ON ALIGNING INTERESTING PARTS OF ONTOLOGIES

Christos Tatsiopoulos, Basilis Boutsinas

Department of Business Administration, University of Patras, Artificial Intelligence Research Center, 26500, Rio, Greece

Konstantinos Sidiropoulos

School of Engineering and Design, Brunel University West London, Uxbridge, Middlesex, UB8 3PH, London, U.K.

Keywords: Ontology Merging, Ontology Alignment.

Abstract: Ontology merging/alignment is one of the most important tasks in ontology engineering. It is imposed by

the decentralized nature of both the WWW and the Semantic Web, where heterogeneous and incompatible

ontologies can be developed by different communities. Usually, ontology merging/alignment is based on an

ontology mapping that has been established in a previous phase. In this paper, we define a new problem

within the alignment process: the problem of detecting and then updating only interesting parts of an

ontology, based on the knowledge included in another one. To this end, we define and evaluate a number of

different measures of interestingness of parts of ontologies. We also present experimental results for their

evaluation on test ontologies.

1 INTRODUCTION

Ontologies are used to handle complex situations,

due to the continuous growth of the Semantic Web,

where they are used to describe the semantics of the

data. Due to the decentralized nature of both the

WWW and the Semantic Web, it is inevitable that

different communities within the so-called

information society represent and treat the same

basic concepts in different ways. For example, the

basic concept ``Person" is treated entirely differently

in a medical ontology than in a business one. The

need for merging/alignment arises when such

ontologies have to be integrated.

In this paper, we consider the task of aligning

source ontologies, which may use different

vocabularies and may have overlapping content.

More specifically, we define a new problem within

the alignment process: the problem of updating each

one of the source ontologies using the knowledge

included in the other but the update is performed

only to the parts of each source ontology which are

considered interesting by its designer. Of course,

updating is taking place if the knowledge included in

the interesting parts of the one ontology is a superset

of knowledge included in the interesting parts of the

ontology to be updated.

All merging and alignment techniques presented

in the literature (such as Chimaera, FCA-Merge,

PROMPT, Ontomorph, OntoDNA) consider

merging or alignment of the entire input ontologies.

The key ideas of any of them could be applied to the

alignment of interesting parts after the latter have

been located.

We reduce the problem to automatic detection of

the interesting parts based only on the structure of

the ontology and not to any user input. This problem

is important for agent oriented applications of

ontologies, whenever an agent need to update its

knowledge from other agents. In this paper, we

define and evaluate a number of different measures

of interestingness of parts of ontologies. The term

"interestingness" was first used in data mining as a

measure of how much interesting an extracted data

mining rule is, with respect to a user judgement.

"Entropy" and "support" are such measures of

interestingness.

There is not any generally accepted definition of

interestingness. In fact, each of the proposed

measures concerns a different aspect of what

"interestingness" in ontologies could mean. Note

that the proposed measures exploit only the structure

of the source ontologies. Thus, the proposed

measures are application independent.

363

Tatsiopoulos C., Boutsinas B. and Sidiropoulos K. (2009).

ON ALIGNING INTERESTING PARTS OF ONTOLOGIES.

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development, pages 363-367

 SciTePress

Interestingness of concepts within an ontology

has already been explored. The DIaMOND plug-in

for Protégé (d’Entremont and Storey, 2006) defines

interestingness based on user’s browsing activities.

It continuously calculates the degree of interest for

each concept by tracking user’s navigation activities

on an ontology. In (Tu, et al., 2005) the importance

of concepts is used in filtering large scale ontologies

in order to obtain efficient visualizations of them.

More specifically, the importance of a concept is

calculated as a weighted combination of the depth of

the concept in the ontology and the sum of the

importance of its direct child nodes. In (Wu, et al.,

2008) interestingness is defined for both concepts

and relations based on the structure of the ontology:

1) a concept is more important if there are more

relations starting from the concept, 2) a concept is

more important if there is a relation starting from the

concept to a more important concept, 3) a concept is

more important if it has a higher relation weight to

any other concept and 4) a relation weight is higher

if it starts from a more important concept.

In the rest of the paper we first present the

proposed measures of interestingness (Section 2)

along with their evaluation on test ontologies

(Section 3). Finally, we conclude (Section 4).

2 THE PROPOSED

INTERESTINGNESS

MEASURES

We consider that the alignment of interesting parts

of two source ontologies follows a mapping process,

where correspondences between elements of the

source ontologies are established (see for instance

Doan et al., 2002, Giunchiglia et al., 2004, Hovy,

1998, Kalfoglou and Schorlemmer, 2002,

McGuinness et al., 2000, Noy and Musen, 2000,

Prasad et al., 2002, Stumme and Maedche, 2001,

Tang et al., 2006, Tatsiopoulos and Boutsinas,

2009).

Given such a mapping and a set of interesting

parts for each source ontology, an alignment

algorithm could be used in order to make the

interesting parts of ontology O

consistent and

coherent with ontology O

. Of course, such

alignment is applied if O

represents more

knowledge than O

, as far the interesting parts of the

latter is concerned.

The contribution of this paper concerns the step

of the identification of interesting parts. Any

mapping and alignment algorithms could be used. In

what follows we define some measures of

interestingness. They are all based on the structure

of the ontology. Note that we have investigated

several others. However the proposed ones exhibit

significant results during empirical tests.

Figure 1: The test ontology.

The proposed measures can be applied to

ontology structures forming a directed acyclic graph.

Thus, it supports multiple inheritance. The required

formal definition of input ontologies contains two

core items shared by most formal definitions of an

ontology in the literature: concepts and a

hierarchical IS-A relation. Thus, we define an

ontology as a pair G=(C,r), where C is a set of

concepts and r is a partial order on C, i.e. a binary

relation rCC which is reflexive, transitive, and

antisymmetric.

The proposed measures are all based on

detecting interesting concepts within an ontology.

Then, we consider interesting parts of the ontology

the subgraphs rooted at these interesting concepts.

Thus, the following measures assign a value to each

concept representing its interestingness:

1) Percentage Direct Child Nodes (rel_cD%): the

number of nodes which are directly connected to a

specific node, as percentage of the number of nodes

in the ontology. Note that the higher is the value of

the measure for a node, the greater is its

interestingness. For example, in ontology shown in

Fig. 1, node oo250 (value=10.71%) is more

interesting than oo180 (value=0%) or even oo40

(value=7.14%), since it has more direct child nodes.

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

364

2) Percentage Indirect Child Nodes (rel_cI%):

the number of nodes in the subgraph rooted at a

specific node, as percentage of the number of nodes

in the ontology. Note that the higher is the value of

the measure for a node, the greater is its

interestingness. For example, node ooo95

(value=42.86%) is more interesting than oo185

(value=14.29%), since there are more nodes in the

subgraph rooted at ooo95. Also, now node ooo40

(value=64.29%) is more interesting than oo250

(value=14.29%) for the same reason. Note that in an

ontology with a deep concept structure, very general

concepts (owl:Thing in the extreme case) would get

higher value than very specific ones. One could

claim that a specific concept is the interesting one,

not the fact that something is an owl:Thing.

However, we consider interesting parts those rooted

at interesting concepts. Thus, according to rel_cI%,

large subgraphs are more interesting than smaller

ones, either the latter are disjoin or subsubgraphs.

Note that in implementation level interesting

concepts are searched within concepts with level

greater than a threshold t, i.e., l(i)>t.

3) Percentage Brother Nodes (rel_b%): the

number of Direct Child Nodes of the father node(s),

i.e., of immediate ancestor(s), of a specific node, as

percentage of the number of nodes in the ontology.

Note that the higher is the value of the measure for a

node, the greater is its interestingness. For example,

node oo250 (value=7.14%) is more interesting than

node oo180 (value=3.57%) and node ooo90

(value=3.57%), since it has more brother nodes

having both oo175 and oo170 as father nodes.

4) Mean Distance of Brother Nodes (mdisbr): the

mean distance of a specific node from its Brother

Nodes. The distance of two nodes d(x,y) is

calculated using the dissimilarity measure presented

in (Boutsinas and Papastergiou, 2008). The

dissimilarity between any two attribute values is

repesented by the distance between the

corresponding nodes of the tree structure as defined

by the following formula: d(X,Y) = 1/fl(X,Y) *

Average((l(X)-fl(X,Y))/max(p(X), (l(Y)-fl(X,Y))/

max(p(Y))) * ( p(X,Y)/ (max(p(X))+max(p(Y))),

where X and Y represent any two nodes, fl(X,Y) is

the level of the nearest common father node of X

and Y nodes, i.e. the level of the nearest common

predecessor, l(X) is the level of node X, i.e. the

depth of the node, max(p(X)) is the length of the

maximum path starting from the root to a leaf and

containing node X, p(X,Y) is the length of the

directed path (number of edges) connecting X and Y

(p(X,X)=0). If there is not a path connecting X and

Y then p(X,Y)=p(X,fl(X,Y))+p(Y,fl(X,Y)).

Mean Distance of Brother Nodes is calculated by

the following algorithm:

for each Brother Node i of node j

calculate d(i,j)

set count+=1, dsum+=d(i,j)

return dsum/count

Note that the lower is the value of d(X,Y) the

greater is the interestingness. For example, node

oo110 (value=0.003%) is more interesting than node

oo610 (value=0.0115%), since its father node is

located deeper in the ontology. Finally, note that

similarity (1-mdisbr) could be used instead of

dissimilarity, for compatibility with the rest

measures.

5) Network Density of range k (nden(k)):

Network Density of range k of a specific node i is

the number of nodes that are connected to or can

be reached from i, via a path of length at most k,

which does not include direction changes. Note that

we have implemented the calculation of nden(k)

dynamically. Note that the higher is the value of the

measure for a node, the greater is its interestingness.

For example, for node oo610 nden(2)=4, since there

are 2 ancestor nodes (ooo40, ooo50) and two

successor ones (oo650,oo700). Thus, it is more

interesting than node oo110 (nden(2)=2).

6) Percentage Incoming Paths (in%): the

indegree (d

(i)) of a node i, i.e., the number of edges

which have i as their end-node, as percentage of the

total incoming and outcoming paths, i.e., of indegree

plus outdegree of i. Note that the higher is the value

of the measure for a node, the greater is its

interestingness. For example, node ooo90

(value=66.67%) is more interesting than node oo250

(value=40%).

7) Percentage Outcoming Paths (out%): the

outdegree (d

out

(i)) of a node i, i.e., the number of

edges which have i as their start-node, as percentage

of the total incoming and outcoming paths, i.e., of

indegree plus outdegree of i. Note that the higher is

the value of the measure for a node, the greater is its

interestingness. For example, node oo250

(value=60%) is more interesting than node oo90

(value=33.33%).

8) Percentage Level distribution (n_l(i)%): Level

distribution of a specific node i is the number of

nodes belonging to the level of node i, i.e., l(i), (i.e.,

the length of the maximum path -number of edges-

from the root to node i), as percentage of the number

of nodes in the ontology. Note that the higher is the

value of the measure for a node, the greater is its

interestingness. For example, there are 4 nodes on

the same level with node oo100 (value=14.3%)

which is more interesting than node oo250

(value=10.7%), since there are 3 nodes on its level.

ON ALIGNING INTERESTING PARTS OF ONTOLOGIES

365

3 EMPIRICAL RESULTS

Empirical tests aim at evaluating the defined

interestingness measures on test ontology G

shown

in Fig. 1. It is constructed with respect to Gene

Ontology (http://www.geneontology.org/). Node

naming is compatible with Gene Ontology.

To evaluate the defined measures we used a node

ranking with respect to their interestingness, defined

by a human expert (a researcher of the Institute for

Language & Speech Processing http://www.ilsp.gr).

The values for all the measures, along with expert's

ranking (column H) are presented in Fig. 2. Note

that expert's ranking assigns "1" to the most

interesting ("0" is assigned only to root node).

Figure 2: Summarized results.

For instance, nodes oo100, ooo95, and oo250 are

of great interestingness to the human expert, with

oo100 to be the most interesting and then the ooo95,

and the oo250.

After testing several test ontologies, like the one

in Fig. 1, we can conclude that many measures

assign interestingness in a way that reflects expert's

first choices.

Moreover, some measures discover additional

interesting nodes. For instance, both the n_l(i)% and

the out% measure identify both oo100 and oo170 as

interesting, assigning the value 14.3% & 66.67%

respectively. This result was returned to the expert

for additional comments. Then, this result was

accepted as valid according to expert's criteria.

However, some other measures have not provided

successful results in a consistent manner.

4 CONCLUSIONS

We defined a new problem within the alignment

process: the problem of aligning only interesting

parts of ontologies. To tackle the problem we

defined and evaluated a number of different

measures of interestingness of parts of ontologies,

each one representing different semantics of

interestingness.

Despite the support or the controversy of the

statement that ontology mapping/alignment is

similar to database schema matching/integration

(Kalfoglou and Schorlemmer, 2003, Noy and Klein,

2004), the proposed measures could be applied to

both of them.

We are now working on an integration of the

different measures, for instance by introducing a

unified model as a function of them: f(w

rel_cD,

..., w

n_l(i)), where w

is a weight. Preliminary

results show that a different unified model is needed

for each different type of structure. For instance, a

unified model of the form w1rel_cD% +

w2rel_cI% + w3rel_b% + w4mdistr +

w5nden[2] + w6in% + w7out% + w8n_l(i)%

results in almost 100% accuracy w.r.t. expert, for

shallow ontologies, where w1 ranges between 0-60,

w2 0-55, w3 0-80, w4 0-95, w5 0-90, w6 0-100, w7

0-45 and w8 0-80.

Moreover, we are now working on taking into

consideration the linguistic analysis of concepts

represented by the nodes with respect to a corpus of

documents or the WWW. More specifically, we are

investigating the use of term weighting techniques

adopted in text mining (such as Document

Frequency, mean TFIDF, Term Frequency Variance,

etc.).

Finally, we are working on applying the

proposed measures for detection of interesting parts

to a system for knowledge transferring between

mobile phones storing ontologies and holding by

tourists.

REFERENCES

Boutsinas, B., Papastergiou, T., 2008. On clustering tree

structured data with categorical nature, Pattern

Recognition, Elsevier Science, 41, pp. 3613-3623.

d’Entremont, T., Storey, M.-A., 2006. Using a degree-of-

interest model for adaptive visualizations in protégé,

9th International Protégé Conference.

Doan, A., Madhavan, J., Domingos, P., Halevy, A., 2002.

Learning to map between ontologies on the semantic

web, Proceedings of the 11th International World

Wide Web Conference (WWW 2002), pp. 303-319.

Giunchiglia, F., Shvaiko, P., Yatskevich, M., 2004. S-

Match: an Algorithm and an Implementation of

Semantic Matching, Proceedings of 1st European

Semantic Web Symposium, pp. 61-75.

KEOD 2009 - International Conference on Knowledge Engineering and Ontology Development

366

Hovy, E., 1998. Combining and Standardizing Large-

Scale, Practical Ontologies for Machine Translation

and Other Uses, Proceedings of the 1

International

Conference on Language Resources and Evaluation

(LREC), Granada, Spain, pp. 535-542.

Kalfoglou, Y., Schorlemmer, M., 2003. Ontology

Mapping: the State of the Art, The Knowledge

Engineering Review, 18(1), 2003, pp. 1-37.

Kalfoglou, Y., Schorlemmer, M., 2002. Information-flow-

based ontology mapping, LNCS 2519, pp. 1132–1151.

McGuinness, D.L., Fikes, R., Rice, J., Wilder, S., 2000.

An Environment for Merging and Testing Large

Ontologies, Proceedings of the Seventh International

Conference on Principles of Knowledge,

Representation and Reasoning (KR2000),

Breckenridge, Colorado, pp. 483-493.

Noy, N.F., Klein, M., 2004. Ontology evolution: not the

same as schema evolution, Knowledge and

Information Systems, 6(4), pp. 428-440.

Noy, N.F., Musen, M., 2000. PROMPT: algorithm and

tool for automated ontology merging and alignment,

Proceedings of the 17th National Conference on

Artificial Intelligence and 12th Conference on

Innovative Applications of Artificial Intelligence, pp.

450-455.

Prasad, S., Peng, Y., Finin, T., 2002. Using Explicit

Information To Map Between Two Ontologies,

Proceedings of the Workshop on Ontologies in Agent

Systems, Bologna, Italy, Vol. 66, pp. 52-56.

Stumme, G., Maedche, A., 2001. Ontology Merging for

Federated Ontologies on the Semantic Web,

Proceedings of the International Workshop for

Foundations of Models for Information Integration,

Viterbo, Italy.

Tang, J., Li, J., Liang, B., Huang, X., Li, Y., Wang, K.,

2006. Using Bayesian decision for ontology mapping,

Journal of Web Semantics, 4(4), pp. 243–262.

Tatsiopoulos, C., Boutsinas, B., 2009. Ontology Mapping

based on association rule mining, 11th International

Conference on Enterprise Information Systems, Milan

Italy.

Tu, K., Xiong, M., Zhang, L., Zhu, H., Zhang, J., Yu, Y.,

2005. Towards imaging largescale ontologies for

quick understanding and analysis, LNCS 3729.

Wu, G., Li, J., Feng, L., Wang, K., 2008. Identifying

Potentially Important Concepts and Relations in an

Ontology , Intern. Semantic Web Conf., pp.33-49.

ON ALIGNING INTERESTING PARTS OF ONTOLOGIES

367
