SCFS: TOWARDS DESIGN AND IMPLEMENTATION OF A SECURE

DISTRIBUTED FILESYSTEM

Juan Vera-del-Campo, Juan Hern

andez-Serrano and Josep Pegueroles

Politechnic University of Catalonia, Jordi Girona 1-3, Barcelona, Spain

Keywords:

Peer-to-peer, Distributed Filesystem, Security, CFS.

Abstract:

Our digital world creates lots of data than users desire to preserve from malfunctioning, local disasters or

human errors. Current nodes in the internet has enough intelligence and processing power to allow the deploy-

ment of distributed services on common nodes. This is the case of peer-to-peer networks and services. There

are several proposals in literature to deploy a distributed ﬁlesystem over the internet. This paper presents and

analyses the security of a prototype based on Cooperative File System.

1 INTRODUCTION

Data is for many people one of the most valuable pos-

sesions. Very often, personal data is stored in hard

disks or removable devices that are both fragile and

localised. Furthermore, there are many situations that

lead to loss of data in this kind of media, such as hu-

man or computer errors, ﬁre or water damage acci-

dents or stealing of hardware. Data is even a more

important resource for enterprises, that are willing to

pay for expensive and complex mechanisms to ensure

its availability.

Distributed ﬁle system spread data in many nodes

of the internet in order to protect it against local mal-

functioning hardware. Today most nodes in the in-

ternet are driven by common people and they have

not special roles in the network. There is plenty of

bandwidth and digital intelligence that is wasted in

personal computers around the world. Peer-to-peer

networks use the latent power and bandwidth of com-

mon nodes in the internet to provide decentralised,

distributed services that seem very convenient to pro-

vide reliability to a distributed ﬁlesystem without as-

suming the cost of high-end internet servers.

But distribution of data has a main drawback re-

garding security. Many people will object if their data

is stored in the computer of a complete stranger, since

he will be able to access, for example, to their sen-

sitive bank accounting information. Even collecting

the name of the ﬁles that a user has in his personal

namespace is a violation of his privacy. A system that

focuses on providing reliable storage of personal data

and backups must face security as one of the main ob-

jectives of design.

In this paper we propose a secure architecture for

the storage of personal data in distributed peer-to-

peer networks. The main objective of the proposal

is to provide a reliable service that clients will use

to backup their valuable and sensitive personal data,

without fear of data losing or undesired spying.

The structure of this paper is as follows. Section 2

studies several distributed ﬁle systems that focus on

security and their weaknesses. Section 3 analyses

CFS, presents the main scenario of application and

explores the requirements of the service. Section 4

presents our proposals to secure CFS. Section 4.8

analyses the security of our prototype implementa-

tion. Finally, the paper ends with the conclusions and

references of our work.

2 RELATED WORK

There are many proposals on distributed ﬁle system

in literature. From NFS to AFS, many widely de-

ployed distributed ﬁle systems rely on several more

replicated servers. But this approach is neither scal-

able nor cheap, and servers are a honeypot for attack-

ers, even if distributed. To solve these problems, dis-

tributed ﬁlesystem over peer-to-peer appeared in lit-

erature. In this section we will summarise some of

the properties of distributed and decentralised ﬁlesys-

tems that has a strong focus on security. Readers can

consult a general analysis of distributed ﬁlesystems

169

Vera-del-Campo J., Hernández-Serrano J. and Pegueroles J. (2008).

SCFS: TOWARDS DESIGN AND IMPLEMENTATION OF A SECURE DISTRIBUTED FILESYSTEM.

In Proceedings of the International Conference on Security and Cryptography, pages 169-176

DOI: 10.5220/0001923901690176

 SciTePress

in (Hasan et al., 2005).

MojoNation (MOJ, 2000) was a robust, decen-

tralised ﬁle storage. Nodes were organised in a peer-

to-peer network with ring shape. Files were broken

down in blocks that were replicated and stored in the

network using a unique identiﬁer per ﬁle. The com-

pany that deployed MojoNation commercialised cash

units, called mojos, as its bussines model. Mojos were

used to prevent abuse and ﬂooding. MojoNation died

because original designers didn’t consider the high

rate of joins and leaves of common nodes.

Free Haven (Dingledine et al., 2001) uses a non-

structured peer-to-peer network and routes searching

messages by ﬂooding the network. Files are bro-

ken down in N blocks using an information disper-

sal algorithm (Rabin, 1989) Clients create a pair of

public-private keys for each ﬁle. Each block is in-

dexed with the same key, hash(PK

sub

), and traded

with a closed list of neighbours taking into account

reputation. When asking for a key, clients wait for

k < N parts and reconstruct the whole ﬁle. Nodes

trade blocks with other nodes to improve anonymity

and persistence of data.

FreeNet (Clarke et al., 2000) was designed to

store common data and to allow its later access by

means of an associated key, preventing the censor-

ship and offering anonymity to the user who publishes

the document and to the one that downloads it. To

achieve these goals, the Freenet network creates a not-

hierarchical and not-structured organisation of nodes

that anonymously transmit and cache messages and

documents among them.

GnuNet (Tatara et al., 2005) has the objective of

building a broadcast routing algorithm based on spe-

ciﬁc nodes currencies of nodes. Each node valuates

its neighbours based on their behaviour and the num-

ber of messages that route or ask to route. Messages

from less valued nodes receive less priority in the out-

put queue. Each node routes its messages based on its

own interests, but the economics of the network sup-

ports strong collaboration.

Over this routing algorithm a ﬁle sharing proto-

col was developed (Grothoff et al., 2006). Files are

divided in blocks B

that are individually encrypted

using H

= hash(B

) as key, and identiﬁed by H

hash(H

) in the network. Nodes trade these blocks

with neighbours, and get other blocks in exchange.

Users searching for ﬁles send the hash of the keyword

to get the data blocks.

Shark (Annapureddy et al., 2005) divides ﬁles in

blocks and uses a DHT to store the address of nodes

with of them (proxies). When a node downloads a

chunks, it publishes itself as holder of a replica. Only

nodes that are controlled by the same user will be

proxies of personal data, so clients need at least one

of their nodes to be connected to retrieve data. Clients

must prove knowledge of the contents of a chunk to

read/write, and then anonymity is not achieved.

Cooperative File System (CFS (Dabek et al.,

2001)) is a ﬁle system over a distributed hash table.

Since this ﬁlesystem is the core of our proposal, it

will be explained in detail in the next section.

3 SCENARIO OF APPLICATION

The scenario of our study is as follows. Individu-

als want to use the internet as a backup of their per-

sonal ﬁles, or even as a nearly unlimited disk space

for little devices. Distribution of their personal data is

not their main objective, but preservation of their own

and unique data and accessibility from any device that

they may own. In addition, they are really interested

in keeping their data private and out of the reach of

both casual and commercial eyes.

The features of structured Peer-to-peer networks

are very convenient to achieve reliability and acces-

sibility of personal data to thousands of users at the

same time. Among the networks that were studied

in section 2, CFS is the only structured Peer-to-peer

network. Authors of CFS didn’t consider security in

their original design, and this paper describes the con-

struction of a secure structure over CFS. We call this

system Secure Cooperative File System (SCFS).

3.1 Cooperative File System

Our proposal aims to add security to the Cooperative

File System (CFS (Dabek et al., 2001)), that is a ﬁle

system over a Distributed Hash Table (DHT). Figure 1

shows the architecture of this algorithm.

A DHT is a structured peer-to-peer network where

nodes pick up a random identiﬁer ID

. Each one

ﬁnds and links at least to the node that has the very

next ID

> ID

in increasing order. The node ID

is in charge of storing data that is identiﬁed with an

ID ∈ (ID

,ID

). The process goes on until that the

last node links to the ﬁrst one and the whole network

creates a ring structure. In order to put or get the in-

formation identiﬁed with ID, a node sends clockwise

a message in the ring to the node in charge of ID, that

answers. To improve the routing in the ring, nodes

have far links to other nodes of their choice. Current

implementation of DHTs include Kademlia (May-

mounkov and Mazi

eres, 2002) or Chord (Stoica et al.,

2001), and the main difference between them is the

speciﬁc algorithm for far links.

SECRYPT 2008 - International Conference on Security and Cryptography

170

CFS was implemented over Chord. It gets a ﬁle F

with a ﬁlename f , divides the ﬁle in blocks, stores the

blocks B

and calculates H

and ID

F = {B

∪ B

... ∪B

} (1)

= hash(B

) (2)

= {H

,...,H

} (3)

= hash( f ) (4)

Then CFS saves each block B

in the DHT identi-

ﬁed as H

and stores the list of H

in a special block

under ID

. Files in CFS are persistent and the system

warrants that every ﬁle will be retrieved, regardless of

its popularity.

Figure 1: Cooperative File System.

3.2 Security Requirements

Distribution of personal data in peer-to-peer networks

has many drawbacks from the point of view of secu-

rity. Many people do not want that strangers were

able to access to their private data, and even they will

object if it is possible to get the knowledge of the ex-

istence of some ﬁles. Intruders may look for common

ﬁle names as “accounting”, “strategic plan” or “pass-

words” in the whole network for any legitimate user.

In addition, in some countries having a single MP3

ﬁle or some kind of adult content may be severally

prosecuted.

The security requirements of SCFS are:

Conﬁdentiality. Data should not be readable for oth-

ers apart from the user than uploaded it. In a dis-

tributed ﬁlesystem every node stores personal data

from any user, and the ﬁlesystem must supply mecha-

nisms to warrant that node administrators cannot read

data from other users. On the other hand, if nodes can-

not read the content that they store they can positively

deny its knowledge and protect themselves from legal

prosecution for storing and distributing illicit content.

Privacy. Malicious users may collect data about

habits or interests of users. Even if an attacker is

not able to access to actual data, the name of the ﬁles

of the user namespace may be relevant. Commercial

research and dictatorial governments may get proﬁt

from capturing the names of ﬁles accessed by users.

The ﬁlesystem must provide methods to prevent such

eavesdropping.

Integrity. Since data is stored in uncontrolled nodes,

it is not possible to prevent the modiﬁcation of data.

The ﬁlesystem must provide mechanisms to detect

modiﬁcation and restore original data, if possible.

Persistence. The ﬁlesystem must prevent data los-

ing. Files can be lost by means of malicious nodes

that remove pieces of data, users that write data in the

same place, both intentionally and unintentionally, or

network or node failures. Storage systems focus on

persistence instead than on publishing of data.

Availability. Users are in the move and own many

devices with different network capabilities, memory

and processing power. In spite of this, they want to

access to a consistent disk space from every device

regardless of its capabilities. The system should pro-

vide mechanisms to allow data to be available from

any of the devices of the users, regardless how and

where they are connected.

In the next section we propose several mecha-

nisms on top of CFS to cover these design objectives.

4 SECURE COOPERATIVE FILE

SYSTEM

Distributed ﬁle systems over structured peer-to-peer

networks provide the requirements that the scenario

under study needs. CFS is the ﬁrst choice to develop

a distributed ﬁle system for personal ﬁles, but it does

not provide the necessary security services. In this

section we propose many mechanisms to add to the

standard CFS system in order to cover the security

objectives studied in section 3.2.

This section will explain in depth each of the

steps. A graphical outline of the whole process is

shown in ﬁgure 2.

Figure 2: Description of the process.

SCFS: TOWARDS DESIGN AND IMPLEMENTATION OF A SECURE DISTRIBUTED FILESYSTEM

171

4.1 Assumptions and Deﬁnitions

Table 1 includes the deﬁnition of the main concepts

of SCFS. Readers will ﬁnd a relation of symbols in

table 2.

Table 1: Deﬁnitions used in this paper.

User A human client of the system.

Node Each one of the devices that a client uses to

join to the network.

File An ordered array of data

Directory An unordered set of ﬁles and directories

Filename A human readable identiﬁer for a ﬁle or di-

rectory. It is not unique in the system, since

two different users can store different ﬁles

under the same ﬁlename

Root Di-

rectory

The ﬁlename of the directory that holds ev-

ery ﬁle and directory of the user. Altough

not mandatory, we assume that users will

have a root directory for all his documents

and ﬁles.

Block Each one of the pieces than the IDA creates

from a ﬁle

Metadata

Blocks

Special blocks of data that have enough in-

formation to restore the complete ﬁle

iNode The ﬁrst block of metadata that holds a list

of the rest of metadata blocks

In order to gather all this information in a single

point, conﬁguration ﬁle exists. A conﬁguration ﬁle

may be associated to a ﬁle, a directory and its con-

tents or every single document of the user. Conﬁgura-

tion ﬁle store the identiﬁer of the root directory of the

user, if needed, and the set of keys K required to get

the associated object or set of objects. These conﬁg-

uration ﬁles are stored locally to the user in each one

of the nodes and kept private.

For example, Bob and Alice join to a SCFS net-

work. They both desire to store a ﬁle that has “rev-

enues.xls” as ﬁlename. Bob has UID

bob

= bob as

his identiﬁer, and Alice UID

alice

= alice. Bob has

c f s : //bob/root/ as the root directory, and Alice has

c f s : //alice/root/. In order to access to the personal

root directory of Bob, he will need his global key K

Since their user identiﬁers and K

are different, their

namespaces will be different as well, as the next sec-

tion shows.

4.2 Securing the Whole File

The ﬁrst step to secure a ﬁle is encrypting its con-

tents. Each ﬁle is encrypted with a symmetric algo-

rithm with K

. Since there are additional steps that

enhance the security of the system and an attacker

cannot get the whole ﬁle from one or several blocks,

an encrypter as strong and slow as AES is not really

needed. Weaker but quicker algorithms such as RC4

are desirable for little devices. Encrypting a ﬁle en-

sures that casual attackers won’t be able to sniff its

contents.

After the encryption process, a shufﬂing and re-

dundancy creator algorithm takes place. SCFS uses

an information dispersion algorithm (IDA) described

in (Rabin, 1989). This step has a double objective.

The ﬁrst one is preventing that consecutive bytes in

the original ﬁle were consecutive in the stored blocks.

This shufﬂing prevents some kind of statistical at-

tacks against ﬁles with a known structure or common

header, such as PDF ﬁles. Since users can choose

the kernel space of vectors for the IDA algorithm, the

spreading of data in the ﬁnal blocks is deterministic

only for the original author. Key K

is used to gen-

erate the vector space that the IDA algorithms need.

The second objective of the algorithm is creating re-

dundancy of data. In order to enhance the availability

of the service, the algorithm takes the original ﬁle and

created m blocks in such a way that it will need k < m

blocks to restore the original ﬁle. During the read-

ing process that redundant information may be used

to check the integrity of data and correct errors. In

this sense, the system is protected against malicious

nodes that randomly changes data that they store,

overloaded nodes than cannot manage all their par-

allel connections and local network failures. The di-

mension of B

is chosen in such a way that it matches

the size of a block in the DHT.

S = {F}

(5)

B = {S}

IDA

= {B

,...,B

} (6)

dim(F) = dim(S) < dim(∪B) (7)

Clearly, this algorithm consumes both time, band-

width and disk space in remote nodes since the di-

mension of the ﬁnal data in B is greater than the di-

mension of the original ﬁle F. Users can choose the

amount of redundancy to apply to each ﬁle, or even if

this algorithm runs or not at all over their ﬁles. Au-

thors expect that clients will use most of the time the

default redundancy of 30%.

The encryption and shufﬂing steps take place lo-

cally in a node and the set B is not yet published in

the ring.

4.3 Securing File Blocks

After the previous step each block B

has the same

size than the DHT blocks. Since the data in each B

was encrypted and shufﬂed, it makes little sense to

any casual attacker that sniffs the blocks.

SECRYPT 2008 - International Conference on Security and Cryptography

172

Table 2: Symbols used in this paper.

UID The identiﬁer of each user. U ID is the same

for every node that a user controls.

F The original ﬁle of the user

The ﬁnal identiﬁer of a ﬁle

S The encrypted ﬁle of the user

Each one of the blocks of a ﬁle

B The set of blocks of the ﬁle

H The set of identiﬁers of blocks

The key used to secure the ﬁlename

The key used to encrypt the ﬁle

f f

The key used to encrypt the metadata

The key used to generate a vector space for

the IDA algorithm

The key used to create block identiﬁers

K The set of keys. It can be generated from a

master key associated to a single ﬁle.

The CFS stores and retrieves blocks of data as-

sociated to a identiﬁer. We propose three different

methods to identify each one of the blocks. All of

them have their advantages and disadvantages.

Random Identiﬁers. The local node picks up a ran-

dom identiﬁer for each block. The identiﬁer has the

same size than identiﬁers in DHT. This is the more se-

cure method since the random identiﬁer has not infor-

mation about the block, its contents or its publisher.

On the other hand, the set of ordered random iden-

tiﬁers of the ﬁle blocks must be stored by the user

locally.

H = {random

} | dim(H) = dim(B) (8)

A ﬁle of 20MB that is stored in blocks of 2048B

need about 160KB to store the random identiﬁers.

Since SCFS uses special blocks to store ﬁle identi-

ﬁers, this approach needs at least 80 blocks just to

store the ﬁle structure.

Pseudorandom Identiﬁers. Identiﬁers for each

block are created with a pseudorandom algorithm us-

ing K

s as seed of the algorithm.

H = {K

} (9)

In this case the user only have to store a key of

128 bits for every ﬁle in the system, no matter of its

length. K

must be kept private, since there is no need

to make the job of an attacker easier publicising the

list of blocks.

Hash of the Block, both basic and secure hash. With

the same considerations as random identiﬁers in re-

spect to size, hashes have the advantage that they

could be used to ensure integrity of data or event

prevent unauthorised overwriting, as will be stated

in next sections. These two advantages are enough

to make advisable to calculate the hash code of each

block and store it in the metadata ﬁle.

H = {hash

),...,hash

)} (10)

4.4 Metadata

In this moment the user’s node has a local buffer

with the blocks of the ﬁle B, a set H to identify each

block and a conﬁguration ﬁle, as stayed in section

4.1. Metadata is then managed in the same way that

a ﬁle object. It is padded, encrypted with K

f f

and di-

vided in blocks using IDA. Many of the special data

is stored in a special block that we call iNode, in the

same sense that iNodes in the traditional ﬁlesystems.

iNodes store the identiﬁcation of the set K, the whole

contents of H and the identiﬁers of the rest of meta-

data blocks.

In SCFS metadata blocks are published as regu-

lar blocks. Since they have the same length and en-

tropy as any other block, they cannot be distinguished

from regular blocks. Identiﬁers are assigned in the

same way as block identiﬁers. The iNode is identiﬁed

in a special way, described in the next section. The

ﬁrst block is referred with a special identiﬁer. Meta-

data blocks are then randomly introduced in the local

buffer. In this way an eavesdropper cannot discrimi-

nate between ﬁle blocks and metadata blocks.

4.4.1 Securing File Identiﬁcations

Every ﬁle in SCFS is related to a URI in a injecting

relation. This means that an URI identify a ﬁle and

any ﬁle is identiﬁed just with one URI. Furthermore,

it should not be possible to ﬁnd out the URI from any

number of parts or blocks of the ﬁle.

Users store in SCFS their private data with an ar-

bitrary name, and the ﬁle system must provide with a

separate namespace of ﬁles for each one of the users.

In this sense, a human readable ﬁlename must be the

main interface of the user to the system. The com-

plexity and security involved in mapping that string

to a DHT identiﬁer must be hidden to the user.

If an attacker is able to identify the iNode, with

convenient cryptanalysis he may be able to retrieve

the complete metadata and then the complete ﬁle. In

this sense, securing the identiﬁcation of the ﬁrst meta-

data block is crucial for the security of the system.

There is a private namespace for each user in

SCFS. Private namespaces have an associated secret

key K

. The ﬁlename is hashed and then encrypted

using this key. The hashing step maximises the en-

tropy of the encrypted string. The encryption step

warrants that the userspace is unique and secured,

SCFS: TOWARDS DESIGN AND IMPLEMENTATION OF A SECURE DISTRIBUTED FILESYSTEM

173

since none can identify the ﬁle even if he knows the

author and the ﬁlename.

= hash

(U ID, f ilename) (11)

4.5 Publishing the File

At this moment, the node has a local buffer with a set

of blocks B that are identiﬁed with H and the iNode

of the system identiﬁed with ID

. The node publishes

the contents of the local buffer in the DHT under they

keys. Readers will notice that since blocks, metadata

and the iNode were randomly introduce in the local

buffer, an attacker is not able to put them aside and a

cryptanalysis is really difﬁcult.

4.6 Reading Process

The reading process is the inversion of the writing

process. From a ﬁlename users create a ID

, maybe

using a user key K

to maintain privacy. From ID

the user gets the iNode of the ﬁle and then the list of

metadata block. From the metadata, the user is able to

recreate H. Then, he downloads the blocks, deshuf-

ﬂes and then decrypts the ﬁle.

4.7 Implementation and Additional

Mechanisms

The ideas in the previous sections were implemented

in a prototype accessible in (del Campo et al., 2008a).

The prototype uses Kademlia (Maymounkov and

Mazi

eres, 2002) as the algorithm for the DHT, blocks

have 2048 bytes and there is a 30% of redundancy

in the IDA algorithm. Identiﬁers of ﬁles, nodes and

users have 128 bits. AES is used as the encryption

algorithm, and the ﬁrst 128 bits of SHA as a hashing

algorithm. Kademlia was chosen as the DHT algo-

rithm since its buckets are more stable against ring

breakages than Chord, the DHT that CFS uses. The

prototype is written in Python and released under the

GPL license.

Apart from the mechanisms of the previous sec-

tions, our implementation of SCFS includes others to

enhance the security of the system. In this section we

will study these additional mechanisms that take place

in phases other that reading and writing data.

Attackers may join a large number malicious

nodes in order to perform a Sybil attack. In this way,

the attacker gains a large inﬂuence in a region of the

Kademlia ring and he may be able to put the complete

system down or perform denial of service attacks to

some users. In order to prevent this kind of attack,

the original designers of CFS proposed that the iden-

tiﬁers of the nodes must depend on the network ad-

dress of the node. Furthermore, the random identiﬁers

of each block disperse blocks in the whole ring, while

the IDA warrants that the ﬁle can be retrieved even

if a segment of the ring is not available. Kademlia is

especially strong against breakage of the ring (May-

mounkov and Mazi

eres, 2002).

Attackers may collect information by means of

snifﬁng the communications of users in the network.

Files are encrypted, shufﬂed and splitted down in

blocks as explained in section 4.3, but metadata have

a slightly weaker encoding process, specially the ﬁrst

of them. An attacker that gets the ﬁrst iNode needs to

decrypt a single block of data to get the list of every

blocks in the system. That ﬁrst iNode is encrypted us-

ing AES, but it contents known information that may

simplify the cryptanalysis. An attacker may identify

this ﬁrst inode because it will be the ﬁrst block than

a user demands. In this way, SCFS asks for several

random blocks apart from the iNode.

There is no deletion service in SCFS. A deletion

service needs to authenticate the owner of the ﬁle in

order to prevent deletion from unauthorised users. In

order to enhance privacy of the users, SCFS does not

include any authentication mechanisms. In order to

prevent exponential growing with time, data is actu-

ally deleted in nodes if owner does not access to the

block after a month. In order to show interest for

a block without the need of downloading it and in-

creasing the bandwidth, users must send a “ping” to

the data block. Nodes count these pings as an access

and will mark the block as no removable for an extra

month.

Both malicious and fair users may overwrite

blocks of legitimate users. Since identiﬁers of blocks

are random numbers, collisions are possible. Kadem-

lia supports storing different blocks under the same

key, and when a user demands that key he will receive

the whole collection. SCFS takes advantage of this by

means of saving the hash of the block in the iNodes.

In this sense, when a user demands a key and receives

several blocks, he is able to discriminate which one is

the valid to create the original ﬁle. This mechanism

does not prevent that malicious users are able to write

blocks under the same key, but their blocks won’t be

used to recreate the original ﬁle.

Directories are ﬁles with an unordered list of ﬁle

or directory identiﬁers than it holds. Raw content of

a directory is managed as any other regular ﬁle in the

system. SCFS uses different URIs to distinguish be-

tween ﬁles and directories.

SECRYPT 2008 - International Conference on Security and Cryptography

174

4.8 Security Analysis

In this section we study some possible attacks against

the system and their counter measures. These attacks

are based on the objectives that were listed in 3.2. For

a detailed comparison of SCFS with other distributed

ﬁle systems, the reader can consult (del Campo et al.,

2008b).

An attacker eavesdrop user’s communications.

Every piece of data is locally encrypted and it is never

stored in plain text on SCFS. The objective of this at-

tack is getting the root directory, the iNode or a col-

lection of blocks of a ﬁle to perform the next attacks.

SCFS asks for a number of random blocks in the ﬁrst

place. File blocks and metadata are indistinguishable

and all of them have the same size. SCFS makes difﬁ-

cult for an attacker to put ﬁle blocks apart from meta-

data or directories.

An attacker wants to get a particular ﬁle of a user.

The attacker knows of the existence of a ﬁle named in

a certain way in the personal namespace of the user,

as “income.xls”. SCFS uses the secure hash of a ﬁle-

name to identify an isolated ﬁle. In this case, the at-

tacker must break down the secure hash to get the iN-

ode, and decrypt this block to get the list of blocks

of the ﬁle. Our prototype uses random identiﬁers for

ﬁles stored in a directory, and only the name of the

directory of the root directory uses secure hash with

. Random identiﬁers are safe against this attack.

An attacker wants to list the contents of a directory

Directory names are protected with K

in the same

way that ﬁlenames are. An attacker could obtain the

identiﬁcation of the root directory, or even its blocks,

if the last attack is successful. Directories are special

ﬁles a small number of blocks. It is feasible a brute

force attack to rearrange blocks on these small ﬁles,

but the attacker still have to break down a symmetric

encryption with K

An attacker gets the metadata of a ﬁle. The ﬁrst

blocks that a user asks to SCFS are the metadata of

a ﬁle. An attacker could put apart these blocks and

cryptoanalise them to get K

f f

. In this sense, SCFS ask

for some random blocks apart from the actual ones to

make this attack less feasible.

An attacker collects every block of a single ﬁle. If

an attacker eavesdrops the communication of a user

he is able to get the list of blocks that conforms a

ﬁle without any need of decrypt the metadata. But

since the IDA algorithm takes place after the encryp-

tion and the attacker has no information about the K

that creates the vector space for the algorithm, he has

to permute the blocks of the ﬁle at random and then

perform the cryptanalysis to break down the ﬁle en-

cryption with K

. The IDA step adds an additional

security to the encryption that makes feasible to use

a weaker algorithm for encryption of the ﬁle for little

devices, as RC4.

An attacker deletes a ﬁle of a user. Since SCFS

does not offer a deletion mechanism as explained in

section 4.7, this attack cannot be performed.

An attacker controls a group of nodes in the net-

work. The original CFS uses Chord at the DHT level

and the identiﬁers of each node depend on the net-

work address. SCFS shares this behaviour with CFS,

and then an attacker has a limited range of identiﬁers

for his nodes. The DHT layer is is able to perform

long jumps even if a segment of the ring. The buckets

of Kademlia, that is the DHT used in SCFS, are even

stronger against a ring breakage (Maymounkov and

Mazi

eres, 2002). Furthermore, since users only need

k blocks of n to reconstruct the original ﬁle, the blocks

stored in the segment that the attacker controls are not

really needed. As stated in (del Campo et al., 2008b),

SCFS does not currently have an economics system

to detect and prevent malicious behaviour. A system

of this kind minimises the dangers of malicious users

in the network by means of identifying them as soon

as possible.

Lazy nodes do not send a block, or an attacker

sends a false block back. Nodes that are overwhelmed

with links or prefer not to cooperate with other nodes

won’t answer to block requests. Since SCFS uses an

IDA algorithm, users will only have to gather k out of

n blocks to reconstruct the original ﬁle. Modiﬁcation

of a block is easily identiﬁed with the hash included

in the iNode. An economics system to prevent such

kind of attack is advisable, as stated previously.

A node try to decrypt the blocks than it stores.

SCFS encrypts blocks using AES and breaks down

ﬁles in pieces with the IDA. The information of a sin-

gle block makes little sense to the node that stores a

single block. Even the block identiﬁcation contents

no information about the contents, its ﬁlename or its

publishers.

Any user overwrites one or more blocks of an-

other user. Since there are many users in the network

that store many ﬁles with many blocks, there are high

chances that a legitimate user use the same identiﬁer

that another user for different blocks. Attackers may

use the same identiﬁer with malicious intentions. The

DHT is able to store several blocks under the same

identiﬁer, and it will returns the whole list after a

question. Since SCFS stores the hash of the blocks

in the metadata, users can discriminate their blocks

from other user’s block even if they are stored under

the same key. Since SCFS uses SHA, we assume that

an attacker has not a feasible way to modify a block

while keeping the same hash and he won’t be able to

SCFS: TOWARDS DESIGN AND IMPLEMENTATION OF A SECURE DISTRIBUTED FILESYSTEM

175

overwrite a user’s block.

An attacker traces the publisher of a ﬁle. In this

attack we assume that the attacker could overcome the

attacks listed above. That assumption needs a consid-

erable processing power, and only major government

agencies can carry out such an attack. Since there is

not an authentication mechanism in the system, the

agency has not any knowledge of the original author

of the ﬁle. In this sense the agency has to supplant

the node that store the initial iNode and wait for the

publisher to download the ﬁle to catch him. Even in

this case, the network can use one of the mechanisms

described in (Freedman and Morris, 2002) or (TOR, )

to warrant access anonymity to its users.

A government agency prosecutes nodes that dis-

tribute a ﬁle. As stated in the previous attacks, nodes

in SCFS do not know which kind of content they

store, their contents or ﬁlename. In many countries,

denying knowledge of the content that a node store is

enough to prevent prosecution from local authorities

to node administrators.

5 CONCLUSIONS

In this paper we analyse several distributed ﬁlesys-

tems from the point of view of security and conclude

that, as far as we know, there is not a satisfying so-

lution to store personal data. We analyse the security

requirements of such service and conclude that CFS is

the network that best matches the necessities of per-

sonal users. Then, we present a Secure Cooperative

Filesystem that solves the security problems of CFS.

The ideas behind SCFS were implemented in (del

Campo et al., 2008a).

As a result of a security analysis, we conclude

that SCFS solves many of the security requirements

of a distributed ﬁle system, but it has several possi-

ble enhancements. Particularly, further research must

be done in order to include an economic system for

SCFS.

ACKNOWLEDGEMENTS

This project was partially supported by a grant of the

Spanish MCT, under the program Consolider-Ingenio

2010 CSD 2007-0004, under the ARES project.

REFERENCES

Tor anonymity online. Webpage: http://www.torproject.org.

(2000). Mnet-mojo nation. Web page: mnetproject.org.

Annapureddy, S., Freedman, M. J., and Mazi

eres, D.

(2005). Shark: Scaling ﬁle servers via cooperative

caching. NSDI.

Clarke, I., Sandberg, O., Wiley, B., and Hong, T. W.

(2000). Freenet: A distributed anonymous informa-

tion storage and retrieval system. In Designing Pri-

vacy Enhancing Technologies: International Work-

shop on Design Issues in Anonymity and Unobserv-

ability, volume 2009/2001 of Lecture Notes in Com-

puter Science, page 46. Springer Berlin / Heidelberg.

Dabek, F., Kaashoek, M. F., Karger, D., Morris, R., and

Stoica, I. (2001). Wide-area cooperative storage with

cfs. In SOSP ’01: Proceedings of the eighteenth ACM

symposium on Operating systems principles, pages

202–215, New York, NY, USA. ACM Press.

del Campo, J. V., Hern

andez-Serrano, J., and Pegueroles, J.

(2008a). Scfs: lewis.upc.es/svn/dfs.

del Campo, J. V., Hern

andez-Serrano, J., and Pegueroles,

J. (2008b). Securing cooperative ﬁle system. In ES-

ORICS (sent).

Dingledine, R., Freedman, M. J., and Molnar, D. (2001).

The free haven project: Distributed anonymous stor-

age service. Designing Privacy Enhancing Technolo-

gies: International Workshop on Design Issues in

Anonymity and Unobservability, Berkeley, CA, USA,

July 2000, Proceedings:, 2009/2001:67.

Freedman, M. J. and Morris, R. (2002). Tarzan: A peer-to-

peer anonymizing network layer. In CCS.

Grothoff, C., Grothoff, K., Horozov, T., and Lindgren, J. T.

(2006). An encoding for censorship-resistant sharing.

http://gnunet.org/.

Hasan, R., Anwar, Z., Yurcik, W., Brumbaugh, L., and

Campbell, R. (2005). A survey of peer-to-peer stor-

age techniques for distributed ﬁle systems. In IEEE

International Conference on Information Technology

(ITCC). Las Vegas.

Maymounkov, P. and Mazi

eres, D. (2002). Kademlia:

a peer-to-peer information system based on the xor

metrid. In IPTPS, pages 53–65.

Rabin, M. O. (1989). Efﬁcient dispersal of information for

security, load balancing and fault tolerance. Journal

of the ACM, 36(2):335 – 348.

Stoica, I., Morris, R., Karger, D., Kaashoek, M. F., and Bal-

akrishnan, H. (2001). Chord: A scalable peer-to-peer

lookup service for internet applications. In Proceed-

ings of the 2001 conference on Applications, technolo-

gies, architectures, and protocols for computer com-

munications, pages 149 – 160. ACM Press.

Tatara, K., Hori, Y., and Sakurai, K. (2005). Query for-

warding algorithm supporting initiator anonymity in

gnunet. Proceedings. 11th International Conference

on Parallel and Distributed Systems, Vol. 2:235 – 9.

SECRYPT 2008 - International Conference on Security and Cryptography

176
