XML PROCESSING. NO PARSING

Yevgeniy Guseynov

Optimal Solutions & Technologies, 2001 M Street, NW, Suite 3000, Washington, DC 20036, U.S.A.

Keywords: XML, Data Exchange, XML Parser, XML Processing Efficiency, DOM, SAX.

Abstract: The main properties considered lacking from XML for a potentially efficient interchange format are

Compactness and Processing Efficiency, and Parsing being the main deterrent to Processing Efficiency. The

proposed Contiguous Memory Tree (CMT) and its XML API completely resolve Parsing and Processing

Efficiency permitting an efficient interchange format for XML. CMT is based on the presentation of XML

documents as a tree that contiguously resides in memory and is simultaneously a stream that can be directly

copied as a message and an application object that can be directly accessed through the CMT XML API.

CMT XML API does not need to read and evaluate markup or decode information items that takes much

CPU time when processing, thus is significantly more efficient than any existing formatting schemes, SAX

and DOM parsers.

1 INTRODUCTION

Many modern technologies in distributed computing

and Web Services are powered by XML

(Cauddwell, et al., 2001). Extensible Markup

Language, abbreviated XML, was defined in the

XML 1.0 Specification (Bray, et al., 2006) published

by the Worldwide Web Consortium (W3C). XML

documents are made up of a sequence of characters

with the textual encoding UTF-8, UTF-16 or others

for storage and interchange data. Thus in memory an

XML document is usually formatted as a stream of

characters (bytes), some of which form character

data, and some of which form the markup. The

computer must interpret this stream as application

objects in order to access the content of the

document. In some applications like insurance,

banking, and financial businesses, the advantages of

XML usage are tempered by inefficiencies that stem

from the textual encoding (White, et al., 2007,

Matthiaas and Jasmi, 2003). The main properties

that are considered lacking in XML for a potential

efficient interchange format are Compactness and

Processing Efficiency (Schneider, et al., 2007).

These shortcomings have led to the development of

alternative encoding formats for example

(Schneider, et al., 2007, Conner, 2003, Sandoz, et

al., 2004). This paper concentrates on developing the

format for resolving the Processing Efficiency of

XML.

While the main rules for constructing XML

documents are relatively simple a document itself

may have a very complex hierarchical (tree)

structure. In order to read XML documents as a

stream of characters, almost all applications rely on

an XML parser that also provides an API to receive

or request information from the documents. There

are two major models for processing XML

documents: the Simple API for XML (SAX) parser

(Megginson, 2004) and the Document Object Model

(DOM) parser (Le Hégaret, et al., 2005). Parsing -

the step where components of an XML document

are transformed (read) from a stream of text data

into application objects - is the main part of the

Processing Efficiency property. For a SAX parser it

is the creation of events for callbacks; for DOM it is

the creation of a tree in memory that is compatible

with the XML document at the XML Information

Set level (Cowan, et al., 2004). Regardless of the

parser type, SAX or DOM, if an application needs to

maintain an XML document or its part in memory

for extended processing it uses a DOM tree structure

that is based on Composite Pattern (Gamma, et al.,

1994) where each component of an XML document

or node is created as a separate application object

and linked to its parent and sibling nodes. By design

the DOM tree structure is spread in memory so, in

order to store, the application must rewrite it back to

a stream of text data. Inevitability having these two

substantially different instances of an XML

document, a stream of text data for storage and

Guseynov Y.

XML PROCESSING. NO PARSING.

DOI: 10.5220/0001819500810084

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

exchange, and application objects in memory in

order to access information, a situation that occurs in

all existing applications, causes inefficiency in

processing XML documents.

The proposed Contiguous Memory Tree (CMT)

and its XML API (Guseynov, 2006) completely

resolve Parsing and Processing Efficiency by

creating an efficient interchange format for XML. It

is based on the presentation of XML documents as a

tree structure that contiguously resides in memory

and is simultaneously a stream that can be directly

copied as a message and an application object that

can be directly accessed through the CMT XML

API. CMT is the universal way to exchange XML

documents and any hierarchical information

regardless of operating systems and languages like

C++ with direct access to memory or Java, Visual

Basic, Perl, others with the ability to contiguously

allocate arrays in memory. CMT and its XML API

has all features of existing formats: the compatibility

with the XML document at the XML Information

Set level, serialization, parsing as DOM and SAX,

XML schema independence and self-description,

support a sequential or fragments processing

(Streamability), indexing of repeated strings,

preservation of the state for documents with the

same schema and vocabulary, platform and language

neutrality, reduced document size, and fast

processing speed. In addition, CMT and its XML

API have significant advantage. CMT XML API

does not need to read and evaluate markup or decode

information items that takes much CPU time when

processing, thus is significantly more efficient than

any known parser by the elapsed time that a parser

needs to parse an input stream before actual

processing.

2 CONTIGUOUS MEMORY TREE

We may define CMT based on pointers for

languages like C++ with direct access and explicit

allocation of memory and like Java based on the

ability to contiguously allocate arrays in memory.

The approach based on arrays is universal because

almost all programming languages have the ability

to contiguously allocate memory arrays of the basic

types, integer and character.

To build CMT for an XML document or any

hierarchical information we need three arrays: the

array of integers, Hierarchy[], to hold the

hierarchical (tree) structure of the document; the

array of characters, SchemaComponents[], to hold

tag names, attribute names, and other components

for all documents with the same XML schema; the

array of characters, DocumentValues[], for each

document to hold elements and attributes values for

the whole document.

The Hierarchy[] array is built with blocks of six

integers:

SchemaNode

{ int parent;

int firstChild;

int nextSibling;

int tagName;

int offset;

int numOfAttributes;

}

The first four integers allow CMT to be built

from any hierarchical information. For each element

E1 from the hierarchy of an XML document, the

parent, firstChild, and nextSibling members of

SchemaNode are positions in the Hierarchy[] array

that are start positions, respectively for parent, first

child, and next sibling elements for E1. The member

tagName is the start position in the

SchemaComponents[] array for the element name.

The last two integers in the struct SchemaNode

pertains to XML documents. The member offset is

the start position in DocumentValues[] for the

content or value that is the text between two tags in

an XML element. numOfAttributes represents the

number of attributes in an XML element.

Each CMT element in memory consists of a

SchemaNode followed by numOfAttributes pair of

integers: the first element of a pair is the start

position of the attribute name in the

SchemaComponents[] array and the second is the

start position of the attribute value in the

DocumentValues[] array. Next three tables present

an example of CMT for an XML document

<ItemName>Chartreuse verte</ItemName>

</ Product >

To define CMT we need to build each element in the

XML document one by one into Hierarchy[],

SchemaComponents[], and DocumentValues[]

arrays. They will remain unchanged if we copy them

to any location and we may also directly store these

arrays contiguously on the disk or any other medium

as a stream of bytes to exchange the XML document

with other applications. After copying these three

arrays back into memory an application can access

without parsing all the information that the XML

document has, starting from any position in the

Hierarchy[] array.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

Table 1: Memory layout for CMT array Hierarchy[23].

0 NULL 1 Parent 2 firstChild 3 NextSibling 4 tagName 5 offset 6 numOfAttrib

utes

0 0 11 0 1 0 2

7 Attribute

Name

8 Attribute

Value

9 Attribute

Name

10 Attribute

Value

11 Parent 12 firstChild 13 nextSib

ling

9 1 17 4 1 0 17

14 tagNa

15 Offset 16 numOfAttributes 17 Parent 18 firstChild 19 nextSibling

22 8 0 1 0 0

20 TagName 21 offset 22 numOfAttributes

31 25 0

Table 2: Memory layout for CMT array SchemaComponents[41].

1 9 17

\0 P r o d u c t \0 b o t T l e s \0 s i z e

22 31

\0 I t e m N a m e \0 I t e m P r i c e \0

Table 3: Memory layout for CMT array DocumentValues[32]].

1 4 8

\0 1 2 \0 9 o z \0 C h a r T r e u s e V

e \0 $ 1 8 . 0 0 \0

There are two more important features of CMT:

direct access to the XML schema hierarchical

information without navigating the tree and the

ability to search for an item in CMT based on its

starting position (integer) in the array. After CMT or

Hierarchy[], SchemaComponents[], and

DocumentValues[] arrays are built they remain

unchanged and we may write out starting positions

for their elements as constants and make them

available for applications for direct access or fast

search. Applications may use these constants even

when CMT is stored or exchanged for direct access

to all information in an XML document without

navigating its CMT structure.

Defined by three arrays, CMT is compatible with

XML at the XML Information Set level (Cowan, et

al., 2004) but not as readable for human eyes, as the

original XML format is, to satisfy the XML design

goal: “XML documents should be human-legible

and reasonably clear” (Bray, et al., 2006).

Meanwhile, the integer and character arrays that

define the CMT are human readable and self

descriptive. In addition, when reading a CMT,

humans do not need to read and evaluate markup or

decode information items that all known formatting

schemes have.

3 PERFORMANCE

CMT eliminates the parsing step in XML processing

and it is evident that the usage of the CMT XML

API is more efficient than any existing XML parser:

both of them need to read documents from the file

(stream); after reading, the CMT object is ready for

use but the XML document in the textual encoding

still needs to be parsed before it will be available for

access by an application. The bigger the XML

documents are the more efficient the CMT XML

API is against any Parser. Direct access to all

information in CMT also greatly increases

Processing Efficiency.

To evaluate CMT performance we use a simple

XML Document Customer-Sales.xml similar to

(Conner, 2003) to build different XML documents

XML PROCESSING. NO PARSING

with sizes between 1 kilobyte and 1 megabyte.

Xerces C++ SAX and DOM Parsers version 2.8.0

(Xerces, 2007) were chosen for the base

measurement. For comparison the CMT Document

Customer-Sales.cmt was built from Customer-

Sales.xml and processed by the CMT Parser. All

timing runs are for 300, 600, 1200 iterations after a

warm up of 500 iterations on a Pentium(R) 4 CPU

2.66GHz, 512 MB of RAM.

The SAX Parser test is based on the MemParse

project from the Xerces-C++ package. It reports all

SAX events and outputs the number of elements and

attributes from Customer-Sales.xml. The same

functionality SAX CMT Parser processes the

Customer-Sales.cmt document that is compatible

with the initial XML document at the XML

Information Set level. The DOM Parser test is based

on the DOMCount project from the Xerces-C++

package that builds DOM for Customer-Sales.xml.

The DOM CMT Parser processes the Customer-

Sales.cmt document. The table below presents the

results for 3 kilobytes XML documents. For other

sizes the comparison is similar.

Table 4: Simple Performance Test.

Iterations

SAX

CMT

(

SAX

Xerces

(

DOM

CMT

(

DOM

Xerces

(

1200 40 2070 40 5340

600 20 1030 20 2740

300 10 510 10 1400

These results show a significant advantage when

using the CMT XML API against the Xerces SAX

and DOM Parsers. They also demonstrate that CMT

SAX and CMT DOM parsers are equivalently fast

which is expectable based on the definition of CMT.

Similar comparison in Efficient XML (Schneider, et

al., 2007, White, et al., 2007), Fast Infoset (Sandoz,

et al., 2004), and CBXML (Conner, 2003) against

Xerces parser show 2 to 3 times improvement.

The Demo and Sample Project CMT XML API

are available from the author upon request via email.

The Sample Project shows how to use the CMT

XML API to manipulate XML documents: build

CMT objects, store and retrieve CMT from a file,

navigate CMT as a tree, update CMT - set values for

attributes and elements, and delete and add nodes.

You may try it on your own XML data and a

favoured parser to compare with the provided

experiments.

REFERENCES

Bray, T. et al. Extensible Markup Language (XML) 1.0

(Fourth Edition). http://www.w3.org/TR/xml/,

September 2006.

Cauddwell, P. et al. Professional XML Web Services.

Wrox Press Ltd., 2001.

Conner, M. CBXML: Experience with Binary XML, IBM

Corporation, http://www.w3.org/2003/08/binary-

interchange-workshop/19-IBM-CBXML-W3C-

Submission-updated.zip, 2003

Cowan, J. et al. XML Information Set (Second Edition),

W3C Recommendation, http://www.w3.org/TR/xml-

infoset/, February 2004.

Gamma, E. et al. Design Patterns: Elements of Reusable

Object-Oriented Software. Addison-Wesley

Professional, 1994

Guseynov, Y. U.S. Patent Application (pending) No.

11/603,299 for Contiguous Memory Tree, Filing Date:

November 21, 2006.

Le Hégaret, P. et al. Document Object Model (DOM),

http://www.w3.org/DOM/, January 2005.

Matthiaas, N., Jasmi, J. XML Parsing: A Threat to

Database Performance. CIKM’03 November 3 – 8,

2003, New Orleans, Louisiana, USA. http://

lists.w3.org/Archives/Public/www-ws/2004Oct/att-

0032/MNicola_CIKM_2003_1_.pdf.

Megginson, D. Simple API for XML (SAX),

http://www.saxproject.org/, April 2004.

Sandoz, P. et al. Fast Infoset,

http://java.sun.com/developer/technicalArticles/xml/fa

stinfoset/, 2004.

Schneider, J. et al. Efficient XML Interchange (EXI)

Format 1.0, W3C Working Draft, http://www.w3.org/

TR/exi/, July 2007.

White, G. et al. Efficient XML Interchange Measurements

Note, W3C Working Draft, http://www.w3.org/

TR/exi-measurements, July 2007.

Xerces-C++ Parser. http://xerces.apache.org/xerces-c/,

2007.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies
