EVALUATION OF UML IN PRACTICE

Experiences in a Trafﬁc Management Systems Company

Michel dos Santos Soares and Jos Vrancken

Faculty of Technology, Policy and Management, Delft University of Technology

2600 GA Delft, The Netherlands

Keywords:

UML, SysML, Petri nets, Empirical Software Engineering, Software Process Improvement, Action Research.

Abstract:

This article is about research performed by the authors into improving the Software Engineering process at a

company that develops software-intensive systems. The company develops road trafﬁc management systems

using the object-oriented paradigm, and UML as the visual modeling language. Our hypothesis is that UML

has some difﬁculties/drawbacks in certain system development phases and activities. Many of these problems

were reported in the literature normally after applying UML to one project and/or studying the language’s

formal speciﬁcations and comparing with other languages. Unfortunately, few publications are based on

surveys and interviews with practitioners, i.e., the developers and project managers that are using UML in real

projects and are frequently facing these problems. As a matter of fact, some relevant questions were not fully

addressed in past research, mainly related to UML problems in practice. The purpose of this text is to report

the main ﬁndings and the proposed improvements based on other methods/languages, or even considering

UML diagrams that are not often used. The research methodology involved surveys, interviews and action

research with a system developed in order to implement the recommendations and evaluate the proposed

improvements. The recommendations were considered feasible, as they are not proposing to radically change

the current situation, which would involve higher costs and risks.

1 INTRODUCTION

This article is about research done to improve Soft-

ware Engineering processes in practice in a com-

pany that develops software-intensive systems. More

speciﬁcally, the domain is dynamic road trafﬁc man-

agement systems, such as road trafﬁc monitoring and

control systems. Software process improvement has

been recognized in the literature as being capable of

reducing costs and augmenting quality and produc-

tivity (Herbsleb and Goldenson, 1996), (Rainer and

Hall, 2003), (Bannerman, 2008). The current ad-

vantages, practices and problems related to the com-

pany’s processes in general, and in particular with

UML, were evaluated.

UML (OMG, 2007) is currently the de facto stan-

dard object-oriented modeling language in the soft-

ware industry. It offers good structural representa-

tion for the static part of objects and provides several

types of dynamic diagrams for behavior speciﬁcation.

UML is used in projects varying from small to large

software-intensive systems, in a variety of domains.

Many studies on the application of UML were

performed in the past, and a large number of prob-

lems, limitations and drawbacks were identiﬁed. The

language is considered too informal and ambiguous

(Beneken et al., 2003), which makes it difﬁcult to

use in automatic code generation (Henderson-Sellers,

2005). There are too many diagrams, with some

rarely used in practice (Dobing and Parsons, 2006),

making it more difﬁcult to chose which one should

be used in a speciﬁc situation (Anda et al., 2006). In

addition, diagrams may overlap in modeling power

(Sequence and Communication diagrams, for exam-

ple), diagrams for important activities in systems de-

velopment are missing, such as designing graphical

user interfaces (Blankenhorn and Jeckle, 2004) and

representing non-functional requirements (Soares and

Vrancken, 2008b). More speciﬁcally, the language

diagrams also present problems. Behavior diagrams,

313

dos Santos Soares M. and Vrancken J. (2009).

EVALUATION OF UML IN PRACTICE - Experiences in a Trafﬁc Management Systems Company.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Information Systems Analysis and Speciﬁcation, pages

313-319

DOI: 10.5220/0001850903130319

 SciTePress

such as the Sequence diagram, cannot represent time

constraints effectively, (Soares et al., 2008), as they

are essentially untimed, expressing only chronologi-

cal order (Andr´e et al., 2007). Use Cases are too infor-

mal, with many semantic problems (Simons, 1999).

One clear semantic problem is that the include and ex-

tend relationships are considered similar or even the

inverse of each other (Jacobson, 2004). In addition,

Use Cases can be easily misused when too many de-

tails are modeled (Agarwal and Sinha, 2003).

Many of these problems were perceived due to

experience, normally after applying UML to some

projects and/or studying OMG Speciﬁcations and

comparing with other languages. Unfortunately, few

publications are based on surveys and interviews with

practitioners, i.e., the developers and project man-

agers that are using UML in real projects and are fre-

quently facing these problems. As a matter of fact,

some relevant questions related to UML problems in

practice were not fully addressed in past research. For

instance, what do developers think of UML? How do

they use UML in their projects? What can be im-

proved? These are among the questions answered in

the research that resulted in this article. Our approach

is based on surveys and interviews with practition-

ers that have used UML for several years in many

projects.

Despite all the well-known problems, UML also

presents many advantages, and is heavily used in

the modeling of software-intensive systems both in

academia and industry. The language is a combina-

tion and adaptation of well-known methods used in

the past, which facilitates the learning process. For

instance, Class diagrams are considered a superset

of Entity-Relationship diagram (Booch et al., 2005),

Sequence diagrams are based on SDL’s Message Se-

quence Charts (Collins et al., 1996), and the State-

Machine diagram is derived from Statecharts (Harel,

1987). As a generic modeling language, UML can be

used in many different projects, domains and method-

ologies. There are many software tools to support di-

agrams drawing. By now, the language has been al-

ready used for more than 10 years. By no means it

will be easy to simply stop using UML, and this arti-

cle and research do not advocate that. This article pro-

poses that UML can be better employed, adapted and

used jointly with other languages and methods. This

avoids radical changes, which have well-known draw-

backs, such as the necessity of additional training for

employees, buying and integrating new software tools

in the process, and adapting documentation of legacy

systems.

The purpose of this paper is to present the

evaluation of how UML is used in a company

that develops software-intensive systems, the main

difﬁculties/disadvantages recognized by the com-

pany, and propose improvements using other meth-

ods/languages.

2 RESEARCH QUESTIONS AND

METHODOLOGY

Our hypothesis is that UML is a useful software mod-

eling language that has some difﬁculties/drawbacks

in certain system development phases and activities.

We want to investigate the following questions about

UML and the development process used at the com-

pany.

• Which systems engineering phases and activities

present UML-related problems?

• What drawbacks/problems are most commonly

observed?

• What can be done to solve these difﬁculties and

drawbacks?

• Which UML diagrams are most suitable for each

development activity?

These questions are answered for a company develop-

ing systems for a speciﬁc domain: road trafﬁc man-

agement systems. Nevertheless, general, similar re-

sults can be inferred, as the systems considered in the

domain are software-intensive systems comparable,

in terms of complexity, to systems in other domains.

Rather then dealing only with theory to answer the

research questions, we have chosen to apply our own

theories in practice. The research methodology was

inspired by Action Research, which supports that re-

searchers should test their theories with practitioners

in real situations and real organizations (Avison et al.,

1999). Action Research combines theory and practice

through an iterative collaboration between practition-

ers and researchers. This collaboration is emphasized,

as it will help researchers understand the ill-structured

and complex environment of organizations. In each

iteration, problems are identiﬁed, intervention is per-

formed, and reﬂections on the results are presented.

The research approach was composed of ﬁve

steps. First, a questionnaire was performed with some

employees in order to understand the company’s de-

velopment context and processes. Then, data were

tabulated to serve as input for interviewing employ-

ees. The ﬁrst two steps were crucial to understand the

current situation, otherwise every effort for process

improvement would be useless. The third step was to

present to the company managers a diagnosis of cur-

rent problems. The diagnosis was based on data from

ICEIS 2009 - International Conference on Enterprise Information Systems

314

the survey and the interviews. The next step was to

use the diagnosis as input for a series of recommenda-

tions for improvements. The ﬁnal step was to actively

apply in practice the recommendations in a project in

order to be used as a model for further projects, and to

demonstrate the usefulness of the recommendations.

3 CURRENT SITUATION

The company where this study was performed is a

software development company with a long stand-

ing experience in the development of innovative traf-

ﬁc management software, with applications in every

major trafﬁc control center in the Netherlands. The

company develops systems according to the 4+1 view

model of software architecture (Kruchten, 1995), us-

ing UML as the modeling language for all the ﬁve

views. Implementation is performed using propri-

etary publish-subscribe middleware and a domain

speciﬁc language. The purpose of both is to raise the

abstraction level when developing applications.

In order to understand the current situation and the

difﬁculties faced in the development process, a survey

was proposed for developers and project managers.

The survey consisted of open questions and closed

statements, in which the respondent could give one of

the following answers: 0) Strongly disagree, 1) Dis-

agree, 2) Neutral, 3) Agree or 4) Strongly agree.

Open questions were related to the employee’s

own career, such as number of years of experience

with UML and road trafﬁc systems. Closed state-

ments were related to:

• UML in systems development activities. Exam-

ple: “UML is useful in the requirements phase”.

• Use Case diagrams. Example: “Use Cases are

sufﬁcient to be used as the only diagram for Re-

quirements representation”.

• UML problems in general. Example: “There are

constructions/diagrams missing in UML”.

• Development Process. Example: “I would like to

change radically the developmentprocess in order

to improve productivity/quality”.

Interviews were performed with selected respondents

in order to clarify some of their answers, receive more

informationabout problems in general, and even com-

ment any additional information added by the respon-

dents in the survey. Both the interviews and the sur-

vey were used to give a diagnosis of the current situa-

tion of the company’s development process.

4 DIAGNOSIS

The most important items of the produced diagnosis

are presented as follows.

1. The employees suggested simpliﬁcations in the

current process but also the inclusion of new

diagrams to model speciﬁc problems. Among

the suggested additions, better system overview,

showing a complete context of the system but

without many details, at least in the ﬁrst phases

of development, was mentioned. This overview

should be related more to the customer’s view-

point and less to the software.

2. According to the employees, UML could be com-

bined with other methods/languagesin order to di-

minish potential drawbacks.

3. About Use Cases.

• Use Case diagrams are used when talking to

clients and during software development. This

means that Use Cases are used for two com-

pletely different purposes in software design.

One is to present to stakeholders a high-level

model, delimiting the functional system con-

text. The other one is during design and im-

plementation.

• Use Cases shouldn’t be used as the only di-

agram for Requirements modeling. The em-

ployees think that there are some missing con-

structs that should be complemented by other

diagrams.

• For large, complex systems, it may be difﬁ-

cult to know to which level of detail Use Cases

should be modeled.

• Use Cases are often misused, with too much

detail added, incorrectly transforming the dia-

grams into ﬂowcharts or making them difﬁcult

to comprehend.

4. The employees recognize that there are some con-

structions/diagrams missing in UML, and that

they can’t model everything they need with the

language. Examples cited were:

• Difﬁculty of representing continuous pro-

cesses.

• Verifying important system properties, such as

absence of deadlock in models of distributed

systems, is not possible with UML diagrams.

• Representing synchronous and asynchronous

messages is not satisfactory, even with Se-

quence diagrams. Only changing the shape of

an arrow can be confusing, and this is only a

representation in a language that cannot be for-

mally checked.

EVALUATION OF UML IN PRACTICE - Experiences in a Traffic Management Systems Company

315

• Another problem with Sequence diagrams ar-

rows is that they have been changed from previ-

ous versions to UML 2.0. This can be confus-

ing because legacy systems were documented

using older versions.

• Some employees agree with the fact that UML

is not capable of representing time accurately.

The main problem is that with UML, represent-

ing important time constraints, such as initial

time and intervals of operations, is very difﬁ-

cult or even impossible.

5. Although problems and missing constructionsthat

would allow more modeling power were recog-

nized by the employees, they think that UML

should not be adapted by creating a particular pro-

ﬁle for modeling speciﬁc road trafﬁc management

systems, or they are neutral on this point. UML is

already a complex language, and adding new spe-

ciﬁc constructs for trafﬁc may not be so beneﬁc.

6. Even considering the recognized problems with

UML, the employees wouldn’t like to radically

change the current situation even if that would re-

sult in a gain in productivityand/or quality. This is

an important issue when trying to improve current

processes or including new languages/methods,

because this would involve high costs with train-

ing and adapting legacy systems with new docu-

mentation.

7. It was argued that a serious problem with

new standard languages/processes/tools/methods

in Software Engineering in general is their high

rate of change. Whether a new technology will

still exist in the near future is hard to predict.

That is one important reason why industry prefers

to use proven concepts/technologies that may not

be the most advanced, but that have already been

used and tested in practice.

For each item, at least one recommendation is pro-

posed in the next section.

5 RECOMMENDATIONS

5.1 Action Planning

Based on the items in the diagnosis section, using

only UML for all the ﬁve views of the 4+1 model

of architecture was recognized as insufﬁcient. It was

recommended that other languages/methods should

be used, combined with UML, to model speciﬁc con-

structions that are difﬁcult with UML only. We inves-

tigated possible languages/methods or approaches in

the literature that already tries to solve UML prob-

lems. The following recommendations were pre-

sented to the company.

5.2 Action Taking

1. Use UML proﬁles, such as MARTE (OMG,

2008b) and SysML (OMG, 2008a), which are

conformant to the same metametamodel – MOF

(OMG, 2006), and wouldn’t radically change the

modeling language used in their developmentpro-

cess. SysML is a proﬁle for systems engineering

and MARTE for real-time and embedded systems.

2. Include SysML Use Case diagrams to represent

not only software, but also systems functionali-

ties. Although having the same syntax, the se-

mantics of UML Use Case models and SysML

Use Case models are different. Within UML, nor-

mally one Use Case is speciﬁed by one or more

Sequence diagrams, which represent object com-

munication through time. Within SysML, Use

Cases normally model higher levels of abstrac-

tion, modeling communication between all types

of elements in a system, such as hardware, soft-

ware and people. Thus, a SysML Use Case, relat-

ing to the system’s view in general, may be reﬁned

into several UML Use Cases, relating only to the

software view.

3. UML Use Cases are useful to model functional re-

quirements, but are not able to model other types

of requirements. SysML Requirements diagrams

can model other types of requirements, including

external and the many types of non-functional re-

quirements. Tracing between requirements is also

enhanced. Requirements can be related to each

other in many different ways (Robinson et al.,

2003), which can be modeled with SysML Re-

quirements diagrams and tables. Requirements

can be modeled in a tree structure, which is also

useful to decompose large systems already in the

early development phases. Whenever a require-

ment is changed or deleted, all related require-

ments are known, as well as the nature of each

relationship, providing the important tracing ac-

tivity to the designers. The other tracing mecha-

nism is to use the “trace” relationship to cross-cut

systems requirements through the whole system

development, tracing requirements and more spe-

ciﬁc/detailed models.

4. Use Activity diagrams to model ﬂow of events.

Initially one high-level Activity diagram is used to

model the general ﬂow. This diagram can later be

reﬁned into more detailed speciﬁcations. At the

ICEIS 2009 - International Conference on Enterprise Information Systems

316

lowest level, Activity diagrams are used to model

complete algorithms to be implemented.

5. Avoid modeling too complicated Use Cases, try-

ing to model them at different levels of detail in-

stead of modeling all functionalities at once in

the same diagram. One Use Case can be reﬁned,

and another Use Case diagram created based on a

higher level one.

6. Apply Petri nets (Murata, 1989) for detailed spec-

iﬁcation of the process view. The resulting mod-

els can be simulated and formally veriﬁed using

a variety of computer-based tools. This is useful

not only to model the behavior of a process, but

also to formally verify this behavior. In addition,

Sequence and Activity diagrams can be translated

into Petri nets, as shown by (L´opez-Grao et al.,

2004), (Eichner et al., 2005) and (Soares and

Vrancken, 2008a), offering better semantics and

executable models.

7. Create small additions to UML and SysML in-

stead of creating huge speciﬁc proﬁles for the traf-

ﬁc domain.

All these recommendations have as ﬁnal result the in-

troduction of Petri nets and SysML into the 4+1 views

of software architecture, avoiding using only UML

for all views when designing software-intensive sys-

tems, by including a systems language and a formal

method.

6 EVALUATION AND FUTURE

WORK

Evaluation was done by applying some of the recom-

mendations in a project in the company. On purpose,

the chosen case study is a small project. The idea

was to produce current company’s documents using

the new diagrams and methods suggested in order to

demonstrate how and where they ﬁt better and how to

use them. The development environment was exactly

the same used by other developers in other applica-

tions, depicted in ﬁgure 1. As a matter of fact, the

idea is to demonstrate that the introduced modiﬁca-

tions are compatible with the current implementation

architecture.

The implementation view is based on a layered

software architecture, which provides improved mod-

ularity and abstraction. One important layer of this ar-

chitecture is the publish-subscribe middleware (Fiege

et al., 2006), on top of the basic software layer.

Publish-subscribe middleware provides higher levels

of abstraction, hiding the complexity of dealing with

BasicSoftware

(Database,Network,OperatingSystem)

Publish-subscribeMiddleware

Presentation

GenericComponents

FunctionalComponents

HardwareInfrastructure

Figure 1: Layered implementation software architecture

a variety of platforms, networks and low-level process

communication. Application developers may concen-

trate only on the current requirements of the software

to be developed, and use lower-level services pro-

vided by the middleware when necessary. In addition,

developers may use a list of existing components and

combine them as much as necessary. The Graphical

User Interface layer is used mainly only to present the

application results.

After the design and implementation, the com-

pany’s project managers gave comments on the re-

sults. According to them, it was clear that SysML

Requirements diagrams are more suitable to repre-

sent all kinds of requirements than Use Cases, and

can represent requirements in a nice structured man-

ner that helps not only during development but also in

system maintenance. In particular, the possibility of

tracing requirements through the development phases

was considered extremely useful. In addition, as the

semantics of SysML Use Cases is considered broader

than that of the UML Use Cases, improved system

overview is achieved, and the detailed speciﬁcation

of software activities is considered separate from sys-

tems’ activities.

Besides the introduction of SysML, the UML di-

agrams normally used at the company (Sequence,

Class and Use Case diagrams) are still considered

useful and will keep being used. In addition, Activ-

ity diagrams will be included to the company’s de-

velopment process in two tasks: i) for the high-level

speciﬁcation of processes, ii) which are later reﬁned

into more detailed speciﬁcations to be implemented.

Another interesting comment was related to the com-

pany’s model of software architecture. The possibility

of including a new language in the 4+1 view model of

software architecture, instead of changing the model

of architecture already in use by the company for the

past ten years, was highly appreciated.

Action Research is an iterative process for chang-

EVALUATION OF UML IN PRACTICE - Experiences in a Traffic Management Systems Company

317

ing and further evaluation is necessary. The second

evaluation step is to apply the recommendations to a

series of projects and compare the results with previ-

ous projects. After experimenting the recommenda-

tions in larger projects, another survey will be per-

formed with the same employees to assess the ad-

vantages perceived by them. In addition, although

Petri nets were used for process modeling in the case

study, their introduction as a regular method was

shown to have more resistance from the company. Fi-

nally, SysML allocation tables will be used in larger

projects to represent the many relationships that map

one model element to another, as for instance, an Ac-

tivity to a Block.

7 DISCUSSION

Software process improvement has been shown to de-

liver software products with reduced cost and higher

quality. There are many proposed models to im-

prove software processes, such as ISO/IEC 15504,

PSP, CMM and CMMI. Normally they are based on

changing the way software is developed, for instance,

by introducing new methods, additional documenta-

tion, and measuring, in terms of costs, defects and de-

velopment time, the deliverables of phases and activ-

ities. Nevertheless, there are many reasons why these

software process improvement initiatives fail (Hard-

grave and Armstrong, 2005). Perhaps the most com-

mon one occurs when large changes that are not com-

patible with the company or not possible to be imple-

mented, at least at that moment, are proposed. As a

result, there will be no support from managers or even

from team members. Large changes are not welcome

in industry for many reasons: high costs and risks in-

volved, the need for additional training and the exis-

tence of legacy systems created using previous tech-

nologies. An approach with few changes, maintaining

compatibility with the current situation, is more likely

to succeed.

In general, using SysML is helpful to bring Sys-

tems and Software Engineering together. The lan-

guage is a UML proﬁle. SysML has been adopted

by several different companies, and many vendors are

already selling software tools, even with a variety of

degrees of integration with UML. As a result, soft-

ware engineers and systems engineers can communi-

cate through the use of similar languages.

Although SysML and UML share the same name

and even syntax for some diagrams, they are not se-

mantically the same. For example, SysML Blocks can

be mapped to UML Classes. SysML Blocks are used

to model general elements in a software-intensivesys-

tem, such as all types of hardware (sensors, actuators)

and their operations, constraints, values and parts.

When the hardware is included as a software object in

the system, then it can be modeled as a UML Class.

There is still resistance to apply formal methods

in general in industry, and Petri nets are no excep-

tion. These methods normally require highly-skilled

personnel, which normally increases costs and time.

Nevertheless, some research studies were published

arguing that there are so many advantages that it is

worth trying (Davis, 2005), (Bowen and Hinchey,

2005). In particular, an advantage of Petri nets is

the wise combination of mathematical deﬁnitions and

graphical representation, which may diminish opposi-

tion to its application in practice. Therefore, Petri nets

provide many advantages, such as formally verifying

models using many differenttechniques, improvedse-

mantics and computer-based tools that may be used to

draw and execute models.

8 CONCLUSIONS

This article presented the research performed in order

to improve Software Engineering processes in prac-

tice in a company that develops software-intensive

systems. The main idea was to try to improve cur-

rent processes without drastically changing them.

The company uses UML as the visual modeling

language. Although recognized as a language with

many drawbacks, UML is generally accepted as use-

ful for many domains and companies. The drawbacks

and problems were identiﬁed in practice, and solu-

tions were proposed and implemented in one case

study. Improvements were considered feasible, as

they are not proposing to radically change the cur-

rent situation, which would involve higher costs and

risks. Speciﬁc measures, such as the difference in

terms of project time and product quality are difﬁcult

to give. The improvements are based on the possi-

bility of discovering errors during requirements and

design phases, the execution of scenarios by Petri net

simulation, and the improved requirements represen-

tation and tracing, through requirements modeling us-

ing SysML.

Future research will address the advantages of in-

troducing SysML and Petri nets in the company by

comparing with the former approach. In addition, cre-

ating a speciﬁc SysML proﬁle for the company is in

study.

ICEIS 2009 - International Conference on Enterprise Information Systems

318

REFERENCES

Agarwal, R. and Sinha, A. P. (2003). Object-oriented Mod-

eling with UML: a Study of Developers’ Perceptions.

Communications of the ACM, 46(9):248–256.

Anda, B., Hansen, K., Gullesen, I., and Thorsen, H. K.

(2006). Experiences from Introducing UML-based

Development in a Large Safety-Critical Project. Em-

pirical Software Engineering., 11(4):555–581.

Andr´e, C., Mallet, F., and de Simone, R. (2007). Mod-

eling Time(s). In ACM-IEEE, editor, 10th Interna-

tional Conference on Model Driven Engineering Lan-

guages and Systems (MODELS ’07), pages 559–573,

Nashville, TN, USA. Springer Verlag.

Avison, D. E., Lau, F., Myers, M. D., and Nielsen, P. A.

(1999). Action research. Communinations of the

ACM, 42(1):94–97.

Bannerman, P. L. (2008). Capturing business beneﬁts from

process improvement: four fallacies and what to do

about them. In BiPi ’08: Proceedings of the 1st inter-

national workshop on Business impact of process im-

provements, pages 1–8, New York, NY, USA. ACM.

Beneken, G., Hammerschall, U., Broy, M., Cengarle, M. V.,

J¨urjens, J., Rumpe, B., and Schoenmakers, M. (2003).

Componentware - State of the Art 2003. In Proceed-

ings of the CUE Workshop Venedig.

Blankenhorn, K. and Jeckle, M. (2004). A UML Proﬁle for

GUI Layout. In Weske, M. and Liggesmeyer, P., ed-

itors, Net.ObjectDays, volume 3263 of Lecture Notes

in Computer Science, pages 110–121. Springer.

Booch, G., Rumbaugh, J., and Jacobson, I. (2005). Uni-

ﬁed Modeling Language User Guide, The (2nd Edi-

tion) (The Addison-Wesley Object Technology Series).

Addison-Wesley Professional.

Bowen, J. P. and Hinchey, M. G. (2005). Ten command-

ments revisited: a ten-year perspective on the indus-

trial application of formal methods. In FMICS ’05:

Proceedings of the 10th international workshop on

Formal methods for industrial critical systems, pages

8–16, New York, NY, USA. ACM.

Collins, W. D., Rasch, P. J., Eaton, B. E., Fillmore, D. W.,

Kiehl, J. T., Beck, C. T., and Zender, C. S. (1996).

Message Sequence Charts (MSC. In ITU-TS Recom-

mendation Z.120, page 2002.

Davis, J. F. (2005). The affordable application of for-

mal methods to software engineering. Ada Lett.,

XXV(4):57–62.

Dobing, B. and Parsons, J. (2006). How UML is used. Com-

munications of the ACM, 49(5):109–113.

Eichner, C., Fleischhack, H., Meyer, R., Schrimpf, U., and

Stehno, C. (2005). Compositional Semantics for UML

2.0 Sequence Diagrams Using Petri Nets. In SDL Fo-

rum, pages 133–148.

Fiege, L., Cilia, M., Muhl, G., and Buchmann, A. (2006).

Publish-Subscribe Grows Up: Support for Manage-

ment, Visibility Control, and Heterogeneity. IEEE In-

ternet Computing, 10(1):48–55.

Hardgrave, B. C. and Armstrong, D. J. (2005). Software

process improvement: it’s a journey, not a destination.

Communications of the ACM, 48(11):93–96.

Harel, D. (1987). Statecharts: A Visual Formalism for

Complex Systems. Science of Computer Program-

ming, 8(3):231–274.

Henderson-Sellers, B. (2005). UML - the Good, the Bad

or the Ugly? Perspectives from a panel of experts.

Software and System Modeling, 4(1):4–13.

Herbsleb, J. D. and Goldenson, D. R. (1996). A system-

atic survey of CMM experience and results. In ICSE

’96: Proceedings of the 18th International Conference

on Software Engineering, pages 323–330, Washing-

ton, DC, USA. IEEE Computer Society.

Jacobson, I. (2004). Use cases - Yesterday, today, and to-

morrow. Software and System Modeling., 3(3):210–

220.

Kruchten, P. (1995). Architectural Blueprints—The “4+1”

View Model of Software Architecture. IEEE Software,

12(6):42–50.

L´opez-Grao, J. P., Merseguer, J., and Campos, J. (2004).

From UML Activity diagrams to Stochastic Petri nets:

application to software performance engineering. In

WOSP ’04: Proceedings of the 4th international

workshop on Software and performance, pages 25–36,

New York, NY, USA. ACM.

Murata, T. (1989). Petri nets: Properties, analysis and ap-

plications. Proceedings of the IEEE, 77(4):541–580.

OMG (2006). Meta-Object Facility (MOF) Core Speciﬁca-

tion Version 2.0.

OMG (2007). Uniﬁed Modeling Language (UML), Super-

structure version 2.1.1.

OMG (2008a). Systems Modeling Language (SysML) Ver-

sion 1.1.

OMG (2008b). UML Proﬁle for MARTE, Beta 2.

Rainer, A. and Hall, T. (2003). A quantitative and quali-

tative analysis of factors affecting software processes.

Journal of Systems and Software, 66(1):7–21.

Robinson, W. N., Pawlowski, S. D., and Volkov, V. (2003).

Requirements Interaction Management. ACM Com-

puting Surveys, 35(2):132–190.

Simons, A. J. H. (1999). Use Cases Considered Harmful. In

In 29th Conference on Technology of Object-Oriented

Languages and Systems, pages 194–203. IEEE Com-

puter Society.

Soares, M. S., Julia, S., and Vrancken, J. (2008). Real-

time Scheduling of Batch Systems using Petri Nets

and Linear Logic. Journal of Systems and Software,

81(11):1983–1996.

Soares, M. S. and Vrancken, J. (2008a). A Metamodeling

Approach to Transform UML 2.0 Sequence Diagrams

to Petri Nets, volume 1, pages 159–164. ACTA Press.

Soares, M. S. and Vrancken, J. (2008b). Model-Driven User

Requirements Speciﬁcation using SysML. Journal of

Software, 3(6):57–68.

EVALUATION OF UML IN PRACTICE - Experiences in a Traffic Management Systems Company

319
