NEURONS OR SYMBOLS
Why does OR Remain Exclusive?
Ekaterina Komendantskaya
School of Computer Science, University of St Andrews, U.K.
Keywords:
Computational logic in neural networks, Neuro-symbolic networks, Connectionism, Hybrid networks.
Abstract:
Neuro-Symbolic Integration is an interdisciplinary area that endeavours to unify neural networks and symbolic
logic. The goal is to create a system that combines the advantages of neural networks (adaptive behaviour,
robustness, tolerance of noise and probability) and symbolic logic (validity of computations, generality, higher-
order reasoning). Several different approaches have been proposed in the past. However, the existing neuro-
symbolic networks provide only a limited coverage of the techniques used in computational logic. In this
paper, we outline the areas of neuro-symbolism where computational logic has been implemented so far, and
analyse the problematic areas. We show why certain concepts cannot be implemented using the existing
neuro-symbolic networks, and propose four main improvements needed to build neuro-symbolic networks of
the future.
1 INTRODUCTION
The joint efforts of researchers in many areas have
given many insights on how logic and neuroscience
can relate
1
: Boolean (binary) networks can com-
pute logical connectives (McCulloch and Pitts, 1943;
Aleksander and Morton, 1993); binary threshold net-
works can simulate Finite Automata, (Universal) Tur-
ing machines can be simulated by neural networks
with rational weights (Siegelmann, 1999).
The natural question that arises is how neural net-
works can cope with logical theories and calculi. The
traditional approach developed by neuro-symbolic
community is based upon McCulloch and Pitts binary
neural networks and encodes the semantics of first-
order logic theories in neural networks. The books
(d’Avila Garcez et al., 2002; d’Avila Garcez et al.,
2008) and papers (Bader et al., 2008; Domingos,
2008; H¨olldobler et al., 1999; Lange and Dyer, 1989;
Hitzler et al., 2004; Wang and Domingos, 2008) are
good examples of this approach. We discuss here
why this kind of view has not yet resulted in a neuro-
symbolic system that successfully implements algo-
rithms of computational logic.
1
The title of this position paper is inspired by the book
”Neurons and Symbols”, (Aleksander and Morton, 1993),
that claimed, rather convincingly, that neural and symbolic
approaches to computation and information processing can
be considered as two complementary sides of one machine.
Throughout this paper, we make one subtle dis-
tinction between the levels of abstraction one uses
when speaking about relations between logic and neu-
ral networks. The most fundamental results relating
logic and neural networks, such as papers by McCul-
loch and Pitts (McCulloch and Pitts, 1943), Kleene
(Kleene, 1956), books by von Neumann (Neumann,
1958) and Minsky (Minsky, 1954; Minsky, 1969),
considered neural networks at the level of automata
and computing machines, showing that the neural net-
works, taken as a hardware, can simulate computa-
tions performed by digital computers.
This line of research has been successfully devel-
oped. There has been series of publications concern-
ing computational complexity of neural networks and
their relation to Turing computability. Pollack (Pol-
lack, 1987) showed that a particular type of heteroge-
neous processor network is Turing universal. Siegel-
mann and Sontag (Siegelmann and Sontag, 1991)
showed the universality of homogeneous networks of
first-order neurons having piecewise-linear activation
functions. Their results were generalised by Kilian
and Siegelmann (Kilian and Siegelmann, 1996) to
include various sigmoidal activation functions. The
number of neurons required for universality with first-
order neurons was estimated at 886 (Siegelmann and
Sontag, 1995), and in the later papers was reduced
to 96 (Koiran et al., 1994) and down to 25 (Indyk,
1995). In (Siegelmannand Margenstern, 1999), it was
502
Komendantskaya E. (2009).
NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?.
In Proceedings of the International Joint Conference on Computational Intelligence, pages 502-507
DOI: 10.5220/0002334805020507
Copyright
c
SciTePress
shown that there is a universal neural network with
nine switch-affine neurons which is Turing universal.
A good summary can be found in (Siegelmann, 1999).
The paper by McCulloch and Pitts (McCulloch
and Pitts, 1943) started another line of research
into the relation between logic and neural networks.
Namely, Connectionism, and one of its branches -
Neuro-Symbolic Integration (G¨usgen and H¨olldobler,
1992; Bader and Hitzler, 2005; Hammer and Hitzler,
2007) took up this problem at another level of ab-
straction. Neural networks were taken as a ready-to-
use tool in which one could implement some aspects
of logical deduction. Unlike the theoretical line of
research we described above, this approach did not
necessarily involve general translation of automata or
Turing machines into Neural networks. On the con-
trary, it often explored the ways of developing neural
networks architectures that could be suitable for a par-
ticular task in computational logic. The generality of
the theoretical level was sacrificed for convenient and
efficient implementations. We give a survey of this
approach in Section 2.
We also note here, that this second approach to
developing neuro-symbolic networks has been influ-
enced by the fact that the hardware development of
digital computers took over from neuro computers;
and the development of neural networks became more
a question of software than of a hardware. And this
justifies the changes in the style of neuro-symbolism.
However, neuro-symbolic networks have not yet
become a useful tool in computational logic. Instead,
neuro-symbolism has found its place somewhere on
the intersection of artificial intelligence, cognitivesci-
ence, and linguistics. See (Markus, 2001; Smolensky
and Legendre, 2006) for very successful examples. In
Section 3, we formulate four principles that are es-
sential for implementing algorithms of computational
logic. We conclude in Section 4.
2 PROPERTIES OF EXISTING
NEURO-SYMBOLIC NETS
Many of the neuro-symbolic networks rely on the rep-
resentation of logical connectives by McCulloch and
Pitts (McCulloch and Pitts, 1943). We start with a
simple example concerning a very popular approach
to implementing semantic operators for logic pro-
grams in neural networks.
Logic programs consist of clauses of the form
A B
1
, . . . , B
n
, where A, B
1
, . . . , B
n
are atomic (first-
order) formulae. For a given program P, the Herbrand
Base B
P
is a set that contains all possible ground in-
stances of atomic formulae appearing in P. Given a
logic program P, one can define a semantic opera-
tor T
P
that computes the least Herbrand model of P:
T
P
(I) = {A B
P
: A B
1
, . . . , B
n
is a ground instance
of a clause in P and {B
1
, . . . , B
n
} I}, where I is an
interpretation of a program given by a set of proposi-
tions that are true. See (Lloyd, 1987) for formal de-
scription.
Theorem 1. (H
¨
olldobler and Kalinke, 1994;
H
¨
olldobler et al., 1999) For each propositional logic
program P, there exists a 3-layer recurrent neural
network built of binary threshold units that computes
T
P
.
We will call these networks T
P
-neural networks
and illustrate them below. The theorem extends to
function-free first-order logic programs, and other
subclasses of first-order logic programs that have fi-
nite models. First-order logic programs in their full-
generality may have infinite models, and these cases
would require infinite neural networks, see (Hitzler
et al., 2004; Bader et al., 2008) for discussions and
solutions.
Example 1. Consider the ground logic program:
B
A
C A, B.
The neural network below computes T
P
2 =
{A, B, C}, that is, the least model of P, in two itera-
tions. Each of the atoms A, B, C is represented by a
neuron in the output and input layers. Connections
between the hidden layer and both outer layers are
set in a particular way that reflects the structure of
clauses. The weights of the recurrent connections be-
tween the output and the input layer are set to 1. That
is, all the connections
//
on the following dia-
gram have weights set to 1. Numbers 0.5, 0.5, etc.
show the thresholds (biases) of the neurons. The ac-
tivation functions are binary, that is, if the neuron re-
ceives a signal greater than its threshold, it outputs 1;
and it outputs 0 otherwise.
A
B C
GFED@ABC
0.5
GFED@ABC
0.5
GFED@ABC
0.5
ONMLHIJK
0.5
OO
ONMLHIJK
0.5
OO
GFED@ABC
1.5
OO
GFED@ABC
0.5
==
z
z
z
z
z
z
z
z
z
z
z
z
GFED@ABC
0.5
PP
GFED@ABC
0.5
A
B C
NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?
503
There are three characteristic properties that
distinguish T
P
-neural networks. We summarise them
as follows.
1. For a given program P, the number of neurons in
the input and output layers is the number of atoms
in the Herbrand base B
P
.
2. Signals of T
P
-neural networks are binary, and this
provides the computations of truth value functions
and that are used in program clauses.
3. As a consequence of the property (3), first-order
atoms are not represented in the neural network
directly, and only truth values 1 and 0, that are the
same for all the atoms, are propagated.
These three properties arise from a more general
Principle universally applicable to neuro-symbolic
networks of other kinds: When processing a logic
theory, the neural networks process truth values of
the ground instances of formulae, and compute the
models of the theory as a result. Moreover, each
ground instance of an atom from the given theory
should be represented by at least one neuron.
The main Principle has three main conse-
quences. The resulting network cannot:
directly deal with recursive programs, that is, pro-
grams that can have infinitely many ground in-
stances;
deal with non-ground reasoning that is common
in computational logic;
cover proof-theoretic aspect of logic theories;
One would be surprised to find how often neuro-
symbolic systems of different architectures obey the
main Principle and its three consequences. We will
consider some examples.
There were attempts to develop an original Learn-
ing Theory within Neuro-Symbolic integration. In
(d’Avila Garcez et al., 2002; d’Avila Garcez et al.,
2008), binary threshold units in the hidden layer of
T
P
networks were replaced by sigmoidal units. Such
networks allow back-propagation which can be used
to train neural networks. These neural networks obey
the general Principle, albeit they process signals from
the interval [1, 1]. They were applied to inductive
logic programming, where facts in a database can be
assigned some measures of probabilities. The values
from the interval [1, 0] were recognised by the out-
put unit as “false”, and the values from the interval
[0, 1] as “true”.
The Markov Logic Networks (Wang and Domin-
gos, 2008; Domingos, 2008) are another possible
modification of T
P
-neural networks. Here, the compu-
tational power of Markov chains and stochastic (prob-
abilistic) methods was used to give an account of
Logics of Probabilities. These networks do not use
a semantic operator directly, but the methodology is
very close to T
P
-networks, in that the networks rely
on ground instances of atoms appearing in logic pro-
grams, and propagate their truth values. This model
has been successfully applied to many practical prob-
lems, but it still obeys the main Principle.
Propositional Modal Logic Programs (d’Avila
Garcez et al., 2007; d’Avila Garcez et al., 2008).
Construction of T
P
-neural networks was exactly re-
produced in this approach, the only difference being
that it was adapted to Kripke semantics. That is, in
each possible world (by Kripke) one could have a sep-
arate T
P
-neural network computing classical values.
Fibrational Neural Networks. Some research was
done on creating networks of T
P
-neural networks,
they were called Fibring Neural Networks in (d’Avila
Garcez and Gabbay, 2004).
Many-Valued Logic Programs. This approach was
developed in (Komendantskaya et al., 2007; Komen-
dantskaya, 2007). Here, binary neurons represented
some atom together with its value, and several ad-
ditional layers were needed in order to reflect some
additional properties of many-valued semantic oper-
ators. These networks have the same properties as
T
P
-networks.
There have been several papers relating Fuzzy
Prolog and Fuzzy Neural Networks, (Ding, 1995;
Nauck et al., 1997; Zadeh, 1992). The resulting neu-
ral networks are called Fuzzy-Logical Neural Net-
works. The authors of (Nauck et al., 1997) show
that Fuzzy Logic Programs can be simulated by feed-
forward neural networks; moreover, they use learning
algorithms when working with fuzzy numbers. The
Fuzzy-Logical Neural Nets are capable of propagating
fuzzy signals, and not just 0, 1. If we examine Fuzzy-
Logical Neural Networks relative to the T
P
-neural net-
works, we will notice that they are not correlated with
semantic operators any more, however, they still obey
the main Principle, in that they work with truth val-
ues and functions over truth values, and do not encode
first-order atoms directly.
Even with approaches that are not directly tied to
logic programs, such as (Pollack, 1990; Shastri and
Ajjanagadde, 1993), one can notice that the networks
essentially rely upon ground reasoningand binary sig-
nal processing.
3 OBSTACLES AND SOLUTIONS
Networks considered in the previous section have
been successfully implemented for certain practical
IJCCI 2009 - International Joint Conference on Computational Intelligence
504
or industrial problems. But they did not advance our
understanding of how inference algorithms used in
computational logic and proof theory could be imple-
mented in neural networks.
In this section, we offer four principles for devel-
oping neuro-symbolic networks suitable for simulat-
ing the algorithms of computational logic.
1. Implementation of Techniques from Proof The-
ory should not be Replaced by the Model Theory.
There are two reasons why such a replacement cannot
lead to successful implementations of computational
logic.
In the case of first-order theories, the semantics is
often developed on the meta-level, not using the syn-
tax of the theory. For example, first-order logic pro-
grams are executed by the algorithms of unification
and SLD-resolution, whereas their semantics is given
by semantic (fixed point) operators. Neural-symbolic
networks we have surveyed can do the semantics of (a
restricted class of) first-order logic programs, but not
the syntactic inference. And implementations of the
former did not lead to the implementation of the lat-
ter. Using logic programming terminology, the neuro-
symbolic networks could do declarative semantics,
but not the operational one.
Another obstacle is that the traditional Neuro-
Symbolic Networks, owing to their dependence on
truth value assignments and first-order semantics, do
not adapt well to higher-order logics and type theory.
Moreover, in typed theories, such as typed lambda
calculus or the calculus of constructions, the very
distinction between syntax and semantics is erased,
and manipulations with types of expressions are per-
formed using the syntax of the theory, and this, in its
turn, justifies correctness of computations.
Because the existing neuro-symbolic networks do
not adapt well to the two major trends in compu-
tational logic automated proving (given by oper-
ational semantics of first-order logic programs) and
Type theory, they have not yet found their proper
niche in the area, and are normally conceived as a
branch of AI rather than of computational logic.
2. Direct Processing of Logic Terms should be Pre-
ferred to Processing of their Truth Values. This
can be achieved by using a one-to-one numerical en-
coding of the symbols of the formal alphabet, such
as G¨odel numbering. The main difficulty here is to
represent strings of such numbers.
Logic formulae are effectively strings of symbols
of a given alphabet. However, according to a general
convention, neurons do not process strings, or ordered
sequences, or any other structured data. Every neu-
ron can accept only a scalar as a signal, and output a
scalar in its turn. This general convention has been
developed through decades of discussion, and differ-
ent views on it are best summarised in (Aleksander
and Morton, 1993; Smolensky and Legendre, 2006).
However, some order is innate to neural networks:
and this order is imposed by position of neurons in a
given layer, and by positions of layers in a network.
So, although each neuron accepts only a scalar num-
ber as an input, a layer of neurons accepts a vector
of such numbers, and the whole network can accept a
matrix of numbers.
Therefore, a vector of neurons in a layer mirrors
the structure of a string, and the matrix that describes
a many-layered neural network mirrors the structure
of a tree. This is all we need to encode logical terms
(strings of symbols of an alphabet), and term trees -
in case we use a tree-like representation of terms in
parallel algorithms. See (Pollack, 1990; Smolensky
and Legendre, 2006) for related discussion.
Given a first-order formula F = P(t) built from
the symbols of the alphabet A, and having a one-to-
one numerical encoding of A given by a function η,
the vector [P
η
; (
η
; t
η
; )
η
] can be directly used as an
input or weight vector in a neural network. Here, we
denote the result of applying η to a symbol x by x
η
.
3. Levels of Abstraction should not be Mixed. Two
levels of abstraction we mentioned in the introduction
can provide two different solutions to the problem of
simulating symbolic logic in neural networks. On the
low level, we can build a network that simulates Tur-
ing machines, and then use it for symbolic computa-
tions. This approach can be bulky, and for this reason
logic algorithms are commonly written on a higher
level of abstraction than Turing machines. We suggest
to look for direct representations of these high-level
algorithms in Neural networks, ignoring the low-level
theoretical correspondence between neural networks
and Turing machines.
This direct approach may seem to lack generality;
nevertheless, we claim that it can be very useful in
practice. Consider, for example, the algorithm of first-
order unification due to (Robinson, 1965), that is used
as one of the basic and essential algorithms in proof
theory and computational logic. It is P-complete and
can be performed by a Turing machine, however, its
definition in terms of Turing machines can be bulky.
Its traditional description is as follows.
Suppose we have two first-order formulae P(a)
and P(x). The algorithm of unification will inspect
each symbol in the formulae, and pick two symbols
that disagree - x and a. Then it will substitute a for x in
P(x), and thus, the two formulae will be unified. This
can be done using a conventional error-correction
learning in neural networks. We simply need to
NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?
505
take numerical vector representation of the symbolic
terms; let [P
η
; (
η
; a
η
; )
η
] and [P
η
; (
η
; x
η
; )
η
] de-
note the numerical encodings. Take a layer of 4
neurons. Let the weight vector be [P
η
; (
η
; x
η
; )
η
]
and the bias vector be [P
η
; (
η
; a
η
; )
η
]. Set the ac-
tivation function to be linear, and the target to be
[0; 0; 0; 0]. Send the signal 1 to the network, it
will output [0; 0; (x
η
a
η
); 0]. Thus, the error
the difference between the desired response and the
output will be [0; 0; (x
η
a
η
); 0]. The error-
correction algorithm will amend the weight vector,
and, on the next iteration, the weight vector will be
[P
η
; (
η
; a
η
; )
η
], and the error will be zero. See
(Komendantskaya, 2009b).
This example illustrates that some algorithms of
computational logic have direct analogy with the
learning algorithms of neurocomputing. This direct
use of neural networks for implementations of com-
putational logic should be further exploited.
This discussion of the unification by error-
correction learning leads us to the last thesis:
4. Attitude to Learning Functions should be More
Liberal, and Allow Symbolic Components. Com-
ing back to the previous example, it is impossible to
get a general-purpose network that performs unifica-
tion algorithm without adding a certain symbolic de-
scription into the definition of the learning function.
For example, we need to make sure that only a can
be substituted for x, and not x for a. In case we deal
with function symbols in the language, we may need
to substitute f(y) for x, and then the network will need
to be enlarged. Also, the occur check should be per-
formed, e.g., we should make sure that f(x) is not
substituted for x.
Among the advantages of having such hybrid
networks would be that simply switching between
conventional and pseudo-symbolic learning functions
one can achieve multi-functionality of the resulting
neural network. Another advantage is parallelism.
The algorithm of unification is not the only algo-
rithm of computational logic that yields a simple and
direct representation as a learning process. As an-
other example, parallel (term)-rewritingcan be shown
to correspond to a form of Hebbian learning. That
is, given a string [1 2 3 1 2 3], a 6-neuron layer can
perform a rewriting operation for the rewriting rule
x 3x using a Hebbian learning rule. For this, we
simply need to set the weight vector to be [1 2 3 1 2 3],
set the rate of learning to be 2, and send the input sig-
nal 1. At the next iteration, the weight will be rewrit-
ten to [3 6 9 3 6 9]. This example, moreover, shows
that neural networks are capable of parallel rewriting,
which will bring a much desired speed up to the com-
putations; (Komendantskaya, 2009a).
In order for this scheme to cover a more symbolic
form of rewriting a term-rewriting one must
allow a symbolic component into the conventional
learning function to deal with the symbolic subtleties
that arise when we rewrite and substitute first-order
terms.
4 CONCLUSIONS
We separated two levels of abstraction at which the
relations between “neurons” and “symbols” can be
considered. We restricted our attention to the im-
plementational level. We analysed common proper-
ties of existing neuro-symbolic networks, and showed
that they obey one general Principle. This Princi-
ple and its three main consequences cause the dis-
junction Neurons OR Symbols to remain exclusive
that is, they prevent implementations of the sym-
bolic (proof-theoretic) aspects of computational logic
in neural networks. Finally, we proposed four princi-
ples for building neuro-symbolic nets of the future.
ACKNOWLEDGEMENTS
The work was sponsored by EPSRC PF research grant
EP/F044046/1.
REFERENCES
Aleksander, I. and Morton, H. (1993). Neurons and Sym-
bols. Chapman and Hall.
Bader, S. and Hitzler, P. (2005). Dimensions of neural sym-
bolic integration - a structural survey. In Artemov, S.,
editor, We will show them: Essays in honour of Dov
Gabbay, volume 1, pages 167–194. King’s College,
London.
Bader, S., Hitzler, P., and H¨olldobler, S. (2008). Connec-
tionist model generation: A first-order approach. Neu-
rocomputing, 71:2420–2432.
d’Avila Garcez, A., Broda, K. B., and Gabbay, D. M.
(2002). Neural-Symbolic Learning Systems: Founda-
tions and Applications. Springer-Verlag.
d’Avila Garcez, A. and Gabbay, D. M. (2004). Fibring
neural networks. In Proceedings of the 19th National
Conference on Artificial Intelligence, pages 342–347.
AAAI Press/MIT Press, San Jose, California, USA.
d’Avila Garcez, A., Lamb, L., and Gabbay, D. (2007). Con-
nectionist modal logic: Representing modalities in
neural networks. Theoretical Computer Science, 1-
2(371):34–53.
IJCCI 2009 - International Joint Conference on Computational Intelligence
506
d’Avila Garcez, A., Lamb, L. C., and Gabbay, D. M.
(2008). Neural-Symbolic Cognitive Reasoning. Cog-
nitive Technologies. Springer-Verlag.
Ding, L. (1995). Neural prolog - the concepts, construction
and mechanism. In Proceedings of the 3rd Int. Confer-
ence Fuzzy Logic, Neural Nets, and Soft Computing,
pages 181–192.
Domingos, P. (2008). Markov logic: a unifying lan-
guage for knowledge and information management. In
CIKM, page 519.
G¨usgen, H. W. and H¨olldobler, S. (1992). Connectionist
inference systems. In Fronh¨ofer, B. and Wrightson,
G., editors, Parallelization in Inference Systems, pages
82–100. Springer, LNAI 590.
Hammer, B. and Hitzler, P. (2007). Perspectives of Neural-
Symbolic Integration. Studies in Computational Intel-
ligence. Springer Verlag.
Hitzler, P., H¨olldobler, S., and Seda, A. K. (2004). Logic
programs and connectionist networks. Journal of Ap-
plied Logic, 2(3):245–272.
H¨olldobler, S. and Kalinke, Y. (1994). Towards a massively
parallel computational model for logic programming.
In Proceedings of the ECAI94 Workshop on Com-
bining Symbolic and Connectionist Processing, pages
68–77. ECCAI.
H¨olldobler, S., Kalinke, Y., and Storr, H. P. (1999). Approx-
imating the semantics of logic programs by recurrent
neural networks. Applied Intelligence, 11:45–58.
Indyk, P. (1995). Optimal simulation of automata by neu-
ral nets. In Mayr, E. and Puech, C., editors, Proc. of
the Twelfth Annual Symposium on theoretical aspect
of Computer Science, LNCS, page 337.
Kilian, J. and Siegelmann, H. (1996). The dynamic univer-
sality of sigmoidal neural networks. Information and
Computation, 128(1):48–56.
Kleene, S. (1956). Neural nets and automata. In Automata
Studies, pages 3 – 43. Princeton University Press.
Koiran, P., Cosnard, M., and M.Garzon (1994). Com-
putability with low-dimensional dynamic systems.
Theoretical Computer Science, 132:113–128.
Komendantskaya, E. (2007). Learning and Deduction in
Neural Networks and Logic. PhD thesis, Department
of Mathematics, University College Cork, Ireland.
Komendantskaya, E. (2009a). Parallel rewriting in neural
networks. In Proceedings of ICNC’09.
Komendantskaya, E. (2009b). Unification neural networks:
Unification by error-correction learning. Submitted.
Komendantskaya, E., Lane, M., and Seda, A. (2007). Con-
nectionist representation of multi-valued logic pro-
grams. In Hammer, B. and Hizler, P., editors, Perspec-
tives of Neural-Symbolic Integration, Computational
Intelligence, pages 259–289. Springer Verlag. To ap-
pear.
Lange, T. E. and Dyer, M. G. (1989). High-level inferencing
in a connectionist network. Connection Science, 1:181
– 217.
Lloyd, J. (1987). Foundations of Logic Programming.
Springer-Verlag, 2nd edition.
Markus, G. (2001). The Algebraic Mind: Integrating Con-
nectionism and Cognitive Science. Cambridge, MA:
MIT Press.
McCulloch, W. and Pitts, W. (1943). A logical calculus
of the ideas immanent in nervous activity. Bulletin of
Math. Bio., 5:115–133.
Minsky, M. (1954). Neural Nets and the Brain - Model
Problem. PhD thesis, Princeton University, Princeton
NJ.
Minsky, M. (1969). Finite and Infinite Machines.
Nauck, D., Klawonn, F., Kruse, R., and F.Klawonn (1997).
Foundations of Neuro-Fuzzy Systems. John Wiley and
Sons Inc., NY.
Neumann, J. V. (1958). The Computer and The Brain. Yale
University Press.
Pollack, J. (1987). On Connectionist Models of Natural
Language Processing. PhD thesis, Computer science
Department, University of Illinois, Urbana.
Pollack, J. (1990). Recursive distributed representations.
AIJ, 46:77–105.
Robinson, J. (1965). A machine-oriented logic based on
resolution principle. Journal of ACM, 12(1):23–41.
Shastri, L. and Ajjanagadde, V. (1993). From associations
to systematic reasoning: A connectionist representa-
tion of rules, variables and dynamic bindings using
temporal synchrony. Behavioural and Brain Sciences,
16(3):417–494.
Siegelmann, H. (1999). Neural Networks and Analog Com-
putation. Beyond the Turing Limit. Birkhauser.
Siegelmann, H. and Margenstern, M. (1999). Nine switch-
affine neurons suffice for Turing universality. Neural
Networks, 12:593–600.
Siegelmann, H. and Sontag, E. (1991). Turing computabil-
ity with neural nets. Applied Mathematics Letters,
4(6):77–80.
Siegelmann, H. and Sontag, E. (1995). On the computa-
tional power of neural nets. J. of Computers and Sys-
tem Science, 50(1):132–150.
Smolensky, P. and Legendre, G. (2006). The Harmonic
Mind. MIT Press.
Wang, J. and Domingos, P. (2008). Hybrid markov logic
networks. In AAAI, pages 1106–1111.
Zadeh, L. (1992). Interpolative reasoning in fuzzy logic and
neural network theory. Fuzzy Systems, pages 1–20.
NEURONS OR SYMBOLS - Why Does OR Remain Exclusive?
507
