MINIMIZING THE MAKESPAN IN TWO-MACHINE JOB SHOP
SCHEDULING PROBLEMS WITH NO MACHINE IDLE-TIME
Fatma Hermès
Faculté des Sciences Mathématiques, Physiques et Naturelles de Tunis, Département Informatique, Laboratoire LI3
Campus Universitaire, 1060 Tunis, Tunisia
Jacques Carlier, Aziz Moukrim
Université de Technologie de Compiègne, Centre de Recherches de Royallieu
Laboratoire Heudiasyc, UMR CNRS 6599, BP 20529, 60205 Compiègne cedex, France
Khaled Ghédira
Institut Supérieur de Gestion de Tunis, Laboratoire LI3
Université de Tunis, 41 Rue de la Liberté – Bouchoucha, 2000 Bardo, Tunisia
Keywords: Scheduling, Job Shop, Two Machines, No-idle Constraint, Makespan, Optimal Solution.
Abstract: This paper deals with two-machine job shop scheduling problems working under the no-idle constraint, that
is, machines must work continuously without idle intervals. The makespan (C
max
) has to be minimized.
First, we study the problem where each job consists of at most two operations and we show that it can be
solved polynomially using Jackson’s rule (Jackson, 1956). Second, we study the problem where the number
of operations per job can be greater than two and all operations are of unit time and we extend the results of
(Hefetz and Adiri, 1982). Finally, we discuss the possibility of getting feasible solutions and then optimal
solutions in the general case where the number of operations per job can be greater than two and all
operations do not have the same processing time.
1 INTRODUCTION
Frequently, the cost of making machines wait is so
high that a no-idle constraint is imposed on
machines and no intermediate idle time between
operations processed by the same machine is
allowed. For example, if the machine is an oven that
must cook some pieces at a given high temperature
then maintaining the required temperature of the
oven while it is empty may be too costly. However,
studies of problems on this topic have not attracted a
great deal of attention. In the literature, we find
some works, most of which are recent, on the
permutation flow shop ((Adiri and Pohoryles, 1982),
(Baptiste and Lee, 1997), (Kalczynski and
Kamburowski, 2007), (Saadani, Guinet and Moalla,
2001), (Saadani, Guinet and Moalla, 2003)). There
are also some recent works discussing one machine
scheduling problems ((Chrétienne, 2008), (Valente
and Alves, 2005), (Valente, 2006)).
The aim of this paper is to study two-machine
job shop problems where a set I of n jobs, I = {1, ...,
n}, has to be scheduled without intermediate delay
on two machines in order to minimize the maximum
of the completion times of the jobs i.e. the makespan
(C
max
). Each job i, i I, is composed of n
i
operations
O
i,j
, j = 1…n
i
, and each operation O
i,j
has to be
processed on a fixed machine for p
i,j
time units.
The job shop problem plays an important role in
the scheduling theory because of its practical
applications. Most of job shop problems are NP-hard
and there are only few special cases which can be
solved polynomially. The two-machine job shop
problem with at most two operations per job is
denoted J2|n
i
2|C
max
. It was solved polynomially by
Jackson (Jackson, 1956) who proposed an algorithm
which calculates an optimal schedule in O(n*log(n))
steps using Johnson’s rule (Johnson, 1954). The
two-machine unit-time job shop problem is denoted
89
Hermès F., Carlier J., Moukrim A. and Ghédira K. (2009).
MINIMIZING THE MAKESPAN IN TWO-MACHINE JOB SHOP SCHEDULING PROBLEMS WITH NO MACHINE IDLE-TIME.
In Proceedings of the 6th International Conference on Informatics in Control, Automation and Robotics - Intelligent Control Systems and Optimization,
pages 89-96
DOI: 10.5220/0002213500890096
Copyright
c
SciTePress
J2|p
i,j
=1|C
max
. It was proved to be polynomial by
(Hefetz and Adiri, 1982) where authors proposed the
longest remaining processing time first algorithm
which schedules operations in a decreasing order of
the remaining processing time of jobs. Lenstra,
Rinnooy Kan and Brucker showed in (Lenstra,
Rinnooy Kan and Brucker, 1977) that problem
J2||C
max
is strongly NP-hard. Later, Brucker showed
in (Brucker, 1994) that the two-machine job shop
problem with a fixed number k of jobs, denoted
J2|n=k|C
max
, can be solved polynomially by reducing
it to a shortest path problem and then he deduced
that it is possible to calculate an optimal schedule for
J2||C
max
for any fixed number of jobs in polynomial
time.
The paper is organized as follows: In section 2,
we define the studied problem and we recall some
backgrounds and basic results relying on the two-
machine job shop problem. In section 3, we study
the two-machine job shop problem where the
number of operations per job is at most equal to two
and machines must work under the no-idle
constraint. This problem is denoted J2|n
i
2,no-
idle|C
max
. We show that it can be solved in
polynomial time using Jackson’s rule (Jackson,
1956). In section 4, we study the two-machine unit-
time job shop problem with no machine idle time,
denoted J2|p
i,j
=1,no-idle|C
max
, and we extend the
results of (Hefetz and Adiri,1982). Finally, in
section 5, we deduce some special cases which are
polynomially solvable.
2 GENERAL POINTS
In this section, we first define the problem subject of
this study and we present some definitions. Next, we
present Johnson’s and Jackson’s algorithms where
Johnson’s algorithm (Johnson, 1954) solves the two-
machine flow shop problem with C
max
criterion
denoted F2||C
max
and Jackson’s algorithm (Jackson,
1956) solves problem J2|n
i
2|C
max
using Johnson’s
rule. Finally we introduce the longest remaining
processing time first algorithm (Hefetz and Adiri,
1982) which solves problem J2|p
ij
=1|C
max
.
2.1 Problem Formulation and Basic
Definitions
The two-machine job shop problem is a problem
where a set I of n jobs, I = {1, ..., n} have to be
processed in a shop with two machines M
1
and M
2
.
Each job i, i = 1, …, n, consists of a sequence of n
i
operations O
i,1
, O
i,2
, ..., O
i,ni
which must be
processed in this order. The precedence constraints
are so that O
i,j
precedes O
i,j+1
, j = 1, …, n
i
– 1. Each
operation O
i,j
must be processed for p
i,j
time units on
machine µ
i,j
{M
1
, M
2
}.
The following assumptions are made:
A machine can process only one operation at a
time.
An operation cannot be interrupted.
The time zero is the earliest time an operation
can be started.
All setup times are included into the job
processing times.
If operation O
i,j
must be processed on machine
M
1
, then operation O
i,j+1
must be processed on
machine M
2
i,j
µ
i,j+1
for i = 1,…, n
i
– 1).
Thus, job i may be characterized by the number
of operations and the machine on which the
first operation must be processed.
Only no-idle schedules are considered.
Let t
i,j
be the starting time of operation O
i,j
and
let C
i,j
be its completion time. Let C
i
be the
completion time of job i so that
C
i
=
i
1...nj
max
=
C
i,j
(1)
Let us present the following definitions:
An initial operation is one without
predecessors: the operation O
i,1
is the initial
operation for job i.
A terminal operation is one without successors:
the operation
i
ni,O
is the terminal operation for
job i.
A ready operation is an operation that has not
yet been scheduled while all its predecessors
have been.
A no-idle schedule satisfies the no-idle
constraint on each machine. In other words, if
operation O
i,j
is executed immediately before
operation O
i’,j’
on the same machine then we
have:
C
i,j
= t
i,j
+ p
i,j
= t
i’,j’
(2)
Given a feasible schedule π we have:
C
max
(π) =
i
1...nj
1...ni
max
=
=
C
i,j
=
1...ni
max
=
C
i
(3)
The objective is to find a no-idle schedule so as
to minimize the C
max
. The problem so formulated is
denoted J2|no-idle|C
max
. When the number of
operations per job is at most equal to two, the
problem is denoted J2|n
i
2,no-idle|C
max
and when all
operations have the same processing time which is
considered as the unit-time, the problem is denoted
J2|p
i,j
=1,no-idle|C
max
.
ICINCO 2009 - 6th International Conference on Informatics in Control, Automation and Robotics
90
2.2 Jackson’s and Johnson’s
Algorithms
Jackson’s algorithm constructs an optimal schedule
for J2|n
i
2|C
max
problem reducing it to F2||C
max
problem. Below, we first describe Johnson’s
algorithm. Then, we present Jackson’s algorithm.
Finally, we conclude with some results concerning
the presence of idle times on machines.
2.2.1 Johnson’s Algorithm
The two-machine flow shop problem is a problem
where a set I
of n
jobs, I
= {1,2,…,n
} must visit
machines in the same order. Each job i consists of
two operations O
i,1
and O
i,2
which must be processed
respectively, first on machine M
1
then on machine
M
2
. Johnson’s algorithm (Johnson, 1954) constructs
an optimal schedule in polynomial time
(O(n*log(n))) for F2||C
max
problem. It applies the
following steps:
i. Divide the set of jobs I
, I
= {1,2,…,n
}, into two
subsets:
a. Let I
1
denote the subset of jobs i, i = 1, …,
n
, which satisfy the condition p
i,1
p
i,2
b. Let I
2
denote the subset of jobs i, i = 1, …,
n
, which satisfy the condition p
i,1
> p
i,2
ii. Schedule on each machine first the jobs of I
1
in
an increasing order of p
i,1
and then the jobs of I
2
in a decreasing order of p
i,2
.
2.2.2 Jackson’s Algorithm
Jackson’s algorithm (Jackson, 1956) calculates an
optimal solution for problem J2|n
i
2|C
max
, in
polynomial time (O(n*log(n))) by first reducing it to
F2||C
max
problem and then using Johnson’s rule. It
applies the following steps:
i. Divide the set of jobs I = {1, 2, …, n} into four
subsets:
a. Let I
1
denote the subset of jobs consisted of
only one operation which must be
processed on machine M
1
.
b. Let I
2
denote the subset of jobs consisted of
only one operation which must be
processed on machine M
2
.
c. Let I
1,2
denote the subset of jobs which are
processed first on machine M
1
then on
machine M
2
.
d. Let I
2,1
denote the subset of jobs which are
processed first on machine M
2
then on
machine M
1
.
ii. Calculate an optimal sequence R
1,2
for the flow
shop problem relative to the job set I
1,2
.
iii. Calculate an optimal sequence R
2,1
for the flow
shop problem relative to the job set I
2,1
.
iv. On machine M
1
schedule first I
1,2
according to
R
1,2
, then all jobs in I
1
and finally I
2,1
according
to R
2,1
.
v. On machine M
2
schedule first I
2,1
according to
R
2,1
, then all jobs in I
2
and finally I
1,2
according
to R
1,2
.
2.2.3 Further Results
Adiri and Pohoryles (Adiri and Pohoryles, 1982)
observe that problems F2|prmu,no-idle|C
max
and
F2|prmu|C
max
are equivalent in the sense that every
F2|prmu|C
max
schedule can be transformed into an
F2|prmu,no-idle|C
max
schedule with maintaining the
same C
max
. Thus, both problems can be solved by
Johnson’s algorithm (Johnson, 1954). Johnson’s
schedule is an active schedule in which machine M
1
is naturally no-idle since operations are processed
consecutively on it without idle interval. Moreover,
the jobs preceding each idle interval on the second
machine M
2
can be delayed without increasing the
C
max
. It is enough to fix the starting time of the last
operation scheduled on M
2
and to schedule the other
operations so that all operations are scheduled
consecutively without any intermediate delay.
Brucker (Brucker, 1995) observes that in
Jackson’s schedule at least one machine processes
jobs without idle intervals. More specifically, having
the following assumption:
+
11,22,1
Ii
i,1
Ii
i,1
Ii
i,2
ppp
(4)
then there is no idle time on machine M
1
. Otherwise,
there is no idle time on machine M
2
.
2.3 The Longest Remaining Processing
Time First Algorithm
The longest remaining processing time first
algorithm has been proposed by (Hefetz and Adiri,
1982) to solve J2|p
i,j
=1|C
max
problem. It constructs
an optimal schedule for this problem with applying
the following steps:
i. Give a label α
i,j
to each operation O
i,j
so that:
α
i,j
= n
i
– j + 1 i = 1,…,n and j = 1,…,n
i
(5)
ii. Schedule the highest label operation for the
earliest possible time on the required machine,
with ties broken arbitrarily.
iii. Remove from the problem the scheduled
operation. Stop if all operations are scheduled,
otherwise return to (ii).
The authors noted that the operation with the
highest label in step (ii) must be a ready operation,
MINIMIZING THE MAKESPAN IN TWO-MACHINE JOB SHOP SCHEDULING PROBLEMS WITH NO MACHINE
IDLE-TIME
91
since, if it is not then there is an unscheduled
predecessor with a higher label, which is a
contradiction.
Let T
j
, j = 1, 2, be the total processing time
required on machine M
j
and p
i
the processing time
of job i. Thus, p
i
= n
i
in view of the fact that all
operations have unit duration.
Theorem 1 (Hefetz and Adiri, 1982). The longest
remaining processing time first algorithm constructs
an optimal schedule for J2|p
i,j
=1|C
max
problem. If all
initial operations require the same machine and we
have:
T
1
= T
2
max
i
n
i
(6)
Then, the optimal schedule length is:
C
*
max
= T
1
+ 1 = T
2
+ 1 (7)
Otherwise, the optimal schedule length is:
C
*
max
= max(T
1
, T
2
, max
i
n
i
)
(8)
3 RESOLUTION OF THE
PROBLEM
J2|N
I
2,NO-IDLE|C
MAX
The problem we consider in this section is to find an
optimal schedule for J2|n
i
2,no-idle|C
max
problem.
We propose first to study the feasibility of Jackson’s
schedule then, we prove its optimality. We also
deduce some interesting results which concern the
necessity of applying Johnson’s rule in Jackson’s
algorithm.
Proposition 1. The C
max
-value of Jackson’s schedule
is a lower bound for the optimal C
max
of J2|n
i
2,no-
idle|C
max
problem.
Proof. Jackson’s schedule is an active schedule in
which all the operations are scheduled as soon as
possible. On the other hand, to satisfy the no-idle
constraint, some operations must be delayed which
must increase the C
max
-value. So, the optimal C
max
of
J2|n
i
2,no-idle|C
max
problem must be greater than or
equal to that of J2|n
i
2|C
max
problem.
So, evidently Jackson’s schedule is optimal for
J2|n
i
2,no-idle|C
max
problem if it is no-idle or if it
can be transformed into a no-idle schedule without
increasing the C
max
-value.
Lemma 1. If (4) then there is no-idle time on
machine M
1
and it is unnecessary for Jackson’s
algorithm to apply Johnson’s rule for the two-
machine flow shop sub-problem relative to I
2,1
.
M
1
M
2
I
2
,
1
I
11
I
2
,
1
I
2
j
0t
tTime
R
1,2
j
R
1,2
Figure 1: A schedule where there is no-idle time on
machine M
1.
Proof. If (4) holds, then at time t where,
+
=
11,2
Ii
i,1
Ii
i,1
ppt
(9)
all the operations of I
2,1
which must be processed on
machine M
1
are ready. Therefore, these operations
can be processed without idle time immediately after
the end of those of I
1
as presented in figure 1 above.
As a result, the order of processing the
operations of I
2,1
on machine M
1
and on machine M
2
does not affect the C
max
-value since all the
operations of I
2,1
which must be processed on
machine M
2
are naturally ready at time 0. They are
completed at time t
, where
t
i,2
p t'
2,1
Ii
=
(10)
Lemma 2. If
+
22,11,2
IiIiIi
i,1
i,2
p
i,2
pp
(11)
then there is no-idle time on machine M
2
and it is
unnecessary for Jackson’s algorithm to apply
Johnson’s rule for the two-machine flow shop sub-
problem relative to I
1,2
.
Proof. The proof is similar to that of lemma 1.
Let us note that if
1,22,1
IiIi
i,2
i,1
pp
(12)
then (4) holds. Also, if
2,11,2
IiIi
i,1
i,2
pp
(13)
then (11) holds.
By summation of (12) and (13), we have:
=
2,11,2
Ii
i,2
Ii
p
i,1
p
(14)
Lemma 3. If any of the following assumptions hold,
namely, (4) and (13), (11) and (12), or (14) then
Jackson’s schedule is no-idle. It is consequently
ICINCO 2009 - 6th International Conference on Informatics in Control, Automation and Robotics
92
optimal for problem J2|n
i
2,no-idle|C
max
and it is
unnecessary for Jackson’s algorithm to apply
Johnson’s rule neither for the two-machine flow
shop sub-problem relative to I
1,2
nor for the two-
machine flow shop sub-problem relative to I
2,1
.
Proof. If (4) holds then there is no idle time on
machine M
1
and it is pointless to apply Johnson’s
rule in Jackson’s algorithm to the sub-problem
relative to I
2,1
(lemma 1).
If (13) holds then there is no-idle time on
machine M
2
and it is pointless to apply Johnson’s
rule in Jackson’s algorithm to the sub-problem
relative to I
2,1
(lemma 2).
By summation of (4) and (13), Jackson’s
schedule is no-idle. It is consequently optimal for
J2|n
i
2,no-idle|C
max
problem and it is unnecessary
for Jackson’s algorithm to apply Johnson’s rule
neither for the two-machine flow shop sub-problem
relative to I
1,2
nor for the two-machine flow shop
sub-problem relative to I
2,1
.
In the same way, we deduce the same results if
assumptions (11) and (12) hold or assumption (14)
holds.
Proposition 2. The problem J2|n
i
2,no-idle|C
max
is
polynomial. It can be solved with Jackson’s
algorithm.
Proof. At least one machine is no-idle (Brucker,
1995). If there is an idle interval on machine M
1
then
it is between the operations of I
2,1
and in this case
the assumption (4) does not hold. If there is an idle
interval on machine M
2
then it is between the
operations of I
1,2
and in this case the assumption (11)
does not hold either.
Supposing that machine M
2
contains an idle
time, then this idle time is between the operations of
I
1,2
relative to the two-machine flow shop sub-
problem where each job visits first, machine M
1
then
machine M
2
. This idle time can be reduced by fixing
the starting time of the last operation scheduled on
machine M
2
and scheduling the other operations of
I
1,2
consecutively without any intermediate delay
(Adiri and Pohoryles, 1982).
This action creates an other idle time between
the first operation scheduled of I
1,2
on machine M
2
and the last operation scheduled of I
2
on the same
machine.
The last idle time can also be reduced by
delaying all the operations of I
2
and then the idle
time becomes between the last operation scheduled
of I
2,1
and the first operation scheduled of I
2
. Since,
there is no idle time on machine M
1
, then (4) holds.
Let t be the ending date of the last operation of
I
1,2
scheduled on machine M
1
and let t
be the
starting time of the first operation of I
1,2
scheduled
on machine M
2
.
Naturally, we have:
t
t (15)
Because if (15) does not hold, then (4) does not
hold. Consequently, it is possible to shift the
operations of I
2,1
on machine M
2
to the right so that
there is no-idle time on machine M
2
.
Thus, the schedule constructed by Jackson’s
algorithm can be easily transformed into a no-idle
schedule without increasing the C
max
-value. It is
enough to fix the last operation on the machine
which contains idle intervals and shift to the right all
the other operations in order to have no idle
intervals.
As a result, Jackson’s algorithm also constructs
an optimal schedule for he problem J2|n
i
2,no-
idle|C
max
problem.
Proposition 3. The set of optimal solutions of
J2|n
i
2,no-idle|C
max
problem is included in the set of
optimal solutions of J2|n
i
2|C
max
problem.
Proof. Jackson’s schedule can easily be transformed
to a no-idle schedule without increasing the C
max
-
value. So, both problems have the same C
max
*
.
Besides, an optimal solution for J2|n
i
2,no-idle|C
max
problem is also optimal for J2|n
i
2|C
max
problem.
Thus, the set of optimal solutions of J2|n
i
2,no-
idle|C
max
problem is included in the set of optimal
solutions of J2|n
i
2|C
max
problem.
4 RESOLUTION OF THE
PROBLEM J2|p
ij
=1,no-idle|C
max
In this section, we study J2|p
ij
=1,no-idle|C
max
problem.
Proposition 4. The optimal C
max
of J2|p
ij
=1|C
max
problem is a lower bound for the optimal C
max
of
J2|p
ij
=1,no-idle|C
max
problem; if an optimal schedule
exists.
Proof. The proof is similar to that of proposition 1.
Below, we denote HA the longest remaining
processing time first algorithm. Let S be the
schedule constructed by HA algorithm.
MINIMIZING THE MAKESPAN IN TWO-MACHINE JOB SHOP SCHEDULING PROBLEMS WITH NO MACHINE
IDLE-TIME
93
Lemma 4. If there is no-idle time in S then the
makespan of S is minimal and the number of idle
times is minimal.
Proof. HA calculates a schedule with minimal
makespan for J2|p
ij
= 1|C
max
problem (theorem 1).
Moreover, if there is no-idle time in S then the
number of idle times is also minimal.
Let us introduce a second criterion to minimize
which is the number of idle times denoted Ā. The
objective is then to minimize first the C
max
then Ā. In
this case, the related problem is denoted
J2|p
ij
=1|Lex(C
max
,Ā).
Evidently, if an optimal schedule for
J2|p
ij
=1|Lex(C
max
,Ā) problem is no-idle then it is
also optimal for J2|p
ij
=1,no-idle|C
max
problem. Also,
if there is no-idle time in S, then S is optimal for
both problems J2|p
ij
=1,no-idle|C
max
and
J2|p
ij
=1|Lex(C
max
,Ā). Furthermore, if it is possible to
built a no-idle schedule S’ from S without increasing
the C
max
then S’ is optimal for both problems
J2|p
ij
=1,no-idle|C
max
and J2|p
ij
=1|Lex(C
max
,Ā).
Let us assume that job h is the job so that
n
h
= max
i
n
i
(16)
Figure 2: The schedule resulting from the assumption of
an idle interval on machine M
2
in interval t and t is even.
Lemma 5. If in S there is an idle time, on some
machine, then
i. the job h is unique, and it is processed
continuously from time
0 to n
h
, alternating on
the two machines;
ii. the only job processed on the machine
containing this idle time is the job h;
iii. from time t – 1, all the operations processed
on the other machine, except of those of the
job h, must have a label 1.
Proof. The time axis is supposed to be split into
intervals of unit times. We suppose that the first idle
interval is the interval t. Let us suppose also that t is
even and that this idle time is on machine M
2
. Let us
denote i
1
(resp: j
1
) the job processed in interval 1 on
machine M
2
(resp: M
1
) and so on. So, i
t-1
is the job
processed on machine M
2
in interval t – 1, and i
t
is
the job processed on machine M
1
in interval t (figure
2). The label of job j
t-1
is 1. Otherwise there doesn’t
exist any idle time in interval t. Consequently, all
jobs processed after t – 1, at the exception of job i
t
which is the only job which can have a label strictly
larger than 1. Let us set i = i
t
. We prove that i
t-1
= i.
It is the only job which can have a label strictly
larger than 2. For the same reason i
t-2
= i (the only
job which can have a label strictly larger than 3) and
so on until i
1
= i. Consequently, i = h. The same
reasoning can be applied when t is odd.
Thus, the job i must be the job h and then the job
h is continuously scheduled from beginning to end
since at each time it have the greatest label. It is
consequently the job h verifying the assumption (16)
and it is unique.
Figure 3: The first operation of job h is processed on
machine M
2
and machine M
1
work for the first interval.
Figure 4: The first operation of job h is processed on
machine M
2
and machine M
1
is free for the first interval.
Algorithm IT
i. Built S with applying HA algorithm
ii. Built S’ by scheduling the first operation of
job h at time 0 and letting the other machine
idle at time 0 and scheduling the remaining
jobs by applying HA algorithm from time 1.
Theorem 2. One of the two schedules built by
algorithm IT is optimal for both objective functions.
Proof. First, let us note that if there is an idle time in
S then this idle time usually precedes an operation of
job h and it is also preceded with an operation of the
same job h. Indeed, if there is an idle time then the
job h is unique and therefore it is continuously
scheduled from beginning to the end (lemma 5).
Thus, in each interval the job h is processed on one
machine and on the other machine either another job
is processed or there is an idle time. On the other
hand, if the first operation of job h is processed on
M
1
M
2
h
h
h
j
t-1
h
j
1
h
j
2
h
h
h
1 2 t-1 t t+1 t
-1 t
Interval
0 1 2 t-2 t-1 t t+1 t
-2 t
-1 t
Time
M
1
M
2
i
t
i
t-1
i
t+1
j
t-1
i
1
j
1
i
2
j
2
1 2 t-1 t t+1 Interval
0 1 2 t-2 t-1 t t+1 Time
M
1
M
2
h
h
h
j
t-1
h
h
j
2
h
h
h
1 2 t-1 t t+1 t
-1 t
Interval
0 1 2 t-2 t-1 t t+1 t
-2 t
-1 t
Time
ICINCO 2009 - 6th International Conference on Informatics in Control, Automation and Robotics
94
machine M
2
then if there is an idle time on machine
M
2
which occurs in interval t then t is even and if
there an idle time on machine M
1
which occurs in
interval t
then t
is odd. Otherwise, t is odd and t
is
even.
Below, we show in four cases that S or S is
optimal for both objectives.
In the first case, we assume that the first
operation of job h is processed on machine M
2
and
the machine M
1
works for the first interval of time
(figure 3). In this case, the number of idle times on
machine M
2
is minimal because the operations
scheduled on machine M
2
, except of those of the job
h, are used optimally to fill idle intervals created by
the job h. It is the same for machine M
1
from time 1.
However, if it is possible to make machine begin
working later with one unit of time without
increasing the ending date on this machine and the
C
max
then we can suppress an idle time. This is done
eventually in S
.
In the second case, we assume that the first
operation of job h is processed on machine M
1
and
the machine M
2
works for the first interval of time.
This case is similar to the first one.
In the third case, we assume that the first
operation of job h is processed on machine M
2
and
the machine M
1
is free for the first interval of time
(figure 4). In this case, the number of idle times is
minimal in both machines because in each machine
the first operation scheduled is an operation of job h.
In the fourth case, we assume that the first
operation of job h is processed on machine M
1
and
the machine M
2
is free for the first interval of time.
This case is similar to the third one.
Thus, S or S’ is optimal for both objectives.
We can resume that S is no-idle if and only if
one of the following cases holds:
Case 1:
max
i
n
i
min(T
1
, T
2
)
(18)
Case 2:
max
i
n
i
= min(T
1
, T
2
) + 1 (19)
and the last operation of the job h is scheduled on
the machine which determines the schedule length.
Case 3:
max
i
n
i
= min(T
1
, T
2
) + 2 (20)
and all jobs begin in the same machine and the last
operation of the job h is scheduled on the machine
which determines the schedule length.
Finally, we note that S’ is no-idle if S is no-idle
or S contains only one idle time.
5 RESOLUTION OF THE
PROBLEM J2|n=k, no-idle|C
max
In this section, we discuss J2|n=k,no-idle|C
max
problem.
Proposition 5. The optimal C
max
of J2|n=k|C
max
problem is a lower bound for the optimal C
max
of
J2|n=k,no-idle|C
max
problem; if an optimal schedule
exists.
Proof. The proof is similar to that of proposition 1.
So, the optimal schedule for J2|n=k|C
max
problem
is optimal for J2|n=k,no-idle|C
max
problem if it is no-
idle or if it can be transformed into no-idle schedule
without increasing the C
max
-value.
Obviously, if n = 1 and n
1
> 2 then it is not
possible to construct a no-idle schedule. There are
exactly n
1
– 2 idle intervals.
Let us consider the problem where the number of
jobs is equal to two. This problem is denoted
J2|n=2,no-idle|C
max
.
Figure 5: Schedule format with two jobs where n
1
> n
2
.
Let us give the following cases:
Case 1: n
1
= n
2
, μ
1,1
μ
2,1
and p
1,j
= p
2,j
for
j = 2… n
1
– 1
Case 2: n
1
= n
2
, μ
1,1
= μ
2,1
and p
1,j+1
= p
2,j
for
j = 1… n
1
– 1
Case 3: n
1
= n
2
, μ
1,1
= μ
2,1
and p
1,j
= p
2,j+1
for
j = 1… n
1
– 1
Case 4: n
1
= n
2
+1, μ
1,1
μ
2,1
and p
1,j
= p
2,j
for
j = 2… n
2
Case 5: n
1
= n
2
+ 1 and μ
1,1
= μ
2,1
and p
1,j+1
= p
2,j
for j = 1…n
2
– 1
Case 6: n
2
= n
1
+ 1, μ
1,1
μ
2,1
and p
1,j
= p
2,j
for
j = 2…n
1
Case 7: n
2
= n
1
+ 1, μ
1, 1
= μ
2,1
and p
1,j
= p
2,j+1
for
j = 1…n
1
– 1
Case 8: n
1
= n
2
+ 2, μ
1,1
= μ
2, 1
, and p
1,j+1
= p
2,j
for j = 1…n
2
Case 9: n
2
= n
1
+ 2, μ
1,1
= μ
2, 1
, and p
1,j
= p
2,j+1
for j = 1…n
1
t
0
t
1
t
2
t
3
t
4
2
n
t T=
1
n
t
2
2
M
1
M
2
1
1
1
1 1
1
1
2
2 2
2
1
1
MINIMIZING THE MAKESPAN IN TWO-MACHINE JOB SHOP SCHEDULING PROBLEMS WITH NO MACHINE
IDLE-TIME
95
Proposition 6. If any of the previous cases holds
then the no-idle schedule is unique; it is
consequently the optimal solution for J2|n=2,no-
idle|C
max
problem. Otherwise, it is impossible to get
a no-idle schedule.
Proof. A feasible schedule for J2|n=2|C
max
problem
takes the format presented in figure 5 above.
Clearly, having this format, it is not possible to
transform any schedule to a no-idle schedule. There
are at most max(n
1
, n
2
) – 2 idle intervals.
However, we deduce that if any of the previous
cases holds then the no-idle schedule is unique. It is
consequently the optimal solution for J2|n=2,no-
idle|C
max
problem. Otherwise, it is impossible to get
a no-idle schedule.
6 CONCLUSIONS
In this paper, we have studied the impact of adding
the no-idle constraint to the problem of minimizing
the makespan in a two-machine job shop. We have
studied separately the case where the number of
operations per job isn’t greater than two and the case
where all operations are of unit time. In the first case
we have showed that there exists usually an optimal
schedule which we can calculate using Jackson’s
rule and then fixing the last operation scheduled on
the machine which contains an idle time and then
scheduling the other operations consecutively
without idle times. However, in the second case, we
showed that it is not usually possible to build a
feasible no-idle schedule. Then, we have proposed
the IT algorithm which minimizes first the C
max
then
the number of idle times (Ā). We have shown that it
is impossible to build a schedule which contains a
number of idle times smaller than that of the
schedule obtained by applying IT algorithm.
Consequently, if this schedule is no-idle then it is
also optimal for the corresponding problem with
adding the no-idle constraint. Moreover, in the
general case, where the number of operations per job
can be greater than two and all operations do not
have the same processing time, we have shown that
where the number of jobs is equal to two there are
only few cases numbered from 1 to 9 which are
efficiently solvable and where the set of feasible no-
idle schedules contains a unique schedule. In
conclusion, we deduce that it is not usually possible
to construct a feasible no-idle schedule for the two-
machine job shop problem and that in the majority
of cases, this set is empty.
REFERENCES
Adiri, I., Pohoryles, D., 1982. Flow-shop/no-idle or no-
wait scheduling to minimise the sum of completion
times.
Naval Research Logistics Quarterly, Vol. 29,
pp. 495-504.
Baptiste, P., Lee, K.H., 1997. A branch and bound
algorithm for the F|no-idle|C
max
. Proceedings of the
International Conference on Industrial Engineering
and Production Management (IEPM’1997)
, Lyon, vol.
1, pp. 429-438.
Brucker, P., 1994. A polynomial algorithm for the two
machine job-shop scheduling problem with fixed
number of jobs.
Operations Research Spektrum, Vol.
16, pp. 5-7.
Brucker, P., 1995. Scheduling Algorithms,
Springer,
ISBN: 3-540-60087-6.
Chrétienne, P., 2008. On single-machine scheduling
without intermediate delays.
Discrete Applied
Mathematics, 156, p. 2543-2550.
Garey, M.R.D., Johnson, D.S., Sethi, R., 1976. The
complexity of flowshop and jobshop scheduling.
Mathematics of Operations Research, Vol. 1, pp. 117-129.
Hefetz, N. , Adiri, I., 1982. An Efficient Optimal
Algorithm for the Two-Machines Unit-Time Jobshop
Schedule-Length Problem.
Mathematics of Operations
Research, Vol. 7, No. 3., pp. 354-360.
Jackson, J.R., 1956. An extension of Johnson’s results on
job lot scheduling.
Naval Research Logistic Quarterly,
Vol. 3, pp. 201-203.
Johnson, S.M., 1954. Optimal two- and three-stage
production schedules with setup times included,
Naval
Research Logistics Quarterly, Vol. 1, pp. 61-68.
Kalczynski, P. J., Kamburowski, J., 2007. On no-wait and
no-idle flow shops with makespan criterion.
European
Journal of Operational Research, Vol. 178, pp. 677–685.
Lenstra, J. K., Rinnooy Kan, A.H.G., Brucker, P., 1977.
Complexity machine scheduling problems.
Annals of
Discrete Mathematics
, Vol. 1, pp. 343-362.
Saadani, H., Guinet, A., Moalla, M., 2001. A travelling
salesman approach to solve the
F|no-idle|C
max
problem.
Proceedings of the International Conference on
Industrial Engineering and Production Management
(IEPM’ 2001)
, Quebec, vol. 2, 880-888.
Saadani, H., Guinet, A., Moalla, M., 2003. Three stage no-
idle flow-shops.
Computers and Industrial
Engineering
, 44, 425-434.
Valente, J. M. S., Alves, R. A. F. S., 2005. Improved
Heuristics for the Early/Tardy scheduling problem with
no idle time.
Computers & Operations Research, 32: p.
557-569.
Valente, J. M. S., 2006. Heuristics for the single machine
scheduling problem with early and quadratic tardy
penalities. Working paper 234, Faculdade de Economia
do Porto, Portugal, December.
ICINCO 2009 - 6th International Conference on Informatics in Control, Automation and Robotics
96
