A SIMULATOR FOR TEACHING AUTOMATAS AND FORMAL

LANGUAGES

FLyA

J. Raymundo Marcial-Romero, Pedro A. Alvarez Contreras

Facultad de Ingenier´ıa, Universidad Aut´onoma del Estado de M´exico, Toluca, Edo. de M´exico, M´exico

H´ector A. Montes Venegas, J. Antonio Hern´andez Serv´ın

Facultad de Ingenier´ıa, Universidad Aut´onoma del Estado de M´exico, Toluca, Edo. de M´exico, M´exico

Keywords:

Finite automata, Context-free grammar, Web simulator, Supporting tools for teaching, Turing machine.

Abstract: Finite automata theory is taught in almost every computing program. Its importance comes from the broad

range of applications in many areas. As any mathematically based subjects, automata theory content is full

of abstractions which constructively explain theoretical procedures. In computing Engineering programs,

teaching is mainly focus on procedures to solve a variety of Engineering problems. However, to follow this

procedures using a conventional approach can be a tedious task for the student. In this paper, a computer based

software as a supporting tool to aid in teaching Automata Theory is presented. The use of an educational

methodology to design the tool, remarkably contributed to the acceptance of the software amongst students

and teachers as compared with existing tools for the same purpose.

1 INTRODUCTION

The constant demand of highly-qualiﬁed Computer

Science (CS) graduates around the world has made

necessary to continuously improve the teaching tech-

niques for different subjects. One of the strategies to

improve teaching has been the development of soft-

ware based on educational methodologies. In partic-

ular, automata theory is essential in almost every CS

curricula due to its applicability in many areas such

as compilers, robotics, circuit design, among oth-

ers. Nowadays, there exists software that helps stu-

dents to give solution to typical problems in automata

theory, however they lack an educational methodol-

ogy development which brings up some difﬁculties

as supporting tools for teaching. The console-type

based methodologies, for example, have the disad-

vantage of not being user friendly. They work as a

“black box”, meaning that they only show partial re-

sults due to their poor interactivity. Examples of these

tools are: Research with an automaton (Charras and

Lecrog, 1997) and Finite State Machine (FSM) Sim-

ulator (Head, 1997).

On the other hand, there are those that present

a graphical environment to interact with the user,

however they have the disadvantage of requiring ad-

ditional software to be used. They also have cer-

tain limitations such as: limited input alphabet, lim-

ited number of states and they work as well as a “

black box”. Among others things which are not de-

sirable from an educational point of view (Marqu´es,

1995). Among some of these tools, it can be men-

tioned: Automaton Simulator (Burch, 2001), DFA

Simulation (Budowski, 2001), Visual Automata Sim-

ulator (Bovet, 2006), JFLAP (Rodger, 2006), SE-

FALAS (Jodar, 2007).

In this work, we present an educational software

to support the teaching of automata theory in CS grad-

uate courses. We combine both educational and soft-

ware development methodologies in order to design

the application. We present two types of evaluations;

one that compares the acceptance of the new soft-

ware against JFLAP (although JFLAP was not de-

veloped under any educational methodology, it is in

constant improvement). The second evaluation con-

sist on measuring the level of learning over the ﬁrst

half of a course in two different groups of students.

One of the groups did not use any supporting learning

tool, whereas the other used the supporting learning

tool presented in this work.

175

Raymundo Marcial-Romero J., A. Alvarez Contreras P., A. Montes Venegas H. and Hernández Servín J. (2009).

A SIMULATOR FOR TEACHING AUTOMATAS AND FORMAL LANGUAGES - FLyA.

In Proceedings of the 11th International Conference on Enterpr ise Information Systems - Software Agents and Internet Computing, pages 175-178

DOI: 10.5220/0002011601750178

 SciTePress

The layout of the paper is as follows. In section 2

the methodological steps for the development are de-

scribed. In section 3 two evaluations of the tool are

presented. Finally the conclusions and further work

are presented.

2 DEVELOPMENT OF FLyA

FLyA consists on three modules: the Finite Au-

tomata module (FA), the Context Free Grammar mod-

ule (CFG) and the Turing Machine module (TM). The

development of FLyA involved the combination of

two methodologies, Cataldi et al. (Cataldi et al., 2003)

and XP (Wells, 2006) which is developed based on

prototypes. The application of the methodologies to

the development of FLyA consisted of the following

steps:

• The Feasibility (FEA) Step. In this step the need

for a supporting tool to teach automata theory was

established. The proportion of student failure at

the UniversityAutonomousof the State of Mexico

(UAEM) was 45%. The costs calculated to build

the tool were minimum including a MSc graduate

student to implement the system and the Univer-

sity hosting resources were used.

• The System Requirements Deﬁnition (SRD)

Step. During this step, several subtasks were de-

ﬁned: the requirement of graphical interfaces, the

shape of the objects to be included and visual-

ized in the application and the details of interac-

tion between the user and the system. The min-

imum requirements for the use of the application

(web navigator and the Flash-Player 7.0 plug-in

or above) was also established.

• The Requirement Speciﬁcation of Prototype

(RSP) Step. A detailed veriﬁcation of the re-

quirements, the interfaces and the outputs of the

application were considered in this step. Ques-

tions such as: is the graphical interface adequate

for the kind of application?, is the interface intu-

itive enough for the end user? is the partial re-

sults shown by the application adequate? were

answered at this step.

• The Prototype Design (PD) Step. In this stage of

the software development, the design of the ﬁrst

prototype was developed taking into account the

previous steps and identifying the main modules

to be developed. The FA module consisted of four

submodules, the GIC module consisted of seven

submodules and the TM was developed in three

submodules. The submodules design considered

areas for: the input alphabet, the evaluation pro-

cess, the intermediate results among others.

• The Detailed Prototype Design (DPD) Step. At

this stage the data structures employed to imple-

ment the algorithms for each of the modules were

established. The algorithms implemented were

those mentioned in Hopfcroft et al. (Hopcroft

et al., 2006) sections 2.3, 7.11, 7.13, 7.14 and 7.15

• The Prototype Design Codiﬁcation (PDC)

Step. During the PDC step, the ﬁrst “func-

tional” prototype was generated. The cod-

ing of the prototype was based on the ex-

treme programming methodology (XP) (Wells,

2006) which has short deliveries in order to

make all the necessary corrections previous to

the next step. The prototype implementation of

FLyA can be found at http://ﬁ.uaemex.mx/aylf or

http://zervero.prohosts.org/. There is no need to

to go to the above address.

• The Testing and Implementation of Prototype

(TIP) Step. Once the prototyped was concluded,

two hosting accounts were opened, one at the Uni-

versity server and the other in an external server.

According to the XP methodology short deliver-

ies should be evaluated. There were two initial

evaluations of the software, the ﬁrst one carried

out by the course’s teachers and the second one

by the students. A complete explanation is given

at Section 3.

• The Iterative Improvement of Prototype (IIP)

Step The IIP was based on the observations made

by lecturers and students registered during the

2007B term for the module at the school of En-

gineering in the UAEM (http://www.uaemex.mx),

who have made both perceptual and procedural

observations.

• Final Steps. The ﬁnal steps, namely, Final Sys-

tem Design (FSD), Final System Implemetaion

(FSI), Maintenance and Operation (MO) and Re-

tired (RET) are not discussed as the FLyA soft-

ware is in constant improvement.

3 EVALUATION

In this section the evaluation of the educational appli-

cation is discussed. In section 3.1 the acceptance by

the students and the pedagogical considerations eval-

uated by the lecturers are presented. How the tool

inﬂuence the teaching-learning process in different

groups of students is discussed in section 3.2.

ICEIS 2009 - International Conference on Enterprise Information Systems

176

3.1 External Evaluation

Two instruments were designed at this stage. The ﬁrst

instrument was to evaluate the acceptance by students

and the other to evaluate the pedagogical aspects of

the software. The evaluation instruments are based

on Cataldi (Cataldi et al., 2003) methodology.

The students evaluation instrument is mainly con-

cern on three aspects: how the student perceive the

application, how easy it is to use and how the proce-

dures are described. Each question of the instrument

had ﬁve possible options as answers. These are: very

easy, easy, acceptable, complicated and very compli-

cated.

The students evaluation instrument consisted of

seventeen questions each one ranked according to

Cataldi (Cataldi et al., 2003) methodology. The high-

est score been 63 points. This evaluation instrument

was applied during three terms 2007B, 2008A and

2008B at the UAEM. During term 2007B a group

of fourteen students were selected to evaluate both

JFLAP and FLyA. The average score of JFLAP was

30 points compare to 45 point of FLyA. It is worth to

mention that some of the main differences at the eval-

uation were the spanish version of FLyA (native lan-

guages of the students), the easy to install and use of

FLyA and the minimum number of buttons and com-

mands of FLyA compared to JFLAP.

At 2008A term, a groups of nine students evalu-

ated the applications. This time FLyA had incorpo-

rated suggestions made by students in the ﬁrst evalu-

ation such as adding options for save, open, and print

the work done. The average score of JFLAP was 31

points in this second evaluation in comparison to 47

points of FLyA.

During 2008B term, two different groups of stu-

dents were considered. One group evaluated JFLAP

and the other FLyA. This time the average score of

JFLAP was 46.33 points compare to 50.3 points of

FLyA (we note that the highest score was 63 points).

The second evaluation instrument was answered

by nine lecturers, three of them teach at the UAEM

and the rest at other universities. All of them evalu-

ated both JFLAP and FLyA.

This evaluation instrument in comparison to stu-

dents evaluation instrument, did not consider ﬁve op-

tions as possible answers, it only allowed three. The

options were not the same for all the questions but

generally speaking they consider the better, the mid-

dle and the worst case. The highest score was 95

points. FLyA had 72.5 points compared to 49.5 points

obtained by JFLAP.

Marqu´es (Marqu´es, 2000) proposed a contextual

evaluation which determines the characteristics of the

Table 1: Contextual evaluation of JFLAP and AyLF.

Evaluation aspect Score

JFLAP AyLF

Efﬁciency high high

Installation and use medium high

Changeability low low

hline Audiovisual quality low high

Content quality low medium

Originality medium high

Pedagogical perpective low high

Motivational low medium

Documentation medium medium

Table 2: Students marks at the AyLF course.

Student Written

Mark

Practical

Mark

Final

mark

1 44 50 94

2 21 50 71

3 8 45 53

4 19 50 69

5 50 40 90

6 36 40 76

7 25 45 70

8 25 30 55

software developed. A summary of the results of this

evaluation to both JFLAP and FLyA are presented in

table 1. Three are the possible scores for each ques-

tion: high (totally recommended), medium (accept-

able) and low (not recommended).

3.2 Learning Evaluation

The learning evaluation was applied in two different

Universities, one in a private university and the other

in a public university.

In the ﬁrst evaluation JFLAP and FLyA were in-

troduced to a group of eight students. Each one of

them had to choose among JFLAP and FLyA as its

supporting tool during the course. After two weeks of

evaluation, sevenof the students decided to use FLyA.

The course consisted on two hours of oral presenta-

tion and a set of practices realized in the supporting

tool. The ﬁnal marks at the end of the term (four

working months) are presented in table 2. As it can

be seen, 50% of the total marks corresponded to writ-

ten exams and the other 50% corresponded to solving

exercises and writing programs. It can also be seen

that 25% of the students failed and 75% succeeded.

In the evaluation at the public university the stu-

dents only used FLyA as their supporting tool. The

A SIMULATOR FOR TEACHING AUTOMATAS AND FORMAL LANGUAGES - FLyA

177

Table 3: Students marks during terms 2008A and 2008B

where Std=Students, WM= written marks, PM=practical

marks, FM=ﬁnal mark.

Std Semester 2008B Semester 2008A

WM PM FM WM PM FM

1 18.4 60 78.4 17.6 40.4 58

2 23.2 54 77.2 4.8 52.4 57.2

3 22.4 54 76.4 22.8 42 64.8

4 31.2 60 91.2 24.4 43.6 68

5 16.8 24 40.8 10 46.4 56.4

6 28 54 82 10.4 40.4 50.8

7 17.2 39.2 56.4 28 55.6 83.6

8 18.4 48 64.4 11.2 45.2 56.4

9 3.2 51.2 54.4 6.4 28.4 34.8

10 24.8 54 78.8 16 13.6 29.6

main idea in this evaluation was to compare the marks

obtained by the students at 2008A term which did not

use a supporting tool against the marks obtained by

students at 2008B term who used FLyA as support-

ing tool. Both of the groups were taught by the same

lecturer and evaluated using the same criteria.

Similar to the case at private university, the stu-

dents at term 2008B had to solved a series of exercises

using FLyA. Columns ﬁve to seven of Table 3 show

the marks of ten students during 2008A term. In this

case 60% of the total marks correspond to written ex-

ams and 40% to exercises and programs. Columns

two to four in table 3 show the results of ten students

during 2008B term. As previously mentioned, the

evaluation criteria was equivalent in both terms, e.g.

same number of exercises, same number of exams and

same number of programs. An easy calculation shows

that there was a 21.4% increase in the success of stu-

dent with the use of FLyA as a supporting tool.

We believe that the design of the tool contributed

to the results obtained since the interface makes use

of a minimum number of controls (steps FEA, SRD,

RSP). Hence, the user need not to worry about learn-

ing the application, it only focuses its attention on the

steps to obtain the results.

4 CONCLUSIONS

Finally, it can be said that FLyA is a tool in develop-

ment, with user acceptation. It is worthy to say that

when a tool deliveries correct results besides of be-

ing accepted by the community, it is without a doubt

a tool with growing possibilities. This application to-

gether with the results are product of a methodology

for the development of educative software. There is

a special emphasis on the aceptation by of the user.

As pointed out by Marqu´es (Marqu´es, 2000), it must

be facilitated the use of educative applications and to

avoid installation and use of additional software. It

is highlighted that the user must not be saturated with

controls or menus on the display. This makes feels the

user impressed over the magnitude of the tool, leading

to the rejection of the application.

REFERENCES

Bovet, J. (2006). Visual automata simulator, aplicaci´on de-

sarrollada en java. Online:www.cs.usfca.edu/ jbovet.

Budowski, Y. (2001). Dfa simulation, aplicaci´on

desarrollada en visual basic. Online:www.vb-

helper.com/contest dfa.html.

Burch, C. (2001). Automaton simulator,aplicaci´on desarrol-

lada en java. Online:www.cburch.com/proj/autosim/.

Cataldi, Z., Lange, F., Pessacq, R., and Garcia, R. (2003).

Metodolog´ıa extendida para la creaci´on de software

educativo desde una visi´on integradora. Revista Lati-

noamericana de Tecnolog´ıa Educativa, 2(1).

Charras, C. and Lecrog, T. (1997). Research with an au-

tomaton, a java aplication. Online:www-igm.univ-

mlv.fr/ lecroq/string/node4.html.

Head, E. (1997). Finite state machine (fsm) simu-

lator. Online:http://www.cs.binghamton.edu/ soft-

ware/fsm/fsmdoc.html#grader.

Hopcroft, J., Motwani, R., and Ullman, J. (2006). Introduc-

tion to Automata Theory, Languages, and Computa-

tion. Addison Wesley.

Jodar, J. (2007). Software para la ense˜nanza de

las fases de an´alisis l´exico y an´alisis sint´actico

(sefalas), aplicaci´on desarrollada en java. On-

line:http://lsi.ugr.es/ pl/software.php.

Marqu´es, P. (1995). Metodolog´ıa para la

elaboraci´on de software educativo. On-

line:http://www.blues.uab.es/home/material/programes/

t023151/uabdisof.htm .

Marqu´es, P. (2000). Dise˜no y evaluaci´on de progra-

mas educativos. Online:http://www.xtec.es/ pmar-

ques/edusoft.htm.

Rodger, S. (2006). Jﬂap, aplicaci´on desarrollada en java.

Online:http://www.jﬂap.org/.

Wells, D. (2006). Extreme programming. On-

line:http://www.extremeprogramming.org/.

ICEIS 2009 - International Conference on Enterprise Information Systems

178
