INTERPRETING STRUCTURES IN MAN-MADE SCENES

Combining Low-Level and High-Level Structure Sources

Kasim Terzi

c, Lothar Hotz

HITeC e.V., Department of Computer Science, University of Hamburg, Hamburg, Germany

Jan

Sochman

Center for Machine Perception, Department of Cybernetics Faculty of Elec. Eng.

Czech Technical University in Prague, Czech Republic

Keywords:

Computer vision, Scene interpretation, Image processing, High-level vision.

Abstract:

Recognizing structure is an important aspect of interpreting many computer vision domains. Structure can

manifest itself both visually, in terms of repeated low-level phenomena, and conceptually, in terms of a high-

level compositional hierarchy. In this paper, we demonstrate an approach for combining a low-level repetitive

structure detector with a logical high-level interpretation system. We evaluate the performance on a set of

images from the building fac¸ade domain.

1 INTRODUCTION

The scene interpretation can be improved by exploit-

ing the structural information present in many do-

mains. In this paper we illustrate the use of high-level

structural models for combining structured low-level

evidence into a complete, coherent interpretation of

an image. The paper addresses the task of window

detection in complex fac¸ade scenes. Windows in a

fac¸ade are often organised into regular structures but

the structure is often complex and there is a lot of

variation. There are two sources of structure avail-

able: (i) visual structure, manifested in repeated vi-

sual phenomena in the image, and (ii) compositional

structure, expressed as part-of relations in the compo-

sitional hierarchy of scene objects.

We exploit the visual structure by using a struc-

tural component detection algorithm for window de-

tection. It detects structural components in the image

consisting of horizontally and vertically aligned de-

tections based on automatically detected seeds. The

problem with this approach is that it leads to a number

of conﬂicting and overlapping structural components,

and many false positives. Each of the the detected

structural components explains some of the windows,

but usually none of them explains all the windows.

The compositional structure is modelled in a

knowledge base describing the domain of fac¸ade

scenes. Objects can be parts of aggregates and their

arrangement within the aggregates can be modelled

manually or learnt allowing more complex relations

than simple alignment. However, logical interpreta-

tion based on object-level depends on correct detec-

tions. Our approach combines the two sources of

structure by using a middle-layer component to form

a complete interpretation of the fac¸ade.

There is a lot of recent interest in the ﬁeld of com-

puter vision for using high-level context for interpret-

ing scenes from a wide range of domains such as air-

port activity recognition (Fusier et al., 2007), inter-

preting building fac¸ades (Hotz et al., 2008;

Cech and

ara, 2007) or analysing trafﬁc situations (Mohnhaupt

and Neumann, 1993; Hummel et al., 2008). However,

we are not aware of other current work combining dif-

ferent high-level and low-level sources of structure for

interpreting highly structured domains.

Several other recent approaches deal with the inte-

gration of low-level image processing and high-level

reasoning like e.g. (Zhu and Mumford, 2006) which

uses grammar-based models for detecting structure at

multiple levels of abstraction including the low level.

Structured scenes are also examined in (Seo et al.,

2009), where images of parking blocks consisting of

parking spots are interpreted. They demonstrate an

approach for ﬁlling gaps in structures by using inter-

polation and extrapolation. In contrast to the more

domain-speciﬁc approach used in that work our ap-

proach is based on a declarative representation of the

357

Terzi

c K., Hotz L. and Šochman J. (2010).

INTERPRETING STRUCTURES IN MAN-MADE SCENES - Combining Low-Level and High-Level Structure Sources.

In Proceedings of the 2nd International Conference on Agents and Artiﬁcial Intelligence - Artiﬁcial Intelligence, pages 357-364

DOI: 10.5220/0002735303570364

 SciTePress

constraints and object classes, which facilitates the

application of the techniques to different domains (see

(Hotz and Neumann, 2005) for an example). We show

that the combination of high-level and low-level struc-

tural models improves the detection of windows in the

fac¸ade domain.

The paper is structured as follows. First, the vi-

sual and conceptual structure models are described in

Section 2. The interpretation process used in our ex-

periments is described in Section 3. The results of an

evaluation on a set of annotated images are presented

in Section 4 and the paper is concluded in Section 5.

2 INTEGRATING DIFFERENT

STRUCTURE MODELS

Two sources of structure are used in this paper. The

visual structure is exploited by a low-level process to

detect repetitive structures in the image. The results

of this procedure are referred to as evidence. The

evidence is mapped into a high-level reasoning sys-

tem which interprets the scene based on a concep-

tual model. The instances of high-level models are

referred to as views. The matching of low-level evi-

dence to high-level views is done by the middle-layer

component Matchbox. This section describes the two

structure models and outlines our integration strategy.

2.1 Visual Structure Model

The structure component detection algorithm is a

greedy procedure for ﬁnding sets of self-similar hor-

izontally and vertically aligned windows in a fac¸ade

image.

The detection process starts by running a sliding

window detector over the image. It produces a set

of initial window hypotheses – component seeds –

(α, β, s), i = 1, . . . , N, parametrised by their position

(α, β) in the image and their scale s. We trained an

AdaBoost classiﬁer as the seed detector (Freund and

Schapire, 1997). It is intentionally built to be weak

(trained on about 100 window images only) to demon-

strate the advantage of structural priors for window

detection. Consequently, the seed set contains many

false positives and usually several windows on the

fac¸ade are missed.

The structural component growing starts by ini-

tialising each component by one seed x

. When ex-

tending a component by a new window, two factors

are considered besides the alignment with already in-

cluded windows: (i) a window model similarity F

and (ii) a component elements appearance similarity

seed (0) and 1st detection (1) L(β) after seed learning

100 200 300 400 500

0.5

1.5

second detection L(β) after 2-sample learning

01 2

100 200 300 400 500

0.5

1.5

third detection L(β) after 3-sample learning

01 2 3

100 200 300 400 500

0.5

1.5

ﬁnal component L(β) after 4-sample learning

01 2 3

100 200 300 400 500

0.5

1.5

Figure 1: A row component growing process. Right column

shows the incrementally updated component conﬁdence L

over the row positions β (blue). Already accepted window

positions are marked by a small circle in the conﬁdence plot

and by a solid-line rectangle in the image (left column).

Their neighbourhood which is suppressed for further search

is shown as red parts in the conﬁdence plot. A new candi-

date for the compoment expansion is marked by a big circle

in the conﬁdence plot and by a dashed rectangle in the im-

age. The acceptance threshold is plotted in green.

The window model similarity F

is used to pre-

vent the search to drift away from the window class

appearance. In our case, the window class is de-

ﬁned by the AdaBoost classiﬁer. Its real-valued out-

put f

(x) =

∑

(x) is used to compute an a poste-

riori probability estimate of an image x being a win-

dow (Friedman et al., 1998)

(x) =

exp( f

(x))

exp(− f

(x)) + exp( f

(x))

. (1)

The component appearance similarity F

assures

only the windows of the same type are included into

a component. It is computed as in equation (1) but

with the use of an on-line adapted AdaBoost classiﬁer

(Grabner et al., 2006) trained on the compoment

windows only. Each time a new window is added

to the compoment, the appearance consistency clas-

siﬁer f

is updated. The negative examples for the

update are collected from the window neighbourhood

as in (Grabner et al., 2006).

The complete component growing procedure is

demonstrated in Figure 1 on a single row of win-

dows. Each component is extended independently in

a greedy way maximising a criterion function

L(α, β, s) = F

(x(α, β, s)) + F

(x(α, β, s)) . (2)

Since the windows in the component are assumed to

be aligned and of the same size, only a 1D search

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

358

start 3rd step conﬂict

Figure 2: Full 2D growing process with alignment conﬂict

illustration.

Figure 3: Examples of components detected using sctruc-

ture component detection algorithm.

in vertical (α parameter, not used in this example) or

horizontal (β parameter) direction is needed. Due to

the non-overlapping assumption, the surrounding of

already visited positions deﬁned by the window size

is masked-out for the search.

To compute the conﬁdence L, the appearance clas-

siﬁer F

is ﬁrst initialised by the seed x

(α, β, s). As

new windows are added to the component, the classi-

ﬁer is updated incrementally. The search is terminated

when max(L) falls below a threshold θ = 1.

Figure 2 shows an example of the component ex-

pansion in both vertical and horizontal direction at the

same time. For each expansion step a maximum of L

is searched along possible horizontal and vertical ex-

pansion of all component elements. To preserve the

alignment of all component elements, the search is

further restricted to positions which are not in conﬂict

with other component windows (Figure 2, right). Sev-

eral detected components grown from different seeds

are shown in Figure 3. The expansion directions used

here are particularly suited for fac¸ade images, but they

can be expressed more generally as a grammar, allow-

ing different types of alignment.

2.2 Compositional Structure Model

As shown in (Hotz and Neumann, 2005), scene inter-

pretation can be formally modelled as a knowledge-

based process. Our conceptual model uses a

knowledge-based representation of all scene objects

that can occur in a fac¸ade scene, i.e. primitive ob-

jects like window or door, aggregates like balcony

or entrance, and alignments. Alignments are used

to represent vertical and horizontal structures like a

eThing

View

View-Primitive

Window-View

Scene-Object

Scene-Primitive

Scene-Aggregate

Window

has-part has-specialisation has-view for each concept

View-Aggregate

Horizontal-Alignment-View

Horizontal-Alignment

Facade

Building

Facade-Scene

Window-Array

Concept

Horizontal-Alignment-View-1

Window-View-1

Window-View-2

Window-View-3

Window-View-4

Window-View-5

Horizontal-Alignment-View-2

has-instance

Instance

Figure 4: Part of the ontology including instances for an

image.

collection of aligned rectangles as they are given by

low-level structure detector (see Section 2.1). Such

structures can be specialised into alignments like

window-array or stack-of-storages. The ap-

proach is general enough to be used on a wide range

of domains, and it is applied to windows and window

arrays in this case.

Besides the part deﬁnitions, the spatial relations

(constraints) are given for aggregates and alignments

that have to be fulﬁlled for scene objects of a partic-

ular object class. Those constraints are learnt in this

case (Hartz et al., 2009) , but they can also be man-

ually constructed. In the case of a window array, the

main constraints on the parts are: (i) same size, (ii)

same distance, and (iii) vertical alignment, all within

a certain tolerance.

The conceptual model represents all known prim-

itive objects, aggregates and alignments, in a declar-

ative way. The interpretation process uses this model

for performing interpretation steps that subsequently

construct an interpretation of a given scene. The ﬁnal

interpretation of the scene includes the detections pro-

vided by the structure as well as hypotheses which are

made according to the conceptual model (see Section

3.2).

2.3 The SCENIC System

A realization of a knowledge-based interpretation sys-

tem capable of interpreting scenes based on models

described in the previous section exists in SCENIC

(Terzic et al., 2007). SCENIC includes a high-level

reasoning layer, a set of low-level image process-

ing modules (IPMs), and a middle-layer component

called Matchbox which matches high-level concepts

to the detections provided by the IPMs.

The reasoning layer of SCENIC is based on the

conﬁguration methodology (Soininen et al., 1998),

which provides commonly known domain indepen-

dent reasoning techniques like constraint propagation

INTERPRETING STRUCTURES IN MAN-MADE SCENES - Combining Low-Level and High-Level Structure Sources

359

(Yang and Yang, 1997) or rule-based reasoning (Rus-

sel and Norvig, 2003) in combination with a declara-

tive domain-speciﬁc knowledge base of concepts and

constraints. Furthermore, the high-level layer consists

of a declarative interpretation process, which struc-

tures the reasoning tasks of propagating constraints,

instantiating concepts to instances, determining rela-

tions between instances, etc. Concepts are mainly

aggregate models, their instances represent aggregate

instantiations (or simply: “aggregates”), i.e. conﬁgu-

rations of concrete objects in scenes. The interpreta-

tion process attempts to recognise aggregates, which

describe the observed evidence. Figure 4 shows a part

of the conceptual model.

Within SCENIC , a strict separation of observed

views (2D projections within an image) and 3d-

objects is given. Views represent typical appearances

of scene objects and 3d-objects collect all kinds of

information known or inferred for scene objects, e.g.

compositional and spatial relations. This allows for

occlusion inferences and 3D reasoning, but since this

paper focusses on interpreting rectiﬁed fac¸ade images

(fac¸ade edges are parallel to image edges), this feature

is not exploited in this paper.

The main task of the Matchbox is the grounding

of high-level concepts by matching evidence to high-

level views. This occurs either in a bottom-up direc-

tion, where new views are created from available evi-

dence, or a top-down direction, where view hypothe-

ses are matched to available evidence. In the context

of this paper, the bottom-up step is the selection of the

best low-level structures and passing them to the high-

level. The top-down step is looking for the low-level

window detections which ﬁt the hypotheses created

by the high-level.

2.4 Integration Approach

The structure component detection algorithm outputs

a set of structural components, one for each seed

(components containing only a single window are re-

moved). They are overlapping as they represent dif-

ferent parts of the same fac¸ade structure grown from

different seeds. Since logic-based interpretation sys-

tems (in our case SCENIC ) expect consistent input,

these structures can not all be passed to the high-level

at the same time, as they would lead to logical con-

ﬂicts. Our approach is to integrate the structured evi-

dence by starting with strong evidence and relying on

top-down inference to ﬁll in the missing objects. The

algorithm is sketched below:

1. select the strongest evidence from the structured

bag of evidence by the Matchbox (Section 3.1),

2. interpret the image based on the available evi-

dence (Section 3.2),

3. suggest hypotheses of missing objects (Section

3.2),

4. match the hypotheses to existing unused evidence

(Section 3.3).

Steps 3-4 are repeated until all hypotheses are

checked and no more hypotheses can be made. The

structural information from the low-level. which ar-

ranges objects into structures, helps the high-level to

instantiate the correct aggregates and thus propagate

the necessary constraints. The use of high-level hy-

potheses means that high-level context is used to pick

out the correct evidence from a set of conﬂicting and

spurious detections. This way, both sources of context

are combined to create a single interpretation

3 INTERPRETATION PROCESS

3.1 Initialising the High-Level

The low-level evidence consists of many structural

components, which in turn consist of many individ-

ual window detections. The window detections often

overlap with detections from other structural compo-

nents. We deﬁne the conﬁdence C

of a window de-

tection W

) =

∑

n6=m

Area(W

∩W

)

max(Area(W

), Area(W

))

Based on the conﬁdences of individual window de-

tections W , the conﬁdence C

is calculated for each

window row R as:

(R) =

∑

∈R

)

The rows are then sorted according to their conﬁ-

dence, and a best set of non-overlapping rows is se-

lected as initial evidence for interpretation by using

a greedy algorithm. The row with the highest con-

ﬁdence C

is selected as the best row and all rows

overlapping with that row in the vertical dimension

are removed. Then the row with the second highest

conﬁdence is selected, and the process continues un-

til there are no rows left. Figure 6 shows the result of

this algorithm on one example image.

The selected rows and the corresponding window

detections are passed to the high level. It is impor-

tant to note that the partonomical relations are also

passed as evidence along with the instantiated views,

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

360

Figure 5: All the evidence from the low level.

Figure 6: Automatically selected initial evidence. All hor-

izontally aligned windows belong to the same rows (not

shown here).

i.e. each window belongs to a row formation along

with other windows. This means that the high-level

doesn’t have to examine all possible combinations of

low-level detections in order to ﬁnd a structure. Af-

ter the initialization, the high-level interpretation is

started.

3.2 High-Level Interpretation Process

The task of the high-level reasoning is to ﬁnd a logi-

cal model for the set of observed scene objects passed

as evidence by a lower-level process, i.e. to integrate

all scene objects into aggregates corresponding to a

conceptual model described in Section 2.2. The in-

terpretation process can hypothesise scene objects if

their existence is likely, considering the current inter-

pretation context. All hypotheses made by the inter-

pretation process should be conﬁrmed by the evidence

in the scene. For conﬁrmation, a request is sent to the

Matchbox, which controls the image processing mod-

ules (see Section 3.3 and (Hotz et al., 2008)).

Instance

has-part

Facade-1

Building-1

1. Decomposition

Hypothesis

hypothesized has-part

Facade-Scene-1

Interpretation goal

Window-2

Horizontal-Alignment-1

Horizontal-Alignment-2

Window-1

Window-3

Window-5

Window-4

has-view for each instance

Horizontal-Alignment

Window-Array

has-instance

has-specialisation

Horizontal-Alignment-View-1

Window-View-1

Window-View-2

Window-View-3

Window-View-4

Window-View-5

Horizontal-Alignment-View-2

3. Specialization

Window-102

Window-103

5. Extrapolation with

position, distance, size

4. Interpolation with

position, distance, size

Window-101

6. Integration

2. Instantiating view and 3d instances.

Figure 7: An interpretation process realisation example.

The high-level reasoning used in this paper is re-

alised through a combination of constraint process-

ing, description-logic like inferences, and conﬁgura-

tion inferences. See (Hotz and Neumann, 2005) for

more details.

The interpretation process starts by creating

mandatory parts that directly follow from a given in-

terpretation goal (see Figure 7). In the case of the

fac¸ade domain, this step is caused by the fact that

each fac¸ade scene (the goal) has a building which has

a fac¸ade as a part. These steps are called decomposi-

tion steps.

As described in the previous section, the next step

is to represent structured and primitive views from

the Matchbox as instances of view concepts (e.g.

horizontal-alignment-view-1) and 3d-concepts

(e.g. horizontal-alignment-1). If the parts of a

horizontal alignment are determined by the Matchbox

to be of object class window, the horizontal alignment

can be specialised to a window-array (see Step 3).

Such window arrays are extended with further win-

dow hypotheses based on the the position, size, and

distance constraints between the windows of an array.

For this step of identifying window hypotheses, three

heuristics are applied.

The ﬁrst one tries to adopt the structure of the

nearby window array with the strongest conﬁdence.

This structure is considered to be context which might

inﬂuence positions, distances, and sizes of hypothe-

sised windows. If no context is present, the second

heuristic, interpolation, ﬁlls gaps in a window array

by trying to ﬁt window hypotheses between exist-

ing windows while observing the window array con-

straints. The third one, extrapolation, hypothesises

windows on the left and right side of a window array

(see (Seo et al., 2009) for similar steps). As a last

step, the observed structure instances are integrated

into the fac¸ade instance.

The interpretation process creates hypotheses of

missing parts based on the conceptual models and the

INTERPRETING STRUCTURES IN MAN-MADE SCENES - Combining Low-Level and High-Level Structure Sources

361

current scene context. The hypotheses describe the

expected objects with their size, position, and object

class (in this case, a window). They are matched to

available evidence as described in the next section.

The hypotheses are updated to reﬂect the observed ev-

idence position and size ranges and the interpretation

process proceeds with those conﬁrmed hypotheses. A

result is shown in Figure 8 (c). The white rectangles

show the low-level detections selected as initial ev-

idence, and the red rectangles show the hypotheses

created by the interpretation process.

3.3 Matching Hypotheses to Evidence

The hypotheses created as a part of the interpretation

process need to be conﬁrmed by evidence from the

low level. The task of the Matchbox is to look for

the unused evidence which can conﬁrm the generated

hypotheses.

The hypotheses are described in terms of allowed

ranges for the position and size. The position and

the size ranges are computed at the high-level such

that the created hypotheses satisfy all the constraints

imposed by the high-level window-array model (e.g.

vertically aligned windows of similar size, which do

non intersect). The hypothesis is conﬁrmed if there is

evidence detected in the provided area which has not

been passed to the high level during the initial step

and which has a size allowed by the size ranges de-

scribing the hypothesis. If there are several possible

matches, the match with the highest conﬁdence C

selected.

Due to the imperfection of low-level detectors,

the exact position and size of the detections is ex-

tended to ranges of allowed values. These uncertainty

ranges cover the observed inaccuracy of the detector

and were determined experimentally on a set of an-

notated images. The matching process then looks at

the intersection of the position and size ranges of the

hypothesis and the available evidence and conﬁrms

the hypothesis if the intersection of all ranges is not

empty.

At the end of the interpretation, the unconﬁrmed

hypotheses are discarded as hallucinations, and the

combination of the evidence selected in the initial step

and the conﬁrmed high-level instances forms the ﬁnal

interpretation of the image.

4 EVALUATION AND

DISCUSSION

We have tested the combined system on 7 hand-

annotated images from the fac¸ade domain, consisting

of 261 windows.

Table 1 shows the effect of the combined struc-

ture models on the detection rate. The selected low-

level detections used for initialisation (third column)

are tested against the annotation. The detection rate of

this bottom-up approach is shown in the sixth column

as a baseline for comparison. If the conﬁrmed high-

level hypotheses (ﬁfth column) are added, the detec-

tion rate generally improves (seventh column).

The different steps of the process can be seen in

Figure 8. An interesting observation is that a num-

ber of hypotheses which correspond to windows in

the image, shown in (d) are not among the hypothe-

ses which were conﬁrmed by the low-level (e). The

main cause for this was poor contrast and occlusions

which prevented some of the windows from being de-

tected by the low-level stage. In other words, there

were no window detections in any of the structural

components which corresponded to these windows.

Figure 9 shows the results on the remaining im-

ages. In three cases, there was no improvement, since

the initially selected evidence has already detected all

the windows. The created hypotheses were not con-

ﬁrmed. Image 5 (shown at the bottom) was particu-

larly challenging due to the rich and irregular struc-

ture. The conﬁrmed high-level hypotheses detected

15 further windows compared to the bottom-up ap-

proach, but also found 3 false positives. The evalua-

tion data show that the combined approach improved

the detection considerably on some images (espe-

cially images 2, 3 and 5). At the same time, it didn’t

hurt the cases where the low-level approach was al-

ready successful (images 4, 6 and 7). Our combined

approach has only resulted in false positive detections

in one case (image 5).

False positives can only occur if both structure

models expect an object at a wrong location. Since

both structure models rely on regularity assumptions,

this sometimes occurs on images with an irregular

structure. However, as can be seen in Figure 8 (c), the

combination of the two structure sources makes good

hypotheses that are conﬁrmable by a human. There-

fore, we see a potential for further improvement of

the detection rate if additional low-level detectors are

integrated into the system and used for conﬁrming hy-

potheses.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

362

(a) (b) (c) (d) (e)

Figure 8: The interpretation process shown on image 3. From left to right: (a) all evidence provided by the structure detector,

(b) the evidence used to initialise the high level, (c) all hypotheses (shown in red), (d) the hypotheses which correspond to real

objects and (e) the hypotheses which were automatically conﬁrmed by low-level evidence. The windows partially occluded

by balconies were hypothesised correctly, but there were no low-level detections to conﬁrm them.

Img1 hypotheses Img2 hypotheses Img4 hypotheses Img6 hypotheses Img7 hypotheses

Img1 conﬁrmed Img2 conﬁrmed Img4 conﬁrmed Img6 conﬁrmed Img7 conﬁrmed

Img5 hypotheses Img5 conﬁrmed

Figure 9: The result of the combined structured models on the testing images.

Table 1: Improvement of the window detection rate after combining two structure sources. In images 4, 6 and 7, the low-level

structure detector detected everything except partial windows at the edge of the image, so there was no improvement.

Img annotated correct correct conﬁrmed low-level combined improvement combined

low-level high-level correct detection detection over pure false

windows windows hypotheses hypotheses rate rate bottom-up positives

1 44 27 13 5 61.4% 72.7% 11.3% 0

2 37 23 7 3 62.2% 70.3% 8.1% 0

3 40 33 9 3 82.5% 90% 7.5% 0

4 35 33 4 0 94.3% 94.3% 0% 0

5 60 22 15 15 36.7% 61.7% 25% 3

6 25 24 4 0 96% 96% 0% 0

7 20 19 0 0 95% 95% 0% 0

INTERPRETING STRUCTURES IN MAN-MADE SCENES - Combining Low-Level and High-Level Structure Sources

363

5 CONCLUSIONS

One of the challenges of scene interpretation is the

use of structural information for improving the inter-

pretation of a scene. This paper describes an approach

for integrating two separate sources of structure and

shows that this combination improves the detection

of windows in the fac¸ade domain. The low-level

structure detector typically computes a large number

of potential primitive and structured evidences. A

middle-layer component called “Matchbox” reduces

this number by selecting the best primitives and struc-

tures. High-level reasoning creates hypotheses of

missing objects that are caused by the context of the

surrounding scene objects. These hypotheses are con-

ﬁrmed or refuted by comparing them to the low-level

results. Thus, the Matchbox mediates between both

sources of structures, and relates high-level concepts

to low-level detections.

The approach was tested on a set of fac¸ade im-

ages, which are rich in structure. The results show

that combining visual and compositional structure can

considerably improve the detection of windows in

this domain compared to pure bottom-up approach

based on visual structure alone. Not all the correct

high-level hypotheses were conﬁrmed by low-level

evidence, mostly due to poor contrast and partially

occluded windows. Further improvements might be

possible by using additional low-level detectors for

conﬁrming or refuting high-level hypotheses.

ACKNOWLEDGEMENTS

This research has been supported by the European

Community under the grant IST 027113, eTRIMS

- eTraining for Interpreting Images of Man-Made

Scenes.

REFERENCES

Freund, Y. and Schapire, R. (1997). A decision-theoretic

generalization of on-line learning and an application

to boosting. Journal of Computer and System Sci-

ences, 55(1):119–139.

Friedman, J., Hastie, T., and Tibshirani, R. (1998). Ad-

ditive logistic regression: a statistical view of boost-

ing. Technical report, Department of Statistics, Se-

quoia Hall, Stanford Univerity.

Fusier, F., Valentin, V., Bremond, F., Thonnat, M., Borg,

M., Thirde, D., and Ferryman, J. (2007). Video under-

standing for complex activity recognition. Machine

Vision and Applications (MVA), 18:167–188.

Grabner, H., Grabner, M., and Bischof, H. (2006). Real-

time tracking via on-line boosting. In British Machine

Vision Conference, volume 1, pages 47–56.

Hartz, J., Hotz, L., Neumann, B., and Terzic, K. (2009).

Automatic incremental model learning for scene inter-

pretation. In Proc. of the Fourth IASTED International

Conference on Computational Intelligence, Honolulu,

Hawaii.

Hotz, L. and Neumann, B. (2005). Scene Interpretation as a

Conﬁguration Task. K

unstliche Intelligenz, 3:59–65.

Hotz, L., Neumann, B., and Terzic, K. (2008). High-

level expectations for low-level image processing. In

KI 2008: Advances in Artiﬁcial Intelligence, volume

5243 of Springer Lecture Notes in Computer Science,

pages 87–94.

Hummel, B., Thiemann, W., and Lulcheva, I. (2008). Scene

understanding of urban road intersections with de-

scription logic. In Cohn, A. G., Hogg, D. C., M

oller,

R., and Neumann, B., editors, Logic and Probability

for Scene Interpretation, number 08091 in Dagstuhl

Seminar Proceedings, Dagstuhl, Germany. Schloss

Dagstuhl - Leibniz-Zentrum fuer Informatik, Ger-

many.

Mohnhaupt, M. and Neumann, B. (1993). Understanding

object motion: recognition, learning and spatiotem-

poral reasoning. Robotics and Autonomous Systems,

pages 65–91.

Russel, S. and Norvig, P. (2003). Artiﬁcial Intelligence - A

Modern Approach. Prentice-Hall.

Seo, Y.-W., Ratliff, N., and Urmson, C. (2009). Self-

supervised aerial image analysis for extracting park-

ing lot structure. In Proc. of Twenty-First Int. Joint

Conf. on AI IJCAI-09, pages 1837–1842, Pasadena.

Soininen, T., Tiihonen, J., M

annist

o, T., and Sulonen, R.

(1998). Towards a General Ontology of Conﬁgura-

tion. Artiﬁcial Intelligence for Engineering Design,

Analysis and Manufacturing (1998), 12, pages 357–

372.

Terzic, K., Hotz, L., and Neumann, B. (2007). Division of

Work During Behaviour Recognition - The SCENIC

Approach. In Schuldt, A., editor, Behaviour Moni-

toring and Interpretation, Workshop Proceedings KI,

Universit

at Bremen.

Cech, J. and

ara, R. (2007). Language of the structural

models for constrained image segmentation. Tech-

nical Report Technical Report TN-eTRIMS-CMP-03-

2007, Czech Technical University, Prague.

Yang, C. and Yang, M.-H. (1997). Constraint Networks: A

Survey. In Proc. of the IEEE International Conference

on Systems, Man and Cybernetics, volume 2, Orlando,

Florida, USA. Institute of Electrical and Electronics

Engineers (IEEE).

Zhu, S. and Mumford, D. (2006). A Stochastic Grammar of

Images. Foundations and Trends in Computer Graph-

ics and Vision. Prentice-Hall.

ICAART 2010 - 2nd International Conference on Agents and Artificial Intelligence

364
