A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO
GAMES
Tom Cuypers, Cedric Vanaken, Yannick Francken, Frank Van Reeth and Philippe Bekaert
Hasselt University - Expertise Centre for Digital Media, Transnationale Universiteit Limburg
Wetenschapspark 2, 3590 Diepenbeek, Belgium
Keywords:
Interactive Video Games, Video-Based Rendering, Human Computer Interaction.
Abstract:
We present a framework that allows for a straightforward development of multi-camera controlled interactive
video games. Compared to traditional gaming input devices, cameras provide players with many degrees of
freedom and a natural kind of interaction. The use of cameras can even obsolete the need for special clothing
or other tracking devices. This partly accounted for the success of the currently popular single-camera video
games like the Sony Eyetoy. However, these games are fairly limited in the use of 3D scene information.
Using multi-camera setups, this limitation can be surpassed, but typically many different image processing
and computer vision techniques are involved. Our framework divides multi-camera based games into basic
algorithms that are easily combinable into several sequentially executed stages. Therefore the amount of effort
to develop new games can significantly be reduced. The capabilities of our framework are demonstrated
with a number of conceptual games, proving that multi-camera controlled video games can be created with
off-the-shelf hardware.
1 INTRODUCTION
Video game companies have recently started broad-
ening their range of traditional input devices - mouse,
keyboard, joystick - with alternative devices such as
motion sensors and cameras. Sony successfully re-
leased camera based Eyetoy games for the Playstation
2 (Eyetoy Sony, 2003) and furthermore created best-
sellers that are controlled with other non traditional
input devices like microphones (Singstar Sony, 2004)
and guitars (Guitar Hero Sony, 2005). Last year, Nin-
tento released the Wii console (Nintendo Wii, 2006)
of which the user-input is mainly based on the tracked
motion of the Wii-Remote. The success of these
games shows that a consumer demand exists for al-
ternative input devices to control video games.
We choose to work with cameras because they
provide multiple degrees of freedom as well as a nat-
ural kind of interaction for the gamer. Current image
processing and tracking techniques eliminate the need
for wearing special clothing or tracking devices. The
live-captured images in camera controlled games fur-
thermore allow for creating an immersive augmented
reality.
Many commercial camera controlled video games
and webcam applications have already been released,
but the Playstation Eyetoy has set the standard for
most of them. Albeit that these products do have
some limitations. The use of a single camera restricts
the developer to only work with 2D scene informa-
tion. Without depth information, the gameplay will
often only feel natural when the user performs move-
ments in a plane parallel to the camera’s image plane.
Many 3D movements are undetectable due to the 2D
projection on the camera’s image plane, substantially
restricting the range of interaction possibilities. The
resulting interaction with the game will often be un-
intuitive and unsatisfying.
When working with multiple synchronized cam-
eras that are viewing a scene from different positions
and/or angles, 3D information of the scene can be re-
constructed. This reconstructed information allows
for creating games that are controlled by 3D human
motions, providing players with a natural way of con-
trolling a virtual avatar.
In this paper we present a framework that allows
for easily creating video games that are controlled
with several cameras. The framework is built keeping
a highly modular paradigm in mind. The video games
are created by implementing up to ve different pro-
gramming stages that are executed sequentially. Tra-
ditional or new image/video processing or computer
443
Cuypers T., Vanaken C., Francken Y., Van Reeth F. and Bekaert P. (2008).
A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES.
In Proceedings of the Third International Conference on Computer Graphics Theory and Applications, pages 443-449
DOI: 10.5220/0001096904430449
Copyright
c
SciTePress
vision techniques can be individually supplied to each
stage.
Our framework consists of the following ve
stages:
Input: capturing the scene and player using a num-
ber of calibrated and synchronized cameras
Video Processing: transforming the captured video
frames into a format better suited for the efficient
extraction of relevant data in subsequent steps
Depth Extraction: combining 2D information of the
images to reconstruct 3D information
Post-processing: using the reconstructed 3D infor-
mation to control the game
Output: composing visual output
An in-depth overview of these stages will be dis-
cussed later, as well as suggestions for algorithms that
can be used in each stage. Some examples of video
games that were created using our framework will be
presented and discussed in the results section.
2 RELATED WORK
Cameras have been previously used as input hardware
for various human computer interaction and virtual
reality applications as well as for computer games.
The quality of these applications is highly dependent
on the hardware and computer vision software used.
Several suitable vision algorithms along with possible
interaction applications are discussed by Crowley et
al. (Crowley, 1997; Crowley et al., 2000).
Camera controlled human computer interaction
applications are also being used by persons with phys-
ical disabilities who are not able to conveniently use
a mouse or a keyboard. These kind of interactions
can be achieved by filming and analyzing certain
body features (Betke et al., 2002) like eg. a person’s
eyes (Chen et al., 2001) or nose (Gorodnichy et al.,
2002).
Balcisoy and Thalmann (Balcisoy and Thalmann,
1997) describe a technique that allows to record a real
actor and place him into a virtual reality world. The
actor can then interact with virtual characters, where
the virtual characters’ actions are chosen from pre-
recorded key-actions by a human operator. De Decker
et al. (De Decker et al., 2007) propose a technique for
interactive collision detection and response between
real objects/people and virtual objects using multiple
cameras.
Mitsubishi Electronics made a considerable con-
tribution to the area of camera controlled interactive
video games. To answer the need for low cost hard-
ware and high speed processing power, they invented
the Artificial Retina Chip (Kyuma et al., 1994; Free-
man et al., 1996; Freeman et al., 1998), this by anal-
ogy with biological retinas that combine the functions
of detection and processing. The chip has a built-in
detector for mereley 32× 32 to 256 × 256 resolution
images and was used by Sega Saturn (Sega Saturn,
1994) and Nintendo Gameboy (Nintendo Gameboy,
1998). Current days, the most famous camera con-
trolled games are those of Sony Playstations Eye-
toy (Eyetoy Sony, 2003).
Camera controlled applications receive their pri-
mary input from filmed objects and/or actors. These
individual subjects can be located and tracked by
using object tracking techniques (Metaxas and Ter-
zopoulos, 1993; Wren et al., 1997).
Most traditional camera based applications are re-
stricted to using only one 2D video input stream.
With a number of calibrated cameras this input
stream can be extended to obtain 3D information
using vision techniques such as dense depth esti-
mation (Scharstein and Szeliski, 2002) and visual
hull reconstruction (Laurentini, 1994), each having
its (dis)advantages. Depth estimation is especially
useful when two cameras are used in a small base-
line setup. Scharstein and Szeliski (Scharstein and
Szeliski, 2002) have published an overview of differ-
ent modern stereo depth estimation algorithms. The
purpose of these algorithms is to create a disparity
map from two small baseline cameras for one of the
reference images. Alternatively, visual hull recon-
structions represent an estimated 3D model of an ac-
tor or object. This 3D model is acquired by using sil-
houettes extracted from different video streams (Lau-
rentini, 1994). The accuracy of visual hull reconstruc-
tions is higher when two or more cameras are placed
in a wide baseline setup.
3 MULTI-CAMERA
INTERACTION FRAMEWORK
In this section a more detailed description of our
framework will be given. We subdivide the produc-
tion process of camera controlled games into five high
level stages, namely input, video processing, depth ex-
traction, post-processing and output. For each stage,
several appropriate algorithms are proposed. The
combination of these stages allows to create interac-
tive video games as well as general purpose applica-
tions. However, we mainly focus on real-time game
interaction.
Although we present five different stages, not all
of them need to be executed. For instance, by ig-
noring the depth extraction stage, regular single cam-
GRAPP 2008 - International Conference on Computer Graphics Theory and Applications
444
era games (Eyetoy Sony, 2003; Freeman et al., 1996;
Freeman et al., 1998) can be created. For real-time
user-interaction, one will most likely need to make
a tradeoff between speed and quality, sometimes even
resulting in eliminating or combining different stages.
The implementation of each stage will furthermore
depend highly on the kind of video game that needs to
be developed, combined with the used camera setup,
processing hardware etc.
3.1 Input
Typically two or three digital cameras are used to
capture a real world actor that controls the vir-
tual world. Nevertheless, other setups are possible,
eg. remote network cameras, infrared cameras, pre-
recorded videos or alternative input hardware.
3.2 Video Processing
In this stage the video frames received from the in-
put devices are transformed into a format better suited
for efficient extraction of relevant data in subsequent
stages.
One commonly used video processing operation
is camera noise reduction. The necessity of this op-
eration depends on the quality of the digital cameras
as well as the lighting conditions in the scene. Input
video frames can be denoised in the spatial, frequency
and temporal domain (Dubois and Sabri, 1984; Gon-
zalez and Woods, 1992), typically having a loss of
high frequency detail as a side effect.
Another commonly used technique in this stage is
background subtraction. Camera controlled applica-
tions are mostly interested in foreground objects or
actors, therefore background subtraction is inevitable
(eg. shape-from-silhouette, see section 3.3). Interac-
tive applications require the background to be elimi-
nated in real-time. Blue or green screen matting tech-
niques (Mishima, 1993; Smith and Blinn, 1996) fulfill
this requirement, as well as (less efficient) techniques
that handle more natural backgrounds (Cheung and
Kamath, 2004; McIvor, 2000).
Many other image or video processing filters
like motion detection (Spacek, 1986), skin detec-
tion (Vezhnevets et al., 2003), etc. also fit perfectly
into this stage.
3.3 Depth Extraction
Given the filtered and annotated video frames, the re-
quired 3D information can be extracted.
When reconstructing the body of the actor with-
out focussing on specific features, standard 3D re-
construction techniques such as dense depth esti-
mation (Scharstein and Szeliski, 2002; M¨uhlmann
et al., 2002) and visual hull modeling (Laurentini,
1994; Erol et al., 2005) are appropriate. Certain lo-
cal dense depth estimation algorithms (Woetzel and
Koch, 2004; Yang and Pollefeys, 2003) can get a
significant speed boost when parallelized on multi-
processor systems such as those featured on current
graphics hardware.
Visual hull methods are best suited for setups that
contain at least three cameras, especially when novel
views need to be synthesized. Although visual hull re-
construction is practically independent of image res-
olution, full model reconstruction has to be avoided
whenever possible because of the high computational
load. For example, in situations where the visual hull
is only needed to determine physical collisions and
responses, calculations can be performed directly in
image space (De Decker et al., 2007).
Depending on the type of game, the full actor’s
motion or a selection of his body parts needs to be
tracked. When it suffices to focus on particular body
parts such as hands and head, standard object track-
ing (Kalman, 1960; Metaxas and Terzopoulos, 1993;
Wren et al., 1997; Isard and Blake, 1998; Li et al.,
2003) can be applied.
3.4 Post-processing
Up until this stage the necessary 2D/3D information
has been gathered and processed to provide interac-
tion between the real scene and the virtual scene. Us-
ing a standard physics engine, this can be achieved by
applying collision detection and response between the
player and virtual objects.
Also alternative avatar approximations and inter-
actions are possible. A very plausible method to cre-
ate an avatar for the player can consist of using kine-
matics. The player is represented by a skeleton and its
pose is defined by the degrees of freedom of the joints.
This pose can be obtained with forward kinematics
by tracking the joints separately (Rubio et al., 2006),
or with inverse kinematics (Welman, 1993; Parent,
2001) by tracking only the end-effectors and estimat-
ing the intermediate joints (Jaume et al., 2006). This
skeleton provides many interaction possibilities from
simple collision detection to 3D motion recognition
etc.
3.5 Output
During the final stage, the visual output for the game
has to be composed. Depending on the specifications,
2D and/or 3D data is rendered to a display. Since real
A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES
445
input frames were obtained at the input stage, a vir-
tual but realistic approximation of the avatar can be
integrated into the output using video-based render-
ing methods (Magnor, 2005). This virtual/augmented
reality data can be displayed on a TV or computer
screen, but can also be rendered to alternative output
devices like 3D glasses.
4 RESULTS
In this section we demonstrate the power and the ease
of use of our framework by discussing how the ve
stages are implemented for a number of conceptual
interactive games. The optimal setup to capture 3D
scene information is a blue/green screen environment
that contains many cameras. Unfortunately, creating
and setting up this kind of construction is often un-
practical and using it may be computationally very ex-
pensive. Therefore we discuss severaldifferent games
that make use of alternative setups. The presented
games run at a framerate between 10 and 15 fps on a
Pentium Mobile 1.5 GHz laptop, which is sufficiently
accurate and usable for real-time interaction.
4.1 Frogger
This game is a camera controlled version of the clas-
sic Frogger game, introduced by Konami (Konami,
1981). The goal of Frogger is to cross the street with-
out getting hit by cars. The player is filmed head-on
and can move in any direction to navigate the avatar
in the game. The setup consists of three small base-
line Point Grey Research Flea2 (Point Grey Research,
2007) cameras and a diffuse green background. Nav-
igation is achieved by locating the player in the in-
put images using green screen matting (Smith and
Blinn, 1996), applying local dense depth map estima-
tion (Yang and Pollefeys, 2003) and calculating the
center of mass. Because of the green screen mat-
ting, almost no specularities are visible, allowing us
to make use of a local depth estimation method to ro-
bustly detect the center of mass. A structural scheme
is shown in Figure 1.
4.2 Depth based Drawing
The goal of this game is to paint a given sequence
of letters or symbols on the screen. The setup
consists of three small baseline Point Grey Research
Flea2 (Point Grey Research, 2007) cameras that film
the player head-on. To make sure that moving per-
sons in the background do not disrupt the gameplay,
background changes behind a certain depth threshold
DepthEstimation
Locating Avatar
INPUT
VIDEOPROCESSING
DEPTH
EXTRACTION
POST
PROCESSING
OUTPUT
Background
Subtraction
Background
Subtraction
Background
Subtraction
Figure 1: Scheme of Frogger.
NoiseReduction
SkinDetection
DepthEstimation
Depth Thresholding
INPUT
VIDEO
PROCESSING
DEPTH
EXTRACTION
POST
PROCESSING
OUTPUT
LetterRecognition
Figure 2: Scheme of the depth based drawing game.
are discarded. Skin detection (Vezhnevets et al.,
2003) is performed on one image and a local depth
estimation technique (Yang and Pollefeys, 2003)
is executed on the skin-classified pixels. Due to
the skin detection, possible specular highlights are
automatically ignored, which makes a local depth
estimation sufficient. Unfortunately, fast player
movements are often undetected because of an excess
of motion blur. The depth-thresholded skin-pixels are
then fed into a letter recognition algorithm that we
have built upon the LibStroke library (Willey, 1997).
An overview is depicted in Figure 2.
GRAPP 2008 - International Conference on Computer Graphics Theory and Applications
446
Background
Subtraction
VisualHull
Physics
INPUT
VIDEO
PROCESSING
DEPTH
EXTRACTION
POST
PROCESSING
OUTPUT
Background
Subtraction
Background
Subtraction
Figure 3: Scheme of Dodge-it.
4.3 Dodge-it
The goal of this game is to dodge the virtual ob-
jects that fall into the scene. A wide baseline setup
is used that consists of three Point Grey Research
Flea2 (Point Grey Research, 2007) cameras that film
the player head-on and sideways. More cameras can
be used in this setup, filming the player from an
other side of the room, or from in-between angles
etc., however note the trade-off between accuracy and
speed. Green screen background subtraction (Smith
and Blinn, 1996) is first performed on every image,
and visual hulls (Laurentini, 1994) are calculated for
the foreground objects and actors. Note that visual
hulls are used because dense depth maps only allow
for limited physical collisions. A voxel based vi-
sual hull is created of the foreground objects (Mar-
tin and Aggarwal, 1983). This model is used to
check for collision detection and response with vir-
tual objects, handled by ODE (Open Dynamics En-
gine, 2001). The output is a combination of a virtual
rendered scene and a billboard of the player. Shad-
ows have been added to provide an extra depth cue.
An overview is given in Figure 3.
4.4 Spiral
Spiral is a digital version of an old traditional folk
game where one must navigate a metal ring around
a curved tube while avoiding collisions between the
ring and the tube. Herefore an object, containing three
different colors, is tracked using a wide baseline setup
of two (or three) Point Grey Research Flea2 (Point
ParticleFiltering
TransformingObject
INPUT
VIDEO
PROCESSING
DEPTH
EXTRACTION
POST
PROCESSING
OUTPUT
CollisionDetection
Figure 4: Scheme of spiral.
Grey Research, 2007) cameras. We use the Conden-
sation algorithm (Isard and Blake, 1998) - a popular
variant of the particle filter - to track this object in
the depth extraction stage. The calculated location
and orientation is then mapped into the virtual world.
Figure 4 shows this game where the player holds the
tracked object that controls the ring in the game. Col-
lision detection between the ring and the spiral is per-
formed to define the player’s score. The output is a
pure virtual world.
4.5 Roboshoot
The purpose of Roboshoot is to shoot moving virtual
3D objects in the scene. The player is filmed head-on
by a Point Grey Research Bumblebee (Point Grey
Research, 2007) camera and can move his arms in the
direction he wants to aim his virtual guns at. First,
skin detection (Vezhnevets et al., 2003) is performed
to locate the hands and face of the player in one of
the input images. This 2D location is expanded to
a 3D location in the depth extraction stage by using
the depth map which is automatically created by
the Bumblebee camera. The transposed Jacobian
method (Welman, 1993) for inverse kinematics is
then used with these locations to estimate the upper-
body pose of the player, defining the movements of
the avatar. Although these virtual movements are not
always exactly corresponding to the real movements,
this proves to be a very efficient and plausible pose
approximation method. However, problems may
occur when bodyparts other than face and hands are
exposed. Figure 5 contains a synopsis of the game.
A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES
447
SkinDetection
FaceandHand Tracking
INPUT
VIDEO
PROCESSING
DEPTH
EXTRACTION
POST
PROCESSING
OUTPUT
InverseKinematics
Figure 5: Scheme of Roboshoot.
5 CONCLUSIONS
We have presented a framework targeted at creating
video games that are controlled by input from multi-
ple cameras. Our framework embodies five modular
stages from which each serves a different role in the
execution of the game. While the purpose of each
stage is fixed during the lifetime of a video game,
novel algorithms can easily be plugged in to replace
or complement already used algorithms. A proof of
concept is provided by discussing several interactive
video games that were implemented using the frame-
work. These multi-camera controlled games not only
show the usability of the framework, but also prove to
be an asset to standard game interaction techniques.
We believe that our framework is applicable to vari-
ous other forms of human computer interaction.
6 FUTURE WORK
Currently our framework mainly focuses on single
setup vision-based interaction methods. Integrating a
specific network layer could allow for creating online
camera-based multiplayer video games. Providing
multi-modal interaction possibilities such as combi-
nations with standard game controllers, speech recog-
nition etc. can furthermore strengthen of this frame-
work.
Although we believe that off-the-shelf technology
is ready for multi-camera computer games for home
users, user friendly setup calibration methods still
need further investigation. While fixed pre-calibrated
cameras such as the Bumblebee (Point Grey Re-
search, 2007) are already available, wide baseline se-
tups are location dependent and need to be calibrated
on the spot. In general, adaptive scene dependent es-
timation of the setup parameters such as camera cal-
ibration data, image resolutions, exposure times, en-
abling or disabling denoising, etc. is an interesting fu-
ture direction.
Experimenting with other hardware such as an in-
frared projector-camera combination might also im-
prove our system, however this hardware is less com-
monly used.
ACKNOWLEDGEMENTS
We gratefully express our gratitude to the European
Regional Development Fund (ERDF), the Flemish
Government and the Flemish Interdisciplinary insti-
tute for Broadband Technology (IBBT), which are
kindly funding part of the research at the Exper-
tise Centre for Digital Media. Part of the work is
also funded by the European research project IST-2-
511316-IP : IP-RACINE (Integrated Project Research
Area CINE). We also like to thank our colleagues,
especially Maarten Dumont and Steven Maesen, for
their time and effort in this work.
REFERENCES
Balcisoy, S. and Thalmann, D. (1997). Interaction be-
tween real and virtual humans in augmented reality.
In CA ’97: Proceedings of the Computer Animation,
page 31, Washington, DC, USA. IEEE Computer So-
ciety.
Betke, M., Gips, J., and Fleming, P. (2002). The Camera
Mouse: visual tracking of body features to provide
computer access for people with severe disabilities.
Neural Systems and Rehabilitation Engineering, IEEE
Transactions on [see also IEEE Trans. on Rehabilita-
tion Engineering], 10(1):1–10.
Chen, Y., Su, C., Chen, J., Chen, C., Hung, Y., and Fuh, C.
(2001). Video-based eye tracking for autostereoscopic
displays. Optical Engineering, 40:2726.
Cheung, S. S. and Kamath, C. (2004). Robust techniques
for background subtraction in urban traffic video. Pro-
ceedings of Video Communications and Image Pro-
cessing, 5308:881–892.
Crowley, J. L. (1997). Vision for man machine interaction.
Robotics and Autonomous Systems, 19(3-4):347–359.
Crowley, J. L., Coutaz, J., and Brard, F. (2000). Things that
see: Machine perception for human computer interac-
tion. ICommunications of the A.C.M., 43(3):55–64.
De Decker, B., Mertens, T., and Bekaert, P. (2007). In-
teractive collision detection for free-viewpoint video.
In GRAPP 2007: Proceedings of the Second Interna-
tional Conference on Computer Graphics Theory and
Applications, pages 114–120.
GRAPP 2008 - International Conference on Computer Graphics Theory and Applications
448
Dubois, E. and Sabri, S. (1984). Noise Reduction in Im-
age Sequences Using Motion-Compensated Tempo-
ral Filtering. Communications, IEEE Transactions on
[legacy, pre-1988], 32(7):826–831.
Erol, A., Bebis, G., Boyle, R. D., and Nicolescu, M.
(2005). Visual hull construction using adaptive sam-
pling. In WACV-MOTION ’05: Proceedings of the
Seventh IEEE Workshops on Application of Computer
Vision (WACV/MOTION’05) - Volume 1, pages 234–
241, Washington, DC, USA. IEEE Computer Society.
Eyetoy Sony (2003). http://www.eyetoy.com.
Freeman, W. T., Anderson, D. B., Beardsley, P. A., Dodge,
C. N., Roth, M., Weissman, C. D., Yerazunis, W. S.,
Kage, H., Kyuma, K., Miyake, Y., and Tanaka, K.
(1998). Computer vision for interactive computer
graphics. IEEE Comput. Graph. Appl., 18(3):42–53.
Freeman, W. T., Tanaka, K., Ohta, J., and Kyuma, K.
(1996). Computer vision for computer games. In FG
’96: Proceedings of the 2nd International Conference
on Automatic Face and Gesture Recognition (FG ’96),
page 100, Washington, DC, USA. IEEE Computer So-
ciety.
Gonzalez, R. C. and Woods, R. E. (1992). Digital Im-
age Processing. Addison-Wesley Longman Publish-
ing Co., Inc., Boston, MA, USA.
Gorodnichy, D., Malik, S., and Roth, G. (2002). Nouse Use
your nose as a mouse-a new technology for hands-free
games and interfaces. Proceedings of International
Conference on Vision Interface (VI2002), pages 354–
361.
Guitar Hero Sony (2005). http://www.guitarherogame.com.
Isard, M. and Blake, A. (1998). Condensation – conditional
density propagation for visual tracking. International
Journal of Computer Vision, 29(1):5–28.
Jaume, A., Varona, J., Gonzalez, M., Mas, R., and Perales,
F. J. (2006). Automatic human body modeling for
vision-based moion capture. WSCG.
Kalman, R. (1960). A new approach to linear filtering
and prediction problems. Transactions of the ASME–
Journal of Basic Engineering, 82(Series D):35–45.
Konami (1981). http://www.konami.com.
Kyuma, K., Lange, E., Ohta, J., Hermanns, A., Banish, B.,
and Oita, M. (1994). Artificial retinas-fast, versatile
image processors. Nature, 372(6502):197–198.
Laurentini, A. (1994). The visual hull concept for
silhouette-based image understanding. IEEE Trans.
Pattern Anal. Mach. Intell., 16(2):150–162.
Li, P., Zhang, T., and Pece, A. (2003). Visual contour track-
ing based on particle filters. Image Vision Comput.,
21(1):111–123.
Magnor, M. A. (2005). Video-Based Rendering. AK Peters
Ltd.
Martin, W. and Aggarwal, J. K. (1983). Volumetric descrip-
tions of objects from multiple views. IEEE Transac-
tions on Pattern Analysis and Machine Intelligence,
5(2):150–158.
McIvor, A. M. (2000). Background subtraction techniques.
Metaxas, D. and Terzopoulos, D. (1993). Shape and non-
rigid motion estimation through physics-based syn-
thesis. IEEE Trans. Pattern Anal. Mach. Intell.,
15(6):580–591.
Mishima, Y. (1993). Soft edge chroma-key generation
based upon hexoctahedral color space. U.S. Patent
5,355,174.
M¨uhlmann, K., Maier, D., Hesser, J., and M¨anner, R.
(2002). Calculating dense disparity maps from color
stereo images, an efficient implementation. Int. J.
Comput. Vision, 47(1-3):79–88.
Nintendo Gameboy (1998). http://www.gameboy.com.
Nintendo Wii (2006). http://wii.com.
Open Dynamics Engine (2001). http://www.ode.org/.
Parent, R. (2001). Computer animation: algorithms and
techniques. Morgan Kaufmann Publishers Inc., San
Francisco, CA, USA.
Point Grey Research (2007). http://www.ptgrey.com.
Rubio, J. M. B., L´opez, F. J. P., Hidalgo, M. G., and Varona,
X. (2006). Upper body tracking for interactive appli-
cations. AMDO.
Scharstein, D. and Szeliski, R. (2002). A taxonomy and
evaluation of dense two-frame stereo correspondence
algorithms. Int. J. Comput. Vision, 47(1-3):7–42.
Sega Saturn (1994). http://www.sega.com.
Singstar Sony (2004). http://www.singstargame.com.
Smith, A. R. and Blinn, J. F. (1996). Blue screen matting. In
SIGGRAPH ’96: Proceedings of the 23rd annual con-
ference on Computer graphics and interactive tech-
niques, pages 259–268, New York, NY, USA. ACM
Press.
Spacek, L. A. (1986). Edge detection and motion detection.
Image Vision Computing, 4(1):43–56.
Vezhnevets, V., Sazonov, V., and Andreeva, A. (2003). A
survey on pixel-based skin color detection techniques.
Graphics and Media Laboratory, Faculty of Compu-
tational Mathematics and Cybernetics, Moscow State
University, Moscow, Russia.
Welman, C. (1993). Inverse kinematics and geometric con-
straints for articulated figure manipulation. Master’s
thesis, B.Sc. Simon Fraser University.
Willey, M. (1997). Design and implementation of a stroke
interface library.
Woetzel, J. and Koch, R. (2004). Real-time multi-stereo
depth estimation on gpu with approximative disconti-
nuity. 1st European Conference on Visual Media Pro-
duction (CVMP 2004), pages 245–254.
Wren, C. R., Azarbayejani, A., Darrell, T., and Pentland,
A. P. (1997). Pfinder: Real-time tracking of the hu-
man body. IEEE Trans. Pattern Anal. Mach. Intell.,
19(7):780–785.
Yang, R. and Pollefeys, M. (2003). Multi-resolution real-
time stereo on commodity graphics hardware. cvpr,
01:211.
A MULTI-CAMERA FRAMEWORK FOR INTERACTIVE VIDEO GAMES
449
