3D HUMAN FACE MODELLING FROM UNCALIBRATED IMAGES

USING SPLINE BASED DEFORMATION

Nikos Barbalios, Nikos Nikolaidis and Ioannis Pitas

Department of Informatics, Aristotle University of Thessaloniki,GR-54124, Thessaloniki, Greece, (+30) 2310 996361

Keywords:

Uncalibrated 3D face reconstruction, face modelling, 3D reconstruction, mesh deformation, model based 3D

reconstruction.

Abstract:

Accurate and plausible 3D face reconstruction remains a difﬁcult problem up to this day, despite the tremen-

dous advances in computer technology and the continuous growth of the applications utilizing 3D face models

(e.g. biometrics, movies, gaming). In this paper, a two-step technique for efﬁcient 3D face reconstruction

from a set of face images acquired using an uncalibrated camera is presented. Initially, a robust structure from

motion (SfM) algorithm is applied over a set of manually selected salient image features to retrieve an esti-

mate of their 3D coordinates. These estimates are further utilized to deform a generic 3D face model, using

smoothing splines, and adapt it to the characteristics of a human face.

1 INTRODUCTION

Reconstructing an object’s geometry from a set of im-

ages has been one of the most popular and challenging

tasks in computer vision with applications such as vir-

tual view synthesis, gaming, security, virtual reality,

3DTV etc. 3D face reconstruction is a special case

of this problem. A popular solution to this problem

are the so-called Structure from Motion (SfM) algo-

rithms, that receive a number of points as input and

return the 3D coordinates of those points

Applications that utilize face models, (i.e. ad-

vertising, gaming, movie industry) prescribe that the

generated 3D face model should not only be accu-

rate but plausible and realistic as well. Faces, how-

ever, are essentially non-rigid surfaces and only a few

features can be reliably extracted and matched across

facial images, thus point-based approaches proposed

in the literature, (Mendonca and Cipolla(1999); Hart-

ley(1994); Pollefeys and Gool(1997)), result to non-

plausible face models restricted only to a small num-

ber of points. To compensate for the sparseness of the

reconstructed 3D points, almost all algorithms use a

prototype face model. Two types of prototype mod-

els are used: generic mesh models and 3D morphable

models.

Generic mesh models comprise of a set of nodes

corresponding to characteristic facial points of an av-

erage person. The generic model can be incorpo-

rated in the algorithm either before, during or after

the 3D reconstruction procedure. In (J. Strom(1999))

the generic mesh model was used to initialize the 3D

reconstruction procedure whereas in (Y. Shan(2001);

Fua(2000)), it was used to constrain the so-called

bundle adjustment optimization. Although these two

methods yield good results, the algorithm converges

close to the initial estimation resulting to a large

bias towards the generic model. This problem was

alleviated in (A.R. Chowdhury(2002); R. Hassan-

pour(2004)), by proposing the incorporation and de-

formation of the generic model after the optical-ﬂow

based estimation of the 3D structure coordinates.

3D morphable models, initially introduced in

(Blanz and Vetter(1999)), are derived by transform-

ing the shape and texture information of a database

containing high resolution head laser scans into a vec-

tor space representation. By doing so, the 3D head is

parameterized in a statistical way by a shape vector,

containing the 3D coordinates of the model’s nodes,

and a texture vector, containing the corresponding

texture value for each node. New faces can be ob-

tained by forming linear combinations of these shape

and texture vectors. Despite its realistic results, the

main drawbacks of this approach are the lack of ac-

curacy, its instability to illumination changes and the

huge computational cost for the convergence of the

algorithm, issues that where partially addressed in

(M. Dimitrijevic(2004); M. Zhao(2006)).

455

Barbalios N., Nikolaidis N. and Pitas I. (2008).

3D HUMAN FACE MODELLING FROM UNCALIBRATED IMAGES USING SPLINE BASED DEFORMATION.

In Proceedings of the Third International Conference on Computer Vision Theory and Applications, pages 455-459

DOI: 10.5220/0001081204550459

 SciTePress

The proposed method is a combination of a ro-

bust SfM algorithm, introduced in (M. Pollefeys and

Gool(1998)), with a 3D generic mesh face model.

Salient features of the face are manually marked on

the set of images and the SfM algorithm is used

to produce a cloud of 3D points. This point cloud

is subsequently utilized for the deformation of the

generic face model. The proposed method is re-

lated to (R. Hassanpour(2004)) and (A.R. Chowd-

hury(2002)) since it also deforms the generic model

after the SfM algorithm. However, in the proposed

method the deformation of the generic mesh model is

implemented using a different approach, namely thin

plate smoothing spline functions which, as shown in

the experimental results, accurately estimates the de-

formation of each node of the model. Moreover, our

algorithm yields satisfactory results using fewer input

images.

2 3D RECONSTRUCTION

Our method is based on the iterative SfM algorithm

proposed in (M. Pollefeys and Gool(1998)). This al-

gorithm is a combination of a projective SfM algo-

rithm with an auto-calibration algorithm to restrict

the ambiguity of the reconstruction from projective

to metric. The basic steps of the algorithm will be

shortly described below for the sake of completeness

of this paper.

The method is based on the ideal pinhole cam-

era model. In such a camera, the projection m =

[x,y,0]

, on the image plane, of an object point

M = [X,Y,Z, 0]

is described, in homogeneous coor-

dinates, by

m ∼ P· M (1)

where P is the 3× 4 projection matrix of the camera,

encoding the camera’s intrinsic and extrinsic parame-

ters. The symbol ∼ denotes that equality is valid up

to an arbitrary scale factor, since we use homogeneous

coordinates.

Initially, a set of N characteristic points (features)

are extracted from the image set and their corre-

spondences across the images are identiﬁed. Using

those feature points, the 3×3 fundamental matrix F

which is an algebraic representation of the epipolar

geometry between two views i and j, can be evaluated

using the following homogeneous system of equa-

tions:

· F

· q

= 0 (2)

where q

= [m

i,1

i,2

i,3

...,,m

i,N

]

and m

i,k

de-

notes the k-th feature in image i. Note that since

has 7 degrees of freedom (M. Pollefeys and

Gool(1998)), at least 7 features should be present in

all the images of the set, i.e. N ≥ 7.

After evaluating, using (2), the fundamental ma-

trix F

between the views 1 and 2, the projection

matrices P

and P

for those two views can be esti-

mated. If we consider that the ﬁrst view is aligned

with the world coordinate system, its projection ma-

trix is P

= [I

3×3

] where I,0 denote the identity

matrix and the all-zero vector respectively. Sub-

sequently, using the epipolar constraint the projec-

tion matrix P

of the second view is constrained to

= [[e

] × F

+ e

|σe

] ,where τ

is a 3× 1 vec-

tor determining the reference frame of the reconstruc-

tion, σ is the scale factor of the reconstruction and e

the position of the epipole in the second image. Af-

ter the evaluation of the two projection matrices, an

estimate M

of the position of the k-th feature point

(k = 1,...,N) in the projective space can be obtained

using (1).

In the next step, this projectivereconstruction M

is further used to iteratively retrieve, through (1), the

projection matrices for all the additional views of the

image set. Up to this step, the evaluation of all the

projection matrices is based on the projective recon-

struction M

retrieved only from the ﬁrst two views.

The next step, which is called bundle adjustment,

comprises the overall optimization of the reconstruc-

tion which reﬁnes both the reconstructed structure and

the projection matrices for all the views. The opti-

mization criterion is the overall minimization for all

the views of the re-projection error, i.e. the distance

between the 2D feature points and the estimates pro-

duced by back-projecting the produced 3D model on

the images :

) = arg min

∑

i,k

− P

· M

)

(3)

where P

is the projection matrix for view i, M

the 3D coordinate vector of the k-th feature and m

i,k

denotes the 2D coordinates vector of the k-th feature

in image i.

The ﬁnal step of the algorithm is the self-

calibration procedure which retrieves, for each view

i, the camera intrinsic parameters matrix K

and up-

grades the structure to the metric space (M. Pollefeys

and Gool(1998)). Once the intrinsic parameters are

retrieved, the reconstructed 3D points are transformed

from the projective space into the metric space, lead-

ing to a 3D point cloud.

In our implementation, we used 15 characteristic

points of the human face namely the corners of the

mouth, the midpoints of the lips, the tip and base of

the nose, the corners of the eyes, the point between

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

456

Figure 1: The selected characteristic points depicted on a

sequence of facial images.

the eyebrows and two characteristic points of the eye-

brows. These points, shown in Figure 1, are selected

not only because they are easily identiﬁable, but also

because they have a representation in the nodes of the

generic model used. It is also worth mentioning that

these points and their correspondences are manually

deﬁned and thus, the absence of large position errors

and false correspondences between them is assumed.

3 GENERIC MODEL

DEFORMATION

The second part of our algorithm deals with the incor-

poration of a generic face model into the reconstruc-

tion procedure. Our algorithm uses a generic face

model derived from the Candide face model, devel-

oped by the Linkoping University (Ahlberg(2001)).

Since Candide is a rather limited resolution model,

comprised of 103 3D nodes and 184 triangles, it has

been enhanced in three steps: Initially, extra nodes

have been added in areas where the original model

has very few nodes (i.e. nose and eyes areas), to in-

crease the deformation ﬂexibility of those areas. Then

the PN triangles mesh subdivision algorithm (A. Vla-

chos(2001)) has been applied leading to an enhanced

generic model composed by 1729 nodes and 3392 tri-

angles. Finally, the enhanced model was smoothed to

eliminate the sharp-edges and its faceted appearance

leading to the ﬁnal generic model used in our algo-

rithm. It should be noted that the nodes of the origi-

nal model are included in the nodes of the enhanced

model.

During the ﬁrst step of the deformation, the

generic model undergoes global rotation, translation

and scaling, so that it is roughly aligned with the

cloud of 3D points. To determine the scale factor, the

mean distance between the two corners of the eyes

and the two corners of the mouth is evaluated both in

the generic model and the point cloud and their ratio

is used as the scale factor. After scaling, the generic

model is rotated so that its orientation is roughly the

same with that of the point cloud. Finally, the generic

model is translated so as to minimize the sum of Eu-

clidean distances between the eyes and mouth centers

of the generic model and the point cloud.

Having aligned the generic model and the point

cloud, the next step is to deform all the nodes of

the generic model according to the reconstructed 3D

point cloud. This problem can be formulated as fol-

lows. Given the 3D points G

of the generic model

(i = 1, ..., L where L = 1729), the 3D points M

the point cloud ( k = 1,..,N where N = 15) and the

distances [dx

,dy

,dz

] , k = 1,...,N between the N

3D points of the cloud and their corresponding nodes

of the generic model, our objective is to estimate the

new coordinates G

′

of the L− N nodes of the generic

model that do not have a corresponding point in the

point cloud.

We introduce three error functions

(x) = dx = x− x

′

(4)

(y) = dy = y− y

′

(z) = dz = z− z

′

where [x,y,z]

are the coordinates of a node of

the generic model and [x

′

] the coordinates of the

corresponding point of a smooth surface that passes

through the points M

of the point cloud. In other

words, these error functions provide the distance D

[dx

,dy

,dz

]

along the three axes between a point

of the generic model and its corresponding point

in the target surface. Since these error functions can

be evaluated only for the N model nodes that have a

corresponding point M

in the point cloud, the values

for the rest of the generic model nodes should be

estimated through extrapolation and interpolation of

those N known values.

For this purpose we used thin plate smoothing

spline functions, which interpolate a curve over a

ﬁxed set of nodes in a way that minimizes the bending

energy of the curve (Bookstein(1989)). The interpo-

lation of the aforementioned error functions results to

a vector ﬁeld deﬁned in the 3-dimensional space that

expresses the difference between the generic model

and a smooth surface passing through the 15 points

of the point cloud. Using these error functions, the

distances D

= [dx

,dy

,dz

]

, i = 1,...,L, for all the

nodes of the generic model can be evaluated. Thus

the new coordinates G

′

of each node of the deformed

3D face model are derived through G

′

= G

+ D

Initially, the functions f

(x) and f

(y) are inter-

polated, estimating the displacements of the generic

model’s nodes along the x and y axis respectively.

Interpolation of function f

(z), which estimates the

depth of the face, is done separately and requires dif-

ferent handling. This can be explained intuitively by

3D HUMAN FACE MODELLING FROM UNCALIBRATED IMAGES USING SPLINE BASED DEFORMATION

457

realizing that if one’s eyes are wide apart, the mouth,

nose and the whole face are likely to be wider as well.

For the depth of a face however this is not true since

the fact that somebody has a long nose has no effect

in the overall distribution of the face nodes along the

z axis. Additionally, the depth of the various parts of

the face, i.e. face, nose, eyes, may vary dramatically

which prescribes that they should be dealt separately.

For all those reasons, the various parts of the face are

interpolated seperately along the z axis, and the ﬁnal

model emerges by combining those partial 3D patches

into the ﬁnal deformed 3D face model.

Up to this point, all the error functions have been

interpolated and the deformed generic model can be

obtained. The ﬁnal stage of the deformation step aims

to improve the model’s visual appeal by adding tex-

ture to the model. This is done by re-projecting the

deformed 3D face model on a 2D image and generat-

ing texture for each triangle of the face mesh. Since

no correspondingcolor is available for some triangles,

due to occlusion, the blank areas are ﬁlled by means

of color interpolation from their neighbor areas.

4 EXPERIMENTAL RESULTS

For our experiments we used a variety of sets of high

resolution (2048× 1536) facial images, acquired with

an off-the-shelf uncalibrated camera, and user sup-

plied features and correspondences. We used 3 im-

ages per set, which is the minimum number of im-

ages for a proper reconstruction, and obtained several

face models which were later used to evaluate our al-

gorithm. Experiments conducted with sets containing

more than 3 images lead to similar results.

The deformed textured model, derived from the 3

facial images depicted in Figure 1, is presented in Fig-

ure 2. It can be seen that the model encodes efﬁciently

well the basic facial characteristics of the subject. De-

spite the fact that the camera positions used to acquire

the facial images are quite close to each other,the pro-

posed method estimates adequately well the depth of

the face and the produced 3D face model resembles

the subject considerably well.

Table 1: Mean, min and max normalized approximation er-

ror of 8 models.

Mean Error Min Error Max Error

0.006 0.000 0.044

Due to the lack of real 3D face data (i.e. laser

scans), we used the face models produced by our al-

gorithm as ground truth to assess the effectiveness of

Figure 2: Different views of the ﬁnal reconstructed 3D

model for the image set depicted in Figure 1.

our method. More speciﬁcally, synthetic images, each

corresponding to a different view of a certain 3D face

model, were obtained and used as input image sets for

our algorithm. The produced 3D face model was sub-

sequently compared with the corresponding original

3D model. The objective criteria to measure the sim-

ilarity between the two face models was the 3D Eu-

clidian distances between the 116 nodes of the orig-

inal face model and their corresponding nodes in the

produced face model. These nodes represent the basic

nodes of the Candide model along with the nodes we

added to enhance the resolution of the model in the

nose area. Results are presented in Table 1 where the

mean, minimum and maximum approximation errors

averaged over 8 such reconstructions is depicted. The

approximation error is calculated for all the 116 nodes

of the 3D face. It should be noted that the approxima-

tion errors in this table have been normalized with the

height of the produced 3D face and thus an error value

of 0.01 corresponds to a approximation error equal to

1/100-th of the head height.

It is obvious that despite the fact that the generic

model was deformed using information only from 15

3D points, the use of thin-plate smoothing splines pro-

duced efﬁcient estimates of the location of the rest

of the nodes and the reconstructed 3D model is very

close to the original. As expected, the mean error

for all the nodes of the model is considerably small

(0.06). The experimental procedurerevealedthat only

5 out of the 116 nodes tend to produce errors larger

than 0.01. These 5 nodes correspond to nodes in the

forehead area where the mean error is larger than the

rest of the face due to the lack of 3D reconstructed

points in the area.

VISAPP 2008 - International Conference on Computer Vision Theory and Applications

458

An alternative way to evaluate the effectiveness

of our method is the re-projection error for all the

images in an image set. Experiments afﬁrmed that

the re-projection error is signiﬁcant small since it

does not exceed 4 pixels for images of dimensions

2048× 1536.

Through experimentation we have reached the

conclusion that the quality of the results is mainly af-

fected by the selection of the ﬁrst two views. These

views should correspond to views taken from angles

that are as far apart as possible to capture adequately

the depth of the face. Furthermore, the accuracy of the

feature selection procedure largely affects the accu-

racy of the reconstruction, since the reconstruction al-

gorithm is based on the determination of the epipoles

and hence is very sensitive to measurement noise.

5 CONCLUSIONS

In this paper, we have presented a two-step technique

to deal with the challenging task of face reconstruc-

tion in three dimensions from a set of uncalibrated

images. In the ﬁrst step of the proposed approach,

15 salient features are manually identiﬁed in all the

images of the set and their 3D coordinates are re-

trieved using an uncalibrated 3D reconstruction algo-

rithm. In the second step, a generic face model is de-

formed according to the 3D points produced in the

ﬁrst step. Since the 3D coordinates of only 15 points

are known, the 3D coordinates for the rest nodes of

the generic model are retrieved through interpolation

and extrapolation, with extra provisions to ensure a

proper face reconstruction. The experimental results

prove that the combination of a robust SfM algorithm

with a generic mesh model deformed using thin plate

smoothing splines can yield very satisfactory 3D re-

constructions.

ACKNOWLEDGEMENTS

This work was supported by the ”SIMILAR” Eu-

ropean Network of Excelence on Multimodal Inter-

faces of the IST Programme of the European Union

(www.similar.cc)

REFERENCES

P. R. S. Mendonca and R. Cipolla. A simple technique for

self-calibration. In Proc. of the IEEE Conf. on Com-

puter Vision and Pattern Recognition (CVPR), vol-

ume 1, pages 500–505, 1999.

R. I. Hartley. Euclidean reconstruction from uncalibrated

views. In Proc. of the 2nd Joint European - US Work-

shop on Applications of Invariance in Computer Vi-

sion, pages 237–256. Springer-Verlag, 1994.

M. Pollefeys and L. Van Gool. A stratiﬁed approach to

metric self-calibration. In Proc. of the IEEE Conf.

on Computer Vision and Pattern Recongition (CVPR),

pages 407–418, 1997.

S. Basu A. Pentland J. Strom, T. Jebara. Real time tracking

and modeling of faces: An ekf-based analysis by syn-

thesis approach. Technical Report 506, MIT Media

Laboratory, 1999.

Z. Zhang Y. Shan, Z. Liu. Model-based bundle adjustment

with application to face modeling. In Proc. of IEEE

Internation Conference on Computer Vision (ICCV),

volume 2, pages 644–651, Vancouver, BC, Canada,

2001.

P. Fua. Regularized bundle-adjustment to model heads from

image sequences without calibration data. Interna-

tional Journal of Computer Vision, 38(2):153–171,

2000.

S. Krishnamurthy T. Vo A.R. Chowdhury, R. Chellappa. 3d

face reconstruction from video using a generic model.

In Proc. of IEEE International Conference on Multi-

media and Expo (ICME), volume 1, pages 449– 452,

2002.

V. Atalay R. Hassanpour. Delaunay triangulation based

3d human face modeling from uncalibrated images.

In Proc. of Computer Vision and Pattern Recognition

Workshop (CVPR), pages 75– 75, June 2004.

V. Blanz and T. Vetter. A morphable model for the syn-

thesis of 3d faces. In Proc. of the International Con-

ference on Computer Graphics and Interactive Tech-

niques (SIGGRAPH), pages 187–194, New York, NY,

USA, 1999.

P. Fua M. Dimitrijevic, S. Ilic. Accurate face models from

uncalibrated and ill-lit video sequences. In Proc of

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR), volume 2, pages 1034–1041,

2004.

T. Sim M. Zhao, T. Seng Chua. Morphable face recon-

struction with multiple images. In Proc. of the Inter-

national Conference on Automatic Face and Gesture

Recognition (AFGR), pages 597–602. IEEE Computer

Society, 2006.

R. Koch M. Pollefeys and L. Van Gool. Self-calibration and

metric reconstruction in spite of varying and unknown

internal camera parameters. In Proc. of the Interna-

tional Conference on Computer Vision (ICCV), pages

90–95, 1998.

J. Ahlberg. Candide 3 - an updated parameterized face.

Technical Report LiTH-ISY-R-2326, Dept. of Elegx-

trial Engineering, Linkoping University, Sweden,

2001.

C. Boyd J.L. Mitchell A. Vlachos, J. Peters. Curved pn tri-

angles. In Proc. of the 2001 Symposium on Interactive

3D graphics, pages 159–166. ACM Press, 2001.

F. L. Bookstein. Principal warps: Thin-plate splines and

the decomposition of deformations. IEEE trans. Pat-

tern Analysis and Machine Intelligence (PAMI), 11

(6):567–585, 1989.

3D HUMAN FACE MODELLING FROM UNCALIBRATED IMAGES USING SPLINE BASED DEFORMATION

459
