A COOPERATIVE AND DISTRIBUTED CONTENT

MANAGEMENT SYSTEM

C. Noviello, M. Mango Furnari and P. Acampa

Istituto di Cibernetica E. Caianiello, Via Campi Flegrei, 34, Pozzuoli, Italy

Keywords:

Cooperative Content Mangement System, Information Grid, Cultural Heritage.

Abstract:

In this paper the authors address some methodological and technical issues on managing collections of digital

documents published on the web by many different stakeholders. To cope with this kind of problems the

notions of document, cooperative knowledge community and content knowledge authority are introduced.

Then the architecture of a distributed and cooperative content management system is presented. A set of

methodologies and tools for organizing the documents space around the notion of contents community were

developed. Each content provider will publish a set of data model interpreters to collect, organize and publish

through a set of cooperative content management system nodes glued together by a web semantic oriented

middleware. These methodologies and software were deployed setting up a prototype to connect about 100

museums spread on the territory of Campania (Italy).

1 INTRODUCTION

Thanks to diffusion of low cost high-speed Internet

connections, institutions and organizations face in-

creasing demands to cooperate in sharing common

knowledge. Content delivery and sharing information

across the network is today possible using a variety

of technologies, such as distributed databases, service

oriented applications, and so forth. However, sharing

content technology is only one aspect of content man-

agement in cooperative and distributed settlements. In

fact, contents need to be created, managed, revised

and ﬁnally published. Contents may also to be ag-

gregated in collections, which in turn may be shared

among stakeholders. Modern Content Management

Systems (CMS) have a complete environment to sup-

port users in content production and publishing for

the web. Thanks to a powerful, complete and user-

friendly interface it is very simple to create, manage

and store contents. However, most CMSs have poor

support for cross systems interoperability and cooper-

ation over the network. They mainly focus the atten-

tion to the users interaction and documents usage.

Prerequisite to share documents in machine under-

standable way is the adoption of de facto standards for

content and metadata representations. Aside of this

standards, documents must provide both user and ma-

chine oriented representations, and play an active rule

in data sharing. In other words it would be of some

interest to explore the possibility to map the docu-

ment conceptual model on the object oriented pro-

gramming model exploiting some of its methodologi-

cal and technological features.

Furthermore, the current semantic oriented ex-

ploitation attempts are mainly oriented to cope with

the conceptualization of a single information source,

they use document semantic models as monolithic en-

tities providing little support to specify, store and ac-

cess them in a modular manner.

In this paper we address the problem of making

distributed document collection repositories mutually

interoperable.

The design methodologies described in this pa-

per are based on the hypothesis that it is yet neces-

sary to develop an adequate treatment for distributed

and heterogeneous document model interpretation to

promote information sharing on the semantic web.

Appropriate infrastructures for representing and man-

aging distributed document model interpreters have

also to be developed. To pursue these goals we in-

troduced the notion of knowledge stakeholders com-

munity that exchange modularized document model

interpretation together documents using a document

middleware. Experimental implementation and tools

were developed to check the adequacy of the pro-

posed methodologies; their deployment for the cul-

tural heritage promotion arena is also described.

The rest of the paper is organized as follows: in

140

Noviello C., Mango Furnari M. and Acampa P. (2008).

A COOPERATIVE AND DISTRIBUTED CONTENT MANAGEMENT SYSTEM.

In Proceedings of the Third International Conference on Software and Data Technologies - ISDM/ABF, pages 140-147

DOI: 10.5220/0001878501400147

 SciTePress

section 2 the reference scenario is described. In sec-

tion 3 the architecture and the implementation of the

proposed Distributed Contents Management System

are given together a description of the document mod-

ular representation model structure is described. In

section 4 the implemented test bed is described and

the proposed architecture advantages are summarized.

2 KNOWLEDGE COMMUNITIES

AND CONTENT

MANAGEMENT SYSTEMS

A knowledge community is created aggregating a

group of information stakeholders that want to share

and reuse their information contents so to improve

their offer to their customers. On doing that they

want retain their operational autonomy and identity

without reducing the cooperation opportunities. To

pursue these goals they need an intermediate coordi-

nation organization (knowledge community authority)

in charge to register, syndicate and guarantee the in-

teroperability of their document repository schema.

Furthermore, the stakeholder managers would also

be interested to organize a set of related documents

into documents collections, according to some rela-

tionships. These collections should be built starting

from documents either directly managed or shared

with other participating stakeholders.

From the managers’ perspective each information

system should allow him to make available the man-

aged information both to the other participating con-

tent managers and to the knowledge community cus-

tomers just after registering it into the content knowl-

edge authority. No assumption about information

schema and attributes names’ schemata should be

taken, so the community could easily grow up and

evolve.

We developed a system architecture where docu-

ments play the role of elementary information build-

ing block. We assumed that at least three main kind

of information compose a document, they are: a) the

content, i.e., the information to which it refers; b)

the metadata, i.e., the information about the contents;

c) the relations, i.e., the collection of relationships

that could be instantiated among the documents. We

also assumed that contents could be themselves doc-

uments, and then we can map the conceptual knowl-

edge graphs into the document network relationships.

Furthermore, document collection can be deﬁned as

graph that maps some instances of document rela-

tions, so we can associate a document to each collec-

tion. This recursive deﬁnition could be instantiated an

arbitrary number of times, although in practical cases

the recursion depth is not greater than three, i.e., doc-

ument, the recursion base case; the collections of doc-

uments; document repository, collections of collec-

tions; and a community i.e., a collection of document

repository.

From software point of view a document together

its components are represented as digital objects. The

digital object plays the role of handle to document

components that are encapsulated into digital objects.

To deploy this recursive deﬁnition process for the

knowledge entities we need software tools to ag-

gregate, both locally and remotely, the knowledge

sources.

We adopted a multi-tiers web architecture in

which the application server plays the central role of

business logic driver. Three main systems were iden-

tiﬁed: Document Repository System (DRS), that it is

in charge to store and organize the documents; the

Document Access System (DAS), to create friendly

and ﬂexible user interfaces to discover and access

contents; and the Contents Authority Management

System (CAMS), that store and manage the document

model schema used by each participating nodes so to

facilitate the DRS semantic oriented interoperability.

These systems communicate among them exchanging

XML encoded messages according to well-deﬁned

protocols.

One of the foreseen scenarios is sketched in Figure

1, where the community is built with three stakehold-

ers that manage heterogeneous information.

The end–user will interact with the knowledge

community through a conventional browser. DAS

is in charge for document access from the docu-

ment repositories community and for the composi-

tion process in order to delivery documents to the

end–users. Processing steps may be represented as

Figure 1: Heterogeneous data provider integration with Oc-

tapy based CMS.

A COOPERATIVE AND DISTRIBUTED CONTENT MANAGEMENT SYSTEM

141

sequence of transformations expressed, for example,

using the eXtensible Stylesheet Language Transfor-

mation (Mangano, 2005). To assemble a document

all its components and related ones must be fetched

from the community of document repositories. In or-

der to satisfy the partial instantiated document rela-

tionships the CAMS is invoked to ﬁlter, according to

the document repository schema, the repositories to

be involved on assembling the documents.

CAMS manages the document models expressed

in RDF/OWL (McGuinness D. and van Harmelen F.,

2003), since we don’t constrains managers to adopt

one common document model we associate to each

document model an “interpreter” that allow to remap,

for example, the values of metadata in some shared

knowledge space. These interpreters are used by

CMS nodes of the knowledge “community”, and de-

termines the pattern of interactions with other servers

(Mango Furnari M. et al., 2003).

Once the subset of the knowledge community

repository nodes is determined, each one is queried in

order to give back the related documents to be sent to

the DAS to complete the document assembling steps.

Next, the documents are assembled into HTML page

that will be directly sent to the browser.

The advantages of the whole proposed architec-

ture are: a) ease of deployment on Internet, high re-

liability and fault-tolerance, and efﬁcient use of the

network infrastructures; b) ﬂexibility and generality

as needed in order to evolve to meet future knowledge

stakeholder needs; c) scalability without fundamental

changes of resource name spaces.

Summarizing, to create a knowledge community

we need software systems and middleware having a

number of key features including:

• Support to semantic web technologies: it should

push semantic web technologies into CMS, allow-

ing interoperability with other systems. It should

use document models suitable for semantic ori-

ented interoperability.

• Extensible metadata management: the document

models should contain metadata to be used to ex-

press any type of digital collections membership,

parent-child or taxonomic relationships. More-

over, document repositories should be confor-

mant with metadata exchange protocols, such as

the Open Archive Initiative Protocol for Metadata

Harvesting (OAI-PMH, 2001).

• Multiple document representations: for each

managed document multiple representations it

should be available that must be adequate for user

and machine processing. Using the XML and

RDF widespread standards, documents could be

exchanged across different document repositories

even if they didn’t directly manage the model for

the transferred documents.

• Powerful component model: it should have a ﬂex-

ible software component model in order to make

easy the development of content-oriented exten-

sions. Extensions that should be generic and not

tightly coupled with the documents models.

In order to check the feasibility of the previously

described architecture we designed and implemented

the Octapy3 software platform, in which attention

is payed to the necessary document repository func-

tionalities so it could participate into a knowledge

community. In the next section the Octapy3 design

choices and its main components are described.

3 THE OCTAPY3 DISTRIBUTED

AND COOPERATIVE CMS

The main Octapy3’ functionalities are oriented to sup-

port: a) documents management and aggregation over

the network; and b) an easy to use and fast process in

order to deﬁne new document types. The way how

to deﬁne document types has been one of the most

intriguing aspect coped with on designing the soft-

ware platform. In fact, we need to describe docu-

ment and its components in such a way to be easily

processed in order to produce software modules that

manage them as digital objects. We approached this

problem deﬁning a document conﬁguration language,

called Octapy3 Content Markup Language (OCML), see

Section 3.2. With this language we can deﬁne the

document structure, the persistency, the presentation,

and so on. These functionalities are built on top of a

component model that could be easily extended. In

Octapy3, contents play a central role since they are

active parts of interoperability settlement among dif-

ferent systems. Contents aren’t only implemented as

data but are also active software components that ex-

pose a well-deﬁned API, that allow implementing dif-

ferent kind of end–user and machine oriented docu-

ments representations.

Octapy3 has been designed to bring functionali-

ties for content-based interoperability in order to cre-

ate knowledge communities of distributed contents

providers that share common knowledge. In Oc-

tapy3 the information sharing is achieved exchanging

documents, each document has multiple representa-

tions, the default one is called Octapy eXchange Format

(OXF), it is a serialization exposed by all digital ob-

ject through the IOctapyContent interface. OXF exports

both document contents and structures, i.e., the doc-

ICSOFT 2008 - International Conference on Software and Data Technologies

142

Figure 2: Heterogeneous data managed by Octapy based

CMSs

providers that share common knowledge. In Oc-

tapy3 the information sharing is achieved exchanging

documents, each document has multiple representa-

tions, the default one is called Octapy eXchange Format

(OXF), it is a serialization exposed by all digital ob-

ject through the IOctapyContent interface. OXF exports

both document contents and structures, i.e., the doc-

ument type deﬁnition. An OXF serialization allows

to implement and manage remote contents consider-

ing them as local contents, even in the case the CMS

doesn’t have, locally available, the deﬁnition of the

remote content type.

From an architecture point of view, Octapy3 have

been organized around three main application levels:

• Documents Deﬁnition Layer: it contains software

modules that add functionalities that simplify the

deﬁnition of new document types. In Octapy3

the document deﬁnition is carried out during the

conﬁguration phase. To pursue this goal XML-

based language Octapy Conﬁguration Markup Lan-

guage (OCML) was deﬁned and used to specify

both application and presentation logic.

• Content Components Layer: one of the main

goals of Octapy3 is to abstract from the content

structure introducing a clear separation among ap-

plication layers. Starting from content descrip-

tion, Octapy3 generates speciﬁc software com-

ponents, called “content component”, that repre-

sent the managed contents. These components ex-

pose interfaces used, for example, to manage doc-

uments structure and documents relationships.

• Distributed and Cooperative Layer: Octapy is

designed to build communities of cooperating

knowledge node providers. Therefore, special at-

tention has been paid to support standards for in-

teroperability, such as XML for data representa-

tion, RDF/RDFS (Lassila O., 1998) for semantic

interoperability, Dublin Core metadata set (DC,

1995), Open Archive Initiative protocol (OAI-

PMH, 2001) for metadata exchange among hete-

reogeneous systems.

To achieve these goals we developed Oc-

tapy3 adopting the Component Architecture of

the Zope3/Plone software platform (von Weiter-

shausen P., 2007). On top of this architecture we

ﬁrst developed the “content components” to imple-

ment the document type deﬁnition process, and next

the middleware to make location independent the doc-

ument process management.

In Octapy3 documents are implemented as

classes, more speciﬁcally the class OctapyContent im-

plements the document living only in each document

repository, i.e., locally. The classes RemoteObject and

OctapyProxy are used to manage, on a given repository

node, documents located in the rest of the knowledge

community nodes.

In the rest of this section we will describe the main

designed and implemented software components. We

start shortly summarizing the components that imple-

ment the “content component”. Next we focus on the

implementation of the distributed and interoperability

functionalities..

3.1 The Octapy3 content component

The Octapy3 platform is built using a Component Ar-

chitecture model mechanism, in particular for doc-

uments that are the community knowledge building

blocks. The Component Architecture make possi-

ble to abstract from the speciﬁc content schemata.

We developed a special Octapy3 component, called

“content components”, that it is in charge to auto-

matically generate software components starting from

document type description written using the OCML

language, see section 3.2 below. The software gener-

ation process is carried out using YODA (Yoda is Oc-

tapy Document Assembler) compiler that generates

both the archetype (von Weitershausen P., 2007) code

and the interfaces describing the document structure.

This interface is an enumeration of attributes for each

Content Type Description ﬁeld and the corresponding

archetype class that implements this interface, called

“content component”.

A content component implements, see Figure 3,

at least two interfaces: the content type deﬁnition and

the IOctapyInterface. This interface is generic in the

sense that it is common to all content components

and exposes the method getContentInteface() and

returns the interface describing the document content

type, i.e. it allows searching for a speciﬁc data inter-

face.

Octapy3 allows also handling and managing con-

tent type extensions in a generic way. An adapter,

to the ﬁxed interface IOctapyContent, could add the

Figure 2: Heterogeneous data managed by Octapy based

CMSs.

ument type deﬁnition. An OXF serialization allows

to implement and manage remote contents consider-

ing them as local contents, even in the case the CMS

doesn’t have, locally available, the deﬁnition of the

remote content type.

From an architecture point of view, Octapy3 have

been organized around three main application levels:

• Documents Deﬁnition Layer: it contains software

modules that add functionalities that simplify the

deﬁnition of new document types. In Octapy3

the document deﬁnition is carried out during the

conﬁguration phase. To pursue this goal XML-

based language Octapy Conﬁguration Markup Lan-

guage (OCML) was deﬁned and used to specify

both application and presentation logic.

• Content Components Layer: one of the main

goals of Octapy3 is to abstract from the content

structure introducing a clear separation among ap-

plication layers. Starting from content descrip-

tion, Octapy3 generates speciﬁc software com-

ponents, called “content component”, that repre-

sent the managed contents. These components ex-

pose interfaces used, for example, to manage doc-

uments structure and documents relationships.

• Distributed and Cooperative Layer: Octapy is

designed to build communities of cooperating

knowledge node providers. Therefore, special at-

tention has been paid to support standards for in-

teroperability, such as XML for data representa-

tion, RDF/RDFS (Lassila O., 1998) for semantic

interoperability, Dublin Core metadata set (DC,

1995), Open Archive Initiative protocol (OAI-

PMH, 2001) for metadata exchange among hete-

reogeneous systems.

To achieve these goals we developed Oc-

tapy3 adopting the Component Architecture of

the Zope3/Plone software platform (von Weiter-

shausen P., 2007). On top of this architecture we

ﬁrst developed the “content components” to imple-

ment the document type deﬁnition process, and next

the middleware to make location independent the doc-

ument process management.

In Octapy3 documents are implemented as

classes, more speciﬁcally the class OctapyContent im-

plements the document living only in each document

repository, i.e., locally. The classes RemoteObject and

OctapyProxy are used to manage, on a given repository

node, documents located in the rest of the knowledge

community nodes.

In the rest of this section we will describe the main

designed and implemented software components. We

start shortly summarizing the components that imple-

ment the “content component”. Next we focus on the

implementation of the distributed and interoperability

functionalities..

3.1 The Octapy3 Content Component

The Octapy3 platform is built using a Component Ar-

chitecture model mechanism, in particular for doc-

uments that are the community knowledge building

blocks. The Component Architecture make possi-

ble to abstract from the speciﬁc content schemata.

We developed a special Octapy3 component, called

“content components”, that it is in charge to auto-

matically generate software components starting from

document type description written using the OCML

language, see section 3.2 below. The software gener-

ation process is carried out using YODA (Yoda is Oc-

tapy Document Assembler) compiler that generates

both the archetype (von Weitershausen P., 2007) code

and the interfaces describing the document structure.

This interface is an enumeration of attributes for each

Content Type Description ﬁeld and the corresponding

archetype class that implements this interface, called

“content component”.

Figure 3: The Octapy component model.

A COOPERATIVE AND DISTRIBUTED CONTENT MANAGEMENT SYSTEM

143

A content component implements, see Figure 3,

at least two interfaces: the content type deﬁnition and

the IOctapyInterface. This interface is generic in the

sense that it is common to all content components

and exposes the method getContentInteface() and

returns the interface describing the document content

type, i.e. it allows searching for a speciﬁc data inter-

face.

Octapy3 allows also handling and managing con-

tent type extensions in a generic way. An adapter,

to the ﬁxed interface IOctapyContent, could add the

required functionalities to the Octapy3 system. For

example, a presentation interfaces can be built us-

ing Browser Pages component that adapts the interface

IOctapyContent and accesses the content interface via

getContentInterface() method. Furthermore, it is

also possible to write extension module for a given

data schemata adapting only the generated content

component interfaces.

3.2 The Octapy3 Conﬁguration

Mark-up Language

In order to extend, during the CMS conﬁguration

phase, the types of the managed contents we deﬁned

a speciﬁc document conﬁguration language, called

OCML. It allows: to deﬁne new document types; to

choose documents storage methods for each docu-

ment or some of its parts; to assign some sort of se-

mantics to the document components associating spe-

ciﬁc interpreters; and to assign user presentation logic

for each content types.

OCML is a command–oriented language whose

syntax is inherited from XML. The commands are

represented as set of XML tags, called directives, and

are grouped in three main XML vocabulary identiﬁed

by the XML namespaces: data, storage and view. A

command interpreter may be associated to each direc-

tives in order to assign a speciﬁc operational semantic.

The data directives allow deﬁning new content

types and express the parent-child relationship among

documents. A new content type is deﬁned using

data:document directives, and the data:field direc-

tives associate to them a structure. Fields can be logi-

cally grouped using data:section directives. For ex-

ample, documents can be composed (nested) to form

hierarchical structures instantiating the containment

relation “is-composed-by” and the corresponding “is-

part-of”. A document could also contain other docu-

ments describing the containerish document type.

The storage directives associate a speciﬁc stor-

age mechanism to a document or to some of its parts.

For example, suppose that a structured document,

called ArtisticObject was deﬁned, and that among its

ﬁelds there is one, called image, to which is asso-

ciated a jpeg digital picture. Then the document may

have database persistence for all its ﬁelds except for

the image ﬁeld whose persistence could be in a local

ﬁlesystem.

The view directives associate one o more ways to

present documents to the end–users. It’s possible to

deﬁne which widget to use in order to display the doc-

ument ﬁeld. Two directives can be used to cover this

operation: view:for, used to specify the widget to be

associated to a speciﬁc ﬁeld; and view:fordata used

to specify the widget to be associated to a given ﬁeld

type (e.g. Text, Image, etc).

OCML documents speciﬁcation may also be split

on multiple ﬁles using the special directive <include

src=‘‘filename’’/>. More details on OCML can be

found in (Acampa P. and Noviello C. , 2007).

3.3 The Metadata Attribute of

Document Models

The content collection of ﬁelds of the application data

layer have, in general, no associated meaning, since

they are considered only containers for “values” and

used to store ﬁxed data. This information is, in gen-

eral, interpreted as expressed by a pair of a name and

uninterpreted values. Nevertheless, in order to be se-

mantic oriented an interpreted value must be assigned

to a metadata name, i.e., it is necessary to make ex-

plicit both the domain from which the values are cho-

sen and the valuation function (interpreter) used to as-

sign a meaning. In a such semantic oriented scenario

it is possible to deﬁne ArtisticObject content type whose

ﬁelds oss and title are not only simply container for

lines of text, but it is also possible to associate mean-

ings that depend on the context. For example, the ﬁeld

oss may be interpreted as the description of an Artistic

Object in one context and as picture caption in another

context, with a different formatting and typesetting.

This means that a document, or part of it, can have

special interpretation that must be correctly handled

by the software.

In OCML the metadata attribute of the directive

data:field has been introduced, whose values

can be used to specify which interpretation model

has to be associated to a ﬁeld. For example, the

value: <data:field name="oss " type="Text"

metadata="{uiuse:description}"/> instructs the

presentation layer, where the ﬁeld is used, that

the ﬁeld oss must be interpreted as the Artistic

Object ﬁeld description, and therefore it must be

correspondently processed.

The values of metadata attribute are transparent

to the data and other application layers: only com-

ICSOFT 2008 - International Conference on Software and Data Technologies

144

ponents that know how process it will use this infor-

mation.

The interpretation model is implemented anno-

tating the document component model attributes

and methods with tags. The YODA generated

content interfaces are annotated with the infor-

mation provided by the metadata attribute using

setTaggedValue() method. Extension modules can

access this information through metadata attribute us-

ing the getTaggedValue() method.

It is important to underline that interpretation

models are not only used to implement the presen-

tation logic, but that may be also used whenever it

is necessary to associate a special meaning to a ﬁeld,

some sort of metadata cross-walk. For example, the

Octapy3 Dublin Core subsystem uses metadata at-

tribute to map ﬁelds name to the DC metadata set,

as shown in the following example:

...

<data:field name="descrizione_breve"

type="Text" metadata="{dc:title}"/>

<data:field name="autore_scheda"

type="Text" metadata="{dc:author}"/>

...

In the next section the Octapy3 test bed and the

experience gained operating it are shortly described

over a knowledge community of about 100 Octapy3

nodes.

3.4 Cooperation and Interoperability

Components

To make effective the cooperation and to share

documents across documents stakeholders, Octapy3

makes available different machines “understandable”

document representations. Some of them are oriented

to semantic web and are based on RDF/RDFS lan-

guage and derivatives; others are oriented to facilitate

the interoperability using standard protocol for meta-

data sharing, like the OAI-PMH protocol. Figure 4

shows the OAI Octapy subsystem components inter-

action, more information can be found in (Noviello,

2007).

In Octapy3 every containers implements the IOc-

tapyContainer interface and all remote contents (docu-

ments and/or aggregates) implements the IOctapyProxy

marker interface, i.e., those objects act as proxy for

remote contents. Documents and their aggregates can

be exported and/or aggregated in other CMS nodes

using the RemoteContainer class. A RemoteObject spe-

cial base class, called OctapyProxy, manages the con-

tent interface creation, starting from the information

provided by OXF serialization. All the document in-

terpretation models are properly added so presenta-

tion layer and other modules can correctly process

them.

Figure 4: The integration of a OAI data provider in a Octapy

based CMS.

4 THE MUSEO VIRTUALE TEST

BED

The aim of any ordinary museum visitor is some-

thing quite different from trying to ﬁnd certain ob-

jects. In physical exhibitions, the cognitive museum

experience is often based on both thematic combina-

tion of exhibits and their contextual information. To

foster the museums cooperation software tools were

developed to aggregate, both locally and remotely, the

knowledge about cultural heritage goods. Using these

tools the knowledge stakeholders could organize vir-

tual exhibitions according to some physical or logical

criteria either in the case either the information is di-

rectly managed or shared with other stakeholders.

The information provider

could also organize a

set of related documents, as document collections, ac-

cording to some relationships.

To assure the necessary museum manager ope-

rational autonomy, without reducing the cooperation

opportunities, we deployed a cooperation schema as

intermediate coordination organization that it is in

charge to register, syndicate and guarantee the qual-

ity of document contents.

From technical point of view the main goal pur-

sued with this test bed was to concretely verify the

In this paper we assumed that museum manager means

the responsible, inside the museum organization, of the cul-

tural heritage goods information.

A COOPERATIVE AND DISTRIBUTED CONTENT MANAGEMENT SYSTEM

145

possibility to create knowledge cooperating commu-

nities. Where each participating museums could ex-

change its own managed knowledge so to improve

their institutional cooperation.

Figure 5: The organization of

campaniabeniculturali.it knowledge community.

Figure 6: The content integration of the cultural heritage

heterogeneous knowledge.

Currently more than 100 Octapy3 nodes, spread

over the geographic region of Campania, are orga-

nized in knowledge clouds, each cloud covers the ter-

ritories around the main cities of Campania, i.e. Ben-

evento, Salerno, Caserta and Avellino. The cultural

heritage knowledge offering is organized according

thematic topics, such as the ﬁrst civilizations in Cam-

pania, the Roman civilization periods, the Gran Tour

period and so on.

From the museum managers’ perspective each in-

formation system allows him to make available the

managed artifacts’ information through the Octapy3

node, where no assumption about ﬁxed attributes

names’ schemata is taken, so the application builder

can create new attributes, as needed just modifying

the associated document interpretation model without

changing the internal CMS schemata.

Since the software allows exchanging the contents

through the OAI-PMH then the circuit itself is in-

cluded in the Italian cultural heritage portal.

5 CONCLUSIONS

One of the most interesting technological aspects in-

vestigated and described in this paper was how to

improve the document repositories systems ﬂexibility

to organize cultural heritage etherogeneous informa-

tion spread in many autonomous organizations. To

achieve this goal we developed, ﬁrst of all, a doc-

ument markup language to describe both document

contents and then the corresponding software com-

ponents devoted to manage the document life cy-

cle. Next, we developed a middleware layer that

make transparent the document physical location into

a “knowledge community network” to easily share

document metadata. On doing so, each museum

document repositories may have different conceptual

schemas, and no assumption about a ﬁxed attribute

names schemata are taken, so museum manager can

create new attributes as needed just modifying the as-

sociated OCML document type description without

change neither the internal software component nor

database schemata.

The information provider could also organize a set

of related document in document collections accord-

ing to some relationships deﬁned using the document

container type with an arbitrary nesting level. With

this feature the museum manager could deﬁne collec-

tion of cultural heritage description that contain inside

other collections descriptions. Each digital document

could belong to multiple collections and have mul-

tiple relationships with other documents. This nest-

ing feature forms the document repository collection

graph, and allow to deliver more than one logical view

of a given digital documents asset.

Our work successfully showed that Octapy3 could

be used as document repository backend for dis-

tributed CMSs, together the central role played by the

cooperation middleware on deploying such kind of

systems. With this type of CMS we could overcome

some limitations suffered by the system described

in (Aiello A. et al., 2005), (Aiello A. et al., 2006).

ICSOFT 2008 - International Conference on Software and Data Technologies

146

Where a “cultural heritage knowledge community in-

frastructure” was build around the use of an ontology

to glue distributed document repositories. Reposito-

ries that didn’t gave good performances when used in

conjunction with a reasoning component. That was

especially true on increasing both the number of doc-

uments and CMS nodes.

We have plans to extend Octapy3 to manage

document schema and document exchange using

RDFS/RDF representations to actively pursue some

of the foreseen goals off semantic web technolo-

gies (Berners-Lee T., 1996), (Jena, 2004), (Horrocks

I., 2002) in a distributed settlement. For exam-

ple, we foresee the possibility to exploit pieces of

well-known and supported ontology fragments, like

ICOM-CIDOC (CIDOC, 1999). Fragment to be spe-

cialized for each different knowledge providers in or-

der to contain the computational complexity on using

ontologies in real cases.

ACKNOWLEDGEMENTS

Acknowledgments are expressed to all members of

Advanced Information System research group team of

Istituto di Cibernetica E. Caianiello that contributed to

the Octapy3 paltform, for their help, and fruitful dis-

cussions. Also to the staff members of the Soprinten-

denza ai Beni Archeologici delle Province di Napoli

e Caserta, Soprintendenza ai beni Artistici, Storici e

Demo Antropologici della Provincia di Napoli, So-

printenda ai Beni Architettonici ed Ambientali della

Provincia di Napoli, Archivio di Stato di Napoli,

a special gratitude must be expressed since without

their assistance the experimental activities and results

would not exist

REFERENCES

Acampa P. and Noviello C. (2007). Speciﬁca ocml, tech-

nical sheet octapy cms. Technical report, Istituto di

CIbernetica.

Aiello A., M. Mango Furnari M., and Massarotti A. (2005).

A distributed multimedia information system for cul-

tural heritage identity preservation. Transaction on In-

ternet Research, pages 11–17.

Aiello A., M. Mango Furnari M., Massarotti A., Caputo V.,

B., and Barone V. (2006). An experimental ontology

server for an information grid environment. Int. Jour-

nal on Parallel Programming, pages 489–508.

Berners-Lee T. (1996). Www: Past, present, and future.

IEEE Computer, 29:69–77.

CIDOC (1999). Icom/cidoc documentation standard group,

revised deﬁnition of the cidoc conceptual reference

model

http://cidoc.ics.forth.gr/.

DC (1995). The dublin core metadata initiative

http://www.purl.org/dc/.

Horrocks I., T. (2002). Querying the semantic web: a for-

mal approach. In Horrocks, I. and Hendler J, edi-

tors, The 1

International Semantic Web Conference

- ISWC2002, volume 2342 of Lecture Notes in Com-

puter Science, pages 177–191. Springer Verlag.

Jena (2004). Jena-a semantic web framework for java

http://www.hpl.hp.com/seweb/. Technical report,

HP Labs Semantic Web Research.

Lassila O., R. S. (1998). Resource description framework

(rdf) model and syntax. Technical report, World Wide

Consortium Working Draft.

Mangano, S. (2005). XSLT Cookbook. O’Reilly, 2nd edi-

tion.

Mango Furnari M., Aiello A., Caputo V., and Barone V.

(2003). Ontology server protocol speciﬁcation. Tech-

nical report, ICIB TR-12/03.

McGuinness D. and van Harmelen F. (2003). Owl web on-

tology language overview. Technical report, W3C.

Noviello, C. (2007). Il component-model di octapy 3, tech-

nical sheet octapy cms. Technical report, Istituto di

Cibernetica.

OAI-PMH (2001). Open archives initiative.

von Weitershausen P. (2007). Web Component Development

with Zope 3. Springer Verlag, New York, 2nd edition.

A COOPERATIVE AND DISTRIBUTED CONTENT MANAGEMENT SYSTEM

147
