Classiﬁcation of RFID Attacks

Aikaterini Mitrokotsa, Melanie R. Rieback and Andrew S. Tanenbaum

Department of Computer Science, Vrije Universiteit

De Boelelaan 1081A, 1081 HV Amsterdam, The Netherlands

Abstract. RFID (Radio Frequency Identiﬁcation) systems are emerging as one

of the most pervasive computing technologies in history due to their low cost and

their broad applicability. Although RFID networks have many advantages, they

also present a number of inherent vulnerabilities with serious potential security

implications. This paper develops a structural methodology for risks that RFID

networks face by developing a classiﬁcation of RFID attacks, presenting their im-

portant features, and discussing possible countermeasures. The goal of the paper

is to categorize the existing weaknesses of RFID systems so that a better under-

standing of RFID attacks can be achieved and subsequently more efﬁcient and

effective algorithms, techniques and procedures to combat these attacks may be

developed.

1 Introduction

RFID networks exist in a broad range of environments and their rapid proliferation

has been underway for quite some time. RFID systems consist of tiny integrated cir-

cuits equipped with antennas (RFID tags), that communicate with their reading devices

(RFID readers) using electromagnetic ﬁelds at one of several standard radio frequen-

cies. Additionally, there is usually a back-end database that collects information related

to the physically tagged objects.

RFID systems are vulnerable to a broad range of malicious attacks ranging from

passive eavesdropping to active interference. Unlike in wired networks, where com-

puting systems typically have both centralized and host-based defenses (e.g. ﬁrewalls),

attacks against RFID networks can target decentralized parts of the system infrastruc-

ture, since RFID readers and RFID tags operate in an inherently unstable and poten-

tially noisy environment. Additionally, RFID technology is evolving quickly – the tags

are multiplying and shrinking - and so the threats they are susceptible to, are similarly

evolving. Thus, it becomes increasingly difﬁcult to have a global view of the problem.

Threat models are necessary for managing risks efﬁciently. In this paper, we will

structure the most common RFID attacks into layers (related, but not identical to, ISO

layering), both enumerating the threats as well as offering potential defenses for each

layer.

The rest of this paper is structured as follows: Section 2 gives an overview of our

layering and classiﬁcation criteria. Section 3 discusses the physical layer, while Section

4 covers the network and transport layers. Section 5 concerns the application layer, and

Mitrokotsa A., R. Rieback M. and S. Tanenbaum A. (2008).

Classiﬁcation of RFID Attacks.

In Proceedings of the 2nd International Workshop on RFID Technology - Concepts, Applications, Challenges, pages 73-86

DOI: 10.5220/0001738800730086

 SciTePress

Section 6 focuses upon the co-called “strategic layer” (that we will deﬁne). Finally,

Section 7 describes RFID-based attacks that cut across multiple layers, and Section 8

concludes the paper.

!"#$%&'()*'#+,

-+./0,123,'4$50,.

)*'#+,

655(%&'.%04)*'#+,

7.,'.+8%&)*'#+,

9+';+,)<=

9:>?).'8$

>7@

ABCDEFAGGGE

H!I)JKK

L+42M

!,05,%+.',#)

9:>?)!,0.0&0($

H!I>7F

@-7

@,'&(+F)

76!

I0NN+,&%'(F

+4.+,5,%$+)N%;;(+/',+

I0$.$)O$PQ.%(%.#)

.,';+0RR$

*08%$.%&'()

:'&.0,$

9+'(2/0,(;)

&04$.,'%4.$

Fig.1. Layers of RFID Communication.

2 Classiﬁcation Overview

In this paper we classify attacks based on the layer that each attack is taking place giving

the special characteristics and discuss possible available solutions that can be used in

order to combat these attacks. We discriminate attacks that are deployed (Fig. 1) in the

physical layer, the network-transport layer, the application layer and the strategic layer

as well as multilayer attacks which affect more than one layer.

Other classiﬁcations of possible threats and risks in RFID networks have also been

proposed ([1], [2], [14], [22]). Avoine et al. [1], Ayoade et al. [2] and Garﬁnkel et al.

[14] have focused on privacy threats while Karygiannis et al. [22] have proposed a

detailed taxonomy of network, business process and business intelligence risks. Avoine

et al. [1] demonstrate that privacy issues cannot be solved without looking at each layer

separately. We expand upon this by examining also other types of threats and give a

better overview of the problem by discussing possible countermeasures in each case.

More speciﬁcally, in the physical layer we include attacks that affect the Radio

Frequencies (RF), the hardware of readers and the RFID tags as physical devices. In

network-transport layer we describe attacks that take advantage of the implemented

RFID protocols such as the standards ISO 15693/14443/18000,the EPC Gen-2 or other

proprietary protocols. In the application layer we include attacks that exploit vulnerabil-

ities of the commercial enterprise middleware and applications such as Oracle, SAP or

the EPCIS/ONS servers. Finally in the strategic layer is related with logistical factors,

real world constraints and costs vs utility tradeoffs. In this layer we include attacks that

take advantage of critical information that is related to the production, the organization

and the expansion policies that are adopted in competitive business environments as

well as privacy and targeted security threats. Finally we create a separate category of

multilayer attacks that exploit vulnerabilities from multiple layers. The detailed classi-

ﬁcation is depicted in Figure 2.

!"#$%&''()*+

,-.+/)(0%1(.23

42'563*7%

83(9+:63'%1(.23

&::0/)('/69%1(.23

;'3('2</)%1(.23

,23=(929'0.%

$/+(>0/9<%8(<+

8(<%!2=6?(0

8(<%$2+'3@)'/69

A#11%B6==(9C

82=:63(3/0.%

$/+(>0/9<%8(<+

,(++/?2

#9'23D2329)2

8(<%&''()*+

!2(C23%&''()*+

B069/9<

E9(@'-63/F2C%

8(<%!2(C/9<

#=:23+69('/69

G(?2+C36::/9<

42'563*%

,36'6)60%&''()*+

,3/?().%8-32('+

8(3<2'2C%

;2)@3/'.%8-32('+

8(<%

H6C/D/)('/69

!20(.%&''()*+

&::0/)('/69%

H/CC025(32%

&''()*+

I@DD23%

J?23D065+

H(0/)/6@+%B6C2%

#9K2)'/69

H@0'/0(.23%&''()*+

&)'/?2%

L(==/9<

B6?23'%

B-(9920+

!2:0(.%&''()*+

$29/(0%6D%;23?/)2%

(''()*+

;/C2%B-(9920%%

&''()*+

B3.:'6%

&''()*+

83(DD/)%&9(0./+

;:66D/9<

B6=:2'/'/?2%

G+:/69(<2

;6)/(0%

G9</9223/9<%

Fig.2. Classiﬁcation of RFID attacks.

3 Physical Layer

The physical layer in RFID communications is comprised of the physical interface and

the RFID devices. The adversary in this layer takes advantage of the wireless nature

of RFID communications, their poor physical security and their insufﬁcient resilience

against physical manipulation. This layer includes attacks that permanently or tem-

porarily disable RFID tags as well as relay attacks. Furthermore, we discuss possible

countermeasures.

3.1 Permanently Disabling Tags

Permanently disabling RFID tags include all the possible risks or threats that may have

as a result the total destruction or substantially degraded operation of an RFID tag.

Possible ways of rendering an RFID tag permanently inoperable are tag removal, tag

destruction or using the KILL command.

Tag Removal. Since RFID tags present poor physical, security, RFID tags that are not

embedded on items can easily be removed from an item and may subsequently attached

to another one (just like “switching” price tags). A trivial example of tag removal could

be the malicious attempt of a thief in a supermarket to switch the RFID tag of an expen-

sive product with that of a cheaper one and pay less at checkout. This kind of threat is a

reality that can be easily performed without the requirement of special technical skills

and poses a fundamental security problem. However, this type of attack does not have

the potential to be carried out in a massive scale.

Tag Destruction. Based on the same concept of poor physical security, a tag may be

physically destroyed intentionally even if there is no speciﬁc gain for the attacker. An

RFID vandal who is just interested in annoying people or disrupting operation may eas-

ily destroy RFID tags with poor physical protection. But even if RFID tags escape from

the malicious intentions of a vandal they are still susceptible of possible destruction

caused by extreme environmental conditions such as too high or too low temperatures

or even abrasion caused by rough handling. Moreover,active RFID tags can be rendered

inoperable by removing or discharging their batteries. Furthermore, RFID tags are ex-

tremely sensitive to static electricity. RFID tags’ electronic circuits can be damaged in

an instant by electrostatic discharge caused by conveyor belts or high energy waves.

KILL Command. The Auto-ID center [3] and EPC global created a command speciﬁ-

cation called KILL that is able to permanently silence an RFID tag. According to this

scheme, each RFID tag has a unique password which is deﬁned by the manufacturer

of the tag and its use can render an RFID tag permanently inoperable. Although this

feature can be used for privacy reasons it is obvious that can be exploited by malicious

adversaries in order to sabotage RFID communications.

3.2 Temporarily Disabling Tags

Even if an RFID tag escapes the threat of permanent disablement, it is still possible for

it to be temporarily disabled. A prospective thief can use an aluminium foil-lined bag

(a simple Faraday Cage (FC)) in order to shield it from electromagnetic waves (such as

those of the checkout reader) and steal any product undisturbed. RFID tags also run the

risk of unintentional temporary disablement caused by environmental conditions (e.g. a

tag covered with ice). Temporarily disabling tags can also be result of radio interference

either passive or active.

Passive Interference. Considering the fact that RFID networks operate in an inher-

ently unstable and noisy environment their communication is rendered susceptible to

possible interference and collisions from any source of radio interference such as noisy

electronic generators and power switching supplies. This interference prevents accurate

and efﬁcient communication.

Active Jamming. Although passive interference is usually unintentional, an attacker

can take advantage of the fact that an RFID tag listens indiscriminately to all radio

signals in its range. Thus, an adversary may cause electromagnetic jamming by creating

a signal in the same range as the reader in order to prevent tags from communicating

with readers.

3.3 Relay Attacks

In a relay attack an adversary acts as a man-in-the-middle. An adversarial device is

placed surreptitiously between a legitimate RFID tag and reader. This device is able

to intercept and modify the radio signal between the legitimate tag and reader. Subse-

quently, an ephemeral connection is relayed from the legitimate tag/reader through the

adversarial device to the legitimate reader/tag. The legitimate tag and reader are fooled

into thinking that they are communicating directly with each other. To make this type of

attack even more sophisticated, separate devices could be used, one for the communica-

tion with the reader and one for the communication with the RFID tag. Of great concern

is the fact that relay attacks may be successful even from considerable distances. For

instance, a relay attack could be used to charge a payment to the victim’s RFID card.

Recently, a German MSc. student [33] proved the vulnerability of the Dutch public

transport by performing a relay attack on the Dutch transit ticket. The student just im-

plemented the “ghost and leech” model as described by Kﬁr and Wool [24] and created

great concerns for the $2 billion Dutch public transport system.

3.4 Defenses against Physical Layer Attacks

In order to safeguard RFID systems against low-tech attacks such as permanently or

temporarily disabling tags, traditional countermeasures should be used, such as in-

creased physical security with guards, fences, gates, locked doors and cameras [23].

Thus, intentional and unintentional physical destruction as well as use of aluminum

foil lined bags could be mitigated. Tag removal could be prevented by adopting these

policies of physical surveillance or by using stronger ways to avoid easy removal of

tags (e.g. stronger glue, embedding tag in products). Intentional of unintentional radio

interference could also be limited by using walls opaque to relevant radio frequencies

[23]. Furthermore, unauthorized use of KILL commands could be prevented with ef-

fective password management. For instance, the KILL command for Class-1 Gen-2

EPC standard [10] tags requires a 32-bit password. For the protection against relay at-

tacks possible approaches could be the encryption of the RFID communication or the

addition of a second form of authentication such as a password, a PIN or biometric

information. However, this requirement deﬁnitely eliminates the convenience and ad-

vantages of RFID communication. Another possible way to counter relay attacks is the

distance bounding protocol based on ultra-wideband pulse communication proposed by

Hancke et al. [15]. Another interesting approach that can be used to safeguard RFID

systems against attacks (including physical layer attacks) was proposed by Bolotnyy et

al. [5]. More precisely, they have proposed a hardware-based approach that relies on

physically unclonable functions (PUFs) to provide security and privacy. PUFs provide

an exponential solution to the critical key distribution problem and can protect against

cloning even if an adversary has physical access to RFID tags.

4 Network - Transport Layer

This layer includes all the attacks that are based on the way the RFID systems are com-

municating and the way that data are transfered between the entities of an RFID network

(tags, readers). In this section we describe attacks that affect the network-transportlayer

and we discriminate them into attacks on the tags, reader attacks and network protocol

attacks. We also provide possible ways to counter these attacks.

4.1 Attacks on the Tags

Cloning. Even the most important and characteristic feature of RFID systems, their

unique identiﬁer, is susceptible to attacks. Although in theory you cannot ask an RFID

manufacturer to create a clone of an RFID tag [26], in practice it has proven that the

task of replicating RFID tags does not requite a lot of money or expertise considering

the wide availability of writable and reprogrammable tags. An ominous example is the

demonstration by a German researcher of the vulnerability of German passports [4] to

cloning.

Spooﬁng. Spooﬁng is effectively a variant of cloning that does not physically replicate

an RFID tag. In this type of attacks an adversary impersonates a valid RFID tag to

gain its privileges. This impersonation requires full access to the same communication

channels as the original tag. This includes knowledge of the protocols and secrets used

in any authentication that is going to take place.

4.2 Reader Attacks

Impersonation. Considering the fact that in many cases RFID communication is unau-

thenticated, adversaries may easily counterfeit the identity of a legitimate reader in

order to elicit sensitive information or modify data on RFID tags.

Eavesdropping. The wireless nature of RFID makes eavesdropping one of the most se-

rious and widely deployed threats. In eavesdropping an unauthorized individual uses an

antenna in order to record communications between legitimate RFID tags and readers.

This type of attack can be performed in both directions: tag-to reader and reader-to tag.

Since readers transmit information at much higher power than tags, the former are sus-

ceptible to this type of attacks at much greater distances and consequently to a greater

degree. The information recorded can be used to perform more sophisticated attacks

later. The feasibility of this attack depends on many factors, such as the distance of the

attacker from the legitimate RFID devices.

4.3 Network Protocol Attacks

RFID systems are often connected with back-end databases and networking devices on

the enterprise backbone. Nevertheless, these devices are susceptible to the same vul-

nerabilities of general purpose networking devices. Flaws in the operating system and

network protocols used, can be used by malicious attackers in order to launch attacks

and compromise the back-end infrastructure.

4.4 Defenses against Network-Tranport Layer Attacks

Through appropriate data collection, it is possible to detect cloned RFID tags. Alterna-

tively, cloning attacks can be mitigated via challenge response authentication protocols.

These should also support robust anti-brute force mechanisms. Nevertheless, the inher-

ent resource constraints that RFID tags present lead to weak authentication protocols

that are inefﬁcient against determined attackers. Juels [19] has demonstrated some tech-

niques for strengthening the resistance of EPC tags against cloning attacks, using PIN-

based access to achieve challenge response authentication. Public awareness of the se-

curity implications related to cloning attacks should be the key policy to defend against.

However, this is not always the case. For instance, none of the countries that issue e-

passports have anti-cloning mechanisms [26] as suggested by the ICAO 9303 standard

[16]. In order to defend against passive eavesdropping attacks encryption mechanisms

could be used to encrypt the RFID communication. Spooﬁng and impersonation could

be combated by using authentication protocols or a second form of authentication such

as one-time passwords, PINs or biometrics. Network protocol attacks could be coun-

tered by hardening all components that support RFID communication, using secure

operating systems, disabling insecure and unused network protocols and conﬁguring

the protocols used with the least possible privileges.

5 Application Layer

This layer include all the attacks that target information related to applications and the

binding between users and RFID tags. Such attacks employ unauthorized tag reading,

modiﬁcation of tag data and attacks in the application middleware. We describe these

attacks as well as possible ways to combat them.

5.1 Unauthorized Tag Reading

Since not all the RFID tags support protocols for authenticated read operations, adver-

saries may easily read the contents of RFID tags (even from large distances) without

leaving any trace.

5.2 Tag Modiﬁcation

Considering the fact that most RFID tags that are in widespread use today employ user

writeable memory, an adversary can exploit this to modify or delete valuable info. We

have to note here that the ease with which such an attack can be performed is highly

dependent on the used standard used and the READ/WRITE protection employed.

5.3 Middleware Attacks

Buffer Overﬂows. Buffer overﬂows constitute one of the major threats and among

the hardest security problems in software. Buffer overﬂow exploits store data or code

beyond the bounds of a ﬁxed-length buffer. Adversaries may use RFID tags to launch

buffer overﬂows on the back-end RFID middleware. Although this might not be trivial,

considering the memory storage of RFID tags, there are still commands that allow an

RFID tag to send the same data block repetitively [31] in order to overﬂow a buffer

in the back-end RFID middleware. Other options include the use of other devices with

more resources such as smart cards or devices that are able to emulate multiple RFID

tags (e.g. RFID guardian), or using a tag with more memory than the one expected.

Malicious Code Injection. RFID tags can be used in order to propagate hostile code

that subsequently could infect other entities of the RFID network (readers and connect-

ing networks) [31]. In this scneario, an adversary uses the memory space of RFID tags

in order to store and propagate the infecting viruses. Although this type of attacks are

not wide-spread, laboratory experiments [31] have proved that they are feasible. Con-

sidering the fact that middleware applications are using multiple scripting languages

such as Javascript, PHP, XML etc. an adversary may exploit this and inject malicious

code in order to compromise the middleware systems. More speciﬁcally, RFID tags can

be employed in order to perform code insertion in RFID applications that use web pro-

tocols and intercept scripting languages. In the same way, can also be performed SQL

injection [31], a special code insertion attack based on unexpectedly executing SQL

statements that may lead unauthorized access to back-end databases and subsequently

reveal or even modify data stored in the back-end RFID middleware.

5.4 Defenses against Application Layer

In order to defend against unauthorized tag reading and tag modiﬁcation, controlling ac-

cess to RFID tags should be our focus. One approachproposed was the use of aluminum-

lined wallets to protect RFID payment cards and epassports against unauthorized read-

ing. Many companies embraced this solution and sell this type of products ([27], [8]).

However since the snifﬁng of conﬁdential data can nevertheless be performed at the

time of actual use, the approach does not seem to be very effective. Encryption tech-

niques, authentication protocols or access control lists may provide an alternative so-

lution. More speciﬁcally, approaches based on symmetric key encryption [25], public

key encryption [11], hash functions [34], mutual authentication ([28], [7] ) or even non-

cryptographic solutions such as pseudonyms [18], have been proposed. However, an

important limitation on employing these schemes in RFID systems is that the latter

have inherent vulnerabilities such as possible power interruptions or the disruption of

wireless channels. Moreover, we have to keep in mind that employing all these encryp-

tion techniques even in non-criticalapplications such as RFID on underwear or chewing

gum is deﬁnitely not worthwhile.

Buffer overﬂows and malicious code injection in the middleware can be combated

with simple countermeasures. Performing regular code reviews to ensure the security of

the system against vulnerabilities and bugs, by for instance ensuring that bounds check-

ing takes place (c.f. [31]). For databases, the use of bound parameters and applying

least possible privileges among other things [13] will help protect the system. Finally,

in general, turning off unnecessary middleware features such as back-end scripting,

further promotes system integrity. Other simple measures include isolating the RFID

middleware server so that in case it is compromised, access to the rest of the network

will not be provided, checking the input data of the RFID middleware and eliminating

special and suspicious characters.

6 Strategic Layer

This layer includes attacks that target organization and business applications, taking

advantage the careless design of infrastructures and applications. More speciﬁcally in

this layer are included competitive espionage, social engineering, privacy and targeted

security threats. We describe these threats and we discuss possible ways that can be

employed to counter them.

6.1 Competitive Espionage

Adversaries may often have business or industrial competitors as a target. Exploiting the

ability to track and detect tagged items, they may gather critical and conﬁdential infor-

mation in order to sabotage their competitors. Such information may include strategies

and practices of the target relating to changing prices, production schedules [23] or

marketing scenarios. Such attacks can be achieved via eavesdropping, or by gaining

unauthorized access to back-end databases etc.

6.2 Social Engineering

An adversary may even use social engineering skills to compromise an RFID sys-

tem and gain unauthorized access to restricted places or information. Instead of going

through the laborious process of hacking/cracking RFID communications, an attacker

simply use a conﬁdence trick to manipulate people into revealing conﬁdential informa-

tion. An attacker may simply take advantage of simple acts of human kindness, such

as holding the door open (whereupon one may enter without an RFID badge in an

otherwise restricted area) or lending an RFID tag (whereupon one may retrieve all its

conﬁdential information).

6.3 Privacy Threats

RFID tags respond to any reader, authorized or unauthorized, without giving any indi-

cation about that to their owners. This special feature can be exploited by adversaries to

track and proﬁle individuals. The potential collection of personal information ranging

from purchasing habits to medical information is one of the greatest risks in RFID sys-

tems and has led to mounting campaigns against the RFID usage. Privacy threats can

have various dimensions depending on the behavior of the owner, the association of an

individual with an item, the location of the owner, the preferences of the owner or a

“constellation” of tags [2].

6.4 Targeted Security Threats

An adversary can use the information collected by an association or location threat in

order to trigger malicious events and/or physical or electronic attacks. Typical example

of this attack is targeting and robbing people who collect valuable items (e.g watches

or jewelry) trucks or ships that carry valuable or critical items.

6.5 Defenses against Strategic Layer Attacks

Attacks in this layer can be defended against using any of the countermeasures em-

ployed against attacks included in the other layers. More precisely, for privacy and

targeted security threats a broad range of technical solutions have been proposed, in-

cluding killing or temporarily silencing tags, blocking access to unauthorized readers

[20], [30], relabeling [17] or clipping [21] tags, using pseudonyms [18], distance mea-

surements [12] and encryption techniques ([25], [11]).

However, to effectivelycounter strategic threats we need to confront them as a prob-

lem that requires long-term effort. Companies and organizations that use RFID systems

should establish and maintain a privacy and data protection policy and perform risk as-

sessment to deﬁne threats and risks associated to the employed RFID infrastructure. It

is important to receive guidance from a privacy ofﬁcer and a legal counsel concerning

the adopted strategic scenarios and privacy related issues. The security policy should

be adequately communicated to all employees. The continuous training and education

of the organization’s personnel on RFID security and privacy policies is essential, as it

promotes awareness and oversight on critical information. Karygiannis et al. [23] pro-

vide a complete list of countermeasures that can be employed to eliminate the business

and privacy risks related to RFID systems.

The privacy issues related to RFID communication should also receive attention

from legislators and authorities that may give guidelines that should be followed by

organizations and companies that use RFID systems. The Center for Democracy and

Technology [6] and the EPC global [9] have already developed a set of guidelines and

principles that can be used by organizations to counter privacy challenges.

7 Multilayer Attacks

A lot of attacks that target RFID communication are not conﬁned to just a single layer.

In this category are included attacks that affect multiple layers including the physical,

the network-transport, the application and the strategic layer. In particular in this layer

are included covert channels, denial of service, trafﬁc analysis, crypto and side channel

attacks. We describe these attacks as well as possible ways to defend against them.

7.1 Covert Channels

Attackers may exploit RFID tags in order to create unauthorized communication chan-

nels to transfer information covertly. Adversaries may take advantage of the unused

memory storage of multiple RFID tags in order to securely transfer data in a manner

that is difﬁcult to detect [22]. For instance, a set of RFID tags implanted in human bod-

ies, whose normal purpose would be to identify a person, could secretly report private

information related to medical data or social activities.

7.2 Denial of Service Attacks

The normal operation of RFID tags may be interrupted by intentionally blocking access

to them. Deliberate blocked access and subsequent denial of service for RFID tags may

be caused by malicious uses of “blocker tags” [20] or the RFID guardian [30]. Both

approaches were proposed to safeguard RFID communications against privacy threats.

Nevertheless, they could also be employed by adversaries to perform a deliberate de-

nial of service. Another denial of service technique is the unauthorized use of LOCK

commands. LOCK commands [22] are included in several RFID standards in order to

prevent unauthorized writing on RFID tags’ memory. Depending on the applied stan-

dard the lock command is applied by a predeﬁned password and can have permanent

or temporary effects. Moreover, since RFID middleware includes networking devices,

an adversary may take advantage of the system’s limited resources and cause a denial

of service in the RFID middleware. For instance, sending a stream of packets to the

middleware so the network or processing capacity is swamped and subsequently denies

access to regular clients.

7.3 Trafﬁc Analysis

RFID communication is also susceptible to trafﬁc analysis attacks. An eavesdropper is

able to intercept messages and extract information from a communication pattern. Even

if the RFID communication is protected by encryption and authentication techniques, it

is still vulnerable to trafﬁc analysis attacks.The greater the number of messages inter-

cepted, the more effective a trafﬁc analysis will be.

7.4 Crypto Attacks

When critical information is stored on RFID tags, encryption techniques are employed

in order to safeguard the integrity and conﬁdentiality of the protected data. However,

determined attackers are employing crypto attacks to break the employed cryptographic

algorithms and reveal or manipulate sensitive information. For instance, in Holland a

security ﬁrm named Riscure [32] has proven that the key used in a Dutch passport can

be easily broken using a standard PC performing a brute-force attack for two hours.

7.5 Side Channel Attacks

Side channel attacks take advantage of the physical implementation of a cryptographic

algorithm rather than its theoretical vulnerabilities. In this type of attacks the informa-

tion that is usually exploited includes timing information, power consumption or even

electromagnetic ﬁelds. The efﬁcient deployment of side channel attacks requires deep

knowledge of the internal system on which cryptographic algorithms are implemented.

Timing attacks are implemented by examining ﬂuctuations in the rate of computation of

the target while simple power analysis (SPA) attacks extract information based on the

variations of the power consumption. Differential Power Analysis (DPA) is a special

type of power analysis attacks which is based on the electromagnetic variations pro-

duced for instance during the communication between an RFID reader and tag. More

precisely, the electromagnetic ﬁeld variations when an RFID tag is performing a cryp-

tographic operation can be used to reveal secret cryptographic keys.

7.6 Replay Attacks

A common defense approach to attacks such as the above, is the use of a challenge

response protocol. RFID tags and readers usually share a secret and use a challenge

response protocol to authenticate their identities. Nevertheless, very often this approach

is subject to replay attacks. In a replay attack, an adversary broadcasts a tag’s response

recorded from a past transaction in order to impersonate the tag to a reader. Typical

example of this attack is the unauthorized access to restricted areas by broadcasting

an exact replay of the radio signal sent from a legitimate tag to the reader that grants

access.

7.7 Defenses against Multilayer Attacks

Covert channels attacks are difﬁcult to detect and defend against. The owners and users

of RFID tags have no knowledge that their tags have been compromised and that they

are used for a covert channel attack. Foiling these attacks is an open research issue.

However, a possible mechanism to combat them should focus on reducing the avail-

ability of memory resources in an RFID tag (e.g. clearing the unused memory every

few seconds or randomizing code and data locations).

Denial of Service attacks and trafﬁc analysis are severe security threats in all types

of networks including wired. While theoretically these types of attacks can be countered

the scarce resources of RFID tags make their defense problematic and remain an open

research issue. Crypto attacks can be eliminated through the employment of strong

cryptographic algorithms following open cryptographic standards and using a key with

sufﬁcient length. Thus, incidents such as the revelation of Mifare smartcard’s security

ﬂaws [29] can be avoided. Side channel attacks and more precisely DPA attacks, can be

guarded against by limiting the electromagnetic emissions of the system. However, this

usually implies limiting the operational range.

In order to defend against replay RFID attacks some simple countermeasures exist

such as the use of timestamps, one-time passwords and challenge response cryptogra-

phy. Nevertheless, these schemes are inconvenient and with doubtful efﬁciency con-

sidering the vulnerabilities to which challenge response protocols are susceptible to.

Another approach is the use of RF shielding on readers in order to limit the directional-

ity of radio signals and subsequently the appearance of a ghost [24]. Another approach

is based on the distance between the information requestor and the information owner.

Fishkin et. al. [12] implied that the signal-to-noise ratio of the reader signal in an RFID

system can reveal even roughly the distance between a reader and a tag. This informa-

tion could deﬁnitely be used in order to make a discrimination between authorized and

unauthorized readers or tags and subsequently mitigate replay attacks.

8 Conclusions

Due to the increasingly wider deployment of RFID systems, their security is more crit-

ical than ever. In this paper, we tried to discover some structure within the universe of

possible attacks that can affect such systems. By considering the point of attack, its sys-

temic effects and countermeasures jointly, we can obtain a more coherent view of the

threats and what must be done to counter them.

In this paper, we classiﬁed attacks based on the layer that each is taking place and

we discussed possible countermeasures that can be used to combat these attacks. We

discriminated them to attacks deployed in the physical layer, the application layer, the

strategic layer and multilayer attacks. Finally, we point out for which attacks further

research is necessary in order to achieve adequate defense against them.

References

1. Avoine, G., Oechslin, P.: RFID Traceability: A Multilayer Problem. In: Patrick, A., Yung, M.

(eds.). In: Proc. of the Ninth Int’l Conf. on Financial Cryptography and Data Security

(FC’05), Lecture Notes in Computer Science, Vol. 3570. (2005) 125–140

2. Ayoade, J., Saxby, S.: Roadmap for Solving Security and Privacy Concerns in RFID Systems.

In: Computer Law and Security Report (2007)

3. Center, A.I.: 900 MHz Class 0 Radio Frequency (RF) Identiﬁcation Tag Speciﬁcation. In:

Draft, www.epcglobalinc.org/standards/specs/900 MHz Class 0 RFIDTag Speciﬁcation.pdf,

(2003)

4. DN-Systems: BBC Reports on Cloning of the new e-passport. In: http://www.dn-

systems.de/press/document.2007-01-04.2112016470, (2007)

5. Bolotnyy, L., Robins, G.: Physically Unclonable Function-Based Security and Privacy in

RFID Systems. In: Proc. of PerCom’07. New York, USA (2007) 211–220

6. CDT: CDT Working Group on RFID: Privacy Best Practices for Deployement of RFID

Technology. In: Interim Draft, http://www.cdt.org/privacy/20060501rﬁd-best-practices.php,

(2006)

7. Dimitriou, T.: A Lightweight RFID Protocol to Protect Against Traceability and Cloning

Attacks. In: Proc. of IEEE Conf. on Security and Privacy for Emerging Areas in Communi-

cation Networks, (2005)

8. Emvelope: Products. In: http://www.emvelope.com/products. (2008)

9. EPCGlobal: Guidelines on EPC for Consumer Products. In:

http://www.epcglobalinc.org/public/ppsc guide/, (2005)

10. EPCGlobal: Class-1 generation-2 UHF RFID Protocol for Communications at 860MHz-960

Mhz. In: EPC Radio-Frequency Identity Protocols, Vol. 1.1.0, (2005)

11. Fedhofer, M., Dominikus, S., Wolkerstorfer, J.: Strong Authentication for RFID Systems

Using the AES Algorithm. In: Proc. of Cryptographic Hardware and Embedded Systems

(CHES’04), Vol. 3156. Lecture Notes in Computer Science. (2004) 357–370

12. Fishkin, K., Roy, S., Jiang, B.: Some Methods for Privacy in RFID Communication. In: Proc.

of the 1st European Workshop on Security (2004) 42–53

13. Friedl, S.: SQL Injection attacks by example. In: http://www.unixwiz.net/techtips/sql-

injection.html, (2007)

14. Garﬁnkel, S., Juels, A., Pappu, R.: RFID Privacy: An Overview of Problems and Proposed

Solutions. In: IEEE Security & Privacy, Vol. 3. (2005) 34–43

15. Hancke, G., Kuhn, M.: An RFID Distance Bounding Protocol. In: Proc. of the 1st Int’l Conf.

on Security and Privacy for Emerging Areas in Communications Networks (SecureComm

2005) (2005) 67–73

16. ICAO. ICAO Document 9303. In: http://mrtd.icao.int/content/view/33/202, (2006)

17. Inoue, S., Yasuura, H.: RFID Privacy Using User-Controllable Uniqueness. In: Proc. of RFID

Privacy Workshop. MIT, Massachusetts, USA (2003)

18. Juels, A.: Minimalist Cryptography for Low-cost RFID Tags. In: Proc. of the 4th Conf. on

Security in Communication Networks (SCN’04), Vol. 3352.Lecture Notes in Computer Sci-

ence. Springer-Verlag (2004) 149–164

19. Juels, A.: Stengthening EPC Tags Against Cloning. In: Proc. of ACM Workshop on Wireless

Security (WiSe’05). ACM Press (2005) 67–76

20. Juels, A., Rivest, R.,Szydlo, M.: The Blocker Tag: Selective Blocking of RFID Tags for Con-

sumer Privacy. In: Proc. of the 10th ACM Conf. on Computer and Communication Security.

(2003) 103–111

21. Karjoth, G., Moskowitz, P.A.: Disabling RFID Tags with Visible Conﬁrmation: Clipped Tags

are Silenced. In: Atluri, V., di Vimercanti, S.D.C., Dingledine, R. (eds). In: Proc. of the 2005

ACM Workshop on Privacy in the Electronic Society (WPES 2005). (2005) 27–30

22. Karygiannis, A., Phillips, T., Tsibertzopoulos, A.: RFID Security: A Taxonomy of Risk. In:

Proc. of China’Com ’06. (2006) 1-8

23. Karygiannis, T., Eydt, B., Barber, G., Bunn, L., Phillips, T.: Guidelines for Securing Radio

Frequency Identiﬁcation (RFID) Systems. In: NIST Special Publication 800-98, National

Institute of Standards and Tecnology (2007)

24. Kﬁr, Z., Wool, A.: Picking Virtual Pockets Using Relay attacks on Contactless Smartcard.

In: Proc. of the 1st Int’l Conf. on Security and Privacy. (2005) 47–48

25. Kinoshita, S., Hoshino, F., Komuro, T., Fujimura, A., Ohkubo, M.: Low-cost RFID Privacy

Protection Scheme. In: IPS Journal, Vol. 45. (2003) 2007–2021

26. Laurie, A.: Practical Attacks Against RFID. In: Network Security, Vol. 2007, No. 9. (2007)

4–7

27. mCloak: mCloak for RFID tags. In: http://www.mobilecloak.com/rﬁdtag/rﬁd.tag.html

(2005)

28. Molnar, D. and Wagner, D.: Privacy and Security in Library RFID: Issues, Practices and

Architectures. In: Proc. of Conf. on Computer and Communications Security. (2004) 210–

219

29. Nijmegen, R.U.: Dismantling Contactless Smartcards. Technical Report 08-33A, Radboud

Universiteit Nijmegen. www2.ru.nl/media/pressrelease.pdf, (2008)

30. Rieback, M.R., Crispo, B., Tanenbaum, A.S.: RFID Guardian: A Battery-Powered Mobile

Device for RFID Privacy Management. In: Proc. of ACISP’05. (2005) 184–194

31. Rieback, M.R., Bruno, B., Tanenbaum, A.S. Is Your Cat Infected with a Computer Virus?

In: Proc. of the 4th IEEE Int’l Conf. on Pervasive Computing and Communications. (2006)

169–179

32. Riscure.: Privacy Issues with New Digital Passport. In:

http://www.riscure.com/2 news/passport.html, July (2005)

33. Tanenbaum, A.: Dutch Public Transit Card Broken. In: http://www.cs.vu.nl/ ast/ov-chip-

card/, (2007)

34. Weis, S., Sarma, S., Rivest, R., Engels, D.: Security and Privacy Aspects of Low-cost Ra-

dio Frequency Identiﬁcation Systems. In: Proc. of 1st Int’l Conf. in Security in Pervasive

Computing, Vol. 2802. (2003) 201–212
