AN ANALYSIS OF RELATIONAL STORAGE STRATEGIES FOR

PARTIALLY STRUCTURED XML

Yasser Abdel Kader

, Barry Eaglestone

and Siobhán North

Department of Computer Science

Department of Information Studies

University of Sheffield, Sheffield, U.K.

Keywords: XML databases, structure mapping, performance analysis.

Abstract: This paper presents a performance analysis of strategies for storing XML data sets in relational databases,

focusing on XML datasets that are a combination of structured and semi-structured data. The analysis

demonstrates advantages of a hybrid approach combining structure mapping and XML data type instances.

However problems remain with current technology with regards to scaling of the approach for large data

sets. Also, anomalous results are identified and a threshold at which the cost of data shredding out weighs

the advantages of structure mapping.

1 INTRODUCTION

The research reported is an exploration of

performance implications of approaches to utilizing

SQL/XML (ISO/IEC, 2006), focusing on datasets

that comprise both structured and semi-structured

data. Compromises between database complexity

and increased size which are a consequence of

structure mapping, and structural simplicity and

compactness achieved by storing data as instances of

XML types were investigated. Results show a hybrid

approach that combines both to be advantageous, but

reveal performance anomalies, problems of scaling,

and thresholds at which cost of data shredding

outweigh advantages of structure mapping.

2 EXPERIMENTAL DESIGN

Our hypothesis was - For the class of partially-

structured XML documents, i.e. containing both a

prescribed structured part and a semi-structured part,

performance enhancement may be achieved over

existing query processing techniques for semi-

structured data by using relational database query

processing and optimisation to exploit pre-

knowledge of the prescribed structured part.

Accordingly, experiments analyzed performance of

a hybrid strorage model which, respectively,

represents structured and semi-structured data using

structure mapping and XML data types. Structure

mapping (Shanmugasundaram et al, 1999;

Yoshikawa & Amagasa, 2001; Balmin &

Papakonstantinou, 2005; Pal et al, 2006) represents

an XML document as a relational table. Other tables

represent its nested tagged elements. Lowest-level

tagged elements are stored as attributes. This suits

highly structured document collections that conform

to a limited number of document structures which

are static over time (Lu et al, 2005; Yoshikawa &

Amagasa, 2001).

We implmented structure mapping manually, in

lieu of effective algorithms for stucture mapping

partially-structured data. Also, a manual approach

better suits partially-structured XML data by giving

designers flexibility to apply structure mapping only

for data deemed to be sufficiently well structured.

This is not true of alternative approaches, i.e., data

mining to extract structure from XML documents

(Deutsch, Fernandez & Suciu, 1999), and DTD or

XML Schema analysis techniques (Lv & Yan, 2006;

Penna et al, 2006), such as inlining

(Shanmugasundaram et al, 1999; Lu et al, 2003;

Atay et al, 2007). In our manual structure mapping,

in addition to devising a relational representation of

the hierarchical organization of the structured

component of the data, we ensured optimal querying

of this part by creating sufficient indices.

We used XML data types (Krishnaprasad et al,

2005; Murthy et al, 2005; Rys, 2005; Pal et al, 2005,

2006; Ozcan et al, 2006; ISO/IEC, 2003, 2006;

165

Abdel Kader Y., Eaglestone B. and North S. (2008).

AN ANALYSIS OF RELATIONAL STORAGE STRATEGIES FOR PARTIALLY STRUCTURED XML.

In Proceedings of the Fourth International Conference on Web Information Systems and Technologies, pages 165-170

DOI: 10.5220/0001525601650170

 SciTePress

Eisenberg & Melton, 2004) within our hybrid model

to represent the semi-structured part because

structural irregularities can cause structure mapping

to generate large complex schemas, and schema

inflexibility becomes problematic for structurally

volatile XML data. Other problems avoided by using

XML data types are the need to resolve naming and

type ambiguities and contentions, and, more

generally, XML structural directives, such as Or

(‘|’), cannot be mapped naturally into the relational

model (Yoshikawa & Amagasa, 2001). XML data

types support flexible querying of semi-structured

data through path-based and regular expression-

based querying facilities supported by SQL/XML.

Also, in practice XML database designers will

mainly utilize XML types within relational

databases for storing XML data sets, given the

current immaturity and relatively poor performance

of native XML database systems (Lu et al, 2003,

Grust at al, 2007).

2.1 Experiment Setup

Experiments were run on a single machine

environment: Intel ® Pentium ® CoreTM Duo

processor T2250, 1.73 Ghz; 1536 MB Ram; 120 GB

Hard Disk Drive; Microsoft Windows XP

Professional 5.1.2600 service pack 2; Microsoft

SQL Server 2005. Transact-SQL was used as the

main language to access the SQL Server. The

decision to use MS XML Server was pragmatic. It

was available, widely used internationally, and is a

representative example of SQL/XML technology.

SQL Server 2005 implements features of

SQL/XML, including XML data types, indexing,

full-text XML search, as well as XQuery and XPath.

XML data can be stored as instances of un-typed or

typed XML data fields (MS SQL Server, 2005; Pal

et al, 2005, 2006; Rys, 2005; Lacoude, 2006). Using

un-typed XML data types, there is no XML schema,

so SQL Server only checks that XML data is well

formed. Instances of a typed XML data type must

conform to an XML schema, which is used to

validate the data, perform type checks, and optimize

storage and query processing. Results, not discussed

here, showed a poor performance for un-typed XML

representations. Therefore results presented here

cover only experiments using typed XML data

fields.

2.2 XML Data Set

The dataset used in the experiments was the Digital

Bibliography & Library Project (DBLP) (http://

dblp.uni-trier.de/xml/), which comprises computer

science-related bibliographic information. This

XML document references over 750,000

publications by 450,000 authors, stored in 335

Megabyte, as of September 2006 (Reuther et al,

2006; Ley & Reuther, 2006). Publications are

mainly conference papers (60%) and journal articles

(37%). This dataset is wide use in XML database

research, thus allowing comparability of results.

Also, the data conforms to a DTD from which it was

possible to derive structure for all or part of the

dataset, allowing flexible interpretations of the

document to simulate varying ratios of semi-

structured to highly-structured content. The use of

“natural”, rather than synthesized data sets, adds to

the validity of the study, but a limitation is our

inability to vary the inherent structured-ness of the

data set itself. This requires multiple data sets,

possibly synthesized, which we advocate as further

work.

2.3 Benchmark

The XBench benchmark (Yao, Ozsu &

Keenleysidem, 2004) was used because of its

comprehensive range of use cases for XQuery, and

flexibility to deal with multiple XML scenarios,

including data- and text-centric, single and multiple

documents. This contrasts with single scenario

benchmarks, such as TPC-C, TPC-H, TPC-R, TPC-

W (Transaction Processing Performance Council

(http://www.tpc.org)), Wisconsin benchmark

(DeWitt, 1993), and XML application benchmarks,

such as XMach-1 (Bohme & Rahm, 2002), XMark

(Schmidt et al, 2002), X007 (Brassan et al, 2002),

XPathMark (Franceschet, M. 2005) and TPoz

(Nicola et al, 2007). We also rejected micro

benchmarks, such as Michigan Benchmark

(Runapongsa et al, 2006) and MemBer (Afanasiev et

al, 2005), since they evaluate at too small a level of

query granularity. The XBench query sets, as

adapted for the DBLP data set, are listed in table 1.

2.4 Storage Strategies

The hybrid storage model and its two base models,

i.e. structure mapping (S/M) and XML data types

(XML), were evaluated. Five implementations of the

hybrid model were created to evaluate the impact of

varying the ratio of semi-structured to structured

data with respect to two dimensions. The vertical

dimension, so called because of the conventional

tabular representation of data, is the ratio of semi-

structured to structured components of the schema.

WEBIST 2008 - International Conference on Web Information Systems and Technologies

166

The horizontal dimension is the ratio of semi-

structured to structured data instances. The vertical

dimension was varied in the first (D), second (DA)

and third (DT) implementations, respectively, by

structure mapping document key, document key and

author(s), and document key and title. In the other

implementations (60%X and 37%X), approximately

60% and 37% of data elements were represented as

typed XML data fields and the rest represented using

structure mapping, thus varying the horizontal ratios.

Experiments were conducted on different sized

databases by selectively removing content: the

whole DBLP data set (DB3/3); two-third of the data

set (one third of in-proceedings references and

article references deleted) (DB2/3); and one third of

the data set (two third of the in-proceedings and

articles referenced deleted) (DB1/3).

2.5 Performance Metrics

Performance was measured in milliseconds, in terms

of execution time, CPU busy time and IO busy time.

Also, the number of IO reads and writes were

recorded for each query. To establish stability, each

query was run 20 times and performance was

computed as the average (excluding maximum and

minimum execution times). Standard deviations

were calculated for each query and storage model, to

identify any instability.

3 EXPERIMENT RESULTS AND

ANALYSIS

Table 1 presents a ranking of the storage strategies

for each category of query in the benchmark when

executed with the largest of our datasets (DB3/3)

(see (Abdel Kader, 2007) for full details). Though

far from exhaustive, these suggest interesting

relative characteristics of the storage strategies.

None performed well for all query groups. For

example, though D performed well accessing via the

document key (Qs 1,9,12-16,19), it was relatively

poor for querying author names (Qs 2-7,10-11). In

the latter group, the DA model performed best,

possibly demonstrating relative efficiency of

querying conventional atomic attributes via indices,

in contrast to using typed XML instances. However,

relatively poor performance of S/M across these

twenty queries illustrates advantages in storing data

not directly utilized as query keywords as typed

XML instances, i.e. the hybrid approach. Examples

of the superiority of the hybrid model over pure

structure mapping include quantification (Q6-7) and

retrieval of individual documents (Q16). This is

probably due to the fact that the hybrid model

reduces data shreding, thus reducing the overhead of

multiple join operations to re-assemble a document.

However, as a counter example, though three of the

queries in which article titles are queried (Qs 8,17)

performed well with DT, this was not the case for

the fourth (Q20), in which the length of the title is

tested, where best performance was achieved using

S/M. Also, storing the whole XML data as a typed

XML instance (XML) always produced poorer

performance than strategies which dividing data into

smaller XML elements. In a number of queries, the

XML model showed good performance, but in these

cases so did the other hybrid models (e.g.,

quantification (Q6-7) and text search (Q17)).

Thus, messages are mixed. However, if we

consider performance of specific strategies the

results give a clearer view.

Pure Structure Mapping (S/M). In most instances

this produced poor performance relative to hybrid

approaches. Exceptions were Q2, Q8, Q18 and Q20.

This was unexpected, since the BDLP dataset is

relatively well structured and therefore well suited to

structure mapping. Experiments with different

dataset sizes demonstrated near linear deterioration

in query time as size increased, with average

deterioration of 59% to 125% respectively, as size

doubled and tripled. This representation seems

particularly ill-suited for irregular data (Q14), with a

possibly exponential deteriorated from 300% to

1053% as size doubles and triples. Thus, dataset size

and application characteristics are important

considerations when contemplating this strategy.

Pure Use of Typed XML Data Types (XML). As

with pure structure mapping, this approach produced

poor performance relative to the hybrid approaches.

Exceptions are Q7 (universal quantification) and

Q20 (datatype casting). However, performance was

poor for all conventional relational-style retrievals

involving selection, projection and join.

Deterioration in query performance was more

extreme than for S/M. On average, deterioration was

respectively 121% and 345% as the dataset size

doubles and triples. The worst case was for the path

expression query, Q8, where deterioration was from

700% to 1264%. Thus, average performance was

poor and deterioration as size increases is worse than

linear, suggesting viability only for small data sets.

AN ANALYSIS OF RELATIONAL STORAGE STRATEGIES FOR PARTIALLY STRUCTURED XML

167

Table 1: Summary of all the relative performance results ranging from 1 (best) to 6 (worst).

Hybrid

Query

Category

Query

S/M XML

37%X 60%X D DA DT

Q1: Return titles of article with key value X. 4 5 1 3 2 - -

Exact match

Q2: Return titles of articles authored by X. 2 6 3 4 5 1 -

Function

application

Q3: Count articles authored by author X 5 6 3 2 4 1 -

Q4: Return titles of articles by author X., retaining

their relative ordering in the BDPL data set.

6 5 4 2 3 1 -

Ordered

access

Q5: Return title of first article authored by X,

listed within the BDPL data set.

5 6 2 2 4 1 -

Q6: Return titles of articles authored either by

author X and/or author Y

6 5 2 4 3 1 -

Quantificatio

Q7: Return titles of articles by both author X and

author Y

6 2 5 4 3 1 -

Q8: Return article titles containing “XYZ” 1 5 3 4 6 - 2

Path

expressions

Q9: Return authors of articles that have a key

value X. (The symbol ‘//’ to select subpaths in the

document that match address an article key.)

4 5 1 3 2 - -

Q10: List the title, publication date and authors of

all articles, sorted by title for specific authors.

5 6 3 4 2 1 -

Sorting

Q11: List the title, publication date and authors of

all articles, sorted by publication date for specific

author.

5 6 3 4 2 1 -

Q12: List title, publication date and authors for a

specific article, preserving original document

structure.

4 5 2 3 1 - -

Document

construction

structure

Q13: List title, publication date and authors for a

specific article, transforming document structure.

4 5 2 3 1 - -

Q14: List the title, publication date and authors of

all articles in which the ‘ee’ element is missing.

4 5 3 2 1 - -

Irregular data

Q15: List title, publication date and authors of

articles in which the ‘year’ element has a specific

value.

5 4 3 2 1 - -

Retrieval of

individual

documents

Q16: Retrieve article data that has key value X,

keeping its original structure.

5 4 2 3 1 - -

Q17: Search for the word XYZ in any field in the

article data.

5 4 2 3 6 - 1

Text search

Q18: Search for the phrase XX YY ZZ in any

field in the article data.

2 5 3 4 6 - 1

References

and Joins

Q19: Retrieve the first author of the article with

key value X, and use the author’s name to return

the tiles of all of their publication.

4 5 2 3 1 - -

Datatype

casting

Q20: Returns the titles of articles, where the word

count is longer than a specific size.

1 2 5 6 4 - 3

Vertical Hybrid Approaches (D, DA, DT). Part of

the XML schema common to all repeating instances

is structure mapped and the rest is represented as

typed XML instances. As expected, this

outperformed the two pure base approaches where

query keywords were within the structure mapped

part. However, this superiority was surprising for

text searches (Q17 and 18) where all fields were

accessed. Also, we anticipated performance would

continue to improve as the ratio of structured to

semi-structured data increased, since conventional

relation querying was likely to outperform the added

XML facilities. Given that the BDLP dataset is

mainly well structured, if this was true, the best

WEBIST 2008 - International Conference on Web Information Systems and Technologies

168

performances would be for S/M. This was not the

case, since there seems to be a threshold beyond

which performance deteriorated. Mainly, query

performance deterioration with increase in dataset

size was near linear. For D, DA and DT deterioration

was respectively from 355% to 769%, 25% to 63%,

and 2801% to 4269% as size doubled and tripled.

DA’s worst deterioration was for quantification

(Q6), where increase in query time was from 126%

to 290%, as the size doubled and tripled. DT

deteriorated most for data type casting (Q20), from

10509% to 15880% as size doubled and tripled. D

has two step changes with respect to query

performance. Theses were also for data type casting

(Q20), with a deterioration of 2204% when the size

doubled, and for text searching (Q17), where there

was a 3969% deterioration when size tripled. Thus,

though our hypothesis is largely born out by the

results, there are other factors which any decision

model must take into account, including overheads

incurred by data shredding, and the impact of dataset

size.

Horizontal Hybrid Approaches (37%X, 60%X).

Some types of repeating instances are structure

mapped while others are stored as typed XML

instances. This produces mainly a middle ranking

performance. Neither 37%X nor 60%X consistently

outperforms the other, but, respectively, in 90% and

75% of cases both outperformed S/M and XML.

Thus, there seems to be an advantage in horizontally

partitioning data into structured and semi-structured

representation, as well as more obvious benefits of

the vertical approach. There is also a worrying

possibly exponential deterioration, as dataset size

increased. Both 37%X and 60%X exhibited similar

average deterioration, from 27% to 395% and from

29% to 445%, as size doubled and tripled. However,

for the path expression query, Q8, deterioration in

performance was from 166% to 2205%. Thus, this

approach mainly improves on pure structure

mapping (S/M), but does not appear to scale to very

large datasets.

Finally, we note that the above results

complement recent and more specific analyses of

performance advantages of using “off-the-shelf”

relational technology to store and query XML data

sets. (Torsten et al, 2007) and (Gou &Chirkova,

2007) respectively analyse XPath processing and the

related more general problem of twig pattern

matching. As in our study, both explore the use of

native relational facilities with XML datasets.

Torsten et al describe and evaluate partitioned B-

trees for non-recursive XPath axis evaluation;

aggregation functions for pruning in tree join

algorithms; and the effectiveness of relational query

optimisation rewrite techniques for tree structured

data. Gou and Chirkova survey relational and native

XML techniques, concluding that a good trade-off

can be achieved with a relational inverted list

representation of XML data, complemented by

efficient XML native join algorithms. Thus, their

studies consider techniques that may be deployed

within an XML type to improve querying

performance. Consequently, we anticipate that the

trade-offs we have explored between structure

mapping and XML type instances will evolve

dynamically with improvements in the

relational/XML technology.

4 CONCLUSIONS

This paper has presented a performance analysis of

relational storage strategies for partially-structured

data. The hybrid approach, combining structure

mapping and XML data types, was show to have

query performance advantages over pure structure

mapping and sole use of XML data types. However,

results are inconclusive, since they identify a

anomalies, problems of scaling, and the existence of

thresholds where cost of data shredding appears to

outweigh advantages of utilizing relation query

processing. Each of these is a motivation for further

research. Also, the experiments described are

limited, as has been discussed in the body of this

paper, and further experimental work is needed.

Our contribution is an analysis of relative

performances within a specific configuration, rather

than across systems, as in other performance studies.

Also, we are not aware of other studies of partially-

structured data and the impact of the horizontal and

vertical dimensions of data structure-ness

Results presented here are part of a more

intensive investigation (Abdel Kader, 2007). In

particular, results have enabled us to devise a

heuristics-based model to inform XML/relational

design which we plan to validate and elaborate as

further research.

REFERENCES

Abdel Kader, Y. 2007. A Performance Analysis of a

Hybrid Relational-Xml Approach to store Partially-

Structured Data. PhD Thesis, University of Sheffield.

AN ANALYSIS OF RELATIONAL STORAGE STRATEGIES FOR PARTIALLY STRUCTURED XML

169

Afanasiev, L. Manolescu, I., Michiels, P. 2005. MemBer:

A Micro-benchmark Repository for XQuery. XML

Symposium (XSym).

Atay, M., et al. 2007. Efficient schema-based XML-to-

Relational data mapping. Information Systems 32(3),

pp.458- 476.

Balmin, A., Papakonstantinou, Y 2005. Storing and

Querying XML data using denormalized relational

databases The VLDB Journal, 14, pp.30-49.

Böhme, T., Rahm, E. 2002. Multi-user Evaluation of XML

Data Management Systems with XMach-1. Efficiency

and Effectiveness of XML Tools, and Techniques

EEXTT, pp.148-158.

Brassan, S., et al. 2002. The XOO7 benchmark. In

Proceedings of VLDB’02 Workshop Efficiency and

Effectiveness of XML Tools, and Techniques EEXTT,

LNCS 2590, pp.146-147.

Deutsch, A., Fernandez, M., Suciu, D. 1999. Storing

semistructured data with STORED. In Proceedings of

the 25th ACM SIGMOD International Conference on

Management of Data.

DeWitt, D. 1993. The Wisconsin Benchmark: Past,

Present, and Future. The Benchmark Handbook for

Database and Transaction Systems (2nd Edition).

Morgan Kaufmann, ISBN 1-55860-292-5.

Eisenberg, A., Melton, J. 2004. Advancements in

SQL/XML. SIGMOD Record 33(3), pp.79-86.

Franceschet, M. 2005. XPathMark – An XPath benchmark

for XMark Generated Data. International XML

Database Symposium (XSYM), pp. 129-143.

Gou, G., Chirkova, R. 2007. Efficiently Querying Large

XML Data Repositories: A Survey. IEE Transactions

on Knowledge and Data Engineering. 19(10), October,

2007, pp.1381-1403.

Krishnaprasad, et al. 2005. Towards an Industrial Strength

SQL/XML Infrastructure. Proceedings of the 21st

International Conference on Data Engineering, ICDE

2005. Tokyo, Japan, pp.991-1000.

Lacoude, P. 2006. Pushing SQL Server 2005 Limits,

Dealing with Oversized XML Documents [online]

Available from: http://www.lacoude.com/Docs/public

/public.aspx?doc=SQL90XML.PDF[Accessed 17.10.2007]

Ley, M., Reuther, P. 2006. Maintaining an Online

Bibliographical Database: The Problem of Data

Quality. EGC 2006, Lille, France, pp.5-10.

Lu, H. et al., et al. 2005. What Makes the Differences:

Benchmarking XML Database Implementations. ACM

Transactions on Internet Technology (ACM TOIT), 5

(1), pp.154-194.

Lu, S., et al. 2003. A new inlining algorithm for mapping

XML DTDs to relational schemas. In Proceedings of

the 1st International Workshop on XML Schema and

Data Management. LNCS, Chicago, Illinois, USA.

Lv, T., Yan, P. 2006. Mapping DTDs to relational

schemas with semantic constraints. Information and

Software Technology, Volume 48 (4), pp. 245-252

Murthy, R. et al. 2005. Towards an enterprise XML

architecture. In Proceedings of the 2005 ACM

SIGMOD international Conference on Management of

Data, Baltimore, Maryland, pp.14-16.

Nicola, M., Kogan, I., Schiefer, B. 2007. An XML

Transaction Processing Benchmark. SIGMOD,

Beijing, China.

Özcan, F., et al. 2006. Integration of SQL and XQuery in

IBM DB2. IBM System Journal. 45 (2), pp.245-270.

Pal, S. et al. 2005. XQuery implementation in a relational

database system. In Proceedings of the 31st

international Conference on Very Large Data Bases.

Trondheim, Norway, pp. 1175-1186.

Pal, S., Tomic, D., Berg, B., Xavier, J. 2006. Managing

Collections of XML Schemas in Microsoft SQL

Server 2005. EDBT 2006, pp. 1102-1105.

Penna, G. et al. 2006. Interoperability mapping from XML

schemas to ER diagrams. Data & Knowledge

Engineering, 59 (1), pp.166-188.

Reuther, P. et al. 2006. Managing the Quality of Person

Names in DBLP. Research and Advanced Technology

for Digital Libraries, 10th European Conference,

ECDL 2006, Alicante, Spain, pp.508-511.

Runapongsa, K. et al. 2006. The Michigan benchmark:

towards XML query performance diagnostics.

Information Systems 31(2), pp.73-97.

Rys, M. 2005. XML and relational database management

systems: inside Microsoft® SQL Server™ 2005. In

Proceedings of the 2005 ACM SIGMOD International

Conference on Management of Data, Baltimore,

Maryland, pp.14-16.

Schmidt, A., et al. 2002. XMark: A benchmark for XML

data management. In Proceedings of the 28th

International Conference on VLDB. Hong Kong,

China, pp.974-985.

Shanmugasundaram et al. 1999. Relational Databases for

Querying XML Documents: Limitations and

Opportunities. Proceeding of the 25th VLDB

Conference, Edinburgh, Scotland.

MS SQL Server 2005 [online] Available from: http://

www.microsoft.com/sql/default.mspx [Accessed

17.10.2007].

SQL:2006. International Organization for Standardization

(ISO). Information Technology-Database Language

SQL. Standard No. ISO/IEC 9075-14:2006. Part 14:

XML-Related Specifications (SQL/XML) (Available

from American National Standards Institute, New

York, NY 10036)

XQuery 1.0 and XPath 2.0 Data Model (XDM) W3C

Candidate Recommendation 11 July 2006 [online].

Available from: http://www.w3.org/TR/xpath-datamodel/

[Accessed 07.11.2006]

Yao, B., Özsu, M. and Keenleysidem J. 2004. XBench

Benchmark and Performance Testing of XML

DBMSs. In Proceedings of 20th International

Conference on Data Engineering, Boston, MA, United

States of America, pp.621-632.

Yoshikawa, M. and Amagasa, T. 2001. Xrel: A Path-

Based Approach to Storage and Retrieval of XML

Documents Using Relational Databases. ACM

Transaction on Internet Technology 1 (1), pp.110-141.

WEBIST 2008 - International Conference on Web Information Systems and Technologies

170
