MONTE CARLO PROJECTIVE CLUSTERING OF TEXTS

Vladimír Ljubopytnov and Jaroslav Pokorný

Department of Software Engineering, Faculty of Mathematics and Physics, Charles University, Praha, Czech Republic

Keywords: Document clustering, Projective cluster, Web snippets, Web mining, Monte Carlo method.

Abstract: In this paper we propose a new, improved version of a Monte Carlo projective clustering algorithm – DOC.

DOC was designed for general vector data and we extend it to deal with variable dimension significance and

use it in web search snippets clustering. We discuss advantages and weaknesses of our approach with

respect to known algorithms.

1 INTRODUCTION

Document or text clustering is a field of Information

Retrieval (IR) (Manning, Raghavan, and Schütze,

2008) that optimizes search in custom document

collections as well as World Wide Web. There are

collections of high-dimensional data (and texts are

among them) that inherently tend to group in

subspaces. It is common in IR to store texts as

vectors of numbers indicating the presence or the

number of terms (vector space model of IR). The

dimensions of these vectors correspond to index

terms (words or phrases) and subspaces shared by

multiple texts may define a distinctive and

interesting topic. Unfortunately, clustering suffers

from the curse of dimensionality. This is the

motivation behind using a projective clustering

algorithm.

We chose DOC, a scalable Monte Carlo method

for clustering coordinate vectors introduced by

Procopiuc (Procopiuc et al, 2002). It is linear in the

number entities to be clustered and polynomial in

dimension (the exponent can be changed to

accommodate high-dimension data more easily).

Subspaces recognized by DOC are perpendicular to

the coordinate axes. In text clustering, information

about dimension (word or phrase) significance is

available. Thus, it made sense to extend the

algorithm to include this data in cluster evaluation.

One can observe that clustering of the results

returned by search engines becomes prevailing in

recent times. The goal of our research is to develop a

more efficient clustering Web snippets.

In Section 2 we give a short overview of the

state-of-art algorithms for document clustering,

particularly for cases in which documents are Web

snippets. Then in Section 3 we introduce the basic

DOC algorithm and present our variant – DocDOC

with an application on Web snippets. We also

discuss possibilities of its usage. Finally, we discuss

its position among existing approaches and mention

some other possibilities of its application.

2 RELATED WORKS

Today search engines return with a ranked list of

search results also some contextual information, in

the form of a Web page excerpt, the so called

snippet. Web-snippet clustering is an innovative

approach to help users in searching the Web. It

consists of clustering the snippets returned by a

(meta-) search engine into a hierarchy of folders

which are labelled with a term. The term expresses

latent semantics of the folder and of the

corresponding Web pages contained in the folder.

The folder labels vary from a bag of words to

variable-length sentences. On the other hand,

snippets are often hardly representative of the whole

document content, and this may in some cases

seriously worsen the quality of the clusters.

Remind that search engine result summarizations

is a subcategory of Web content mining. There are

various approaches to snippets clustering in

literature. Zamir and Etzioni presented the Suffix

Tree Clustering (STC) algorithm (Zamir and Etzioni,

1998). It uses suffix tree to identify groups of

documents sharing a common phrase. These groups

are merged if their overlap exceeds given threshold

using a single link method. The phrase awareness of

237

Ljubopytnov V. and Pokorný J. (2009).

MONTE CARLO PROJECTIVE CLUSTERING OF TEXTS.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 237-242

DOI: 10.5220/0002247602370242

 SciTePress

this algorithm caused a positive jump in quality

when compared to classical algorithms. However, it

may suffer from the chaining effect of the single

linkage in some cases and the cluster scoring is

based on phrase length and cluster size only.

In 2003, Maslowska introduced Hierarchical

STC, which replaces single link merging with

topological ordering of a directed cluster graph

(Maslowska, 2003). The edges between base clusters

are defined by inclusion ratio of respective base

clusters and again, a threshold ratio is given. Fully

overlapping base clusters are merged in advance.

The result is a hierarchy, where those clusters that

are not included by any other are on top.

The Lingo algorithm (Osinski, Stefanowski, and

Weiss, 2004) uses singular vector decomposition

(SVD) to find correlating index term groups and

selects best among them while preferring phrases.

Phrases are discovered efficiently using a suffix

array. Roughly said, found phrases are used to create

cluster labels and documents are assigned to their

best matching label. This approach (description-

first) concentrates on label quality which suffers in

classical algorithms. It is designed for web snippet

clustering where the time costly SVD does not show

itself.

A more advanced algorithm is described in

(Mecca, Raunich, and Pappalardo, 2007). Its main

contribution is a novel strategy – called dynamic

SVD clustering – to discover the optimal number of

singular values to be used for clustering purposes.

Authors apply the algorithm also on the full

documents and justify the idea that clustering based

on snippets has inherently lower quality than on full

documents. The algorithm was used in the Noodles

system - a clustering engine for Web and desktop

searches.

Very efficient online snippet clustering based on

directed probability Graphs is described in (Li and

Yao, 2006)

Web-snippet clustering methods are usually

classified in according to two dimensions: words vs.

terms and flat vs. hierarchical (Ferragin and Gulli,

2006). Four categories of approaches are

distinguished:

1. Word-Based and Flat Clustering

2. Term-Based and Flat Clustering

3. Word-Based and Hierarchical Clustering

4. Term-Based and Hierarchical Clustering

Our considerations concern rather the second

category of methods. A lot of background material

to clustering, including web snippets, can be found

in (Húsek et al, 2007).

3 DocDOC CLUSTERING

ALGORITHM

In this chapter we describe the original DOC

algorithm and its variant appropriate for Web

snippets.

3.1 DOC Algorithm

The DOC algorithm operates with projective clusters

that additionally store information about bound

dimensions (dimensions where all vectors are

sufficiently near with respect to a pre-defined value).

When looking for a cluster, it randomly guesses a

combination of vectors, finds their bound

dimensions, and returns all vectors that share bound

dimensions with those randomly selected. Multiple

guesses are made to ensure optimality of returned

cluster with proven probability. A key feature of this

algorithm is the use of special quality function that

takes cluster size as well as bound dimensions into

account. This function is called β-balanced. In other

words, a β-balanced function is any function

μ: R × R → R

increasing in both parameters, that fulfils two

conditions:

1. μ(0, 0) = 0

2. μ(βa, b + 1) = μ(a, b)

for 0 ≤ β < 1 and any non-negative a and b. For

example, the function defined as

μ(a, b) = a(1/β)

is β-balanced.

When applied to cluster size |C| and

dimensionality |D| it returns the same quality as for

smaller cluster with size β|C| and dimensionality

increased by one (|D|+1). β specifies a trade-off

between cluster size and dimension and is one of

algorithm parameters. The other – α – sets minimal

recognized relative cluster size. DOC algorithm is

proven to return an optimal projective cluster (or an

approximation of it) with probability at least 50%, if

1/4n ≤ β < 1/2 (n denotes total number of

dimensions) and 0 ≤ α < 1. For full detail see

(Procopiuc et al, 2002).

3.2 Adapting DOC to Text

Here presented extension of DOC, called DocDOC,

was introduced in (Ljubopytnov, 2006). When

adapting DOC to web snippets, some obvious

observations were done:

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

238

 In web search snippets, multiple term

occurrences hardly influence term importance.

Thus, term frequency (tf) was discarded (in

contrast with widely used tf×idf metric),

leaving only dimension bound weighing in

play. This enables use of Boolean model with

weights and efficient bit array representation.

 Only shared presence of term defines bound

dimension as association power of non-present

terms is next to zero. This makes determining

bound dimensions a matter of bitwise AND

operation.

 A change to the quality function that favours

better weighed dimensions should be

employed to make full use of significance

estimates (idf, etc.).

First two points are trivial but the third step

requires further explanation. We mentioned that β

parameter is the trade-off between cluster size and

dimension. Having dimensions of different value, it

is this trade-off that should be set individually for

each dimension to determine projective cluster

quality. If we have a good, preferred dimension, it

should be more costly to throw away. Fewer objects

are required to stay in the cluster to keep its quality

if we try to bind this highly priced dimension. Thus,

we see that for better weighed dimensions we want

smaller β.

In the DocDOC algorithm, dimension weights

are transformed to fit into the interval [1/4n; 1/2) as

required for the β value in DOC and stored in a

function

β’: D

all

→ [1/4n; 1/2)

where D

all

is set of all dimensions. β’-balanced

function is any function

μ : R × P(D

all

) → R

increasing in both parameters (in case of second

parameter, natural set ordering is assumed), that

fulfils two conditions:

1. μ(0,Ø) = 0

2. μ(β’(i)a, D ∪ {i}) = μ(a, D)

for 0 ≤ β < 1 and any non-negative a and D subset of

all

. For example, the function defined as

μ‘(a, D) = a Π

i ∈D

1/ β’(i)

is β’ balanced.

Proof of correctness of this change is easy. The

key is that we keep the β’ values in required range as

they vary across dimensions. Once we ensure this,

the proof works identically as for original DOC in

(Procopiuc et al, 2002).

Algorithm 1: DocDOC procedure.

Procedure DocDOC(P, dim_score, α, β)

1. r := log(2n)/ log(1/2β);

2. m := (2/α)

ln 4;

3. hash := Ø;

4. best_quality := −1;

5. for i := 1 to 2/α do

begin

Randomly select p ∈ P;

for j := 1 to m do

begin

Randomly select X ⊆ P, |X| = r;

D := {i| |q

− p

| ≤ w, ∀q ∈ X};

if D ∈ hash

then quality = hash(D);

else begin

C := B

p,D

∩ P;

quality := μ’(|C|,D,dim_score);

hash(D) := quality;

end

if best_quality < quality

then begin

best_quality := quality;

C* := C;

D* := D;

end

6. return (C*,D*)

DocDOC parameters remain the same, i.e. β is used

to set the lower bound for β’ values (best dimension

β). The DocDOC Procedure is described by

Algorithm 1.

3.3 Phrase Discovery

Lingo makes use of phrases and evaluates them

using SVD (correlation strength). STC sets the

phrase score according to its length. Although such

pre-processing introduces additional time cost, we

decided to use a more thorough phrase evaluation

scheme based on the LLR-test (Log Likelihood

Ratio) described, e.g. in (Cox and Hinkley, 1974).

We look at all bigrams and trigrams and we

study the hypothesis of them being a random

collocation (their word occurrences are

independent). Using G-test, we determine the

likelihood ratio of this hypothesis:

G = O

log(O

where Oi is observed event frequency and Ei is

expected event frequency according to the

hypothesis, i iterates over all possible events. For a

bigram w1w2 we have a contingency table in Table

1 describing a number of situations when w1 does or

MONTE CARLO PROJECTIVE CLUSTERING OF TEXTS

239

Table 3: The best scored phrases for queries “salsa” and “clinton”.

”salsa” (912)

core ”clinton” (300)

core

salsa danc 18.84 clinton county 25.03

salsa congres 14.09 bill clinton 23.03

salsa recip 12.87 hillary clinton 21.82

salsa festival 12.06 clinton presidential 19.66

salsa lesson 11.71 new york 19.57

danc salsa 10.58 clinton porti 18.23

salsa verd 10.47 united stat 17.42

danc 10.43 barack obama 17.03

salsa music 10.43 clinton lead 16.39

music 10.26 clinton say 16.39

salsa class 9.85 clinton administration 16.39

latin 9.82 whit hous 16.26

salsa dancer 9.78 clinton hill 15.37

salsa club 9.75 clinton memorial 14.37

event 9.45 clinton jumped 14.16

recip 9.23 rodham clinton 14.16

salsa scen 8.99 clinton impeachment 14.16

latin danc 8.82 clinton st 14.16

cha cha 8.76 presidential rac 13.20

san francisco 8.40 chamber of commerc 13.16

does not precede w

and w

does or does not

supersede w

Table 1: Contingence table for a bigram w

¬w

If we know the bigram w1w2 occurrence

frequency c12, the occurrences of words w1: c1, w2:

c2, and the total bigram count B we can write the

contingency table as it is on Table 2.

Table 2: Improved contingence table for a bigram w

For the independence hypothesis, expected event

frequencies are

*nn

ip pj

where n

= Σ

and n

=Σ

. We execute the G-

test on these values:

log( / )Gnnm

ij ij ij

∑

The higher the value, the more the probability of

bigram being not random co-occurrence but a

phrase.

For trigrams, the situation is more complicated

as there can be as much as four models of trigram

words independence (one for mutual independence

of all words in trigram and three for independence of

one word on other two that correlate). Contingency

table is three dimensional and sub-bigram

frequencies are needed for its construction.

Hypothesis with best (lowest) score is returned (it is

nearest to reality).

For longer n-grams, the complexity keeps

growing. We settled with bigrams and trigrams only.

If a frequent quadgram is present in the text, it’s first

and second trigram will rank high and they will be

associated together by DocDOC, but only in case,

that there are no stoplist words at their boundaries.

Otherwise, most high ranking phrases contain a stop

word on its boundary, thus being quite useless (e.g.,

”lot of ”, ”in the”).

Scores obtained by G-test tend to grow rapidly,

so we logarithmized them to get a reasonable scale

and combined with inverted document frequency.

Tests presented here have been performed with a

sample of 912 snippets obtained by Google for the

query “salsa” and 300 snippets for the query

“clinton”. The results are presented in Table 3.

3.4 Optimizations

Web snippets demonstrate strong regularities;

dimension (word, phrase) combinations appear

− c

= c

− c

B − c

− c

+ c

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

240

repetitively when trying to guess an optimal cluster.

In contrast with original DOC, we use a hash

structure to store previously calculated dimension

qualities. That saves us a costly data scan per each

cluster quality computation. Hash is indexed by used

dimension combinations.

The benefit of dimension caching may be worth

over 50% of data scans for web snippets. It grows if

the DocDOC procedure is called multiple times on

the same data (i.e. to bump the optimality

probability). The beauty of dimension cache is also

that when sorted, it gives a ranked list of

overlapping clusters that is identical to STC base

clusters, only with 100% overlapping clusters

merged. This is very important, since that makes

DocDOC identical to STC with respect to the result

achieved (when identical postprocessing is done, i.e.

hierarchization).

3.5 Usage and Output

The DOC procedure returns one cluster at a time.

There are three possibilities how to use it:

 greedy – found clusters are removed from

collection, this relies heavily on cluster quality

estimation by the quality function, valuable

information can be lost, must be run several

times to increase the guaranteed 50%+

probability of returning an optimal

 cluster (empirically, the algorithm returns good

clusters all the time, but potentially destroying

the optimal one), runs while there is enough

data (with collection size percentage as

threshold) and its running time may vary

substantially.

 overlapping – every found cluster is

remembered in a list sorted by quality and the

procedure is run few times. This improves

result stability and speed, loses no information

and can be dealt with as with merged STC

base clusters, that is, merging and rescoring

until no clusters overlap enough.

Final task is creating cluster labels from (C, D)

projective clusters. That is done by choosing all or

best ranking dimensions (phrases, words) from D.

As in HSTC, clusters can be topologically sorted to

get a nice cluster hierarchy.

4 COMPARISON

OF ALGORITHMS

We have made the following observations:

 Clusters found by DOC are exactly those

generated by STC, but merged in case of 100%

overlap.

 Suffix arrays are 5 times more efficient with

respect to memory usage than suffix tree.

 DocDOC has a potential for more flexible

ranking than STC.

 The quality function introduced in DocDOC

defines different ordering of clusters than STC.

 DocDOC is better parallelizable and scalable.

 DocDOC need less memory footprint than

Lingo and maybe STC.

 The quality function introduced in DocDOC

defines different ordering of clusters than STC.

5 CONCLUSIONS

We proposed and implemented an improved version

of the DOC algorithm used on Web snippets in our

experiments. We have shown that it has a number of

better properties than other algorithms of this

category.

Since discovering knowledge from and about

Web is one of the basic abilities of an intelligent

agent, an applicability of the algorithm can be found

e.g. in semantic Web services.

Although named DocDOC, the algorithm has far

greater usability than just texts. If used on vector

data (as opposed to the Boolean model, but keeping

the dimension weight information), there are

applications across various disciplines (i.e.

medicine, data mining) that may benefit from this

algorithm.

ACKNOWLEDGEMENTS

This research was supported in part by GACR grant

201/09/0990.

REFERENCES

Cox, D. R. and Hinkley, D. V: Theoretical Statistics,

Chapman and Hall, 1974.

Ferragin, P. and Gulli, A.: A personalized search engine

based on Web-snippet hierarchical clustering. In: Proc.

of 14th International Conference on World Wide Web

2005, Chiba, Japan, pp. 801-810.

Húsek, D., Pokorný, J., Řezanková, H., Snášel, V.: Data

Clustering: From Documents to the Web. Chapter 1 in

book Web Data Management Practices: Emerging

Techniques and Technologies, A. Vakali and Pallis

Eds., Idea Group Inc., 2007, p. 1-33.

MONTE CARLO PROJECTIVE CLUSTERING OF TEXTS

241

Li, J., Yao, T.: An Efficient Token-based Approach for

Web-Snippet Clustering. In: Proc, of the Second

International Conference on Semantics, Knowledge,

and Grid (SKG'06), 2006, 6 pages.

Ljubopytnov, V.: Webmining. Master thesis, Charles

University, Prague, 2007 (In Czech).

Manning, Ch., D., Raghavan, P., and Schütze, H. (2008).

Introduction to Information Retrieval. Cambridge

University Press, 2008.

Mecca, G., Raunich, S., and Pappalardo, A.: A new

algorithm for clustering search results. Data &

Knowledge Engineering. Volume 62, Issue 3

(September 2007) pp. 504-522, 2007

Maslowska, I.: Phrase-based hierarchical clustering of web

search results. In: Advances in Information Retrieval –

ECIR 2003, LNCS, vol.2633, Springer-Verlag Berlin,

2003, pp. 555-562

Osinski, O., Stefanowski, J., and Weiss, D.: Lingo: Search

results clustering algorithm based on singular value

decomposition. In: Proceedings of the International

Conference on Intelligent Information Systems

(IIPWM), 2004, pp. 369–377.

Procopiuc, C, Jones, M., Agarwal, P., and Murali. T.: A

Monte Carlo algorithm for fast projective clustering.

In: Proceedings of the 2002 ACM SIGMOD

International Conference on Management of Data,

New York, NY, USA, ACM Press, 2002, pp. 418–427.

Zamir O. and Etzioni, O.: Web document clustering: A

feasibility demonstration. In: Proceedings of ACM

SIGIR Conf. on Research and Development in

Information Retrieval, 1998, pp. 46-54.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

242
