CROSSING FRAMEWORK

A Dynamic Infrastructure to Develop Knowledge-based Recommenders

in Cross Domains

Mustafa Azak and Aysenur Birturk

Dept. of Computer Engineering, Middle East Technical University, Inonu Bulvarı, Ankara, Turkey

Keywords: Web Personalization, Recommender Systems, Cross Domain Recommendation, Recommendation

Frameworks, Recommender Engines.

Abstract: We propose a dynamic framework that differs from the previous works as it focuses on the easy

development of knowledge-based recommenders and it proposes an intensive cross domain capability with

the help of domain knowledge. The framework has a generic and flexible structure that data models and

user interfaces are generated based on ontologies. New recommendation domains can be integrated to the

framework easily in order to improve recommendation diversity. We accomplish the cross-domain

recommendation via an abstraction in domain features if the direct matching of the domain features is not

possible when the domains are not very close to each other.

1 INTRODUCTION

Over the last decade, several researches have been

made to improve the recommendation methods and

user modeling techniques in order to extend quality

of recommendations and provide maximum user

satisfaction (Anand & Mobasher, 2003).

Therefore, exploiting the user profiles of Web

2.0 style sharing platforms (Szomszor et al, 2008)

and applying advanced recommendation methods,

recommender systems have achieved remarkable

practical and commercial success. Amazon.com,

Last.fm, Netflix and MovieLens are the most

successful and popular examples of the

recommender systems. Although web-based social

and commercial networks provide variety of

interests for users in various domains such as books,

movies, music and games; most recommendation

systems currently provide recommendations within a

single domain based on the domain specific

knowledge. The current infrastructures of the

recommender systems cannot provide the complete

mechanisms to meet user needs in different domains

and recommender systems show poor performance

in cross-domain item recommendations. Generally,

they only consider the statistical analysis on the

cross-selling markets and try to make use of

relations between popular items without

personalized recommendations. Therefore, there is a

lack of cross-domain recommenders which can

make successful personalized recommendations in

cross-domains. Moreover, there is no framework to

develop cross-domain recommender systems.

In this paper, we propose a dynamic framework,

which enables addition of new recommendation

domains and provides the development of

knowledge-based cross-domain recommenders as

well as single domain recommenders. The addition

of a new recommendation domain is crucial because

it enables to improve the recommender system’s

capability and evolve the system according to new

user needs. In order to provide dynamic domain

additions to framework, our system considers each

domain as a pluggable component that provides the

required domain data via well defined interfaces.

Providing accurate predictions and useful

recommendations among these integrated domains

are the other important capabilities of the proposed

framework. The framework provides knowledge-

based recommender development with a hybrid

approach for generating recommendations. Our

recommendation engine has different types of

recommendation strategies which are applied

depending on the available data about the user and

the items in domains. Collaborative and content-

based strategies use feature-weighted models in

similarity calculations. In addition, we have also

high level abstractions and relations between

domains. The relational information about domains

can be dynamically added to the framework by

125

Azak M. and Birturk A.

CROSSING FRAMEWORK - A Dynamic Infrastructure to Develop Knowledge-based Recommenders in Cross Domains.

DOI: 10.5220/0002807901250130

In Proceedings of the 6th International Conference on Web Information Systems and Technology (WEBIST 2010), page

ISBN: 978-989-674-025-2

defining the rule sets which provide inter-domain

knowledge between two specific domains. The

inter-domain knowledge is used for feature mapping

between domains and it affects the weights of

features in target domain while generating a cross

domain recommendation.

The remainder of the paper is organized as

follows. In the next section, we overview the related

work, then we present the overview of our proposed

framework in the section 3. Then, the

implementation process is described in detail in the

section 4. Evaluation process is explained in the

section 5. Finally, the future work and concluding

remarks are presented in the last section.

2 RELATED WORK

There has been much research done on the possible

extensions of current recommenders systems. In this

section, we briefly mention some related work in

recommender systems architectures, cross-domain

and multi-content recommendation approaches.

(Loizou, 2007) introduces a framework outline for

achieving multi domain recommendation by

providing detailed user representation with a

universal vocabulary and community experts’ data

during the addition of new domains. (Chung et al,

2007) discusses another framework for individual

functioning in multiple domains. (Gonzalez et al,

2006) analyzed the cross-disciplinary trends from

human perspective to develop ambient recommender

systems by introducing smart user models.

(Berkovsky et al, 2005) represents mechanisms to

develop cross-domain user modeling by mediating

and integrating partial user models stored in

different resources and knowledge bases.

There are few framework approaches to meet

users’ needs in multiple domains. Our framework

approach differs from the previous works as it

focuses on the easy development of knowledge-

based recommenders and proposes an intensive

cross domain capability with the help of domain

knowledge. Our aim is to develop reasonable

recommenders and generating useful and

personalized cross-domain recommendations. We

accomplish the cross-domain recommendation via

an abstraction in domain features if the direct

matching of the domain features is not possible

when the domains are not very close to each other.

3 OVERVIEW OF THE

FRAMEWORK

The objective of this study is to provide a framework

for recommender systems that is capable of

integrating new domains dynamically, creating

semantic relationships between existing domains and

extending traditional recommendation approaches to

provide more accurate and useful recommendations

in cross domains. The capability of adapting new

domains and creating useful cross domain

recommendations result in offering a bundle of

related items from different domains and thus

improve the possibility of user satisfaction. The

adaptive and flexible infrastructure also provides the

capability to integrate variety of new and existing

systems to framework easily. In addition, the cold

start problems of new domains can be minimized by

providing domain knowledge and assigning features’

weights as accurate as possible in user models. The

dynamically provided inter-domain knowledge helps

us to determine the domains’ relationships and

features mapping in different domains. In order to

achieve the above goals, we designed our framework

in a modular way, shown in Figure 1. The details of

the framework and its components are explained in

the rest of the section.

Figure 1: Overview of the Framework.

3.1 Profile Management

Creating a comprehensive and detailed user model is

very important to analyze user interests and needs

correctly. Our profile management component is

responsible for creating and maintaining the user

profiles. It has two main parts to support the

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

126

recommenders in the system. “Data” part provides

required knowledge about user preferences while

“Actions” part enables users to edit their profiles.

3.2 Recommender Engine

Our framework provides knowledge-based

recommender development and provides a hybrid

approach for generating recommendations. The

recommendation engine has different types of

recommendation strategies which are applied

depending on the available data about the user and

the items in domains. The system starts with the

simple recommendation techniques and move to

more complex algorithms with user’s experience.

3.2.1 Recommendation Strategies

Most Popular Items strategy is the simplest

technique in the system but it helps us to generate

useful prediction when no data available about users.

The algorithm finds the most popular items in

integrated domains by sorting the item scores. This

strategy also used with other strategies to find the

popular items for a specific set of users.

Demographic Filtering is similar to collaborative

filtering but it uses the demographic information of

user in order to find the similar user profiles. User’s

demographic information is represented as feature

vector and each feature has weights for each domain.

Content Based Filtering recommends similar items

to the ones that user preferred in the past. The

candidate items compared with the previously rated

items and best matching items are recommended as

described in (Adomavicius & Tuzhilin, 2005).

Collaborative Filtering recommends the items that

people sharing the similar preferences with the user

prefer. It assumes that user likes the items that are

highly rated by similar users. The similarity between

users is calculated based on commonly rated items.

Our system uses Pearson correlation coefficient to

measure the user similarity (Adomavicius &

Tuzhilin, 2005).

Surprise strategy is used to overcome

“Overspecialization Problem” and “Sparsity

Problem in Rating”. Our framework generates one

surprising recommendation randomly among the

newly added items, popular items or few rated items

Knowledge-Based recommendation is not used

standalone but it helps other recommendation

strategies. The knowledge base is used by our

system to retrieve rules about the users, features,

domain relations and feature mappings. These rules

help us to create user groups in domains and define

the relations between user groups and item features.

The rules for these relations are defined as 6-tuples

,, ,,,

GroupRule d uf ufv if r status

> where

d represents the domain,

defines the user

feature name and

ufv is the value of the given

feature in

uf , if indicates the item feature name,

ifv

is the value of that item feature and status

determines whether this rule affects rating prediction

positively or negatively.

For instance, we can define a group rule such as

“Observer people like Animation movies”. It is

based on “personality” feature of user and it uses

“genre” feature of items in “movie” domain. It also

states that if this rule holds for a user, it affects the

rating positively.

GroupRules < Movie, Personality,

Observer, Genre, Animation, Like >

The group rules directly affect the predicted ratings

of a user on items by using the formula below:

knowlege effect ( if conditions holds)

0 (otherwise)

ik ik

⎧

=±

⎨

⎩

,ik

r is the final rating calculated where

,ik

r is the

rating by user i on item k determined by

Collaborative Filtering or Content-Based filtering

algorithm. The value of knowledge effect is

between 0 and 1. It is calculated experimentally and

can be configured.

3.2.2 Recommendation Generation

When a new user logs in to system and there is no

information available about user, recommendations

are generated using the “most popular item”

strategy. If the demographic information is

available, “demographic filtering” is also applied.

Recommendation generation evolves with the user

experience in the system. In the case of having

enough rating history for a domain but not having

required number of co-rated items with other users

in target domain, “content-based filtering” is used.

When the user has enough number of co-rated items

with other users in target domains, “collaborative

based filtering” is used to generate

recommendations. “Knowledge-Based”

recommendation is used with Collaborative Filtering

or Content-Based filtering algorithm. “Surprise”

Strategy is always used but it only generates one

random recommendation at a time.

3.3 Domain Management

The domain management component mainly deals

with the integrated domains and their relationships.

It includes the “Domain Knowledge” of all domains

which is required by knowledge-based

CROSSING FRAMEWORK - A Dynamic Infrastructure to Develop Knowledge-based Recommenders in Cross Domains

127

recommendation. Domain management component

also contains the general ontology interface with

XML schema of the framework. General ontologies

of framework have the specifications of features and

relationships between features of different domains.

They provide the uniformity and knowledge

exchange between different domains.

3.4 Code Generation Module

Code generation module generates the code for all

dynamic graphical user interfaces based on the data

models defined in ontology files. When new

domains are integrated to framework or data models

are updated, the changes can easily be applied to

system by this module.

3.5 Items Module

Items are the elements of domains such as books,

movies, or songs that are recommended to user

according to the user preferences. Our items module

is responsible for retrieving and maintaining items

from integrated domains.

3.6 Test Suite

It is one of the most important components of the

framework. Test Suite provides an environment to

test, evaluate and verify the algorithms of

recommender engine. It also allows us to observe the

effects of the knowledge base on the integrated

domains.

3.7 Common Vocabulary Adapters

Each domain data has its own data structures and

ontology but in order to integrate a domain to

framework, we have to transform its domain

information to a common vocabulary and structure.

Therefore, for each domain, a common vocabulary

adapter is needed to be developed. Considering the

general ontologies and XML schema of the

framework; a common vocabulary adapter deals

with ontology mapping and type conversions of the

features.

3.8 Target Domains

Recommendation domains are the specific fields of

interests and constitute of knowledge about users,

items, concepts and relationships in a field. We

divided domain information into four categories:

User data is a feature vector that represents the

user preferences. User data has also transaction

history and item ratings which constitute the

knowledge about user actions history that help us

predict user attitude to new items and new domains.

Items are the elements of the domains which have

certain features based on the domain structures and

specifications. Domain knowledge stores the

structured knowledge about the domains which is

retrieved and used to determine weights of factors

which have effects on items during the

recommendation process. Domain ontology

represents the meanings of the terms in user data,

community data and item features. The concepts and

relationships are defined by ontological categories.

4 IMPLEMENTATION DETAILS

A prototype of the framework has been developed to

evaluate the proposed structure in the Figure 2. It is

an online cross domain recommender system which

will be available at www.crossingframework.org.

The main purposes of the prototype are to test

applicability of the framework, provide interaction

with real world users, observe the performance of

inter-domain knowledge rules and prepare an

environment to evaluate the recommendation

strategies. The core of framework was developed

with Java programming language. Dynamic and

flexible data interaction is provided over the

ontology files with XML interfaces. Common

vocabulary adapters are developed for target

Figure 2: The Prototype Implementation of the

Framework.

domains such as movie and book domains.

Ontology files are required for the generation of

the data structures in the system and creation of

tables in the database. They consist of features with

the description and other required attributes for

system. All dynamic graphical user interfaces of the

framework are generated automatically based on

these features.

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

128

When a new domain is needed to integrate with

the framework, the corresponding data files should

be created according to the following ontology files:

Domain Ontology, Item Ontology, User Ontology,

Rating Ontology, User Profile Similarity Ontology

and Item Similarity Ontology.

The framework has different interfaces and

perspectives for end users and administrators.

5 EVALUATION

Automated testing is not applicable for cross-domain

testing because there is no dataset available for our

target domains. Therefore, we focus on the single

domain testing and defer cross-domain tests until the

deployment of the prototype of the framework and

beta testing with real end users. For each single

target domain, recommender engine is tested with

framework’s test suite and we observed the effects

of group rules on collaborative filtering algorithm.

Besides the evaluation results, our aim is to show

that our framework enables easy development of

knowledge-based recommenders and it also facilities

a testing environment to test, evaluate and verify the

algorithms of recommender engine and its

knowledge base. For their evaluation process, we

follow the steps explained below.

5.1 Knowledge Acquisition

In order to form a knowledge base about the target

domains ‘movies’, ‘music’ and ‘books’, we prepared

an online survey and 100 people from 10 different

countries were participated. The purpose of the

survey is to learn users’ preferences and needs in

target domains and their personality features. Some

example questions from the survey are as follows:

 Would you sort the following MOVIE features

considering the importance for you?

"Title, Actor, Actress, Producer, Director, Year,

Genre, Tags, Language, Country”

 Which types of MOVIES you like?

“Action, Animation, Comedy,…, Other”

 How do you define yourself?

“Perfectionist, Helper, Performer, Romantic,

Observer, Questioner, Adventurer, Boss,

Peacemaker”

For personality types we chose the nine types of

the Enneagram of personality given above which are

useful in classifying characters. The results of the

survey are analyzed statistically with the SPSS

(Statistical Package for the Social Sciences)

software by the help of two professional

statisticians. The feature relations and rules about

users’ preferences and tendencies such as

“Observers dislike Romance movies” and “Helpers

like Romance movies” are obtained.

We tested each rule’s effects on the collaborative

and content-based recommendation algorithms.

5.2 Metrics

In order to determine the prediction quality of our

knowledge-based approach which extends

collaborative and content-based algorithms, Mean

Absolute Error (MAE) metrics (

Sarwar et al, 2001)

was used. The MAE is computed by first summing

the absolute errors of the N corresponding ratings-

prediction pairs and then averaging the sum. A

smaller value of MAE indicates a better accuracy.

5.3 Data Sets, Common Vocabulary

Adapters and Data Preprocessing

In order to test our approach we developed common

vocabulary adapters for the movie, music and book

domains using the datasets available datasets. For

this work, we present the dataset for movie domain.

We used a popular database, the MovieLens

dataset by the GroupLens Research group. The data

set contains 1682 movies, 943 users and 100,000

ratings (1–5 scales), where each user has rated at

least 20. We matched the movie’s information with

the IMDb dataset to extract extra features.

To compare our approach with the state of art

collaborative algorithm, we chose the cross

validation technique with holdout method and

performed the experiments under the different

configurations.

As our knowledge base rules make use of user’s

personality features, some preprocessing is required

in order to determine the active user’s personalities

in these configurations. We used Weka (Waikato

Environment for Knowledge Analysis) which is a

popular suite of machine learning software in order

to classify users via Decision Trees.

5.4 Evaluation Results

Because of space limitation, we present two

different knowledge base performances against a

state-of art collaborative filtering technique (CF)

(Adomavicius & Tuzhilin, 2005) on movie data set.

We prepare the knowledge bases with the following

rules:

Knowledge Base 1 (KB1)

 “Observers like Animation movies”

 “Observers dislike Romance movies”

CROSSING FRAMEWORK - A Dynamic Infrastructure to Develop Knowledge-based Recommenders in Cross Domains

129

Knowledge Base 2 (KB2)

 “Helpers like History movies”

 “Helpers like Romance movies”

The number of nearest neighbors in collaborative

filtering is set as 35 and the knowledge effect

variable is set to 0.4 in all configurations since it is

best value shown in Figure 3.

Table 1: MAE comparison of methods.

Training

Users

Metho

Given5 Given10 Given20

Movie

100

CF 0.8605 0.8461 0.8591

KB1 0.8628 0.8482 0.8606

KB2 0.8619 0.8474 0.8612

Movie

200

CF 0.8528 0.8357 0.8453

KB1 0.8541 0.8365 0.8461

KB2 0.8533 0.8358 0.8454

Movie

300

CF 0.8490 0.8430 0.8377

KB1 0.8500 0.8433 0.8383

KB2 0.8493 0.8432 0.8376

In table 1, we can observe that our prediction

approach cannot improve the quality of the state-of-

art collaborative filtering algorithm in any

configurations. The only improvement is in the

Movie300Given20 with KB2 but the difference

between Collaborative filtering is not significant.

Although the initial results do not seem very

satisfying, we can assume that our framework

infrastructure and testing suite is working and group

rules have effects on the predictions. The results can

be better with different rule combinations.

Additionally, we had some disadvantages about

determining the users’ personality in the survey and

the dataset. The participants might make mistakes

about deciding their real personalities in the survey

and there is an error rate at the decision trees used in

WEKA

In order to examine the sensitivity of the

knowledge effect variable, we varied the value of the

variable and computed the MAE for each variation.

The Figure 3 shows that 0.4 is the optimum value for

the knowledge effect variable.

Figure 3: Impact of Knowledge Effect on MAE.

6 CONCLUSIONS

In this work, we proposed a dynamic framework for

developing knowledge-based cross-domain

recommender systems. The framework has a generic

and flexible structure that data models and user

interfaces are generated based on ontologies. New

recommendation domains can be integrated with the

framework easily in order to improve

recommendation diversity. In addition, knowledge

base helps to generate useful recommendations in

cross-domains and maximize user satisfaction.

We can conclude that cross-domain

recommendation approach will gain more attention

in near future and our framework can be used to

develop successful recommenders.

REFERENCES

Adomavicius, G. and Tuzhilin A. 2005. Toward the Next

Generation of Recommender Systems: A Survey of

the State-of-the-art and Possible Extension. IEEE

Trans. Know. And Data Eng. 17, 6: 734-749.

Anand, S. and Mobasher, B. 2003 Intelligent Techniques

for Web Personalization. IJCAI 2003 Workshop.

Berkovsky, S., Kuflik, T. and Ricci, F. 2005.

Entertainment Personalization Mechanism through

Cross-domain User Modeling. 1st Int’l Conf.

Intelligent Tech. for Interactive Ent., 215-219.

Chung, R., Sundaram, D. and Srinivasan, A. 2007.

Integrated Personal Recommender Systems. ICEC’07.

Minneapolis, Minnesota, USA.

Gonzalez, G., Lluıs de la Rosa. J, Dugdale, J., Pavard, B.,

El Jed, M., Angulo, C. and Klann, M. 2006 Towards

Ambient Recommender Systems: Results of New

Cross-disciplinary Trends. In Proc. of the EU Conf. on

AI, WS on Recommender Systems.

Loizou, A. 2007. Unlocking the Potential of

Recommender Systems: A Framework to Achieve

Multiple Domain Recommendations. Sch. of

Electronics and CS, University of Southampton.

Sarwar, B., Karypis, G., Konstan, J., & Reidl, J. 2001.

Item-based collaborative filtering recommendation

algorithms. In Proc. of the 10th Int’l conf. on WWW.

Sebastiani, F. 2002. ML in Aut. TC. ACM Comp. Surv.

Szomszor, M., Cantador, I. and Alani, H. 2008.

Correlating User Proﬁles from Multiple Folksonomies.

ACM Conf. on Hypertext and Hypermedia.

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

130
