CAPTURING THE HUMAN ACTION SEMANTICS
USING A QUERY-BY-EXAMPLE
Anna Montesanto, Paola Baldassarri, A. F. Dragoni, G. Vallesi and P. Puliti
DEIT, Università Politecnica delle Marche, Italy
Keywords: Query by example, human action semantics, artificial intelligent systems, neural networks.
Abstract: The paper describes a method for extracting human action semantics in video’s using queries-by-example.
Here we consider the indexing and the matching problems of content-based human motion data retrieval.
The query formulation is based on trajectories that may be easily built or extracted by following relevant
points on a video, by a novice user too. The so realized trajectories contain high value of action semantics.
The semantic schema is built by splitting a trajectory in time ordered sub-sequences that contain the features
of extracted points. This kind of semantic representation allows reducing the search space dimensionality
and, being human-oriented, allows a selective recognition of actions that are very similar among them. A
neural network system analyzes the video semantic similarity, using a two-layer architecture of multilayer
perceptrons, which is able to learn the semantic schema of the actions and to recognize them.
1 INTRODUCTION
In the literature several Content-Based Video
Retrieval (CBVR) papers have been published.
CVBR appears like a natural extension of Content-
Based Image Retrieval (CBIR) and Content-Based
Audio Retrieval systems (Marchand-Maillet, 2000).
However there are a number of factors which should
be dealt with when using video that are ignored
when dealing with images. These factors are related
to the temporal information available from a video
document. The temporal information induces the
concept of motion for the objects that are in the
video. This information allows us to encode within
the indexing of a video the behaviour of all objects
throughout the document.
An important aspect to evaluate is the complexity of
the query system because a video contains a greater
amount of information than a textual description. In
this study, we intend to supply a method of query
where a user can specify the features of interest
using a sketch pad or the whole video like example.
A partial solution could be represented by a query-
by-example: through the query a user can specify the
characteristic of the video that he searches. There
Behaviour understanding involves the analysis and
recognition of motion patterns, and the production of
high level description of actions and interactions (Hu
et al., 2004). We can suppose that the understanding
of the actions is related to the temporal classification
of particular features and to the matching with an
unknown sequence with previously learned
sequences representatives of typical behaviours.
Then a fundamental problem of behaviour
understanding is to learn the reference behaviour
sequences from training samples and to devise both
training and matching problems. Some efforts have
been made in this direction (Bobick & Davis, 2001;
Venkatesh Babu & Ramakrishnan, 2004; Kang et
al., 2004) and some methods of behaviour
understanding are outlined in the following. Other
authors (Bobick & Wilson, 1997) used Dynamic
Time Warping (DTW) to match a test sequence to a
deterministic sequence to recognize human gestures.
Hidden Markow Models (HMM) consisted of
training and classifications outperform DTW for
undivided time series data and so are used to
behaviour understanding (Brand & Kettnaker, 2000;
Oliver et al., 2000). Time Delay Neural Networks
(TDNN) has been used to hand gesture recognition
and lip reading (Meier et al, 2000). The self-
organising neural network can be applied for scenes
where the type of object in motion is not known
(Owens & Hunter, 2000; Sumpter & Bulpitt, 2000).
In this paper we focus the attention on the movement
of a single object. In particular we intend to realize a
system that is able to recognize a human movement.
The process of human movement recognition is
356
Montesanto A., Baldassarri P., F. Dragoni A., Vallesi G. and Puliti P. (2008).
CAPTURING THE HUMAN ACTION SEMANTICS USING A QUERY-BY-EXAMPLE.
In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 356-363
DOI: 10.5220/0001932703560363
Copyright
c
SciTePress
based on a schema in which the whole action is
organized in a kind of macrostructure. A schema is a
cognitive structure characterized by cases that are
arranged in a hierarchical way, but they are also
restructured on the base of the context (Rumelhart &
Ortony, 1964). Moreover the schema also organizes
the information that can be extracted in different
levels. Our schema consisted of a temporal sequence
subdivided in 10 steps. Three are the parameters
characterizing the trajectory of the action: the (x,y)
coordinates and the (v) instantaneous velocity. We
suppose that these three spatio-temporal parameters
constitute the minimal information representative of
the action semantics. The choice of these variables
reduces the dimensionality of the space of searching
and then respects a user-oriented representation.
Each schema of movement used to recognize an
action can represent a class of movement and
different movements can belong to the same class.
In order to recognize a human movement a visual
system has not to passively record local motion
since they are ambiguous (kinematics
indetermination), but the local signals have to be
integrated in a coherent local motion. In a classic
demonstration (Johansson, 1973) were created
displays of human movement by attaching lights to
the major joint of human models. The models were
recorded so that only the point lights were visible to
the observers. So the observers had vivid
impressions of the human figures, although the
images contained only few bright points. So, the
movement is enough to extract meaningful
information of 3D shapes.
In (Runeson, 1994) it is suggested that an
accurate appraisal of kinematics aspects of the
movement allows us understanding its dynamic
aspects. It is important to estimate the active forces
that cause the movement. A very important aspect is
the co-variation of kinematics and geometry that is
well exemplified from a lot of study about the hand
gestures. They satisfy some principles of invariance
that characterize and distinguish them from the
movements of mechanical type (Viviani &
Schneider, 1991).
So we can affirm that the semantics of the action
corresponds to the human perception of the co-
variation of kinematics and geometry. By departing
from this point of view, we have built a system that
concurs with the user to formulate its query using a
representation that implicitly corresponds to the
semantic-cognitive schema of the humans. Such
modality of query formulation goes behind the
problem of the query by example in the video, since
it is not necessary a particular training to use this
system. Moreover the same system can easily
succeed to extract the semantic aspects of the action.
Our recognition system has also to form a base
of knowledge for correctly classify, but above all it
must be sufficiently resistant to the noise. This last
could be the variation of the point of view from
which the action has been recorded. A particularly
suitable methodology uses the artificial neural nets
which are trained through a learning process on
known scenes.
2 SYSTEM OF
QUERY-BY-EXAMPLE IN
VIDEO
We realised 4 sub-systems, communicating between
them through an exchange of information
(memorisation and recovery) carried out using a
database.
2.1 Learning Phase
The proposed system has to recognize and to codify
the actions of the query. Therefore, in a preliminary
phase the videos are inserted in a database, and so
they represent the pattern of training. For that, the
manager of the system (an expert user) determines
the number n of videos for the training of the system
for the recognition of the actions and the number τ
of typologies of actions. From that it is created a
table in which the list of the actions encoded through
a binary code is represented. So, this table contains
the list of actions used for the learning. After carried
out the tracking of the point, its trajectory is inserted
in the database pointing to the video from which
come from. The video is identified by a series of
features: the code of the typology of the action and
the coordinates (x,y) of the points. At this point, it is
possible to supply a feedback for the user designing
the video trajectory superimposes to the first frame.
The coordinates of the point are sent to the “analysis
module” which it calculates the third feature
characterizing the trajectory is the instantaneous
velocity (v). All the information concerning the
video (the binary code of the action, the x,y
coordinates and the velocity v) are stored in a file.
The data of the file are the inputs of the
“recognition module”. In this module start the phase
of training of the neural architecture. At the end of
the learning the weights vectors of the neural
networks architecture are trained in order to allow
the system to recognize and to classify a particular
CAPTURING THE HUMAN ACTION SEMANTICS USING A QUERY-BY-EXAMPLE
357
action during the testing or the generalization phase.
These vectors are added to the characteristics of the
trajectory of the action in the database.
2.2 Generalization Phase
After the training of the system we can use as query
a video that the system has never seen before. Such
video is recalled from the system of tracking. The
novice user clicks on the frame evidencing the
interest point of which made the tracking and the
trajectory is inserted in the database with the pointer
to the file of the video. Specific features characterize
the trajectory of the action: the coordinates of the
points belonging (but it has not the typology of
action because the novice user has not to necessarily
express it inside the query). Now is supplied a
feedback for the user: it is draw the video trajectory
superimposes to the first frame.
The coordinates of the points of the trajectory
are sent to the analysis system which it calculates the
instantaneous velocity v. The parameters are the
inputs to the “recognition module” that classifies the
trajectory indicating the class of belonging of the
analysed action.
Moreover this information is sent to the system
of matching that collects all the trajectories that have
the same class vector of belonging to the database.
The results are shown to the user as the first
frame with over drawn the trajectory of the action;
such frame is clickable and let’s starts the video.
3 THE TRACKING ALGORITHM
Starting from a video, this algorithm made the
tracking of the points chosen by the user or of the
point that it retains optimal to be tracked. Then it
extract the coordinates x and y of such points.
The algorithm used to realize the tracking is
based on the pyramidal Lucas-Kanade technique
(Bouget, 1999) for its performances of robustness
and accuracy. Concerning the accuracy we need
small integration window for not smoothing the
details of the image. While the robustness concerns
the power of the algorithm related to the light
variations, the image dimensions and the motion. So
the robustness need large image.
In this method the pyramidal representation is
used because it is simpler to follow wide movements
of pixel, that they are wider than the window of
integration at the main image level, while they are
confined in the same window at the lower level.
Resuming it is important a pyramidal representation
of the image, in which in the high level we obtain a
small image that, allows precise comparison among
the pixels of two consecutive frames. While in the
lower level we obtain a large image that allows
maintaining the macroscopic differences of the
movements.
For each analysis level the Lucas-Kanade
algorithm halves the image resolution. The Lucas-
Kanade algorithm considers two frames at a time
and for each pixel of the first image it finds the
corresponding in the successive image. So,
considering different image resolution we intend to
minimize the “Residual Error” function є(·), that
derives from the summation of all the motion
vectors related to the iteration level:
(1)
where I and J represent two frames, while ω
x
e
ω
y
indicates the dimensions of the window of
integration. These parameters have to be
appropriately chosen in order to guarantee the
performances of robustness and accuracy typical of
the algorithm.
Having the (x,y) point in a particular frame, we
can determine the corresponding point in the
successive frame. The (x,y,v) tern is stored in a
database (Yoon et al., 2001), where v is the
instantaneous velocity. The matrix contains the
spatio-temporal minimal information representing
the semantic of the action. The semantic is defined
by the way in which the motion in time develops.
In particular we can affirm that the dynamical
constraints render perceptively unique the action,
even if the geometry of its trajectory is very similar
among different actions. The (x,y,v) tern allows us
studying the motion considering the implicated
forces, but only if we extend the information on the
complete temporal sequence.
Such algorithm, moreover, has been optimised
through a procedure that allows the user choosing
the optimal points. They are those points that carry
with greater probability to good results. The
computation of the gradient of the brightness
function has been implemented in such way that the
user can choose between the best points that have a
gradient value upper to a fixed threshold. To such
purpose, during the recording of the movies the
subject wore a bracelet with a white marker. So in
correspondence of the wrist we have a strong
gradient of brightness and therefore a greater
precision in phase of tracking.
SIGMAP 2008 - International Conference on Signal Processing and Multimedia Applications
358
4 ALGORITHM OF ANALYSIS
AND INDEXING
This algorithm read the trajectory coordinates and
draws the shape of it. Also using those coordinates it
computes all the necessary features. In particular it
extracts the instantaneous velocity of every point of
the trajectory. It uses the data store in the DB in
order to process them or to visualise them. The first
phase of the algorithm assigns to a vector the
coordinates of the points individualised from
tracking (abscissa and ordinate); while in the
successive phase the trajectory is represented. It is
applied, therefore the algorithm of chain-coding, that
it chases the points finds realising one chain
codified. In such phase we start from the first stored
point, centred in a matrix 3x3, and we look for
around to it, the successive point pertaining to the
trajectory. Once characterised the successive point,
moves the matrix and restart the search. In this way,
starting from the first point, the chain is
automatically generated and characterises the
dynamic of the movie. Once stored the trajectory, is
carried out the analysis and therefore the extraction
of its characteristic parameters.
The interface visualise an image that represents
the mosaic of the considered movie, used like
background and visual reference. On such image the
program draws the codified trajectory and on the
same window the extracted parameters are
described.
5 ARCHITECTURE OF PATTERN
RECOGNITION SYSTEM
We realized a system consisted of two layers
architecture. The first layer consists of 10
perceptrons, while the second layer consists of only
one perceptron. The system receives in input the
features extracted from the video sequences and
gives in output which is the kind of action that a
subject performed. The three actions (eating,
drinking and smoking) are codified as subsequently
explained.
We subdivided the trajectory of each action in 10
steps each consisted of 8 frames. This subdivision is
based on the hypothesis that an action is recognized
through an initially general scheme. The scheme is
defined during the development of the action itself.
Figure 1: The architecture of the neural system.
The figure 1 shows architecture consisted of two
neural networks levels. In the first level we have 10
Multilayer Perceptrons (MLP) (Rumelhart et al.,
1986) each of them has 24 nodes in the input layer.
Each node of the input layer receives the values xyv
for all the subjects and for each action. The vector
xyv
iAS
identifies the elements of the trajectory,
where the index i (that goes from 1 to 10) indicates
the number of steps in which the trajectory is
subdivided. The index A = E,D,S identifies the three
action, and the index S (that goes from 1 to N)
identifies a particular subject (N is the number of the
subjects). So the dimension of the input for each
network of the first layer is equals to 8×3×N.
The hidden layer consists of 12 nodes, while the
output layer consists of only 2 nodes. The vector
o
k
[2] identifies the output of this last layer, where k
goes from 1 to 10 (number of steps in which the
sequence is divided). The vector o
k
consists of two
elements, these identify a specific action according
to the following code: [0,1] for the eating action,
[1,0] for the drinking action and [1,1] for the
smoking action.
The second level consists of only one MLP
which receives as input the outputs of the previous
10 neural networks. So in the input layer it has 20
nodes, in the hidden layer it has 5 nodes and finally
in the output layer it has 2 nodes, which encode the
kind of action.
6 TEST ON HUMAN ACTION
RECOGNITION
We want to see how sensitive was the neural system
to recognize sequences of action very similar one
another, in particular from the geometrical point of
view. The experiment is made so to study the
CAPTURING THE HUMAN ACTION SEMANTICS USING A QUERY-BY-EXAMPLE
359
answers invariance changing the point of record of
the camera. We can observe events that are equal as
regard the trajectory and are different as regard the
semantics: these can hide in practice their actual
meaning in small differences.
6.1 Methodology
In order to try the effectiveness of the parameters in
an unambiguous recognition of the action, the
motion of the wrist of subjects while they are eating,
drinking and smoking was recorded. The movies
have been recorded always to the same distance,
using a fixed experimental setting. This has made so
that the trajectories were much similar between
them. The recorded sample consists of 25 subjects.
We have chosen simple actions to carry out and
to study: Eat, Drink and Smoke.
In each action, the movement is always of the
arm, always to leave from the bottom to the up, until
arriving and stopping themselves on the mouth, and
then from here, to return behind until stopping itself,
caught up the desk newly.
The technical apparatus consists of two
analogical television cameras: one of these was in a
frontal position, whilst the other was in a lateral
position respect to the subject. There are also one
desk, one chair, and finally cracker, water and
cigarettes. Above all were fixed the relevant
positions, so that the features unchanged. We
arranged the desk and the position of the chair
relatively to it.
Then it has been taken the centre of the desk and
in connection to this, one camera is blocked to 5
meters of distance and 53° approximately of angle-
shot as regards the lateral position, whilst the second
is blocked to 5 meters and concerns the frontal
position. It is moreover fixed on the table the start-
position of the objects (cracker, water, and
cigarettes), so the gesture had a precise fixed point
of reference.
Finally, in order to obtain a metric calibration of
the digital images, in order to have a correlation
between the real distances and the resolution in pixel
after the digitalisation, a graded bar has been placed
(it was 30 centimetres long).
During the recording, each subject wore a
bracelet with two white markers, obtaining a high
gradient of brightness in the point of the body that
mainly characterises the movement.
To extract the interesting data from the movies
we digitised them (card of acquisition ATI All in
Wonder 128), to 20 frame for second with a
resolution of 320x240 pixels and with a colour depth
of 24 bits. Then we transform them in grey-scale
levels. We compressed the video sequences through
the algorithm of Run Length Encoding: that replaces
the sequences of identical pixel with the indication
of the number of epochs in which the pixel is
repeated, followed from the value of the pixel itself.
Each of the 50 movies (25 for each camera) has
been decomposed in 3 shorter movies
(correspondent to a particular action), every one of
which has been then analysed singularly.
7 EXPERIMENTAL RESULTS
During the learning, in all the experiments in order
to achieve comparable results we fixed the same
number of iteration epochs and the same learning
rate. In particular the number of iterations was fixed
to 15000 epochs and the learning rate was η = 0.1.
Remembering that each of the three actions was
subdivided in a sequence of ten steps, we determined
the mean square error for each step after 15000
iterations, or rather in the end of the learning. The
figure 2 shows the trend of the mean square error
after 15000 iterations: the black line refers to the
learning by the three actions of 25 subjects of lateral
view, whilst the grey line refers to the learning by
the three actions of 25 subjects of frontal view.
Considering the training with the 25 subjects of
the lateral view, the average error calculates on all
the sequence is 0.04. If we divide the sequence in
two phases (going and return): the average error of
going is 0.006, whist the average error of the return
is 0.08.
Moreover training the networks with the 25
subjects of the frontal view the average error is 0.03.
Dividing the sequence in two phases the average
error for the going is 0.01, whilst the error is 0.05 for
the return phase. These values are understandable if
we consider the “kind” of action. In order to have
more possible similar actions, all the subjects started
the movement from a fixed point, caught up the
mouth and then returned in the fixed starting point.
Initially the action is loaded of meaning both for the
aim linked to the action and for the object grasped
by the end. The heaviness of a water glass is
certainly different from a cigarette. So, in the going
the actions are quite different, instead in the return
they show a conjunction of meaning: all the
movement have only to reach a fixed point. The
consequence is the increase of the average error, so
the not ambiguous recognition of a particular action
is closely related to the development of the
sequence.
SIGMAP 2008 - International Conference on Signal Processing and Multimedia Applications
360
Figure 2: Trend of the mean square errors for each net of
the first layer after 15000 iterations (black line = training
with 25 subjects of lateral view; grey line = training with
25 subjects of frontal view).
7.1 Experiment 1: View Point
Invariance
In the first experiment we want to demonstrate the
invariance from the point of view. The aim is to
verify that a particular action (that is eating, drinking
and smoking) of a subject is recognizable apart from
the point of view. In fact, in this example we
considered both the frontal view and the lateral view
of the same subject in the act of doing one of three
actions previously described.
The system was trained using the lateral shots of
25 subjects during the development of the three
actions. During the testing we used only the frontal
shots of the same 25 subjects in the act of doing the
same three actions. We have to remember that the
two shots took place contemporaneously from two
cameras one in a lateral positions and the other in a
frontal position as regards the subjects.
The training using the parameters (x,y and v)
extracted by the lateral view and the successive
testing using the same parameters extracted by the
frontal view allows evaluating the independence
from the point of view.
This implies that the system is able to recognize
an action done by a subject independently from the
observation position.
Table 1: Confusion Matrix.
EAT DRINK SMOKE
EAT 19 0 6 25
DRINK 0 18 7 25
SMOKE 3 4 18 25
The table 1 shows the confusion matrix of the
test results. The first rows and the first column
indicate the three different actions done by the 25
subjects. The last column indicates the total number
of the subjects that they do a specific action. The
main diagonal shows the total number of actions
correctly recognized. For example as regards the
eating action (EAT), the system correctly recognizes
19 subjects out of 25 subjects during the execution
of the eating action. As we can see in confusion
matrix, both the eating action and the drinking action
are mistaken with the smoking action. In other
words, the system misses to recognize both some
eating actions and some drinking actions identifying
them with smoking. Finally, the last row of the table
1 shows that the smoking action was identified 3
times (12%) with the eating action and 4 times
(16%) with the drinking one.
The rates of recognition are comparable between
them. The rate of recognition is 76% for the eating
action, 72% for the drinking action and finally 72%
for the smoking action. For the first experiment we
obtained an average rate of recognition equals to
73.3%. The experimental results show that the
invariance from the point of view is rather well
respected.
7.2 Experiment 2: Subject Invariance
The second experiment intends to demonstrate the
performances of the system concerning the
invariance from the subject. In other words, we want
to demonstrate that the system is able to correctly
recognize an action independently from the subject,
who makes this. For this purpose, the system was
trained with 15 subject of the frontal view in act of
doing the three actions, while for the test we
considered the others 10 subjects of the same frontal
view. The correct recognition of a particular action
implies that the development of an action is not
determined by the particular subject involved, but
from the characteristics implied in the action itself.
Table 2: Confusion Matrix.
EAT DRINK SMOKE
EAT 10 0 0 10
DRINK 0 9 1 10
SMOKE 1 0 9 10
As for the first experiment, we introduced the
confusion matrix of the actions the system correctly
recognizes (table 2). Each of the 10 subjects carries
out the three actions (eating, drinking and smoking),
in total 30 actions.
The results in the table 2 put in evidence that the
system correctly recognizes the eating action carried
out by the 10 subjects of the testing phase: so the
eating action is recognized with a rate of 100%
(corresponding to 10 out of 10). The drinking and
CAPTURING THE HUMAN ACTION SEMANTICS USING A QUERY-BY-EXAMPLE
361
the smoking actions are also recognized with a
rather high rate: the system correctly recognizes both
the drinking action and the smoking 9 out of 10
times.
We obtained an average rate of recognition
equals to 93.3%. The three actions are correctly
recognized independently by the subject who makes
the action.
7.3 Experiment 3: View Point and
Subject Invariance
The last experiment intends to combine the two
previous experiments. In fact, in this part we want to
demonstrate that the system is able to recognize the
three actions (eating, drinking and smoking)
changing both the point of view and the subject who
makes the action. For this purpose, the system is
trained using the lateral view of the 15 subjects
during their movement. While the testing procedure
is executed using the frontal view of the other 10
subjects in act of doing the same actions. The
training using the parameters (x,y, and v) extracted
by the lateral view of 15 subjects and the successive
test using the same parameters extracted by the
frontal view of the other 10 subjects intend to
evaluate the independence of the system both from
the point of view and from the subject. This implies
the ability of the system to recognize an action
independently from the position of observation of
the subject and independently from the subject
himself.
Referring to the usual representation of the
results, we analyze the confusion matrix in the table
3.
The confusion matrix put in evidence that the
three actions are rather well recognized. Observing
the main diagonal we can see that the eating action
is recognized 8 out of 10 times, the drinking action 9
out of 10 times and the smoking action 7 out of 10
times.
Table 3: Confusion Matrix.
EAT DRINK SMOKE
EAT 8 0 2 10
DRINK 0 9 1 10
SMOKE 1 2 7 10
As for the first experiment both the eating action
and the drinking action are confused with the
smoking action. The smoking action was identified
for a 10% with the eating action and for a 20% with
the drinking.
We can determine an average rate of recognition
equals to 80%. In the last experiment we also
obtained rather encouraging results, having a high
rate of recognition for all the three actions.
8 CONCLUSIONS
The implemented neural architecture learns to
recognise the kinematics and the dynamic aspects of
actions concerning the trajectories but also the
velocity variations. The experimental results showed
the real possibility of building a system that allows a
semantic recognition of an action, taking advantage
from the action recognition modalities of the human.
The lightness of information joined to the
generalisation abilities of the neural networks, make
the system extremely effective. The typology of
action is recognized also if we observe a subject
from two different points of view (lateral and frontal
view), and so the invariance of the system as regard
the point of view is rather well respected. Moreover
the results demonstrated that the system recognized
a specific movement performed by a different
subject from those one learning during the training
and observed from the same point of view (lateral
view). So we can conclude that our system catch
also the subject invariance. Finally we test the
system invariance changing both the point of view
and the subject who makes the action, obtaining high
value of recognition rate.
In all the experiments the recognition of each
action has enough high values, but they could be
better in the case in which every networks of the
first layer will be trained with a number of iterations
that fit with the minimum square error. In fact, in
this work we stopped the simulation after 15000
steps to achieve comparable results evaluating the
suitability of particular chosen knowledge
representation. The experimental evidences show
that the three spatio-temporal parameters (x, y, v)
constitute the minimal information representative of
the action semantics. The neural networks
architecture allows us to have a smart classification
of the part of sequence in which there is a great
amount of different semantics.
One of the possible future developments of the
work can be using the system as recogniser of the
behaviour of a given subject that may be used in
surveillance applications. The study realized in this
work could be applied in numerous and different
environments but with an only common feature: the
necessity of understanding not “what there is in a
scene?", but “what is happening?”. For instance we
SIGMAP 2008 - International Conference on Signal Processing and Multimedia Applications
362
could develop safety systems able to recognise
anomalous and dangerous situations by automatic
extraction of scene semantics. This represents an
evident advantage of efficiency.
REFERENCES
Bobick A. and Davis J., 2001 “The Recognition of Human
Movement Using Temporal Templates,” IEEE
Transactions on Pattern Recognition and Machine
Intelligent, vol.23, pp. 257–267.
Bobick A.F. and Wilson A.D., 1997 “A State-Based
Technique to the Representation and Recognition of
Gesture”, IEEE Transactions on Pattern Analysis and
Machine Intelligent, Vol.19, pp.1325-1337.
Bouget J.Y., 1999 “Pyramidal Implementation of the
Lucas Kanade Feature Tracker. Description of the
Algorithm”, Intel Corporation, internal report.
Brand M. and Kettnaker V., 2000 “Discovery and
Segmentation of Activities in Video,” IEEE
Transactions on Pattern Analysis and Machine
Intelligent, Vol.22, pp.844-851.
Hu W., Tan T.,, Wang L., and Maybank S., 2004 “A
Survey on Visual Surveillance of Object Motion and
Behaviors” IEEE Transactions on Systems, Man, and
Cybernetics-Part C: Applications and Reviews, Vol.
34, No. 3.
Johansson G., 1973 “Visual Perception of Biological
Motion and Model of its Analysis”, Perception and
Psychophysics, Vol.14, pp.201-211.
Kang H., Lee C.-W., and Jung K., 2004 “Recognition-
Based Gesture Spotting in Video Games”, Pattern
Recognition Letters, Vol.25, No. 15, pp. 1701-1714.
Marchand-Maillet S., 2000 “Content-based Video
Retrieval: An overview”, Technical Report Vision.
Meier U., Stiefelhagen R., Yang J., and Waibel A., 2000
“Toward unrestricted lip reading,” International
Journal on Pattern Recognition and Artificial
Intelligent, Vol.14, no.5, pp.571-585.
Oliver N. M., Rosario B., and Pentland A. P., 2000 “A
Bayesian Computer Vision System for Modeling
Human Interactions,” IEEE Transactions on Pattern
Analysis and Machine Intelligent, Vol.22, pp.831-843.
Owens J. and Hunter A., 2000 “Application of the Self-
Organizing Map to Trajectory Classification,”
Proceedings of IEEE International Workshop on
Visual Surveillance, pp.77–83.
Rumelhart D., Ortony A., 1964 “The Representation of
Knowledge in Memory” In R.C. Anderson, R.J. Spiro,
W.E. Montague (Eds.) Schooling and the acquisition
of knowledge pp.99-135. Hillsdale, NJ: Erlbaum.
Rumelhart D.E., Hinton G.E., and Williams R.J., 1986
“Learning Representations by Back-propagation of
Errors”, Nature, Vol.323, pp.533-536.
Runeson S., 1994 “Perception of Biological Motion: the
KSD-Principle and the Implications of a Distal Versus
Proximal Approach”. In G. Jansson, W. Epstein & S.
S. Bergström (Eds.), Perceiving events and objects,
pp.383-405.
Sumpter N. and Bulpitt A., 2000 “Learning Spatio-
Temporal Patterns for Predicting Object Behaviour,”
Image and Vision Computing, Vol.18, No.9, pp.697–
704.
Venkatesh Babu R. and Ramakrishnan K.R., 2004
“Recognition of Human Actions using Motion History
Information Extracted from the Compressed Video”,
Image and Vision Computing, Vol.22, No.8, pp.597-
607.
Viviani P. and Schneider R., 1991 “A Developmental
Study of the Relationship Between Geometry and
Kinematics in Drawing Movements” Journal of
Experimental Psychology: Human Perception and
Performance, Vol.17, pp.198-298.
Yoon H., Soh J., Bae Y. J., Yang H.S., 2001 “Hand
Gesture Recognition Using Combined Features of
Location, Angle, and Velocity”, Pattern Recognition,
Vol.34, pp.1491-1501.
CAPTURING THE HUMAN ACTION SEMANTICS USING A QUERY-BY-EXAMPLE
363
