ON THE DETECTION OF NOVEL ATTACKS USING BEHAVIORAL
APPROACHES
Benferhat Salem and Tabia Karim
CRIL-CNRS UMR8188, Universit´e d’Artois, Rue Jean Souvraz 62307 Lens Cedex, France
Keywords:
Intrusion detection, behavioral approaches, Bayesian networks.
Abstract:
During last years, behavioral approaches, representing normal/abnormal activities, have been widely used in
intrusion detection. However, they are ineffective for detecting novel attacks involving new behaviors. This
paper first analyzes and explains this recurring problem due on one hand to inadequate handling of anoma-
lous and unusual audit events and on other hand to insufficient decision rules which do not meet behavioral
approach objectives. We then propose to enhance the standard classification rules in order to fit behavioral
approach requirements and detect novel attacks. Experimental studies carried out on real and simulated http
traffic show that these enhanced decision rules allow to detect most novel attacks without triggering higher
false alarm rates.
1 INTRODUCTION
Intrusion detection aims at detecting any mali-
cious action compromising integrity, confidentiality
or availability of computer and network resources or
services (Axelsson, 2000). Intrusion detection sys-
tems (IDSs) are either misuse-based (Snort, 2002)
or anomaly-based (Neumann and Porras, 1999) or a
combination of both the approaches in order to ex-
ploit their mutual complementarities (Tombini et al.,
2004). Behavioral approaches, which are variants of
anomaly-based approaches, build profiles represent-
ing normal and abnormal behaviors and detect in-
trusions by comparing system activities with learnt
profiles. The main advantage of these approaches
lies their capacity to detect both known and novel at-
tacks. However, there is no behavioral approach en-
suring acceptable tradeoff between novel attack de-
tection and underlying false alarm rate.
Intrusion detection can be viewed as a classification
problem in order to classify audit events (network
packets, Web server logs, system logs, etc.) as nor-
mal events or attacks (Lee, 1999). During last years,
several works used classifiers in intrusion detection
(Kruegel et al., 2003)(Sebyala et al., 2002)(Valdes
and Skinner, 2000) and achieved acceptable detection
rates on well-known benchmarks such as KDD’99
(Lee, 1999), Darpa’99 (Lippmann et al., 2000). The
recurring problem with the majority of classifiers is
their high false negative rates mostly caused by the
incapacity to correctly classify novel attacks (Elkan,
2000)(Lee, 1999). For instance, in (Benferhat and
Tabia, 2005)(Barbar´a et al., 2001), decision trees and
variants of Bayes classifiers are used to classify net-
work connections and concluded that their main prob-
lem lies in their failure to detect novel attacks which
they classify normal connections.
In this paper, we first analyze and explain the prob-
lem of high false negative rates and classifiers in-
capacity to correctly classify new malicious behav-
iors. We illustrate our approach with Bayesian clas-
sifiers. We first focus on how new behaviors affect
and manifest through a given feature set. Then we ex-
plain why standard classification rules fail in detect-
ing these new events. Different possibilities are con-
sidered and discussed. More precisely, we consider
on one hand problems related to handling unusual and
new behaviors and on other hand problems due to in-
sufficient decision rules which do not meet anomaly
detection requirements. After that, we propose to en-
hance standard classification rules in order to improve
detecting novel attacks involving abnormal behaviors.
Experimental studies on real and simulated http traf-
fic are carried out to evaluate the effectiveness of the
new decision rules in detecting new intrusive behav-
iors. Two variants of Bayesian classifiers using the
enhanced classification rule are trained on real normal
http traffic and several Web attacks. Then we evalu-
265
Salem B. and Karim T. (2008).
ON THE DETECTION OF NOVEL ATTACKS USING BEHAVIORAL APPROACHES.
In Proceedings of the Third International Conference on Software and Data Technologies - PL/DPS/KE, pages 265-272
DOI: 10.5220/0001894302650272
Copyright
c
SciTePress
ated these classifiers on known and novel attacks as
well new normal behaviors.
2 BEHAVIORAL APPROACH FOR
BOTH NORMAL AND
ABNORMAL BEHAVIORS
Behavioral approaches build models or profiles rep-
resenting normal and abnormal activities and detect
intrusions by computing deviations of current sys-
tem activities form reference profiles. Behavioral ap-
proaches are like anomaly detection ones except that
profiles are defined for both normal and abnormal be-
haviors while in anomaly approaches, only normal
behaviors are profiled(Axelsson, 2000). For instance,
every significant deviation from normal behavior pro-
files may be interpreted as an intrusion since it rep-
resents an anomalous behavior. The main advantage
of anomaly approaches lies in their potential capac-
ity to detect both new and unknown (previously un-
seen) attacks as well as known ones. This is particu-
larly critical since new attacks appear every day and
it often takes several days between the apparition of
a new attack and updating signature data bases or fix-
ing/correcting the exploit.
Within anomaly detection approaches, the detection
of novel attacks has several negative side effects
which concern triggering very high false alarm rates.
This drawback seriously limits there use in real ap-
plications. In fact, configuring anomaly-based IDSs
to acceptable false alarm rates cause their failure in
detecting most malicious behaviors. In (Kumar and
Spafford, 1994), authors pointed out that intrusive
activities used to extract signatures or train detec-
tion systems are a subset of anomalous behaviors and
identified four audit event possibilities with non zero
probabilities:
Intrusive but Not Anomalous (False Negative).
They are attacks where input data do not catch any
anomalous evidence. This usually due to feature
extraction problem. Therefore, new attacks often
require supplementary features and data in order
to be detected.
Not Intrusive but Anomalous (False Positive).
Commonly called false alarms, these events are
legitimate but new. Consequently, they signifi-
cantly deviate from normal events profile. This
problem requires updating normal profiles in or-
der to integrate such new normal behaviors.
Not Intrusive and Not Anomalous (True Nega-
tive). They correspond to known normal events.
Intrusive and Anomalous (True Positive). Such
events correspond to attacks where intrusive evi-
dence is caught by input data.
In the following, we particularly focus on behavioral
approaches failure to detect novel attacks involving
abnormal behaviors and enhancing standard decision
rules in order to detect these novel attacks.
3 WHY STANDARD
CLASSIFICATION RULES ARE
INEFFECTIVE FOR
DETECTING NOVEL ATTACKS
Behavioral approaches can be viewed as classifiers
which are mapping functions from a discrete or con-
tinuous feature space (observed variables A
0
= a
0
,
A
1
= a
1
, .., A
n
= a
n
) to a discrete set of class labels
C={c
1
, c
2
,..,c
m
}. Once a classifier is built on labeled
training data, it can classify any new instance. The
goal of classification is to maximize the generaliza-
tion ability to correctly classify unseen instances. De-
cision trees(Quinlan, 1986) and Bayesian classifiers
(Friedman et al., 1997) are well-known classification
algorithms.
In intrusion detection, each instance to classify rep-
resents an audit event (network packet, connection,
application log record, etc.). In order to analyze stan-
dard classification rules incapacity to detect novel at-
tacks, we first focus on how novel attacks involving
new behaviors affect feature sets which provide input
data to be analyzed.
3.1 How Novel Attacks Affect Feature
Sets
The following are different possibilities about how
new anomalous events affect and manifest through
feature sets:
1. New Value(s) in a Feature(s). A never seen
1
value is anomalous and it is due in most cases
to a malicious event. For example, Web server
response codes are from a fixed set of prede-
fined values (ex. 200, 404, 500...). If a new re-
sponse code or any other response is observed,
then this constitutes an anomalous event. For in-
stance, successful shell code attacks cause server
response without a common code. Similarly, a
1
By never seen value we mean new value in case of
nominal features or very deviating value in case of numeri-
cal features.
ICSOFT 2008 - International Conference on Software and Data Technologies
266
new network service using a new and uncom-
mon port number is probably intrusive since most
back-door attacks communicate through uncom-
mon ports while common services are associated
with common port numbers.
2. New Combination of Known Values. In normal
audit events, there are correlations and relation-
ships between features. Then an anomalous event
can be in the form of a never seen combination
of normal values. For example, in some http re-
quests, numerical values are often provided as pa-
rameters. The same values which are correctly
handled by a given program, can in other con-
texts cause value misinterpretations and result in
anomalous behaviors. Another example from net-
work intrusion field is when a network service like
http uses uncommon transport protocol likeUDP.
Both http and UDP are common protocols in net-
work traffic. However,http service uses TCP pro-
tocol at the transport layer and never UDP, then
http using UDP is anomalous event.
3. New Sequence of Events. There are several nor-
mal audit events which show sequence patterns.
For example, in on-line marketing applications,
users are first authenticated using https protocol
for confidential data transfers. Then a user session
beginning without https authentication is proba-
bly intrusive since the application control flow has
not been followed. Such intrusive evidence can
be caught by history features summarizing past
events or by using appropriate mining anomaly
sequence patterns algorithms.
4. No Anomalous Evidence. In this case, new
anomalous events do not result in any unseen ev-
idence. The underlying problem here is related to
feature extraction and selection since not enough
data is used for catching the anomalous evidence.
In principle, the three first possibilities can be de-
tected since intrusive behavior evidence had appeared
in the feature set. However, anomalous audit event of
fourth case can not be detected for lack of any anoma-
lous evidence in the audit event.
3.2 Why Novel Attacks Cause False
Negatives
Novel attacks often involve new behaviors. However,
in spite of these anomalousness evidence in the fea-
ture set, most classifiers flag novel attacks as normal
events. This failure is mainly due to the following
problems:
1. Inadequate Handling of New and unusual Events.
New and unusual values or value combinations
are often involved by novel attacks. How-
ever, most classifiers handle such evidence inad-
equately regarding anomaly detection objectives.
For instance, in Bayesian classifiers (Friedman
et al., 1997), new values cause zero probabili-
ties which most implementations replace with ex-
tremely small values and rely on remaining fea-
tures in order to classify the instance in hand. De-
cision trees (Quinlan, 1986), which are very ef-
ficient classifiers, often use few features in order
to classify audit events. Therefore, if the anoma-
lous evidence (abnormal values or value combina-
tions) appears in a feature which is not used, then
this evidence is not used. Other techniques suffer
from other problems such as incapacity to handle
categorical features which are common in intru-
sion detection (Shyu et al., 2005).
2. Insufficient decision rules: The objective of stan-
dard classification rules is to maximize classify-
ing previously unseen instances relying on known
(training) behaviors. However, unseen behav-
iors which should be flagged abnormal according
to anomaly approach, are associated with known
behavior classes. For instance, when decision
trees classify instances, new behaviors such as
new values are assigned to the majority class at
the test where the new value is encountered. As
for Bayesian classifiers, they rely only on like-
lihood and prior probabilities to ensure classifi-
cation. This strongly penalize detection of new
and unusual behaviors in favor of frequent and
common behaviors. Given that normal data of-
ten represent major part of training data sets (Lee,
1999)(Lippmann et al., 2000), standard classifica-
tion rules fail in detecting novel attacks involving
new behaviors and flag them in most cases normal
events.
In the following, we will basically focus on
Bayesian networks as an example of behavioral ap-
proaches. This choice is motivated by the fact that
they are among most effective techniques and because
of their capacity to handle both numeric and categori-
cal features which are common in intrusion detection
(Shyu et al., 2005). Furthermore, in comparison with
other classifiers, main advantage of Bayesian ones for
detecting anomalous behaviors lies in using all the
features and feature dependencies.
ON THE DETECTION OF NOVEL ATTACKS USING BEHAVIORAL APPROACHES
267
4 ENHANCING STANDARD
CLASSIFICATION RULES
In order to overcome standard classification rules
drawbacks, we propose enhancing them in order to
fit behavioral approach requirements.
4.1 Standard Bayesian Classification
Bayesian classification is a particular kind of
Bayesian inference (Friedman et al., 1997). Classi-
fication is ensured by computing the greatest a pos-
teriori probability of the class variable given an at-
tribute vector. Namely, having an attribute vector A
(observed variables A
0
= a
0
, A
1
= a
1
, .., A
n
= a
n
),
it is required to find the most plausible class value c
k
(c
k
C={c
1
, c
2
,..,c
m
}) for this observation. The class
c
k
associated to A is the class with the most a posteri-
ori probability p(c
k
/A). Then Bayesian classification
rule can be written as follows:
Class = argmax
c
k
C
(p(c
i
/A)) (1)
Term p(c
i
/A) denotes the posterior probability of
having class c
i
given the evidence A. This probability
is computed using Bayes rule as follows:
p(c
i
/A) =
p(A/c
i
) p(c
i
)
p(A)
(2)
In practice, the denominator of Equation 2 is ignored
because it does not depend on the different classes.
Equation 2 means that posterior probability is pro-
portional to likelihood and prior probabilities while
evidence probability is just a normalizing constant.
Naive Bayes classifier assumes that features are inde-
pendent in the class variable context. This assumption
leads to the following formula
p(c
i
/A) =
p(a
1
/c
i
) p(a
2
/c
i
)..p(a
n
/c
i
) p(c
i
)
p(A)
(3)
In the other Bayesian classifiers such as TAN (Tree
Augmented Naive Bayes), BAN (Augmented Naive
Bayes) and GBN (General Bayes Network) (Fried-
man et al., 1997), Equation 2 takes into account fea-
ture dependencies in computing conditional probabil-
ities as it is denoted in Equation 4.
p(c
i
/A) =
p(a
1
/Pa(a
1
)) .. p(a
n
/Pa(a
n
)) p(c
i
)
p(A)
(4)
Note that terms Pa(a
i
) in Equation 4 denote parents
of feature a
i
.
Bayesian classifiers have been widely used in intru-
sion detection. For instance, in (Valdes and Skinner,
2000), naive Bayes classifier is used to detect mali-
cious audit events while in (Kruegel et al., 2003), au-
thors use Bayesian classification in order to improve
the aggregation of different anomaly detection model
outputs.
4.2 Enhancing Standard Bayesian
Classification for Anomaly
Detection
Bayesian classification lies on posterior probabilities
given the evidence to classify (according to Equations
1 and 2). The normality associated with audit event E
(observed variables E
0
= e
0
, E
1
= e
1
, .., E
n
= e
n
) can
be measured by posterior probability p(Normal/E).
This measure is proportional to the likelihood of E in
Normal class and prior probability of Normal class.
In practice, normality can not be directly inferred
from probability p(Normal/E) because this proba-
bility is biased. For instance, major Bayesian clas-
sifier implementations ignore denominator of Equa-
tion 2 while zero probability and floating point un-
derflow problems are handled heuristically. Assume
for instance that a never seen value had appeared in a
nominal feature e
i
. Then according to Equation 2, the
probability p(e
i
/c
k
) equals zero over all classes c
k
. In
practice, it is an extremely small value that is assigned
to this probability. The strategy of assigning non zero
probabilities in case of new values is to use remain-
ing features and prior probabilities in order to classify
the instance in hand. The other problem consists in
floating point underflow which is caused by multiply-
ing several small probabilities each varying between
0 and 1. This case is often handled by fixing a lower
limit when multiplying probabilities.
4.2.1 Using Normality/Abnormality Duality
Anomaly-based systems flag audit events ”Normal”
or ”Abnormal” according to a computed normality
degree associated with each audit event. Having
two scaled functions computing respectively normal-
ity and abnormality relative to audit event E then
these two functions are dual. Namely, this propriety
can be formulated as follows:
Normality(E) + Abnormality(E) = constant (5)
The intuitive interpretation of this propriety is more
an event is normal, less it is abnormal. Conversely,
less normal is the event, it is more abnormal. Trans-
lated in probability terms, Equation 5 gives the fol-
lowing propriety:
P(Normal/E) + P(Abnormal/E) = 1 (6)
Term P(Normal/E) (resp. P(Abnormal/E)) denotes
the probability that audit event E is normal (resp. ab-
normal). Bayesian classifiers associate a probability
distribution with the instance to classify (audit event)
and return the class having the utmost posterior prob-
ability. Let us assume for instance that training data
ICSOFT 2008 - International Conference on Software and Data Technologies
268
involve normal data (with class label Normal) and
several attack categories (labeled Attack
1
, Attack
2
,..,
Attack
n
). Consider the case when p(Normal/E) is
greater than all posterior probabilities p(Attack
1
/E),
..., p(Attack
n
/E). In this case, standard Bayesian
rule, will return Normal class according to Equation
1. However, if
p(Normal/E) < (p(Attack
1
/E) + .. + p(Attack
n
/E))
Then according to Equation 6, the probability that
audit event E is abnormal is 1-(p(Normal/E)). In-
tuitively, this audit event should be flagged anoma-
lous. We accordingly propose to enhance standard
Bayesian rule as follows:
Rule 1
If p(Normal/E) < (
(p(c
k
6= Normal/E))
then Class = argmax
c
k
C
(p(c
k
6= Normal/E)
else Class = argmax
c
k
C
(p(c
k
/E))
Rule 1 enhances standard Bayesian classifica-
tion rule in order to take into account normal-
ity/abnormality duality relative to audit events. Un-
like standard Bayesian classification rule, Equation
7 first compares normality with abnormality relative
to audit event E and returns Normal only when the
posterior probability p(Normal/E) is greater than the
sum of posterior probabilities p(Attack
i
/E). When
abnormality is more important, this rule returns the
attack having the utmost posterior probability.
4.2.2 Using Zero Probabilities as Abnormal
Evidence
Anomalous audit events can affect the feature set
either by new values, new value combinations or
new audit event sequences. Then classifying anoma-
lous events strongly depends on how zero probabil-
ity and floating point underflow problems are dealt
with. However, since a zero probability is due to
new (hence anomalous) value, then this is anomalous-
ness evidence. The underlying interpretation is that
instance to classify involves a never seen evidence.
Then anomaly approach should flag this audit event
anomalous. Similarly, an extremely small a posteriori
probability can be interpreted as a very unusual event,
hence anomalous. Then, standard Bayesian classifica-
tion rule can accordinglybe enhancedin the following
way:
If there is a feature e
i
where probability p(e
i
/c
k
)
equals zero over all training classes, then this is a
new value (never seen in training data). Enhanced
Bayesian classification rule can be formulated as
follows:
Rule 2
If e
i
, k, p(e
i
/c
k
) = 0 then Class = New
else Class = argmax
c
k
C
(p(c
k
/E))
New intrusive behaviors can be in the form of un-
seen combination of seen values. In this case, fea-
ture dependencies must be used in order to reveal
such anomalousness. Since new value combi-
nations will cause zero conditional probabilities,
then this anomalous evidence can be formulated
as follows:
Rule 3
If e
i
, p(e
i
/Pa(e
i
)) = 0 then Class = New
else Class = argmax
c
k
C
(p(c
k
/E))
Note that when building Bayesian classifiers,
structure learning algorithms extract feature de-
pendencies from training data. Then there may
be unseen value combinations that can not be de-
tected if the corresponding dependencies are not
extracted during structure learning phase.
4.2.3 Using Likelihood of Rare Attacks as
Abnormal Evidence
When training classifiers, some attacks have often
very small frequencies in training data sets. The prob-
lem with such prior probabilities is to strongly penal-
ize the corresponding attacks likelihood. This prob-
lem was pointed out in (Ben-Amor et al., 2003) where
authors proposed simple duplication of weak classes
in order to enhance their prior probabilities. An alter-
native solution is to exploit likelihood of audit events
as if training classes (Normal, Attack
1
, .., Attack
n
)
were equiprobable. Assume for instance intrusive au-
dit event E is likely to be an attack (for example, like-
lihood p(E/Attack
j
) is the most important). Because
of the negligible prior probability of Attack
j
, poste-
rior probability p(Attack
j
/E) will be extremely small
while p(Normal/E) can be significant since Normal
class prior probability is important. Then we can rely
on likelihood in order to detect attacks with small fre-
quencies:
Rule 4
If Attack
j
, k, p(E/Attack
j
) >= p(E/c
k
) and
p(Normal/E) > P(Attack
j
/E) and p(Attack
j
) < ε
then Class = Attack
j
else Class = argmax
c
k
C
(p(c
k
/E))
ON THE DETECTION OF NOVEL ATTACKS USING BEHAVIORAL APPROACHES
269
Rule 4 is provided in order to help detecting
anomalous events with best likelihood in attacks hav-
ing extremely small prior probabilities (p(Attack
j
) <
ε). It will be applied only if the proportion of in-
stances of Attack
j
in training data is less than thresh-
old ε fixed by the expert.
Note that the standard classification rule (see Equa-
tion 1) is applied only when Rules 1, 2, 3 and 4 can
not be applied.
5 EXPERIMENTAL STUDIES
In this section, we provideexperimentalstudies of our
enhanced Bayesian classification rule on http traffic
including normal real data and several Web attacks.
Before giving further details, we first present training
and testing data then we report evaluation results of
naiveBayes and Tree Augmented naive Bayes (TAN),
the two Bayesian classifiers we used in the following
experimentations.
5.1 Training and Testing Data Sets
We carried out experimentations on a real hhtp traf-
fic collected on a University campus during 2007. We
extracted http traffic and preprocessed it into connec-
tion records using only packet payloads. Each http
connection is characterized by four feature categories:
Request General Features providing general in-
formation on http requests. Examples of such fea-
tures are request method(s), request length, etc.
Request Content Features searching for partic-
ularly suspicious patterns in http requests. The
number of non printable/metacharacters, number
of directory traversal patterns, etc.
Response Features extracted by analyzing http
response to a given request. These features can
reveal the success or failure of an attack and can
reveal suspicious http content in the response, in
which case Web clients are targeted by a possible
attack.
Request History Features providing statistics
about past connections given that several Web at-
tacks such as flooding, brute-force, Web vulner-
ability scans perform through several repetitive
connections. Examples of such features are the
number/rate of connections issued by same source
host and requesting same/different URIs.
Note that in order to label the preprocessed http traf-
fic (as normal or attack), we analyzed this data using
Snort(Snort, 2002) IDS as well as manual analysis.
As for other attacks, we simulated most of the attacks
involved in (Ingham and Inoue, 2007) which is to
our knowledge the most extensive and uptodate open
Web-attack data set. In addition, we played vulnera-
bility scanning sessions using w3af(Riancho, 2007).
Note that attack simulations are achieved on a sim-
ulation network using the same platform (same Web
server software and same operating system) and same
Web site content.
Table 1: Training/testing data set distribution.
Training data Testing data
Class Number % Number %
Normal 55342 55.87% 61378 88.88 %
Vulnerability scan 31152 31.45% 4456 6.45 %
Buffer overflow 9 0.009% 15 0.02%
Input validation 44 0.044% 4 0.01 %
Value misinterpretation 2 0.002% 1 0.00%
Poor management 3 0.003% 0 0.00%
URL decoding error 3 0.003% 0 0.00%
Flooding 12488 12.61% 3159 4.57 %
Cross Site Scripting 0 0.00% 6 0.0001 %
SQL injection 0 0.00% 14 0.001 %
Command injection 0 0.00% 9 0.001 %
Total 99043 100% 69061 100%
Attacks of Table 1 are categorized according to
the vulnerability category involved in each attack.
Regarding attack effects, attacks of Table 1 include
DoS attacks, Scans, information leak, unauthorized
and remote access (Ingham and Inoue, 2007). In or-
der to evaluate the generalization capacities and the
ability to detect new attacks, we build a testing data
set including real normal http connections as well
as known attacks, known attack variations and novel
ones (attacks in bold in Table 1).
Note that new attacks included in testing data either
involve new feature values or anomalous value com-
binations:
Attacks Causing New Values. New attacks involv-
ing new values are SQL injection, XSS and com-
mand injection attacks. These attacks are charac-
terized by never seen values in training data.
Attacks Causing New Value Combinations. New
attacks involving new value combinations are
buffer overflow attacks including shell code and
shell commands and vulnerability scans search-
ing particularly for SQL injection points. In train-
ing data, vulnerability scans search for vulnerabil-
ities other than SQL injection points. Similarly, in
training data, there are shell command injection
attacks and buffer overflow attacks without shell
codes or shell commands.
ICSOFT 2008 - International Conference on Software and Data Technologies
270
Note that SQL injection attacks include two insuffi-
cient authentication attacks performing through SQL
injection. These attacks cause simultaneously anoma-
lous new values and value combinations.
5.2 Experiments on Standard/Enhanced
Bayesian Classification Rule
Table 2 compares results of standard then enhanced
naive Bayes and TAN classifiers built on training data
and evaluated on testing one.
Table 2: Evaluation of naive Bayes and TAN classifiers us-
ing standard/enhanced Bayesian classification rules.
Standard Bayesian rule Enhanced Bayesian rule
Naive Bayes TAN Naive Bayes TAN
Normal 98.2% 99.9% 91.7% 97.8%
Vulnerability scan 15.8% 44.1% 100% 100%
Buffer overflow 6.7% 20.2% 80% 100%
Input validation 75.0% 100% 100% 100%
Value misinterpretation 100% 0.00% 100% 100%
Flooding 100% 100% 100% 100%
Cross Site Scripting 0.00% 0.00 % 100% 100%
SQL injection 0.00% 0.00% 100 % 100%
Command injection 0.00% 0.00 % 100 % 100%
Total PCC 92.87% 96.24% 96.45% 98.07%
Note that enhanced classification rule evaluated in
Table 2 uses normality/abnormality duality and zero
probabilities (see Rules 1, 2 and 3).
Experiments on standard Bayesian classification
rule: At first sight, both classifiers achieve good
detection rates regarding their PCCs (Percent of
Correct Classification) but they are ineffective in
detecting novel attacks (attacks in bold in Ta-
ble 2). Confusion matrixes relative to this ex-
perimentation show that naive Bayes and TAN
classifiers misclassified all new attacks and pre-
dicted them Normal. However, results of Table
2 show that TAN classifier performs better than
naive Bayes since it represents some feature de-
pendencies. Furthermore, testing attacks causing
new value combinations of seen anomalous values
(involved separately in different training attacks)
cause false negatives. For instance, testing vul-
nerability scans are not well detected since they
involve new value combinations.
Experiments on enhanced Bayesian classification
rule: Naive Bayes and TAN classifiers using the
enhanced rule perform significantly better than
with standard rule. More particularly, both the
classifiers succeeded in detecting both novel and
known attacks. Unlike naive Bayes, enhanced
TAN classifier improves detection rates without
triggering higher false alarm rate (see correct clas-
sification rate of Normal class in Table 2. Further-
more, TAN classifier correctly detects and identi-
fies all known and novel attacks.
Results of Table 2 show that significant improvements
can be achieved in detecting novel attacks by enhanc-
ing standard classification rules in order to meet be-
havioral approach requirements.
6 CONCLUSIONS
The main objective of this paper is to overcome one
of the main limitations of behavioral approaches.
We proposed how to enhance standard classification
rules in order to effectively detect both known and
novel attacks. We illustrated our enhancements on
Bayesian classifiers in order to improve detecting
novel attacks involving abnormal behaviors. More
precisely, we have proposed four rules relying on
normality/abnormalityduality relative to audit events,
zero probabilities caused by anomalous evidence oc-
currence and likelihood of attacks having extremely
small prior frequencies. Experiments on http traffic
show the significant improvements achieved by the
enhanced decision rule in comparison with the stan-
dard one. Future work will address handling incom-
plete and uncertain information relative to network
traffic audit events.
REFERENCES
Axelsson, S. (2000). Intrusion detection systems: A sur-
vey and taxonomy. Technical Report 99-15, Chalmers
Univ.
Barbar´a, D., Wu, N., and Jajodia, S. (2001). Detecting
novel network intrusions using bayes estimators. In
Proceedings of the First SIAM Conference on Data
Mining.
Ben-Amor, N., Benferhat, S., and Elouedi, Z. (2003). Naive
bayesian networks in intrusion detection systems. In
ACM, Cavtat-Dubrovnik, Croatia.
Benferhat, S. and Tabia, K. (2005). On the combination of
naive bayes and decision trees for intrusion detection.
In CIMCA/IAWTIC, pages 211–216.
Elkan, C. (2000). Results of the kdd’99 classifier learning.
SIGKDD Explorations, 1(2):63–64.
Friedman, N., Geiger, D., and Goldszmidt, M. (1997).
Bayesian network classifiers. Machine Learning,
29(2-3):131–163.
Ingham, K. L. and Inoue, H. (2007). Comparing anomaly
detection techniques for http. In RAID, pages 42–62.
Kruegel, C., Mutz, D., Robertson, W., and Valeur, F. (2003).
Bayesian event classification for intrusion detection.
ON THE DETECTION OF NOVEL ATTACKS USING BEHAVIORAL APPROACHES
271
Kumar, S. and Spafford, E. H. (1994). An appli-
cation of pattern matching in intrusion detection.
Tech. Rep. CSD–TR–94–013, Department of Com-
puter Scien’ces, Purdue University, West Lafayette.
Lee, W. (1999). A data mining framework for constructing
features and models for intrusion detection systems.
PhD thesis, New York, NY, USA.
Lippmann, R., Haines, J. W., Fried, D. J., Korba, J., and
Das, K. (2000). The 1999 darpa off-line intrusion
detection evaluation. Comput. Networks, 34(4):579–
595.
Neumann, P. G. and Porras, P. A. (1999). Experience with
EMERALD to date. pages 73–80.
Quinlan, J. R. (1986). Induction of decision trees. Mach.
Learn., 1(1).
Riancho, A. (2007). w3af - web application attack and audit
framework.
Sebyala, A. A., Olukemi, T., and Sacks, L. (2002). Ac-
tive platform security through intrusion detection us-
ing naive bayesian network for anomaly detection. In
Proceedings of the London Communications Sympo-
sium 2002.
Shyu, M.-L., Sarinnapakorn, K., Kuruppu-Appuhamilage,
I., Chen, S.-C., Chang, L., and Goldring, T. (2005).
Handling nominal features in anomaly intrusion de-
tection problems. In RIDE, pages 55–62. IEEE Com-
puter Society.
Snort (2002). Snort: The open source network intrusion
detection system. http://www.snort.org.
Tombini, E., Debar, H., Me, L., and Ducasse, M. (2004).
A serial combination of anomaly and misuse idses ap-
plied to http traffic. In ACSAC ’04: Proceedings of the
20th Annual Computer Security Applications Confer-
ence (ACSAC’04), pages 428–437, Washington, DC,
USA. IEEE Computer Society.
Valdes, A. and Skinner, K. (2000). Adaptive, model-based
monitoring for cyber attack detection. In Recent Ad-
vances in Intrusion Detection, pages 80–92.
ICSOFT 2008 - International Conference on Software and Data Technologies
272
