A STUDY OF NATIVE XML DATABASES

Document Update, Querying, Access Control and Application

Programming Interfaces in Native XML Databases

M. Mercedes Mart´ınez-Gonz´alez, Miguel A. Mart´ınez-Prieto and Mar´ıa Mu˜noz-Nieto

Department of Computer Science, University of Valladolid, Campus ’Miguel Delibes’ s/n, Valladolid, Spain

Keywords:

Native XML databases, NXD, Standard APIs, Access control, Document update, Query language.

Abstract:

Native XML databases (NXD) are called to play a crucial role in the near future. The experience with rela-

tional databases shows that standard methods for accessing and manipulating databases are necessary if wide

acceptance of these database systems is to be expected in information systems whose applications should ac-

cess databases preferably through standard APIs. In this paper, the current state of APIs that provide standard

access to NXD, standard query languages and standard methods for document update and access control are

analyzed from the perspective acquired with our experience using NXD in information systems. Our conclu-

sions show the weak points which still need to be improved as compared with relational databases.

1 INTRODUCTION

Native XML databases (NXD) promise to play a key

role in the near future as management systems for

XML data (Garofalakis et al., 2004). There are sev-

eral facts that favour these good expectations. XML is

the preferred ’format’ for storing non-structured data

(Bourret, 2007; Bonifati and Cuzzocrea, 2007).

XML and its query language, XQuery (Boag et al.,

2007), is a more ﬂexible and less structured way of

representing and querying a collection of data than

relational databases are. XQuery is a World Wide

Web Consortium (W3C) Recommendation since Jan-

uary 2007, which makes it stable, and it is now imple-

mented (with different levels of conformance) in all

database management systems that handle XML. Be-

sides their inherent suitability for XML and XQuery

features, NXD have the important advantage, over

other database systems, that they free users from hav-

ing to know document schema in advance (prior to

designing the database).

However, these systems have still not won the

’XML market’ as was predicted, and they still com-

pete with XML-Enabled Databases for this market

(Pardede et al., 2008).

An analysis of some of the possible reasons for

this situation, resulting from our experience with

NXD, is offered in this paper. It does not intend to

be an exhautive analysis of NXD, for which a confer-

ence paper could not be enough, but to provide an up-

dated position of the considered issues. Some issues,

whose current situation is studied, are selected: docu-

ment update, querying, access control, and the avail-

ability of Application Programming Interfaces (APIs)

in NXD. Other important issues in databases, such

as security or concurrency, are beyond the scope of

this paper. Our reﬂection is guided by the compar-

ison with relational databases, as they are nowadays

the referent for database users.

The paper is structured as follows. Section 2

presents the problem we faced, the database issues

treated in this paper, and the databases used in the

experiments. Section 3 brieﬂy introduces NXD and

our ﬁndings. Finally, the conclusions are presented in

section 4.

2 MOTIVATION

We work with legislative information systems, in

which legal documents and additional metadata are

represented with XML documents. A large amount

of our data are normative texts and legal documents,

whose nature implies that the resulting XML repre-

sentations are document-centric XML documents

Following (Chaudhri et al., 2003) ’a document-centric XML

document is one that captures unstructured data as in articles,

MartÃ nez-GonzÃ ˛alez M., MartÃ nez-Prieto M. and MuÃ

soz-Nieto M.

A STUDY OF NATIVE XML DATABASES - Document Update, Querying, Access Control and Application Programming Interfaces in Native XML Databases.

DOI: 10.5220/0001822300890092

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

As NXD are well-suited for this type of XML doc-

ument, and they are considered the best option as op-

posed to (relational) XML-enabled databases (Bour-

ret, 2007; Bonifati and Cuzzocrea, 2007; Kolar and

Loupal, 2006; Jagadish et al., 2002), we used an NXD

to store our XML document collections. Several ap-

plications should work on it.

Some of our applications are learning tools, used

by Law teachers and students in practical works. As

in any other learning tool, a distinction of user roles

needs to be managed (at least the roles of ’teacher’,

’student’ and ’administrator’). Besides, our teachers

should be able to organize documents in repertoires

(collections) according to their own criteria. Finally,

the collections are queried and updated with the in-

troduction or deletion of documents, but also with the

modiﬁcation of some documents as ,for instance, the

comments that teachers provide to their students.

Moreover, we wanted the freedom to test differ-

ent NXD systems without being obliged to modify

our applications if the NXD system they accessed

changed, or if a different NXD system was used.

Thus we expected to be able to:

• Query the database using a standard query lan-

guage for XML. We searched a standard which

played a role similar to SQL, which is the stan-

dard query language for RDBMS.

• Gain standard access to NXD database systems.

We expected to be able to use an API which

played a role similar to the one ODBC or JDBC

play with relational databases.

• Create ’repertoires’ of documents, which we

would populate with XML documents. The reper-

toires are equivalent to the ’collection’ concept

used by NXD.

• Update the database, that is, to insert new XML

documents into the repertoires, to delete docu-

ments, or to modify them.

• Support multiple users and user roles. Some of

these users should be able to create their own

repertoires, and to select whether they want to

share their collections with other users or not.

These requirements are similar to the require-

ments we would have if working with relational

databases. In relational databases, the creation, pop-

ulation and updates of the database are supported

through standard query commands (create table, up-

date, insert, delete). Inserting documents in collec-

tions is equivalent to inserting tuples in relations. The

books, or e-mails. This is opposed to data-centric documents,

which capture structured data as that pertaining to a product cat-

alog, an order, or an invoice.’

problem of sharing documents and/or collections with

other users is equivalent to the problem of transfer-

ring permissions on data objects to other users in re-

lational databases (access control). In this last type of

database, permissions can be transferred and revoked

with SQL commands, grant and revoke.

We have used two NXD systems, eXist (Meier,

2002; Meier, 2003) and Sedna (Fomichev et al., 2006)

databases. Other possibilities among the most popu-

lar systems at the moment were Timber and XIndice

(Apache XIndice). We chose eXists as it is a very

popular system, is freeware, and it has better support

for XPath 1.0 than XIndice (Kolar and Loupal, 2006).

This last factor supposes a bigger variety of queries

supported, which is an issue on which we wanted to

have good support. On the other hand, Sedna released

a new version 3.0 very recently, in April 2008

, which

is supposed to provide better support of client authen-

tication and database users and privileges. Testing

this new version that enhanced access control seemed

to us an interesting possibility.

3 STANDARDS FOR NATIVE

XML DATABASES

Native XML Databases are systems developed purely

for storing XML documents. Their data models

are ﬂexible, so that documents do not need to be

transformed to equivalent tables and columns, which

means that they support the complexity of XQuery

more efﬁciently than relational databases can. For

document-centric XML documents, these systems

are preferable to XML-enabled relational databases

(Chaudhri et al., 2003; Bourret, 2007; Bonifati and

Cuzzocrea, 2007; Kolar and Loupal, 2006; Jagadish

et al., 2002).

Standard connectivity with NXD is achieved with

a standard API, XML:DB API, promoted by the XML

DB Initiative

. This API plays a role similar to JDBC

or ODBC in relational databases. It has methods for

connecting to the database, exploring metadata, exe-

cuting queries, and retrieving results (Chaudhri et al.,

2003). It uses XQuery as its query language and

has been implemented by a number of native XML

databases. This API is built around four core con-

cepts: drivers, collections, resources, and services.

Drivers encapsulate the database access logic. A re-

source can be either an XML resource or a binary

large object. Finally, services may be requested to

http://www.cs.wisc.edu/dbworld/messages/2008-

04/1207738519.html

http://xmldb-org.sourceforge.net/xapi/

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

perform tasks like querying a collection with XPath

or managing collections. The API considers that doc-

uments are stored in collections. This allows col-

lections to be managed (Get Collection), documents

to be inserted (methods setContentAsDOM for DOM

documents, and use of a document handler for SAX

documents), and a resource to be deleted (removeRe-

source method).

XQuery (Boag et al., 2007) is a standard query

language for XML documents, which has been a

stable W3C recommendation since January 2007.

XQuery plays an equivalent role to that played by

SQL in relational databases for querying, providing

the ﬂexibility and power that the XML data model re-

quires. It uses the structure of XML data in its queries.

XQuery embeds XPath (Clark and DeRose, 1999) and

includes ’SQL-like’ capabilities by means of FLOWR

expressions (FOR, LET, WHERE, ORDER BY, RE-

TURN clauses). However, it does not include pos-

sibilities to update the database or to manage access

control.

XML update is an interesting topic in the XML

community. The XML DB Initiative investigated

the XML update and released a proposal in 2000

(XUpdate Working Group, 2000). The W3C re-

leased the requirements and use cases for XML up-

date as Candidate Recommendations in March 2008

(Robie and Chamberlin, 2008; Robie and Manolescu,

2008). From these, it obtained the updates facilities

for XQuery, whose last version was released in Au-

gust 2008 (Chamberlin et al., 2008). Nevertheless,

updates are not yet treated in a standard way.

Following (Pardede et al., 2008), there are four

main strategies for updates in NXD. There are NXD

products that use their own proprietary language.

Other products use a special language called XUp-

date. A third strategy is to retrieve the XML docu-

ment, update it by using an XML API, and to return

the document to the database after updating. This

is the strategy followed by the XML:DB API, as it

follows from its ’Updating a Text XML Document’

use case

, shown in ﬁgure 1. The fourth option is to

embed the update processes into XML language, as

XQuery, within which would fall the XQuery Update

Facility (Chamberlin et al., 2008). In fact, the XQuery

Update Facility 1.0 is an extension to XQuery.

The XQuery Update Facility 1.0 is intended to be

used to make persistent changes to instances of the

XQuery 1.0 and XPath 2.0 Data Model. The opera-

tions it supports are: ’insertion of a node, deletion of

a node, modiﬁcation of a node by changing some of

its properties while preserving its node identity, cre-

http://xmldb-org.sourceforge.net/xapi/UseCases.html

#N64ab4d

ation of a modiﬁed copy of a node with a new node

identity’ (Chamberlin et al., 2008).

String id = "gladiator-2000";

XMLResource resource =

(XMLResource) collection.getResource(id);

String doc = (String) resource.getContent();

// Change document ...

resource.setContent(doc);

collection.storeResource(resource);

Figure 1: Updating an existing Text XML Document stored

in the database. Use case from XML:DB API.

Access control has also been the target of some

investigation. In (Gabillon, 2004) an authorization

model inspired in relational databases is proposed. It

supports read and write privileges and is intended to

be used with NXD that support the XML DB XUpdate

language. However, this model has not been adopted

by some popular NXD, such as eXist, which provide

access control through proprietary extensions to the

XML:DB API. In fact, the NXD used in our experi-

ments, eXists and Sedna, provided their own propri-

etary methods for access control. That is, a change of

the database system that stores the XML documents,

would suppose changing the programming code part

of any application that manages access control.

4 CONCLUSIONS

The current situation is that there is a standard query

language, XQuery, and a standard API, the XML:DB

API, but no standards for updates and access control.

This situation generates a dependence of software ap-

plications on the NXD used, which is clearly a serious

drawback. It seems quite reasonable that almost any

application needs to update the uderlying database,

and access control is a common need as well. For

example, if we had used some of the Sedna or eXist

database extensions, we would have been forced to

renounce to database system’s independence, one of

our requirements. Our solution was to build a middle-

ware, which copes with the update management inter-

operability and interacts with each database to offer a

uniﬁed set of methods for access control to our ap-

plications. Of course, this supposes a hard overload

on the middleware as compared with an equivalent

situation with relational databases. This is a draw-

back of NXD as compared with relational databases.

We expect that the stabilization of XUpdate as a W3C

Recommendation will suppose its spread and general

acceptance by NXD systems. This would eliminate

the dependence on proprietary solutions for updates.

Access control is an important issue in a database,

A STUDY OF NATIVE XML DATABASES - Document Update, Querying, Access Control and Application

Programming Interfaces in Native XML Databases

for which standard methods are necessary. At the mo-

ment of writing this paper, it seems that a standard so-

lution is farther away than it is for updates. However,

we are conﬁdent that current work on this issue will

produce the standard solution needed.

We also found some aspects which could be im-

proved in the future. As with relational databases,

users can create their own tables with the names they

prefer without risking confusion between tables from

two different users (table names avoid ambiguity with

a schema name of the form user.table), in native XML

databases, users should be able to create collections

whose names could coincide (which would become

something of the style user.collection). However, as

we worked with eXist, we discovered that such a thing

was not possible. The management of collections by

users still has to improve to acquire the ﬂexibility it

has in relational databases.

The ability of NXD to store schema-less XML

documents and their privileged position for imple-

menting complex XQuery queries efﬁciently (Boni-

fati and Cuzzocrea, 2007) are important advantages.

Standard APIs and query languages are already avail-

able. These are positive aspects of NXD, in contrast

of access control and document updates, which are

the weak aspects of NXD concerning standardization.

The situation with updates promises to be standard-

ized soon with the stabilization of the W3C XQuery

proposal as a Recommendation. Implementation will

probably appear soon after it. As for access control,

more work needs to be done. As access control is a

basic facility of databases, the effort is necessary if

NXD are to play the role they should.

ACKNOWLEDGEMENTS

This work was partially supported by the Consejera

de Educacin de la JCyL research projects VA010B06,

VA012B08, and the project TIN2006-15071-C03-02

from MCyT, Spain (second author). The work of the

second author is supported by a fellowship granted by

the JCyL and the ESF.

REFERENCES

Boag, S., Chamberlin, D., Fernndez, M. F., Flo-

rescu, D., Robie, J., and Simon, J. (2007).

XQuery 1.0: An XML Query Language. Techni-

cal report, http://www.w3.org/TR/2007/REC-xquery-

20070123/.

Bonifati, A. and Cuzzocrea, A. (2007). Synopsis data struc-

tures for xml databases: Models, issues, and research

perspectives. In DEXA Workshops, DEXA 2007, pages

20–24.

Bourret, R. (2007). XML Database Products.

http://www.rpbourret.com/xml/XMLAndDatabase-

Products.htm. Last upated March 2007. Visited the

2008/10/20.

Chamberlin, D., Florescu, D., Melton, J., Robie, J.,

and Simon, J. (2008). XQuery Update Fa-

cility 1.0. W3C Candidate Recommendation,

http://www.w3.org/TR/xquery-update-10-20080801/.

Chaudhri, A. B., Rashid, A., and Zicari, R., editors (2003).

XML Data Management: Native XML and XML-

Enabled Database Systems. Addison-Wesley.

Clark, J. and DeRose, S. (1999). XML Path Language

(XPath) version 1.0. W3C Recommendation 16

November 1999, http://www.w3.org/TR/1999/xpath.

Fomichev, A., Grinev, M., and Kuznetsov, S. D. (2006).

Sedna: A Native XML DBMS. In 32nd Conference

on Current Trends in Theory and Practice of Com-

puter Science, SOFSEM 2006, pages 272–281.

Gabillon, A. (2004). An authorization model for XML

databases. In 1st ACM Workshop On Secure Web Ser-

vices, SWS 2004, pages 16–28.

Garofalakis, M. N., Manolescu, I., Mesiti, M., Mihaila,

G. A., Schenkel, R., Thuraisingham, B. M., and Vas-

salos, V. (2004). What’s next in xml and databases? In

Current Trends in Database Technology - EDBT 2004

Workshops, pages 318–324.

Jagadish, H. V., Al-Khalifa, S., Chapman, A., Lakshmanan,

L. V. S., Nierman, A., Paparizos, S., Patel, J. M., Sri-

vastava, D., Wiwatwattana, N., Wu, Y., and Yu, C.

(2002). TIMBER: A native XML database. VLDB J.,

11(4):274–291.

Kolar, P. and Loupal, P. (2006). Comparison of Native XML

Databases and Experimenting with INEX. In Annual

International Workshop on DAtabases, TExts, Speciﬁ-

cations and Objects, DATESO6.

Meier, W. (2002). eXist: An Open Source Native XML

Database. In Web, Web-Services, and Database Sys-

tems, pages 169–183.

Meier, W. (2003). XML Data Management: Native XML

and XML-Enabled Database Systems, chapter eXist

native XML database, pages 43–68. Addison-Wesley.

Pardede, E., Rahayu, J. W., and Taniar, D. (2008). Xml

data update management in xml-enabled database. J.

Comput. Syst. Sci., 74(2):170–195.

Robie, J. and Chamberlin, D. (2008). XQuery Update

Facility 1.0 Requirements. W3C Candidate Recom-

mendation, http://www.w3.org/TR/xquery-update-

10-requirements-20080314/.

Robie, J. and Manolescu, I. (2008). XQuery Update Fa-

cility 1.0 Use Cases. W3C Candidate Recommen-

dation, http://www.w3.org/TR/xquery-update-10-use-

cases-20080314/.

XUpdate Working Group (2000). XUpdate - XML Update

Language. http://xmldb-org.sourceforge.net/xupdate/.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies
