SIMILARITY ASSESSMENT IN A CBR APPLICATION FOR

CLICKSTREAM DATA MINING PLANS SELECTION

Cristina Wanzeller

and Orlando Belo

Escola Superior de Tecnologia, Instituto Politécnico de Viseu, Campus Politécnico,Viseu, Portugal

Escola de Engenharia, Universidade do Minho, Campus de Gualtar, Braga, Portugal

Keywords: Web usage mining, clickstream data mining assistance, case based reasoning and similarity measures.

Abstract: We implemented a mining plans selection system founded on the Case Based Reasoning paradigm, in order

to assist the development of Web usage mining processes. The system’s main goal is to suggest the most

suited methods to apply on a data analysis problem. Our approach builds upon the reuse of the experience

gained from prior successfully mining processes, to solve current and future similar problems. The

knowledge acquired after successfully solving such problems is organized and stored in a relational case

base, giving rise to a (multi-) relational cases representation. In this paper we describe the similitude

assessment devised within the retrieval of similar cases, to cope with the adopted representation. Structured

representation and similarity assessment over complex data are issues relevant to a growing variety of

application domains, being considered in multiple related lines of active research. We explore a number of

different similarity measures proposed in the literature and we extend one of them to better fit our purposes.

1 INTRODUCTION

Selecting the most suitable methods to apply on a

specific data analysis problem is an important and

known challenge of Data Mining (DM) and Web

Usage Mining (WUM) processes development. This

challenge is the main motivation of our work, which

aims at promoting a more effective, productive and

simplified exploration of such data analysis

potentialities, focusing, specifically, on the WUM

domain. Our approach relies on the reuse of the

experience gained from prior successfully WUM

processes to assist current and future similar

problems solving. In (Wanzeller and Belo, 2006) we

described a system founded on the Case Based

Reasoning (CBR) paradigm, implemented to

undertake our purposes. This system should assist

the users in two main ways: (i) restructuring and

memorizing, on a shared case based repository, the

knowledge acquired after successfully solving

WUM problems; (ii) proposing the mining plans

most suited to one clickstream data analysis problem

at hand, given its high level description.

The case based representation model must

support a comprehensive description of WUM

experiences, regarding the nature and requirements

of such process development. The CBR exploitation

relies on the similarity notion, based on the

assumption that similar problems have similar

solutions (Kolodner, 1993). Thus, a strictly related

and essential concern is to devise a similarity model

able to cope with the provided representation.

Though, we were faced with the issue of defining a

similarity model over WUM processes, mainly

because we used a (multi-) relational cases

representation. This issue arises due to the one to

many relationships appearing among components of

cases description.

Structured representation and similarity

assessment over complex data are issues nowadays

common and crucial to various areas, such as CBR,

computational geometry, machine learning and DM,

particularly within distance-based methods.

Important tasks of the last area include the grouping

of objects and the classification of unseen instances.

Several research efforts aim to handle and learn

from more expressive and powerful data

representations, than the classical propositional

setting. Inductive logic programming and multi-

relational data mining fields traditionally symbolize

the approaches to deal with more complex and

intuitive settings directly. Some prominent examples

are the RIBL (Relational Instance Based Learning)

(Emde and Wettschereck, 1996), the RIBL2

137

Wanzeller C. and Belo O. (2007).

SIMILARITY ASSESSMENT IN A CBR APPLICATION FOR CLICKSTREAM DATA MINING PLANS SELECTION.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - AIDSS, pages 137-144

DOI: 10.5220/0002396201370144

 SciTePress

(Bohnebeck, Horváth and Wrobel, 1998) and the

RDBC (Relational Distance-Based Clustering)

(Kirsten and Wrobel, 1998) systems. For instance,

RIBL constructs cases from multi-relational data and

computes the similarity between arbitrary complex

cases (by recursively comparing the first-order

components, until fall back into propositional

comparisons over elementary features). Besides,

great attention is being focused on upgrading some

propositional learning algorithms based on typed

representations. A typed approach often simplifies

the problem modeling (Flach, Giraud-Carrier and

Lloyd, 1998). Namely, distance-based methods can

be easily extended by embedding similarity

measures specifically defined over common

structured data types as lists, graphs and sets.

The CBR domain also embodies a relevant and

closely related line of research to address the

discussed issues. Cases are often represented by

complex structures (e.g. graphs, objects), requiring

tailored forms of similarity assessment (e.g.

structural similitude). These measurements are

usually computationally expensive, but more

relevant cases may be retrieved. Object-oriented

case representations generalize simple attribute-

value settings and are useful to represent cases from

complex domains. This kind of representation is

frequent, being particularly suitable when cases with

different structures may occur (Bergmann, 2001).

The objects’ similitude is determined recursively in

a bottom up fashion and has been extended by a

framework, to allow comparing objects of distinct

classes and considering the knowledge implicit in

the class hierarchy (Bergmann and Stahl, 1998).

There are multiple approaches proposed to deal

with the faced issues. In this paper we describe the

ones considered and applied to accomplish the

similarity assessment within our system. Section 2

concerns to the main attributes of problem

description and, so, the ones comprised on the

similitude estimation. Section 3 covers the similarity

model adopted in the retrieval process. In sections 4,

5 and 6 we define the similarity measures

considered, according to the similarity model

adopted. Section 7 reports comparative tests of some

similarity measures and section 8 ends the paper

with conclusions and proposals of future work.

2 MATCHING WUM PROBLEMS

Our system’s relational case base consists in a

metadata repository, containing detailed examples of

successful WUM processes, described in terms of

the domain problem and the respective applied

solution. Figure 1 shows the core components of

cases representation, through a class diagram in

Unified Modeling Language simplified notation.

The central class Process represents each WUM

process and interconnects the classes of problem and

solution description. The transformations of the

dataset, the modeling steps, together with the applied

models, theirs configuration parameters and the

involved variables, build up the major solution part

of a case. The case’s problem part comprises the

features that characterize the problem type. Those

features are useful to specify new problems and can

be organized into two categories: the dataset

specification and the requirements description. The

former regards to characterization metadata,

gathered at dataset and individual variable levels.

The last stands for a set of constrains, based on the

analysis nature and the analyst preferences.

olution

Case's representation

Problem

Tool

Stage

Param_Mod

DataSet

Function Schema_var

Application VariableMode l

Transf_var

Process

Modelation Transformation

Paramete

Type_transf Goal

Application

area

Process

AArea

Dataset

specification

Requirements

description

Figure 1: Cases representation conceptual model.

The conceptual metadata model reveals the cases

multi-relational representation. Focusing on the

problem description part, each instance of the central

Process class is (directly or indirectly) related to

several instances from some classes (e.g. Variable

and ProcessAArea). The one-to-many relationships

also occur in the specification of new problems

within the target object. Table 1 illustrates the main

features of the target object, along with theirs values

type and organized by description categories and

subcategories. The values type can be: (i) simple

(atomic) in what respects to single-value attributes;

(ii) a set of elements, modelling the one-to-many

relationships as composed or structured multiple-

value features. The table also shows the type of

comparison (e.g. 1-1, N-1) when matching the

correspondent features of the target and each case.

The structured features give raise to comparisons

between sets of finite elements, with inconstant and

possibly different cardinality. We highlight three

kinds of comparisons between sets:

 N-1 matches, between the sets of (symbolic)

values from the Goal(s) feature, since the

target might include the selection of one or

ICEIS 2007 - International Conference on Enterprise Information Systems

138

more goals, although each case is related to

only one instance of the Goal class;

 N-M matches, between the sets of (symbolic)

values from the Application area(s) attribute,

as both the target and case might be related to

several instances of the ProcessAArea class;

 N-M’ matches, between sets of elements with

theirs own features, when comparing dataset

variables from the target and each case.

Besides the target object, the specification of

new problems might comprise additional

information: (i) degrees of importance assigned to

each feature, expressing which attributes are more or

less relevant to the user; (ii) exact filters that define

hard constraints for the features values of the

available cases.

3 RETRIEVING SIMILAR CASES

A key process of CBR systems is retrieving the most

similar case(s) that might be useful to solve the

target problem. A core task to undertake is to

measure the similarity of the target problem to the

previous described problems, stored on the case

base, along with theirs known solutions. In the most

typical application of CBR, the similarity assessment

of the cases is based on theirs surfaces features.

Such features are the qualitative and quantitative

attributes held as part of the cases’ description,

usually represented using attribute-value pairs. The

similitude of each case’s problem to the target

problem is computed considering the correspondent

feature values and the selected similarity measures.

The similarity measures are a critical component in

any CBR system, containing by itself knowledge

about the utility of an old solution reapplied in a new

context (Bergmann, 2001).

A general principle to orient the similitude

assessment splits its modelling, defining two types

of measures: the local and the global ones. The local

similarity measures are defined over the simple

attributes. The global similitude considers the whole

objects and gives an overall measure, according to

some rule that combines the local similarities (an

aggregation function) and a weight model. This

useful principle has to be extended to tackle our

requirements. Since the structure and the features

considered are the same to all cases, we do not have

to handle the issues of comparing objects with

arbitrary or distinct structure, neither measuring

deeper forms of similarity (as the ones covered in

Bergmann and Stahl, 1998; Emde and Wettschereck,

1996). We can explore a simpler and intermediate

approach, based on the similarity assessment over

structured data types, namely set valued features.

The adopted approach comprises the modelling of

the following items:

 global similarity measures defined through an

aggregation function and a weight model

(Sim

global

);

 local similarity measures for simple (single-

value) attributes (Sim

local SINGLE

);

 local similarity measures for structured (set-

value) features (Sim

local SETS

The basic procedure of similarity assessment

using the previous model (omitting the weight

factor) can be described by the following algorithm.

Input: target t and case c, whose problems are described by a set of features f.

Output: the similitude value between t and c.

1. Features loop: For each feature f Do:

If f is simple then /* Similarity for simple/single-value features */

sim

← Sim

local SINGLE

measure applied to the f values from t and c;

Else /* Similarity for structured/set-value features */

If the elements of the sets are simple then

Use a Sim

local SINGLE

measure between each pair of values from t and c;

sim

← Sim

local SETS

measure applied to all the previous values;

Else /* sets’ elements have their own inner features */

Use Sim

local SINGLE

measures to determine the similarity between the

correspondent inner features, for each pair of elements from t and c;

Employ Sim

global

to aggregate the similarities of the inner features,

deriving a similitude value for each pair of elements from t and c;

sim

← Sim

local SETS

measure applied to all the previous values;

2. Overall similarity between t and c: Apply a Sim

global

measure to all the sim

values.

SIMILARITY ASSESSMENT IN A CBR APPLICATION FOR CLICKSTREAM DATA MINING PLANS SELECTION

139

Table 1: List of (sub)categories, features and values type of the target problem description.

Subcategory Features Value ( comparison) type

Evaluation

criteria

Precision; Time of reply; Interpretability; Resources

requirements; Implementation simplicity

Simple ordinal (1-1)

WUM process date - Process date Simple continuous (1-1)

Requirements

description

DM task

-Goal(s)

-Application area(s)

Set of symbolic (N-1)

Set of symbolic (N-M)

Characteristics at

dataset level:

- DM generic

-Number of lines and columns/variables

-Percentage of numeric, categorical, temporal and binary

columns/variables

Simple continuous (1-1)

- WUM specific

-Type of visitant’s identification

-Access order and access repetition availability

-Granularity (e.g. session), etc.

Simple Boolean and

symbolic (1-1)

Characteristics at

variable level:

- DM generic

(a set of) -Data type

-Number of distinct values

-Number of null values

Dataset

specification

- WUM specific

-Semantic category

Set of variables (N-M’):

Simple symbolic and

continuous

4 MEASURING GLOBAL

SIMILARITY

Global similarity measures are applied at different

levels, namely at case and sub-object levels, to

aggregate the local similitude values from simple or

structured features. The adopted and implemented

measure consists on the traditional weight average

function, defined by equation (1), where t and c

denote the target and the case objects (or part of

them), t.f and c.f are the correspondent values of

each feature f, Sim

local

is a local similarity measure, n

is the number of features used in the comparison and

is the importance weighting of the feature f.

∑

∗

flocal

global

wfcftSim

ctSim

).,.(

),(

(1)

A global similarity measure is task oriented and

contains utility knowledge (Bergmann, 2001). The

adopted measure reflects the case features relevance,

based on the respective assigned weights, allowing

them to have varying degrees of importance. Our

perspective is that defining features relevance levels

(e.g. important, very important) is useful to better

specify the problem and belongs to its description.

Thus, our weight model (currently) consists

essentially in representing the mappings between the

available relevance levels and the used (internal)

weighting values.

5 MEASURING SIMILARITY ON

SINGLE-VALUE FEATURES

Local similarity measures contain domain

knowledge, reflecting the relationship between the

values of a feature. The adoption of a local similarity

measure depends mainly on the feature domain,

besides the intended semantic. The local similarity

between categorical features is based on exact

matches (e.g. for binary and text attributes) or can be

expressed in form of similarity matrices (e.g. for

symbolic attributes), which establish the similitude

level. These matrices are held by relational tables.

To compare numeric features we adopted a

common similarity measure, based on the

normalized Manhattan distance (i.e. Similarity=1-

Distance), defined by the equation (2), where t.f, c.f

denote the target and case values of feature f and

max

, f

min

are the maximum and minimum values

(observed) on feature f, used to normalize the result.

minmax

1).,.(

fcft

fcftSim

Local

−

−=

(2)

The local similarity measure for the evaluation

criteria features is an exception, being build upon a

constraint imposed to equation (2), given by the rule:

⎪

⎩

⎪

⎨

⎧

−

≥

ftfc

fcft

ftfc

fcftSim

Local

..1

).,.('

minmax

(3)

ICEIS 2007 - International Conference on Enterprise Information Systems

140

The constraint imposed (3) was applied since the

target values of evaluation criteria are meant as

lower bounds of the features. In addiction, greater

(>) always means better than the searched value,

using the ordinal scale defined to these features. By

this reason, the similarity should be estimated only if

the case value is worst (lower).

6 MEASURING SIMILARITY

OVER SET-VALUE FEATURES

The cases structured representation brings up issues

to the similarity estimation, not addressed by the

previous measures. We need to define similarity

measures between sets of elements, containing

atomic values or objects having themselves specific

properties. The similitude between each pair of

elements was modeled through: similarity matrices,

defined over the distinct values of a feature (e.g. for

goals); specific features that might have different

levels of importance (e.g. for dataset variables).

There are already many proposals in the

literature for measuring the similarity or distance

between sets of objects (Eiter and Mannila, 1997;

Gregori, Ramírez, Orallo and Quintana, 2005;

Ramon, 2002). One widely used measure is the

Jaccard coefficient. This coefficient, however, is not

suited for our application, since only exact matching

between elements is taken into account. We want to

consider inexact matches, namely the proximity that

can be derived by the similitude between different

elements of the sets. Hence, this coefficient, theirs

variants and alternative measures with the same

behavior will not be considered in the sequel.

In (Hilario and Kalousis, 2003) three similarity

measures are used to handle the comparison between

sets, namely between dataset variables sets. Those

measures rely on notions from clustering, where

such type of comparison is a common task. Two of

the used similarity measures are inspired in ideas

developed in agglomerative hierarchical clustering

algorithms (Duda, Hart and Stork, 2001). The first

one is based on the single linkage algorithm, being

defined as the maximum similarity observed

between all pairs of elements of the two sets (as

explaned in Table 4). Given two sets A and B, such

that a ∈ A and b ∈ B, this measure is defined by the

following equation:

)),((max),(

basimBASim

(4)

where sim(a,b) is the similarity between each

pair of elements of the two sets (determined as

explained in section 3). The other (second) similarity

measure comes up from the average linkage

algorithm. This measure is defined as the average

similarity between all pairs of elements (a,b) from

the two sets A and B, being given by:

∑

∗

basim

BASim

),(

(5)

where n

and n

denote the respective cardinality

of the sets A and B. The third measure is used on the

scope of similarity-based multi-relational learning

(Kirsten, Wrobel and Horvath, 2001), being based

on the measure of RIBL (Emde and Wettschereck,

1996). The similarity between two sets is defined on

equation (6) as the sum of the maximum similarities

of the set elements with lower cardinality with the

elements of the set with the greater cardinality,

normalized by the cardinality of the greater set.

⎪

⎩

⎪

⎨

⎧

≥

∑

∈

nnbasim

BASim

)),,(max(

),(

(6)

In (Eiter and Mannila, 1997) the authors review

various distance functions proposed on sets of

objects, among them the known Hausdorff distance

(and metric) and the sum of minimum distances

(SDM). The Hausdorff distance has some quite

attractive properties (e.g. being a metric), but it does

not seem to be suitable as similarity measure for our

application, since it relies too much on the extreme

values of the elements of both sets. Thus, after

testing its inadequacy, this measure has not

considered any more.

Given the measures considered as the most

promising to our purposes and based on the

comparative tests performed (and exemplified in

section 7), we combined the best ideas from some

measures to define two refined similarity measures

more suited to our approach. The first one (Sim

) is

alike the SDM measure (after transforming the

minimum into maximum), which maps every

element of both sets to the closest element in the

other set. The Sim

measure (i.e. “Maximums

Average”) takes into account the maximum

similarity between each element and the other set,

and averages these values, being defined by:

∑∑

∈∈

basimbasim

BASim

)),((max)),((max

),(

(7)

SIMILARITY ASSESSMENT IN A CBR APPLICATION FOR CLICKSTREAM DATA MINING PLANS SELECTION

141

where sim(a,b) is the similarity between each

pair of elements and n

, n

are the cardinality of the

sets. In the second proposed measure the similarity

between the target and the other set is defined as the

average of the maximum similarities of the elements

from the target set with the elements of the case set.

This measure is asymmetric and is a variant of

Sim

(7), based on Sim

(6). It uses less

information than Sim

, namely the half concerning

directly to the target, and gives emphasis to the

greatest similarities of one set, like the Sim

measure. The measure is defined by the equation:

( , ) max( ( , )) A Target set

HMA

Sim A B sim a b

∈

=⊂

∑

(8)

where sim(a,b) is the similarity between each

pair of elements and n

is the cardinality of the set

A, contained by the target.

7 COMPARING SIMILARITY

MEASURES FOR SET-VALUED

FEATURES

In order to compare and evaluate some previously

described measures, we implemented them to

estimate the similarity between datasets variables.

The reported tests are not a systematic evaluation.

They only exemplify results involving some critical

situations to justify our decisions. We used six

variables sets (VS

, VS

and VS

whose main characteristics are shown in Table 2.

For each variable we selected two features: the data

type (symbolic) and the number of distinct values

(numeric). The similitude between each pair of

variables was determined applying the global

measure (1) to aggregate the values derived, using: a

similarity matrix for the symbolic feature; the

normalized Manhattan similarity measure (2) for the

numeric feature. To minimize the factors involved,

the tests were performed using: (i) the same weight

value 1 for all features; (ii) a similitude value 0

between distinct values of the data type feature. To

obtain two resembling datasets, VS

was derived

from VS

removing one variable. VS

shares one

(integer) similar variable with VS

and VS

, while

shares one (string) similar variable with VS

and VS

. VS

has variables of common data type

with VS

, VS

and VS

, although with different

properties. One difference between the two groups

{VS

, VS

} and {VS

, VS

} is the cardinality. VS

does not share similar variables with VS

and VS

Table 3 sums up the results of the tests, using

, VS

and VS

as target. For all the measures,

the similitude is determined after computing the

similarity between all pair of elements from the two

sets. The difference among them comes afterwards,

as shown on Table 4. The criteria used to evaluate

the measures included the following requirements:

 R1 - the measure should reflect equal variables

sets, i.e. the reflexivity property (sim(x,x)=1)

should hold;

 R2 - the measure should distinguish pairs of

sets that are far apart from pairs of sets that

are closer to one another.

As expected, the single linkage algorithm’s

similarity measure (Sim

) is not suited to the current

purpose, since it fails requirement R2. If we have at

least one equal variable (same data type and number

of distinct values), the differences among the other

variables are not reflected (e.g. Table 3 cells (a,D)

and (f,E)). The average linkage algorithm’s measure

(Sim

) is not a better option. First, it generally fails

criteria R1. This measure provides low similarities,

even using equal variables sets, since it includes in

the average value the differences between all

variables pairs. Besides, this influence might be

greater than the one from equalities (e.g. cells (b,A)

and (g,B)). Second, and by the same reason, the

differences in similarity between variables sets very

diverse and equal are not substantially significant

(e.g. between (b,A) and (b,F) and between (g,B) and

(g,F)), failing too the R2 requirement.

The Sim

measure is intentionally sensitive to

cardinalities differences. The idea beyond is to

achieve perfect similarity only if the cardinality of

both sets is equal. To our application this property is

a disadvantage. This fact is exemplified by the very

low similarities of (c,D),(c,E),(h,D)

and (h,E) cells,

particularly when compared with the VS

similarity

which should be lower. The approach does not fail

the basic requirements, but provides results in an

unexpected order and penalizes a difference that we

do not want to emphasize. On one hand, in several

DM methods the inclusion of a distinct number of

variables is not a relevant factor to methods

selection. On the other hand, we have a feature at

dataset level to reflect this difference.

The similarity measures Sim

and Sim

HMA

fulfill

the requisites and seem to be the ones that most

adequately reflect the intended semantic. The idea of

Sim

is to provide the closest mappings using

information from both sets. Sim

HMA

aims at

reflecting the best matches of the target set with

every considered case, being intentionally

asymmetric. Its main characteristic is the orientation

by the target, which embodies the relevant properties

that we want to retrieve. Sim

HMA

is easier to compute

ICEIS 2007 - International Conference on Enterprise Information Systems

142

and generally provides more distant similarity

values. Sim

uses more data than Sim

HMA

, but not

necessarily more informative. An exception occurs

when the case set overlaps the target set. Namely,

Sim

HMA

does not distinguish VS

from VS

, if VS

is the target. VS

-VS

(j,A) is maximal since VS

overlaps with everything found in VS

. Conversely,

the VS

-VS

(d,B) similarity is less, as VS

only

contains part of what is found in VS

. This result

accords to the intended one, in what respects to

features as application area. A user looking for

application area x would be satisfied by analysis

including x and y. However, this kind of result is not

proper when comparing dataset variables. Having

common variables is a possible situation, since the

same dataset is typically used in other alternative

analyses, being important to distinguish variables

sets as VS

and VS

. Hence, the Sim

measure was

used to compare variables while Sim

HMA

was

adopted to compare the remaining set features.

Table 2: Dataset variables sets main properties.

Variable set (VS) VS

Number of variables 3 2 6 43 453 8

Data types

2 integer

1 string

1 integer

1 string

integer

1 integer

42 boolean

1 string

452 boolean

boolean

Number of

distinct values

452, 44

452

8,240,171, 23, 60,83 452

Similar variables 2 common variables 1 with VS

,VS

1 with VS

,VS

Table 3: Results of the similarity measures between variables sets.

Target Similarity Measures

Sim

(4) 1 1 .99 1 1 .73

Sim

(5) .79 .76 .82 .65 .65 .65

Sim

(6) 1 .67 .33 .06 .005 .24

Sim

(7) 1 .95 .93 .74 .73 .71

Sim

HMA

(8) 1 .92 .87 .83 .76 .65

Sim

(4) 1 1 .88 1 1 .73

Sim

(5) .76 .76 .75 .62 .61 .61

Sim

(6) .67 1 .20 .04 .003 .15

Sim

(7) .95 1 .81 .74 .73 .71

Sim

HAM

(8) 1 1 .81 .86 .76 .61

Sim

(7) .93 .81 1 .76 .74 .73

Sim

HMA

(8) .95 .80 1 .80 .71 .69

A B C D E F

Table 4: Similarity measures schematic example.

Sim(a,b) matrix Sim

Sim

HMA

Case set

Max by line (L

)

u v L

w x L

y z L

Target set

Max by column (C

) C

,,(

max

2*3

321

LLL

Case set

Max by line (L

)

u v w L

x y z L

Target set

Max by column (C

) C

L +

≡

L +

SIMILARITY ASSESSMENT IN A CBR APPLICATION FOR CLICKSTREAM DATA MINING PLANS SELECTION

143

8 CONCLUSIONS

The proposed and developed work aims at

contributing to a more simplified, productive and

effective exploration of WUM potentialities. The

practice shows that often it is more efficient to solve

a problem starting from a tested successful solution

of a previous similar situation, than to generate the

entire solution from scratch. This fact is particularly

truth in the DM and WUM domains, where recurrent

problems are quite common. To achieve this aim, we

implemented a system, essentially founded on the

CBR paradigm, which should suggest the more

suited mining plans to one clickstream data analysis

problem, given its high level description.

In this paper we described the similarity

assessment approach, followed within the retrieval

process, in order to cope with the multi-relational

case representation. Structured representation and

similarity assessment over complex data are

important issues to a growing variety of application

domains. It is a known fact that there is a trade-off

between the expressiveness of the representation

languages and the efficiency (complexity) of the

learning method. The strategy of extending distance-

based propositional methods through structured and

typed representations, able to simplify the problem

modelling, and treating the features and theirs

properties in the similarity measures is

advantageous. It is simple, enables to benefice from

the research and the efficiency from these methods,

exploring at the same time the greater

expressiveness of such representations. Since this

strategy is suited to our current demands, it was

adopted to handle the faced issues.

We considered specifically the issue of

measuring the similarity between sets of elements.

There are multiple proposals in the literature to deal

with this issue, but an ideal and general approach,

appropriate to several purposes such as the intended

semantic and properties, does not exist.

Consequently, we explored a number of different

already defined similarity measures and we extended

one of them to better fit our purposes. This extension

gave raise to two measures suited to the similarity

assessment of features with different properties.

We are currently working on the construction of

more cases, comprising WUM process with higher

complexity. Afterward, a more detailed and

systematic experimental evaluation of the system is

necessary. Moreover, one future direction of work

concerns the weights assignment improvement,

based on a comprehensive evaluation of the features

relevance and discriminating power.

ACKNOWLEDGEMENTS

The work of Cristina Wanzeller has been supported

by a grant from PRODEP (Acção 5.3, concurso nº02

/2003).

REFERENCES

Bergmann, R., 2001. Highlights of the European INRECA

projects. In ICCBR’01, 4th International Conference

on CBR, Springer-Verlag, 1-15.

Bergmann, R., Stahl, A., 1998. Similarity Measures for

Object-Oriented Case Representations. In EWCBR'98,

4th European Workshop on Case-Based Reasoning.

Springer-Verlag, Vol. 1488, 25-36.

Bohnebeck, U., Horváth, T., Wrobel, S., 1998. Term

Comparisons in First-Order Similarity Measures. In

8th International Conference on Inductive Logic

Programming, Vol. 1446, Springer-Verlag, 65-79.

Duda, R., Hart, P., Stork, D., 2001. Pattern Classification

and Scene Analysis, chapter Unsupervised Learning

and Clustering. John Willey and Sons.

Eiter, T., Mannila, H., 1997. Distance Measures for Point

Sets and their Computation. Acta Informatica, 34(2),

109–133.

Emde, W., Wettschereck, D., 1996. Relational Instance-

based Learning. In 13th International Conf. on

Machine Learning, Morgan Kaufmann, 122-130.

Gregori, V., Ramírez C., Orallo, J., Quintana, M., 2005. A

survey of (pseudo-distance) Functions for Structured-

Data. In TAMIDA’05, III Taller Nacional de Minería

de Datos y Aprendizaje, Editorial Thomson,

CEDI’2005, 233-242.

Flach, P., Giraud-Carrier, C., Lloyd, J., 1998. Strongly

Typed Inductive Concept Learning. In 8th

International Workshop on Inductive Logic

Programming, Springer-Verlag, Vol. 1446, 185-194.

Hilario, M., Kalousis, A., 2003. Representational Issues in

Meta-Learning. In ICML'03, 20th International Conf.

on Machine Learning , AAAI Press, 313-320.

Kirsten, M., Wrobel, S., 1998. Relational Distance Based

Clustering. In 8th Int. Conf. on Inductive Logic

Programming, Vol. 1446, Springer-Verlag, 261-270.

Kirsten, M., Wrobel, S., Horvath, T., 2001. Relational

Data Mining. Distance Based Approaches to

Relational Learning and Clustering, Springer-Verlag,

212-232.

Kolodner, J., 1993. Case Based Reasoning. Morgan

Kaufmann, San Francisco, CA.

Ramon, J., 2002. Clustering and Instance Based Learning

in First Order logic. PhD thesis, K.U. Leuven,

Belgium.

Wanzeller, C., Belo, O., 2006. Selecting Clickstream Data

Mining Plans Using a Case-Based Reasoning

Application. In DMIE’06, 7th International

Conference on Data, Text and Web Mining and their

Business Applications and Management Information

Engineering, 223-232.

ICEIS 2007 - International Conference on Enterprise Information Systems

144
