WATA

A System for Written Authenticated though Anonymous Exams

Giampaolo Bella, Gianpiero Costantino and Salvatore Riccobene

Dipartimento di Matematica e Informatica, Universit

a di Catania, Catania, Italy

Keywords:

Exam, Open Competition, Authentication, Anonymity, Platform independence.

Abstract:

University exams or open competitions raise signiﬁcant security concerns because they are typically driven by

strong interests. The candidate and the examiner may want to cheat on each other, or even coerce each other.

While candidate authentication would address certain threats, his anonymity would address some other threats,

but their conjugation appears to be contradictory. The classical approach to facing this security problem is

weak as it poses signiﬁcant trust upon the examiner. It is the double envelope, with a big envelope containing

an anonymous exam sheet and a smaller envelope in turn sealing the candidate’s identity. Surprisingly, there

appears to be almost no computer-assisted solutions available.

WATA is a system, implemented in a portable software, for Written Authenticated though Anonymous exams.

It protects the candidate and the examiner from each other by ensuring that the examiner corrects an authenti-

cated though anonymous exam sheet. The candidate is the sole entity who can establish the link between his

identity and his exam sheet, and normally has interest in safeguarding such a link. With various additional

functionalities, WATA can be freely downloaded from the Internet for academics to try (Gianpiero, 2009).

1 INTRODUCTION

Taking an exam typically is a sensitive step for a can-

didate. Success may signify advancing towards a uni-

versity degree or getting an important job. It is there-

fore an obvious requirement that both the candidate

and the examiner behave honestly in their respective

roles.

Nevertheless, various forms of cheating may oc-

cur. For example, the candidate may try to send some-

one else, who is particularly skilled and thus certain to

pass, to sit for the exam on his behalf. In practice, the

accomplice might be a friend or even an expert who

is paid for his illegitimate task. Authentication can ef-

fectively withstand these threats, and in this context

can be read as: the candidate really has the identity he

claims on his exam sheet. The obvious enforcement

of authentication during an exam is to have the exam-

iner check that the candidate’s ID matches what the

candidate writes down on his exam sheet.

However, other forms of cheating are possible dur-

ing an exam. The candidate might explicitly or im-

plicitly inﬂuence an examiner who wants to mark the

exam sheets fairly but happens to be a friend or rel-

ative of the candidate’s. The candidate might even

coerce the examiner. Also the examiner may want to

act dishonestly by favouring or disfavouring an exam

sheet for whatever reason, for example because he

likes or dislikes the corresponding candidate. Re-

markably, these forms of cheating are exacerbated by

authentication, because the examiner is entitled to as-

sociate each exam sheet to a candidate. Anonymity

can effectively withstand these threats, and in this

context can be read as: the candidate can effectively

conceal his identity on the exam sheet. It is clear that

authentication and anonymity are, at least at the ab-

stract level, the opposite of one another. Therefore, a

security system to thwart cheating during an exam is

not trivial to design because it cannot simply enforce

one of the two goals, while enforcing both of them

appears to be conceptually impossible.

The original motivation to tackle this problem

dates back to 2003 for the inception of the Computer

Security course towards the degree in Computer Sci-

ence at our university. Not only was it was felt that a

computer-assisted solution to the problem would pro-

132

Bella G., Costantino G. and Riccobene S. (2010).

WATA - A System for Written Authenticated though Anonymous Exams.

In Proceedings of the 2nd International Conference on Computer Supported Education, pages 132-137

DOI: 10.5220/0002797401320137

 SciTePress

vide fairness to both the examiner and the candidate,

but it was also taken as a stimulating research chal-

lenge. In fact, it was somewhat surprising to ﬁnd out

that no attempts existed at tackling the problem using

computers, as there was no public availability of the

only related publication (Gray, 2003), which was just

about to appear (§2). Our efforts to study the prob-

lem from a security perspective produced the ﬁrst beta

version of WATA, a system for Written Authenticated

Though Anonymous exams, which has recently met a

stable Java implementation, as we shall see below.

The gist of WATA is to mechanise in a software

the classical method of the double envelope, which is

often used during open competitions. As we detailed

below, because this system classically has no com-

puter support, it is easy for a dishonest examiner to

subvert it. The main idea is to authenticate each exam

sheet conventionally, but to keep it anonymous for the

examiner until he terminates his marking. The only

real limitation of WATA is against a scenario where

the candidate and the examiner collude to subvert the

exam. This seems, however, rather extreme, and may

as such require dedicated enforcement.

This manuscript begins with a survey of the re-

lated work (§2). It then describes WATA (§3), illus-

trates its interface (§4) and outlines its implementa-

tion (§5). Finally, it terminates (§6).

2 RELATED WORK

As mentioned above, only two signiﬁcant works are

related to ours at present. One is the double paper

envelope, which is a classical attempt at conjugating

authentication and anonymity without computer sup-

port. Two envelopes are used for each candidate. A

big one, which must be anonymous, will contain his

exam sheet. A small one will contain only the can-

didate personal information. When the candidate ﬁn-

ishes his exercises, the examiner puts the exam sheet

inside the big envelop, whereas his personal informa-

tion gets sealed in the small envelop — sealing-wax

could be used to make the small envelop more tamper-

proof. During the marking phase, the examiner will

open only the big envelop in order to mark an anony-

mous exam sheet. Only afterwards, when the exam-

iner will have marked the exam sheet, he will asso-

ciate the anonymous sheet with the personal informa-

tion of the candidate by opening the small envelop.

This terminates the marking phase, which is authenti-

cated though anonymous only if the examiner is hon-

est.

Clearly, a dishonest examiner could easily violate

the anonymity of the exam sheet. If he is not super-

vised by someone else, or if all members of the exam-

ining committee agree, he/they can decide to open the

small envelope beforehand, and dishonestly advan-

tage or disadvantage some candidate. Various cheat-

ing scenarios could take place, especially if the small

envelop is weakly sealed, because anyone in the ex-

amining committee could open and close it without

any apparent tampering. As mentioned, sealing-wax

would be of some help here.

Another related work is a software to sub-

mit coursework in an electronically from the stu-

dent to the examiner while maintaining the student

anonymous (Gray, 2003). Based on the client-

server paradigm, the system lets the student use a

pseudonym to submit his coursework. This process

is mechanised through a JAVA (Microsystems, 1991)

application, which keeps the identity of the student

from the examiner. The latter is therefore deemed to

mark the coursework fairly. Only when the course

(that is, the actual teaching classes) terminates, will

the examiner associate the pseudonym with the real

identity. The system has weaknesses, as the author

himself says; for example, a student could submit

his coursework with his personal information in or-

der to invalidate the anonymity of his work. This may

happen either deliberately or indeliberately, that is by

mistake. It remains questionable, however, whether

this qualiﬁes as a signiﬁcant weakness in a realistic

threat model where the student has interest in con-

forming to the rules in order to get through the exam.

The goals of this system are rather different from

WATA’s. Rather than assisting with coursework sub-

mission prior to the end of teaching, when anonymity

is relaxed, WATA is targeted at exams whose marks

must be produced in due time, as is the case of open

competitions or ﬁnal exams of university courses, for

example. Another difference is that WATA is a tool

for the examiner and, as such, does not need to be

distributed.

3 OUR SOLUTION: WATA

In this Section, we advance a system called WATA. It

is a system for Written Authenticated Though Anony-

mous exams, which offers an examiner full computer

support to print, mark and notify the marks of exam

sheets that are anonymous though still authenticated.

Anonymity is relaxed only at the ﬁnal phase of mark

notiﬁcation, that is after the actual marking phase.

WATA is an application software that accomplishes its

goals by printing exam sheets with a particular layout.

WATA - A System for Written Authenticated though Anonymous Exams

133

3.1 Authentication

To support authentication, we design what we name

an authentication token (Fig.1), which essentially is a

form for personal information.

Figure 1: Authentication token.

WATA prints this token on the exam sheet. At the

beginning of the exam, the candidate is required to ﬁll

it in with his personal information (name, surname,

student enrollment number), date and signature.

Figure 2: Top of an exam sheet.

The barcode is the most important feature of the

token. Because it is unique, and is duplicated on the

exam sheet, it associates the token to its sheet, as we

shall see below (§3.2).

When the candidate has ﬁlled in the token, the ex-

aminer authenticates him by asking his identity doc-

ument. If the personal information as shown on the

candidate’s ID matches what he has written on the to-

ken, the examiner puts a signature on the token to val-

idate it. By doing so, he certiﬁes the association be-

tween the candidate and his token. In addition, each

token will be reinforced with a stamp of the exam-

iner’s organization in order to make it more tamper-

proof. The examiner’s signature and the organiza-

tion’s stamp are the only non-digital expedients that

WATA adopts.

Finally, the candidate is required to cut out the to-

ken from the exam sheet and to keep it with him in a

safe place. After this, the candidate, who is authenti-

cated, can start answering the questions on an anony-

mous exam sheet.

3.2 The Barcode

The barcode is printed on the sheet in two different

places, one is inside the token and the other one is

on the top-right corner of the sheet. It therefore is the

only connection between an authentication token, that

is, between an identity, and an exam sheet. Of course,

no barcode must be printed on more than one exam

sheet, otherwise it would become impossible to later

associate the candidate to his exam sheet.

WATA supports the reading of a barcode through a

standard barcode scanner, so all operations described

in the following can be signiﬁcantly mechanised and

speeded up. It is understood that this raises some trust

in the examiner, who may in practice, at authentica-

tion time, memorise the barcode number correspond-

ing to the candidate he wants to mark disonestly.

To guarantee uniqueness and unpredictability of

a barcode, we use a random function that is detailed

below (§4.1). During the computation of the number

to represent as a barcode, we apply an extra sanity

check that the last extracted number has not already

been computed. This helps to circumvent any weak-

nesses of the implemented random function. Since

the extracted numbers are stored in a database with

the primary key in the number of the barcode, check-

ing whether a number is present is not heavy.

When the generated barcodes are enough for the

exam sheets, the system is ready to print out the bar-

code using the standard barcode codiﬁcation cod.39.

This codiﬁcation covers uppercase letters, digits and

special characters such as % but, for the sake of sim-

plicity, WATA only encodes numbers as barcodes.

3.3 Anonymity

An exam sheet is anonymous when an examiner can-

not go back during the marking phase to the candidate

who completed that exam sheet. The authentication

token of WATA declares the owner of the sheet, but

without it the sheet remains anonymous. As explained

before, the candidate must remove the token from the

exam sheet after the examiner validates the token, but

prior to submitting the sheet. In our practical use of

WATA, the examiner enforced this by declaring the

policy that failing to detach the authentication token

would automatically invalidate the exam sheet: hardly

anyone walked away without his token.

Fig.3 shows the exam sheet without the token.

This is what the examiner sees while he is marking

the exam sheet. It can be noticed that the sheet is

anonymous.

CSEDU 2010 - 2nd International Conference on Computer Supported Education

134

Figure 3: Exam sheet without Authentication Token.

3.4 The Database

The structure of the database underlying WATA is

simple, as it consists of three tables: the barcode table,

the question table and the mark table. The barcode ta-

ble is very simple as it stores the generated barcodes.

We shall see that it is particularly useful during the

notiﬁcation of marks to the candidates in order to de-

tect fake barcodes the candidate might have built by

himself (§4.3). The second table stores the questions

for the exam sheets (Table 1).

Table 1: A question table.

QID Question

1 How did he/she discover the hot water?

2 How far is the sun?

3 What was the best thing before sliced bread?

4 Can crop circles be square?

Each question is associated to a progressive num-

ber called “QID” (acronym of question identiﬁer),

while the questions belong to the “Question” ﬁeld. In

addition, WATA allows one to manage questions for

different subjects, such as different university courses.

The examiner merely needs to create one such table

for each subject. Creating a table does not require par-

ticular skill; it can be done using the dedicated button

that WATA provides (§4.4).

Table 2: A mark table.

S-Barcode Mark S-ID Date ENRL

5070920 Passed 1 2009/07/09 Empty

6483021 Failed 2 2009/07/09 Empty

1111220 Passed 3 2009/07/09 Empty

3628103 Passed 4 2009/07/09 Empty

The database also contains a mark table (Table

2). The examiner marks an exam sheet that is token-

less. So, he only stores the barcode of the sheet in

“S-Barcode”, the ﬁnal mark (in “Mark”) and the date

of the exam in “Date”. The examiner has no means to

know the enrollment number “ENRL”, which is only

ﬁlled in later, during the notiﬁcation phase (§4.3).

Therefore, the mark table supports full auditing of the

candidate’s attempts at passing an exam by recording

the mark for each date the candidate took an exam.

4 USING WATA

Using WATA is simpliﬁed by a friendly user interface

(Fig.4). The main features can be accessed through

the buttons on the left hand side. The remaining but-

tons interact with the underlying database.

Figure 4: Interface to WATA 2.0.

The “Add Questions” button initiates a straightfor-

ward interaction to expand the database of questions

for an exam. The other buttons are explained in the

sequel of this Section.

4.1 Print Exam Sheets

To prevent collaboration between candidates during

an exam, WATA supports the printing of different

questions for each exam sheet. Prior to printing, the

questions are shufﬂed using a random function, which

is the same as that used for barcode generation (§3.2).

The random function combines the number of sec-

onds elapsed from 1970-01-01 with the output of the

standard random function provided by the program-

ming language. The details can be observed from the

omissis of the source code, which is detailed sepa-

rately (§5.1).

Finally, the shufﬂed questions form a list to print

questions from. The examiner can choose how many

exam sheets and how many questions per exam sheet

to print. In case the number of available questions is

insufﬁcient, WATA shufﬂes the questions again. This

feature was added in order to allow an examining

committee to print the desired number of exam sheets

even if the number of questions available were rather

small. Clearly, this would cause lower entropy.

WATA - A System for Written Authenticated though Anonymous Exams

135

Figure 5: Omissis of extraction of shufﬂed questions from a question table.

4.2 Mark Exam Sheets

When the examiner has ﬁnished to mark all exam

sheets, he is ready to insert the marks in the system.

Using the “Mark Exam Sheets” button, the examiner

ﬁlls in the ﬁelds “S-Barcode”, “Mark”, “Date” in-

side the mark table seen above (Table 2). This is the

only information that the examiner can gather from

an anonymous exam sheet. The enrollment number

(“ENRL”) will be ﬁlled in later.

4.3 Notify Exam Sheets

When the examiner has ﬁnished marking the anony-

mous exam sheets and stored the marks in the sys-

tem, he is ready to notify the marks to the candidates.

However, he cannot link each exam sheet to its owner

yet. This can be done only through the authentication

tokens. So, the examiner asks each candidate to hand

his token in. As the examiner scans in a barcode, the

system matches it against two tables.

First, the live barcode is searched in the barcode

table to prevent potential attempts at submitting a fake

token with a fake barcode. Without this check, the

candidate might have downloaded our system (Gi-

anpiero, 2009), printed out an exam sheet with the

proper layout, a barcode and some plausible questions

at home, and answered the questions before the exam

date. At the exam, he would have needed to swap the

real exam sheet with his fake, terminated, one before

being authenticated.

If this ﬁrst check succeeds, the live barcode is

searched in the mark table. When found, the examiner

ﬁlls its “ENRL” ﬁeld with the enrollment number read

from the token. This is how WATA audits each can-

didate’s attempts at passing an exam. Then, WATA

opens up a popup window with the candidate’s latest

mark and full audit trail. The examiner can then tell

the candidate his mark if the trail complies with the

exam policy — for example, certain university poli-

cies prevent a candidate who fails an exam to try it

again at the very next available exam date.

This process shows how the system guarantees

anonymity of the candidate until the candidate him-

self gives the token back. As noted above, this feature

protects both the candidate and the examiner from

each other, but cannot help towards their collusion.

4.4 Other Features of WATA

WATA also implements the following useful facilities

(Fig.4) to interact with the underlying database.

• Show Table: it visualizes the contents of a table,

such as a question table or a mark table.

• Create Table: it creates an empty table, for exam-

ple to support exams for more than one discipline.

• Rename Table: it edits a table name conveniently.

• Import from File: it imports questions from a for-

matted text ﬁle, such as those exported from Mi-

crosoft Access.

5 IMPLEMENTATION OF WATA

Portability is one of the most important requirements

for a software. It should be possible to install the soft-

ware on different computers regardless of the Operat-

ing System. To meet this requirement, we decided to

write WATA in JAVA, which allows one to develop

multiplatform-software and to run it through the Java

Virtual Machine (JVM).

Moreover, WATA uses MySQL (Sun-

Microsystem, 1996) as DataBase Management

CSEDU 2010 - 2nd International Conference on Computer Supported Education

136

System (DMBS). The implementation of WATA

is lightweight and can therefore run on all current

machines. The only requirements are a JAVA version

(al least 1.4.2), and a MYSQL version (at least 5.0).

5.1 A Glimpse at the Code

While the full code of WATA can be obtained from

the authors on demand, it may be useful to look more

closely at a key fragment here.

Fig.5 shows the kernel of the method used to shuf-

ﬂe the questions from the question table (§4.1). In

particular, rows 440 to 446 pertain to the SQL query,

which shufﬂes the questions according to a random

number taken as a parameter. It is interesting to ob-

serve how that random number is computed, as it is

also used for barcode generation (§3.2). Our initial

attempt to compute the random number was to use the

number of seconds elapsed from the date 1970-01-01,

which is output by UNIX TIMESTAMP(). However,

it was soon realised that this is insufﬁcient because the

query could be launched more than once in the same

second and would then yield the same output. So, the

output of the Math.random() function is added.

Then, the loop from rows 451 to 455 extracts the

questions just shufﬂed and stores them in a dynamic

vector. During the printing phase, WATA takes the

questions from that vector and sends them out to the

printer.

5.2 History and Future of WATA

The version of WATA described in this paper is WATA

2.0, which supersedes WATA 1.0.

WATA 1.0 was the ﬁrst stable release. It was only

available for Microsoft Windows (Microsoft, 1985),

as it was written in Visual Basic and the database

support was provided by Microsoft Access. The big

drawback of WATA 1.0 was scalability. In fact, when

the examiner tried to print a high number of exam

sheets, the software became very slow because the al-

gorithm used to shufﬂe the questions was inefﬁcient.

Today, with WATA 2.0, we overcome the scalability

and portability limitations of WATA 1.0

As future extensions WATA, could introduce a

functionality to separate the questions into difﬁculty

classes. This would enable the system to let the ex-

aminer somewhat control the difﬁculty of the ques-

tions printed out on the exam sheets. For example, it

would be possible to implement a requirement that

each exam sheet contain one question of difﬁculty

“medium” and two questions of difﬁculty “high”.

Another feature that we plan to introduce in the

future is some L

X(LaTeX, 1985) support. The cur-

rent version of WATA allows to store only text ques-

tions, and so no mathematical symbols are allowed. A

Xplugin would offer full support to a large range

of symbols.

6 CONCLUSIONS

University exams or public competitions may suf-

fer various forms of cheating. Authentication and

anonymity may alternatively help face some of them,

but are inherently difﬁcult to use jointly.

We advance a solution called WATA to face these

problems in case of written tests. WATA supports the

establishment of exam sessions that are authenticated

though anonymous. The system relies on an authenti-

cation token, which contains the candidate’s personal

information, and a truly anonymous exam sheet. The

authentication token is retained by the candidate who

therefore is the sole entity who can protect his own

anonymity. The token is mechanically linked to the

right exam sheet by scanning a barcode.

WATA has been used in support of the ﬁnal exam

of the Computer Security course at our university

ever since 2004. The results are encouraging: the

overhead on the lecturer was only negligible, while

the students gladly accepted the new system. WATA

was described at the beginning of the course. At the

end of the course some students felt that WATA had

given them more freedom in their interaction with the

lecturer, because it had dissipated their concerns to

somewhat negatively inﬂuence the lecturer’s evalua-

tion of their exams.

The latest version of WATA has been made pub-

licly available through the Internet these days (Gian-

piero, 2009). WATA currently comes under a Creative

Commons (Creative-Commons, 2001) — Attribution

Non-Commercial No Derivatives — licence.

REFERENCES

Creative-Commons (2001). Creative commons.

Gianpiero, C. (2009). Wata.

Gray, D. (2003). Anonymous coursework submission. In

CompSysTech ’03: Proceedings of the 4th interna-

tional conference conference on Computer systems

and technologies, pages 556–561, New York, NY,

USA. ACM.

LaTeX (1985). Latex project site.

Microsoft (1985). Microsoft windows.

Microsystems, S. (1991). The source for java technology.

Sun-Microsystem, M. (1996). Mysql.

WATA - A System for Written Authenticated though Anonymous Exams

137
