources by the Web services. For this

reason, the Resource Utilization sub-

characteristic is dismissible. On the other

hand, the Time Behavior sub-characteristic

has its name modified to Performance because

it refers not only to the reply time of the

service processing, but also to how fast the

response is sent to the requester. The Stability

sub-characteristic, in accordance with the ISO

9126, pertaining to the Manutenability sub-

characteristic, by having its context modified,

was relocated for the Efficiency characteristic,

meaning how available is the service in a

continuous and consistent form.

 Maintainability: This characteristic is not

included in the proposed model. A natural

characteristic of Web services is the fact that

they are considered black-box components,

that is, consumers are not worried about how

the service is implemented, but what the

service makes (McGovern, 2003). In this way,

the developer can not make internal

modifications, adaptations or reconfigurations

in the Web service.

 Portability: Since the Web service does not

have the same characteristic that components

to be deployable, that is, the service is

available in some place of the Internet to be

accessed through the net, it is not necessary

that services be installed in different

platforms. Hence, the Portability characteristic

is unnecessary to the model.

 Market: Express the market Web services

characteristics, finishing the proposed quality

model. Although this characteristic is not

important for the evaluation of service quality,

it was incorporated to the model for making

possible the analysis of some factors related to

the service organization provider in order to

improve service credibility for the consumers

(Alvaro et al., 2005b)(Carvalho et al., 2006).

Table 1 shows a summary of Web services

quality model based on ISO 9126, with its

modifications being divided into two classes:

characteristics that are observed at runtime and

characteristics that are observed during the service

life cycle (development phase).

Table 1: Quality Model for Web Services.

Characteristics Sub-characteristics

(Runtime)

Sub-Characteristics

(Life Cycle)

Functionality

Accuracy

Security

Suitability

Compliace

Compatibility

Reliability

Recoverability

Fault Tolerance

Maturity

Usability

Understandability

Learnability

Operability

Efficiency

Performance

Stability

3.1 Attributes and Respective Metrics

Since the quality model was defined, it is necessary

to specify attributes in order to make possible the

characteristics evaluation..

Three types of metrics will be used to evaluate

the attributes: Presence, that defines if an attribute is

present or not in the Web service, consisting of a

boolean value, which indicates if an attribute is

present, and a string, which describes how the

attribute is described by the Web service; Value that

indicates the accurate value of the Web service

information, being described by an integer value and

a string to indicate the unit, and; Ratio that describes

percentages, being measured by an integer value in

the interval of 0 to 100.

ICEIS 2007 - International Conference on Enterprise Information Systems

290

3.1.1 Attributes Measured at Runtime

Table 2 shows the quality attributes for Web

services, which are evaluated at runtime, grouped by

the sub-characteristics, and including the kind of

metrics used.

A description of each attribute is presented

below:

 Correctness: It evaluates the percentage of

results gotten with precision. It is calculated

dividing the number of correct results by the

total number of results gotten in one

determined series of calls to the service.

 Data Encryption: It indicates if the Web

service makes use of encryption in order to

protect the data that it manipulates.

 Controllability: It indicates how the access

control to the Web service is made.

 Auditability: It indicates if the Web service

implements some auditory mechanism.

 Error Handling: It indicates if the Web service

manipulates error situations.

 Persistent: It indicates if the Web service can

store its state in a persistent way for later

consultation.

 Mechanism available: It indicates the

tolerance mechanism implemented by the

Web service.

 Response time: It indicates the time taken to

receive a reply, from a request, including the

processing time and net traffic.

 Throughput: It indicates the amount of output

that can be successfully produced during a

period of time.

 Processing Capacity: It indicates the amount

of input that can be successfully produced

during a period of time.

 Availability: It indicates the period of time

which a service exists or is available for use.

 Successability: It is defined by the number of

received messages divided by the number of

required messages.

 Accessibility: It indicates if the Web service is

accessible, through the verification if it can

return an act for each required message.

3.1.2 Attributes Measured at Life Cycle

Table 3 presents quality attributes, as well as the

kind of metrics used, referring to the sub-

characteristics evaluated during the Web services

life cycle.

Table 2: Attributes of the sub-characteristics evaluated at

runtime.

Sub-Characteristics

(runtime)

Attributes Metric

Accuracy Correctness Ratio

Data Encryption Presence

Controllability Presence

Security

Auditability Presence

Error Handling Presence

Recoverability

Persistent Presence

Fault Tolerance Mechanism available Presence

Response time Value

Throughput Value

Performance

Processing Capacity Value

Availability Ratio

Successability Value

Stability

Accessibility Value

Table 3: Attributes of the sub-characteristics evaluated at

life cycle.

Sub-Characteristics

(runtime)

Attributes Metric

Coverage

Ratio

Suitability

Pre-condition and Post-

condition

Presence

Service agreement

Presence

Compliance

Certification Presence

Compatibility

Presence

Volatility

Value

Maturity

Evolution Value

Understandability

Documentation available

Presence

Learnability

Time and effort to (use,

configure, admin an

expertise) the Web service

Value

Provided Interfaces

Value

Operability

Dependencies Value

 Coverage: It indicates how much of the

required functionalities are implemented by

the Web service.

 Pre-conditions and Post-conditions: It

determines the input and output conditions of

the service.

 Service agreement: It indicates if the Web

service has a WS-* agreement.

 Certification: It indicates if the Web service is

certified by some organization.

 Compatibility: It indicates if the service is

compatible with its previous versions.

 Volatility: It indicates the time between the

availability of a version and another one of the

Web service.

 Evolution: It indicates the versions number of

the Web service launched in the market.

A XML-BASED QUALITY MODEL FOR WEB SERVICES CERTIFICATION

291

 Documentation available: It indicates the

availability of documentation, demos, user

guide, APIs and tutorials.

 Time and effort to (use, configure, admin and

expertise) the Web service: It measures the

necessary time and effort for accomplishment

of specific tasks, like use, configuration and

administration of the Web service.

 Provided Interfaces: It indicates the amount of

provided interfaces for the Web service.

 Dependencies: It indicates the amount of

services of which the service is dependent.

3.1.3 Market Attributes

The market attributes complement the model with

information about the market structure that involves

the service, such as:

 Reputation: Description of the provider to

perform similar projects based on past

experiences;

 CMM Level: It indicates the CMM level of

the provider.

 Support: It describes the support mechanism

offered by the provider.

 Business model: It indicates how the service is

acquired, as well as its cost.

 Target Market: It indicates the target market

for which the service was implemented.

There is no specific metric to measure such

attributes and, thus, they are described using a string

with the information.

4 XML REPRESENTATION

MODEL

Web Services architecture uses several standards

used in different levels to obtain interoperability

between three basic operations: publish, find and

bind. Almost all these levels depend on XML

language (Gottschalk, 2002). The main goal of XML

use in Web Services architecture is to solve the

service dynamic discovery problem (Tosic, 2004).

After the quality model is defined, a certifier

entity must test and validate the service, certifying it.

For this reason, a XML model was developed to

represent the service certification with its

characteristics, sub-characteristics and attributes

mentioned in section 3.

The proposed XML model is basically divided in

two parts (see figure 1), where the document root is

service-certification. The first part refers to

certification data, that is, the information collected in

service tests and validation. The second part

mentions the certifier identify, as well as its digital

signature.

<service-certification>

<certification-info>

</certification-info>

<certifier-info>

</certifier-info>

</service-certification>

Certifier digital

signature

Quality model

data

Figure 1: XML representation model correspond to service

certification.

In its first part, the model contains certification

information, such as the certification date (element

date), and elements that represent the characteristics,

sub-characteristics and collected metrics attributes.

Attributes are represented by the same idea proposed

in (Bertoa et al., 2002), where the ODP reference

model is used (ISO 10746, 1997). In this approach,

each attribute is written using a name-value pair.

Each name has a type that determines the possible

values that it can assume. The benefits in this

approach include the fact that it is in accordance

with an international standard, and also that it is easy

to document using XML templates.

<certification-info date=“2006-05-06”>

<sub-characteristic name=“Stability”>

<type>xsd:ratio</type>

</property>

</sub-characteristic>

</characteristic>

</certification-info>

Figure 2: Part of the model that contains certification

information.

A security schema is necessary to guarantee that

the service certification will not be corrupted by

malicious entities. In this way, the proposed solution

is based on a digital signature calculated on the

XML certification model and the WSDL description

URL, guaranteeing its integrity. Public key digital

signatures are typically, in order to provide integrity

(Stallings, 1995). For that, the XML-Signature

(W3C, 2006) standard was used. The main

characteristic of XML-Signature is the ability to sign

only specific portions of the XML tree, instead of

signing the complete original document.

ICEIS 2007 - International Conference on Enterprise Information Systems

292

This XML document serves as a service

certification stamp, that is, the service provider will

be able to attach this document to any other

document that is related to the service, for example,

a WSDL description or even to extend the tModel of

the UDDI, such as considered in (Ran, 2003). In this

way, the consumer locates the desired service, being

able to analyze the certificate information and to

verify if that certificate is signed by a trusted

certifier or not. This verification is made by the

consumer itself, since that XML document contains

the certifier public key. If any person tries to modify

any element of the certification document, then the

signature becomes invalid.

5 CONCLUDING REMARKS

This work presented a quality model based on the

ISO 9126 international standard in order to certify

Web services. However, in contrast of existent

service contracts and SLAs, the goal of the proposed

model is not limited to services dynamic selection,

as it also aims to facilitate, in a simple way, a static

choice of the most appropriate service to be reused

by the consumer.

A XML representation model was developed to

support the proposed quality model, such as a

security schema using the XML-Signature standard

in order to guarantee the integrity and authenticity of

the certificate generated by the certifier entity.

In this way, this model could be adopted by Web

services vendors that publish Web services,

guaranteeing information standardization in these

sites, making possible the services selection by

consumers in the system development adopting the

SOA approach.

A preliminary case study was elaborated with

Web sites that sell commercial and financial Web

services were visited, namely StrikeIron (StrikeIron,

2006), Xignite (Xignite, 2006), and XWebServices

(XWebServices, 2006), that have their products

published in Xmethods, one of the most popular

sites that lists publicly available Web services. From

this survey, it is possible to have the first impression

about the sort of information available at these sites,

how it is advertised, and how difficult it is to extract

the quality information we are looking for. It was

not carried out a rigorous statistical analysis of the

Web services population, since the objective is only

to have coverage that is just enough to make a first

impression of the available information possible.

However, due to the limited pages, we could not

expose the results of this preliminary case study.

As future work, a formal case study about the

services information available in the vendor sites

will be done, in order to verify how much

information of the model is actually available in the

Web services providers.

REFERENCES

Alvaro, A., et al, 2005. Quality Attributes for a

Component Quality Model, In The 10Th International

Workshop on Component-Oriented Programming

(WCOP). Glasgow, Scotland.

Bertoa, M., Troya, J., Vallecillo, A., 2003. A Survey on the

Quality Information Provided by Software Component

Vendors. In Proceedings of QAOOSE 2003 at 7th

ECOOP.

Bertoa, M., Vallecillo, A, 2002. Quality Attributes for

COTS Components. Proc. of the 6th International

ECOOP Workshop on Quantitative Approaches in

Object-Oriented Software Engineering (QAOOSE),

Spain.

Carvalho, J. P., Franch, X., 2006. Extending the ISO/IEC

9126-1 Quality Model with Non-Technical Factors for

COTS Components Selection. ICSE. China.

Elfatatry, A., Layzell, P., 2004. Negotiating in Service-

Oriented Environments. Communications of the ACM.

Vol 47, Nº 8.

Gottschalk, K., Graham, S., Kreger, H., Snell, J., 2002.

Introduction to Web Services Architecture. IBM

System Journal 41, nº 2.

ISO - International Organization for Standardization,

2006. http://www.iso.org.

ISO 14598, 1998. Software Engineering – Product

evaluation. Internacional Standard ISO/IEC 14598,

Internacional Standard Organization.

ISO 9126, 2001. Information Technology – Product

Quality – Part1: Quality Model, International

Standard ISO/IEC 9126, International Standard

Organization.

ISO/IEC. RM-ODP, 1997. Reference Model for Open

Distributed Processing. Rec. ISO/IEC 10746-1 to

10746-4, ITU-T X.901 to X.904, ISO/ITU-T.

McCoy, D. W., Natis, Y. V., 2006. Service-Oriented

Architecture: Mainstream Straight Ahead.

http://www4.gartner.com/DisplayDocument?doc_cd=

114361

McGovern, J., Tyagi, S., Stevens, M., Matthew, S., 2003.

Java Web Services Architecture. Morgan Kaufmann

Publishers.

OASIS, 2006. Web Services Quality Model (WSQM).

Available at http://www.oasis-

open.org/committees/download.php/15910/WSQM-

ver-2.0.doc.

Ran, S., 2003. A Model for Web Services Discovery With

QoS. ACM SIGecom Exchanges, Vol. 4.

Stal, M., 2002. Web Services: Beyond Component-Based

Computing. Communications of the ACM, Vol. 45,

No 10.

A XML-BASED QUALITY MODEL FOR WEB SERVICES CERTIFICATION

293

Stallings, W., 1995. Network and Internetwork Security:

Principles and Practice. Prentice Hall.

StrikeIron. (n.d.). Retrieved November 4, 2006, from

http://www.strikeiron.com.

Szyperski, C., 1998. Component Software: Beyond Object-

Oriented Programming. Addison-Wesley.

Tosic, V., Pagurek, B., 2004. On Comprehensive

Contractual Descriptions of Web Services. Technical

Report, Department of Computer Science, The

University of Western Ontario.

W3C World Wide Web Consortium, 2006. XML Signature

WG. http://www.w3.org/Signature/.

Xignite. (n.d.). Retrieved November 4, 2006, from

http://www.xignite.com.

XMethods. (n.d.) Retrieved November 03, 2006, from

http://www.xmethods.com.

XWebServices. (n.d.). Retrieved November 4, 2006, from

http://www.xwebservices.com.

ICEIS 2007 - International Conference on Enterprise Information Systems

294
