ReHap: AN INTEGRATED SYSTEM FOR THE HAPLOTYPE

ASSEMBLY PROBLEM FROM SHOTGUN SEQUENCING DATA

Filippo Geraci and Marco Pellegrini

IIT-CNR, Via Moruzzi 1, Pisa, Italy

Keywords:

Haplotype assembly problem, Single individual haplotype reconstruction, Shotgun sequencing.

Abstract:

Single nucleotide polymorphism (SNP) is the most common form of DNA variation. The set of SNPs present

in a chromosome (called the haplotype) is of interest in a wide area of applications in molecular biology and

biomedicine. Personalized haplotyping of (portions of/all) the chromosomes of individuals is one of the most

promising basic ingredients leading to effective personalized medicine (including diagnosis, and eventually

therapy). Personalized haplotyping is getting now technically and economically feasible via steady progress

in shotguns sequencing technologies (see e.g. the 1000 genomes project - A deep catalogue of human genetic

variations). One key algorithmic problem in this process is to solve the haplotype assembly problem, (also

known as the single individual haplotyping problem), which is the problem of reconstructing the two haplo-

type strings (paternal and maternal) using the large collection of short fragments produced by the PCR-based

shotgun technology. Although many algorithms for this problem have been proposed in the literature there has

been little progress on the task of comparing them on a common basis and on providing support for selecting

the best algorithm for the type of fragments generated by a speciﬁc experiment. In this paper we present Re-

Hap, an easy-to-use AJAX based web tool that provides a complete experimental environment for comparing

ﬁve different assembly algorithms under a variety of parameters setting, taking as input user generated data

and/or providing several fragment-generation simulation tools. This is the ﬁrst published report of a compari-

son among ﬁve different haplotype assembly algorithms on a common data and algorithmic framework. This

system can be used by researchers freely at the url: http://bioalgo.iit.cnr.it/rehap/.

1 INTRODUCTION

Shotgun sequencing technology (Pop, 2004) has been

key to the determination of whole genomes of sev-

eral higher species, most notably homo sapiens (Is-

trail et al., 2004). More recently the attention has

shifted from what is common among members of

a species (the genome), to what is different among

members of the same species, thus to the individual

variations in the chromosomic content. This shift is

driven by two forces. One is the importance of pro-

ﬁling individual genetic features for the purposed of

individual genomic medicine (Crawford and Nicker-

son, 2005). The second force is the steady decrease

in the cost of sequencing equipment that will soon

render cost-effective the effort of producing complete

genomic proﬁles of individuals versus collecting data

on predeﬁned genetic markers, for which other tech-

nologies (such as those based on micro-arrays) may

be more suitable. The ﬁrst publication of a com-

plete individual diploid human genome sequence has

been announced (Levy et al., 2007) in 2007, and two

individual diploid human sequences were published

in 2008 (Wang and et al., 2008; Wheeler and et al.,

2008). An ambitious project to determine the genetic

proﬁle of about 1200 individuals all over the world

has been launched in 2008 (see. “1000 Genomes

Project - A Deep Catalog of Human Genetic Varia-

tion” http://www.1000genomes.org). As for the cost-

effectiveness of the sequencing technology, the cur-

rent aim of the research community is to attain within

a few yearsa cost of 1000 USD per individual genome

sequenced (Mardis, 2006). The cost of state-of-the-

art technology is decreasing (von Bubnoff, 2008), so

to make the 1000 USD target a realistic one.

The role of individual genomic variations and their

impact in the emergence of diseases is also at the

core of the so called Common disease common

variation hypothesis (CDCV) (Iles, 2008), (Schork

et al., 2009). The compilation of complete individ-

ual genomes including rare (or private) variants might

help in predicting traits and diseases in that particular

Geraci F. and Pellegrini M. (2010).

ReHap: AN INTEGRATED SYSTEM FOR THE HAPLOTYPE ASSEMBLY PROBLEM FROM SHOTGUN SEQUENCING DATA.

In Proceedings of the First International Conference on Bioinformatics, pages 19-25

DOI: 10.5220/0002713400190025

 SciTePress

person. Thus it is important to produce accurate in-

dividual haplotype maps in a timely manner and with

reduced costs.

A key component of the reconstruction pipeline

is the so called ”haplotype assembly” problem

((Halld´orsson et al., 2004), (Zhao et al., 2007),

(Bonizzoni et al., 2003)). During the fragment gen-

eration phase, depending on the precise technology

used (Morozova and Marra, 2008), a large set of frag-

ments of length in the range of 200/900 bases are read

which cover with multiple overlays the (portion of)

chromosome being analyzed. By the use of refer-

ence maps it is relatively easy to locate the position

and orientation of such fragments in the chromosome,

but not to determine the association of the fragments

to the two homologous copies (paternal and mater-

nal) of a chromosome. The haplotype assembly prob-

lem is the problem of determining the association of

each fragment to one of the two homologous chromo-

somes and to determine the haplotype (i.e. the value

of the bases in the SNP positions of the two homol-

ogous chromosomes). In absence of errors or gaps,

with sufﬁcient coverage, this problem is easily solved,

however more realistic models of the problem take

into account several types and sources of error/noise

in the data, and in this setting the problem is much

more challenging (intractable in some cases). Sev-

eral algorithms and heuristics have been proposed in

the literature to solve the haplotype assembly prob-

lem (see e.g. (Rizzi et al., 2002; Li et al., 2003; Pan-

conesi and Sozio, 2004; Zhao et al., 2005; Lindsay

et al., 2005; Wang et al., 2007; Cilibrasi et al., 2007;

Genovese et al., 2008; Chen et al., 2008; Bansal and

Bafna, 2008)).

A common feature of all these researches is that,

due to lack of a common benchmark and of publicly

available implementations in a uniﬁed framework, ex-

perimental comparisons among different methods are

based on a narrow choice of data, parameters and al-

gorithms. Thus, in the view of large scale haplotyp-

ing projects, when the need comes to test the avail-

able algorithms onto the set of data and parameters

of a speciﬁc experiment and/or technology, the ques-

tion as to the best algorithm to employ is currently

not explored to the its full extent. To remedy this situ-

ation, and to provide a service to the bioinformatics

community, we have developed the web-based tool

(ReHap) that provides an easy to use environment for

testing several algorithms, on a variety of data sets,

and with a variety of parameter settings. We envision

three modalities of use for our tool.

(I) In modality (I) the user supplies as input the two

testing haplotype strings and sets a series of pa-

rameters relative to the simulation of the fragment

generation. The system simulates the fragmen-

tation process, applies any number of algorithms

(among the 5 methods currently supported) and is

able to measure the reconstruction rate and the re-

construction time of those methods.

(II) In modality (II) the user provides to the system

a matrix of fragments and the system returns the

reconstructed haplotypes. Note that in this case

the reconstruction error cannot be computed by

ReHap. However the quality of the reconstruction

can be assessed by the user that has generated the

fragments.

(III) In modality (III) the user has no data yet but an

hypothesis to be tested on the basic parameters of

the experiment/techology to be employed. In this

case ReHap will use data from Hapmap ((Consor-

tium, 2005)) as haplotype test data. The recon-

struction rate and the reconstruction time is then

measured.

Modality III is interesting since in this modality Re-

Hap can give guidance in an early critical stage of ex-

perimental design. In particular the length of the hap-

lotypes chunks to be reconstructed, the (minimum,

average) coverage of each SNP by fragments, and the

error rate that can be handled in the ﬁnal reconstruc-

tion phase are critical parameters to be assessed in

early stage of design. Modality I and II can be use-

ful by researchers wishing to develop new assembly

algorithms (even exploiting additional private infor-

mation) since ReHap can provide a common testing

framework and a reference benchmark for the assess-

ment of performance.

ReHap is complementary to other tools such as

Haploview (Barrett et al., 2005), where the emphasis

is on visualization and computation of statistics for

haplotype data from population studies (mainly geno-

type data).

The paper is organized as follows. Section 2 de-

scribes the web interface and the practical use of the

tool. Section 3 gives a brief self-contained description

of the ﬁve reconstruction algorithms currently sup-

ported. Section 4 gives an example of the results that

can be obtained with this tool.

2 FUNCTIONALITIES

ReHap allows the user to generate a SNP matrix

starting from a pair of haplotypes provided by the

HapMap project (Consortium, 2005) (or submits

his/her own data) according to some user-deﬁned pa-

rameters. Haplotypes in (Consortium, 2005) came

from four different populations. For each population,

BIOINFORMATICS 2010 - International Conference on Bioinformatics

a number ranging from 44 to 60 of different individu-

als, equally divided in males and females, are avail-

able (in total 209 unrelated individuals). For each

individual the two haplotypes of chromosomes 1-22

are available. For females also the haplotypes of X

chromosome are available. The SNP matrix is gener-

ated according to a model similar to that proposed in

(Myers, 1999), which is considered a good approxi-

mation of the actual physical process of shotgun se-

quencing technology. The generator allows users to

select a speciﬁc chromosome, individual and popula-

tion. Once selected the desired haplotype, it is possi-

ble to control many other parameters. Among them:

the haplotype length, the average coverage of each

haplotype, the error probability, a range specifying

the length of each fragment, a range specifying the

expected hamming distance of the two haplotypes,

and the gaps rate. By default ReHap’s parameters are

set with technologically reasonable values. ReHap al-

lows also the user to upload his/her own SNP matrix.

The generated SNP matrix (with and without er-

rors) can be downloaded or inspected inside ReHap.

Errors are highlighted using color codes and the cor-

rect value showed just clicking on an error basis. Be-

sides the SNP matrix, ReHap also computes as a refer-

ence baseline the output of an “omniscient algorithm”

(called the baseline) that can access the true subdivi-

sion of the fragments but still decides the imputation

of SNPs based on majority.

ReHap allows the user to test and evaluate the ef-

fectiveness of four recent reconstruction algorithms:

SpeedHap (Genovese et al., 2008) (a robust algorithm

for individual haplotype reconstruction developed by

the authors), Fast Hare (Panconesi and Sozio, 2004)

(a well known algorithm in the bio-informatics com-

munity), MLF (Zhao et al., 2005), and a two-distances

clustering algorithm for the MEC model (Wang et al.,

2007). All methods have been re-implemented by the

authors. SpeedHap has a ﬂag to enable the use a en-

tropic ﬁlter to break ties in the reconstruction of the

haplotypes. MLF accepts as a parameter the number

of trials to run before selecting the “best” haplotypes.

Besides running time, for each selected algorithm Re-

Hap displays the returned haplotype and highlights

the reconstruction errors. Moreover a synthetic nu-

merical evaluation of the performance of each al-

gorithm is computed by the standard reconstruction

rate. All these outputs are available when the data is

generated by ReHap. When the SNP matrix is upload

from the user, only the reconstructed haplotypes are

returned. ReHap provides a contextual help for each

feature of the interface, and a general help page.

3 ALGORITHMS SUPPORTED

ReHap implements ﬁve recently proposed algorithms

for the haplotype assembly problem: Speedhap (Gen-

ovese et al., 2008), FastHare (Panconesi and Sozio,

2004), MLF (Zhao et al., 2005), 2D (Wang et al.,

2007) and SHR (Chen et al., 2008). These ﬁve al-

gorithm have been selected because (i) they represent

different approaches to the assembly problem and (ii)

they are described in the literature with sufﬁcient de-

tail so that accurate re-implementation is possible.

A common feature of the above cited algorithms

is the use of a notion of distance similar to the stan-

dard Hamming distance to compare two fragments.

When considering a certain position of the compared

strings, if both character in that position are not gaps

they contribute to the distance as in the case of stan-

dard Hamming distance, otherwise they do not con-

tribute. In the following, for sake of completeness,

we provide synthetic description of the implemented

algorithms.

SpeedHap (Genovese et al., 2008) follows a multi-

phase greedy approach: it has four phases and makes

choices that are optimal in a local sense. In each

phase SpeedHap performs three tasks: 1) detect likely

positions of errors 2) allocate fragments to the two

partially built haplotype strings, and 3) build partial

haplotype strings deciding via majority on ambigu-

ous SNPs calls. The difference among the four phases

is twofold: on one hand the algorithm uses knowl-

edge built up in the previous phases, and on the other

hand in passing from one phase to the next it relaxes

the conditions for the decisions to be taken regarding

tasks 1), 2) and 3). The aim is to be always very con-

servatives in the choices made so to introduce as little

error as possible in the early phases. MoreoverSpeed-

Hap (Genovese et al., 2008) solves ties in the allele

determination using an entropy-based biased ﬁlter so

to give priority to choices that reduce the entropy of

the ﬁnal solution.

Fash Hare (Panconesi and Sozio, 2004) is the oldest

simple and practical heuristic algorithm for the hap-

lotype reconstruction problem. It is widely used as a

benchmark for comparisons. In a nutshell, Fast Hare

works as follows: as ﬁrst step the fragments of the

SNP matrix are sorted so that a fragment precedes

another fragment if the position of the ﬁrst non-gap

character of the former is lower or equal to the ﬁrst

non-gap position of the latter. The main loop of Fast

Hare consists in processing the fragments in the SNP

matrix one at time according to their ordering and di-

viding them in two sets. The ﬁrst set is initialized

with the ﬁrst fragment while the second set is left

empty. At each iteration, from each set Fast Hare de-

ReHap: AN INTEGRATED SYSTEM FOR THE HAPLOTYPE ASSEMBLY PROBLEM FROM SHOTGUN

SEQUENCING DATA

0.7

0.75

0.8

0.85

0.9

0.95

3 4 5 6 7 8 9 10 11 12

average reconstruction rate

Coverage

Baseline

Fast Hare

SHR

SpeedHap

MLF

Figure 1: Reconstruction rate of 5 reconstruction algorithms and the baseline algorithm for covering in the range [3,..,10].

The other parameters are ﬁxed: error rate 0.15 and haplotype length 250 bases. Each point is the average of 20 experiments

with randomly chosen haplotype strings of Hapmap.

rives the consensus haplotypes. A fragment is com-

pared to the consensus haplotypes and assigned to the

set with lower distance.

The MLF algorithm (Zhao et al., 2005) is based on the

well-known one-pass k-means clustering algorithm

due to McQueen (McQueen, 1967). The procedure

initialization consists in randomly splitting the SNP

matrix in two partitions and, for each one, compute

its consensus string. Then, in the main loop fragments

are partitioned again in two sets according to the fol-

lowing procedure. Each fragment is compared with

the two consensus strings and assigned to the set as-

sociated to the closest haplotype. Once all fragments

are processed two new consensus strings can be com-

puted and returned. Since this procedure performance

strongly depends from the initial random partition, it

is repeated a certain (large) number of times and as ﬁ-

nal result is returned the pair of consensus haplotypes

that minimize the MEC (Minimum Error Correction)

score.

The 2D algorithm (Wang et al., 2007) main contri-

bution is the introduction of a notion of distance that

overcome the structural drawbacks of Hamming dis-

tance which assign distance 0 to both: two equal

strings and two strings which cover two disjoint set of

SNPs. The distance introduced in 2D not only gives

a penalty to different characters in a certain position,

but also gives a bonus to equal (not gaps) characters

in a certain position. The procedure goal is to par-

tition the rows of the SNP matrix in two partitions

and works as follows: using the Hamming distance

compute the two furthest fragments and initialize each

partition with one of them. Each fragment is com-

pared using the Hamming distance with the consen-

sus strings derived from each partition. In case of tie

the second distance function is used to break the tie

and select the partition to which assign the fragment.

The corresponding consensus haplotype is updated.

The SHR algorithm (Chen et al., 2008) uses a prob-

abilistic framework to approach the SIH problem.

Fragments in the SNP matrix are divided in two par-

titions according with the following procedure. At

the beginning two fragments f

and f

randomly ex-

tracted from the SNP matrix are used to initialize two

empty sets, Then, each fragment is compared to f

and f

and inserted in the set corresponding to the

lower distance. Once all fragments are assigned to a

set, the procedure computes the MEC score induced

from f

, f

and the computed bipartition. Due to its

probabilistic nature, the above procedure is repeated

a certain number of times and as ﬁnal bipartition it is

selected the one with lower MEC score. At the end

the consensus haplotypes are computed by majority

from the ﬁnal bipartition. The main contribution of

this algorithm stands in the theoretical framework de-

veloped by its authors.

BIOINFORMATICS 2010 - International Conference on Bioinformatics

0.65

0.7

0.75

0.8

0.85

0.9

0.95

0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4

average reconstruction rate

Error rate

Baseline

Fast Hare

SHR

SpeedHap

MLF

Figure 2: Reconstruction rate of 5 reconstruction algorithms and the baseline algorithm for error rates in the range [0.0,..,0.30].

The other parameters are ﬁxed: covering 8 and haplotype length 250 bases. Each point is the average of 20 experiments with

randomly chosen haplotype strings of Hapmap.

4 EXPERIMENTS

In this section we report on experiments in modality

(III), using Hapmap data to explore relative perfor-

mance in a range of possible parameter choices. We

concentrate on three parameters (covering, error rate,

length) and we measure the reconstruction rate

of the

reconstructed haplotype returned by ﬁve algorithms.

The reconstruction rate is a real number in the range

[0.0, .., 1.0] and has value 1.0 for perfect reconstruc-

tion. We also include the outcome of the baseline al-

gorithm that has access to the true association of the

fragments to the two haplotype strings and decides the

base call by majority vote. This algorithm is clearly

useful only as a reference in simulations, as an ideal

for the proper algorithms that have no access to this

information. To the best of our knowledge this is the

ﬁrst published report of a comparison among ﬁve dif-

ferent haplotype assembly algorithms on a common

data and algorithmic framework.

As fragment coverage increases we expect the perfor-

mance of all the algorithms also to improve. This is

expectation conﬁrmed for all algorithms, except SHR

that seems unaffected. From ﬁgure 1 one can observe

that for high coverage (say 10 and more) SpeedHap,

The reconstruction rate is the ratio of correctly re-

constructed bases over the length of the reconstructed se-

quences.

Fast Hare, MLF and 2D match the baseline and are

above 95% reconstruction rate, while at low cover-

age (3-7) Speedhap is notably more accurate and very

close to the baseline.

From ﬁgure 2 one observes that increasing the error

rate in the range [0.0,..,0.3] the baseline reference al-

gorithm is also affected. This is to be expected, as the

accumulation of many errors in the same SNP posi-

tion makes it impossible even for the baseline method

to decide correctly by majority. Speedhap although

performing worse than the baseline is not far from it,

and it is much better than the other 4 algorithms at

high error rate, attaining a respectable reconstruction

rate only 0.1 below the baseline, even with 30% of

reading errors. Fast Hare MLF, and 2D perform rea-

sonably well, better than SHR, but all four converge

to the similar reconstruction rate (about 0.70-0.75) for

the higher reading error situation.

From ﬁgure 3 one can observe that for the set of pa-

rameters tested the length of the haplotype has little

inﬂuence on the relative performance of the 5 algo-

rithms w.r.t. the baseline. Speedhap, Fast hare and

2D have reconstruction rate above 90% for the range

of length considered, while MLF and SHR have re-

construction rate in a lower region (0.75% - 0.85%).

ReHap: AN INTEGRATED SYSTEM FOR THE HAPLOTYPE ASSEMBLY PROBLEM FROM SHOTGUN

SEQUENCING DATA

0.75

0.8

0.85

0.9

0.95

100 200 300 400 500 600

average reconstruction rate

Haplotype length

Baseline

Fast Hare

SHR

SpeedHap

MLF

Figure 3: Reconstruction rate of 5 reconstruction algorithms and the baseline algorithm for length in the range [50,..,500].

The other parameters are ﬁxed: error rate 0.15 and covering 8. Each point is the average of 20 experiments with randomly

chosen haplotype strings of Hapmap.

5 CONCLUSIONS

The integrated frameworkReHap for testing and com-

paring ﬁve different haplotype assembly algorithms

is described. Our hope is that ReHap will help the

bioinformatics community in selecting the most suit-

able algorithm for each speciﬁc haplotype assem-

bly task, as large scale individual haplotyping pro-

grammes are getting momentum. This system can

be accessed and used by researchers freely at the

url: http://bioalgo.iit.cnr.it/rehap/ without any login

requirement.

ACKNOWLEDGEMENTS

This work was supported by the European Com-

munity’s Seventh Framework Programme FP7/2007-

2013 under grant agreement N 223920 (Virtual Phys-

iological Human Network of Excellence).

REFERENCES

Bansal, V. and Bafna, V. (2008). Hapcut: an efﬁcient and

accurate algorithm for the haplotype assembly prob-

lem. Bioinformatics, 24(16):i153–159.

Barrett, J. C., Fry, B., Maller, J., and Daly, M. J. (2005).

Haploview: analysis and visualization of LD and hap-

lotype maps. Bioinformatics, 21(2):263–265.

Bonizzoni, P., Vedova, G. D., Dondi, R., and Li, J. (2003).

The haplotyping problem: an overview of computa-

tional models and solutions. J. Comput. Sci. Technol.,

18(6):675–688.

Chen, Z., Fu, B., Schweller, R. T., Yang, B., Zhao, Z.,

and Zhu, B. (2008). Linear time probabilistic algo-

rithms for the singular haplotype reconstruction prob-

lem from snp fragments. In Brazma, A., Miyano, S.,

and Akutsu, T., editors, APBC, volume 6, pages 333–

342. Imperial College Press.

Cilibrasi, R., van Iersel, L., Kelk, S., and Tromp, J. (2007).

On the complexity of the single individual SNP hap-

lotyping problem. Algorithmica.

Consortium, T. I. H. (2005). A haplotype map of the human

genome. Nature, 437:1299–1320.

Crawford, D. and Nickerson, D. (2005). Deﬁnition and

clinical importance of haplotypes. Annu. Rev. Med.,

56:303–320.

Genovese, L., Geraci, F., and Pellegrini, M. (2008). Speed-

hap: An accurate heuristic for the single individual

snp haplotyping problem with many gaps, high read-

ing error rate and low coverage. IEEE/ACM Transac-

tions on Computational Biology and Bioinformatics,

5(4):492–502.

Halld´orsson, B. V., Bafna, V., Edwards, N., Lippert, R.,

Yooseph, S., and Istrail, S. (2004). A survey of com-

putational methods for determining haplotypes. In

BIOINFORMATICS 2010 - International Conference on Bioinformatics

Computational Methods for SNPs and Haplotype In-

ference, volume 2983 of Lecture Notes in Computer

Science, pages 26–47.

Iles, M. M. (2008). What can genome-wide association

studies tell us about the genetics of common disease?

PLoS Genet, 4(2).

Istrail, S., Sutton, G. G., Florea, L., Halpern, A. L., Mo-

barry, C. M., Lippert, R., Walenz, B., Shatkay, H.,

Dew, I., Miller, J. R., Flanigan, M. J., Edwards, N. J.,

Bolanos, R., Fasulo, D., Halldorsson, B. V., Hannen-

halli, S., Turner, R., Yooseph, S., Lu, F., Nusskern,

D. R., Shue, B. C., Zheng, X. H., Zhong, F., Delcher,

A. L., Huson, D. H., Kravitz, S. A., Mouchard, L.,

Reinert, K., Remington, K. A., Clark, A. G., Water-

man, M. S., Eichler, E. E., Adams, M. D., Hunkapiller,

M. W., Myers, E. W., and Venter, J. C. (2004). Whole-

genome shotgun assembly and comparison of human

genome assemblies. Proceedings of the National

Academy of Sciences of the United States of America,

101(7):1916–1921.

Levy, S., Sutton, G., Ng, P., Feuk, L., Halpern, A., and et al.

(2007). The diploid genome sequence of an individual

human. PLoS Biology, 5(10).

Li, L., Kim, J. H., and Waterman, M. S. (2003). Haplo-

type reconstruction from SNP alignment. In Proceed-

ings of the seventh annual international conference

on Computational molecular biology, pages 207–216.

ACM Press.

Lindsay, S. J., Bonﬁeld, J. K., and Hurles, M. E. (2005).

Shotgun haplotyping: a novel method for surveying

allelic sequence variation. Nucl. Acids Res., 33(18).

Mardis, E. R. (2006). Anticipating the $1,000 genome.

Genome Biology, 7.

McQueen, J. (1967). Some methods for classiﬁcation and

analysis of multivariate observations. In Proc. of the

Berkeley Symposium on Mathematical Statistics

and Probabilily, volume 1, pages 281–297. University

of California Press.

Morozova, O. and Marra, M. A. (2008). Applications of

next-generation sequencing technologies in functional

genomics. Genomics, 92(5):255 – 264.

Myers, G. (1999). A dataset generator for whole genome

shotgun sequencing. In Proceedings of the Seventh

International Conference on Intelligent Systems for

Molecular Biology, pages 202–210. AAAI Press.

Panconesi, A. and Sozio, M. (2004). Fast hare: A fast

heuristic for single individual SNP haplotype recon-

struction. In WABI, pages 266–277.

Pop, M. (2004). Shotgun sequence assembly. Advances in

Computers, 60:193–248.

Rizzi, R., Bafna, V., Istrail, S., and Lancia, G. (2002). Prac-

tical algorithms and ﬁxed-parameter tractability for

the single individual SNP haplotyping problem. In

Proceedings of the Second International Workshop on

Algorithms in Bioinformatics, pages 29–43. Springer-

Verlag.

Schork, N. J., Murray, S. S., Frazer, K. A., and Topol, E. J.

(2009). Common vs. rare allele hypotheses for com-

plex diseases. Current Opinion in Genetics & Devel-

opment, 19(3):212 – 219.

von Bubnoff, A. (2008). Next-generation sequencing: The

race is on. Cell, 132(5):721 – 723.

Wang, J. and et al. (2008). The diploid genome sequence of

an asian individual. Nature, 456:60–65.

Wang, Y., Feng, E., and Wang, R. (2007). A clustering algo-

rithm based on two distance functions for mec model.

Computational Biology and Chemistry, 31(2):148–

150.

Wheeler, D. and et al. (2008). The complete genome of

an individual by massively parallel dna sequencing.

Nature, 452:872–876.

Zhao, Y., Xu, Y., Zhang, Q., and Chen, G. (2007). An

overview of the haplotype problems and algorithms.

Frontiers of Computer Science in China, 1(3):272–

282.

Zhao, Y.-Y., Wu, L.-Y., Zhang, J.-H., Wang, R.-S., and

Zhang, X.-S. (2005). Haplotype assembly from

aligned weighted SNP fragments. Computational Bi-

ology and Chemistry, 29(4):281–287.

ReHap: AN INTEGRATED SYSTEM FOR THE HAPLOTYPE ASSEMBLY PROBLEM FROM SHOTGUN

SEQUENCING DATA
