RELATIVE DISTANCE METHOD FOR LOSSLESS IMAGE

COMPRESSION ON PARALLEL ARCHITECTURES

A New Approach for Lossless Image Compression on GPU

Luca Bianchi, Riccardo Gatti, Luca Lombardi

Computer Vision Lab, University of Pavia, Via Ferrata 1, Pavia, Italy

Luigi Cinque

Department of Computer Science, University of Roma “La Sapienza”, Via Salaria 113, Roma, Italy

Keywords: Parallel, Lossless image compression, CUDA, GPU, Relative distance.

Abstract: Computer graphics and digital imaging have finally reached the goal of photorealism. This comes however

with a huge cost in terms of memory and CPU needs. In this paper we present a lossless method for image

compression using relative distances between pixel values belonging to separate and independent blocks. In

our approach we try to reach a good balance between execution time and image compression rate. In a

second step, by considering the parallel characteristics of this algorithm (and nonetheless the trend of multi-

core processor), a parallel version of this algorithm was implemented using Nvidia CUDA architecture.

1 INTRODUCTION

Computer graphics and digital imaging have finally

reached the goal of photorealism. However such

result has been paid with huge costs in terms of

memory requisites and CPU time, especially for

large size images. By the way, there are always a lot

of redundancies in a sequence of bits representing a

non-compressed image. Finding them and

converting sequences of bits into a shorter form is

the type of approach of data compression algorithm

like LZ (Ziv, 1977). The Relative Distance

Algorithm (RDA) presented in this paper, uses a

similar approach by removing redundancy of data

and translating the sequence of image’s bits in a

shorter form. The compression provided by RDA is

lossless.

RDA first divides the image into separate blocks

and then elaborates them independently, both in the

compression and decompression phase (in this paper

it is proposed the use of an 8x8 pixel window).

Thanks to this characteristic it is quite easy porting it

to a multi-processor architecture just by making

every single processor working on a different block

in parallel.

Multi-core architectures are becoming more and

more common even on consumer markets. Every

new processor is equipped with at least two cores (Q

series of Intel and AMD Phenom has up to 4 cores;

IBM Cell processor has 9 cores). GPUs evolution

has been even faster: for example a recent Nvidia

G80 chipset can be considered up to a 16 processor

device (each one with SIMD capabilities). Classic

algorithms that used to work on a single processor

machine need therefore to be arranged to take

advantage of all this new computational capabilities.

Many efforts have been done so far to optimize the

execution of lossless compression algorithms on

different kinds of parallel architectures: LOCO-I

Jpeg-LS (Ferretti, 2004), EREW-PRAM block

matching (Cinque, 2007), with Huffman and

Arithmetic Coding on PRAM model (Howard, 1996)

and with Burrows-Wheeler Transform on NUMA

system (Gilchrist, 2007).

As already noticed RDA is born with parallel

concepts clear in mind. To show the real advantages

of a parallel implementation we compared the

execution time between a single-core and a multi-

core architecture. We have chosen a G80 graphic

card by Nvidia supporting CUDA for drawing a

comparison.

Bianchi L., Gatti R., Lombardi L. and Cinque L. (2009).

RELATIVE DISTANCE METHOD FOR LOSSLESS IMAGE COMPRESSION ON PARALLEL ARCHITECTURES - A New Approach for Lossless Image

Compression on GPU.

In Proceedings of the Fourth International Conference on Computer Vision Theory and Applications, pages 20-25

DOI: 10.5220/0001767800200025

 SciTePress

2 RELATIVE DISTANCE

ALGORITHM (RDA)

The Relative Distance algorithm is a lossless method

for compression that uses local operators to find a

way to rearrange data in a different mode. The main

idea is to analyze the local chromatic characteristics

of an image and compress them according to their

peculiarities. This is made in O(N) time in the

sequential form of the algorithm. The algorithm

operates separately on every single channel (RGB)

of the image. Of course it can be applied to single-

channel images too.

Let’s consider for example a non-compressed 24

bit bitmap image. In a lot of images it can be

observed that the representation of the colour (RGB)

follows local features. For example in a picture of a

landscape we can identify some areas with minimal

colour change (e.g the sky) and areas with large

colour difference in particular near the edge of

objects. In general it can be assumed that the

difference between all pixel values in a small area is

usually small (Storer, 1997).

The first step is to divide every single channel of

the image in blocks of dimensions n x n (with n = 8

every block is made of 64 values in the range [0,

255]). For each block is then applied RDA and

estimated the compression rate (see details in next

section). Then the block is split in 4 blocks of 4x4

pixels and again the RDA is applied for the new

ones to check if this operation is able to produce a

better compression. The data produced by the

algorithm are saved in a single stream that contains

all results of every single block in sequence. Two

different types of header (formally called DR64 and

DR16) are used to identify 8x8 blocks from 4x4

blocks sequences. It’s important to note that the

header of each compressed block contains enough

information to evaluate the block size. This is very

helpful during read operations. Some compression

rates showing the capabilities of Relative Distance

approach are reported in section 4.

2.1 Compression of a Single Block

Let’s consider a single 8x8 block of the image. A

pixel matrix P is defined by this block as follows:

)min('

88 px

M ⋅−= PP

(1)

iip

63..0

minmin

(2)

pii

pp min' −=

(3)

In equation (1) every element of M is 1. Every p’

represents the distance between the element i from

min

. The last step consists in finding the necessary

bits to represent each p’

[]

)'(logmaxmax

263..02log ii

(4)

The block is then reconstructed with the values

of p’

coded with max

log2

bits. This value is formally

known as “block distance”.

If 0 ≤ max

log2

≤ 2 (the maximum distance is in [0,

4]) the algorithm proceed with DR64 header

recording. Otherwise the block is divided into 4 sub

blocks of 4x4 pixels and the algorithm loops back

for each new subset. In this way the algorithm

checks if a smaller relative distance (and therefore a

better compression) can be obtained through a

smaller subdivision. Then the results are compared

and the best type of coding (DR64 for one 8x8 block

or DR16 for four 4x4 blocks) is chosen. If both types

of coding do not provide advantages, the block is

leaved as it is and a special header (NC64) is used to

identify it among the non-compressed block.

All the information gathered for each block 8x8

of the starting image is then recorded in a binary file.

In this file the ordered sequence of all blocks can be

found starting from the upper left corner to the lower

right corner of the image.

2.2 Header DR64

DR64 header contains the specifics of compression

of all the 64 values of an 8x8 block. The header

looks like this:

XXX

(3 bit)

Min

p (8bit)

where the three x values contain the result of

equation (4) and Min

contains the minimum value

of the block. The first bit is set to “1” to recognize

the start of the header. Therefore DR64 length is 12

bits. After that there are the distances of all 64 pixel

belonging to the block expressed with max

log2

bit.

Table 1 resumes the necessary bits for recording

a block depending on the minimum value found. The

necessary bits for a block are calculated with (5) and

compression ratio with (6) where uncompressed

block size is 512 bits (64x8).

necessary bits = (DR64 bits) + distance * 64

(5)

c.ratio = uncompressed block size / nec. bits

(6)

2.3 Header DR16

In DR16 header, as already mentioned, there is the

need to record the information of four different

blocks, each one with its own minimum value and

relative distances. DR16 header is used only if it

provides a better compression (requires less bits)

RELATIVE DISTANCE METHOD FOR LOSSLESS IMAGE COMPRESSION ON PARALLEL ARCHITECTURES - A

New Approach for Lossless Image Compression on GPU

Table 1: Dr64 distances coding and compression rates.

Distance

Coded

Distance

Necessary

Bits

Compression

Ratio

0 000 12 42.73

1 001 76 6.73

2 010 140 3.65

3 011 204 2.51

4 100 268 1.91

5 101 332 1.54

than DR64. Table 2 resumes all the possible

combination of DR16 header signatures. The correct

coding of DR16 is guaranteed by the uniqueness of

the code created. DR16 header looks like this:

0 d

Min

(8 bit)

Min

(8 bit)

Min

(8 bit)

Min

(8 bit)

where d

fields (the distance of each sub-block)

have different type of values according to Table 2.

The first bit is set to “0” for recognize DR16 from

DR64. Min

contains the minimum value for each

4x4 block. The total size of the 8x8 block is the sum

of the size of the four 4x4 block each one

compressed with different compression ratio.

Table 2: d

fields in DR16 header.

2.4 Header NC64 (No compression)

If compression with DR64 or DR16 does not

provide any benefit, the best thing to do is to leave

the block 8x8 as it is. It must be preceded anyway

with a special header. The format is the following:

1111 Value1 Value2 Value3 … Value64

2.5 Pseudo Code

This section contains a pseudo code example for

RDA implementation. Remember that this procedure

is the same for all blocks and must be done for all

the channel (RGB) of the image separately.

For(channel = 1 to N) {

for(block[8x8] = 1 to N){

maxDist8x8=findMaxDist(block[8x8]);

If (maxDist8x8 < 4) {

recordDR64();

}

else {

numBitDR64 =

(DR64headerBit)+64*maxDist8x8;

numBitDR16 = 0;

for(block[4x4] = 1 to 4) {

maxDist4x4=findMaxDist(block[4x4]);

numBitDR16 +=

(DR16HeaderBit)+16*maxDist4x4;

}

if(numBitDR16 > numBitDR64)

recordDR64();

else

if(numBitDR16 < sizeNotCompressed)

recordDR16();

else

recordNC64();

}

In this example code findMaxDist(block[]) function

returns the results of equation (4). “DR64headerBit”

is always 12 (according to Table 1),

“DR16headerBit” depends on the distance

(according to Table 2) and “sizeNotCompressed” is

the size of the block without compression (8 bit * 64

pixel).

3 RDA ON CUDA

The characteristics of Relative Distance algorithm

makes it very suitable for an implementation on a

multi-processor machine. Its main quality is the fact

that every block is totally independent from the

others. Therefore we can work, both in compression

and in decompression stage, on more than one block

in parallel. In theory, the more processors we have

the fast will be the algorithm steps. For providing

Distance Coded Distance d

0 000

1 001

2 010

3 011

4 100

5 101

6 110

7 111100

8 111101

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

some benchmark of the algorithm in a multi-

processor situation, a porting for G80 Nvidia graphic

cards featuring CUDA (Computer Unified Device

Architecture) was realized.

3.1 CUDA Specifications

Today’s GPUs offer incredible resources for both

graphics and non-graphics processing. The GPUs in

particular are well-suited for problems that can be

expressed in a data-parallel form. CUDA

architecture was introduced by Nvidia on G80

graphic card series as a data-parallel computing

device for managing computations on GPU (Nvidia

2008). The GPU is considered as a device capable of

executing a very high number of threads in parallel.

It operates as a coprocessor to the main CPU (or

host) but it has its own DRAM (referred as device

memory) separated from the CPU RAM (referred as

host memory). Transfer of data between them is

made by high-performance DMA access.

The device is implemented as a set of SIMD

(Single Instruction Multiple Data) multiprocessors.

Each multiprocessor supplies a set of local 32-bit

registers and a parallel data cache (or shared

memory), a read only constant cache and a texture

cache that are shared between all the processors.

A function that is executed on the device as many

different threads is called “kernel”. In the parallel

version of RDA every kernel will contain all the

steps required for compressing or decompressing a

single block of pixels.

3.2 Optimize RDA for CUDA

For using CUDA full computing capabilities, there

is the need to write a general “kernel” that operates

on different sets of input data. Every kernel is loaded

in a thread and a grid of threads is then sent to the

GPU multiprocessors for execution. Reference to

input data could be made by using thread IDs. In this

way a multiprocessor that is running a thread with

(Thread

IDx

, Thread

IDy

) is working to the block

having coordinates (X,Y). Since CUDA usually

works in an almost random order, there is not the

certainty that the blocks will be executed in a pre-

established way. As a consequence the file

containing the compressed data must be organized in

an appropriate way.

In a standard sequential form of the algorithm

(working on a single processor) the file is organized

as a list of blocks (each one with its correct header)

and the program reads, executes and writes every

single block starting from the first to the last one.

In random parallel execution condition we need

to read from memory the correct set of input data

related to each block of coordinates (X,Y). Since all

blocks have different size in bits due to different

compression rate and header length, there is the need

to arrange the order of the file both in compression

and decompression phase. Let’s consider

compression stage first. The steps of the algorithm

are:

1. Load uncompressed data to device memory.

2. Run RD kernel on each block.

3. Transfer results file to host memory.

During step 2 each processor has to share both

input and output data. While reading input data do

not create problems cause it is performed in different

and independent parts of the original image, the

output data have a big problem: it is impossible to

know the final data size of compressed block and

therefore each thread does not know where to write

down results (because we are in a random parallel

thread execution). A way to solve this problem is to

separate each block information in different but

consecutive memory location:

Header type bit list (0 = DR64, 1 = DR16).

Blocks minimum values.

Blocks d

Pixel in every blocks expressed with d

bits

In this way each processor knows exactly where

its results have to be written, because the length of

each one of this vector can be known a priori. All

these vectors are created as unsigned char vectors

and then cleaned out of useless data before starting

memory transfer from device to host. Vectors #2 and

#3 will be created with a size of 4 * (number of

image’s block). In this way it is possible to write

down 4 different data if a DR16 header occurs.

As benchmarks highlight (section 4) memory

transfer is a big problem in CUDA approach and

takes more than 90% of total execution time in

compression phase. Since it is better making a

unique large transfer instead of a set of many small

transfers, image data has to be moved from and to

the device memory all at once. That’s the reason

because memory clean out of unnecessary data is

very important before starting the transfer between

devices. When compressed data is available to host

memory a file is written maintaining the block

information division. This helps in decompression

phase where the first step is to reconstruct the four

vectors. In fact decompression stage operates in a

very similar way:

1. Load compressed data to device memory.

2. Division of the data in 4 vectors.

3. Run RD kernel on each block.

RELATIVE DISTANCE METHOD FOR LOSSLESS IMAGE COMPRESSION ON PARALLEL ARCHITECTURES - A

New Approach for Lossless Image Compression on GPU

Again, by maintaining the division between

block’s information every thread reads different and

precise memory locations without overlap memory

access.

4 RESULTS

RDA has very few and simple execution steps that

can provide very fast performance even on low-end

computers. For benchmarking we used a standard set

of images supplied by Kodak that range between

every color sample and chromatic characteristic.

These images reproduce different subjects and

situations and can provide a good model of a generic

collection of pictures. The file size of every original

picture is 1.179.702 byte. As compression ratio (c.

ratio) we define the amount given by the ratio

between the original size and the compressed file

size. On Table 3 compression ratio of RDA is

compared with compression ratio of the well-known

JPEG2000-LS (Christopoulos 2000).

Table 3: Compression ratio of RDA vs JPEG2000-LS.

Image c. ratio RDA

c.ratio JPEG2000-LS

Kodim01 1.22

2.27

Kodim02 1.55

2.54

Kodim03 1.75

3.05

Kodim04 1.52

2.51

Kodim05 1.23

2.13

Kodim06 1.40

2.45

Kodim07 1.58

2.85

Kodim08 1.19

2.10

Kodim09 1.60

2.67

Kodim10 1.57

2.65

Kodim11 1.44

2.56

Kodim12 1.63

2.83

Kodim13 1.16

1.93

Kodim14 1.31

2.28

Kodim15 1.67

2.61

Kodim16 1.53

2.77

Kodim17 1.52

2.65

Kodim18 1.32

2.08

Kodim19 1.43

2.42

Kodim20 2.10

2.95

Kodim21 1.45

2.40

Kodim22 1.43

2.23

Kodim23 1.74

2.75

Kodim24 1.40

2.35

On average RDA gives a compression ratio of 1.49

while JPEG-LS gives a compression ratio of 2.41.

The main reason of this result is that RDA is not

adaptive to account for high detailed areas.

4.1 Execution Time

In table 2 are reported the total execution time for an

operation of compression and for an operation of

decompression of images with increasing resolution

size. We considered for testing an Intel Q6600 CPU

and an Nvidia 8800GTX with 768M on board ram.

Table 4: Execution time x86 vs GPU.

Table 5: Nvidia 8800 detailed compression benchmark.

As benchmarks highlight there is a great

improvement in speed between sequential and

parallel execution of the algorithm. However even in

the sequential form, a compression of a 1920x1440

image takes only 770 ms and its decompression

takes only 680 ms. This shows clearly how this

algorithm is performing well on all architectures.

On Nvidia G8800 GTX a compression needs on

average 50% time less. But as table 5 point out, the

total time needed for computation is only a very

small part if compared to the total execution time.

Regardless, on CUDA architectures memory

transfers from device to host are usually slower than

memory transfers from host to device and this helps

out to achieve an awesome total execution time of

101 ms for a decompression of a 1920x1440 image.

The reason is that there is not need to send back the

decompressed image to the main system memory

since it’s already in the framebuffer ready for

visualization on screen. On Table 6 are reported the

comparisons between RDA and JPEG2000-LS

parallel GPU implementation (Wong, 2007). RDA

clearly gives better performances than JPEG2000-

Image Size

Intel q6600 Nvidia 8800

Compr. Decompr. Compr. Decompr.

640x480 100 ms 100 ms 38 ms 18 ms

800x600 170 ms 160 ms 58 ms 29 ms

1024x768 250 ms 220 ms 98 ms 37 ms

1280x960 380 ms 320 ms 147 ms 55 ms

1600x1200 560 ms 480 ms 226 ms 74 ms

1920x1440 770 ms 680 ms 326 ms 101 ms

Image Size

Nvidia 8800 – Compression

Memory Transfer

Time

Computation Time

640x480 36.63 ms 1.36 ms

800x600 56.90 ms 1.68 ms

1024x768 96.64 ms 2.21 ms

1280x960 143.50 ms 2.99 ms

1600x1200 221.92 ms 4.34 ms

1920x1440 320.91 ms 5.93 ms

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

LS especially with low resolution images. RDA can

perform the compression of around 20 image/second

and the decompression of around 40 image/second if

the resolution is 800x600.

Table 6: Benchmark on Nvidia G80: RDA vs JPEG-LS.

This results shows that RDA approach is a good

candidate for real-time compression and

decompression problem.

5 CONCLUSIONS

Relative distance algorithm for image compression

proved to be a good compromise between sufficient

compression ratio and very fast performance thanks

to its algorithm structure that suits very well to

multi-core parallel architectures. Future works will

address the problem of reaching a better

compression ratio by making better compression

rates even when the image has lots of non

homogeneous areas. This can be done with the use

of a dynamic block size.

Moreover RDA approach will be considered for

inter-frame compression of movie files. It’s not

difficult to find sequences where the actors are

speaking in front of the camera or the scene is quite

stand-still. When this happen some areas are not

changing too much their colours between frames. If

we define blocks not on a single image but between

frames of a video sequence, RDA can be applied on

them quite easily. This application will be discussed

in future works.

ACKNOWLEDGEMENTS

This work has been partially supported by FIRB

Project RBIN043TKY.

REFERENCES

Christopoulos C., Ebrahimi T., Skodras A., 2000. The

JPEG 2000 Still Image Coding System: an Overview.

In IEEE Transactions on Consumer Electronics. Vol.

16, num. 4, p. 1103-1127.

Cinque L., De Agostino S., 2007. A parallel decoder for

Lossless Image Compression by Block Matching. In

Proceedings of the 2007 Data Compression

Conference. DCC. IEEE Computer Society, p 183-

192.

Ferretti M., Boffadossi M., 2004. A parallel Pipelined

Implementation of LOCO-I for JPEG-LS. In

Proceedings of the Pattern Recognition, 17

international Conference on (Icpr’04). Vol. 1, p. 769-

772.

Gilchrist J., Cuhadar A., 2007. Parallel Lossless Data

Compression Based on the Burrows-Wheeler

Transform. In Proceedings of 21

international

Conference on Advanced Networking and

Applications. AINA. IEEE Computer Society, p. 877-

884.

Howard P.G., Vitter J.S., 1996. Parallel Lossless Image

Compression Using Huffman and Arithmetic Coding.

In Inf. Process. Lett., p. 65-73.

Kodak test images: http://r0k.us/graphics/kodak

Nvidia Corporation, 2008. Cuda Programming Guide,

Version 2.0.

Storer J.A., 1996. Lossless Image Compression Using

Generalized LZ1-Type Methods. In Proceedings of the

Conference on Data Compression. DCC. IEEE

Computer Society, p. 290-299.

Wong T.T., Leung C.S., Heng P.A., Wang J., 2007.

Discrete Wavelet Transform on Consumer-Level

Graphics Hardware. In IEEE Transaction on

Multimedia. Vol. 9, No. 3, p. 668-673.

Ziv J., Lempel A. 1977. A universal algorithm for

sequential data compression. In IEEE Trans. on

Inform. Theory. Vol. IT-23, no. 3, p. 337-343.

Image Size

Nvidia 8800GTX – Compression

RDA JPEG2000-LS

640x480 38 ms 516 ms

800x600 58 ms 560 ms

1024x768 98 ms 600 ms

1280x960 147 ms 721 ms

1600x1200 226 ms 828 ms

1920x1440 326 ms 969 ms

RELATIVE DISTANCE METHOD FOR LOSSLESS IMAGE COMPRESSION ON PARALLEL ARCHITECTURES - A

New Approach for Lossless Image Compression on GPU
