Deise de Brum Saccol, Rodrigo Perozzo Noll, Nina Edelweiss and Renata de Matos Galante
Instituto de Informática, Universidade Federal do Rio Grande do Sul,
Bento Gonçalves 9500, Porto Alegre, Brazil
Keywords: Ontology, peer-to-peer, schema matching, similarity.
Abstract: In peer-to-peer (P2P) systems, files from the same application domain are spread over the network. When
the user poses a query, the processing relies mainly on the flooding technique, which is quite inefficient for
optimization purposes. To solve this issue, our work proposes to cluster documents from the same
application domain into super peers. Thus, files related to the same universe of discourse are grouped and
the query processing is restricted to a subset of the network. The clustering task involves: ontology
generation, document and ontology matching, and metadata management. In this paper, we focus on the
matching step.
P2P refers to a class of application systems that use
distributed resources to perform tasks in a
decentralized context
. The usability of such
systems is mainly dependent on techniques used to
find and retrieve results. However, the searching
optimization faces two problems: how to find
relevant files for the user query with a low cost, and
how to deal with the poor semantics of the
Files that belong to the same application domain
and that are needed for answering a specific query
may be stored in several peers. The use of the
flooding technique would be necessary in order to
access all the relevant files. But this technique is
expensive and time-consuming, since all the peers
get the query message and usually only some of
them are able to answer it. Another attempt for
balancing cost is to use any flooding variation
technique, such as breadth-first traversal (over the
network with depth limit D measured in hops) or
depth-first traversal with depth limit D (Yang,
2002). However, their use does not guarantee the
optimal results, since not all the peers get the
Gnutella. Available at
Kazza. Available at
eMule. Available at
requesting message.
Related to the semantics, let us consider two
applications that need to exchange data. One
possible approach is to build an adapter that
transforms data and structure between them.
However, the adapter construction is a hard task that
requires knowing the data organization in both
applications. Furthermore, the complexity and the
developing time tend to be quadratic in relation to
the number of component applications (Staab,
2004). A possible solution should use some kind of
metadata for describing the semantics of the
underlying repositories. But this scenario states two
critical questions (Mena, 2001): (i) how to deal with
different concepts used to describe the same
information; and (ii), how to acquire and maintain
the necessary metadata to solve the vocabulary
sharing issue.
To overcome these problems we propose an
ontology-based approach that can be used for
improving traditional searching techniques in P2P
systems. We focus on two important issues: (i) the
extra traffic produced by traditional flooding
techniques when the optimal results are required;
and (ii) the lack of semantics regarding the
information storage and searching. In order to avoid
such unnecessary traffic caused by the flooding
solution, our approach relies on file clustering into
super peers, based on the application domain of the
peer files. The file grouping criteria is based on the
de Brum Saccol D., Perozzo Noll R., Edelweiss N. and de Matos Galante R. (2008).
In Proceedings of the Tenth International Conference on Enterprise Information Systems - DISI, pages 310-316
DOI: 10.5220/0001711503100316
similarity analysis between the files and the domain.
In order to increase the semantics, we adopt an
ontology for describing the document concepts.
The main contributions of this paper are:
- The specification of the ontology manager, a
component used for allowing semantic
interoperability in P2P systems;
- The definition/implementation of a mechanism for
file and ontology matching, based on lexical and
semantic similarity between concepts.
The functionalities of this mechanism are
performed by the ontology manager, as part of
DetVX (Saccol, 2007), as following described.
The proposed framework (Detector of Replicas and
Versions of XML Documents) stores files according
to the super peer architecture. Files stored in peers
are related to a specific application domain,
described by an ontology (e.g., curriculum or
research projects domain). We use the ontology as
peer grouping criterion into super peers. The
ontologies are automatically generated (from the
schema integration process). All the peers belonging
to the same domain are clustered in the same super
peer. Since one domain is represented in only one
super peer, two files belonging to the same domain
cannot be found in different super peers. With this
assumption, a certain query related to a domain will
be forwarded only within a specific super peer
network, reducing unnecessary network traffic.
2.1 Ontology Manager
The ontology manager is responsible for maintaining the
ontology repository and for associating ontologies to
super peers. In this proposal, ontologies are represented
in OWL
format. The activities are presented in Figure 1
and are described as follows:
Figure 1: UML activity diagram for the ontology manager.
Web Ontology Language (OWL). Available at
- Show available ontologies – this activity returns a
short description of existent ontologies stored in
the repository. The user can choose an ontology to
be used for a (set of) document (s) belonging to
this domain (i.e., select a super peer to connect).
- Match the file to a proper ontology – for
document and ontology matching, our work
assumes one of the following approaches:
o There is a compatible ontology for the
document – thus, the peer that stores the file is
connected to the super peer described by this
ontology. To figure out which ontology best
describes a certain file, our proposal relies on
using similarity techniques between the file and
the ontologies. The ontology that presents the
higher similarity is chosen to represent the file
domain, as described in Section 3.
o There is not a compatible ontology for the
document – thus, we create a new ontology
(generate ontology activity) that represents the
concepts and relationships of this domain.
- Generate ontology - The ontology is created from
the schema integration process. The integration
activity uses a thesaurus for helping to infer
terminological relationships in order to match
equivalent concepts. The full description of this
task is presented in (Saccol, 2008).
- Update ontology repository – this activity is
responsible for storing the created ontology into
the ontology repository.
- Associate the ontology to a super peer – this
activity is responsible for associating the new
ontology to an existent super peer. Some
administrative metadata also need to be
Load balancing must be considered when choosing a
super peer to associate to an ontology. In our work,
load balancing is performed based on the number of
peers in super peers. The goal is to keep the same
number of peers in each super peer. The mean
number (A) of peers (p) in each super peer is defined
as: A(p)=(number of peers)/(number of super
peers)+range. The range value allows some
flexibility in terms of number of peers before
performing load balancing. The load balancing must
agree with the grouping criteria (belong to the same
ontology). Thus, the load balancing regrouping may
imply on associating ontologies to other super peers.
- Update metadata – this activity updates the
In this paper, we focus on file and ontology
The matching task aims to define the ontology that
best describes a XML file, by measuring the overall
similarity between both representations. Given a
XML file d and a set of n ontologies
}, the procedure computes the
similarity score sim(d,O). The ontology o
with the highest score (greater than a threshold t) is
chosen to represent the corresponding file domain
The strategy aims to find resemblances between
classes. Two questions must be answered: ‘which
pairs of classes will be compared’ and ‘what are the
criteria to determine how similar the classes are’.
Several approaches address similarity analysis
(Madhavan, 2001), (Maedche, 2002). These
approaches are usually based on three main steps:
- Normalization: determines which elements are
semantically equivalent;
- Categorization: separates the elements into
classes, in order to reduce the number of
- Comparison: defines the similarity score
computed among the elements in their categories.
To evaluate the similarity between files, two types of
perspectives are considered: the lexical perspective
evaluates the relations between terms by comparing
the strings, while the semantic perspective focuses
on the meaning and conceptual correlation among
terms. For the similarity analysis, we consider both
types, as follow described:
- Lexical Similarity Analysis: two main
approaches are used:
o Edit distance functions (Levenshtein, 1966): this
approach analyses the minimum number of
operations to transform one character sequence
into another;
o Stemmer algorithms
: this approach reduces the
character sequence to the stem (i.e., the form of
a word after all affixes are removed).
In our approach, we use a stemmer algorithm for
lexical similarity analysis.
- Semantic Similarity Analysis: two main
approaches are commonly used:
o Thesaurus: used to figure out the terminological
relationships (e.g., WordNet
The Lancaster Stemming Algorithm. Available at
WordNet. Available at
o Taxonomic Overlap procedure (Maedche,
2002): it does not individually analyze the
element, but the element context. For
calculating the similarity degree between two
sets of elements, we use the Jaccard coefficient
(Manning, 1999).
Our mechanism aggregates and extends the
advantages of some existent approaches, as
described in the next section.
3.1 Matching Approach
We use the following process to compute the
similarity score sim(d,o
) between a XML file d and
an ontology o
. The first step corresponds to the
normalization and categorization tasks, as follows.
- Normalization and Categorization Phase: for
each file (XML and OWL), we map all the
component elements, by traversing the document
and storing the stem (key) and a list with the
complete names for each element. If the element
name is composed by n-words, then the list also
consists of each component. This initial mapping
corresponds to the lexical perspective and is
presented in Figure 2.
Key List
skill skillArea skill area
Figure 2: Lexical normalization of XML elements.
The next step considers the element synonyms. The
list of synonyms is retrieved from WordNet. The
resulting list is presented in Figure 3.
Key List
skill skillArea skill area accomplishment acquisition domain
Figure 3: Semantic normalization of XML elements.
The normalization occurs in two steps. First, we
normalize the ontology elements, as above
described. We traverse the XML elements and verify
in their lists the existence of any lexical
correspondence with other elements from the OWL
list. These correspondences are analyzed by looking
only at the stems, using a stemmer. At last, we have
two normalized and categorized lists (XML and
OWL elements). In this phase, the system is able to
identify the existent correspondences between the
XML and OWL elements, providing the initial step
for element comparison.
- Comparison Phase: this step analyzes the
taxonomic overlap. For each element that consists of
a root-leaf set (i.e., a path from the root to the leaf
ICEIS 2008 - International Conference on Enterprise Information Systems
nodes), the system knows the existence of
correspondences in the ontology (obtained during
the normalization task). To get the similarity degree,
we define the union as the total number of XML
elements in the root-leaf set. The intersection is
defined as the number of relations with a
correspondence between the XML and the ontology
elements. By relations, we mean: an OWL class that
relates to an OWL subclass; an OWL class that
relates to Object or Datatype properties; and the
relations between OWL classes.
The taxonomic overlap method traverses the left-
side tree and analyzes only the nodes that have
correspondence with the right-side tree. This
procedure is repeated for all the root-leaf sets. Thus,
we obtain a list with the all the similarity values. The
final value is calculated as the arithmetical mean of
this list.
3.2 Matching Example
Let us consider the XML file presented in Figure 4.
Figure 4: XML document.
Figure 5 presents part of the resume ontology (some
properties are not shown, such as the address
properties - city, state, street and zip). Let us also
suppose the existence of another ontology
representing another domain, e.g., academic
research. We aim to figure out which ontology best
describes the XML document, by measuring the
similarity among the XML file and the ontologies.
Figure 5: The resume ontology.
By following the mechanism previously presented in
Section 3.1, the matching approach produces the
similarity values described in Table 1. By looking at
the last line, we can see that the first ontology
(resume.owl) presents the highest similarity (0.899).
Thus, this ontology is chosen for describing the
XML file domain.
While analyzing the partial similarities, the
mechanism is capable to store information about
mappings between concepts in the XML document
and concepts in the ontology. Basically, for each
term in the ontology the mapping information is
represented as a transforming function. The
transforming functions are represented in XPath
For instance, the concept fullName can be mapped in
different documents, such as name and
firstName+lastName. The mappings are extensively
used in query transformation.
Table 1: Individual (ISim), partial and final similarity
values for the files presented in Figure 4 and Figure 5.
XML (Resume)
(Resume) ISim
Research) ISim
[header, name,
Firstname] 0.667
firstName] 0.333
[header, name,
LastName] 0.667
lastName] 0.333
[header, name] [name] 0.500 [name] 0.500
[header, address,
street] 0.667 [address] 0.333
[header, address,
city] 0.667 [address] 0.333
[header, address,
state] 0.667
Department] 0.667
[header, address,
zip] 0.667 [address, nil] 0.333
[header, address] [address] 0.500 [address] 0.500
[header, contact,
phone] [phone] 0.333 [phone] 0.333
[header, contact,
email] [email] 0.333 [email] 0.333
[header, contact,
url] [url] 0.333 [url] 0.333
[header, contact] [] 0.000 [] 0.000
[header] [] 0.000 [] 0.000
… …
Partial similarity value 0.462 0.333
Final similarity value 0.899 0.433
Some metadata are also maintained, but not
presented in this paper.
Our approach is implemented in a tool named The
Matcher. The tool measures the lexical and semantic
similarity among XML files and ontologies. The
Matcher was implemented using the following APIs:
Paice/Husk stemmer
, for the lexical analysis (word
XML Path Language. Available at
The Lancaster Stemming Algorithm. Available at
<address><street>123 Elm #456</street>
stems); WordNet
, for the semantic analysis
(synonyms); JWNL
, for accessing the WordNet
dictionary; Jena
, for manipulating the OWL files;
and Xerces
, for manipulating the XML files.
We ran some experiments to calculate the
similarity between a curriculum XML file and some
ontologies. The goal is to prove that a file belonging
to a domain D has higher similarity with the
ontology that describes that domain than others. The
input consists of one XML file and six OWL files.
The output is a similarity value for each pair of
representations. The ontologies are related to the
following domains: academic research, amino acids,
wine, pets and owners, travel, and curriculum. The
similarity results are presented as follows.
Academic_research.owl: 0.496 Amino_acid.owl: 0.377
People_pets.owl: 0.448 Resume.owl: 0.899
Travel.owl: 0.382 Wine.owl: 0.39
The similarity values show that the ontology
Resume.owl has the highest similarity with the XML
document used in the experiments (89.9%). Other
ontologies from different domains presented very
low similarities (between 38% and 49%). Thus, the
Resume ontology is chosen for describing the
document. In these experiments, we considered that
ontology with the highest similarity is always
chosen. However, it may occur that even the most
similar ontology is still not proper to describe a
document (i.e., low similarity). In this case, our
proposal relies on a threshold-based approach. The
threshold definition is not addressed in this paper.
Our mechanism allows users to formulate queries
over ontologies and the system takes the
responsibility for managing the heterogeneity and
distribution in the peers.
The usability of P2P systems is mainly dependent on
the techniques used for finding and retrieving the
resources. The result quality can be measured by
some metrics (Yang, 2002), such as: the size of the
result set, the user satisfaction, and the time to get
the results. However, there is a relation between cost
and quality that must be balanced. The use of the
flooding technique guarantees the optimal results,
but it is expensive and time-consuming, since all the
peers get the query message and usually only some
of them are able to answer it. Another attempt for
WordNet. Available at
JWNL Java WordNet Library. Available at
Jena-Semantic Web Framework. Available at
Xerces. Available at
balancing cost is to use any flooding variation
techniques, such as breadth-first traversal
(over the
network with depth limit D measured in hops) or
depth-first traversal
with depth limit D. However,
their use does not guarantee the optimal results,
since not all the peers get the requesting message.
For systems focusing on availability, search
techniques such as those presented in (Ratnasamy,
2001) and (Rowstron, 2001) are well-suited, because
they guarantee location of content if it exists.
However, to achieve these goals, these techniques
strongly control the data placement and work only
for a delimited number of hops. In our proposal, it is
fundamental to retrieve all the relevant files, while
using an optimized searching technique.
Furthermore, keyword-based systems do not
retrieve the necessary document if a synonym is
used as part of the query. This situation happens
because different but related terms may be used to
describe similar information. Besides, automatic
systems lack to find and extract relevant information
and fail to integrate information spread over
different sources (Fensel, 2001). To address these
issues, semantic annotations in our proposal allow
structural and semantic definitions of documents,
providing an intelligent query processing that allows
users to pose queries in a P2P system without being
aware of the location and structure of the files.
The peer aggregation into super peers is an
important issue and it is the basis of our proposal for
searching enhancement. This task is usually
performed based on some features, such as subject
and location (Nejdl, 2002). In this paper, we
consider both the domain application of the files
(described by an ontology) and a quantitative metric
defined by the desired mean number of peers in
super peers.
There are some works based on similarity
techniques that can be used for figuring out the
application domain of a XML document (Bertino,
2004). These works are usually based on structural
(Francesca, 2003), (Dalamagas, 2004), (Lian, 2204)
or content similarity (Baeza-Yates, 1999). Diff
algorithms are commonly used for detecting
differences between the files. However, our problem
is to identify semantic correspondences, which may
exist even between representations that are quite
differently in structure and content. Although an
ontology and a XML file can present low structural
and content similarity, they can describe the same
application domain. Thus, traditional similarity
techniques are not proper for our problem.
Gnutella. Available at
Freenet. Available at
ICEIS 2008 - International Conference on Enterprise Information Systems
Search engines provide support for automatic
information retrieval which helps in finding data
sources. However, the tasks of extracting the
relevant information remain for the user. Thus, there
are some bottlenecks that must be passed, such as
(Fensel, 2001): lack of a means for representation
and translation and lack of a means for content
Considering P2P systems, there is an extra issue:
to increase the result quality while optimizing the
search space. In this scenario, two problems must be
addressed: how to find relevant files for the user
query and how to increase the semantics in the
information resources. To overcome these issues, we
proposed an ontology-based approach that can be
used for improving searching techniques. With this
proposal, we have reduced the extra traffic produced
by traditional flooding techniques when the optimal
results are required, and increased the semantics
regarding the information storage and searching. The
search space optimization is achieved by clustering
files into super peers, based on file similarity. The
increasing of the semantics is done by adopting
ontologies, making explicit the information content
in a manner independent of the underlying structures
used to store the information.
We have presented the ontology manager, by
defining and implementing a tool for matching
ontologies to XML documents. By matching the
ontology to a XML file, the system can connect the
peer to a proper super peer that is described by a
specific ontology. The matching phase basically
considers the concept name, the structure similarity
and stemmer algorithms. The ontologies are
generated from an integration process among the
conceptual schemas that describe the XML files.
We implemented a tool named The Matcher that
identifies the similarity between XML files and
OWL ontologies. To evaluate the results, we have
performed a set of experimental tests, which clearly
demonstrated the accurate results. As future work,
we are going to incorporate this tool into DetVX, a
framework for detecting, managing and querying
XML replicas and versions in P2P scenarios. We are
currently developing a graphic tool for peer
management based on JXTA platform (Gong, 2001).
The system will allow managing the super peers,
peers and corresponding files, as well to assess the
performance when using the presented approach.
This work has been partially supported by CNPq
under grant No. 142396/2004-4 for Deise de Brum
Saccol; Pronex Project – FAPERGS under grant No.
0408933 and CNPq Universal under grant No.
481055/2007-0 for Renata de Matos Galante.
Baeza-Yates, R.A. and Ribeiro-Neto, B.A., 1999. Modern
Information Retrieval. ACM Press / Addison-Wesley.
Bertino, E.; Guerrini, G. and Mesiti, M., 2004. A
Matching Algorithm for Measuring the Structural
Similarity between an XML Document and a DTD and
its Applications. Information Systems, Elsevier
Science Ltd., 29, 23-46.
Dalamagas, T.; Cheng, T.; Winkel, K.J. and Sellis,
T.,2004. Clustering XML Documents using Structural
Summaries. In: EDBT Work. on Clustering
Information over the Web, Greece.
Fensel, D., 2001. Ontologies: A Silver Bullet for
Knowledge Management and Electronic Commerce.
Francesca, F.D.; Gordano, G.; Ortale, R. and Tagarelli,
A.., 2003. Distance-based Clustering of XML
Documents. In: Work. on Mining Graphs, Trees and
Sequences, Croatia.
Gong, L., 2001. JXTA: A Network Programming
Environment. IEEE Internet Computing, 5(3):88–95,
Kantrowitz, M., Mohit, B. and Mittal, V., 2000.
Stemming and its effects on TFIDF ranking. In: SIGIR
Conf. on Research and Development in Information
Retrieval. Athens.
Levenshtein, V., 1966. Binary Codes capable of correcting
deletions, insertions, and reversals. Cybernetics and
Control Theory, 10(8):707–710.
Lian, W.; Cheung, D.; Mamoulis, N. and Yiu, S., 2004.
An Efficient and Scalable Algorithm for Clustering
XML Documents by Structure. IEEE Trans. on
Knowledge and Data Engineering , 16, 82-96.
Madhavan, J., Bernstein, P. A. and Rahm, E., 2001.
“Generic schema matching using Cupid”. In:
VLDB’01, Rome, Italy.
Maedche, A.; Staab, S., 2002. “Measuring similarity
between ontologies”. In: EKAW.
Manning, C. D. and Schütze, H., 1999. Foundations of
Statistical Natural Language Processing. 1
Cambridge, MA: MIT Press.
Mena, E., and Illarramendi, A., 2001. Ontology-based
query processing for global information systems.
Nejdl, W., Wolf, B., Qu, C., Decker, S., Sintek, and et. al.,
2002. EDUTELLA: A P2P Networking Infrastructure
Based on RDF. In: WWW’02, Hawaii, EUA.
Ratnasamy, S., Francis, P., Handley, M., Karp, R., and
Shenker, S., 2001. A scalable content-addressable
network. In: SIGCOMM.
Rowstron, A., and Druschel, P., 2001. Pastry: Scalable,
distributed object location and routing for large-scale
peer-to-peer systems. In: Middleware.
Saccol, D.B., Edelweiss, N. , Galante, R.M. and Zaniolo,
C., 2007. Managing XML Versions and Replicas in a
P2P Context. In: SEKE, Boston, USA.
Saccol, D.B. et al., 2008. Gerenciamento de Domínios de
Aplicação através do Uso de Ontologias. In: ERBD,
Florianópolis, Brazil – in Portuguese. (to be
Staab. S. and Studer, R., 2004. Handbook on Ontologies
(International Handbooks on Information Systems).
Yang, B. and Garcia-Molina, H., 2002. Efficient Search in
Peer-to-Peer Networks. In: ICDCS, Vienna, Austria.
ICEIS 2008 - International Conference on Enterprise Information Systems
