SEMANTIC BASED TEST DATA EXTRACTION FOR

INTEGRATED SYSTEMS (iSTDE)

Ali Raza and Stephen Clyde

Computer Sceince Department, Utah State University, 400 Old Main Hill, Logan, Utah 84322-1400, U.S.A.

Keywords: Test data extraction, Test data generation, Testing database applications, Semantic-based data extraction,

Integrated systems, Integrated healthcare systems.

Abstract: Testing an integrated information system that relies on data from multiple sources can be a serious

challenge, particularly when the data is confidential. Such is the case for the Child-Health Advanced

Record Management (CHARM) system, which is now in production at the Utah Department of Health.

CHARM allows various public health-care programs, like vital records, immunization, and hearing

screening, to seamlessly access data from each others’ databases in real-time. Since CHARM deals with

confidential health-care information, it was impossible to use real data for testing purposes, especially since

the development and testing environments were outside the confidential environment in which CHARM

operates. This paper describes a test-data extraction tool built and successfully used for testing the

CHARM system. This tool, called Semantic based Test Data Extractor for Integrated Systems or iSTDE,

reads a consistent cross-section of data from the production databases, manipulates that data to obscure

individual identities while preserving overall data characteristics that are critical to thorough system testing,

and finally moves that test data from the confidential production environment to the unprotected test

environment.

1 INTRODUCTION

Child Health Advanced Record Management

(CHARM) is an integrated system that provides

health-care professionals with accurate and timely

information about children in Utah whose medical

records are housed in various federated public

healthcare databases, including Vital Records (VR),

the Utah State-wide Immunizations Information

System (USIIS), and Early Hearing Detection and

Invention (HiTrack).

A collaborative team of software engineers from

Utah State University (USU), Utah Department of

Health (UDOH), and Multimedia Data Services

Corporation (MDSC) started developing CHARM in

November 2000. Its architecture, illustrated in

Figure 1, is that of an arms-length information

broker (Clyde and Salkowitz, 2006)

with

 A CHARM server, which is the information

broker, and

 A CHARM agent for each connected database

also called a participating program or PP.

When a user of a PP requires CHARM-accessible

data, the PP submits a request for that data to

CHARM via its own agent. That agent is

responsible for mapping PP-specific data types and

identifiers to CHARM-specific data types and

identifiers. It next passes the modified query onto

the CHARM server. The CHARM server either

Figure 1: CHARM Architecture.

173

Raza A. and Clyde S. (2010).

SEMANTIC BASED TEST DATA EXTRACTION FOR INTEGRATED SYSTEMS (iSTDE).

In Proceedings of the Third International Conference on Health Informatics, pages 173-180

DOI: 10.5220/0002692401730180

 SciTePress

looks up or computes an appropriate strategy for

processing the query and then executes that strategy.

This process may involve retrieving information

from several other PPs via their CHARM agents and

merging the results of those individual data

retrievals into a final query result.

The first functional prototype was successfully

demonstrated in March 2002. It was at this point that

the developers began to see the real challenges of

testing an integrated system that involves

confidential data. With the three original

participating programs, the system made use of

seven different databases: three from the

participating programs, three used by the agents to

map PP-specific IDs to internal CHARM IDs, and

one used by the CHARM server to match and link

persons based on their demographic information

(CHARM). From a testing stand-point, however,

such data separation made generating realistic test

data difficult. At first, the developers tried to create

test data by hand. This quickly proved to be time

consuming and error prone. Next, the developers

built an automated test-data generator that created

test data for each database using that database’s

scheme and codified knowledge about field

domains, constraints, and overall data characteristics

(Maddy, 2006). Such an approach allowed the

developers to create large amounts of test data, but

correlating the information between different

databases and creating patterns similar to those in

the real data proved difficult.

So, for the latest version of CHARM, the

developers have taken a new approach for creating

test data. Specifically, they created a distributed

tool, called Semantic Test Data Extractor for

Integrated Systems (iSTDE), which first extracts a

consistent cross-section of data from the production

databases. It next manipulates that data in a way that

obscures individual identities, while preserving

other important aggregate data characteristics, such

as the frequency of name occurrences, the

percentage of multiple births (i.e., twins), and the

presence of bad data. Preserving these characteristic

is critical to effective system testing of components

like a person matcher. After de-identifying the test

data, iSTDE moves that test data from the

production environment to a test environment.

Section 2 discusses related work for creating

realistic test data, while, Section 3 provides some

additional background on the production and test

environment of testing CHARM. Section 4

describes the process iSTDE uses to extract data, de-

identify that data, and move it to a test environment.

Experience and observations in using iSTDE are

presented in Section 5. Future work is in Section 6.

2 RELATED WORK

In general, approaches for test data creation fall in

two general categories: one based on automatic

generation and the other based on real data

extraction.

A review of eight automated test-data generation

tools revealed six different common techniques for

generating data at a field level, i.e., for a domain.

See Table 1 for list of the tools reviewed and Table

2 for the techniques each supported.

The first two techniques create random data

based on a field’s data type along with some simple

constraints. For example, an algorithm based on

random generation could populate a salary field in a

payroll table with values between $20,000 and

$65,000. Similarly, a random-generation algorithm

could populate a first name field in a person table

with a string between 1-10 characters long,

containing characters A-Z. In general, random

generation is more applicable to numeric fields than

other types of domains. Six of the eight tools

support random generation for numeric data, while

only three support it for strings.

The third technique constrains the random

generation of data by percentages that represent

value distributions in real data. For example,

imagine a person table with 20% of the records

having birth dates in 2008 and the remaining 80% in

2007. A tool that supports this type of data creation

could preserve such distributions. Only one of the

tools supports this type of random data generation.

The fourth technique generates data according to

user-defined grammars. For example, the grammar

Aa-9999 could generate data that has one capital

letter, followed by one small letter, a dash and four

numeric digits. This technique is most applicable

for string domains with an implicit language that can

be easily defined with a pattern or simple grammar.

Interestingly, it is common for database schemes to

have fields with simple hidden languages, but only

two of the eight tools support this technique.

The fifth technique pulls randomly selected data

from a pre-defined domain. For example, this

technique could be used to populate a last-name

field from a pre-defined domain of common Spanish

names. Four of the eight tools support this

technique, and several of them even had some built-

in domains for female names, male names,

countries, etc.

The sixth technique identifies an algorithm that

links child records to parent records in hierarchical

structures. For example, an algorithm that uses this

HEALTHINF 2010 - International Conference on Health Informatics

174

technique could be used to generate data for a

purchasing system consisting of customer, order,

line item tables that relate to each other via

referential integrity constrains.

Although automated test-data generation

techniques can save time compared to collecting and

loading meaningful test data by hand, they fall short

of producing test data that possess many of

characteristics found in real data, such as:

 the presence or frequency of missing values;

 the presence or frequency of incomplete

information;

 the presence of garbage data;

 duplicates, wherein the duplicates were caused

by or allowed to exist because of other field

values; and

 other characteristics caused inter-field

dependencies.

The second approach, test-data extraction,

attempts to create test beds from real data sources. A

review of the eight tools uncovered extraction

techniques at three different levels, namely,

extracting data from a single file, extracting data

from multiple tables in a single database, and

extracting data from multiple unrelated databases.

See the first three rows in Table 3.

Three of the tools support the first technique,

which has some similarities to test-data generation

from predefined domains. However, a key

difference is that test-data extraction can produce

test data with realistic characteristics without

explicitly having to state those characteristics.

The second technique deals with extracting test

data from multiple tables in a real database. This

type of test-data extraction does everything

supported by the first technique, but it also

maintains inter-record dependencies across the

tables. However, these dependencies can go beyond

the referential integrity constraints mentioned above.

Specifically, they can include frequency constraints

involving fields from multiple tables. Three tools

support this type of data extraction, at least to some

degree.

The third technique, which only one of the eight

reviewed tools supports, goes a step further by

allowing users to extract data from multiple

databases. However, without any cross-correlation

of data between the databases, this technique can be

viewed as simply a convenience for performing

multiple, separate extractions.

Clearly, being able to create test data for multiple

databases is necessary for testing integrated systems,

but it is not enough. To test an integrated system, its

constituent components (i.e., participating

information systems) need realistic and correlated

slices of data that contain the same inter-

relationships and hidden dependencies from the

production databases. For example, it would be

meaningless to extract one set of person records

from one database and a non-overlapping set of

records from another database. Testing would not

be able to verify the results of any actual data

integration.

Also, to test integrated systems that contain

confidential data, it is important to remove or hide

all identified personal information so that testing can

be conducted in unsecured environments.

To address the need for correlating data across

databases and for de-identified test data, we have

added two additional test-data extraction techniques

to Table 3, namely, correlated real data from

multiple related databases and de-identified data

from confidential databases. The iSDTE tools

presented in the next section support these

additional techniques.

3 ISTDE ENVIRONMENT

In general, multiple CHARM execution

environments exist, including one for production,

one for staging and user-acceptance testing, several

for system testing, and at least six for development.

From a data-security perspective, these

environments can be grouped in two categories:

confidential and unprotected. The confidential

environments, which include the production

environment and staging environment, are protected

by firewalls in UDOH. Only authorized users can

access these environments containing sensitive

demographic and health-care data. The unprotected

environments, which include all the system testing

and development environments, run on a variety of

machines and networks outside of UDOH firewalls,

and may be used by individuals not authorized to

see real data.

Besides the access restrictions, the confidential

and unprotected environments differ in terms of the

database managers they use for the various data

sources. The data sources in the confidential

environments are either the actual production

databases or staging databases for the production

system. In either case, these databases are tied to

legacy software and, therefore, rely on a number of

different database managers, including Oracle,

Microsoft SQLServer, Postgres, and Pervasive.

SEMANTIC BASED TEST DATA EXTRACTION FOR INTEGRATED SYSTEMS (iSTDE)

175

Table 1: Eight software packages reviewed.

Abr. Software Package Author / Vendor

DG GenerateData.com (GenerateData.com,2008) GenerateData.com

SE DTM Data Generator (SqlEdit, 2008) DTM Soft

FS ForSQL Data Generator (www.forsql.com, 2008) ForSQL

Automated Test Data Generator

(http://www.tethyssolutions.com/T10.htm, 2008)

Tethys Solutions

DN DB Data Generator V2 (www.datanamic.com, 2008) Datanamic

TB TurboData (www.turbodata.ca, 2008)

Turbo Computer

Systems, Inc.

TN Tnsgen – Test Data Generator(www.tns-soft.com , 2008) TNS Software Inc.

EMS Data Generator for MySQL

(http://www.sqlmanager.net/en/products/postgresql/datagenerator)

EMS Inc.

Table 2: Six common test-data generation features

Table 3: Test-data extraction techniques.

Test Data Extraction DG SE FS TS DN TB TN EM

1 From real data from files

2 From real data from one database

From uncorrelated real data from multiple

databases

4 Correlated real data from multiple related databases

5 De-identified data from confidential databases

All the unprotected environments, on the other

hand, use Postgres as the database manager to

eliminate extra licensing fees that might otherwise

be necessary. However, using a different database

manager for testing introduces two new challenges.

First, the types of database that the integration

system accesses will depend on the environment it is

running in. So, testing iSTDE in one of the

unprotected environments may not verify the

correctness of the database drivers, connection

strings, or SQL-statement syntax. For CHARM, we

solved this problem by doing a final system test in

the staging environment, which does use all of the

same types of databases as the production

environment.

Second, converting all the data to Postgres for the

unprotected environment introduces certain data-

type mapping problems. Some data types in the

original database do not have compatible data types

in Postgres. For example, SqlServer supports a

global unique identifier (GUID) data type that

Postgres does not support. So, iSDTE maps

SqlServer GUIDs to an alternative data type, like

VARCHAR. Section 4.2 describes iSDTE’s solution

to this problem in detail.

4 APPROACH

The iSTDE software itself is installed in a

environment, thereby ensuring that no unauthorized

person can execute it. When iSTDE executes, it

goes through seven steps to create a consistent set of

de-identified test data from the confidential data and

then moves it to an unprotected environment. See

Figure 2. Each of these steps is described in more

detail below.

Test Data Generation Features DG SE FS TS DN TB TN EM

1 Random numeric data generation

2 Random string data generation

3 Percentage-based data generation

4 Generate data from user-defined grammars

5 Generate data from predefined domains

6 Generate data for database, with master child relations

HEALTHINF 2010 - International Conference on Health Informatics

176

4.1 Specifying Extraction Parameters

In the first step, a user specifies what data to extract

(e.g., all children born from 7/1/2008 to 9/30/2008)

and the target environment wherein test data should

ultimately be sent, along with a username and

password for accessing that environment. In

addition, the user can specify the location of a

temporary database within the confidential

environment that iSTDE will use to collect and

manipulate the test data before sending it over to the

target environment.

iSTDE also supports a number of other

configuration parameters that the user typically does

not change, such as connection strings for the

various data sources in the confidential

environment. These parameters are kept in a

properties file and only need to be changed if the

data sources in the confidential environment change.

4.2 Creation of Temporary Databases

The second step in the iSTDE execution involves

creating the temporary database in a confidential

environment to hold the extracted data from multiple

source databases, while they are being collected and

manipulated. In this step, iSTDE first makes sure

that there are no existing temporary databases in

confidential environment. It then retrieves schema

metadata for all the source databases and transforms

them into Postgres creation scripts. Next, it

executes those scripts to create the temporary

database, with all of the necessary tables, indices,

views, stored procedures, and triggers. Further into

the process in Step 6, iSTDE drops the temporary

databases, so unnecessary copies of the extracted

data are not left lying around.

iSTDE uses Postgres for the temporary database

because it is Open Source and it supports a broad

range of features and data types. Nevertheless, it

does not support everything; nor did we find an

Open Source database manager that did.

One challenge for Step 2 was accessing metadata.

Some source databases do not allow external

processes to read the database’s metadata, or they do

not support reflection. So, iSTDE could not

automatically retrieve and analyze their structures

directly. For such databases, iSTDE reads the

metadata from an externally managed meta-data

repository. This repository has to be updated

manually when the real database’s structure

changes.

Figure 2: iSTDE Overview.

Another challenge was unsupported or

incompatible data types, as mentioned in Section 3.

For each unsupported data type, iSDTE designers

selected an alternative Postgres data type and wrote

a mapping function that converts data from the

original type to the alternate type. So, when iSDTE

comes upon a field with an unsupported data-type, it

simply looks up its alternative data type and uses

that type in the table creation scripts for the

temporary database. Then, later in Step 3, iSDTE

uses the corresponding mapping function to convert

the values from that field before placing them into

the temporary database.

The third challenge was handling views in

iSTDE. The test databases need to support or

simulate any views in the real database such that the

legacy programs and integrated system will function

correctly. There are two approaches for supporting

a view. The first is to include all the tables and their

data that makes up the view in the test set.

However, this can be problematic because some

views are very complex and may end up requiring

far more data to be extracted into the test database

than necessary. A second approach is to implement

the views as tables populated with a snapshot (or a

portion of a snapshot) of the view. This approach

can reduce both the amount space required for the

test data and the extraction time. However, this

approach is only appropriate if the integrated system

does not need to update any of the data involved in

the view.

Like views, database procedures also need to be

either implemented directly in the test database or

simulated through tables, since different database

managers use different procedural languages and it

is very difficult to automate their extraction and

SEMANTIC BASED TEST DATA EXTRACTION FOR INTEGRATED SYSTEMS (iSTDE)

177

direct implementation. However, as with views,

when the integrated system does need to modify the

underlying data, simulating a stored procedure using

a table of stored results is relatively straightforward.

When this was not possible for CHARM, a

programmer manually created versions of the store

procedure in plsql (Postgres’s procedural language.)

Manual conversions of stored procedures need only

be done once. After that, iSTDE can re-use them

whenever needed.

A final challenge stems from version conflicts.

The systems that comprise an integrated system, as

well as the integration framework itself, evolve

independent of each other. Changes do not occur in

a lock-step chronology. One system will upgrade its

database, while other systems are still using older

structures. For example, over the past few years,

there have been two major versions of the CHARM

integration framework, and at least one significant

database change to each of the participating

programs. The database schemas for these versions

have slightly different metadata. Such was the case

when the CHARM developers were testing Version

2, yet the production environment was still using

Version 1 data structures. Mapping data across

versions of an integrated system is a significant

problem. iSTDE handles this by adding some

additional metadata to the external metadata

repository, so it can track the version and then re-

map data if necessary.

Some challenges are still unresolved. For

example, in cases wherein iSTDE has to store the

meta-data for a system in an external repository,

changes to the original database’s structure can

create an inconsistency. Organization procedures

have to be put in place and followed to ensure that

changes to a participating information system are

reflected in iSTDE metadata for that system. It

would be better if more of this process could be

automated or at least monitored by iSTDE.

4.3 Extraction and Loading of Real

Data to Temporary Databases

The previous steps created empty temporary

databases for holding the extracted data, with all the

necessary tables, constraints, views (or their

simulations), and stored procedures (or their

simulations). Now in this the third step, iSTDE

extracts a consistent slice of real data from the

participating data sources in the confidential

environment and loads that data into these

temporary databases.

The process of extracting a data slice starts when

iSTDE generates SQL queries through parsing and

analyzing user-specified test-data selection criteria,

e.g., child birth date range. One SQL query is

generated for each of the relevant production

databases. A challenge in data extraction was to

ensure that the slice contains records for the same

sample population across all of the participating

programs. To ensure the slice’s internal consistency,

iSTDE uses cross-database links created and

maintained by the integrated system. In CHARM,

each agent maintains a mapping of its participating

program’s IDs to a common, internal CHARM ID.

Together, these maps link the records for a person

across all of the participating information systems.

iSTDE uses and preserves these inter-database links

to guarantee that the overall test data are internally

consistent.

When these SQL queries return result sets,

iSTDE uses the data in these result sets to construct

SQL insert statements. While constructing these

SQL insert statements, individual data fields in a

result set are parsed according to the temporary

databases’ metadata. Later these insert statements

are written to data files located in a confidential

environment. The purpose of generating data files is

to effectively utilize the connection time on

production databases.

Once the process of extracting data into data files

is complete, iSTDE loads these files to the

temporary databases. A challenge was to load data

in such a way as to not violate referential integrity

constraints. iSTDE deals with this challenge by

loading data files for parent tables before child

tables. However, the cyclic nature of relational

interdependencies among tables makes this solution

unfeasible. A better approach would be to first load

the data into tables and later implement referential

integrity constraints.

4.4 Data Mangling

Once real data has been extracted and loaded into

the temporary databases, iSTDE obfuscates that data

by applying data mangling to each domain that

contains personal indentifying information (PII). In

this step, data mangling randomly swaps data values

in the domain so the PII’s of any given record are

unrecognizable and untraceable, but without

changing the overall characteristics of the data set.

As mentioned early, preserving the overall

characteristics of the data set is critical for thorough

testing in integrated systems.

The first step of data mangling is the

identification of PII domains, e.g., first names, last

names, birth dates, addresses, etc. PII domains can

be simple or composite. Simple domain consists of

HEALTHINF 2010 - International Conference on Health Informatics

178

only one identifying element, and composite

domains may involve multiple elements. For

example, male first name and phone number are

simple domains, whereas a full address domain

(street, city, state, zip code) may be a composite

domain. To preserve consistency, composite

domains have to be mangled as a whole unit. For

example one instance of an address may be swapped

with another random but complete address. iSTDE

also sometimes subdivides a domain wherein

swapping needs to be constrained by the value of

some other element. For example, it partitions

gender-dependent domains into female and male

subset, i.e., first name domain is partitioned into

male first names and female first names.

After PII domains selection, we build dictionaries

for these domains. These domain dictionaries are

data structures that consist of real domains and test

domains. Real domains are data slices that are built

from similar PII domains from across all databases

included in CHARM, not just one database. For

example, in the case of first male names, the

dictionary real domain contains all first male name

entries that exist in all tables of temporary databases.

Test domains are populated by semi-random

shuffling of real domain entries. The term semi-

random hints that there are chances that an entry in a

real domain maps to the same entry in a test domain.

Entries in test domains would be the newly assigned

values for the real data. In the next step of the

mangling process, we swap all the values of PII

domains in real data with the newly assigned test

values, using domain dictionaries that provides

mapping from real values to test values. Once we

have mangled all the data, we then delete these

dictionaries so that no one can perform reverse

mapping to real data. Essentially, iSTDE deals with

three different types of data mangling.

The first type is 1-1 logical domain dependency.

Two domains are said to be logically dependent

when they are semantically related to each other, a

change in one domain requires a similar change in

the other. Consider two domains, D1 and D2, which

have a 1-to-1 logical dependency between them but

have different data representations. When we swap a

value in one of the domains, a corresponding swap

must also be made in the second. More specifically,

if x, x'∈ D1 and y, y'∈ D2 such that x ↔ y, and x'

↔ y', then if x is swapped with x', y must also be

swapped with y' and vice versa. For example,

consider two tables containing identical

demographic information about patients. One table

uses just one column to store birth dates, i.e., say

05/11/2009 for patient A, while another table uses

three columns to store the same birth date of patient

A, i.e., say 05 as MM, 11 as DD, and 2009 as

YYYY. iSTDE ensures that two tables maintain the

same logical dependency after mangling, that is, if

the birth date 05/11/2009 is swapped with some

other date 07/10/2007 in one table, iSTDE also

makes the same logical swap in the other table that

uses three columns to represent the birth dates.

The second type of dependency in the iSTDE

mangling process is called data value dependency.

Two domains D1 and D2 are said to have a data

value dependency when for any single record that

uses values from both domains, there is a constraint

involving those values in these domains. Then, if

values in D1 are swapped, a random swap must also

be made in D2, but the original constraint must still

hold (if the original record satisfies that constraint.)

More specifically, if x, x'∈ D1and y, y'∈ D2 such

that x⊗y where ⊗ represent some constraint, then if

x is swapped with x', y can also be swapped with y'

as long as x'⊗y'. Stated another way, we can say that

a child birth date in any of the databases cannot be

greater than a parent birth date.

The third type of data mangling relates to the

mangling of computed fields and partial computed

fields. These two types of fields are considered

dependent and are derived from some other fields.

For example, a full name field can be a computed

field as it is derived from a first name and last name.

When iSTDE mangles the first name and last name,

it also re-computes the full name to maintain names

consistency. Partial computed fields are those fields

that have partial independent values and partial

computed values. For example, a contact name field

can contain a brother name. It might be possible that

two brothers have the same last name, so if we

mangle the last name, we also need to re-compute

the partial value in the contact name field.

4.5 Transferring Mangled Data

Once mangling of data is complete, the fifth step in

the entire process is the automatic transfer of the de-

identified test data to the user-specified unprotected

environment. To do this, iSTDE creates a dump of

all the temporary databases, transfers them via a

secure copy to the unprotected environment, and

executes remote commands to restore those dumps

in databases in the unprotected environment. A

significant challenge while transferring the test data

was to manage the access controls and firewalls.

iSTDE uses a number of built-in scripts in

confidential environment to manage these network

transfer obstacles.

SEMANTIC BASED TEST DATA EXTRACTION FOR INTEGRATED SYSTEMS (iSTDE)

179

4.6 Destroying Mappings

In this semantic-based extraction process, iSTDE

produces and uses data files and domain

dictionaries. The data files are created in the third

step of iSTDE execution and contain extracted

records from different database managers, whereas

domain dictionaries are developed in the fourth step.

These domain dictionaries are a sort of mapping

table that helps in shuffling the records. Ideally, this

step destroys all traces i.e., data files and domain

dictionaries that could indentify or even hint at any

sensitive information about the patients. Thus,

iSTDE ensures the sensitivity of patients records by

deleting the temporary databases as well as the data

files mentioned above.

5 EXPERIENCES WITH ISTDE

We have used iSTDE to test several key CHARM

components. For example, it was particularly

useful in testing the SyncEngine because its primary

function is to correlate data among multiple PP.

Previously, testing the SyncEngine required

developers to create test data manually. Not only

was this very time consuming, but it resulted in test-

data sets with limited coverage. The CHARM

developers found data set produced by iSDTE to be

good approximation of the real data and that they

properly hid personal identities. Most importantly,

the CHARM developers found several critical

software faults using the iSDTE test data that would

have been difficult to find with handcrafted test

data. The CHARM developer had similar

experiences testing the CHARM matcher and web

interface.

6 FUTURE WORK AND

SUMMARY

iSDTE is a work in progress and would benefit from

a few enhancements. First, iSTDE currently is a

desktop-based application that runs in a confidential

environment by external actor. With some minor

modifications it could be converted into a web-

service-based application that can make it accessible

without physical interaction. Second, it could be

enhanced to allow incremental construction of test

sets. This would allow the developers to extract an

initial slice of test data and then add to it later, if a

large test-data set is needed. Third, iSTDE could be

further optimized to reduce execution time by better

restructuring some of SQL queries that extract data

from PPs and by improving the efficiency of the

data mangling. Finally, the current iSTDE is tightly

coupled to source databases, so addition of a new

database requires developers to add modules that are

specific to the new database. With some refactoring

and application of the Adapter Pattern

[11]

, this

undesirable coupling could be reduced or

eliminated.

In summary, preliminary indications are that

iSTDE is very beneficial for testing integrated

systems and merits further enhancement and study.

REFERENCES

GenerateData.com, a tool for generating test data, last

accessed on December 22, 2008.

SqlEdit, www.sqledit.com, last accessed on November 28,

2008.

www.forsql.com, a tool for automatics generating test

data for developers, last accessed on December 30,

2008.

http://www.tethyssolutions.com/T10.htm, a tool for

generating meaningful randomized data for QA

testing, load testing, last accessed on December 30,

2008.

www.tns-soft.com, a tool for generating meaningful

randomized data for QA testing, load testing, last

accessed on December 30, 2008.

CHARM Exective summary reference.

www.datanamic.com, generate the test data from a

variety of sources, including the database tables, last

accessed on December 30, 2008.

www.turbodata.ca, generate the test data from a real

database, last accessed on February 11, 2008.

R.Maddy, DBTESTGEN – MS Thesis 2006, Computer

Science Department, Utah State University.

Clyde, S., and Salkowitz, S., The Unique Records

Portfolio, Public Health Informatics Institute, Decatur,

GA, April, 2006.

Refactoring: Improving the Design of Existing Code

(Addison-Wesley Series) by M. Fowler

http://www.sqlmanager.net/en/products/postgresql/datage

nerator, generate the test data by a variety of sources,

last accessed on February 11, 2008.

Bersano, T., Clement, B., and Shilkrot, L. Synthetic Data

for Testing in Databases, University of Michigan,

1997.

Harper, K.E. Syntactic and semantic problems in

automatic sentence generation. In Proceedings of

International Conference on Computational

Linguistics, 1967, 1-9.

Chays, D., Dan, S., Vokolos, F.I., and Weyuker, E.J. A

framework for testing database applications. In

ISSTA

2000, ACM 1-58113-266-2.

Phyllis F., D. Chays, Test data generation for relational

database applications, 2004, ACM AA13115007.

HEALTHINF 2010 - International Conference on Health Informatics

180
