MAKING STRUCTURAL PATTERN RECOGNITION

TRACTABLE BY LOCAL INHIBITION

E. Michaelsen, L. Doktorski and M. Arens

Forschungsinstitut f¨ur Optronik und Mustererkennung, Gutleuthausstr. 1, 76275 Ettlingen, Germany

Keywords:

Structural pattern recognition, Local inhibition.

Abstract:

Declarative knowledge and control decisions on the sequence of interpretation acts are separated in a structural

pattern recognition system. The control can be optimized leaving the knowledge ﬁxed. A simple production

system is used as declarative example knowledge. It is tailored to recognize and locate rectangles in images

– where object primitives are several thousand very short contour segments. Different control strategies can

be realized: (i) a simple quality driven bottom-up control; (ii) an heuristic strategy punishing object instances

which have been partner in an already performed reduction and (iii) a new psychologically inspired strategy

that combines local inhibition with less local excitation. These strategies are compared quantitatively on

synthetic data and qualitatively on a real aerial image.

1 INTRODUCTION

Controlling the search for feasible reductions given a

declarative knowledge structure – such as a produc-

tion system – and a set of measured primitive objects

has been an interesting topic ever since the proposal

of structural pattern recognition was put forth decades

ago. In particular production systems can implicitly

deﬁne huge combinatorial search spaces that cannot

be systematically explored with feasible effort. The

following three major requests are set for the con-

trol unit of a production system interpreter suitable for

pattern recognition and machine vision: (i) it should

avoid visiting the whole combinatorial search space;

in fact it should get along with working out only a

very tiny portion of it; (ii) it should be capable of

handling large numbers of object instances; and (iii)

it should have anytime capability in the sense that it

provides some reductions of full depth very early and

use additional time to check alternatives and improve

the evidence for the validity of the already found. If

run to a complete end or inﬁnitely the system should

approach a correct interpreter.

For these requests the correctness of the interpre-

tation system may be traded. The practitioner is sat-

isﬁed with approximate correctness as long as it does

not affect the usability and reliability of the system

on real data. In Section 2 of this contribution we

give an approximating interpreter that is tailored to

these requests. A particular simple system containing

only a few simple productions is given in Section 2.

It is complex enough to elaborate the differences –

yet simple enough to maintain an overview on what

is going on. Section 3 compares three control strate-

gies using this setup. Quantitative testing is done with

synthetic data and there is an additional qualitativeas-

sessment with a real aerial image. The remainder of

this chapter will set the work in relation to the pub-

lished state-of-the-art in the ﬁeld.

Automatic ”image understanding” has been a ma-

jor issue in pattern recognition for many decades

(Basu et al., 2005; Matsuyama and Hwang, 1990;

Draper et al.,1989). Most such proposals were tai-

lored to automatic recognition – of man-made struc-

ture in particular – from remote sensing data. But

structural and cognitive methods for image analy-

sis are not restricted to remote sensing applications.

There are also examples of similar structure that were

originally designed for medical applications (Nie-

mann et al., 1990) and for automatic reasoning for

safety in robotics (Qureshi et al., 2005). All of these

proposals contain also approaches to optimizing the

control – in particular ERNEST had a sophisticated

theory of optimal control with it. Syntactic methods

for image understanding recently gain interest again.

E. g., (Zhu and Mumford, 2006b) have introduced

a stochastic grammar for the understanding of im-

ages. Emphasis is not on efﬁcient control of user

deﬁned ﬁxed knowledge but on deﬁning a sound de-

scription langugage capable of capturing and learn-

381

Michaelsen E., Doktorski L. and Arens M. (2009).

MAKING STRUCTURAL PATTERN RECOGNITION TRACTABLE BY LOCAL INHIBITION.

In Proceedings of the Fourth International Conference on Computer Vision Theory and Applications, pages 381-384

DOI: 10.5220/0001767203810384

 SciTePress

ing diverse and general visual categories. Biological

inspiration for our inhibition/excitation function pre-

sented in Section 3 comes from interdisciplinary work

between perceptual psychology and computer vision

such as (Aziz and Mertsching, 2007). Our work can

be seen as a straight decendentand continuation of the

blackboard-based accumulating interpretation system

proposed in (Stilla and Michaelsen, 1997). There the

main application was seen in the recognition of man-

made structures – such as buildings – in aerial im-

agery. The system has also been used for other pur-

poses (compare (Michaelsen et al., 2006; Michaelsen

et al., 2006)).

Intelligent control has always been a major issue.

Using Gaussian local inhibition in order to acquire a

priority sorting for 3D-surface plane patches in laser-

data has been reported by (von Hansen et al., 2006a).

Though this work used the same interpretation dis-

patcher the inhibition was only performed after the

search in order to rank order the resulting object set.

In this contribution such inhibition is used for the con-

trol of the search for all kinds of objects during the

run.

2 A SIMPLE SYSTEM

The example production system acts on primitive ob-

jects called line, which are extracted from an image

with a gradient ﬁlter. For simplicity, the system only

has three non-primitive object classes, namely long-

line, angle and rectangle. The system contains the

three productions given in Table 1.

Table 1: Example production system. The terminal symbol

denotes lines, whereas the non-terminal symbols

, and

denote long lines, angles, and rectangles, respectively.

co−linear ∧ overlapping

−−−−−−−−−−−−−−−→

regression

·· ·

(1)

rectangular ∧ ad jacent

−−−−−−−−−−−−−−→

intersection

L L

(2)

crosswise ad jacent

−−−−−−−−−−−→

intersection

A A

(3)

We distinguish two normal forms of productions:

Normal form 1 generates a pair of objects from a sin-

gle non-terminal object. Productions of this form are

used for part-of intentions (compare productions (2)

and (3) in Table 1). Normal form 2 generates a set of

objects of arbitrary (ﬁnite) size of the same type from

a single non-terminal object. Such productions are

used for cluster intentions (Michaelsen et al., 2008).

Production (1) for example codes a Hough-type accu-

mulator for straight lines.

The system codes declarative knowledge for

searching rectangles in pictures. The interpretation

system we use approximates correct parsing. Pseudo-

code scheme Algorithm 1 explains the interpreter.

It works accumulating instead of reducing and thus

avoids backtracking. Hypotheses are constructed of

single (triggering) objects, and productions where

such objects appear on the right-hand side. Such hy-

potheses are tested by looking for appropriate partner

objects. Once the set fulﬁlling the query is found the

procedure is different for the two normal forms: for

productions of normal form 1 all elements of the set

are handled separately – according to the combina-

toric nature of the production system. Each possible

partner leads to a new and separate reduction possi-

bility. For productions of normal form 2 all elements

of the set are used for one minimization calculation.

They lead to exactly one new instance of the cluster

object type of the left hand side of the production.

Algorithm 1: Approximative interpretation of

production systems.

while queue not empty OR other break do

sort(queue);

set of hopothesis = choose best n(queue);

foreach trigger hypo ∈ set of hopothesis do

if p=nil then

remove queue(trigger hypo);

foreach q where trigger obj ∈ right-hand

side do

new priority = prio(q) *

priority(trigger hypo);

append queue(trigger elem, q,

new priority);

end

else

actual query =

construct query(trigger hypo);

candidate set = pose query(actual query);

if p of Normal form 1 then

foreach partner ∈ candidate set do

p:new elem ← (trigger elem,

partner);

add database(new elem);

construct null hypo(new elem);

end

else

p:new elem ← candidate set;

add database(new elem);

construct null hypo(new elem);

end

3 LOCAL INHIBITION

A frequent observation with the dispatcher control

unit of our systems showed that the same or very

similar intermediate non-primitive objects were mul-

tiply reduced from the same objects. Of course there

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

382

is a test for existence before the new elements are

appended to the set of reducible objects, so as to

avoid multiple listing in it, however, the computa-

tional effort for the query and construction method

is wasted. A more detailed observation of the phe-

nomenon revealed that, e. g., neighbouring primitive

line segments often get similar assessments, too. Thus

the corresponding working hypothesis tend to clus-

ter together also in the process queue and cause very

similar queries and constructions. One way to rem-

edy these unpleasant repetitions is the inclusion of

a remove-queue command for the hypothesis corre-

sponding to all the right-hand-side objects into the

modules coding the productions. This leads to very

efﬁcient systems. However, it contradicts the combi-

natoric nature of such production systems: only the

actual triggering hypothesis can (and must) be re-

moved, the others will cause differentqueries and thus

open different possibilities. With the remove-queue

command these possibilities are cut away which alters

the declarative semantics of the system. The remove-

queue command may be replaced by a re-assess com-

mand. This does not alter the declarative semantics of

the production system. It shifts all the repetitions to

the end of the interpretation run. If the interpretation

is halted long before the queue runs empty they will

not be performed anymore. For the experiments we

used an appropriate inhibition constant γ = 0.5 (com-

pare Algorithm 2).

Algorithm 2: Heuristic inhibition.

remove queue(hypothesis(triggering-element));

foreach objects x ∈ candidate set (and not

x=triggering-element) do

priority(hypo(p,x))=γ*priority(hypo(p,x));

end

Algorithm 3: ‘Biological’ local inhibition.

foreach hypo(o,p) 6= hypo(ot,pt) do

priority(hypo(o,p))=ω(o, ot)*priority(hypo(o,p));

end

The sequence of inspection – or saccade or gaze

control – has been subject of psychological inves-

tigations for a long time. There are also works

on incorporating such behaviours into computer vi-

sion systems. E. g., recently (Aziz and Mertsching,

2007) described a control mode they call ”examine

behaviour”. I. e. a particular part of the space un-

der observation becomes uninteresting when the focus

of interest has been there. The whole closer neigh-

bourhood is lowered in its priority. Instead a less

close neighbourhood is getting higher priority (is ex-

cited). In particular such objects get more priority

which have similar other attributes concerning prop-

erties like orientation, colour etc. Thus a sequence

of observation is achieved which follows perceptual

Gestalts almost the same way like human subjects do.

Following such ideas we have implemented a priority

upgrade function ω which is between zero and one in

a close neighbourhood and slightly greater than one

in the further neighbourhood:

ω = 1− (1+ α)e

−δ

+ αe

−

where δ

indicates a speciﬁc metric distance from the

object of the triggering hypothesis

= σ

loc

∗ |loc−loc(ot)|

+ σ

ori

∗ |ori− ori(ot)|

with weights σ

loc

and σ

ori

balancing location in the

image against orientation. The values of these pa-

rameters where set as σ

loc

= 0.0004 and σ

ori

= 0.08

(in 512x512 images and with orientation measured

in degree) after systematic optimization of the per-

formance. Thus local inhibiton is quite far reaching

with respect to the image location but quite narrow

with respect to orientation. ω becomes zero for δ

= 0

and ω is approaching one for δ

→ ∞. The weight of

the exciting versus the inhibiting effect of the function

depends on the parameter alpha. The experiments in-

dicated below used α = 0.9. Whenever a particular

hypothesis (ot,pt) is tested all other hypotheses of the

same object and production type are getting a priority

upgrade using this function.

4 EXPERIMENTS AND RESULTS

Experiments were performed with 200 randomly gen-

erated images each containing one ramdomly rotated,

sized (25-100), and positioned square with randomly

set greyvalue on black background,two circular disks

drawn with the same speciﬁcations, and ten lines of

three pixels width drawn accordingly. The images

were blurred and Gaussian noise was added. Each

image results in two or three thousand primitive lines

constructed with a gradient ﬁlter. The interpretation

using the production-system given in Section 2 was

halted when the queue ran empty or an instance of

the class rectangle was reduced. In the latter case the

experiment was counted as success if the object was

found in the correct position (with ﬁve Pixels toler-

ance).

We also made experiments with a real aerial im-

age. In the real data experiment the interpretation

was stopped, when twelve or more rectangles were

reduced. Tab. 1 shows the results for the three runs

(no inhibition, heuristic inhibition and Gaussian inhi-

bition/excitation). Red crosses indicate the centres of

the found rectangle objects.

MAKING STRUCTURAL PATTERN RECOGNITION TRACTABLE BY LOCAL INHIBITION

383

a b c

Figure 1: Objects Rectangle found on a real aerial image: a) no inhibition, b) heuristic inhibition, c) Gaussian inhibi-

tion/excitation.

Table 2: Results on synthetic images without, with heuris-

tic, and with biologically inspired inhibition.

success rate computational effort

no inh. 27% 100%

heur. inh. 29,3% 61,4%

bio. 30,8% 69,2%

While both – heuristic inhibition and Gaussian in-

hibition/excitation – need much less interpretation cy-

cles than the run without any inhibition (3200 and

3700 versus 5800 cycles) the spreading of the result-

ing rectangle objects looks much different: the Gaus-

sian control spreads its interest much more in the im-

age space. It marks several less salient rectangles as

well.

5 CONCLUSIONS

Both – the heuristic and the more sophisticated con-

trol scheme – are successful. An important point is

whether the extra administration effort spend for the

control calculations equalizes the gain in search ef-

fort. This is of course implementation dependent. An

important drawback are the extra parameters intro-

duced by the control which are domain-dependent.

REFERENCES

M. Z. Aziz and B. Mertsching: An Attentional Approach

for Perceptual Grouping of Spatially Distributed Pat-

terns. In: F. Hamprecht et al. (eds.): Proc. 29th

DAGM-Symposium 2007, LNCS 4713, Springer, pp.

345-354.

M. Basu et al. (eds): PAMI Special Issue on Structural and

Syntactical Methods, 27:7 (2005).

B. Draper, R. Collins, J. Brolio, A. Hanson, E. Riseman:

The Schema System. IJCV, Vol. 2 (1989) 209-250.

T. Matsuyama and V. S.–S. Hwang: Sigma a Knowledge–

based Image Understanding System. Plenum Press,

New York (1990).

E. Michaelsen, L. Doktorski, and M. Arens: Shortcuts in

Production Systems - A way to include clustering in

structural Pattern Recognition. Proceedings of PRIA-

9-2008, Vol. 2, Lobachevsky State University, Nis-

chnij Nowgorod, pp. 30–38.

E. Michaelsen, W. von Hansen, M. Kirchhof, J. Mei-

dow, and U. Stilla: Estimating the Essential Matrix:

GOODSAC versus RANSAC. ISPRS Symposium on

Photogrammetric Computer Vision PCV 2006, Bonn,

Germany, September 20-22 2006, Int. Archives of

Photogrammetry and Remote Sensing. Vol. XXXVI,

Part 3, PPV 2006, pp. 161–166, 2006.

E. Michaelsen, U. Soergel, and U. Thoennessen: Perceptual

Grouping in Automatic Detection of Man-Made Struc-

ture in high resolution SAR data. Pattern Recognition

Letters 27:4(2006) 218–225.

H. Niemann, G. Sagerer, S. Schr¨oder, F. Kummert:

ERNEST: A Semantic Network System for Pattern Un-

derstanding. PAMI 12:9(1990) 883–905.

F. Qureshi, D. Macrini, D. Chung, J. Maclean, S. Dickinson,

P. Jasiobedzki: A Computer Vision System for Space-

borne Safety Monitoring. 8th Int. Symposium on Arti-

ﬁcial Intelligence, Robotics and Automation in Space

(iSAIRAS), Munich (2005).

U. Stilla and E. Michaelsen: Semantic modelling of man-

made objects by production nets. In: A. Gr¨un et

al. (eds.): Automatic Extraction of Man–Made Ob-

jects from Aerial and Space Images (II). Birkh¨auser–

Verlag, pp. 43–52.

W. von Hansen, E.Michaelsen, U. Th¨onnessen: Cluster

Analysis and Priority Sorting in Huge Point Clouds

for Building Reconstruction. In Proc. 18th Int. Conf.

on Pattern Recognition (ICPR’06), Vol. 1, pp. 23-26,

2006.

S.–C. Zhu and D. Mumford: A Stochastic Grammar of Im-

ages Foundations and Trends in Computer Graphics

and Vision 2:4 (2006) 259–362.

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

384
