KEYMANTIC: A KEYWORD-BASED SEARCH ENGINE USING

STRUCTURAL KNOWLEDGE

Francesco Guerra

Dipartimento di Economia Aziendale, Universit`a di Modena e Reggio Emilia, Italy

Sonia Bergamaschi, Mirko Orsini, Antonio Sala

Dipartimento di Ingegneria dell’Informazione, Universit`a di Modena e Reggio Emilia, Italy

Claudio Sartori

Dipartimento di Elettronica, Informatica e Sistemistica, Universit`a di Bologna, Italy

Keywords:

Keyword-based search engine, Database, semantics, Metadata, Querying process.

Abstract:

Traditional techniques for query formulation need the knowledge of the database contents, i.e. which data are

stored in the data source and how they are represented.

In this paper, we discuss the development of a keyword-based search engine for structured data sources. The

idea is to couple the ease of use and ﬂexibility of keyword-based search with metadata extracted from data

schemata and extensional knowledge which constitute a semantic network of knowledge. Translating key-

words into SQL statements, we will develop a search engine that is effective, semantic-based, and applicable

also when instance are not continuously available, such as in integrated data sources or in data sources ex-

tracted from the deep web.

1 INTRODUCTION

Querying structured data sources addresses sev-

eral critical issues, especially in large and complex

sources that may not easily be known and managed

by users. The query formulation needs the knowledge

of the database contents, i.e. which data are stored in

the data source and how they are represented. Let us

consider, for example, relational databases, where ex-

pressing a query means to be able to select the right ta-

bles and attributes of a database, and to specify proper

constraints on attributes. Such a process implies over-

coming some critical tasks concerning structural and

lexical aspects:

1. the user selects the tables and attributes of interest

on the basis of their names, which may be mis-

leading or not meaningful (lexical aspect);

2. the user expresses constraints on attribute without

having accurate knowledge of the domain. Thus,

s/he may deﬁne too selective or, vice-versa, too

broad or illegal selection clauses (lexical aspect);

3. the user does not know the relationships between

the tables and, consequently, it is hard to pose

multi-table queries (structural and lexical aspect).

Therefore, there is a direct connection between the

user’s ability to express queries and the knowledge

of what and how the data are stored. If the user

knows the database contents, the query process re-

quires only the translation of the user’s search crite-

ria into a proper formalism. On the contrary, selective

queries require an analysis of the data source, i.e. a

complex and time consuming task, for users that do

not knowthe database contents. This issue is very sig-

niﬁcant when you deal with real applications, where

data structures and instances are heterogeneous, since

they come from different and unknown sources. The

same issue has to be addressed in querying an inte-

grated data source, i.e. the uniﬁed view that results

from the application of an integration methodology to

a set of data sources (Lenzerini, 2002). In these cases,

the same real world objects are represented in differ-

ent sources with different data schemata, names of

241

Guerra F., Bergamaschi S., Orsini M., Sala A. and Sartori C. (2009).

KEYMANTIC: A KEYWORD-BASED SEARCH ENGINE USING STRUCTURAL KNOWLEDGE.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Databases and Information Systems Integration, pages

241-246

DOI: 10.5220/0002155802410246

 SciTePress

attributes and domains of values, and, consequently,

synonym, polysemic, broader terms have to be taken

into account in query formulations. The knowledgeof

the data collected in the “integrated” view is manda-

tory for expressing selective queries.

The research community has developed tech-

niques for querying structured data sources that, from

the user’s perspective, can be roughly grouped into

two categories:

1. query engines where the structures of the sources

allow the users formulating selective queries by

means of a speciﬁc query language;

2. keyword-based search engines, which exploit in-

formation retrieval techniques for selecting the in-

stances closer to the terms provided by the users.

Query engines allow users to express complex queries

with selection clauses deﬁning constraints on the re-

sults. On the other hand, a user has to know the

structure of the sources (i.e. names of the tables,

the names and domains of attributes, the relationships

between the tables) and a query language for writ-

ing effective queries. The research community has

been involved in developing tools for supporting users

in writing queries (according to the query by exam-

ple approach (Zloof, 1975)) and for visualizing data

sources structures (see (Katifori et al., 2007) for a

survey).

Keyword-based search engines are more intuitive

for the user, but they support less selective queries,

since they detect instances in data sources that satisfy

speciﬁed keywords. Some effective keyword-based

search techniques applied to relational databases have

been proposed (see section 2 for some related work).

All those systems apply information retrieval tech-

niques to the database instances, and, consequently,

they suffer of several limitations. First, they are based

on instance-analysis. This is a critical aspect, because

it limits their action area to materialized data sources.

Thus, traditional keyword-based search engine can-

not be applied to integrated data sources, or to data

sources which are part of the deep web. Second, they

do not take into account the particular knowledge that

is conveyed by database structures for the search pur-

poses. Current techniques exploit database informa-

tion mainly to identify the same instances in different

tables (typically by means of foreign keys).

We claim that the currentapproachesfor keyword-

based searching on structured data sources may be

improved in two directions. Firstly, the search pro-

cess may be coupled with techniques derived from

database systems and information retrieval. This is

a new research direction, with challenging perspec-

tives (Weikum, 2007). Secondly, we think that tech-

niques based on semantics may improve the develop-

ment of an effective keyword-based search. There is a

lot of research on data and semantics. In data integra-

tion, techniques based on semantics are exploited for

making the integration process as automatic as pos-

sible (Doan and Halevy, 2005). The Semantic Web

aims at building a web of data, where semantic tech-

niques are exploitedfor allowing data to be shared and

reused across application, enterprise, and community

boundaries

. Some researchers suggest the applica-

tion of semantic web techniques to deep web, for im-

proving the search (Wright, 2008).

In this paper, we discuss the development of

a keyword-based search engine for structured data

sources that exploits the semantics associated to the

data structures for improving the results, by means of

the exploitation of a semantic network of knowledge.

In particular, we claim that semantics may be added

to the process by taking into account:

1. the semantics associated to the data schemata

may be used for improving searches. In particu-

lar, let us consider a relational database: semantic

relationships join the table with the correspond-

ing attributes, other relationships connect the at-

tributes belonging to the same table, foreign keys

link tables with each other, attribute domains al-

low addressing the search to speciﬁc attributes.

Such semantics constitute a network of relation-

ships that has to be exploited for selecting the ta-

bles containing the user’s keywords;

2. lexical knowledge may be used for two pur-

poses: ﬁrst to analyze the keywords inserted by

the user in order to “ﬁt in” them with the lexi-

con used in the sources: a set of functions for

translating a term in a set of synonym, simi-

lar, broader/narrower, meronym terms may turn a

keyword into a set of keywords with higher re-

call. Obviously, such operation has to be properly

parametrized since it may decrease the result pre-

cision. Second, lexical knowledge allows deﬁning

relationships connecting the database schema ele-

ments, enhancing the semantic network of knowl-

edge;

3. new kinds of metadata may be deﬁned to im-

prove searches. Statistical indexes based on in-

stance analysis may support the search process

by indicating the data structures where to ad-

dress the research. Keywords introduced in pre-

vious searches and the corresponding obtained re-

sults may be exploited to build and update in-

dexes, with the goal of improving next searches

and ranking the results. Besides these kinds of

metadata, we think that it may be useful to intro-

http://www.w3.org/2001/sw/

ICEIS 2009 - International Conference on Enterprise Information Systems

242

duce a “semantic” metadata, i.e. a metadata that

“synthesizes” the knowledge held by the instances

represented in tables/attributes. For this reason,

we think to exploit and extend “relevant values”

as deﬁned in (Bergamaschi et al., 2007). Relevant

values, which are automatically computed, repre-

sent an attribute domain with a reduced list of its

most important values w.r.t. a semantics based on

lexical and syntactic knowledge. Relevant values

may be used to address the search to speciﬁc ta-

bles and attributes that have their relevant values

“similar” to the user provided keywords.

4. external tools and external ontologies may be

used to build and reﬁne the semantic network. In

particular, WordNet

may be exploited for deriv-

ing lexical knowledge, ontologies and taxonomies

available in Internet (e.g.: SUMO

, OpenCyc

dmoz

) for deriving new semantic relationships.

By taking into account these semantics, we aim at

developing a keyword-based search engine working

even in absence of knowledge about instances. Our

proposal, namely Keymantic, conceives the search

engine as a component for query routing, i.e. works

coupled to a generic relational database management

system, with the task of identifying the relevant do-

main(s) of a query and then mapping the keywords

into a query to the ﬁelds of the data schema for that

domain (Madhavan et al., 2006).

Our proposal extends the issues for the implemen-

tation of a keyword search engine based on query

routing introduced in (Madhavan et al., 2007), accord-

ing with the following outline: section 2 introduces

some related work, section 3 describes the functional

architecture of our proposal, and the main features

of the modules that constitute it and ﬁnally section 4

sketches out some conclusion.

2 RELATED WORK

Works related to the issues discussed in this paper are

in the areas of Semantic Web, matching based on se-

mantic techniques and keyword-based search engines.

The ﬁrst two topics have been extensively investi-

gated in the literature: a complete overview of these

themes is out of the purposes of this paper. Besides

the references inserted in the text, we would like to

highlight that current main challenges for creating a

http://wordnet.princeton.edu

http://www.ontologyportal.org/

http://www.opencyc.org/

http://www.dmoz.org/

“web of data”, i.e. the semantic web purpose, con-

cern the application of semantic techniques to the

deep web, thus building a semantic deep web (Wright,

2008) and the application of techniques developed for

DBMS to the structured data that exist on the Web

today (Madhavan et al., 2006).

This paper starts from the assessments introduced

in (Guha et al., 2003), where the concept of seman-

tic search is deﬁned as navigational search, i.e. when

the user provides keywords that s/he expects to ﬁnd

in the data, and research search, i.e. the user pro-

vides a phrase that is intended to denote the object an

user wants to have information about. We take into

account and extend the ideas for the implementation

of a keyword search engine based on query routing

introduced in (Madhavan et al., 2007), where a new

data integration architecture with features similar to

the ones depicted in this paper, PAYGO, is proposed

for web scale data integration. Few other proposals

may be compared to Keymantic: EasyQuery (Li et al.,

2007), that follows an approach based on statistic and

syntactic matching for query routing, and the YACOB

system (Sattler et al., 2005), that does not follow a se-

mantic approach and is mediator based data integra-

tion system oriented.

Finally, Keymantic differs from the approaches

adopted by the current keyword-based search en-

gines for relational databases under development

by the research community (e.g.: BANKS (Aditya

et al., 2002), DISCOVER (Hristidis and Papakon-

stantinou, 2002), DBXplorer (Agrawal et al., 2002),

Pr`ecis (Simitsis et al., 2008)). All these systems

do not really take into account intensional knowl-

edge extracted from database schemata, but they ap-

ply and extend information retrieval techniques to

their instances. Challenges for such systems are

mainly related to query optimization and ranking

(see (Liu et al., 2006)), keyword search on mul-

tiple data sources (see (Sayyadian et al., 2007)),

identiﬁcation of related records in different tables -

with the application of join techniques or other tech-

niques (BANKS, DBXplorer, DISCOVER and (Yu

et al., 2007)), and the development of a new search

paradigm (Pr`ecis). On the contrary, our proposal aims

at exploiting the structural knowledge available in

the data sources in conjunction with the extensional

knowledge, and foresees the deﬁnition of easy lan-

guages for expressing selection clauses.

KEYMANTIC: A KEYWORD-BASED SEARCH ENGINE USING STRUCTURAL KNOWLEDGE

243

3 FUNCTIONAL

ARCHITECTURE OF

KEYMANTIC

From the architectural point of view, the search en-

gine is designed to be an add-on to allow querying

generic relational databases. Figure 1 showsthat Key-

mantic may functionally be divided into four mod-

ules, with speciﬁc tasks. The pre-processing mod-

ule builds the semantic network, stored in a Knowl-

edge base repository, that is exploited by the search-

ing module to select the tables and attributes that col-

lect the required data. The keyword analysis module

is in charge of analyzing user’s input and, by means

of the knowledge held in the semantic network, trans-

forms it into a corresponding set of terms closer to the

domains of the involved database. Finally, the post-

processing module aims at providing the results to the

user, cleaning them from duplicated items and rank-

ing them.

Figure 1: The functional architecture of Keymantic.

Next sections adds some details on the the main

features and issues of each module.

3.1 The Pre-processing Module

The pre-processing moduleis in chargeof the creation

of indexes and data structures to be exploited for the

keyword analysis and the search task. Our approach

exploits the following elements:

1. The semantic network: a set of relationships that

connect the elements of the data structures of the

involved database. The relationships generate a

weighted path that connects tables and attributes.

The relationships are generated by taking into ac-

count structural and lexical knowledge extracted

from the sources (see (Beneventano et al., 2001;

Bergamaschi et al., 2001) for an example);

2. Attribute domain evaluation: indexes storing in-

formation about the attribute domains may be ex-

ploited for checking the compatibility between

keywords and data types of the attributes;

3. “Relevant values” (Bergamaschi et al., 2007):

since they are automatically computed values of

an attribute that allow synthesizing the domain of

an attribute, they may be exploited, by means of

speciﬁc matching techniques, for addressing the

keyword search on the most promising attribute.

3.2 The Keyword Analysis Module

A keyword-based search engine foresees as input a

set of keywords and provides as a result the instances

of the data sources containing those keywords. The

analysis of the users input may allow distinguishing

schema-related keywords (that indicate on which por-

tion of the schema the search should be addressed)

from intensional related keywords that allow ﬁltering

out the results. Such an analysis is mainly based on

matching techniques (Giunchiglia et al., 2007) that

compute the proximity of every keyword with respect

to the terms used to name the elements of the data

sources and which are collected in the semantic net-

work by the pre-processing module.

Some functions may be developed and applied to

the keywords in order to enrich the search process.

We divide such functions in two categories: conceptu-

alization and transformation functions. In our experi-

ence, most of the keyword a user provide are about in-

stances. The metadata describing the database struc-

tures refers to abstract concepts. Thus, we need

a conceptualization function, which transforms data

in metadata, for associating a keyword to the most

promising database structure. We think that only the

semantics extracted from external knowledge sources

may support this task. In particular, it is possible to

exploit the “instance” function provided by WordNet

that returns the concept associated to a term. Some

other conceptualization functions may be developed

by taking into account Wikipedia

and Dmoz. For

each term collected, Wikipedia indicates a set of cat-

egories where the term belongs. Dmoz organizes in-

formation in nested categories. For each term, it is

therefore possible to have a list of terms that repre-

sent increasingly broader conceptualizations. Lexical

transformation are based on WordNet. For each ele-

ment, WordNet returns synonym, broader/narrower,

meronym terms thus allowing a richer search, de-

creasing at the same time the precision level of the

result. This aspect has to be taken into account in

ranking the results.

http://en.wikipedia.org/

ICEIS 2009 - International Conference on Enterprise Information Systems

244

Such a process may be further reﬁned by provid-

ing an annotation of the keywords with respect to a

lexical reference or an ontology. By associating a def-

inite meaning to the keywords, the recall of the results

improves. Some disambiguation techniques may be

applied to automatize the process. Such techniques

are typically based on context. Since the context pro-

vided by few keywords is too poor to be exploited by

automatic software, a graphical interface to support

the user in this task has to be developed.

Finally, the adoption of an easy language for the

keyword deﬁnition has to be evaluated, exploiting the

structural characteristics of the underlying databases

to express simple selection predicates and approxi-

mate searches. In particular, we will evaluate the

possibility of expressing keywords such as “vehi-

cle:price=15000”, stating that the search is addressed

to vehicles whose price is 15000 euro. This kind

of keywords allows to search for instances that have

given values (15000) of a speciﬁc structural element

(the attribute price of the table vehicle). The approx-

imate searches among structural elements will pro-

vide not only results from the table “vehicle” (if it

exists) but also those coming from tables whose name

is semantically close to vehicle (for example the ta-

ble “car”,...). The approximate searches on the exten-

sional side will provide, not only the vehicles whose

price is 15000 euro, but also those with a price close

to that value.

3.3 The Searching Module

This module performs two tasks: the selection of the

searched tables and attributes and the rewriting of the

user provided keyword into an SQL query to be exe-

cuted by the DBMS holding the data.

The ﬁrst operation is performed by applying

matching techniques to schema-related keywords (or

the ones obtained by the application of conceptual-

ization functions). The goal of this task is to identify

the most promising tables and attributes on the basis

of the results of the pre-processing phase. There is a

rich literature about matching techniques (see for ex-

ample (Giunchiglia et al., 2007)). For our purposes,

we aim at extending some algorithms for approximate

matching (see (Navarro, 2001) for a survey) in order

to base our work on the semantic network computed

in the pre-processing phase.

The second operation transforms keywords re-

sulting from the previous phase into SQL queries.

It is a straightforward process, since the target at-

tribute/table computed in the previous step will be

translated into a select/from clause and intensional re-

lated keyword that will deﬁne the selection clause of

the query. Notice that (a) each keyword may gener-

ate more than one query, according to the semantic

network and to the applied transformation functions.

Each query result differently ranks the user keyword;

(b) a trivial approach will be adopted for reconciliat-

ing keywords that cannot be referred to the same table

(or to tables that may not be connected by join opera-

tions). In this case the user will be informed of the in-

consistency and asked to change the set of keywords.

3.4 Post-processing

This module concerns the analysis of the query re-

sults to be proposed to the user. We think that two

tasks have to be achieved in this phase: data fusion

and result rank.

Data fusion is the identiﬁcation and the handling

of the same real world object in different databases

in order to provide the user with a unique and cor-

rect answer. Several techniques have been proposed

for solving the issues related to data fusion. In partic-

ular, (Naumann et al., 2006) proposed an automatic

technique that shall be adapted and extended for a

keyword-based search engine.

Results will be ranked according to the keywords

used for generating the SQL queries. In particular, the

transformations to the keywords obtained applying

the techniques introduced in section 3.2 are weighted

and then exploited to rank the results.

4 CONCLUSIONS AND FUTURE

WORK

In this paper, we presented our preliminary work for

the development of a keyword-based search engine

for data schemata. We think that research on this

topic is challenging: ﬁrstly, it allows the combination

of techniques from information retrieval and database

systems; secondly, it investigates issues that are com-

plementary and orthogonal to the ones addressed by

current search engines; thirdly, it allows the reuse and

the extension of techniques previously developed in

the ﬁeld of semantic web, data matching, data fusion.

We think that our work may be applied in several

domains, such as non-materialized integrated sources

and deep web data sources.

Future work will be devoted to the development,

implementation and testing of each component where

a particular attention will be addressed on the opti-

mization of the developed techniques, concerning es-

pecially the response time. The search engine will

be evaluated in different application domains, such

KEYMANTIC: A KEYWORD-BASED SEARCH ENGINE USING STRUCTURAL KNOWLEDGE

245

as the TPC-H benchmark

, which provides a relevant

database for the industrial domain and it is an impor-

tant reference for similar applications.

ACKNOWLEDGEMENTS

This work has been partially funded by the Ital-

ian Ministry of University and Research within the

project ”NeP4B - Networked Peers for Business” and

by the Fondazione Cassa di Risparmio di Modena

within the project ”Searching a needle in amounts of

data!”.

REFERENCES

Aditya, B., Bhalotia, G., Chakrabarti, S., Hulgeri,

A., Nakhe, C., Parag, and Sudarshan, S. (2002).

Banks: Browsing and keyword searching in relational

databases. In VLDB 2002, Proceedings of 28th Inter-

national Conference on Very Large Data Bases, Au-

gust 20-23, 2002, Hong Kong, China, pages 1083–

1086. Morgan Kaufmann.

Agrawal, S., Chaudhuri, S., and Das, G. (2002). Dbxplorer:

A system for keyword-based search over relational

databases. In ICDE, pages 5–16. IEEE Computer So-

ciety.

Beneventano, D., Bergamaschi, S., Guerra, F., and Vincini,

M. (2001). The momis approach to information inte-

gration. In ICEIS (1), pages 194–198.

Bergamaschi, S., Castano, S., Vincini, M., and Beneven-

tano, D. (2001). Semantic integration of hetero-

geneous information sources. Data Knowl. Eng.,

36(3):215–249.

Bergamaschi, S., Sartori, C., Guerra, F., and Orsini, M.

(2007). Extracting relevant attribute values for im-

proved search. IEEE Internet Computing, 11(5):26–

35.

Chan, C. Y., Ooi, B. C., and Zhou, A., editors (2007). Pro-

ceedings of the ACM SIGMOD International Confer-

ence on Management of Data, Beijing, China, June

12-14, 2007. ACM.

Doan, A. and Halevy, A. Y. (2005). Semantic integration

research in the database community: A brief survey.

AI Magazine, 26(1):83–94.

Giunchiglia, F., Yatskevich, M., and Shvaiko, P. (2007). Se-

mantic matching: Algorithms and implementation. J.

Data Semantics, 9:1–38.

Guha, R. V., McCool, R., and Miller, E. (2003). Semantic

search. In WWW, pages 700–709.

Hristidis, V. and Papakonstantinou, Y. (2002). Discover:

Keyword search in relational databases. In VLDB

2002, Proceedings of 28th International Conference

http://www.tpc.org

on Very Large Data Bases, August 20-23, 2002, Hong

Kong, China, pages 670–681. Morgan Kaufmann.

Katifori, A., Halatsis, C., Lepouras, G., Vassilakis, C., and

Giannopoulou, E. G. (2007). Ontology visualization

methods - a survey. ACM Comput. Surv., 39(4).

Lenzerini, M. (2002). Data integration: A theoretical per-

spective. In Popa, L., editor, PODS, pages 233–246.

ACM.

Li, X., Meng, W., and Meng, X. (2007). Easyquerier: A

keyword based interface for web database integration

system. In Ramamohanarao, K., Krishna, P. R., Mo-

hania, M. K., and Nantajeewarawat, E., editors, DAS-

FAA, volume 4443 of Lecture Notes in Computer Sci-

ence, pages 936–942. Springer.

Liu, F., Yu, C. T., Meng, W., and Chowdhury, A. (2006).

Effective keyword search in relational databases. In

Chaudhuri, S., Hristidis, V., and Polyzotis, N., editors,

SIGMOD Conference, pages 563–574. ACM.

Madhavan, J., Cohen, S., Dong, X. L., Halevy, A. Y., Jef-

fery, S. R., Ko, D., and Yu, C. (2007). Web-scale data

integration: You can afford to pay as you go. In CIDR,

pages 342–350. www.crdrdb.org.

Madhavan, J., Halevy, A. Y., Cohen, S., Dong, X. L., Jef-

fery, S. R., Ko, D., and Yu, C. (2006). Structured data

meets the web: A few observations. IEEE Data Eng.

Bull., 29(4):19–26.

Naumann, F., Bilke, A., Bleiholder, J., and Weis, M. (2006).

Data fusion in three steps: Resolving schema, tuple,

and value inconsistencies. IEEE Data Eng. Bull.,

29(2):21–31.

Navarro, G. (2001). A guided tour to approximate string

matching. ACM Comput. Surv., 33(1):31–88.

Sattler, K.-U., Geist, I., and Schallehn, E. (2005). Concept-

based querying in mediator systems. VLDB J.,

14(1):97–111.

Sayyadian, M., LeKhac, H., Doan, A., and Gravano, L.

(2007). Efﬁcient keyword search across heteroge-

neous relational databases. In ICDE, pages 346–355.

IEEE.

Simitsis, A., Koutrika, G., and Ioannidis, Y. E. (2008).

Pr´ecis: from unstructured keywords as queries to

structured databases as answers. VLDB J., 17(1):117–

149.

Weikum, G. (2007). Db&ir: both sides now. In (Chan et al.,

2007), pages 25–30.

Wright, A. (2008). Searching the deep web. Commun.

ACM, 51(10):14–15.

Yu, B., Li, G., Sollins, K. R., and Tung, A. K. H.

(2007). Effective keyword-based selection of rela-

tional databases. In (Chan et al., 2007), pages 139–

150.

Zloof, M. M. (1975). Query-by-example: the invocation

and deﬁnition of tables and forms. In Kerr, D. S., edi-

tor, VLDB, pages 1–24. ACM.

ICEIS 2009 - International Conference on Enterprise Information Systems

246
