AN ONLINE SPEAKER TRACKING SYSTEM

FOR AMBIENT INTELLIGENCE ENVIRONMENTS

Maider Zamalloa, Mikel Penagarikano, Luis Javier Rodríguez-Fuentes, Germán Bordel

GTTS, Department of Electricity and Electronics, University of the Basque Country, Leioa, Spain

Juan Pedro Uribe

Ikerlan - Technological Research Centre, Mondragón, Spain

Keywords: Speaker tracking, Ambient intelligence, AMI Corpus.

Abstract: Ambient intelligence is an interdisciplinary paradigm which envisages smart spaces that provide services

and adapt transparently to the user. As the most natural interface for human interaction, speech can be ex-

ploited for adaptation purposes in such scenarios. Low latency is required, since adaptation must be conti-

nuous. Most speaker tracking approaches found in the literature work offline, fully processing pre-recorded

audio files by a two-stage procedure: (1) performing acoustic segmentation and (2) assigning each segment

a speaker label. In this work a real-time low-latency speaker tracking system is presented, which deals with

continuous audio streams. Experimental results are reported on the AMI Corpus of meeting conversations,

revealing the effectiveness of the proposed approach when compared to an offline speaker tracking system

developed for reference.

1 INTRODUCTION

Ambient Intelligence (AmI) is an interdisciplinary

applied research field, aiming to create smart spaces

which provide services featuring user and context

adaptation capabilities (ISTAG, 2001) (Cook, 2009).

It was originally devised as Ubiquitous Computing

in (Weiser, 1991) where it was suggested the

interaction of consumer electronics,

telecommunications and computing devices to

support people carrying out everyday life activities

in a natural way. In such environment, daily objects

feature computing and telecommunication

capabilities. Transparency is critical, so natural and

intelligent interfaces are needed for human-computer

interaction (Abowd, 2005). Speech is a natural

interface for human interaction and the most suitable

means to support user interaction and adaptation.

Speech streams can be exploited to extract user

related information such as location, identity, etc.

But in such environments, user adaptation must be

continuous, and low-latency online processing is

needed.

Speaker diarization and speaker tracking are well

known tasks which aim to answer the question Who

spokes when?. Speaker tracking aims to detect

segments corresponding to a known set of target

speakers (Martin, 2001). Speaker diarization consists

of detecting speaker turns without any prior

knowledge about the target speakers (Tranter, 2006)

(Meignier, 2006). Speaker diarization and tracking

primary applications domains assume that audio

recordings are fully available before processing.

Common approaches to these tasks consist of two

uncoupled steps: (1) audio segmentation and (2)

speaker detection. In speaker diarization, segments

hypothetically uttered by the same speaker are

clustered together. In speaker tracking, however,

once the audio stream is segmented, speaker

detection is carried out through classical speaker

recognition techniques (Moraru, 2005) (Istrate,

2005) (Bonastre, 2000). In any case, these

methodologies are not suitable for low-latency

online speaker detection.

Few works related to real-time speaker

segmentation and tracking can be found in the

literature (Wu, 2003) (Lu, 2005) (Liu, 2005). Most

of the speaker segmentation approaches are based on

343

Zamalloa M., Penagarikano M., Javier Rodríguez-Fuentes L., Bordel G. and Pedro Uribe J. (2010).

AN ONLINE SPEAKER TRACKING SYSTEM FOR AMBIENT INTELLIGENCE ENVIRONMENTS.

In Proceedings of the 2nd International Conference on Agents and Artiﬁcial Intelligence - Artiﬁcial Intelligence, pages 343-349

DOI: 10.5220/0002734803430349

 SciTePress

metrics measuring spectral changes, such as

Bayesian Information Criterion (Chen, 1998) and

Generalized Likelihood Ratio (Bonastre, 2000) (Liu,

2005). These procedures are robust but

computationally expensive since two or three

Gaussian models must be estimated for scoring each

possible change point in each analysis window, and

there can be between 100 and 1000 analysis

windows per second. In (Wu, 2003), a real-time

model-based speaker change detection system is

proposed, where a Universal Background Model

(UBM) is taken as reference to classify speech

segments, and a distance between two adjacent

windows is computed which accounts for the

spectral change. In (Lu, 2005), an unsupervised

speaker segmentation and tracking algorithm is

presented. Once the speaker change boundaries are

determined, each segment is scored with a set of

incremental quasi Gaussian Mixture Models

corresponding to unknown target speakers. In (Liu,

2005), an online speaker adaptation methodology is

applied for real-time speaker tracking, with

unknown target speakers. This approach combines a

phonotactic speaker change detection module with

an online speaker clustering algorithm. Speaker

adaptation is based on feature transformation. The

transformation matrix is incrementally adapted as

labeled segments become available.

In this paper, a real-time low-latency online

speaker tracking approach is presented, designed for

an AmI scenario (for example, an intelligent home

environment), where the system continuously tracks

known speakers. The expected number of target

speakers is low (i.e. the members of a family). This

scenario requires taking almost instantaneous (low

latency) speaker tracking decisions. A very simple

speaker tracking algorithm is proposed, where audio

segmentation and speaker detection are jointly

accomplished by defining and processing fixed-

length audio segments and scoring each of them to

decide whether it belongs to a target speaker or to an

impostor. Audio segments are scored by means of

acoustic models (corresponding to target speakers)

estimated via Maximum a Posteriori (MAP)

adaptation of a UBM (Reynolds, 2000). The MAP-

UBM methodology yields good speaker recognition

performance and allows for a fast scoring technique

which speeds up the score computation. Finally,

detection scores are calibrated (i.e linearly mapped

to likelihood ratios) and then, based on the scores

obtained for a development corpus, an optimal

application-dependent decision threshold (that

minimizes the expected error cost) is established

(Brummer, 2006). The performance of the proposed

approach is compared to that of an offline system

developed for reference, which follows the classical

two-stage approach: audio segmentation is done

over the whole input stream, and MAP-UBM

speaker detection is performed on the resulting

segments. Speaker tracking experiments applying

both systems were carried out on the AMI Corpus

(Carletta, 2007), which contains human

conversations in the context of smart meeting rooms,

close to the AmI scenario described above.

The rest of the paper is organized as follows. In

section 2 the main features of the speaker tracking

systems are described, including the acoustic front-

end, the audio segmentation (required for the offline

reference system) and the speaker detection and

calibration stages. Section 3 gives details about the

experimental corpus and the UBM estimation.

Speaker tracking results using the proposed and the

reference systems are presented in section 4. Finally,

conclusions and guidelines for future work are given

in Section 5.

2 SPEAKER TRACKING

SYSTEMS

2.1 Acoustic Front-End

In this work, 16 kHz audio streams are analyzed in

frames of 20 milliseconds, at intervals of 10

milliseconds. A Hamming window is applied and a

512-point FFT computed. The FFT amplitudes are

then averaged in 24 overlapped triangular filters,

with central frequencies and bandwidths defined

according to the Mel scale. A Discrete Cosine

Transform is finally applied to the logarithm of the

filter amplitudes, obtaining 12 Mel-Frequency

Cepstral Coefficients (MFCC). To increase

robustness against channel distortion, Cepstral Mean

Normalization (CMN) is applied. When the audio

stream is processed on-the-fly, a dynamic CMN

approach is applied, the cepstral mean being updated

at each time t as follows:





1



(1)

where α is a time constant, C(t) is the vector of

cepstral coefficients at time t and µ

t-1

is the dynamic

cepstral mean at time t-1. After CMN, the first

derivatives of the MFCC are also computed,

yielding a 24-dimensional feature vector.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

344

2.2 Audio Segmentation

Audio segmentation, also known as acoustic change

detection, is required by most speaker tracking

systems as a previous step to the detection of target

speakers. A simple algorithm is applied in this work,

which segments the audio signal in a fully

unsupervised way, by locating the most likely

change points from a purely acoustic point of view.

The algorithm considers a sliding window W of N

acoustic vectors and computes the likelihood of

change at the center of that window, then moves the

window K vectors ahead and repeats the process

until the end of the vector sequence. To compute the

likelihood of change, each window is divided in two

halves, W

left

and W

right

, then a Gaussian distribution

(with diagonal covariance matrix) is estimated for

each half and finally the cross-likelihood ratio is

computed and stored as likelihood of change. This

yields a sequence of cross-likelihood ratios which

must be post-processed to get the hypothesized

segment boundaries. This involves applying a

threshold τ and forcing a minimum segment size δ.

In practice, a boundary t is validated when its cross-

likelihood ratio exceeds τ and there is no candidate

boundary with greater ratio in the interval [t-δ,t+δ]

(see (Rodriguez, 2007) for details).

2.3 Speaker Detection

The real-time speaker tracking system proposed in

this work computes a detection score per target

speaker and outputs a speaker identification decision

at fixed-length intervals. That length has been

empirically set to one second, which provides

relatively good time resolution and spectral richness,

and a reasonably small latency for most online

speaker tracking scenarios. The offline system

developed for reference does the same computation,

but using the segments produced by the algorithm

described in Section 2.2. Regardless the way audio

segments are obtained, they are scored with the same

set of MAP-UBM target speaker models (Reynolds,

2000).

In the adaptation of a speaker model from the

UBM, only non-overlapped training segments (i.e.

those segments containing only speech from that

speaker, according to the time references of manual

annotations) are used. This way, component

densities related to the acoustic classes strongly

observed in training data will change, whereas

component densities that correspond to weaker or

missing acoustic units (such as silence or impostors)

will remain un-adapted. Therefore, it is assumed that

the resulting MAP-UBM system should be able to

detect speech from target speakers and reject silence,

noise and speech from impostors.

Given the acoustic model λ

for the target

speaker s and λ

UBM

for the UBM, the detection score

∆

(X) is computed as follows:

∆

(X)= L(X|λ

) - L(X|λ

UBM

)

where L(X|λ) is the log-likelihood of X given λ.

Once the detection scores are computed for all the

target speakers, a unique identification decision is

made per segment: X is marked as coming from the

most likely target speaker s*=arg max

s∈[1,S]

{∆

(X)},

if ∆

(X) > θ. Otherwise X is marked as coming from

an impostor. The decision threshold θ can be

heuristically established to optimize the

discrimination. Note that, for any given segment X,

there could actually be two or more speakers

speaking at the same time. However, the detection

approach described above cannot inform of speaker

overlaps, because only the most likely speaker can

be detected.

2.4 Calibration of Scores

Calibration maps detection scores {∆

| s ∈ [1,S]} to

likelihood ratios {C(∆

)

| s ∈ [1,S]} without any

specific application in mind. The scaling parameters

are computed over a development corpus by

maximizing Mutual Information, which is equivalent

to minimizing the so called C

LLR

(a metric defined in

(Brummer, 2006)), which integrates the expected

cost over a wide range of operation points

(representing specific applications) in the Detection

Error Tradeoff (DET) curve (Martin, 1997). The

final decision is taken by applying the minimum

expected cost Bayes decision threshold to calibrated

scores C(∆). The target speaker is accepted only if

the following inequality holds:

  ln





1













(3)

where C

miss

and C

are miss and false-acceptance

error costs, and P

target

the prior probability of target

speakers. Scores are calibrated by means of the

FoCal toolkit, applying a linear mapping strategy

(see http://www.dsp.sun.ac.za/~nbrummer/focal/).

AN ONLINE SPEAKER TRACKING SYSTEM FOR AMBIENT INTELLIGENCE ENVIRONMENTS

345

3 EXPERIMENTAL SET-UP

3.1 The AMI Corpus

Experiments are carried out over the AMI Corpus of

meeting conversations, available as a public resource

(see http://corpus.amiproject.org/). The AMI Corpus

is a multimodal dataset concerned with real-time

human interaction in the context of smart meeting

rooms. Data, collected in three instrumented meeting

rooms, include a range of synchronized audio and

video recordings. Meetings contain speech in

English, mostly from non native speakers.

In this work, the development and evaluation of

speaker tracking systems is based on a subset of the

AMI Corpus, the Edinburgh scenario meetings,

including 15 sessions: ES2002-ES2016, with four

meetings per session, each meeting being half an

hour long on average. Training data are taken from

meetings recorded at the three AMI sites. The audio

stream is obtained by mixing the signals from the

headset microphones of the participating speakers.

Three of the four speakers participating in each

session are taken as target speakers, the remaining

one being assigned the role of impostor. Careful

impostor selection –not random– is made to account

for gender unbalanced sessions. In sessions

containing just one female speaker, the impostor is

forced to be male (and vice versa), in order to avoid

that gender favors impostor discrimination.

In order to assess the speaker tracking

performance in realistic conditions, two independent

subsets are defined, consisting of different sessions

(and therefore different speakers), for development

and evaluation purposes, respectively. The

development set, consisting of 8 sessions (32

meetings), is used to tune the configuration

parameters of the speaker tracking systems. The

evaluation set, including the remaining 7 sessions

(28 meetings), is used only to evaluate the

performance of the previously tuned speaker

tracking systems.

Both the development and evaluation subsets are

further divided into train and test datasets. Two

meetings per session are randomly selected for

training speaker models, and the remaining two are

left for testing purposes. Time references are based

on manual annotations provided in the AMI Corpus.

3.2 UBM Estimation

Two speaker detection systems have been developed

based on the MAP-UBM approach. They only differ

in the data used to estimate the UBM: UBM-g uses

15 gender-balanced AMI meetings from all sites

except Edinburgh (so, a kind of room mismatch may

be expected), whereas UBM-t uses only speech from

target speakers in training meetings. UBM-g is

estimated once and can be applied to whatever

evaluation data and target speakers, whereas UBM-t

must be estimated specifically for each set of target

speakers.

3.3 Performance Measures

The performance of speaker tracking systems is

commonly analyzed by means of Detection Error

Tradeoff (DET) plots (Martin, 1997). Performance is

measured in terms of time that is correctly or

incorrectly classified as belonging to a target.

Therefore, miss and false alarm rates are computed

as a function of time (Martin, 2001) and not as a

function of trial number, like in speaker detection

experiments.

DET performance can be summarized in a single

figure by means of the Equal Error Rate (EER), the

point of the DET curve at which miss and false

alarm rates are equal. Obviously, the lower the EER,

the higher the accuracy of a speaker tracking system.

Another way to summarize in a single figure the

performance of a speaker tracking system is the so

called F-measure, defined as follows:



2.0PRC  RCL

PRC  RCL

(4)

where precision (PRC) and recall (RCL) are related

to false alarm and miss rates respectively. PRC

measures the correctly detected target time from the

total target time detected. RCL computes the

correctly detected target time from the actual target

time. The F-measure ranges from 0 to 1, with higher

values indicating better performance. Collar periods

of 250 milliseconds at the end of speaker turns are

ignored for scoring purposes. Thus, speaker turns of

less than 0.5 seconds are not scored.

4 EXPERIMENTAL RESULTS

Figures 1 and 2 show the performance of the online

and offline speaker tracking systems, using UBM-g

and UBM-t as background models, for the

development and evaluation sets, respectively. Since

the speaker detection strategy followed in this work

cannot detect speaker overlaps, all the segments

containing speech from two or more speakers are

removed when scoring test meetings.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

346

Figure 1: DET performance of speaker tracking systems

on the development set defined on the AMI corpus.

Figure 2: DET performance of speaker tracking systems

on the evaluation set defined on the AMI corpus.

As expected, the classical offline system

outperforms the proposed low-latency online

system, but the performance of the latter is quite

good. Taking the performance of the offline system

as reference, in speaker tracking experiments over

the evaluation set, the EER increases from 25.80 to

26.20 (1.55% relative degradation) when using

UBM-g, and from 19.07 to 21.14 (10.85% relative

degradation) when using UBM-t. On the other hand,

UBM-t systems outperform UBM-g systems, maybe

due to the aforementioned room mismatch in UBM-

g and the limited amount of training data.

In addition, performance degradation from

development to evaluation is small (from around

20% to 21% EER) in MAP-UBM-t, which means

that system configuration (based on the development

set) was also suitable for the evaluation set. The

MAP-UBM-g system suffers a bigger degradation

from development to evaluation. It seems that

estimating the UBM from unknown speakers in

mismatched conditions (different rooms) degrades

acoustic coverage and reduces the robustness of

system configuration with regard to using a room-

specific UBM estimated from target speakers. The

UBM-t system might be getting advantage not only

from matching the room, but also from the

consistency between the speakers in the UBM and

the target speakers. In fact, 100% of the target

speakers appearing in the test corpus contribute data

to the UBM-t, increasing the consistency of speaker

models estimated through MAP adaptation (because

a perfect match exists between the adaptation data

corresponding to any target speaker and some of the

component densities of the UBM).

Table 1 shows precision (PRC), recall (RCL) and

F-measure performance of the speaker tracking

systems, for both the calibrated and uncalibrated

speaker detection scores. These results correspond to

the operation point (threshold) considered optimal in

the DET curve. The threshold used for calibrated

scores is based on application-dependent costs and

target priors, adjusted on the development corpus.

For uncalibrated scores, the threshold is fixed to

zero, i.e. a target speaker is detected if the likelihood

of the null hypothesis is higher than that of the

alternative hypothesis.

Table 1: Precision (PRC), Recall (RCL) and F-measure

performance of the real-time (rt) and reference (ref)

speaker tracking systems, using UBM-g and UBM-t, on

the development (Dev) and evaluation (Eval) sets.

Uncalibrated Calibrated

PRC RCL F PRC RCL F

Dev

rt-UBM-g

0.66 0.92 0.77 0.81 0.8 0.81

ref-UBM-g

0.67 0.93 0.78 0.82 0.82 0.82

rt-UBM-t

0.67 0.91 0.77 0.82 0.83 0.82

ref-UBM-t

0.69 0.92 0.79 0.84 0.86 0.85

Eval

rt-UBM-g

0.69 0.92 0.78 0.78 0.85 0.8

ref-UBM-g

0.69 0.93 0.79 0.78 0.84 0.81

rt-UBM-t

0.71 0.91 0.8 0.81 0.85 0.83

ref-UBM-t

0.72 0.92 0.81 0.81 0.87 0.84

Results in Table 1 demonstrate the usefulness of

the calibration stage, which leads to better

performance in all cases. Finally, note that the real-

time (online, low-latency) system provides only

slightly worse performance than the reference

(offline) system: 1.7% average relative degradation

in F-measure. Though speaker tracking actually

takes advantage from an offline acoustic

segmentation of the audio stream, depending on the

scenario and the required latency, offline audio

AN ONLINE SPEAKER TRACKING SYSTEM FOR AMBIENT INTELLIGENCE ENVIRONMENTS

347

segmentation would not be feasible. In such a

situation, the proposed approach provides real-time

low-latency online speaker tracking at the cost of

little performance degradation.

5 CONCLUSIONS AND FUTURE

WORK

In this paper, an online speaker tracking system,

designed for an Ambient Intelligence scenario, is

presented an evaluated. The system processes

continuous audio streams and outputs a speaker

identification decision for fixed-length (one second)

segments. Speaker detection is done by means of a

MAP-UBM speaker verification backend. A

calibration stage is applied which linearly maps

detection scores to likelihood ratios. Calibration

parameters are estimated beforehand based on

development data, yielding significant performance

improvements without increasing the computational

cost, which is crucial for a real-time low-latency

system. An alternative speaker tracking system,

based on an offline segmentation of the audio stream

has been developed and evaluated for reference.

Experiments have been carried out on a subset of

the AMI Corpus of meeting conversations. Results

demonstrate that better results can be attained when

the UBM is estimated from data matching test

conditions (same room, same speakers), instead of

using general but unrelated data. The calibration

stage provides performance improvements in all

cases. Finally, offline segmentation of audio streams

actually improves speaker tracking performance

with regard to using fixed-length segments.

However, depending on the scenario and the

required latency, offline audio segmentation would

not be feasible. The proposed system provides real-

time low-latency online speaker tracking with little

performance degradation.

Current work involves increasing the robustness

of detection scores (and decisions) by using

information from past segments. Future work

includes using detection scores in a speaker

verification framework (thus allowing the detection

of multiple speakers), and making a smart use of all

the available data through new UBM estimation

strategies.

ACKNOWLEDGEMENTS

This work has been partially funded by the

Government of the Basque Country, under program

SAIOTEK, project S-PE07IK03; and the Spanish

MICINN, under Plan Nacional de I+D+i, project

TIN2009-07446.

REFERENCES

Abowd, G.D., Mynatt, E.D., "Designing for the Human

Experience in Smart Environments" in D.J. Cook and

S.K. Das, Editors, Smart Environments: Technology,

Protocols, and Applications, Wiley, 153-174, 2005.

Bonastre, J.F., Delacourt, P., Fredouille, C., Merlin, T. and

Wellekens, C., "A Speaker Tracking System based on

Speaker Turn Detection for NIST Evaluation", in Pro-

ceeding of the IEEE International Conference on

Acoustics, Speech and Signal Processing, Istanbul,

Turkey, 2000.

Brummer, N. and Preez, J., "Application Independent

Evaluation of Speaker Detection", Computer Speech

and Language, 20:230-275, 2006.

Carletta, J., "Unleashing the killer corpus: experiences in

creating the multi-everything AMI Meeting Corpus".

Language Resources and Evaluation Journal , 41(2):

181-190, 2007.

Chen, S.C. and Gopalakrishnan, P.S., "Speaker, Environ-

ment and Channel Change Detection and Clustering

via the Bayesian Information Criterion", Proceedings

of DARPA Broadcast News Transcription and Under-

standing Workshop, 1998.

Cook, D.J., Augusto, J.C., Jakkula, V.R., "Ambient Intelli-

gence: Technologies, Applications, and Opportuni-

ties", Pervasive and Mobile Computing, 5(4): 277-298,

2009.

ISTAG, "Scenarios for Ambient Intelligence in 2010".

European Commission Report, 2001.

Istrate, D., Scheffer, N., Fredouille, C. and Bonastre, J.F.,

"Broadcast News Speaker Tracking for ESTER 2005

Campaign", in Proceedings of the International Con-

ference on Speech and Language Processing, Lisboa,

2005.

Liu, D., Kiecza, D., Srivastava, A. and Kubala, F., "Online

Speaker Adaptation and Tracking for Real-time

Speech Recognition", in Proceedings of the Interna-

tional Conference on Speech and Language

Processing, Lisboa, 2005.

Lu, L. and Zhang H.J., “Unsupervised Speaker Segmenta-

tion and Tracking in Real-time Audio Content Analy-

sis”, Multimedia Systems,10:332-343, 2005.

Martin, A., Doddington, G., Kamm, T., Ordowski, M., and

Przybocki, M., "The DET curve in assessment of de-

tection task performance", in Proceedings of the 5th

European Conference on Speech Communication and

Technology (Eurospeech), Vol. 4, pp. 1895-1898,

1997.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

348

Martin, A.F. and Przybocki, M.A., "Speaker Recognition

in a Multi-Speaker Environment", in Proceedings of

the 7th European Conference on Speech Communica-

tion and Technology (Eurospeech), Denmark, 2001.

Meignier, S., Moraru, D., Fredouille, C., Bonastre, J.F. and

Besacier, L., "Step-by-step and Integrated Approaches

in Broadcast News Speaker Diarization", Computer

Speech and Language, 20:303-330, 2006.

Moraru, D., Ben, M., Gravier, G., "Experiments on Speak-

er Tracking and Segmentation in Radio Broadcast

News", in Proceedings of the International Conference

on Speech and Language Processing, Lisboa, 2005.

Reynolds, D.A., Quatieri, T.F. and Dunn, R.B., "Speaker

Verification Using Adapted Gaussian Mixture Mod-

els". Digital Signal Processing, 10:19-41, 2000.

Rodríguez, L.J., Peñagarikano, M. and Bordel, G., "A

Simple But Effective Approach to Speaker Tracking in

Broadcast News", Pattern Recognition and Image

Analysis, LNCS 4478: 48-55, Springer-Verlag, 2007.

Tranter, S.E. and Reynolds, D.A., "An Overview of Auto-

matic Speaker Diarization Systems", IEEE Transac-

tions on Audio, Speech and Language Processing,

14(5): 1557-1565, 2006.

Weiser, M., "The Computer for the Twenty-First Century",

Scientific American, 94-104, 1991.

Wu, T.Y., Lu, L., Chen, K. and Zhang, H.J., "UBM-based

Real-time Speaker Segmentation for Broadcasting

News", in Proceedings of the IEEE International Con-

ference on Acoustics, Speech and Signal Processing,

China, 2003.

AN ONLINE SPEAKER TRACKING SYSTEM FOR AMBIENT INTELLIGENCE ENVIRONMENTS

349
