HOW TO PRESERVE PATIENT’S PRIVACY AND ANONYMITY IN

WEB-BASED ELECTRONIC HEALTH RECORDS

Daniel Slamanig and Christian Stingl

School of Medical Information Technology, Carinthia University of Applied Sciences, Primoschgasse 10, Klagenfurt, Austria

Keywords:

Anonymity, Cryptography, Electronic Health Record, Health Data, Information Security, Privacy.

Abstract:

In recent years, demographic change and increasing treatment costs demand the adoption of more cost efﬁ-

cient, highly qualitative and integrated health care processes. The rapid growth and availability of the Internet

facilitate the development of eHealth services and especially of electronic health records (EHRs) which are

promising solutions to meet the aforementioned requirements. Considering actual web-based EHR systems,

patient-centric and patient moderated approaches are widely deployed. Besides these initiatives there is an

emerging market of so called personal health record platforms, e.g. Google Health. Both concepts provide a

central and web-based access to highly sensitive data of EHRs. Additionally, the fact that these EHR systems

may be hosted by not fully trustworthy providers necessitates to thoroughly consider privacy issues. In this

paper we deﬁne security and privacy objectives that play an important role in context of web-based EHRs.

Furthermore, we discuss deployed solutions as well as concepts proposed in the literature with respect to this

objectives and point out several weaknesses. Finally, we introduce a system which overcomes the drawbacks

of existing solutions by considering an holistic approach to preserve patient’s privacy and discuss the applied

methods in detail.

1 INTRODUCTION

In recent years many countries have installed eHealth

initiatives and working groups in order to develop

strategies to harmonize the exchange of health re-

lated information using the Internet. A central as-

pect of eHealth is called the electronic health record

(EHR) which integrates all relevant medical informa-

tion of a person and represents a lifelong documenta-

tion of the medical history. Considering implementa-

tions of EHRs, one of the most critical factors of suc-

cess is the protection of the patient’s privacy, which

is clearly reﬂected in surveys concerning such sys-

tems (HI, 2004). Additional issues are, that the EHR

is patient-centered and that the patient herself moder-

ates her EHR (Pyper et al., 2004). This means, that

solely the patient is able to grant access to her medi-

cal data to other parties and to nominate delegates re-

spectively. Moreover, the study in (Pyper et al., 2004)

shows, that patient access to their electronic records

needs to be developed in partnership with the patients.

In this paper we are considering web-based EHR sys-

tems which enable persons to manage their EHRs by

means of a web-application.

Besides the classical aspects such as standardization,

interoperability, time and location independent ac-

cess, legal frameworks, etc. basic requirements for

web-based EHRs are the possibility for a patient to

freely deﬁne the structure (e.g. folders) of the EHR

and to share medical data or even the entire EHR

with other parties (e.g. physicians, relatives). Fur-

thermore, we will introduce and discuss further as-

pects and concepts which are especially applicable for

patient-moderated and web-based EHRs. This con-

sideration for EHR architectures helps to improve the

trustworthiness of an EHR system by means of pri-

vacy preserving techniques.

The organization of the rest of the paper is as follows:

In the subsequent section 2 we motivate why privacy

issues are important in this context and deﬁne poten-

tial attacker models. We propose and discuss basic

management, security and privacy relevant objectives,

which need to be considered when designing privacy

enhanced EHRs in section 3. Based on these objec-

tives in section 4 we investigate systems which are

explicitly designed to provide EHRs as well as sys-

tems which are not originally developed to manage

EHRs but may also be used to store health related

257

Slamanig D. and Stingl C. (2009).

HOW TO PRESERVE PATIENT’S PRIVACY AND ANONYMITY IN WEB-BASED ELECTRONIC HEALTH RECORDS.

In Proceedings of the International Conference on Health Informatics, pages 257-264

DOI: 10.5220/0001547502570264

 SciTePress

data. In the subsequent section 5 we introduce a novel

system for EHRs called PE

HR (Privacy Enhanced

EHR) that realizes the security and privacy objectives

deﬁned in section 3. In the remaining section 6 we

will provide a conclusion and discuss some future as-

pects.

2 MOTIVATION

Web-based EHR solutions are growing in popularity

and provide mechanisms that enable people to com-

fortably manage their medical data online and further-

more help to improve the quality of care, by means of

availability of all relevant medical data. However, in

context of the Internet we are confronted with a set of

attacker models and threats that need to be considered

when designing systems which deal with sensitive

data. For example, the lack of anonymity in Internet

communication and the trustworthiness of providers

hosting such EHR systems may constitute serious

problems. Additionally, there exists a phenomenon

often denoted as privacy myopia. This means, that

people often are not aware of dangers related to the

“ordinary” use of the Internet, e.g. that they reveal

IP-addresses or Ethernet MAC-addresses which may

enable third parties to link several actions and may

even enable them to identify the physical users behind

their computers. Furthermore, users often give away

their data very easily, without reﬂecting on potentially

negative consequences.

2.1 Attacker Models

In order to identify realistic threats, we need to con-

sider potential attackers ﬁrstly, which are listed sub-

sequently.

• Client intruder: This kind of attackers breaks into

the client computer, e.g. they compromise a host

by means of malware, e.g. trojan horses, and thus

obtain access to sensitive data which should solely

be available to its owner. This threat is highly re-

alistic and indeed one of the major problems in

context of the Internet and should be reduced by

means of trusted computing (TCG, 2008) in the

future.

• Eavesdropper: An eavesdropper compromises or

owns a subset of nodes of the communication in-

frastructure and thus is able to inspect messages

which are routed over them. This attacker is usu-

ally able to link communicating parties by means

of addresses used by the communication media

(e.g. IP-addresses) and to fully access content

data of messages in absence of transmission en-

cryption (e.g. SSL/TLS).

• Curious insider or server intruder: This attacker is

in possession of administrativeprivileges and thus

has full access to log information as well as con-

tent data of the EHR system. Clearly, in analogy

to the client intruder an external adversary may

also compromise a host which provides server ap-

plications.

In this work we are especially interested in the lat-

ter two types of attackers, since in absence of trusted

computing and remote attestation in particular, it is

very hard to decide whether client hosts are secure or

not.

In context of eavesdropping, even if transmission en-

cryption is used, the attacker may be able to obtain in-

formation about users which are communicating with

an EHR system. Thus, an attacker is able to derive

communication patterns. In order to hide these pat-

terns from external parties, e.g. how often a user

logs into the system, we need to investigate com-

munication anonymity (cf. section 5). Additionally,

there exist potential attackers which are located at the

provider of the EHR system. As a recent study (CSI,

2007) shows, more than 50% of attacks against infor-

mation system are conducted by insiders, and hence

this threat is highly realistic. Consequently, the trust-

worthiness of service providers is in question and we

need to design and investigate concepts, which pro-

tect content as well as metadata (e.g. relationships

between users and data objects) from insiders in or-

der to improve their privacy.

3 SECURITY AND PRIVACY

OBJECTIVES FOR EHR’S

In this section we propose and discuss security and

privacy objectives which need to be considered when

designing privacy enhanced EHRs. Before discussing

the main objectives in detail, we want to point out that

there are some basic functionalities which need to be

provided by any serious EHR system. These func-

tionalities comprise amongst others the availability of

the system, the conﬁdentiality of data transmitted be-

tween users and the system (e.g. SSL/TLS) and the

integrity of stored data.

A major criterion for the choice of these objectives

was the inﬂuence of a user on the degree of privacy.

More precisely, considering a single objective, the

privacy protection depends mainly on the provider or

on the user, subject to the applied method. For exam-

ple, conﬁdentiality can be realized on the one hand

HEALTHINF 2009 - International Conference on Health Informatics

258

by means of client-side encryption (by the user, e.g.

XML-Encryption) and on the other hand by means of

server-side encryption (by the provider, e.g. database

encryption).

Subsequently we will provide a brief discussion re-

garding our objectives.

3.1 Anonymity

Anonymity is often referred to as the property of be-

ing not identiﬁable with respect to a set of actions

inside a group of people, the so called anonymity

set (Pﬁtzmann and K¨ohntopp, 2000). Intuitively the

degree of anonymity is the higher, the larger the

anonymity set is and the more uniformly the actions

are distributed within this set. Considering an EHR

system we can deﬁne anonymity at three different lev-

els.

• Anonymous communication: Anonymous com-

munication is guaranteed, if an observer is not

able to determine a communication relationship

between two communicating parties by means of

information revealed by the communication chan-

nel.

• Sender- and receiver-anonymity: A communica-

tion relationship between a sender and receiver

provides sender-anonymity, if the receiver is not

able to identify the sender by means of received

messages. The receiver-anonymity can be deﬁned

analogously.

• Data anonymity: A system provides data

anonymity, if data stored in the system of the re-

ceiver and related to a speciﬁc sender can not be

linked to the sender by the receiver and any other

person. This means, that even an insider of a sys-

tem is not able to establish a relationship between

a patient and her related data. Consequently, seri-

ous measures to provide data anonymity must be

realized by the sender.

3.2 Authentication

If access to a system is restricted to an authorized set

of users, the systems needs to establish the identity

of a potentially authorized user. This is in general

realized by means of authentication mechanisms. In

authentication or identiﬁcation protocols the holder of

an identity usually claims a set of attributes including

an identiﬁer and interactively proves the possession

of the claimed identity to a veriﬁer based on these

attributes. This identiﬁer is usually unique within a

speciﬁc context (e.g. application) and thus enables

the system to link an authentication and subsequent

transactions to a speciﬁc user.

The above mentioned authentication mechanisms ob-

viously establishes a one-to-one mapping between

an authenticating user and her identity. In contrast,

anonymous authentication (cf. section 5.2) provides

mechanisms such that the before mentioned one-to-

one mapping does not longer exist. In particular, an

authenticating user proves solely her membership in a

group of authorized users, whereas the veriﬁer is not

able to decide which member of this group actually

conducted the authentication.

3.3 Authorization

Authorization is the concept of providing access to

resources only to users who are permitted to do so.

Usually the process of authorization takes place af-

ter a successful authentication. Mainly, authorization

concepts in systems are realized by means of dis-

cretionary access control (DAC) strategies, e.g. ac-

cess control lists (ACLs) or mandatory access con-

trol (MAC) strategies, e.g. role based access control

(RBAC) (Win, 2005). In the former case, the access

policies for objects are speciﬁed by the their owners

whereas in the latter case access policies are speciﬁed

by the system. The before mentioned strategies rep-

resent only a selection methods which exist in the lit-

erature and in practice today (Bishop, 2002), however

they share one important commonality. These strate-

gies are implemented by means of application layer

mechanism which can be easily bypassed by insiders

of the respective system.

3.4 Conﬁdentiality

In context of EHRs, which provide web-based ac-

cess to health related data, methods to guarantee con-

ﬁdentiality are essential. In general, conﬁdentiality

is realized by means of encryption and relies on the

protection of the respective cryptographic keys. For

the key management we distinguish two widely used

techniques. On the one hand cryptographic keys are

solely accessible to the user and all cryptographic op-

erations are performed by the user’s client (client-side

encryption). On the other hand the system at the

provider is responsible for the key management and

all cryptographic operations (server-side encryption).

From the security point of view, client-side encryp-

tion provides a higher level of conﬁdentiality, since

content data is not available in plaintext at any time

at the provider. Thus, the number of feasible attacks

can be reduced signiﬁcantly. It must be mentioned,

that in this paper we are not considering proprietary

encryption-software that may be applied by the user

HOW TO PRESERVE PATIENT’S PRIVACY AND ANONYMITY IN WEB-BASED ELECTRONIC HEALTH

RECORDS

259

in addition to mechanism provided by the EHR sys-

tem.

3.5 Deniability

One major advantage of a web-based EHR is the time

and location independent availability of health related

data. However, under certain circumstances this can

be disadvantageous and even result in dramatic con-

sequences for the user. In order to demonstrate this

problem, we will provide an example which is in our

opinion highly realistic. Assume that a person was

suffering from a cardiovascular diseases, diseases of

the musculoskeletal system, drug addiction or a men-

tal diseases like (burn out) depression. This disease is

in detail documented in the EHR of the person, how-

ever does not affect the current state of health of that

person signiﬁcantly. It is obvious, that this potentially

compromising information is solely available for per-

sons who are directly involved in the medical treat-

ment process of the person and are authorized to ac-

cess these data. In our opinion this is a basic require-

ment of an EHR. Consequently, there is absolutely no

way for unauthorized persons to gain access to these

data by means of the EHR system. However, since

the EHR is accessible via the Internet, the user her-

self may be “motivated” or even enforced to present

this compromising data during a job interview or an

insurance contract conclusion. This is what we call

the disclosure attack. It must be emphasized, that a

person which has presented her EHR under such cir-

cumstances is not able to prove this involuntary dis-

closure to another party later on. Thus, there exists

the need for mechanisms to plausibly deny the ex-

istence of highly compromising information (e.g. a

cured burn out depression) from people who dot not

need to know that information at all.

3.6 Unlinkability

Unlinkability of items of interest means that relations

between items, which a priori exist, can not be iden-

tiﬁed through pure observation of the system (Pﬁtz-

mann and K¨ohntopp, 2000; Steinbrecher and K¨opsell,

2003). A system containing n users provides perfect

unlinkability, if the relation of an object and a user u

exists with probability p = 1/n for all objects. Hence,

an insider of the system can not gain any informa-

tion on links between users and objects by means of

solely observing the system. In context of EHR sys-

tems we additionally need to consider static as well

as dynamic aspects of unlinkability. The static as-

pect covers data objects which are stored in the EHR

system and unlinkability is provided, if an insider at

the system is not able to establish links between data

objects and users signiﬁcantly better than guessing.

The dynamic aspect covers user’s interaction with the

system. In particular, we raise the question whether

an eavesdropper or an insider at the system is able to

link instances of authentication protocols and transac-

tions with the system together and to a speciﬁc user.

Clearly, a system which does not provide dynamic un-

linkability also negativelyinﬂuences static unlinkabil-

ity aspects. For example, if a transactions represents

an access to a speciﬁc data object and this transaction

can be linked to a speciﬁc user then the data object

linked to the user, although the system may provide

static unlinkability.

3.7 Data Structure

The data structure deﬁnes primarily the logical struc-

ture of the EHR, e.g. a hierarchy of users, folders,

subfolders and documents. In contrast to the objec-

tives discussed above, the data structure does not con-

tribute to the overall security of the system. However,

the data structure is the main componentregarding the

usability and efﬁciency of the EHR system. More-

over, the degree of structuredness massively inﬂu-

ences the concepts used for authorization. Especially,

when considering sharing of health data between sev-

eral parties the absence of any structure complicates

standardized mechanisms for this task.

We want to point out that the data structure always

contains information on the entire system (metadata),

which may potentially reduce the degree of privacy,

e.g. unlinkability, authorization, provided by the sys-

tem. For example, if a system holds pseudonymized

or even anonymized medical documents then authen-

tication information and information provided by the

data structure can be used to identify the holder of the

respective documents.

4 INVESTIGATION OF EHR

SYSTEMS

Prior to presenting our proposed solution in detail,

we investigate systems which are either explicitly de-

signed to provide web-based EHR functionality, i.e.

Personal health record platforms, PIPE, and systems

which may be used by people to “build” their own

web-based EHR, i.e. virtual hard disks. This investi-

gation is based on the security objectives introduced

in section 3 and summarized in Table 1. In the re-

mainder of this section we provide a discussion of the

above mentioned systems with respect to the security

objectives.

HEALTHINF 2009 - International Conference on Health Informatics

260

Table 1: This table provides an analysis of the virtual hard

disk concept (VHD), Google Health (GH), the PIPE system

and our system introduced in section 5 regarding the objec-

tives deﬁned in section 3. Thereby C denotes client-side, S

server-side, SC a combination thereof, ¬ denotes that this

feature is not provided and ? denotes that it is not clear

whether this feature can be provided. In context of authen-

tication T denotes traditional and A anonymous authentica-

tion.

Objective VHD GH PIPE PE

Comm. anonymity O O O C

Sender anonymity ¬ ¬ ¬ C

Data anonymity ¬ ¬ ? C

Authentication T T T A

Authorization S S C C

Conﬁdentiality ? ? ? C

Deniability ¬ ¬ ¬ C

Unlinkability ¬ ¬ ? C

Data structure C SC ¬ SC

4.1 Virtual Hard Disk

This approach provides remote storage space which is

accessible via the Internet. It offers the user the pos-

sibility to realize arbitrary folder structures for data

management, usually by means of the WebDav proto-

col. Typical representatives are iDisk (Apple), Xdrive

(AOL) and Gspace (Google). Considering these prod-

ucts one can conclude that authentication is realized

by means of traditional authentication methods, e.g.

username/password, and authorization is realized by

means of DAC or MAC strategies. The data struc-

ture is solely determined by the user. In general meth-

ods to guarantee conﬁdentiality are not integrated into

these products, however server-side encryption could

be established. Methods for the remaining objectives

are not yet implemented in the above mentioned prod-

ucts, as far as we could ﬁnd out.

4.2 Personal Health Record Platforms

Personal health record platforms provided by major

vendors such as Google (Google Health) or Microsoft

(Health Vault) are growing in popularity. For ex-

ample, Google provides a patient centric and patient

moderated system, that offers the possibility to orga-

nize health related data of a person and moreover en-

ables the integration of third party services offered by

physicians, hospitals and pharmacies. As above, the

same arguments hold for these systems, but the server

takes inﬂuence on the data structure by demanding

certain aspects of this structure.

4.3 PIPE

The architecture PIPE (pseudonymizationof informa-

tion for privacy in eHealth) (Riedl et al., 2007; Riedl

et al., 2008) focuses on the management of person re-

lated medical documents in a pseudonymizedfashion.

In this context pseudonymization means the replace-

ment of personal information by a document related

speciﬁer which is not linkable to the holder of the

document. The authorization for pseudonymized doc-

uments is realized by means of a hierarchical struc-

ture of cryptographic keys and encrypted document

related speciﬁers. Both can be shared with other

users. One major aspect of the architecture is the

establishment of key-backup mechanisms based on

threshold secret sharing schemes. The latter aspect

positively inﬂuences the availability of cryptographic

keys, however, has no positive impact on security and

privacy properties considered in this paper.

Authentication against the system is realized by ap-

plying digital signatures, whereas the used protocol

easily allows impersonation attacks. However, the au-

thentication solely provides access to the encrypted

master cryptographic key of the user, which will sub-

sequently be decrypted at the client. In context of

an EHR the above mentioned pseudonymization is in

our opinion impractical when using different medical

document types, because they always contain unstruc-

tured narrative text passages (even CDA Level 3).

Consequently, the pseudonymization has to be per-

formed manually, and hence the effort would be unac-

ceptable in our opinion. Additionally, data anonymity

can not be guaranteed when not using anonymous au-

thentication. For example, if a patient integrates a

pseudonymized medical ﬁnding into the system, then

this document will be linkable to the authenticating

party (the patient) by an insider. The same argument

holds for the objective unlinkability. Conﬁdentiality

is not taken into the consideration in (Riedl et al.,

2007; Riedl et al., 2008) due to the pseudonymiza-

tion. The remaining objectives are not provided by

this architecture. The data structure can not be ana-

lyzed seriously due to the facts that a simple concep-

tual model is used and further crucial details are not

published. Additionally, it must be emphasized that

the “pseudonymization” of more complex conceptual

models requires more sophisticated methods (Sla-

manig et al., 2007).

5 PRIVACY ENHANCED EHR

In this section we discuss methods that help to pre-

serve the patient’s privacy in context of EHRs with

HOW TO PRESERVE PATIENT’S PRIVACY AND ANONYMITY IN WEB-BASED ELECTRONIC HEALTH

RECORDS

261

respect to the security and privacy objectives deﬁned

in section 3.

5.1 Anonymous Communication

Mechanisms that provide anonymity and unlinkabil-

ity of messages sent over a communication channel

are denoted as anonymouscommunication techniques

and have been intensively studied in recent years,

see (Danezis and Diaz, 2008) for a sound overview.

There are several implementations available for low-

latency services like Web browsing, e.g. Tor (Din-

gledine et al., 2004), JAP (Federrath, 2005) as well

as high-latency services like E-Mail, e.g. Mixmin-

ion (Danezis et al., 2003).

These anonymous communication channels help to

improve the privacy of users in context of eavesdrop-

pers and curious communication partners. Especially,

regarding the latter one anonymity can be preserved if

electronic interaction does not rely on additional iden-

tifying information at higher network layers, i.e. the

application layer. For example, a user who queries a

public web page using an anonymous communication

channel may remove all identifying information from

higher network layers and thus can stay anonymous.

However, if service providers offer their services only

to authorized sets of users (e.g. subscription-based

services, closed communities), they require identiﬁ-

cation which in general takes place at higher layers

by means of authentication mechanisms. In the lat-

ter context anonymity can however be preserved by

means of anonymous authentication.

5.2 Anonymous Authentication

Anonymous authentication aims to provide a some-

what paradoxical solution to enhance user’s privacy

in context of authentication. It provides mechanisms

such that a user is able to prove membership in a

group U

′

⊆ U of authorized users U, whereas the ver-

iﬁer does not obtain any information on the identity

of the user. Clearly, anonymous communication sys-

tems are a prerequisite for providing anonymity in the

context of anonymous authentication.

A naive approach to realize anonymous authentica-

tion would be to give a copy of a secret k to every

user u ∈ U, which could be used in conjunction with

a traditional authentication scheme. Obviously, the

revocation of a single user u

would result in a reini-

tialization and thus in reissuing a new secret k

′

to ev-

ery user u ∈ U \ u

. Hence, this approach is far from

being practical. Improved techniques for anonymous

authentication were explicitly treated in (Boneh and

Franklin, 1999; Lindell, 2007; Schechter et al., 1999)

and can additionally be derived from group signatures

(Ateniese et al., 2000; Chaum and van Heyst, 1991,

etc.), ring signatures (Rivest et al., 2001; Dodis et al.,

2004, etc.) or similar concepts as (deniable) ring au-

thentication (Naor, 2002), whereas the latter class of

signatures and authentication schemes is preferable to

group signatures in the context of large groups, since

they can be generated “ad hoc” without depending on

an explicit setup phase.

5.3 Authorization and Conﬁdentiality

In contrast to strategies implemented by means of ap-

plication layer mechanism (see section 3.3) there ex-

ists the possibility to realize DAC based on crypto-

graphic tokens (Stingl et al., 2006). In particular, all

resources are encrypted by their owners (client-side

encryption) which hold the corresponding secret keys

and are stored encrypted in the system. In particular,

if a user grants access to another user she provides a

cryptographic token to this user. This cryptographic

token represents the secret key to the respective data

object, encrypted with the public key of the grantee.

In other words, access control based on cryptographic

tokens is realized by means of the ability of autho-

rized persons to properly decrypt resources, e.g. con-

tent data. This access control strategy provides a se-

rious advantage in comparison with the before men-

tioned strategies, namely insiders are solely able to

bypass the access control by breaking the underlying

cryptographic primitives (symmetric resp. asymmet-

ric cryptosystem). Additionally, it can be used to re-

alize ﬁne-grained access, i.e. to single data objects, in

contrast to approaches which allow to share all data

or no data with other persons, e.g. physicians, (De-

muynck and Decker, 2005).

5.4 Pseudonymization

Pseudonymization of person related data (u,x) is the

process of replacing every person identiﬁer u for ex-

ample by the value nym = E

(u), where E

is an ap-

propriate symmetric encryption function with a corre-

sponding secret key k. Since k is kept secret it is prac-

tically impossible to invert E

(·) without the knowl-

edge of k and thus compute u given the value nym.

However, a person which is in possession of k can

easily compute D

(nym) = u using the corresponding

decryption function D

(·). Hence (nym,x) can not be

linked to u anymore.

We realize pseudonymization by letting every user u

choose a second identiﬁer P

uniformly at random,

i.e. a pseudonym (Chaum, 1981). This pseudonym is

used by her to identify her shares. In order to pre-

HEALTHINF 2009 - International Conference on Health Informatics

262

vent the linkage between a user and a pseudonym,

the pseudonym is solely stored in an encrypted fash-

ion, E

), in the user repository. The unlinka-

bility holds, since P

is independently chosen from

and furthermore E

) can only be inverted

by u

, who holds the corresponding key k

(which

can be derived from a appropriately chosen password

or passphrase deﬁned by u

). This simple example

can be generalized to pseudonymize an arbitrary con-

ceptual model (Slamanig et al., 2007). The result-

ing pseudonymized conceptual model provides data

anonymity and static unlinkability (concerning any

observer of the system) and it enables highly efﬁcient

implementations. Additionally, by means of anony-

mous authentication the system provides dynamic un-

linkability. Furthermore, it must be emphasized that

the conceptual model can be deﬁned by the EHR sys-

tem and users are able to freely create their own struc-

tures with respect to the conceptual model.

5.5 Multiple Identities

However, there still exists the precarious disclosure

attack which can lead to the disclosure of the com-

plete EHR of a person. Therefore we need a mea-

sure to provide plausible deniability in a cryptograph-

ically provable sense. As countermeasure we propose

the use of so called multiple identities (Slamanig and

Stingl, 2008b). In this context multiple identities can

be described by means of dividing the EHR of a per-

son into so called sub-identities (see Figure 1).

Non

compromi-

sing

User

Super-Identity: Person

Internal medicine

Orthopedics

General medicine

ELectronic Health Record

Inclusion

Emergency

Dentist

Figure 1: Multiple identities.

A user can assign a subset of her EHR to each

of these sub-identities. Thereby, these subsets do not

need to be disjoint. Subject to the person, the medical

data are presented to, the user is able to choose one of

her sub-identities (e.g. a special prepared, non com-

promising one) and consequently opens the assigned

subset of medical data. Hence, a user can hide sensi-

tive data in a special sub-identity in order to prevent

disclosure of medical data. However, one drawback

of this approach is that passwords which are used to

derive the cryptographic keys for the respective iden-

tities need to be chosen independently of each other.

More precisely, there must not be any relationship be-

tween passwords which clearly could be computed by

an adversarytoo. However, we assume that in practice

the number of identities and passwords respectively

will be moderate. Furthermore, this concept addition-

ally provides the possibility to create so called super-

identities which can hold several sub-identities. Thus,

super-identities can be used to comfortably manage

the respective sub-identities.

6 CONCLUSIONS

In this paper we discussed security and privacy as-

pects which are especially of relevance in context of

web-based EHR systems. Following these objectives,

we investigated deployed solutions for EHR systems

as well as concepts discussed in the literature. Re-

garding these systems we can conclude that either pa-

tient’s need to fully rely on the trustworthiness of the

provider of an EHR system (e.g. Google Health) or

there exist methods to bypass the implemented se-

curity concepts. This is due to the fact that security

concepts are focusing solely on speciﬁc aspects and

not the entire EHR system. However, in our opinion

it is absolutely necessary to consider all the relevant

security objectives in order to provide an adequate

protection of the patient’s privacy. Nevertheless, by

applying speciﬁc methods (e.g. anonymous authenti-

cation) one is confronted with additional challenges.

For example, in context of anonymous authentication

it is apparently impossible to realize user speciﬁc re-

source limits. Actually, we are working toward a so-

lutions based on blind signature techniques. Further-

more, we are investigating strategies for the choice

of anonymity sets for anonymous authentication. The

latter aspect is crucial, since not appropriately cho-

sen strategies may lead to unwanted user identiﬁca-

tion (Slamanig and Stingl, 2008a).

REFERENCES

Ateniese, G., Camenisch, J., Joye, M., and Tsudik, G.

(2000). A Practical and Provably Secure Coalition-

Resistant Group Signature Scheme. In Advances in

Cryptology – CRYPTO ’00, pages 255–270. Springer.

Bishop, M. (2002). Computer Security: Art and Science.

Addison-Wesley.

Boneh, D. and Franklin, M. (1999). Anonymous authenti-

cation with subset queries. In Proc. of the 6th ACM

conference on Computer and communications secu-

rity, pages 113–119.

HOW TO PRESERVE PATIENT’S PRIVACY AND ANONYMITY IN WEB-BASED ELECTRONIC HEALTH

RECORDS

263

Chaum, D. (1981). Untraceable electronic mail, return ad-

dresses, and digital pseudonyms. Commun. ACM,

24(2):84–90.

Chaum, D. and van Heyst, E. (1991). Group signatures. In

Advances in Cryptology – EUROCRYPT ’91, LNCS,

pages 257–265.

CSI (2007). Computer Crime and Security Sur-

vey 2007, Computer Security Institute.

http://www.gocsi.com/forms/csi survey.jhtml.

Danezis, G. and Diaz, C. (2008). A Survey of Anonymous

Communication Channels. Technical Report MSR-

TR-2008-35, Microsoft Research.

Danezis, G., Dingledine, R., and Mathewson, N. (2003).

Mixminion: Design of a Type III Anonymous Re-

mailer Protocol. In SP ’03: Proceedings of the 2003

IEEE Symposium on Security and Privacy, pages 2–

15, Washington, DC, USA. IEEE Computer Society.

Demuynck, L. and Decker, B. D. (2005). Privacy-

Preserving Electronic Health Records. In Commu-

nications and Multimedia Security, 9th IFIP TC-6

TC-11 International Conference (CMS 2005), volume

3677 of LNCS, pages 150–159. Springer-Verlag.

Dingledine, R., Mathewson, N., and Syverson, P. (2004).

Tor: The Second-Generation Onion Router. In Pro-

ceedings of the 13th USENIX Security Symposium,

pages 21–21.

Dodis, Y., Kiayias, A., Nicolosi, A., and Shoup, V. (2004).

Anonymous Identiﬁcation in Ad Hoc Groups. In

Advances in Cryptology - EUROCRYPT’04, volume

3027 of LNCS, pages 609–626.

Federrath, H. (2005). Privacy Enhanced Technologies:

Methods, Markets, Misuse. In Proceedings of the 2nd

International Conference on Trust, Privacy, and Secu-

rity in Digital Business (TrustBus ’05), volume 3592

of LNCS, pages 1–9. Springer-Verlag.

HI (2004). Harris Interactive, Survey on Medical Privacy.

http://www.harrisinteractive.com/news/newsletters/

healthnews/HI HealthCareNews2004Vol4 Iss13.pdf.

Lindell, Y. (2007). Anonymous Authenticaion.

Whitepaper Aladdin Knowledge Systems, 2007,

http://www.aladdin.com/blog/pdf/Anonymous

Authentication.pdf.

Naor, M. (2002). Deniable Ring Authentication. In

CRYPTO ’02: Proceedings of the 22nd Annual Inter-

national Cryptology Conference on Advances in Cryp-

tology, LNCS, pages 481–498. Springer-Verlag.

Pﬁtzmann, A. and K¨ohntopp, M. (2000). Anonymity,

Unobservability, and Pseudonymity - A Proposal for

Terminology. In Workshop on Design Issues in

Anonymity and Unobservability, pages 1–9.

Pyper, C., Amery, J., Watson, M., and Crook, C. (2004).

Access to Electronic health records in primary care –

a survey of patients views. Med Sci Monit, 10(11):17–

22.

Riedl, B., Grascher, V., and Neubauer, T. (2008). A Se-

cure e-Health Architecture based on the Appliance of

Pseudonymization. Journal of Software, 3(2):23–32.

Riedl, B., Neubauer, T., Goluch, G., Boehm, O., Reinauer,

G., and Krumboeck, A. (2007). A Secure Architec-

ture for the Pseudonymization of Medical Data. In

Proceedings of the The Second International Confer-

ence on Availability, Reliability and Security (ARES

2007), pages 318–324. IEEE Computer Society.

Rivest, R. L., Shamir, A., and Tauman, Y. (2001). How

to Leak a Secret. In Advances in Cryptology – ASI-

ACRYPT ’01, LNCS, pages 552–565. Springer.

Schechter, S., Parnell, T., and Hartemink, A. (1999).

Anonymous Authentication of Membership in Dy-

namic Groups. In Proc. International Conference on

Financial Cryptography 99, volume 1648 of LNCS,

pages 184–195. Springer-Verlag.

Slamanig, D. and Stingl, C. (2008a). Anonymous Au-

thentication - Principles and Application (German).

In Horster, P., editor, Proceedings of DACH-Security

2008, pages 123–134. IT-Verlag.

Slamanig, D. and Stingl, C. (2008b). Privacy Aspects of

eHealth. In Proceedings of theThe Third International

Conference on Availability, Reliability and Security

(ARES 2008), pages 1226–1233. IEEE Computer So-

ciety.

Slamanig, D., Stingl, C., Lackner, G., and Payer, U. (2007).

Preserving Privacy in a Web-based Multiuser-System

(German). In Horster, P., editor, Proceedings of

DACH-Security 2007, pages 98–110. IT-Verlag.

Steinbrecher, S. and K¨opsell, S. (2003). Modelling Un-

linkability. In Proceedings of Privacy Enhancing

Technologies workshop (PET 2003), volume 2760 of

LNCS, pages 32–47. Springer-Verlag.

Stingl, C., Slamanig, D., Rauner-Reithmayer, D., and Fis-

cher, H. (2006). Realization of a Secure and Central-

ized Data Repository (German). In Horster, P., editor,

Proceedings of DACH Security 2006, pages 32–45. IT-

Verlag.

TCG (2008). Trusted Computing Group.

http://www.trustedcomputinggroup.org.

Win, K. T. (2005). A review of security of electronic health

records. HIM J, 34(1):13–8.

HEALTHINF 2009 - International Conference on Health Informatics

264
