TOWARD SOCIAL SEARCH

From Explicit to Implicit Collaboration to Predict Users’ Interests

Luca Longo, Stephen Barrett and Pierpaolo Dondio

Department of Computer Science and Statistics, Trinity College Dublin

Keywords:

Social search, User behavior, Computational trust, Web site classiﬁcation.

Abstract:

The concept of social search has been acquiring importance in the WWW as large-scale collaborative com-

puting environments have become feasible.This ﬁeld focuses on the reader’s perspective in order to assign

relevance and trustworthiness to web pages. Although current web searching technologies tend to rely on

explicit human recommendations, these techniques are hard to scale as feedback is hard to obtain. Implicit

feedback techniques, on the other hand, can collect data indirectly. The challenge is in producing implicit

web-rankings by reasoning over users’ activity during a web-search without recourse to explicit human inter-

ventions. This paper presents a comparison between explicit and implicit users’ feedbacks upon web pages.

An experiment, involving 25 volunteers explicitly evaluating the usefulness of 12 thematic web-sites, was per-

formed implicitly gathering their web browsing activity. The results obtained prove the existence of a strong

correlation between explicit judgments and generated implicit feedbacks.

1 INTRODUCTION

The main advantage of systems supporting social

search is that Web pages are considered relevant

and trustworthy from the reader’s perspective rather

than web sites owners. Such solutions contrast with

the majority of the current search engines, above all

Google, whose Page-Rank algorithm assigns impor-

tance to web-pages based on the analysis of the link

structure of the Web. A key open challenge in de-

signing social search systems is to improve the over-

all information seeking and consuming activities on

the Web. Reading time, scrolling, cut-paste are all

considered relevant implicit sources of user prefer-

ences (Kelly and Belkin, 2001). In the current web-

searching technologies, a substantial inhibitor in gath-

ering this content from users is that they tend to be

resistant to invasive techniques and there exists lack

of motivation to actively generate recommendations.

Implicit feedback techniques gather data indirectly

and the key issue is to produce implicit web-rankings

automatically deduced by reasoning on the activity

performed by users over web-pages. In this work

we propose a novel approach to collaborative social

search that analyses users’ actionsduring Internetses-

sions capturing this activity. Such activity embod-

ies implicit ‘human judgement’ where each web-page

has been viewed and endorsed by one or more peo-

ple concluding that it is There are three key beneﬁts

of such a solution. First, as each result has been se-

lected by users, by reasoning on their behaviour, it

is possible to obtain a relevant degree of trustworthi-

ness. Second, the social search engine operates con-

currently over continuously updating of user activity

and so it is well positioned to display stronger results

more current or in context with changing information.

Third, it is possible to reduce the impact of link Spam

by relying less on link structure of web-pages. The

paper is structured presenting in 2 related works; in

3 we underline the hypothesis, we describe the ex-

periment and the formal model commenting obtained

results. We conclude in 4, with future work and open

issues.

2 RELATED WORK

The concept of social search has been acquiring im-

portance as the World Wide Web grows in size and

web-searching technology has become an essential

need in web-browsing. Several methods have been

conceived from the simplest, based on sharing book-

marks, to more sophisticated approaches that com-

bine human intelligence with computer paradigms

(Agichtein, et al,.2006) supporting collaborativegath-

693

Longo L., Stephen B. and Dondio P.

TOWARD SOCIAL SEARCH - From Explicit to Implicit Collaboration to Predict Usersâ

Z Interests.

DOI: 10.5220/0001841406840687

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

ering and collaborative directories. In (Atterer

et al.,2006) the authors focused on tasks such as clas-

sifying the user with regard to computer usage proﬁ-

ciency or making a detailed assessment of how long it

took users to ﬁll in ﬁelds of a form. They developed

an HTTP proxy that collects data about mouse move-

ments, keyboard input and more. Similarly in the

work of Velayathan and Al. (Velayathan and Yamada,

2007), an unobtrusively framework logs and analyses

users’ behaviour to extract effective rules to evaluate

web-pages using a machine-learning techniques. In

the work reported in (Kelly and Belkin, 2001) the au-

thors focused on the hypothesis that users will spend

more time, scroll more often and interact more with

those documents they ﬁnd relevant. Similarly, in the

work of Weinreich et Al., (Weinreich et al., 2006) au-

thors found that users spend less than 12 seconds on

nearly 50% of the web-pages shown to them demon-

strating users make nearly 50% of their decision to

navigate to the next page before reading substantial

part of the contents.

Collaboration is a process where people interact

each other toward a common goal, by sharing their

knowledge, learning and building consensus. There

are two main way to provide judgement: explicitly

and implicitly. In the former way, users can pro-

vide feedback using a speciﬁc metric, for example as

in eBay and Amazon community. In the latter way,

implicit judgements are inferred from user behaviour

while doing a speciﬁc action. Collaboration applied

to the Web 2.0 supports a new kind of shared intelli-

gence, named Collective Intelligence where users are

able to generate their own content building up an in-

frastructure where contributions are not merely quan-

titative but also qualitative.

The relevance of Trust and Reputation in human

societies is indisputably recognised A trust-based de-

cision is a multi-stage process on a speciﬁc domain.

This process starts identifying and selecting pieces

of trust evidence, generally domain-speciﬁc, conduct-

ing an analysis over the application involved. Subse-

quently, trust values are produced performing a Trust

computation over the pieces of evidences estimating

the trustworthiness of entities in the domain consid-

ered. Both the previous steps are informed by a no-

tion of trust in the Trust model and the ﬁnal Trust de-

cision is taken by considering the computed valued

along with exogenous factor like disposition or risk

assessments. The proliferation of collaborative envi-

ronments represent good examples in which Compu-

tational Trust paradigms are applied in order to eval-

uate the trustworthiness of virtual identities. Longo et

al. (Longo et al., 2007) conceived a set of rare trust

evidences based on time and applied on Wikipedia,

demonstrating how plausible Trust decisions can be

reached using exclusively temporal factors. Team-

work and co-operation (Montaner et al., 2002) repre-

sent other areas where the game theory is the predom-

inant paradigm considered to design Computational

Trust models.

3 IMPLICIT/EXPLICIT

COLLABORATION:

EXPERIMENT AND TRUST

MODEL

The hypothesis behind this work is to understand

whether, taking into account an entity and applying

Computational Trust paradigms by using reasoning

techniques, explicit human judgements are correlated

with the corresponding implicit derived feedback. We

explore this question in the context of web-page me-

dia. If the answer is positive, i.e., there exists a cor-

relation between them, it is possible to build up a col-

laborative environment achieving good predictions in

a non-invasive way. In particular, we can conclude

that, examining users’ behaviour while surﬁng the In-

ternet, we can generate a set of ranked results where

the top ones represent the most valuable content con-

sidered by users and thus, by implication valuable to

other similar users. We refer at this kind of collabora-

tion as implicit collaboration to distinguish from the

classic, explicit collaboration, where users expressly

provide feedback, evaluations and judgements. Our

solution was to log all the activity in the browser gath-

ering the main events(E

) that may occur during an In-

ternet session. The logger does not perform any kind

of computation, it does not apply any Computational

Trust paradigms nor does it ﬁlter out events.

We conducted experiments in order to investigate

the ability of our approach to gather logs of user be-

haviour. 25 unpaid volunteers, with different back-

grounds, were recruited to participate in this study.

We asked each of them to organise a trip to Morocco,

2-weeks long, surﬁng a pre-deﬁned list of web-sites

from which it is possible to collect information about

popular cities, transports, hotels. We proposed a list

of 12 selected urls, that users can use within 60 min-

utes in which they have to naturally interact with the

browser, collecting useful data, cutting and pasting

relevant information, bookmarking interesting pages,

submitting data, saving picture or documents in order

to recover this information in the future. Finally, we

ask to each of them to explicitly provide a judgement

of the usefulness of each web-site using a common

scale from 1 to 10 (1 means not useful and 10 means

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

694

Table 1: Event hierarchy with associated weights.

♯ Type Description Weight

1 very rare E

: save as (page) W

= 22%

2 rare E

: bookmark W

= 18%

3 rare E

: printing W

= 18%

4 not frequent E

: save as (picture) W

= 10%

5 not frequent E

: download W

= 10%

6 frequent E

: cut & paste text W

= 8%

7 frequent E

: search text W

= 8%

8 very frequent E

: form input W

= 4%

9 very frequent E

: scrolling W

= 2%

very useful). In this experiment we assume that vol-

unteers act not maliciously, hence the data contained

in the logs ﬁle is the proper representation of the real

actions performed by them while surﬁng the Inter-

net. We assume also that volunteers do not change

their behaviour in order to alter generated logs data.

At the end of the experiment, a set of noisy infor-

mation is obtained for each user, containing his ac-

tivity while surﬁng the given web-sites. Since vol-

unteers can jump from one given web-site to another

one, gathered logs need to be ﬁltered and aggregated

to produce a well deﬁned set of data that we refer as

‘user-behaviour pattern’. For these reasons, we devel-

oped a function named ‘ﬁlter/aggregator’ that analy-

ses the data, ﬁlters all the urls not in the given set

and aggregate it grouping per web-page. This mod-

ule produces 12 ‘user-behaviour patterns’ containing

the occurrences of events, one for each given web-

sites. At this stage, it is now possible, by applying

Computational Trust paradigms, to generate a unique

value of a given pattern indicating the usefulness of

a given web-site for a speciﬁc user. More than one

Computational Trust factors may be adopted and each

of their outputs may be aggregated to obtain a more

precise usefulness/trustworthiness degree for a given

web-site. Considering the ‘ﬁlter/aggregator’ function,

12 unique values, one for each given web-site are

generated. We deﬁned a basic Computational Trust

model that extracts the occurrences of events in the

‘user-behaviour pattern’ and compute a real value in

the range [0..1]. Since ‘scrolling’ events are more fre-

quent than ‘save as’ events or a ‘cut & paste’ should

be less important than ‘bookmark’ events, a hierarchy

is needed to discriminate their importance. The goal

of this paper is not to study a hierarchy of such events

hence we consider the work presented by (Velayathan

and Yamada, 2007), in which the authors provide the

frequency of the most and the least events performed

in their experiment while surﬁng the Internet, to pro-

pose our ‘event-hierarchy’ with weights, as described

in the table 1.

The ﬁnal real value of the model is computed

by aggregating the occurrences of each event con-

tained in the ‘user-behaviour pattern’ and by using

the ‘event-hierarchy’ as shown in the following for-

mal model:

Trust

value

: BP[] → [0..1]

Trust

value

(BP[]) =

∑

i=1

S(BP[E

])

S =











0 if ∀E

, BP[E

] = 0

if BP[E

] = 1 & E

= 6, 7, 8, 9

if BP[E

] = 2 & E

= 6, 7, 8, 9

if BP[E

] ≥ 2 & E

= 6, 7, 8, 9

if BP[E

] = 1 & E

= 4, 5

if BP[E

] ≥ 2 & E

= 4, 5

if BP[E

] ≥ 1 & E

= 1, 2, 3

where BP is the ‘user-behaviour pattern’ vector, E

is a speciﬁc event and n is the cardinality of the possi-

ble events. For frequent and very frequent events, the

model assigns full corresponding weight (W

), if and

only if events occurred more than twice, otherwise

of weight is returned for 2 occurrences,

for just one

and 0 otherwise. For not frequent event two occur-

rences are enough to set full weight and

for just one

occurrence. Eventually, for rare events such as ‘book-

marks’, ‘save as page’ and ‘printing’, just one occur-

rence is relevant, hence full corresponding weight is

assigned. Taking into account both the 12 values pro-

duced by using our schema and the 12 judgements

provided by each volunteer, we can use statistical cor-

relation indexes to test the hypothesis. In particular,

in this work we adopt the Pearson’s correlation co-

efﬁcient that measures the strength of the linear de-

pendence between the implicit and the explicit val-

ues. If the correlation value obtained by considering

the implicit value and the explicit judgement, for a

given web-site and a given volunteer, tends to 1, a lin-

ear equation describes the relationship positively with

the implicit value increasing with the explicit value.

A score of −1 shows the inverted relationship and a

value tending to zero shows that there is no linear re-

lationship so the variable considered are independent.

In order to test the hypothesis, we expect high correla-

tion values, one for each use: if the majority of these

values tend to 1, our hyphotesis is conﬁrmed and we

can sustain there exists a strong relationship between

implicit feedback and explicit human judgements as

captured by our model.

The set of Pearson’s correlation values obtained

from the experiment are encouraging. The mean of

the users is 0.6 and more than 50% of them are above

the value of 0.7. The 24% of them has a correla-

tion value less then the threshold of 0.5. The 12%

TOWARD SOCIAL SEARCH - From Explicit to Implicit Collaboration to Predict Users' Interests

695

of user show a low relationship between the explicit

judgement and the implicit derived value: this fact

shows our method did not succeed for 3 people. In 2

cases the experiment returns negative correlation co-

efﬁcients, hence implicit and explicit values have an

inverted relationship. 68% of users exhibit a corre-

lation value above the mean. The strategy proposed

is not strong in the short term: a web-site visited

by a couple of users may have an average of trust-

worthiness higher than a web-site visited by thousand

of users. An approach to resolve this problem may

be the adoption of a threshold, explicitly deﬁned or

learned with unsupervised techniques, indicating the

minimum number of users who had to have implicitly

viewed the same site.

4 CONCLUSIONS AND FUTURE

WORK

In this study we performed a context-dependent com-

parison between explicit human judgements, pro-

vided by volunteers, and implicit judgements derived

by using Computational Trust techniques. Through

an experiment we demonstrated how, taking into ac-

count a digital entity as a web-site, human explicit

judgement can be strongly connected to the implicit

derived value on the same entity. The evaluation was

conducted by considering 12 Urls evaluated by users

explicitly providing a degree of usefulness. During

browsing sessions we logged users’ activity and a

behaviour-pattern, containing the occurrences of gen-

erated events, was extracted for each of them and each

web-site. Computational Trust paradigms helped us

to automatically evaluate these patterns and to gen-

erate trustworthiness values. The Pearson’s coefﬁ-

cient was used to study the correlation between ex-

plicit users’ judgements and derived usefulness val-

ues. Even considering a small number of users and

a basic Trust model, encouraging results were ob-

tained proving our hypothesis and underlying how

it is possible to automatically evaluate entities such

web-pages, by reasoning on users’ activity over them.

This is a new approach and thus there is further work

to do. Authors believe it represents a start point

to predict users’ interests and to build up a third-

generation social search engine based on implicit col-

laboration. Future works will be focused on exper-

iment in malicious environments taking into account

privacy/anonymity issues. New reasoning techniques

should be investigated to better evaluate web-pages

and new algorithms are needed to semantically con-

nect searching queries to relevant sets of Urls gener-

ated by our schema.

REFERENCES

Kelly D. and J. Belkin N. (2001). Reading Time, Scrolling

and Interaction: exploring Implicit Sources of User

Preferences for Relevance Feedback During Interac-

tive Information Retrieval, SIGIR 2001, New Orleans,

LA, USA.

Agichtein E., Brill E. and Dumais S. (2006). Improving

Web Search Ranking by Incorporating User Behavior

Information. SIGIR 2006, USA.

Atterer R., Wnuk M. and Schmidt A. (2006). Knowing

the User’s Every Move - User Activity Tracking for

Website Usability Evaluation and Implicit Interaction.

WWW 2006, Edinburgh.

Velayathan G. and Yamada S. (2007). Behavior-based Web

Page Evaluation, WWW 2007, Canada.

Longo L., Dondio P. and Barrett S. (2007). Temporal Fac-

tors to evaluate trustworthiness of virtual identities.

IEEE SECOVAL 2007, France.

Weinreich H, Obendort H., Herder E. and Mayer M. (2006).

Off the Beaten Tracks: Exploring Three Aspects of

Web Navigation. WWW 2006.

Montaner M., Lopez B. and De La Rosa J. (2002). De-

veloping Trust in Recommender Agents. AAMAS-02,

Bologna, Italy, 2002.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

696
