MISUSE DETECTION

An Iterative Process vs. A Genetic Algorithm Approach

Pedro A. Diaz-Gomez and Dean F. Hougen

Robotics, Evolution, Adaptation, and Learning Laboratory (REAL Lab)

School of Computer Science, University of Oklahoma

Norman, OK, USA

Keywords:

Misuse detection, genetic algorithms, iterative process, false negative, false positive.

Abstract:

With the explosion of the Internet and its use, the development of security mechanims are quite important

in order to preserve the conﬁdentiality, integrity, and availability of data stored in computers. However, the

growth of intrusions can make such mechanisms almost unusable, in the sense that the computation time

or space needed in order to mantain them can grow exponentially. This position paper presents an iterative

process for doing misuse detection, and compares it with another approach for doing that: a Genetic Algorithm.

1 INTRODUCTION

Every company or enterprise usually has a security

mechanism in order to protect data. One such security

mechanism is the Intrusion Detection System (IDS),

which monitors and detects intrusions, or abnormal

activities, in computers or computer networks. For

doing that, the IDS usually knows what constitutes

“normal” activity, and then a deviation of normality

could be an intrusion (Denning, 1986) or the IDS has

in advance patterns of suspicious activity that consti-

tute intrusions, and those are compared with current

activities, in order to determine if there is an intru-

sion. The former type of detection is called anomaly

detection and the later misuse detection.

There have been various mechanisms proposed for

doing intrusion detection. One of the most important

is the seminal work of Dorothy Denning, which pro-

poses a real-time statistical rule base system (Bace,

2000), which is an anomaly detector that builds the

rule base system based on user activity. Another

mechanism proposed is expert systems, where the

knowledge usually is entered as if-then-clauses (Bace,

2000) and that constitutes principally misuse detec-

tion. Other mechanisms include neural networks,

which could be anomaly detectors in the sense that

they are usually trained with “normal” activity and

then the neural network can ﬁnd abnormal activity,

Genetic Algorithms (GAs), which evolve the possible

intrusions and could be misuse detectors, and so forth

(Bace, 2000).

Besides the possible drawbacks of almost any IDS

in storage and computation time used, is the problem

of false positives and false negatives. A false positive

is when the IDS sets an alarm indicating an intrusion

that, in reality, did not happen. A false negative is

when the IDS did not detect an intrusion or a devia-

tion from normality that constitutes an intrusion but

the intrusion really happened (Tjaden, 2004). Both

types of problems are critical. On one side, if the IDS

has many false positives, then the attention to a pos-

sible intrusion is diminished. On the other side, if the

IDS missed many possible intrusions, then it is almost

useless, and great damage can be caused to the system

it monitors if intrusions are not detected.

The iterative process used in this article is the re-

sult of our experience in working with GAs in doing

misuse detection in log ﬁles. It uses the concept of

a ﬁtness function used in a GA for ﬁnding intrusions

(Diaz-Gomez and Hougen, 2006).

A GA has a ﬁtness function that guides evolu-

tion, operators that try to simulate mating and selec-

tion of some natural systems, and parameters like the

crossover and mutation probabilities (Mitchell, 1998).

However, the ﬁtness function used and the setting of

parameters is at the same time a difﬁculty, in the sense

that a “good” choice of those can give approximate

“good” solutions, but an incorrect choice of those can

455

A. Diaz-Gomez P. and F. Hougen D. (2007).

MISUSE DETECTION - An Iterative Process vs. A Genetic Algorithm Approach.

In Proceedings of the Ninth International Conference on Enter prise Information Systems - AIDSS, pages 455-458

DOI: 10.5220/0002410804550458

 SciTePress

give “bad” solutions, i.e., the algorithm could give

a high rate of false positives and/or negatives (Diaz-

Gomez and Hougen, 2005c). Heuristic tools, like a

GA, have been considered for doing misuse detec-

tion, because the problem is NP-Complete (M

e, 1998)

and/or because the search space is huge, in which case

an exhaustive search of possible intrusions would be

almost impossible in an affordable computation time.

2 MISUSE DETECTION

Usually an IDS processes log records received from

the operating system for a speciﬁc period of time in

order to have a complete set of user activity (Bace,

2000; Crosbie and Spafford, 1995). After that, the

IDS performs analysis of the current activity, using a

rule base system, statistics, or a corresponding heuris-

tic, in order to determine the possible occurrence of

abnormality or intrusion.

For the present, the misuse mechanism uses a pre-

deﬁned matrix of intrusion patterns (M

e, 1998), so the

system knows in advance the appearance of misuse

and/or abuse. The bigger this table, the more space

and computation time is spent in the analysis. Previ-

ous work with a GA used a table of size 28x48 (Diaz-

Gomez and Hougen, 2006), where 28 was the num-

ber of activities to be considered—an activity could

be a user logging, reading of a speciﬁc ﬁle, execut-

ing a program, and so forth—and 48 was the number

of intrusion patterns. Present work uses hundreds and

more than one thousand intrusions, validates previous

work, and suggests an iterative system as another al-

ternative.

An intrusion can be speciﬁed by an array of activ-

ities to check, where each entry speciﬁes the number

of activities of a speciﬁc type that should occur in or-

der to have an intrusion. Likewise, the results of the

user records gathered can be seen as an array, where

each entry speciﬁes the total number of activities of

that speciﬁc type performed by a user. Figure 1 shows

an example of arrays P of intrusion patterns and an ar-

ray UA of user activity.

If an intrusion array pattern P is such that each en-

try of it is less or equal than each entry of the user’s

activity UA, then, it is possible that intrusion P has oc-

curred. However, looking at some possible intrusions

together, it is possible that one or several can occur,

but not all together, because adding each correspond-

ing entry, some results could be greater than the cor-

responding entry of the user activity vector UA (M

1993; Diaz-Gomez and Hougen, 2006; Diaz-Gomez

and Hougen, 2005c). This is called a violation of the

constraint.

. . .

. .

. . .

. .

Known Intrusions

Passwd file read

Port B open

File C printed

A execution

Hypothesis Array

Activity Type User Activity

0 1 0 1

Figure 1: Arrays of intrusions P, array of user activity UA,

and hypothesis array OZ.

2.1 Iterative Misuse Detection

The iterative process ﬁrst checks each intrusion pat-

tern P to determine if it may have occurred. For do-

ing that, each entry of each P array is compared with

the corresponding UA entry. If there is no violation

of the constraint, i.e., if I

≤ UA

∀ 1 ≤ j ≤ M, where

M is the number of activities monitored, then P is a

possible intrusion. After ﬁnding all the possible intru-

sions, the iterative process begins to build two sets. It

adds iteratively the corresponding entries of the possi-

ble intrusions found, in order to check for a violation

of the constraint when considered together. If in do-

ing such addition, an entry of an intrusion violates the

constraint, then that possible intrusion is marked as

an exclusive intrusion. So, the result is going to be a

set of possible intrusions that can occur together and

a set of exclusive intrusions.

2.2 Genetic Misuse Detection

The genetic algorithm approach checks all possible

intrusions together, using an hypothesis array of ones

and zeros OZ, where a one in an entry means that that

type of intrusion may have occurred—see Figure 1.

Previous work uses an operator called the union op-

erator (Diaz-Gomez and Hougen, 2006). With the

union operator, the GA stores possible intrusions—if

any—and checks for violation of the constraint. The

result then—as the iterative process shows—is two

sets of possible intrusions, ones that can occur to-

gether (i.e., with no violation of the constraint) and

the others that in conjunction with the previous ones

ICEIS 2007 - International Conference on Enterprise Information Systems

456

Iterative

1,000

100

48 144 528 1008

100

110

Number of Arrays

Ave. Number of Possible Intrusions

1,000

100

Iterative

Figure 2: Average number of possible intrusions found by

a GA and total found by an iterative process. 40, 100 and

1, 000 individuals in the initial population. 30 runs on each

population size.

violate the constraint—if that is the case.

The GAs’ parameters used in these tests are the

following: 60% probability of one-point crossover,

2.4% probability of mutation per chromosome,

20, 000 generations, selection pressure of 1.5 (tour-

nament selection of size 2 with 75% of choosing the

ﬁttest), and a population size of 40. With this conﬁgu-

ration of parameters the tests were perfomed 30 times

for 48, 144, 528, and 1008 intrusions.

3 ITERATIVE VS. GENETIC

APPROACH

Figure 2 shows the average number of possible intru-

sions found by the GA and the total number of intru-

sions found by the iterative process. There were no

false positives given by either algorithm and the iter-

ative process had no false negatives in these tests.

If the number of individuals in the GA’s popula-

tion is changed from 40 to 100 and 1, 000 (keeping

other parameters the same) the GA’s false negative

percentage is better, as expected (see Figure 3 for the

average number of false negatives when using 40, 100

and 1, 000 individuals). However, setting parameters

so that the quality of the solution is better is one of the

difﬁculties in working with GAs.

48 144 528 1008

100

Number of Arrays

False Negative Percentage

100

1,000

Figure 3: Average percentage of false negatives using a GA

with 40, 100, and 1, 000 individuals in the initial population.

30 runs on each population size.

3.1 Exclusive Intrusions

As stated in Section 2, the result of both algorithms

is two sets: one of possible intrusions (Y ) and the

other of possible intrusions that could not happen at

the same time as the previous ones because of vi-

olations of the constraint (M

e, 1993; Diaz-Gomez

and Hougen, 2006; Diaz-Gomez and Hougen, 2005c).

This is called exclusive set (X) (Diaz-Gomez and

Hougen, 2005c). For the case of the iterative process,

these two sets (Y and X) are always the same, but for

the GA case, the two sets could be different because

of the randomness involved in the process.

In this work, the exclusive set X was disaggre-

gated, i.e., the algorithm continues looking for con-

straints until a set of disjoint sets X

, X

, ..., X

found, the union of which is the set X, so the entire set

of possible intrusions is Y ∪ X

∪ X

∪ ... ∪ X

, where

Y ∩ X

∩ X

∩ ... ∩ X

It should be emphasized that exclusive intrusions

makes this an NP-Complete problem because the so-

lution set Y ∪ X

∪X

∪...∪ X

is not unique. However,

the algorithms presented in this paper are ﬁnding one

solution, not all possible solutions.

3.2 Computational Complexity

The iterative process performs, for each P array, M

comparisons (M is the number of types of user ac-

tivity), and as there are N such arrays, then it spends

M ∗ N computation time. For the second step of look-

ing at the exclusive intrusions, that depends on the ac-

MISUSE DETECTION - An Iterative Process vs. A Genetic Algorithm Approach

457

tual number of possible intrusions found K. For each

type of activity M, it checks the common type of ac-

tivity in order to check for violations of constraints.

So for this case it spends M ∗ K computation time,

where K < N. In conclusion, the iterative process is

O(MN).

For the case of the GA, it depends on the popula-

tion size S, number of generations G and length M of

each P array. So, for each hypothesized array OZ—of

length N, and the ones that belong to the population—

the algorithm performs N calculations for each type of

activity, and as there are M types of activity, this gives

M ∗ N calculations. As the population size is S, for

each generation the algorithm performs M ∗ N ∗ P cal-

culations. As the algorithm has G generations, it gives

a total computational complexity of order O(MNSG).

Clearly, the GA cost is higher by O(PG) with the

down side of a false negative ratio that depends in part

on the population size (see Fig 3).

The computational complexity done by both algo-

rithms in ﬁnding the disjointed sets of possible intru-

sions is O(K

M), where K is the cardinality of the

disjointed set X (see section 3.1).

The space complexity is such that both algorithms

have to store the matrix of known intrusions and the

user activity (see Figure 1). The GA, additionally, has

to store the population that is of order O(SN).

4 CONCLUSIONS AND FUTURE

WORK

In this position paper we continue our previous work

(Diaz-Gomez and Hougen, 2005a; Diaz-Gomez and

Hougen, 2006; Diaz-Gomez and Hougen, 2005c;

Diaz-Gomez and Hougen, 2005b) using a GA for

doing misuse detection in log ﬁles, expanding the

number of intrusion arrays from 48 to 1, 008. Be-

sides that, the performance of an iterative process was

compared with a current implementation of a GA,

looking at the false negative ratio and computational

complexity of both algorithms. The iterative process

outperformed the GA for the test set, as established

by the false negative ratio and in computational and

space complexity. The population size of the GA

was increased in order to improve the quality of the

solution—fewer false negatives—but other parame-

ters may be changed in the GA as well, such as the

number of generations and the probability of the op-

erators, in trying to improve its performance. How-

ever, some of those possible changes may or may not

improve the quality of the solution and some may ex-

pend more computation time. The correct setting of

parameters is one of the difﬁculties in working with

GAs. Other heuristic methods, like neural networks,

can be addressed in order to continue comparing the

iterative process and the GA examined in this paper.

REFERENCES

Bace, R. G. (2000). Intrusion Detection. MacMillan Tech-

nical Publishing, USA.

Crosbie, M. and Spafford, G. (1995). Applying genetic pro-

gramming to intrusion detection. In Proceedings of

the AAAI Fall Symposium, pages 1–8.

Denning, D. E. (1986). An intrusion-detection model. In

Proceedings of the IEEE Symposium on Security and

Privacy, pages 118–131.

Diaz-Gomez, P. A. and Hougen, D. F. (2005a). Analysis and

mathematical justiﬁcation of a ﬁtness function used in

an intrusion detection system. In Proceedings of the

Genetic and Evolutionary Computation Conference,

pages 1591–1592.

Diaz-Gomez, P. A. and Hougen, D. F. (2005b). Analysis

of an off-line intrusion detection system: A case study

in multi-objective genetic algorithms. In Proceedings

of the Florida Artiﬁcial Intelligence Research Society

Conference, pages 822–823.

Diaz-Gomez, P. A. and Hougen, D. F. (2005c). Improved

off-line intrusion detection using a genetic algorithm.

In Proceedings of the 7th International Conference on

Enterprise Information Systems, pages 66–73.

Diaz-Gomez, P. A. and Hougen, D. F. (2006). A genetic al-

gorithm approach for doing misuse detection in audit

trail ﬁles. In Proceedings of the CIC-2006 Interna-

tional Conference on Computing, pages 329–335.

e, L. (1993). Security audit trail analysis using genetic

algorithms. In Proceedings of the 12th. International

Conference on Computer Safety, Reliability, and Se-

curity, pages 329–340.

e, L. (1998). GASSATA, a genetic algorithm as an alter-

native tool for security audit trail analysis. In Proceed-

ings of the First International Workshop on the Recent

Advances in Intrusion Detection.

Mitchell, M. (1998). An Introduction to Genetic Algo-

rithms. MIT Press.

Tjaden, B. C. (2004). Fundamentals of Secure Computer

Systems. Franklin and Beedle & Associates.

ICEIS 2007 - International Conference on Enterprise Information Systems

458
