STATISTICAL DECISIONS IN PRESENCE OF IMPRECISELY
REPORTED ATTRIBUTE DATA
Olgierd Hryniewicz
Systems Research Institute, Polish Academy of Sciences, Newelska 6, Warsaw, Poland
Keywords: Statistical decisions, Attribute data, Imprecise data, Fuzzy approach, Possibility distribution.
Abstract: The paper presents a new methodology for making statistical decisions when data is reported in an
imprecise way. Such situations happen very frequently when quality features are evaluated by humans. We
have demonstrated that traditional models based either on the multinomial distribution or on predefined
linguistic variables may be insufficient for making correct decisions. Our model, which uses the concept of
the possibility distribution, allows to separate stochastic randomness from fuzzy imprecision, and provides a
decision – maker with more information about the phenomenon of interest.
1 INTRODUCTION
When we make decisions on the basis of statistical
analysis of data, we call such decisions – statistical
decisions. An important class of statistical decisions
is based on attribute data. In the simplest case,
attribute data are presented in a form of a random
sample consisting of elements having only two
values: zero and one. All cases described by zeroes
are usually called “failures”, and the remaining
statistical observations are called “successes”.
Statistical decisions based on attribute data are
well known in many fields of application. They were
introduced more than eighty years ago in statistical
quality control, and since that time they have been
widely used in industry, business and administration.
However, in information technology these methods
are, as for know, not very popular. Take, for
example, typical decision problems of Artificial
Intelligence or Pattern Recognition. Quality of
proposed algorithms is evaluated on widely accepted
benchmarks without taking into account the
randomness of their outputs which results from the
randomness of input data. In this paper we present
an attempt to deal with this problem in cases which
seem to be typical in such applications like e.g.
linguistic summarizations of text data or automatic
classification of documents.
The theory of statistical decisions for the
attribute data (i.e. 0 – 1) is well known for more than
eighty years. It has been developed mainly for
applications in statistical quality control or other
industrial applications. In all such cases each
element of the analysed sample is precisely
evaluated as either “success” (1) or “failure” (0).
However, in many areas of application such precise
evaluations are hardly possible. Consider, for
example, an automatic selection of text documents,
where users evaluate the appropriateness of the
selection. The proportion of documents which have
been wrongly classified may serve as a measure of
the effectiveness of this algorithm. In many cases
however, it is difficult to present unequivocal
evaluations. The users may prefer to have a
possibility to give also answers like “May be Yes”,
“I am Undecided” or “May be Not”, and not only
either “Yes” or “No”. To give another example from
the area of information technology, let us consider
the evaluation of a new algorithm for the
compression of graphics. The perceived quality of
this new method can be evaluated by a group of
experts who are asked about the acceptability of
compressed pictures.
The practical necessity to work with such
imprecisely reported data prompted some authors to
develop appropriate statistical tools that could be
useful in decision making. The simplest approach is
based on the multinomial model for imprecisely
reported attribute data. We present this model in the
second section of the paper. Another possibility, the
application of fuzzy linguistic variables is analysed
in the third section. In the fourth section we present
a new approach based on the possibility theory
introduced by Zadeh. We present a possibilistic
309
Hryniewicz O. (2009).
STATISTICAL DECISIONS IN PRESENCE OF IMPRECISELY REPORTED ATTRIBUTE DATA.
In Proceedings of the 11th International Conference on Enterprise Information Systems - Artificial Intelligence and Decision Support Systems, pages
309-312
DOI: 10.5220/0001863003090312
Copyright
c
SciTePress
generalization of the multinomial model. In Monte
Carlo simulation experiments which are not
described in this short paper we have shown that this
approach provides more information for decision
makers in comparison to the aforementioned
methods.
2 MULTINOMIAL MODEL FOR
IMPRECISE ATTRIBUTE DATA
Suppose that a random variable, representing
statistical data of interest, may have k distinct
values. These values can be represented by natural
numbers, but can be also represented by either
ordered or unordered labels. The probabilities of
observing those values are denoted by
()
k
p,,p
1
,
where
=
=
k
i
i
p
1
1. If we observe a random sample
of n realization of this random variable, the
probability distribution that describes the numbers of
occurrences of all possible values
()
k
X,,X
1
of
this random variable is called the multinomial
distribution, and is defined by the following function
()
.xpp
xx
n
xX,,xXP
k
i
i
x
k
x
k
kk
k
=
=
===
1
1
1
11
1
!!
!
1
(1)
This distribution may be used for the
construction of decision-making procedures when
observed values may be assigned to k different
categories. For example, in statistical quality control
we may observe different types of failures. If for
each considered type of failure we fix a critical
number of nonconforming items in the sample, we
can use (1) for the calculation of the probability of
the acceptance of the sampled population for all
possible values of the probabilities
()
k
p,,p
1
.
Let us now consider the situation when observed
attribute data are imprecisely described by linguistic
labels. Without loosing generality, we may assume
that these data are described by the following set of
labels: “Yes” (Y) “May be Yes” (MY), “I am
Undecided” (U), “May be Not” (MN), and “Not”
(N). Let denote by
()
NMYY
p,p,p the vector of
the corresponding probabilities of observations.
Then, we can use (1) for the calculation of all
interesting probabilities. We should note, however,
that in the considered case the decision – making
procedure should be different than in the
aforementioned case of statistical quality control.
We are usually interested in the unknown proportion
of actual (A) successes. Let us assume that we may
make only two decisions: “Accept” (if the actual
proportion of “successes” is small) or “Reject” (if
otherwise). The decision is based on the number of
“successes” in the sample. If this number is not
greater than a certain critical number c our decision
is to “Accept”. Otherwise, the decision is to
“Reject”. The decision criterion c is determined
from the analysis of the probability of “Acceptance”
calculated from the appropriate binomial
distribution.
In the considered case of imprecisely reported
observations actual “successes” may be hidden
under four possible labels, i.e Y, MY, U, and even
MN. Therefore, we may think about four possible
critical numbers: c
Y
, for observations, which occur
with probability p
(Y)
=p
Y
, c
MY
, which occur with
probability p
(MY)
=p
Y
+p
MY
, c
U
, which occur with
probability p
(U)
=p
Y
+p
MY
+p
U
, and c
MN
, which occur
with probability p
(MN)
=p
Y
+p
MY
+p
U
+p
MN
. In order to
set all these critical values we have to know all
acceptable values for all these probabilities.
However, in practice we know these values only for
the actual probability of a “success”. Therefore, it is
natural to use only one critical value c for all these
possible outcomes of the test. If we do so, it is easy
to show that the probabilities of “Acceptance” will
be quite different, depending on the values of the
probabilities
(
)
NMYY
p,p,p . However, usually
we do not know these probabilities, so we don’t
know the actual characteristics of our decision
procedure. Therefore, the multinomial model, if it
has to be used for the modelling of imprecise
attribute data, requires additional knowledge about
the probabilities of different answers.
3 FUZZY LINGUISTIC
VARIABLES AS MODELS OF
IMPRECISE ATTRIBUTE DATA
Imprecise values of attribute data can bee looked
upon as linguistic data described by fuzzy linguistic
variables as it was proposed by Zadeh. For
modelling quality data his approach was adopted in
(Wang and Raz, 1990) who proposed to describe
imprecise answers by predefined fuzzy subsets of
the interval [0,1]. In their original paper they
proposed to use fuzzy triangular number defined on
overlapping subsets of [0,1]. For making decisions
Raz and Wang proposed to use some real-valued
representations of fuzzy numbers, such as: modal
ICEIS 2009 - International Conference on Enterprise Information Systems
310
value, midpoint of the 50%
α
-cut, average, and
centroid. It is easy to show that for the first three of
the abovementioned representations it does not
matter if we calculate representative values for
individual observation and then sum them up or if
we calculate a fuzzy sum, and then its representative
value. In the fourth case this important property
holds only either for triangular fuzzy numbers or for
rectangular fuzzy numbers (i.e. for intervals).
In order to make decision about “Acceptance”
(or “Rejection”) we have to compare the
representative value of the sum of observed
linguistic variables with a certain critical value.
Unfortunately, this critical value cannot be easily
calculated for a simple reason that the representative
values of the fuzzy sum of fuzzy observations may
be quite different from the expected number of
evaluated “successes”. Especially when the fraction
of imprecise observations is significant the observed
representative values may be quite different than the
expected numbers of “successes” in the sample.
Another problem with determination of a correct
critical value for representative values of fuzzy
observations is related to their strong dependence on
the assumed representations of imprecise linguistic
concepts. All these problems and difficulties make
decision – making which is based on this fuzzy
approach rather questionable.
It is also worth noticing that in all cases when
calculation of representative values can be
performed on individual fuzzy observations the
whole procedure boils down to ordinary weighting
of observations. This concept is also known as the
calculation of “demerits”, and has been successfully
implemented in statistical process control (SPC).
However, in SPC it is assumed that available
information let us compute probabilistic
characteristics of the considered statistic.
Unfortunately, this is usually not the case for the
problem considered in this paper. Recently, in
(Gülbay and Kahraman, 2007) another fuzzy
approach has been proposed for the analysis of
linguistic quality data. However, this approach in the
context of decision-making has exactly the same
limitations as that of Wang and Raz.
4 POSSIBILITIC MODEL OF
IMPRECISE ATTRIBUTE DATA
In the previous two sections we have demonstrated
that in case of imprecisely reported attribute data the
information provided in terms of simple linguistic
labels may be not sufficient for correct decision –
making if this correctness should depend upon the
fraction of “successes” in a considered population.
In (Hryniewicz, 2008) an extension of the
considered model has been proposed by allowing
additional information about imprecise observations.
Our extension is based on a fact that each
observation may be treated as a “success”, but to a
certain degree, and vice versa, as a “failure”, but
also to a certain degree. Thus, the result of each
observation can be described by a fuzzy set
{}
11010
101010
=
+
μ
μ
μ
μ
μ
μ
,max,,,||
,
(2)
defined on the set {0,1}. This fuzzy representation
may be also interpreted as a possibility distribution
over the set of two crisp outcomes of an observation:
“success” (one) and “failure” (zero). When the result
of an observation is described linguistically in such a
way that it can be regarded as a “failure”, the result
of observation is expressed as a fuzzy set with the
membership function
101
1
||
μ
+ . Full (i.e.
undoubted) “failures”, which in our setting are
represented by labels “No”, are now described by
crisp sets. In this case the membership function is
given by
1001 ||
+
. When 10
1
<<
μ
the
corresponding label is “May be No”, and
μ
1
in this
case describes the degree to which this label is
incompatible with an unequivocal label “No”. On
the other hand, if the result of an observation is
described linguistically in such a way that it can be
regarded as a “success”, the result of observation is
expressed as a fuzzy set with the membership
function
110
0
||
+
μ
. Full (i.e. undoubted)
“successes”, which in our setting are represented by
a labels “Yes”, are described by crisp sets with the
membership function
1100 || + . When 10
0
<
<
μ
the corresponding label is “May be Yes”, and
μ
0
in
this case describes the degree to which this label is
incompatible with an unequivocal label “Yes”.
When
1
10
=
=
μ
μ
, we have the situation which we
describe by a label “Undecided”, as in this case there
is the same possibility either of “successes” and
“failures”.
Assume now, that in the sample of n items n
1
cases are characterized by fuzzy sets described by
the membership function
10
1110 n,,i,||
i,
=
+
μ
,
(3)
and in the remaining
12
nnn
=
cases by fuzzy sets
described by the membership function
21
1101 n,,i,||
i,
=
+
μ
.
(4)
STATISTICAL DECISIONS IN PRESENCE OF IMPRECISELY REPORTED ATTRIBUTE DATA
311
Without loss of generality we can assume that
10
1
010
n,,
μμ
,
(5)
and
01
2
111
n,,
μμ
.
(6)
Hence, the fuzzy total number of “successes” in this
sample, calculated using Zadeh’s
extension
principle, is given by:
() ( )
.
nn|n|
n|||x
~
n,,
,,
211111
12010
2
1
110
+++++
++++=
μμ
μ
μ
(7)
This number has to be compared with a critical
number of “successes” c in order to make a decision
of “Acceptance” or of “Rejection”.
Comparison of fuzzy numbers cannot be done
unequivocally, as they are not completely ordered.
One of the widely accepted methods of comparison
is based on the concepts of possibility and necessity
of dominance introduced in (Dubois and Prade,
1983). Let
()
x
μ
be the membership function of the
fuzzy set
X
~
, and
()
y
be the membership function
of the fuzzy set
Y
~
. When the evidence that
X
~
is
strictly greater than
Y
~
is rather strong we can
express this feature using the Necessity of Strict
Dominance (NSD) index, defined as follows:
(
)
()
(
)()
[]
y,xminsupY
~
X
~
NSD
yx:y,x
νμ
= 1
.
(8)
When this evidence is weak, we can use the
Possibility of Strict Dominance (PSD) index which
is related to the NSD using the following formula.
(
)
(
)
X
~
Y
~
PSDY
~
X
~
NSD = 1 .
(9)
The interpretation of these indices reflects
common understanding of the words “possible” and
“necessary”. Relations which are only partially
possible (PSD < 1) are not necessary (NSD = 0). On
the other hand, relations which are even partially
necessary (NSD > 0) are always fully possible (PSD
=1).
It is easily seen that when the number of
“successes” with the maximal value of the
membership function (equal to one) is situated to the
left of c we can say about a certain necessity that the
relation x<c has been fulfilled. This necessity is
equal to one only in case when the whole support of
x
~
(i.e. values of x with positive membership) is
located to the left of
c. When the number of
“successes” with the maximal value of the
membership function (equal to one) is situated to the
right of
c we can only say about a certain possibility
that the relation
x<c has been fulfilled. This
possibility is equal to zero only in case when the
whole support of
x
~
is located to the right of c.
This interpretation of possibility and necessity
indices let us formulate simple rules for decision –
making. We have to fix the critical value
c and the
required value of the necessity/ possibility of
cx
~
.
Thus, we are able to define a non-fuzzy decision
rule.
5 CONCLUSIONS
In the paper we have proposed a new approach to
the analysis and decision – making when
information is presented in a form of imprecisely
reported attribute data. We have demonstrated on
examples that traditional and popular approaches
provide only restricted information which might be
insufficient for correct decision making. The new
approach is definitely more flexible. Moreover, it
can be straightforwardly extended to the case when
the definitions of “success” and “failure” may be
imprecise. This imprecision may lead to imprecise
(fuzzy) decision criteria.
REFERENCES
Dubois, D., Prade, H., 1983. Ranking Fuzzy Numbers in
the Setting of Possibility Theory. Information Science,
vol.30, 183-224.
Gülbay, M., Kahraman, C., 2007. An alternative approach
to fuzzy control charts: Direct fuzzy approach.
Information Sciences, vol.177, 1463-1480.
Hryniewicz, O., 2008. Statistics with fuzzy data in
statistical quality control. Soft Computing, vol.12, 229-
234.
Wang, J.H., Raz, T., 1990. On the Construction of Control
Charts Using Linguistic Variables. International
Journal of Production Research, vol.28, 477-487.
ICEIS 2009 - International Conference on Enterprise Information Systems
312
