A COLLABORATIVE FILTERING APPROACH COMBINING
CLUSTERING AND NAVIGATIONAL BASED CORRELATIONS
Ilham Esslimani, Armelle Brun and Anne Boyer
KIWI Team, Universit´e Nancy2, LORIA
615 rue du Jardin Botanique, 54600 Villers-L`es-Nancy, France
Keywords:
Recommender systems, Collaborative filtering, Clustering, Usage analysis, Navigational patterns.
Abstract:
Recommender systems are widely used for automatic personalization of information on web sites and informa-
tion retrieval systems. Collaborative Filtering (CF) is the most popular recommendation technique, but several
CF systems still suffer from problems like data rating availability and space dimensionality for neighborhood
selection. In this paper, we present a new CF approach (PSN-CF) that uses usage traces to model users. These
traces are used to estimate ratings that will be employed to generate clusters. Then, the PSN-CF evaluates
navigational correlations between users within these clusters. Predictions are performed in a following step.
The performance of PSN-CF is evaluated in terms of accuracy and time processing on a real usage dataset.
We show that PSN-CF highly improves the accuracy of predictions in terms of MAE. Moreover, the use of
clustering and positive sequences before computing the navigational correlations contributes to an important
reduction of time processing.
1 INTRODUCTION
The development of Internet engendered an impor-
tant proliferation of information resources. Thus, the
need of tools for automatic personalization of infor-
mation becomes heightened. Recommender systems
are widely used for this purpose thanks to their abil-
ity to analyze users behaviors and guide them towards
relevant resources that suit their preferences.
Collaborative Filtering (CF) is a recommendation
technique that identifies similarities between users,
based on their ratings in order to select neighbors and
compute predictions for the active users.
Despite the success of recommender systems
and collaborative filtering in many application areas,
some research questions still remain. Some of these
questions concern the requirement of explicit rating
data to compute correlations between users. As ex-
plicit rating data is not always available, one chal-
lenge for recommender systems is to take into consid-
eration another type of data that could represent effi-
ciently users behaviors. In this context, usage traces
can be a relevant source of data.
Moreover, another challenge for CF systems is the re-
duction of space dimensionality. Indeed, as the num-
ber of users and resources tend to increase, it turns out
that the required time for computing correlations and
generating neighborhoods also increases. Therefore,
employing clustering techniques is one way to reduce
time required for processing these correlations.
So, the research problem we are interested in, is
related to the integration of usage traces in CF sys-
tems. Thus, by using these traces, how can we es-
timate implicit ratings, how can we select nearest
neighbors and evaluate correlations between users, fi-
nally how can we improve the accuracy of predic-
tions.
In this paper, we attempt to explore these issues
and propose some solutions. We suggest a new CF ap-
proach called PSN-CF, that exploits navigational pat-
terns to model users. This approach integrates users
clustering and a new navigational based technique to
enhance the performance of CF.
This paper is organized as follows. We describe in
the second part some research studies related to clus-
tering based recommendersystems and analysis of us-
age traces. In the third part of the paper, we present
the PSN-CF approach. The fourth part describes the
experimentation. Then, the results of the model ex-
perimentations are put forward in the fifth part and
finally we discuss these results and present a conclu-
sion.
364
Esslimani I., Brun A. and Boyer A.
A COLLABORATIVE FILTERING APPROACH COMBINING CLUSTERING AND NAVIGATIONAL BASED CORRELATIONS.
DOI: 10.5220/0001841303640369
In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page
ISBN: 978-989-8111-81-4
Copyright
c
2009 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
2 RELATED WORK
2.1 Clustering based Recommender
Systems
In the context of recommender systems, clustering
algorithms are generally used to identify clusters of
similar users, sharing preferences. Clustering meth-
ods have been integrated in several CF based recom-
mender systems in order to reduce dimensionality or
to alleviate the sparsity and scalability problems. To
overcome the sparsity problem, (Xue et al., 2005) use
a CF system based on a K-meansclustering in order to
smooth the unrated data for individual users accord-
ing to the clusters. For the same issue, (Jiang et al.,
2006) suggest a cluster-based collaborative filtering
based on an iterative clustering method that exploits
the inter-relationship between users and items. In this
model, both users and items are clustered using the K-
means algorithm, then a predicted rating is generated
over user classes and item classes.
As regards the problem of scalability, (Conner and
Herlocker, 1999) choose to partition items by exper-
imenting various clustering algorithms. Predictions
are then computed independently within each parti-
tion. With the same perspective (George and Merugu,
2005) use a collaborative filtering approach based on
a weighted co-clustering algorithm that involves si-
multaneous clustering of users and items.
2.2 Analysis of Usage Traces
Several studies describe the impact of usage traces
on the recommendation process in predictivesystems.
Analysis of usage traces is mainly related to the area
of Web Usage Mining (WUM) which aims at observ-
ing users behaviors while interacting with a system.
This observation refers to direct traces as explicit rat-
ings and annotations, or non direct traces like book-
marking, frequencies of visits, visited links, etc. from
which users preferences can be inferred.
Frequent patterns mining, Longest Common Sub-
sequences (LCS) technique and Markov models, are
some of the WUM approaches that tend to harness the
navigational activities in order to analyze users behav-
iors. (Gery and Haddad, 2003) describe the attempt of
frequent patterns mining as the discovering of time or-
dered sequences that have been followed by past users
in order to predict future resources.
Discovering of Longest Common Subsequences
(LCS) is another technique that has been applied in
WUM domain in order to analyze the potential links
between navigational paths and users profiles. Ba-
sically, this technique is one dynamic programming
method, it aims at identifying the longest common
subsequence relating to two given sequences. (Jalali
et al., 2008) suggest an LCS based architecture for
classifying navigational patterns and generating pre-
dictions to users. In (Banerjee and Ghosh, 2001) an
algorithm based on LCS technique is proposed for
clustering users by using their navigational data. This
clustering approach uses the similarities between two
navigational paths based on the LCS and the time
spent on resources contained in this LCS.
Another approach that uses sequential links for
navigational activities is Markov chain model. In ac-
cordance with (Eirinaki et al., 2005), the sequential
dependencies of navigational behaviors of users are
modeled by Markov Models ; the conditional proba-
bility of one resource, considering users navigational
traces is computed.
3 DESCRIPTION OF PROPOSED
APPROACH
In this paper, we propose a new collaborative filtering
model which exploits on one hand clusters of users
based on a similarity matrix of users ; this step allows
a reduction of dimensionality. On the other hand it
uses the navigational patterns, so as to refine the result
of this clustering and produce recommendations.
Figure 1 describes the different layers of our
model called “Pam clustering on Similarities and
Navigational based-CF” (PSN-CF) comparing to the
classical clustering based CF model. The classical
clustering based CF (dashed lines) uses directly the
rating matrix (User x Item) in order to generate clus-
ters and compute predictions. At the opposite, the
PSN-CF model (solid lines) uses a similarity matrix
(User x User) computed by using the rating matrix,
so as to create clusters of users. At the same time,
PSN-CF applies a selection of “Positive Sequences”
from the original users sequences, these sequences
contain the preferred accessed resources. Then PSN-
CF computes the navigational correlations between
users, based on Positive Sequences, within individ-
ual clusters. The Positive Sequences are used to im-
prove the time processing over the stage of computing
navigational correlations. Finally, the new generated
neighbors are used to compute predictions.
The following sections present in details the dif-
ferent mechanisms used by PSN-CF model at each
layer.
A COLLABORATIVE FILTERING APPROACH COMBINING CLUSTERING AND NAVIGATIONAL BASED
CORRELATIONS
365
Similarity Matrix (U x U)
Rating Matrix (U x I)
Clustering
Clusters
Computing of Navigational
correlations
Generation of Predictions
Users Sequences
Positive Sequences
Estimation of ratings
Computing
Correlations of ratings
Generation of clusters
Selection of neighbors
Selection of neighbors
Input
Usage Traces
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Input
Classical clustering based CF
PSU-CF
Figure 1: Global scheme comparing the PSN-CF approach
to the classical clustering based CF.
3.1 Estimating Ratings
As mentioned in section 2.2, implicit ratings can be
inferred from users navigational activities. In our ap-
proach, to estimate these ratings (Layer 1) we choose
two implicit parameters: frequencies of visiting a re-
source and duration of visiting a resource. Consider-
ing an active user u
a
, the frequency of visiting an item
i
k
is the ratio of the number of visits of i
k
(N
(u
a
,i
k
)
) and
the average number of visits on all items I (
N
(u
a
,I)
) as
described in Equation (1).
Frequency
(u
a
,i
k
)
=
N
(u
a
,i
k
)
N
(u
a
,I)
(1)
As regards duration, it is computed as the ratio of the
duration of visiting an item i
k
(Drt
(u
a
,i
k
)
) and the total
duration of visiting all items I (Drt
(u
a
,I)
) as presented
in Equation (2).
Duration
(u
a
,i
k
)
=
Drt
(u
a
,i
k
)
Drt
(u
a
,I)
(2)
Once frequencies and durations are calculated, we
use a formula suggested by (Castagnos, 2008), in or-
der to compute and normalize our ratings according
to the rating scale [1 5] from bad to excellent.
3.2 Computing Clusters
In the context of recommender systems, clustering
methods usually use “User x Item” matrices to cre-
ate clusters. In our approach, we choose to employ
rather a “User x User” matrix (containing similarity
values between users) in order to generate clusters.
Hence, the clusters are constructed based on similari-
ties with other users instead of similarities on ratings.
Moreover,in classical clustering approaches, the clus-
ters are constructed based on co-rated items between
users. At the opposite, our approach ensures the ex-
ploitation of additional items by taking into account
users similarities.
3.2.1 Generation of the Similarity Matrix
In order to generate the “User x User similarity ma-
trix (Layer 2) required for the clustering step, we use
the Pearson Correlation Coefficient (Herlocker et al.,
1999) so as to compute the similarities between users
based on the estimated ratings.
3.2.2 Users Clustering
In our approach, the goal of clustering data is to
reduce the search space and the time required for
computing navigational correlations and to improve
the selection of neighborhoods. We choose a parti-
tioning algorithm called PAM (Partitioning Around
Medoids). The relevance of the PAM method com-
paring to other partitioning algorithms like K-means
is its robustness (Kaufman and Rousseeuw, 1990).
We choose to use a “User x User” matrix as input of
the PAM algorithm. Thus, clusters are generated ac-
cording to the similarities between users as presented
in Layer 3. In the following section, we present the
technique used for evaluating navigational similarities
between users.
3.3 Navigational Similarities
We propose at this step the integration of navigational
patterns in the process of recommendations based on
a collaborative approach, so as to refine the clusters
provided by the previous step (Layer 4).
In our model, we consider that two users u
a
and
u
b
, who share common sequential patterns are highly
correlated. Therefore, our goal is to identify for ev-
ery pair of users < u
a
, u
b
>, the maximum length
L
Kmax
(u
a
, u
b
) of a pattern among their common pat-
terns. As described in (Layer 3), we select from orig-
inal sequences, only “Positive Sequences”(P
s
) in or-
der to reduce the time processing required to identify
these common patterns among users sessions. Thus,
WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies
366
we retain in sequences only items with high ratings.
Then, the similarity of navigation between two users
is computed by using Equation 3.
This formula computes, for each pair of users u
a
and u
b
the correlation of navigation SimNav
(u
a
,u
b
)
as
the ratio of the maximum length of a common fre-
quent pattern L
Kmax
(u
a
, u
b
) and the minimum of max-
imum sizes of u
a
and u
b
sessions denoted SessMax
(u
a
)
and SessMax
(u
b
)
. We note that the common frequent
pattern is intra-session.
imNav
(u
a
,u
b
)
=
L
Kmax
(u
a
, u
b
)
min(SessMax
(u
a
)
, SessMax
(u
b
)
)
(3)
This metric emphasizes the importance of the
longest frequent patterns to evaluate similarities of
users. The higher the length of a sequential pattern
is, the more the users are correlated.
3.4 Prediction Generation
Once the navigational similarities between the active
user and other users within a cluster are calculated, we
employ the weighted average prediction formula used
by classical CF (Herlocker et al., 1999) to compute
predictions. This step corresponds to the last layer of
the PSN-CF approach (Layer 5).
4 EXPERIMENTATION
4.1 Datasets
In order to evaluate the performance of PSN-CF, we
use real usage datasets extracted from the intranet of
Credit Agricole Banking Group, in particular the us-
age data relating to the Department of Strategies and
Technology Watch.
Thus, to train our model, we use the usage data
that reflects the navigational activities of users. This
data has been collected during 24 months and stored
in server log files. The selected dataset is related to
748 users and 3856 resources. It has been split into
80% and 20% corresponding respectively to training
and test datasets. The tests have been performed on
a Windows Server 2003 PC, with 2 Go of RAM and
3, 4 GHz processor (Pentium IV).
As regards clustering, in order to create clusters
from matrices, we used “R”
1
, an environment for sta-
tistical computing and graphics. In our experiments,
10 clusters are created.
1
http://www.r-project.org
4.2 Evaluation
Different evaluation metrics can be used in the exper-
imentation of CF systems. The most important crite-
rion in recommender systems is precision. The preci-
sion measures the accuracy of recommendations com-
paring to real votes. As a measure of precision evalu-
ation, we used the Mean Absolute Error (MAE). This
metric computes the mean of absolute errors between
predicted ratings and the real ratings that are actually
assigned by users.
Since items that have high prediction values are
the ones that are recommended to users, we use also
the HMAE (High MAE) metric (Baltrunas and Ricci,
2007) to evaluate the performance of the model. The
HMAE is similar to MAE but it considers only items
that are predicted with a value of 4 or 5. In our exper-
imentation, we choose the HMAE metric to measure
how our system is able to recommend relevant items
to active users.
5 RESULTS
In order to analyze the performance of our approach,
we evaluate the precision of predictions generated by
the PSN-CF model in terms of MAE and HMAE.
PSN-CF accuracy is compared to several variants of
CF models so as to study the impact of clustering
users, the influence of the nature of the matrix used
for clustering users and the importance of using navi-
gational patterns.
Additionally, we evaluate the impact of the use of
Positive Sequences on time processing of naviga-
tional based correlations.
We note that, before the computation of predic-
tions (Layer 5), we used at the same time (for all the
models) two criteria to select the nearest neighbors of
the active user: a threshold relating to the correlation
value between the active user and other users and a
minimum number of co-rated items between the ac-
tive user and other users.
5.1 MAE
Table 1 presents the MAE values related to CF mod-
els when either no clustering is performed or cluster-
ing is applied on a rating matrix. We can first no-
tice that when no clustering is performed the accu-
racy only slightly decreases when only navigational
data is used, compared to classical CF. This confirms
the idea that navigational patterns are almost as infor-
mative as rating data and may contain complementary
information to ratings.
A COLLABORATIVE FILTERING APPROACH COMBINING CLUSTERING AND NAVIGATIONAL BASED
CORRELATIONS
367
Table 1: MAE values with and without clustering.
Classical CF Navigational CF
No clustering 0.7631 0.7895
K-means 0.7826 0.7971
PAM 0.7998 0.8253
Table 2: MAE values when using a similarity matrix for
clustering.
Navigational CF
K-means 0.7809
PAM 0.6747
In the case of classical CF, performing clustering
on ratings (referred to as Classical Clustering based
CF in Figure 1, Layers 1, 3 and 5) does not improve
the accuracy. PAM clustering leads to the lowest ac-
curacy (decrease of about 5%). Besides, when con-
sidering navigational data (in addition to ratings), we
can notice that, as in the case of classical CF, the use
of PAM clustering on a rating matrix leads to the low-
est accuracy.
The PSN-CF model we propose is based on clus-
tering applied on a similarity matrix (Layers 1, 2, 3,
4 and 5), we thus present in Table 2 the correspond-
ing MAE when either PAM or K-means algorithm is
performed.
From Table 2, we observe that when performing
PAM clustering on a similarity matrix of users, MAE
is improved by about 15% compared to clustering on
a rating matrix. This configuration corresponds to the
PSN-CF model. This improvement can be explained
by the fact that using a similarity matrix to perform
clustering does not group users only according to the
way they have similarly rated items commonly seen.
Users are grouped in a cluster when they are com-
monly similar to all the other users. Moreover, this
approach has the advantage to not only consider com-
monly rated items, but all the items users have rated.
From Tables 1 and 2, we can notice that the K-
means clustering slightly depends on the nature of the
matrix: similar accuracy values are obtained for both
matrices.
5.2 HMAE
Let us recall that only items with high prediction val-
ues are suggested by recommender systems to the ac-
tive user. Here, we are also interested in the HMAE
values when performing clustering, based on a rating
matrix or a similarity matrix. These values are pre-
sented in Tables 3 and 4.
Table 3: Comparison of HMAE values with and without
clustering.
Classical CF Navigational CF
No clustering 0.5415 0.5014
K-means 1.2851 1.2723
PAM 1.1689 1.1590
Table 4: HMAE values when using a similarity matrix for
clustering.
Navigational CF
K-means 0.5874
PAM 0.6036
We can first notice that when no clustering is per-
formed, navigational based CF outperforms classical
CF by 7% in terms of HMAE, contrary to MAE.
When clustering is based on a rating matrix (Table
3), HMAE values are highly increased for both clas-
sical and navigational CF. However, at the opposite
of MAE (Table 1), the use of navigational patterns in
addition to ratings leads to an improvementof HMAE
in all the studied models.
Table 4 presents the HMAE values related to clus-
tering based on a similarity matrix in the case of a
navigational CF. When clustering is applied on a sim-
ilarity matrix, HMAE is highly decreased for both K-
means and PAM clustering comparing to the results
of Table 3. The lowest HMAE is obtained when K-
means is used, however a similar HMAE is observed
when using PAM clustering (the PSN-CF model).
Even if no improvement is obtained in terms of
HMAE compared to no clustering, a large improve-
ment is obtained in terms of MAE and the computa-
tion time of neighbors is decreased. The following
section is dedicated to the study of this computation
time.
5.3 Time Processing
We are now interested in the time processing required
during the phase of computing the navigational cor-
relations within clusters, by either applying the selec-
tion of Positive Sequences or not.
Results show that the models that do not perform
clustering require on average a computation time 4
times higher for computing the navigational corre-
lations. We observe also that the selection of Posi-
tive Sequences contributes to an important reduction
of time processing. Indeed, the processing time de-
creases by about 8% when no clustering is used and
from 16% to 30% for clustering-based models. Let
us note that the use of Positive Sequences by naviga-
WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies
368
tional based models decreases accuracy at the worst
case by about 1.85% in terms of MAE and by 2.34%
in terms of HMAE. When PAM clustering is used ei-
ther an improvement or a stability is observed in terms
of accuracy.
6 CONCLUSIONS
In this paper, we presented a new Collaborative Fil-
tering approach, named PSN-CF, that exploits navi-
gational patterns. PSN-CF is structured in different
layers as described in Figure 1.
Unlike classical predictive systems based on us-
age patterns, PSN-CF is user-based and attempts to
identify behavioral correlations between users. The
originality of PSN-CF consists in the exploitation of
navigational patterns in the context of CF, thus no ex-
plicit preferences need to be provided by users. Ad-
ditionally, PSN-CF exploits the concept of Positive
Sequences so as to assess navigational correlations
based on users preferred resources with the objective
of reducing time processing required for computing
these correlations.
PSN-CF has been evaluated both in terms of MAE
and HMAE and has been compared to other CF mod-
els. The experimentation shows the high interest of
using the PAM clustering based on a similarity ma-
trix, on the accuracy of the CF system in terms of
MAE. Moreover, the use of clustering based on simi-
larities is also benefit in terms of HMAE. Experiments
also showed the relevance of using both navigational
patterns and estimated rating data for generating ac-
curate high predictions. Last, the experiments showed
the advantage of selecting Positive Sequences that is
a trade-off between the optimization of time process-
ing of navigational correlations and reduction of ac-
curacy.
As a future work, we intend to first exploit addi-
tional methods that allow the reduction of dimension-
ality, second evaluate the impact of its combination
with the navigationalbased CF on the accuracy of rec-
ommendations. Additionally, we plan to extend PSN-
CF in the direction of social networks and examine
the possibilities of modeling potential links between
users in the context of behavioral networks.
ACKNOWLEDGEMENTS
We would like to thank Mr. Jean Philippe Blanchard
and acknowledge the financial support to this project
provided by the Credit Agricole Banking Group.
REFERENCES
Baltrunas, L. and Ricci, F. (2007). Dynamic item weighting
and selection for collaborative filtering. In Web mining
2.0 Workshop, ECML-PKDD 2007. Springer-Verlag.
Banerjee, A. and Ghosh, J. (2001). Clickstream cluster-
ing using weighted longest common subsequences. In
Proceedings of the Web Mining Workshop at the 1st
SIAM Conference on Data Mining.
Castagnos, S. (2008). Mod´elisation de comporte-
ments et apprentissage stochastique non supervis´e de
strat´egies d’interactions sociales au sein de syst´emes
temps r´eel de recherche et d’acc´es `a l’information.
PhD thesis, Nancy 2 University, France.
Conner, M. and Herlocker, J. (1999). Clustering items for
collaborative filtering. In Proceedings of the ACM SI-
GIR Workshop on Recommender Systems.
Eirinaki, M., Vazirgiannis, M., and Kapogiannis, D. (2005).
Web path recommendations based on page ranking
and markov models. In Proceedings of the 7th annual
ACM international workshop on Web information and
data management. ACM Press.
George, T. and Merugu, S. (2005). A scalable collaborative
filtering framework based on co-clustering. In Pro-
ceedings of the Fifth IEEE International Conference
on Data Mining. IEEE Computer Society.
Gery, M. and Haddad, H. (2003). Evaluation of web usage
mining approaches for user’s next request prediction.
In Proceedings of the 5th ACM international work-
shop on Web information and data management. ACM
Press.
Herlocker, J., Konstan, J., Borchers, A., and Riedl, J.
(1999). An algorithmic framework for performing
collaborative filtering. In Proceedings of the 22nd
annual international ACM SIGIR conference on Re-
search and development in information retrieval.
Jalali, M., Mustapha, N., Sulaiman, N., and Mamat, A.
(2008). A web usage mining approach based on lcs
algorithm in online predicting recommendation sys-
tems. In Proceedings of 12th conference of informa-
tion visualisation.
Jiang, X., Song, W., and Feng, W. (2006). Optimizing col-
laborative filtering by interpolating the individual and
group behaviors. In APWeb.
Kaufman, L. and Rousseeuw, P. (1990). Finding Groups
in Data: An Introduction to Cluster Analysis. John
Wiley and Sons, New York.
Xue, G., Lin, C., and Yang, Q. (2005). Scalable collabo-
rative filtering using cluster-based smoothing. In Pro-
ceedings of the 28th annual international ACM SIGIR
conference on Research and development in informa-
tion retrieval.
A COLLABORATIVE FILTERING APPROACH COMBINING CLUSTERING AND NAVIGATIONAL BASED
CORRELATIONS
369
