A PROJECTION-BASED HYBRID SEQUENTIAL PATTERNS

MINING ALGORITHM

Chichang Jou

Department of Information Mangement, Tamkang University, 151 Ying-Chuan Road, Tamsui, Taipei, Taiwan

Keywords: Hybrid sequential pattern, Pattern growth, Projected position array, Projected support array, Projected

database.

Abstract: Sequential pattern mining finds frequently occurring patterns of item sequences from serial orders of items

in the transaction database. The set of frequent hybrid sequential patterns obtained by previous researches

either is incomplete or does not scale with growing database sizes. We design and implement a Projection-

based Hybrid Sequential PAttern Mining algorithm, PHSPAM, to remedy these problems. PHSPAM first

builds Supplemented Frequent One Sequence itemset to collect items that may appear in frequent hybrid

sequential patterns. The mining procedure is then performed recursively in the pattern growth manner to

calculate the support of patterns through projected position arrays, projected support arrays, and projected

databases. We compare the results and performances of PHSPAM with those of other hybrid sequential

pattern mining algorithms, GFP2 and CHSPAM.

1 INTRODUCTION

Data mining aims to extract implicit information

inside voluminous electronic data, and has become

more and more important for science, engineering,

business, etc. Frequent sequential pattern mining

obtains item sequence patterns satisfying the

condition that the number of their occurrences in the

database, called support, is greater than or equal to a

given minimum threshold. It has been applied to

applications like stock trend, genome sequencing,

web page traversal, customer behavior analysis, etc.

Based on requirement of items’ adjacency in a

pattern, sequential patterns could be classified into

three categories (Chen et al., 2002): (1) Continuous

patterns, where the adjacent items in a pattern must

be matched by consecutive items in the transactions.

(2) Discontinuous patterns, where adjacent items in

a pattern are matched by items separated by zero or

more items. (3) Hybrid patterns, where discontinuity

is represented by a special symbol ‘*’ so that

continuous and discontinuous adjacency

requirements could be specified together. For

example, for a transaction T to match the hybrid

pattern <AB*C>, its matching items for A and B

must be adjacent, and its matching items for B and C

are not necessarily consecutive.

As far as we know, the most efficient hybrid

sequential pattern mining algorithm is GFP2 (Chen

et al., 2002). Its basic concept is the Apriori

principle--candidate frequent patterns of length n

could be generated by joining frequent patterns of

length n-1. However, with repetitive items in a

transaction, some frequent patterns might be missed

by this technique. For example, suppose the database

has only one transaction T=<ABCBD>, and the

minimum threshold is 2. The only frequent pattern

of length 1 is . By joining frequent patterns of

length 1, the candidate frequent patterns of length 2

are <B*B> and <BB>. Supports for patterns

<A*B> and <B*D> are 2, but they are not

obtainable by filtering <B*B> and <BB>.

Jou (2006) proposed an algorithm, CHSPAM, to

obtain the complete hybrid sequential patterns.

However, CHSPAM’s performance is no better than

GFP2. We utilize the pattern growth methodology

and propose Projection-Based Hybrid Sequential

PAttern Mining algorithm, PHSPAM, to tackle this

performance problem.

The rest of the paper is organized as follows:

Section 2 surveys related work. Problem definition

and PHSPAM are illustrated in Section 3.

Experimentations and their results are discussed in

Section 4. Section 5 concludes the paper and points

out future work directions.

152

Jou C. (2009).

A PROJECTION-BASED HYBRID SEQUENTIAL PATTERNS MINING ALGORITHM.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Artiﬁcial Intelligence and Decision Support Systems, pages

152-157

DOI: 10.5220/0001986001520157

 SciTePress

2 RELATED WORK

Agrawal and Srikant (1995) extended the frequent

itemset mining algorithm (Agrawal and Srikant,

1994; Agrawal et al., 1993) for non-serial

transactions to discontinuous sequential pattern

mining for serial transactions using the Apriori

principle for sequential patterns. Pei et al. (2000)

obtained discontinuous sequential web traversal

patterns by constructing the access pattern tree from

web access logs. Chen et al. (1998) extended the

Apriori principle to obtain frequent continuous

sequential web path traversal patterns.

Based on the approach to attack the sequential

pattern mining problem, its solutions could be

classified into two categories: 1. Candidate pattern

generation and filtering; 2. Pattern growth.

The methods in the candidate pattern generation

and filtering category extend the Apriori principle.

The whole database needs to be scanned in each

candidate pattern generation step. For large

databases, this approach needs huge memory space

to store the candidate patterns. GSP (Agrawal and

Srikant, 1996), GFP2 (Chen et al., 2002), and

SPADE (Zaki, 2001) all belong to this category.

GSP added time constraints between adjacent items

in a pattern, relaxed the restriction that elements of a

pattern must be from the same transaction, and

allowed items to cross taxonomy levels. GFP2 was

the first to obtain hybrid sequential patterns. It

utilized the containment relationship of supports

between the patterns with ‘*’ and those without ‘*’

to reduce the number of database scans. SPADE

utilized subset relationship of patterns in calculating

the support of candidate patterns by checking the

positions of each item in the transactions.

In the pattern growth methodology, to skip the

time-consuming candidate patterns generation step,

a candidate pattern is built by concatenating a

pattern p with patterns obtained from its projected

databases, which are collections of after-p sub-

transactions. Supports of patterns with prefix p are

counted by summing supports of patterns supported

by sub-transactions in p’s projected database.

FreeSpan (Han et al., 2000a; Pei et al., 2004) first

utilized the pattern growth concept from FP-Growth

(Han et al., 2000b). PrefixSpan (Pei et al., 2001; Pei

et al., 2004) used bi-level projection to reduce the

number of projected databases. It also recorded the

transaction id and the position of sequential patterns,

instead of the real data, to reduce the memory

requirement. Jou (2006) discovered that some

frequent patterns could not be obtained by the

Apriori principle. He proposed the first complete

hybrid sequential pattern mining algorithm,

CHSPAM. Its mining procedure is performed

recursively in the pattern-growth manner by the

backward support counting method.

3 THE PHSPAM ALGORITHM

Our definition of hybrid sequential pattern follows

that of GFP2 (Chen et al., 2002): Let I = {i

, i

, …, i

}

denotes the set of items in a database. A transaction

T=<t

… t

> is an item sequence, where for all i

between 1 and k, t

∈

I. A database consists of a set

of transactions. A special symbol ‘*’ not in I is used

in the pattern specification to denote the occurrence

of 0 or more items. A sequence <x

… x

> is

called a hybrid sequential pattern if:

(1) x

∈

∪

{ * } for all 1 ≤ i ≤ n

(2) x

∈

I and x

∈

I; and

(3) for all 1 < i < n, if x

=’*’ then x

i-1

∈

I and

i+1

∈ I.

Condition (2) requires a pattern to start and end with

an item. Condition (3) exclude consecutive *’s in a

pattern. Hybrid sequential pattern will be

abbreviated as pattern henceforth when no confusion

arises. Thus, <ABC>, <A*BC> and <A*B*C> are

legitimate patterns, while <*AB> and <AB**C> are

not.

A pattern p is said to be contained in a

transaction T, denoted as p

⊂

T, if:

(1) for all items x

∈

p, there is a matching item x

∈

(2) for all items x, y

∈

p, if x precedes y in p, then

x’s matching item in T also precedes y’s; and

(3) for all items x, y

∈

p, if x is adjacent to y in

p, then x’s matching item in T is also

adjacent to y’s.

The above conditions require that a matching

instantiation of p in T must respect the serial order of

items in p.

For each pattern p and transaction T, the number

of different matching instantiations for p

⊂

T is

called the support of p in T, denoted by supp

p,T

. For

example, suppose p=<A*BC> and T=<BACABC>.

Then supp

p,T

= 2, where the first instantiation

matches A, B, C to positions 2, 5, 6 of T, and the

second matches them to positions 4, 5, 6. For a given

minimum support threshold minSupp, we call pattern

p a frequent pattern if p satisfies the condition:

minSuppsupp

≥

∑

∀

From short to long patterns, PHSPAM generates

for each pattern p a projected position array, which

A PROJECTION-BASED HYBRID SEQUENTIAL PATTERNS MINING ALGORITHM

153

keeps for all matching transactions the positions of

the items matching p’s last item. Corresponding to

each position in the position array, their contribution

to the support for p is stored in p’s projected support

array. The mining procedure is recursively applied

to the projected databases by summing supports

from their projected support arrays.

PHSPAM has four steps: Step 1 scans the

database and constructs the Supplemented Frequent

One Sequence itemset, denoted as SFOS, to collect

items that may appear in frequent patterns. Step 2

transforms items not in SFOS into ‘+’ to generate the

reduced database, which helps decrease the number

of comparisons in step 4. Step 3 generates the

projected position arrays, projected support arrays,

and projected databases for each SFOS item. Step 4

performs recursive support counting in the projected

databases, and finally checks whether SFOS items

are frequent patterns. We discuss each step in the

following subsections.

3.1 Generating the SFOS Itemset

The length of a pattern p is defined as the number of

items occurring in p. In hybrid sequential pattern

mining, frequent patterns of length 1 are the same as

the set of items with support greater than or equal to

minSupp. As illustrated in Section 1, items with

support less than minSupp could appear in frequent

patterns of length longer than 1. PHSPAM remedies

the problem by constructing SFOS in the first step as

follows:

(1) All items with their total number of

occurrence greater than or equal to minSupp.

These are the traditional frequent one

sequence items;

(2) All repetitive items, which are items

occurring more than once in a single

transaction; and

(3) All items before and after any pair of

repetitive items in a transaction.

For the example in Section 1, Items A and D are

added into SFOS since A occurs before the first B,

and D after the second B. According to the definition

of SFOS, if an item occurs more than two times in a

transaction, then all items in that transaction will be

added into SFOS.

3.2 Database Reduction

The second step transforms each series of

consecutive non-SFOS items in the original database

DB into a special symbol ‘+’, to obtain DB’, the

reduced database. Since the first and last items of a

pattern are in SFOS, ‘+’s appearing in the prefix or

suffix of a reduced transaction are deleted in this

reduction. For example, suppose the sample

database DB contains the 3 transactions in Table 1,

and minSupp is 4. By scanning DB once, its SFOS

could be constructed as {A, B, D} with supports 4, 5,

3 respectively. Note that the support of item D is less

than minSupp. D’s inclusion in SFOS is because D is

after the repetitive items B in transactions 2 and 3.

By scanning DB once more, the reduced database

DB’ in Table 2 could be constructed.

Table 1: The sample

database.

Table 2: Reduced

sample database.

trans. id serial items trans.id serial items

1 ABCED 1 AB+D

2 BACBAD 2 BA+BAD

3 BCABD 3 B+ABD

3.3 Generating Projected Databases for

Each SFOS Item

For pattern p and transaction T, projected position

array PPA

p,T

contains the positions of T’s item

matching p’s last item, and projected support array

PSA

p,T

contains the supports for p at these positions.

The collections of PPA

p,T

(similarly, PSA

p,T

) over all

transactions T is denoted as PPA

(PSA

). The third

step constructs for each item i in SFOS PPA

, PSA

and the projected database PDB

from DB’ as

follows: if i occurs in transaction T, then push all

pairs of T’s transaction id with i’s positions in T into

PPA

. Additionally, set the support for T as 1 for

each pair in PSA

. The projected database of pattern

, PDB

, is the set of all after-i sub-transactions.

For repetitive items in a transaction, we will have a

sub-transaction for each occurrence of the item.

Table 3: Projected position array, projected support array,

projected database of pattern .

subtr. id trans. id

PPA

PSA

PDB

1 1 2 1 +D

2 2 1 1 A+BAD

3 2 4 1 AD

4 3 1 1 +ABD

5 3 4 1 D

To simplify the explanation, a tabular form of PPA

PSA

, PDB

will be indexed by the same sub-

transaction id. Table 3 illustrates the tabular form of

PPA

, PSA

, and PDB

for the reduced sample

database. These projected data structures for SFOS

items are stored in the hard disk. Since the support

counting procedure uses one projected database for

ICEIS 2009 - International Conference on Enterprise Information Systems

154

an SFOS item at a time, at any time PHSPAM loads

only one set of these projected data structures into

memory.

3.4 Recursive Traverse and Count

Figure 1 demonstrates the fourth step,

TraverseAndCount, for a pattern p. Let I

denote the

set of items in the projected database PDB

. This

step first calls GetSupport(p) to obtain the support

count mapping, M

, which maps, for all items i in I

patterns <p*i> and <pi> to the their supports.

Details of GetSupport will be explained in the next

paragraph. The supports M

(<p*i>) and M

(<pi>)

are compared to minSupp to decide whether <p*i>

and <pi> are frequent patterns. Then, it calls

BuildProjectedArrays(p,i) to build projected position

arrays (PPA

p*i

and PPA

), and projected support

arrays (PSA

p*i

and PSA

). Suppose the first item of p

is x. The projected database PDB

p*i

(similarly, PDB

)

could be obtained on the fly from PDB

and PPA

p*i

(similarly, PDB

and PPA

). TraverseAndCount will

then be recursively applied to <p*i> and <pi>.

Figure 1: Pseudo code of TraverseAndCount.

For a pattern p, Figure 2 shows the construction of

the support count mapping M

in GetSupport(p) by

scanning the sub-transactions in PDB

as follows:

Suppose the index of sub-transaction T

in PDB

is j.

Out of all matching instantiations of in T

’s

original transaction T, PSA

p,T

[j] matching

instantiations satisfy the condition that the last

element of p is in position PPA

p,T

[j]. Thus, for all

items i in T

, T would contribute PSA

p,T

[j] to the

support of <p*i>. That is, each occurrence of item i

in T

would increase M

’s final supports of <p*i> by

PSA

p,T

[j]. Similarly, if an item i in T

satisfies the

condition that the last element of p in the matching

instantiation is adjacent to i, verified by checking

whether the position of i is equal to PPA

p,T

[j]+1,

each occurrence of i would increase the support

count mapping of <pi> by PSA

p,T

[j]. In M

, the

support counts for <p*i> and <pi> are the

accumulated sum of supports of <p*i> and <pi>

over all sub-transactions in PDB

. It is clear that M

maps each pattern to their support count in the

original database.

From projected database PDB

of pattern

in Table 3, I

{A, B, D}. Take item A as an

example. The detailed support counting of the

mapping of <B*A> in M

is demonstrated in Table 4.

Note that the support of <B*A> contributed from

transaction 2 position 5 is 2, where both sub-

transactions 2 and 3 in PDB

contribute one support.

Since sum of supports of <B*A> in PDB

B*A

is 4,

<B*A> is added into the set of frequent patterns.

However, since only 2 of the 4, both from

transaction 2, satisfy the condition that item A is

immediately after B, support of <BA> is 2, and

<BA> is not a frequent pattern. The function

BuildProjectedArrays(,A) then builds projected

position arrays (PPA

B*A

and PPA

), and projected

support arrays (PSA

B*A

and PSA

TraverseAndCount is then recursively performed on

<B*A> and <BA> separately.

For the projected database PDB

B*A

in Table 4,

item D occurs once in sub-transactions 1, 2 and 3.

Figure 2: Pseudo code of GetSupport.

/* PDB

: the Projected Database of pattern */

/* PPA

p,T

: the Projected Position Array for sub-transaction

T in PDB

/* PSA

p,T

: the Projected Support Array for sub-transaction

T in PDB

Function GetSupport(p)

Begin

for each item i

∈

(<p*i>)=0; M

(<pi>)=0

endFor

for each T

∈

PDB

j = index of T in PDB

for each item i

∈

/* do not count ‘+’ as an item */

if i != ‘+’ then

(<p*i>)=M

(<p*i>)+ PSA

p,T

[j]

if (PPA

p,T

[j]+1==position of i

in T) then

(<pi>)=M

(<pi>)+

PSA

p,T

[j]

endFor

return M

/* denotes a pattern */

/* PDB

is the projected database of */

/* FP is the set of frequent patterns */

Procedure TraverseAndCount(p)

Begin

= GetSupport(p)

/* M

maps <p*i> and <pi>, i being one of the

items in PDB

, to their supports */

for each item i

∈ I

if M

(<p*i>)

≥

minSupp then

add <p*i> to FP

endIf

if M

(<pi>)

≥

minSupp then

add <pi> to FP

endIf

BuildProjectedArrays(p, i)

/* build projected position/support arrays, for

patterns <p*i>

and <pi> */

TraverseAndCount(<p*i>)

TraverseAndCount(<pi>)

endFor

End Procedure

A PROJECTION-BASED HYBRID SEQUENTIAL PATTERNS MINING ALGORITHM

155

Table 4: Projected position array, projected support array,

and projected database of pattern <B*A>.

subtr. id trans. id PPA

B*A

PSA

B*A

PDB

B*A

1 2 2 1 +BAD

2 2 5 1+1 D

3 3 3 1 BD

The supports for <B*A*D> contributed by sub-

transaction 1, 2, and 3 are 1, 2, and 1, respectively.

Thus, M

B*A

(<B*A*D>)=4. Since only the case in

sub-transaction 2 satisfies the condition that D is

immediately after A, M

B*A

(<B*AD>)=2. The support

count accumulation details of <B*A*i> and <B*Ai>

for all items i in I

B*A

could be computed in the same

fashion. Thus, the sample database has the following

frequent patterns: <A>, , <A*D>, <B*A>,

<B*D>, and <B*A*D>.

4 EXPERIMENTS

We implement GFP2, CHSPAM and PHSPAM in

VB.NET 2005. The first experiment compares

numbers of obtained frequent patterns and execution

time with respect to database size and average length

of frequent patterns. The second experiment checks

the sensitivity of PHSPAM regarding the minimum

support. The experiments are performed in the

Windows Server operating system, Intel Xeon 3100

Dual-Core CPU, and 1024MB DDR memory. The

databases, generated by IBM Quest Synthetic Data

Generator, are stored in Microsoft SQL Server 2005.

The fixed parameters for generating the databases

are: the number of distinguished items is 10000; the

number of items in the frequent one sequence

itemset is 1500; the average transactions length is 15.

The varied parameters are: |D|: the number of

transactions in the database, and |I|: the average

length of frequent patterns.

The first experiment is with minSupp set as

0.015% of |D|. The parameters of |D| are 100K,

200K, 300K, 400K and 500K, and the parameters of

|I| are 2 and 4. Number of frequent patterns and

execution time results are displayed in Table 5. In all

10 settings, the numbers of frequent patterns

obtained by CHSPAM and PHSPAM are the same.

They are 0.08% to 14.67% more than those by GFP2,

but the percentage fluctuates with the database size.

This shows that the behavior of PHSPAM is

dependent on the probabilistic population of the

repetitive items. Figure 3 displays the execution time

in these 10 settings for GFP2 and PHSPAM only.

With the projected data structures to accumulate

support counts, PHSPAM runs faster than GFP2 and

Table 5: Results and performances for minSupp equal to

0.015% of |D|.

database

no. of freq patterns execution time (second)

GFP2

CHSPAM/

PHSPAM

GFP2 CHSPAM PHSPAM

2D100K 968 973

212 1958 102

2D200K 1506 1509

564 2625 352

2D300K 1059 1062

803 6164 467

2D400K 1787 1814

1222 10389 829

2D500K 1306 1335

1277 13027 893

4D100K 1315 1326

205 3053 200

4D200K 2108 2117

521 4089 502

4D300K 1535 1760

771 9856 687

4D400K 4495 4995

1498 20638 1268

4D500K 6146 6151

1862 29741 1441

500

1000

1500

2000

100K 200K 300K 400K 500K

Number of Transactions (K)

Execution time (sec)

GFP2-I2

PHSPAM-

GFP-I4

PHSPAM-

Figure 3: Execution time comparison of GFP2 and

PHSPAM.

2000

4000

6000

8000

0.0100 0.0125 0.0150 0.0175 0.0200

Minumum Support (%)

Number of Frequent Patterns

I2D100K

I2D200K

I2D300K

I4D100K

I4D200K

I4D300K

Figure 4: Number of frequent patterns with respect to the

minimum support rate.

CHSPAM.

The second experiment runs PHSPAM with

minSupp set as 0.0100%, 0.0125%, 0.0150%,

0.0175% and 0.0200% of |D|. The parameters of |D|

are 100K, 200K, and 300K, and the parameters of |I|

are 2 and 4. Number of frequent patterns and

execution time results are displayed in Table 6. Both

consistently grow with the decrease of the minimum

support. Figure 4 shows the trend of number of

frequent patterns regarding to the minimum support.

ICEIS 2009 - International Conference on Enterprise Information Systems

156

Note that the growth rate is sharper for the number

of frequent patterns than that of the execution time.

Thus, by decreasing the minimum support, the extra

execution time is worthy of the insights gained from

the extra frequent patterns.

Table 6: Execution time for minSupp equal to 0.0100

0.0125%, 0.0150%, 0.0175%, 0.0200% of |D|.

database

no. of freq patterns / execution time (second)

0.0100% 0.0125% 0.0150% 0.0175% 0.0200%

2D100K 1633/125 1295/114

973/102 714/95 579/88

2D200K 2920/394 2235/371

1509/352 1287/327 1133/304

2D300K 1843/557 1340/511

1062/467 859/426 692/391

4D100K 1902/237 1688/211

1326/200 1163/193 747/180

4D200K 7460/794 3429/586

2117/502 1648/453 1381/425

4D300K 7185/1206 3280/826

1760/687 937/452 589/415

5 CONCLUSIONS

We designed the PHSPAM algorithm to remedy the

problems that the set of frequent hybrid sequential

patterns obtained by previous researches is

incomplete and that the execution time does not

scale with growing database sizes. PHSPAM obtains

the complete set by first collecting items that might

appear in the frequent patterns. PHSPAM then uses

the pattern growth techniques to calculate the

support of patterns. PHSPAM was implemented and

compared with GFP2 and CHSPAM. The

experiments demonstrated that PHSPAM indeed

obtained more frequent patterns than GFP2. In

addition, achieving the same completeness result,

the execution time of PHSPAM is better than GFP2

and much better than CHSPAM, due to the

accumulated counts preserved in the projected data

structures.

Our future research regarding hybrid sequential

pattern mining includes:

(1) Apply PHSPAM in real world applications, like

web page traversal paths mining through web

logs.

(2) Examine the effect of replacing the support

definition such that a transaction could

contribute at most one in the support counting

of a pattern.

(3) Consider application specific constraint of the

patterns, like timing limitations.

ACKNOWLEDGEMENTS

This work was supported in part by Taiwan’s Natio-

nal Science Council under Grant NSC ：97-2221-E-

032-046.

REFERENCES

Agrawal, R., Imielinski, T., Swami, A., 1993. Mining

association rules between sets of items in large

databases. In Proc. of the 1993 ACM SIGMOD

International Conference on Management of Data,

Washington D.C., U.S.A., pp. 207-216.

Agrawal, R., Srikant, R., 1994. Fast algorithm for mining

association rules. In Proc. of the 20th International

Conference on VLDB, Santiago, pp. 487-499.

Agrawal, R., Srikant, R., 1995. Mining sequential patterns.

In Proc. of the 11th International Conference on Data

Engineering, Taipei, Taiwan, pp. 3-14.

Agrawal, R., Srikant, R., 1996. Mining sequential patterns:

generalizations and performance improvements. In

Lecture Notes in Computer Science, Vol.1057, pp. 3-17.

Chen, M., Park, J.S., and Yu, P.S., 1998. Efficient data

mining for path traversal patterns. IEEE Trans.

Knowledge Data Engineering, Vol. 10(2), pp. 209-221.

Chen, Y.L., Chen, S.S., Hsu, P.Y., 2002. Mining hybrid

sequential patterns and sequential rules. Information

Systems, Vol. 27(5), pp. 345-362.

Han, J., Pei, J., Mortazavi-Asl, B., Chen, Q., Dayal, U.,

Hsu, M.C., 2000a. Freespan: frequent pattern-

projected sequential pattern mining. In Proc. of the 6th

ACM SIGKDD International Conference on

Knowledge Discovery and Data Mining, Boston,

U.S.A., pp. 355-359.

Han, J., Pei, J., Yin, Y.W., 2000b. Mining frequent

patterns without candidate generation. In Proc. of the

2000 ACM SIGMOD International Conference on

Management of Data, New York, U.S.A. pp. 1-12.

Jou, C., 2006. Mining Complete Hybrid Sequential

Patterns. In Proc. of the DMIN 2006 International

Conference on Data Mining, pp. 218-223, Las Vegas,

USA, June 26-29.

Pei, J., Han, J., Mortazavi-Asl, B., Pinto, H., Chen, Q.,

Dayal, U., Hsu, M.C., 2001. PrefixSpan: mining

sequential patterns efficiently by prefix projected

pattern growth. In Proc. of the 17th International

Conference on Data Engineering, Heidelberg,

Germany, pp. 106-115.

Pei, J., Han, J., Mortazavi-Asl, B., Wang, J., Pinto, H.,

Chen, Q., Dayal, U., Hsu, M.C., 2004. Mining

sequential patterns by pattern growth: the PrefixSpan

approach. IEEE Trans. on Knowledge and Data

Engineering, Vol. 16(10), pp. 1-17.

Pei, J., Han, J., Mortazavi-Asl, B., Zhu, H., 2000. Mining

access patterns efficiently from web logs. In Proc. of

the 4

Pacific-Asia Conference on Knowledge Disco-

very and Data Mining, Kyoto, Japan, pp. 396-407.

Zaki, M. J., 2001. SPADE: an efficient algorithm for

mining frequent sequences. Machine Learning,

Special Issue on Unsupervised Learning, Vol.42(1-2),

pp. 31-60.

A PROJECTION-BASED HYBRID SEQUENTIAL PATTERNS MINING ALGORITHM

157
