MODELING AND MONITORING THE QUALITY OF DATA

BY INTEGRITY CONSTRAINTS AND INTEGRITY CHECKING

Hendrik Decker

Instituto Tecnol´ogico de Inform´atica, Valencia, Spain

Keywords:

Quality, Integrity constraints, Integrity checking, Inconsistency tolerance.

Abstract:

Characteristic attributes for describing the quality of data, such as trustworthyness, soundness, riskiness, uncer-

tainty, dependability, reliability and other semantic properties can be modeled and monitored by conventional

database integrity technology. As opposed to traditional consistency constraints, occasional violations of some

of the integrity conditions that describe quality aspects may be tolerable, even for extended periods of time.

Traditional integrity checking methods are intolerant wrt. any constraint violation. They insist that all con-

straints are totally satisﬁed before updates can be checked for integrity preservation. Inconsistency-tolerant

methods can waive that insistence. Thus, if data quality is modeled by constraints, it can be monitored by any

integrity checking method that is inconsistency-tolerant. We illustrate that by an extended example, by which

inconsistency-tolerant integrity checking is also compared to some alternative aproaches.

1 INTRODUCTION

In relational databases, ﬁrst-order predicate logic sen-

tences called assertions, integrity constraints or sim-

ply constraints are used to express conditions that

are required to be invariantly satisﬁed across state

changes caused by updates.

In knowlege bases and decision support systems,

the expressive power of logic also can be used to cap-

ture any other semantic information that goes beyond

the simple structures of common database content. In

particular, conditions for characterising the quality of

data can be expressed as assertions.

The basic motivation and idea behind this paper is

that the database should not suffer from semantically

imperfect data, and that stored data can be considered

to have sufﬁcient quality if the database satisﬁes suit-

ably many quality constraints. Otherwise, if a critical

amount of the required quality assertions is violated,

then the quality of the database is impaired or dam-

aged beyond tolerable proportions.

The evaluation of assertions tends to be pro-

hibitively expensive. Thus, for the interpretation of

assertions as integrity constraints, speciﬁc integrity

checking methods for simplifying their evaluation are

used. However, since the semantics of quality asser-

tions is different from that of integrity constraints, the

use of integrity checking methods for simplifying the

evaluation of quality assertions is questionable.

Traditional integrity checking insists on total con-

straint satisfaction. That is not suitable in general

for monitoring quality assertions, since some of them

may be occasionally violated, even for extended pe-

riods of time, without impairing ongoing routine op-

erations. As opposed to that, we are going to see that

integrity checking methods that are able to tolerate ex-

tant violations of constraints also are able to monitor

the dynamics of the quality of data.

More precisely, we show how to gain a better

control over the quality and possible imperfections

of stored data, by expressing quality properties as

constraints, and monitoring them with inconsistency-

tolerant integrity checking methods. Conditions that

model quality properties may qualify data positively,

e.g., as trustworthy, secure or healthy, or negatively,

as imperfect or risky, uncertain or vague, etc. If each

such property is satisﬁed, there is no quality erosion

that would violate the constraints. Conversely, viola-

tion of quality properties means that the data that are

responsible for violation qualify as corrupt.

Capturing quality properties of data by describing

them in the form of integrity constraints yields a dou-

ble beneﬁt: Firstly, to use the expressive power of the

syntax of semantic integrity constraints also for de-

scribing arbitrarily general quality properties of data.

Secondly, to make use of established integrity check-

207

Decker H. (2009).

MODELING AND MONITORING THE QUALITY OF DATA BY INTEGRITY CONSTRAINTS AND INTEGRITY CHECKING.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 207-214

DOI: 10.5220/0002264602070214

 SciTePress

ing methods in order to efﬁciently check data also for

quality. Thus, monitoring and controlling stored and

incoming new data and updates with regard to their

quality can be achieved.

In section 2, we ﬁrst strive to gain a better under-

standing of the similarities and differences between

integrity and quality. Then, we claim that, in spite

of seemingly severe differences, it is possible to cap-

ture conditions for quality by integrity constraints,

and to monitor them by using methods for integrity

checking. This claim is substantiated in the remain-

der. In section 3, we recapitulate the concept of

inconsistency-tolerant integrity checking (Decker and

Martinenghi, 2006; Decker, 2008). (Inconsistency

here is synonymous to integrity violation.) We show

that it is precisely the inconsistencytolerance of meth-

ods that makes them apt to be used for monitoring

quality. In section 4, we elaborate an extended ex-

ample that illustrates how inconsistency-tolerant in-

tegrity checking can be used for risk management.

The latter is a special case of managing the quality

of data. In section 5, we address related work. In

section 6, we conclude.

2 QUALITY AND INTEGRITY

In 2.1, we analyse the similarities, and in 2.2 the dif-

ferences between quality and integrity. Essentially,

integrity and quality are very similar since both can

be described by assertions. They differ since integrity

constraints and their evaluation traditionally are much

more exigent than quality assertions. However, as ex-

plained in 2.3, this difference is reconciled and can be

overcome by inconsistency-tolerant methods for in-

tegrity checking, with which also quality assertions

can be evaluated.

2.1 Similarities

Traditionally, integrity constraints are used to express

correctness conditions with which all stored data must

comply. Upon each issued update, the constraints im-

posed on the database are checked. Updates are com-

mitted only if they do not cause integrity violation.

For example, in a civil registry database containing

information about citizens and their marital status, in-

serting married(john,mary) violates

∀x∀y∀z(married(x, y) ∧ married(x, z) → y6=z),

i.e., a constraint forbidding bigamy, if the tuple

married(john,susan) is already stored. Then, also the

integrity constraint

∀x∀y married(x,y) → person(x,m) ∧ person(y,m)

which requires that each spouse of each married cou-

ple is registered in the person table of the database

and has the marital status attribute set to m(arried),

will signal violation upon an attempt to delete the tu-

ple person(susan,m).

Also conditions for characterising database entries

that lack quality (i.e., data that are risky, uncertain,

precarious, dubious, suspicious, etc), as well data that

are devoid of such deﬁciencies (i.e., data that are trust-

worthy, dependable, reliable, credible, etc) can be ex-

pressed in the syntax of integrity constraints. Obvi-

ously, datalog negation can be used to convert posi-

tive into negative qualities and vice-versa.

The constraint uncertain ← person(x,null), for

instance, qualiﬁes each entry in the person table as

uncertain by a namesake 0-ary predicate if the marital

status of that entry is unknown, as represented by a

null value. Another example is the constraint

∀x p(x, null) → p(x, s) ∨ p(x,m) ∨ p(x,d) ∨ p(x,w)

where p abbreviates person. It says that each person

with unknownmarital status is either single or married

or divorced or widowed. Similarly, entries of persons

with birth date before the 20th century can be char-

acterized as dubious. By amalgamating higher-order

predicates into ﬁrst-order terms (Bowen and Kowal-

ski, 1982), also sentences such as

conﬁdence(row(x,y),z) ∧ z < th → ∼trustworthy(x)

may serve as constraints for disqualifying the trust-

worthyness of rows x in database tables y such that

the conﬁdence value z of x is below a certain thresh-

old value th (which can be thought of as a constant

parameter or the output of some evaluable function).

Thus, it is possible to characterize uncertain data

in the syntax of integrity constraints. Analogously,

this can also be done for any semantic properties that

capture some other quality aspects. Hence, it should

also be possible to use integrity checking methods in

order to check incoming data for violations of quality

constraints, and, symmetrically, check deletions for

having the effect of impairing the quality of the re-

maining data. In the following subsection, we are go-

ing to see that this is not as straightforward as it may

seem at ﬁrst glace.

2.2 Differences

In 2.1, we have seen that the representation of prop-

erties describing logical consistency or quality is very

similar. Both can be modeled by integrity assertions.

However, there is a signiﬁcant difference between

quality and integrity. Data that lack integrity are not

just uncertain or dubious, but deﬁnitely bad, while

data the quality of which is compromised may or

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

208

may not have integrity. Essentially, the difference is

that integrity is two-valued (i.e., satisﬁed or violated),

while quality is not binary, or at least not in the sense

that imperfect data with impaired quality would al-

ways be invalid. In fact, data that violate integrity are

usually considered useless, harmful and unwanted,

while data that lack quality can still be useful.

For example, the integrity constraint

violated ← emp(x), age(x,y), y < 14

expresses that integrity is violated by underage em-

ployment (because there is a law by which this con-

straint is enforced), while the assertion

dubious ← emp(x), age(x,y), y > retirement age

expresses that overage employment qualiﬁes as dubi-

ous (since, though not forbidden, it may contradict an

employer’s general policy that a person beyond retire-

ment age would remain employed). Another example

is the integrity constraint

violated ← email(x), sent(x,y), received(x,z), y > z

which declares that integrity is violated if the sent-

date of an email item is after its received-date (assum-

ing that both x and y are normalised wrt the same time

zone). By contrast, the formula

suspect(x) ← email(x,from(y)), ∼authenticated(y)

rates an email item x received from y as suspect if the

latter cannot be authenticated, although the message

content of x may well be valid and unproblematic.

Although the same syntax can be used to represent

conditions for integrity and quality, the use of known

integrity checking methods for checking the quality of

data must be deemed problematic, if not unfeasible,

for the following reason.

All methods for efﬁcient integrity checking insist

that integrity must be satisﬁed before a given update

is checked for integrity. That way, the evaluation of

constraints can focus on the relevant part of the data

that are actually affected by the update, while the

rest can be ignored, since it is known to satisfy in-

tegrity. It would be unrealistic, however, to generalise

that insistence on total integrity satisfaction by requir-

ing that, before each update, all stored data should

comply perfectly with all quality requirements. After

all, certain defects of quality can never be excluded

with complete certainty. Thus, not all data can be as-

sumed to be of pristine quality whenever an update

needs to be checked for quality preservation. Ex-

amples of databases where quality is not perfect but

most information is useful are given by each large the-

saurus or encyclopedia (think, e.g., of Wiktionary or

Wikipedia).

In principle, a way out of this dilemma could be

to use a method that does not insists on total integrity

before each update. The only method in the litera-

ture that does not require the total satisfaction of all

constraints is the so-called brute-force method. It ex-

haustively evaluates all constraints upon each update,

without any simpliﬁcation. But brute-force evalua-

tion may be prohibilively expensive, due to the high

complexity of constraints. Another way out could be

to repair all violated constraints before or after each

update.

A more elegant and less expensive solution of us-

ing integrity checking methods for monitoring quality

assertions is presented in the following section.

2.3 Reconciliation

Inconsistency-tolerant integrity checking has been in-

troduced in (Decker and Martinenghi, 2006; Decker

and Martinenghi, 2008). In particular, it has been

shown that, contrary to common belief, many well-

known integrity checking methods, although not all

of them, can waive the requirement that each con-

sistency assertion be totally satisﬁed before updates

can be checked efﬁciently. An important feature of

inconsistency-tolerant methods is that none of their

functionality and efﬁciency is compromised by arbi-

trarily high amounts of extant constraint violations.

Since quality properties can be expressed by the

same syntax as constraints, it follows that integrity

checking methods can be used to check quality prop-

erties. In particluar, the use of inconsistency-tolerant

methods enables an efﬁcient way of evaluating such

properties even if there are data that do not fully com-

ply with all quality constraints.

Nevertheless, inconsistency-tolerant methods are

capable of detecting and rejecting each impairment of

quality assertions upon each update, no matter if the

extant imperfections are minor shortcomings or ma-

jor corruptions of data. Thus, the task of improving

the quality of damaged data can be delegated to sepa-

rate, possibly off-line processes. Such processes may

be run at any convenient point of time. In particular,

they need not be run at update time, as required by

traditional integrity checking approaches.

3 INCONSISTENCY TOLERANCE

In this section, we recap the main deﬁnitions of incon-

sistency-tolerant integrity checking (Decker and Mar-

tinenghi, 2006; Decker, 2008). Unless speciﬁed oth-

erwise, we use terminology and notations that are

conventional in the databases community (see, e.g.,

(Ramakrishnan and Gehrke, 2003)).

MODELING AND MONITORING THE QUALITY OF DATA BY INTEGRITY CONSTRAINTS AND INTEGRITY

CHECKING

209

Throughout, let ‘method’ always signify an in-

tegrity checking method. We assume that each con-

straint is represented in prenex form, i.e., an implicit

or explicit quantiﬁer precedes a quantiﬁer-freematrix.

This includes the two most common forms of repre-

senting a constraint, either as a denial (i.e., a clause

without head whose body is a conjunction of liter-

als) or in prenex normal form (i.e., quantiﬁers out-

ermost, negations innermost). An integrity theory is a

set of constraints. An update is a bipartite ﬁnite set of

database clauses to be inserted or deleted.

From now on, let the symbols D, IC, U, I and M

always denote a database, an integrity theory, an up-

date, a constraint and, resp., a method. We write D

to denote the updated database, and also refer to D

and D

as the old and the new state, respectively.

We assume that the semantics of D and IC is

given by a distinguished unique Herbrand model of

D. Thus, I is satisﬁed (violated) in D if I is true

(resp., false) in that model. As usual, IC is called

satisﬁed (violated) in D if each I ∈ IC (resp., at least

one I ∈ IC) is satisﬁed (resp., violated) in D. For

convenience, we write D(IC) = true and D(I) = true

for denoting that IC or, resp., I is satisﬁed in D, and

D(IC) = false (D(I) = false) that it is violated. ‘Con-

sistency’ and ‘inconsistency’ are synonymous with

‘satisﬁed’ and, resp., ‘violated’ integrity.

Each correct method M can be formalized as a

mapping that takes as input a triple (D,IC,U) such that

D(IC) = true, and outputs upon termination either ok

or ko. Here, ok means that M accepts U because U

does not violate any constraint, and ko means that M

does not accept U. For inconsistency-tolerant meth-

ods, the premise D(IC) = true can be waived without

penalty. For simplicity, we only consider input triples

(D,IC,U) such that the computation of M (D,IC,U)

terminates. In practice, that can always be achieved

by a timeout mechanism with output ko.

Each constraint I can be conceived as a set of

particular instances, called ‘cases’, of I, such that I

is satisﬁed iff all of its cases are satisﬁed. Thus, in-

tegrity maintenance can focus on satisﬁed cases, and

check if their satisfaction is preserved across updates.

Violated cases can thus be tolerated and possibly

dealt with at any moment that is more convenient.

That is captured by the following deﬁnition.

Deﬁnition. Inconsistency-tolerant Integrity.

a) A variable x is called a global variable in I if x

is ∀-quantiﬁed in I and ∃ does not occur left of the

quantiﬁer of x.

b) For a constraint I and a substitution ζ of its global

variables, let Iζ be obtained by replacing each global

variable in I by the term assigned to it in ζ. Each such

Iζ is called a case of I.

c) Let SC(D,IC) denote the set of all cases C of all

I ∈ IC such that D(C) = true, i.e., C is satisﬁed in D.

d) M is called inconsistency-tolerant if, for each

triple (D,IC,U), the output M (D, IC,U) = ok en-

tails that D

In words, the deﬁnition above means: If an

inconsistency-tolerant M accepts an update without

insisting that each constraint be satisﬁed before the

update, then the output ok guarantees that each case

of IC that was satisﬁed in D remains satisﬁed in D

Example. For relations p, q, let the second

column of q be subject to the foreign key con-

straint I = ∀x,y ∃z(q(x,y) → p(y,z)), which refer-

ences the primary key column of p, constrained by

′

= ← p(x,y), p(x,z), y 6= z. The global variables of

I are x and y; all variables of I

′

are global. For

U = insert q(a,b), a typical method M only eval-

uates the simpliﬁed basic case ∃z p(b,z) of I. If,

for instance, (b,b) and (b,c) are rows in p, M out-

puts ok, ignoring all irrelevant violated cases such

as, e.g., ← p(b,b), p(b,c), b 6= c and I

′

, i.e., all ex-

tant violations of the primary key constraint. M is

inconsistency-tolerant if it always ignores irrelevant

violations. M outputs ko if there is no tuple match-

ing (b,z) in p.

It is easy to see that inconsistency-tolerant in-

tegrity checking signiﬁcantly generalizes the tradi-

tional approach, which does not legitimize the use

of methods in the presence of extant constraint vio-

lations.

As shown in (Decker and Martinenghi, 2006,

2008), many known methods for integrity check-

ing are inconsistency-tolerant. The reasoning of

inconsistency-tolerant methods, and also of meth-

ods that are non inconsistency-tolerant, is featured at

length in subsection 4.2.

4 RISK MANAGEMENT

In this section, we illustrate how to use the evaluation

of assertions by integrity checking methods for mon-

itoring and managing risks.

4.1 Risks and Quality

A risk is a negative quality. Its positive counterpart

may be characterized by properties such as security,

dependability, reliability, safety and the like. Risks

can often not be totally excluded, while it is always

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

210

requisite to minimize and to control them for lowering

their probability to increase.

Of course, the amount of tolerable risk depends

on the application and often also on its users (think,

e.g., of stock market transactions). The example elab-

orated in 4.2 is open to interpretation. By assign-

ing convenient meanings to predicates, it could be in-

terpreted as a risk model of, e.g., ﬁnancial services

(think, e.g., of Basel II), or a nuclear power plant.

4.2 An Extended Example

Of course, a single example can always be criticized

to be statistically irrelevant. However, for each of the

mentioned alternatives, several typical features that

are independent of the particular example are illus-

trated. In particular, we are going to see that, for

safety-critical applications, the use of a method that

is inconsistency-tolerant is more dependable than to

use one which is not. Our example will show that

using a non-inconsistency-tolerant method for moni-

toring risks may have fatal consequences.

We are going to compare inconsistency-tolerant

integrity checking with the following alternative ap-

proaches to monitor risk: brute-force evaluation, non-

inconsistency-tolerant integrity checking, repairing,

and consistent query answering (Arenas et al., 1999).

In detail, we address the following points 1) - 6).

1) The cost of the brute-force method.

2) The cost of inconsistency-tolerant methods.

3) The dependability of methods.

4) The cost of repairing the old state.

5) The cost of repairing the new state.

6) The risk of consistency query answering.

Let us consider a database D whith the following

deﬁnitions of view predicates rl, rm, rh that model

risks of low, medium and, respectively, high degree.

rl(x) ← p(x, x)

rm(y) ← q(x,y), ∼p(y,x)

rm(y) ← p(x, y), q(y,z), ∼p(y,z), ∼q(z,x)

rh(z) ← p(0, y), q(y,z), z > th

In the clause deﬁning rh, let th be a evaluable

threshold value that we assume to be always greater

or equal 0. Now, let the risks be denied as in the fol-

lowing integrity theory:

IC = {← rl(x), ← rm(x), ← rh(x)}.

Before populating D with facts about p and q, let

us verify that IC is satisﬁable at all by any etension of

D. Indeed, it is, e.g., by each extension of p such that

no fact of the form p(0,y) is in p and any of the fol-

lowing alternatives holds: either p = q, or D contains

{q(2,1), p(1,2), p(2,1)} and arbitrarily many facts of

the form p(n,n+ m), for n > 1, m > 0.

Now, let the extensions of p and q be as follows.

p(0,0), p(0,1), p(0,2), p(0,3), .. ., p(0, 10000),

p(1,2), p(2, 4), p(3,6), p(4,8),. .., p(5000, 10000)

q(0,0), q(1,0), q(3,0), q(5,0), q(7,0),..., q(9999,0)

Clearly, there is a single violated low-risk case in

D, which is caused by p(0,0). Let us make sure that

there is no other violated risk case in D, but trying to

refute each denial about rl, rm and rh.

First of all, there obviously is no other low-risk

cause of form p(x,x) that would violate ← rl(x).

Next, let us try to ﬁnd an instance of the body of

the ﬁrst clause of rm that would be true in D. Since

the second column of q is always 0, q(x,0),∼p(0,x),

would have to be true. That, however, cannot be,

since p(0,x) /∈ D for each x such that q(x, 0) ∈ D.

For trying to ﬁnd a satsiﬁed instance of the body of

the second clause of rm, let e stand for an even num-

ber greater or equal 0, o for an odd number greater or

equal 1, and n for any natural number greater or equal

0. Further note that each p-fact in D is either of the

form p(0,e) or p(0,o) or p(n,2n), for n > 1. So, since

the second column of p joins with the ﬁrst column of

q only if their value is an even number, the only possi-

ble instances of that clause which could make its body

true are of one of the following three forms:

p(0, e), q(e,z), ∼p(e, z), ∼q(z,0)

p(0,o), q(o,0), ∼p(o,0), ∼q(0, 0)

p(n,2n), q(2n,0), ∼p(2n,0), ∼q(0,n)

Obviously, none of these instances can become

true, because q(e,z) does not hold for any z, q(0, 0)

is true in D, and q(2n,0) is false for each n > 0.

Last, the clause of rh: to make its body true would

require that 0 > th, but we have excluded that. Hence,

we have veriﬁed that ← rl(0) is the only violated risk

case of IC in D, and that p(0,0) is its only cause.

Now, consider U = insert q(0,9999), for illustrat-

ing 1) - 6) above.

1) The cost of brute-force checking for any up-

date is high. That is a commonplace, but let us see in

some more detail to what brute-force evaluation of IC

amounts, for later comparison.

Evaluation of ← rl(x) involves a scan of all of

p. Evaluation of ← rm(x) involves joins of p and q,

a join of local p with remote q, plus possibly many

lookups in p and q. Evaluation of ← rh(x) involves

a join of local p with remote q, plus the evaluation of

MODELING AND MONITORING THE QUALITY OF DATA BY INTEGRITY CONSTRAINTS AND INTEGRITY

CHECKING

211

possibly many ground expressions of the form z > th.

With large extensions of p and q, the evaluation

steps outlined above may last too long, particularly if

safety-critical risks are monitored in real time. In the

following point, we shall see that it is far less expen-

sive to use an inconsitency-tolerant method that sim-

pliﬁes the evaluation of integrity constraints by taking

the update into account and by limiting its focus on

the data that are affected by the update.

2) We are going to see that the cost of

inconsistency-tolerant integrity checking of U is

much lower than to use brute-force evaluation. But,

before we go into details, recall that the use of any

traditional method that insists on the satisfaction of

IC in the old state D is prohibited for the database in

our example, since D(IC) = false.

Typical simpliﬁcation methods compile pre-

simpliﬁcations for update patterns at constraint

speciﬁcation time. Thus, the cost of such pre-

simpliﬁcations at update time is nil. U matches the

update pattern q(a,b), which in turn matches pre-

cisely the following unfoldings of ← rm by the two

clauses deﬁning rm, and of ← rh, respectively.

← q(x, y), ∼p(y,x)

← p(x,y), q(y,z), ∼p(y,z), ∼q(z,x)

← p(0, y), q(y,z), z > th

Thus, the pre-simpliﬁcations complied for the pat-

ter for insertions of facts of the form q(a,b), are as

follows.

← ∼p(b,a)

← p(x,a), ∼p(a,b), ∼q(b,x)

← p(0, a), b > th

Substituting (a,b) by the inserted values (0,9999)

at update time yields the following simpliﬁcations.

← ∼p(9999,0)

← p(x,0), ∼p(0,9999), ∼q(9999,x)

← p(0, 0), 9999 > th

By a simple lookup of p(9999,0) for evaluating

the ﬁrst of the three denials, it is inferred that ← rm is

violated.

Since a medium risk has been detected, there is in

principle no need to continue checking the remaining

two simpliﬁed denials. However, we are going to do

that, in order to build a bridge to point 3).

Evaluating the second denial from left to right

amounts to the cost of answering the query ← p(x, 0).

The single answer is x = 0. Then, a lookup of

q(9999,0) succeeds. Hence, the second denial is true,

which means that there is no further medium risk.

Since p(0, 0) is true, the third denial turns out to

be violated if 9999 > th holds, thus indicating a high

security risk.

To summarize this point: Inconsistency-tolerant

integrity checking of U essentially costs a simple ac-

cess to the p relation. Moreover, if all constraints are

evaluated evenafter some violation has been detected,

only an additional simple lookup is needed. And,

perhaps more importantly, inconsistency-tolerant in-

tegrity checking prevents medium- and high-risk vio-

lations that would be caused by the update if it were

not rejected.

3) Inconsistency-tolerant checking is dependable,

non-inconsistency-tolerant checking is not. This

claim is conﬁrmed by considering the following kind

of reasoning, as performed by methods that are not

inconsistency-tolerant. Such methods are speciﬁed,

e.g., in (Gupta et al., 1994; Lee and Ling, 1996).

Since the p relation is not affected by U, the truth

value of the unfolding ← p(x,x) of the constraint

← rl(x) is the same in D. Since each method that is

not inconsistency-tolerant insists on the premise that

all constraints be satisﬁed in the old state, such meth-

ods, when applied to our example, conclude that the

unfolded denial ← p(x,x) is true in D and D

, even

though p(0,0) ∈ D. That conclusion is then applied to

the third of the simpliﬁed unfoldings from 2), which

is reprinted below, for convenience.

← p(0,0), 9999 > th

The subsumption-based reasoning of methods that

are not inconsistency-tolerant can be summarized as

follows: Applying the premise that ← p(x,x) is satis-

ﬁed to ← p(0,0),9999 > th infers that the latter also

remains satisﬁed in D

, because it is subsumed by

← p(x,x). Thus, non-inconsistency-tolerant integrity

checking wrongly concludes that the high risk con-

straint ← rh(z) is not violated in D

4) Now, we are going to see that repairing the old

state is costly. Recall that the traditional integrity

checking approach insists on total constraint satis-

faction in the old state. This means that all extant

violations need to be repaired before each update.

In general, the identiﬁcation of all extant constraint

violations may already be very expensive in large

databases, and indeed unaffordable at update time.

Fortunately, however, there is only a single low-

risk constraint violation in our example, as we have

already seen before: p(0,0) is the only cause of the

only constraint violation ← rl(0) in D. Thus, to repair

D means to ﬁrst delete p(0, 0), and then check if that

preserves all assertions.

To check delete p(0,0) for integrity means to

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

212

check the simpliﬁed denials

← q(0,0)

and

← p(x,0), q(0,0), ∼q(0,x)

obtained from resolving ∼p(0,0) with the bodies of

the two clauses deﬁning rm, since precisely those two

clauses are affected by the deletion of p(0,0). Hence,

no constraint other than ← rm(y) is potentially vio-

lated by the intended repair.

Of the two simpliﬁed denials above, the second

one clearly is satisﬁed in D

, since no fact of the form

p(x,0) remains in the database after p(0,0) is deleted.

However, the ﬁrst one is violated, since q(0,0) is true

in D

. Hence, another repair action is needed. The

obvious candidate is delete q(0,0).

To delete q(0, 0) affects

rm(y) ← p(x, y), q(y,z), ∼p(y,z), ∼q(z,x)

and yields the simpliﬁed check of

← p(0, y), q(y,0), ∼p(y,0).

Obviously, this denial is violated by all facts in D

that are of the form p(0,o) and q(o, 0), where o is an

odd number in the interval [1,9999]. Thus, to delete

q(0,0) for repairing the violation caused by deleting

p(0,0) causes the violation of each case of the form

← rm(o), for each odd number o in [1,9999].

Clearly, many facts about p or q would have to be

deleted in order to repair each of these violated cases.

For simplicity, we won’t follow them through, since

the point that repairing D is very complexand tends to

be much more expensive than inconsistency-tolerant

integrity checking has become obvious already. We

only recall the big advantage of inconsistency-tolerant

integrity checking that repair actions do not have to

take place at update time. Instead, they can be taken

off-line, at any convenient moment.

5) Also repairing the new state is more costly than

to simply tolerate extant constraint violations until

they can be repaired at some better moment. In our

example, this becomes obvious by recalling from 1)

that, in D

, there are three violated cases: thelow-risk

case that is already violated in D and the medium- and

high risk cases as detected by inconsistency-tolerant

integrity checking. To repair them is indeed even

more complicated than to only repair the violated low-

risk case, as attempted in 4).

Moreover, it should be noted for risk management

that it is no good idea in general to simply accept an

update without checking for potential violations of

constraints, and to attempt repairs only after the up-

date is committed, because repairing takes time, dur-

ing which an updated but unchecked state may con-

tain malicious risks of any order.

6) Consistent query answering in inconsistent

databases (CQA) is a popular approach to cope with

extant constraint violations for query answering (Are-

nas et al., 1999). Although query answering is

not the topic of this paper, a connection between

inconsistency-tolerant integrity checking and CQA

can easily be drawn, because the monitoring of qual-

ity constraints involves the evaluation of such con-

straints or their simpliﬁcations. Thus, the idea may

arise to use CQA for evaluating constraints as queries,

in order to avoid wrong answers hat could be due to

extant constraint violations.

However,to evaluate constraints or simpliﬁcations

thereof by CQA is not recommendable, because con-

sistent answers are deﬁned to be those that are true in

each minimally repaired state of the datbase. Thus,

for each queried constraint, CQA will by deﬁnition

return the empty answer, which indicates the satis-

faction of the constraint. Thus, answers to queried

constraints that are computed by CQA have in fact no

meaningful interpretation.

For instance, CAQ computes the empty answer to

the query ← rl(x) as well as to the query ← rh(z),

for any extension of the relations p and q. However,

the only sensibly correct answer to the ﬁrst query in

D is x = 0. Similarly, the only reasonable answer

to the second query in D

is x = 9999, assuming

that 9999> th. These answers are reasonable because

they correctly indicate risks contained in D and D

respectively.

This shows that, despite of many unquestionable

merits of CQA, it should not be used for monitoring

quality, if quality is modeled by integrity constraints.

5 RELATED WORK

Although database quality and database integrity are

intuitively related, they never have been approached

in a uniform manner, to the best of our knowledge,

neither in theory nor in practice.

Kinships and semantic differences between data

that have or lack quality, and data that have or violate

integrity are observed, in a collection of work on mod-

eling and managing uncertain data (Motro and Smets,

1996). In that book, largely diverse approaches to

handle data that lack quality are proposed. In par-

ticular, approaches such as probabilistic and fuzzy set

modeling, exception handling, repairing and paracon-

sistent reasoning are discussed. However, no particu-

lar approach to integrity checking is considered.

Integity checking also has never been addressed in

detail by related work on consistent query answering

in inconsistent databases (Arenas et al., 1999).

MODELING AND MONITORING THE QUALITY OF DATA BY INTEGRITY CONSTRAINTS AND INTEGRITY

CHECKING

213

Moreover, several paraconsistent logics that toler-

ate inconsistency and quality impairment of data have

been proposed, e.g., in (Decker et al., 2002; Bertossi

et al., 2005). Each of them, however, departs from

classical ﬁrst-order logic, by adopting some anno-

tated, probabilistic, modal or multivalued logic, or by

eliminating and replacing standard axioms and infer-

ence rules with non-standard axiomatizations. As op-

posed to that, inconsistency-tolerant integrity check-

ing fully conforms with standard two-valued datalog

and does not need any extension of classical logic.

Further work on the management of inconsisten-

cies in databases is going on in the ﬁeld of measur-

ing inconsistency (Grant and Hunter, 2006; Decker,

2009). Inconsistency measures can be used for a

form of inconsistency-tolerant integrity checking that

is different from the approach outlined in section 3.

It accepts an update only if the measured amount of

inconsistency in the old state does not increase in the

new state. There are several possible ways to measure

inconsistency. Two that are directly related to sec-

tion 3 are to count the number of violated cases, or to

compare the set of violated cases before and after the

update (Decker and Martinenghi, 2008). In (Decker,

2009), some more measures related to inconsistency-

tolerant integrity checking are discussed.

6 CONCLUSIONS

We have shown that the quality and the integrity

of stored data can be modeled and monitored in a

straightforward, uniform manner. Conditions that

capture properties of data quality and integrity can

both be modeled by database assertions.

Traditionally, no method for simpliﬁed integrity

checking has tolerated as input a database that is in-

consistent with its constraints. However, as shown in

(Decker and Martinenghi, 2006, 2008), it is possible

to waive that restriction. Hence, quality and integrity

assertions, the occasional violation of which is toler-

able, can be monitored efﬁciently by inconsistency-

tolerant constraint checking methods.

It is important to note that, for achieving incon-

sistency tolerance, no re-implementation or extension

of any existing method that can be shown to have that

property is needed. As illustrated in the extended

example of this paper, inconsistency tolerance is es-

sential, since wrong, possibly fatal conclusions can

be inferred from deﬁcient data by using a method

that is not inconsistency-tolerant. Many methods

that are inconsistency-tolerant, and also some that are

not, have been identiﬁed in (Decker and Martinenghi,

2006, 2008).

Ongoing work is concerned with establishing a

closer relationship of inconsistency-tolerant integrity

checking with the ﬁelds of repairing, consistent query

answering and inconsistency measuring.

REFERENCES

Arenas, M., Bertossi, L. E., and Chomicki, J. (1999). Con-

sistent query answers in inconsistent databases. In

Proceedings of PODS, pages 68–79. ACM Press.

Bertossi, L., Hunter, A., and Schaub, T. (2005). Inconsis-

tency Tolerance, volume 3300 of LNCS. Springer.

Bowen, K. and Kowalski, R. A. (1982). Amalgamating lan-

guage and metalanguage. In Clark, K. and T¨arnlund,

S.-A., editors, Logic Programming, pages 153–172.

Academic Press.

Decker, H. (2008). Inconsistency-tolerant integrity check-

ing for knowledge assimilation. In Filipe, J., Shishkov,

B., Helfert, M., and Maciaszek, L., editors, Software

and Data Technologies, volume 22 of CCIS, pages

320–331. Springer.

Decker, H. (2009). Quantifying the quality of stored data

by measuring their integrity. Submitted.

Decker, H. and Martinenghi, D. (2006). A relaxed approach

to integrity and inconsistency in databases. In Her-

mann, M. and Voronkov, A., editors, Proc. 13th LPAR,

volume 4246 of LNCS, pages 287–301. Springer.

Decker, H. and Martinenghi, D. (2008). Classifying in-

tegrity checking methods with regard to inconsistency

tolerance. In Proceedings of the 10th ACM SIGPLAN

conference on Principles and Practice of Declarative

Programming, pages 195–204. ACM Press.

Decker, H., Villadsen, J., and Waragai, T., editors (2002).

Proceedings of the ICLP 2002 workshop on Paracon-

sistent Computational Logic, volume 95 of Datalo-

giske Skrifter. Roskilde University, Denmark.

Grant, J. and Hunter, A. (2006). Measuring inconsistency

in knowledgebases. Journal of Intelligent Information

Systems, 27(2):159–184.

Gupta, A., Sagiv, Y., Ullman, J. D., and Widom, J. (1994).

Constraint checking with partial information. In Pro-

ceedings of PODS 1994, pages 45–55. ACM Press.

Lee, S. Y. and Ling, T. W. (1996). Further improvements on

integrity constraint checking for stratiﬁable deductive

databases. In VLDB’96, pages 495–505. Kaufmann.

Motro, A. and Smets, P. (1996). Uncertainty Manage-

ment in Information Systems: From Needs to Solu-

tions. Kluwer.

Ramakrishnan, R. and Gehrke, J. (2003). Database Man-

agement Systems. McGraw-Hill.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

214
