CLUSTER MECHANISMS IN A SELF-ORGANIZING

DISTRIBUTED SEMANTIC STORE

Marko Harasic, Anne Augustin, Robert Tolksdorf and Philipp Obermeier

AG Networked Information Systems, Freie Universität Berlin, Königin-Luise-Str. 24/26, D-14195 Berlin, Germany

Keywords:

Self-organization, Semantic web, Clustering.

Abstract:

Distributed semantic stores can employ self-organization principles to improve their scalability. We present

an implementation that uses ant colony optimization for clustering similar semantic information facilitating

scalable retrieval. For the clustering mechanisms we use similarity measures that do not rely on access to

a complete ontology. We describe a syntactical and a ﬁngerprint-based similarity measure and discuss them

regarding to expressiveness and computational effort. The results of an evaluation show that, with increasing

volume of data and number of processes, the ﬁngerprint-based measure performs much better than the syn-

tactical one. We conclude with a discussion how to combine the advantages of the two measures and propose

some technical enhancements improving the efﬁciency of the system.

1 INTRODUCTION

In adherence to the Semantic Web’s distributed na-

ture, RDF knowledge bases are, in general, scattered

across multiple server machines on the Internet. How-

ever, there are still no coherent solutions for efﬁcient

distributed storage and retrieval for these vastly grow-

ing amount of data. Admittedly, there are a num-

ber of very powerful RDF triple stores handling mil-

lions or even billions of triples, e.g. Virtuoso Server

BigOWLIM

and Allegro Graph

. These are de-

signed, though, to operate on a central server ma-

chine or a computer grid comprising a limited number

of hosts still depending on centralized components.

Therefore, these concepts cannot scale for the mil-

lions of web servers as they exist on the Internet today.

To cope with such huge server networks, our approach

is to use self organization mechanisms like they are,

for example, found in ant colonies to decentralize the

storage access, preventing bottlenecks and as a result

provide a scalable highly distributed store for seman-

tic information. In this paper we present a distributed

RDF store where triple storage and retrieval is per-

formed by simple virtual ants which cluster similar

triples in a server network. The resulting system gets

http://virtuoso.openlinksw.com/

http://www.ontotext.com/owlim/big/

http://www.franz.com/agraph/allegrograph/

along without any central control, triple writing and

retrieval can be executed from each node in the net-

work enabling load-balanced requests.

The rest of this paper is organized as follows. In

Section 2 we give a short introduction in RDF and

SwarmLinda, present two other approaches of dis-

tributing RDF stores. We introduce in section 3 the

underlaying algorithms for writing an retrieving data,

while in section 4 we present the similarity measures

used by the algorithms of section 3. Section 5 gives a

brief overview about the implementation. Finally sec-

tions 6 and 7 show and discuss the test results of this

paper and gives an outlook over future work.

2 RELATED WORK

SwarmLinda (Menezes and Tolksdorf, 2003) is a

Linda-System (Gelernter, 1985) that uses swarm al-

gorithms to store and retrieve data from a server net-

work. Data is stored as tuples that contain several

typed ﬁelds and retrieval is performed on the base

of templates that match these tuples. For example

to retrieve a tuple <"zebraﬁsh",55> from the store a

template <String, int> could be used as well as <"ze-

braﬁsh",int> or <String,55>. In analogy to ants in

nature that perform foraging and brood sorting tasks

(Bonabeau et al., 1999), tuples in SwarmLinda that

131

Harasic M., Augustin A., Tolksdorf R. and Obermeier P.

CLUSTER MECHANISMS IN A SELF-ORGANIZING DISTRIBUTED SEMANTIC STORE.

DOI: 10.5220/0002808401310136

In Proceedings of the 6th International Conference on Web Information Systems and Technology (WEBIST 2010), page

ISBN: 978-989-674-025-2

match the same template are clustered and trails are

left in the system to make these clusters traceable.

In (Tolksdorf and Augustin, 2009) and (Koske,

2009) the ant colony algorithms of SwarmLinda were

adopted to realize a distributed storage for RDF triples

in which similar triples are clustered. RDF (Resource

Description Language)

is a language to represent in-

formation about resources on the Web in a machine

readable way. An RDF triple is used to describe a

resource that is identiﬁed by a URI. An RDF triple

always has the form (S,P,O), where S is the subject

and P and O the predicate and object of the triple. For

example, with the triple( http://birds.org/description/

onto.rdf#sparrow, http://animals.org/livesOn, http://

plants.org/grains) we can state that sparrows live on

grains.

To overcome the scalability issues for storing mil-

lions of triples, P2P-algorithms where adopted to ﬁt

the needs of RDF-storage. While Edutella (Nejdl

et al., 2001) bases on a Gnutella like approach, RDF-

Peers (Cai and Frank, 2004) uses a distributed hash

table (DHT) to compute the storage locations of RDF-

triples. Edutella offers a simple and cost effective way

to create the P2P-network for an arbitrary large num-

ber of peers, query processing suffers from a large

number of peers since queries are processed by ﬂood-

ing the network creating a large overhead of traf-

ﬁc. On the other side the DHT approach of RDF-

Peers guaranties the routing of queries in O(logn)

messages, but DHTs are costly to maintain. In our

approch we try to combine the beneﬁts of both ap-

proaches without their drawbacks. The network is

created as simple as possible like Edutella and the

routing with pheromones makes it possible to answer

a query as fast as RDFPeers by using the optimal path

to the location of the triple. Since the dimension d

of power law graphs is usually limited to O(logn),

a query can be processed with only O(log n) mes-

sages. In this work we present an implementation of

a triple storage using optimised versions of the algo-

rithms from (Tolksdorf and Augustin, 2009) and pro-

vide an evaluation of this system in respect of scal-

ability comparing the syntactical similarity measure

from (Tolksdorf and Augustin, 2009) and a ﬁngerprint

based similarity measure.

3 ALGORITHMS

To store and retrieve RDF triples from the system the

write and read procedures are used which are per-

formed by w- and r-ants. Ants communicate indi-

http://www.w3.org/RDF/

rectly by depositing information on the nodes. These

so-called pheromones evaporate over time, making

the system adaptive to changes in network topology

and stored content. All ants behave autonomously

and probabilistically and use only local information

to compute their decisions. Each node holds a routing

table, maintained by the passing ants and which they

use for returning to the node of request.

3.1 Triple Writing

In the system, three copies for each inserted triple ex-

its, which each is clustered in regard to the triple’s

subject, predicate and object. As a result each node

holds three types of clusters, a subject, predicate and

object cluster which contain the triples that were clus-

tered regarding their subjects, predicates and objects,

respectively. Thus for a triple to be stored three w-ants

are generated which roam the network to ﬁnd a suit-

able cluster for one of the triple’s resources respec-

tively. In the following we will refer to this resource

as cluster resource. The behavior of a single w-ant

is as follows. The w-ant starts living at the node of

the request and carries one triple copy and a resource

pointer r ∈ {S, P,O} which indicates the triple’s clus-

ter resource. In order to decide if the triple should be

dropped on the current node the ant measures the sim-

ilarity of its cluster resource r to the cluster resources

... r

in the appropriate resource cluster. The nor-

malized sum of the resulting similarity values

Sim =

∑

i=1

sim(r,r

) (1)

is used for computing the drop probability.

drop

Sim

Sim + c

drop

(2)

In equation 2 Sim is an exchangeable similarity mea-

sure to determine the similarity between two re-

sources and c

drop

a constant value which modiﬁes the

likelihood of dropping the triple on the current node.

Based on P

drop

the w-ant decides whether to drop

its triple on the current location. If it does it stores

it in the appropriate cluster and walks back to its ori-

gin to report the success of the writing procedure. On

its way back it lays its cluster resource as pheromone

on each edge it takes. While the ant does not decide

to drop the triple it roams the network selecting paths

which are marked with pheromones of its cluster re-

source. The probability to change from the current

node i to a node j in its neighborhood NH(i) is given

by the following equation.

i j

(cr)

∑

n∈NH(i)

(cr)

(3)

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

132

In equation 3 Ph

(cr) is the amount of pheromones

matching the cluster resource cr on node k. The w-

ants age with each node change preventing them from

wandering around in the network endlessly. When a

w-ant reaches a certain age it drops its triple on the

current location whether it ﬁts there or not and returns

back to its origin, spreading the pheromone Ph

(cr)

corresponding to its cluster resource cr along the path

traveled.

3.2 Triple Retrieval

Triple retrieval is performed by r-ants which return

all found triples matching a given pattern. For ex-

ample, to retrieve the triple (S,P, O) from the sys-

tem we can invoke read<(S,?P,?O)>. The pattern

matches all triples that have S as subject. For each

operation, one r-ant is generated which looks for a

triple that matches the pattern. For example, if the

pattern is (S, ?P,?O) the ant follows S-pheromones

Ph(S) to locate the appropriate cluster using equation

3 for the path selection. r-ants which ﬁnd a matching

triple or a set of matching triples return to the node

of the request and like the w-ants leave pheromones

on their way back. The r-ants also age with each hop

in the network, meaning that if they are not success-

ful in ﬁnding a matching triple after having visited a

certain number of nodes, they return to the node of

the request without result, not leaving a pheromone

trail. Because of the pure probabilistic behavior of

the whole system, an empty result does not imply the

absence of matching triples, leaving the client the de-

cision to rerun the reading process. Following oper-

ations for the same query use w-ants with increased

maximum age, realizing a deeper search.

4 MEASURES

The algorithms above work with exchangeable sim-

ilarity measures that lead to different kinds of clus-

ters. In the following we will present two different

measures. The syntactical similarity measure leads

to clusters of triples that resemble in their contained

URIs but has more computing complexity. The vec-

tor similarity measure does abstract entirely from the

actual similarity of the resources minimizing the com-

putational costs of the ants.

4.1 Clustering based on URI Similarity

The ﬁrst similarity measure that we used to cluster

similar triples was taken from (Tolksdorf and Au-

gustin, 2009) and compares the namespace of two

URIs. The similarity of two hierarchical URIs is mea-

sured by comparing the host and path component sep-

arately. The host and path themselves are splitted

into their hierarchical components which are com-

pared pairwise by applying the Levenshtein-distance

edit. The comparison of the segmented paths m =

/.. ./m

and n = n

... /n

of two URIs is

given as follows.

sim

path

(m,n) =

min(k,l)

∑

i=1

edit(m

) (4)

with

max(k,l)−i

max(k,l)

− 1

as a weighting function and edit as the normal-

ized Levenshtein-distance of two strings. As a re-

sult of the weighting function, a path segment a

level higher in the hierarchy is weighted double. To

compare the URIs http://birds.org/description/onto.

rdf#sparrow and http://birds.org/description/onto.rdf#

duck, ﬁrst the hosts would be compared which are

equal in this case and then the paths would be com-

pared. The paths would be splitted into three parts,

the ﬁrst one into description, onto.rdf and sparrow

and the other one into description, onto.rdf and duck.

The similarity between the two paths is then ≈ 0.86.

The similarity of two hosts is computed comparing

their domain-labels pairwise, starting with the hier-

archical highest label which is weighted highest. The

weighted sum of the host- and path comparison values

results in the overall similarity of the regarded URIs

and u

sim

URI

) = c

· sim

host

)

· sim

path

)

To achieve that the paths only differentiate the URIs

if the hosts are equal (or very similar) c

is set to 0.9

and c

to 0.1, so that the host is weighted ninefold.

So the overall similarity for the URIs above would

be 0.9 · 1 + 0.1 · 0.86 = 0.986. An overview of the

comparison is shown in ﬁgure 1.

In order to compute Sim, an ant has to compare r

with all cluster resources on the current node. Since

computing the Levenshtein-distance is rather costly,

this measure suffers from a growing amount of data.

In the following section, an approach for dealing with

a larger number of triples will be presented.

4.2 Clustering based on Fingerprints

For the second similarity measure we take an arbitrary

hash function which maps the URI strings to 32-bit

CLUSTER MECHANISMS IN A SELF-ORGANIZING DISTRIBUTED SEMANTIC STORE

133

Figure 1: Example for the comparison of two URIs with

the URI similarity measure.

numbers and consider them as vectors as deﬁned in

equation 5.

−→

h (v) = (h

(v),·· · , h

(v))

with h

(v) =



1, if h(v)/2

≥ 1

0, else

(5)

As similarity measure sim

vec

between two URI strings

v and w we take the scalar product of their so called

hash vectors which are normalized by the Euclidean

Norm kk.

sim

vec

(v, w) = h

−→

h (v)

−→

h (v)k

−→

h (w)

−→

h (w)k

∑

i=0

(v) · h

(w)

∑

i=0

(v)

∑

i=0

(w)

(6)

The sim

vec

value is in the range of 0 and 1. It is 1

if the hash values of the two URI strings are equal

and 0 if the resulting hash vectors are orthogonal as

the scalar product of two orthogonal vectors is al-

ways 0. For example, to compare two URIs u

=http:

//birds.org/description/onto.rdf#duck and u

=http://

birds.org/description/onto.rdf#sparrow, these would

ﬁrst be mapped to 32-bit numbers by an arbitrary

hash function h. For simpliﬁcation, in this ex-

ample we assume that the function maps to 4-bit

numbers. Given that h(http://birds.org/description/

onto.rdf#duck) = 5 = (0,1,0,1) and h(http://birds.org/

description/onto.rdf#sparrow) = 11 = (1,0,1,1) the

ﬁngerprint-based similarity sim

vec

between the two

URIs would be ≈ 0.4. Figure 2 shows the calculation

steps for this example.

For any scalar product holds:

∑

i=1

hx,y

i = hx,

∑

i=1

i (7)

Therefore for the vector similarity sim

vec

the follow-

Figure 2: Example for the comparison of two URIs with

the ﬁngerprint similarity measure.

ing holds.

∑

i=0

sim

vec

(v, w

) = sim

vec

(v,

∑

i=0

) (8)

This helps to reduce the computational effort of the

w. For each r-cluster on a node with r ∈ {s, p,o}

we keep the sum of the hash vectors to all clus-

ter resources l

... l

in that cluster up to date: T

∑

i=1

h(l

). An ant which wants to compute the simi-

larity sum Sim for a r-cluster gets along with one com-

parison: sim

vec

(cr,T

) instead of computing the sim-

ilarity to all cluster resources l

... l

in that cluster:

∑

i=1

sim

vec

(cr,l

). As T

is only updated when there

are triples removed or added to the cluster, the effort

to keep T up to date is relatively low compared to the

computational costs that are omitted with each step

that the writing ants make in the network. There-

fore the computational time can be kept in O(1) in

opposite to the O(n) time for the URI measure.

On the other hand, unlike the URI-based similar-

ity measure, the vector-based similarity measure does

not take any semantic similarity of the URIs into ac-

count. Depending on the given hash function, two

URIs which are semantically similar can have com-

pletely different hash values or completely different

URIs can have the same hash value.

5 IMPLEMENTATION

The RDFSwarms system is implemented in Java. It

consists of an arbitrary large number of identical

nodes following the P2P-paradigm.

Nodes and clients communicate over TCP/IP

streams through an byte based protocol, where each

operation is encoded as a single message. If a mes-

sage is received by a node, a thread is started to per-

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

134

form the operation (e.g. reading from a store, updat-

ing the pheromone table etc.), migrating the thread

from node to node until it fulﬁlls its task. Ants are re-

alized as single operations moving from node to node.























Figure 3: Architecture of the RDFSwarms System.

A node consists of several subsystems shown in

ﬁgure 3. The external socket to which other nodes

and clients can connect to is represented in the ﬁg-

ure as outgoing arrows. Over these connections the

ManagementAPI and the API communicates with the

neighborhood and the clients.

Decoded messages are passed by the API to the

Core Engine, which handles the management of the

performing threads. Every outgoing operation is ini-

tialized by the Core Engine and is passed to the cor-

responding APIs which handle the communication.

Ant-based operations are forwarded to the mod-

ular similarity system, supporting the measures pre-

sented in section 4. It further provides an interface

making the measures completely exchangeable for

further research.

Furthermore the system contains a Sesame 2

based component for storing triples and pheromones.

The storage system for triples is further divided into

three sub-stores (see section 3). Each store is respon-

sible for reading and writing triples according to its

cluster type. For pheromones only one store exists,

which is used by all ant-operations regardless of their

type of cluster resource.

6 EVALUATION

For the evaluation we used four networks with respec-

tively 10, 20, 30 or 40 virtual nodes which each had

the topology of power law graphs. The test runs were

executed on 10 identical machines, each equipped

with 512 MByte RAM, a 2.4 GHz Intel P4 using De-

bian Lenny as operating system.

http://www.openrdf.org/

We made sure, that no connected nodes run on

the same machine, otherwise the results would be

falsiﬁed as the inﬂuence of the communication be-

tween the two nodes running on the same machine

would not accounted into the evaluation results. As

test data, several testing sets with respectively 1.000,

10.000, 100.000, 1.000.000 RDF triples randomly se-

lected from the WordNet ontology

, were used. After

writing the data into the network, 10000 queries for

the corresponding datasets were performed. The same

test runs were carried out using the URI similarity as

well as the ﬁngerprint based similarity-measure. The

averaged results per performed operation of the four

test runs are shown in ﬁgures 4, 5 and 6.

Figure 4: Average writing time using ﬁngerprints.

Figures 4 and 5 show the time needed for writ-

ing n triples into a network of N nodes. The URI-

similarity measure was only evaluated with datasets

smaller than 10000 triples. As more nodes are added

to the network, the stores are stronger partitioned,

holding a smaller set of triples which can be compared

faster with r when using the URI-similarity. The

ﬁngerprint similarity does not proﬁt on more nodes,

since Sim can always be computed the same time. The

extra nodes visited in a larger network imply added

costs, but the path length is still limited to the dimen-

sion d of the network, which is O(log(N)), because

of the power law structure of the network.

Figure 5: Average writing time using URI.

The scalability behavior over the amount of triples

http://www.w3.org/2006/03/wn/wn20/

CLUSTER MECHANISMS IN A SELF-ORGANIZING DISTRIBUTED SEMANTIC STORE

135

differs between the two measures. Optimizations per-

formed on the ﬁngerprint measure realized a constant

cost for comparing a cluster resource with its corre-

sponding cluster. It even beneﬁts from large amount

of data, since the probability of ﬁnding a matching

cluster rises with large amounts of data stored on each

node. For the URI-clustering a similar optimization

was not found so far. Performance tests show, that the

ﬁngerprint based system performed about 500 times

faster then the URI system, storing about 2000 triples

per second making it competitive to a local instance

of a Sesame store in writing performance.

Figure 6: Average reading time per Triple.

Figure 6 shows the averaged test results for read.

In opposite to write, read performs slower, as more

triples are stored in the network, which can be justi-

ﬁed with the scalability problems of the Sesame stor-

age system (100 triples: 0.184 ms/triple, 10000 triples

3.434 ms/triple).

7 CONCLUSIONS AND FUTURE

WORK

We have presented an approach to build scalable dis-

tributed RDF stores. At the core are basic clustering

algorithms which are derived from ant colony opti-

mization and conﬁgured by distinct similarity mea-

sures. In this paper we have presented two simple

measures that can be determined by strictly local cal-

culations.

We have further noticed the inﬂuence of the stor-

age layer on the read performance. While being

scalable on writing, the read performance drops, if

enough data is stored. With a more scalable sys-

tem, the network can process read queries for larger

datasets in a shorter time. A new storage layer, which

supports the measures natively would increase the

whole performance, since current opererations suffer

from a wrapping mechanism for Sesame.

As previously pointed out, our URI and ﬁngerprint

similarity measures bear a trade-off of performance

against expressiveness, and vice versa, respectively.

In the future we aim for a hybrid measure, that com-

bines both clustering measures introduced here, en-

abling efﬁcient RDF triple clustering with regard to

URI similarities.

On another note, we are currently investigating

concepts that allow for reasoning in such a RDF store

by deﬁning algorithms for reasoning ants. These then

have to be integrated in our implementation and an

optimization cycle of the engineered RDFSwarms im-

plementation will be started. Furthermore, the RDF-

Swarms system will be applied as a storage infrastruc-

ture for an upcoming project dealing with semantic

geoinformation.

REFERENCES

Bonabeau, E., Dorigo, M., and Theraulaz, G. (1999).

Swarm Intelligence: From Natural to Artiﬁcial Sys-

tems. Santa Fe Institute Studies in the Sciences of

Complexity Series. Oxford Press.

Cai, M. and Frank, M. (2004). Rdfpeers: A scalable dis-

tributed rdf repository based on a structured peer-to-

peer network.

Gelernter, D. (1985). Generative communication in linda.

ACM Transactions on Programming Languages and

Systems, 7:80–112.

Koske, S. (2009). Swarm Approaches for Semantic Triple

Clustering and Retrieval in Distributed RDF Spaces.

Technical Report B-09-04B, FU Berlin, Institut für In-

formatik.

Menezes, R. and Tolksdorf, R. (2003). A new approach to

scalable linda-systems based on swarms. In Proceed-

ings of ACM SAC 2003, pages 375–379.

Nejdl, W., Wolf, B., Qu, C., Decker, S., Naeve, M.

S. A., Nilsson, M., Palmer, M., and Risch, T. (2001).

Edutella: A p2p networking infrastructure based on

rdf.

Tolksdorf, R. and Augustin, A. (2009). Selforganisation in a

storage for semantic information. Journal of Software,

WEBIST 2010 - 6th International Conference on Web Information Systems and Technologies

136
