PERFORMANCE EVALUATION OF POINT MATCHING
METHODS IN VIDEO SEQUENCES WITH ABRUPT MOTIONS
Wael Elloumi
*
, Sylvie Treuillet, Remy Leconge and Aicha Fonte
Institut Prisme, Polytech’Orléans, 12 rue de Blois, 45067 Orléans cedex2, France
Keywords: Interest Points, Local Descriptors, Matching, Performance Evolution, Video Sequence, Abrupt Motions.
Abstract: In this paper, we compare the performance of matching algorithms in terms of efficiency, robustness, and
computation time. Our evaluation uses as criterion, for efficiency and robustness, number of inliers and is
carried out for different video sequences with abrupt motions (translation, rotation, combined). We compare
SIFT, SURF, cross-correlation with Harris detector, and cross-correlation with SURF detector. Our
experiments show that abrupt movements perturb a lot the matching process. They show also that SURF is
the most disturbed, by such motions, and which even fails in cases that present a large rotation unlike the
rest of descriptors as SIFT and cross-correlation.
1 INTRODUCTION
While the problem of image matching has been
studied extensively for various applications, the
remaining questions are which feature detector and
descriptor performs the best and which one is the
most appropriate to match images in real time for
camera motion estimation. The field of our interest
is the indoor/outdoor navigation assistance for the
visually impaired with a low cost body mounted
camera. Since vision based localization of mobile
robots can rely on the assumption of the smooth
movements, human motions are rougher and
unpredictable and may cause loss in vision tracking.
It will be wise to investigate the limits of the vision
based localization especially in video sequences
with abrupt motions.
Some previous works propose comparative
studies of descriptors. Carneiro and Jepson (Carneiro
and Jepson, 2002) introduce a phase-based local
feature using Harris corner detector and compare it
to the differential invariant features. They use the
Receiver Operating Characteristic (ROC) curves as
performance criterion and demonstrate that
differential invariants are not the best for common
illumination changes and 2D rotation. A variant of
SIFT algorithm (Lowe, 2004) based PCA performs
better on artificial data according to the recall-
precision criterion (Ke and Sukthankar, 2004).
*
This study is supported by HERON Technologies SAS and the
Conseil Général du LOIRET.
Another extension of SIFT outperforms many
local descriptors but is more costly in computation
time (Mikolajczyk and Schmid, 2005).
All the references cited above compare
descriptors on image pairs using data set with
artificial or real geometric and photometric
transformations but not on video sequences. In this
paper, we propose a performance comparison of
three popular point matching methods. SIFT (Lowe,
2004), SURF (Bay and al., 2006), and Harris (Harris
and Stephen, 1988) with cross-correlation. All of
these algorithms are evaluated in efficiency,
robustness, and computation time criterion, using the
same scenario. The comparison is based on
sequences acquired with a camera attached to a
robot hand. Efficiency and robustness is evaluated
by the number of inliers (correct matches between
two images). Next section presents the experimental
setup, before results in section 3 and conclusion.
2 EXPERIMENTAL SETUP
Our experimental prototype is composed of USB PC
camera (320×240 pixels) fixed on the gripper of a
6dof robot arm and which are connected to a
desktop. Intrinsic parameters of the camera are
estimated by a prior calibration. The robot arm can
be controlled manually by its remote controller or
automatically by programming dedicated software,
using Cartesian or joint coordinate systems, with an
427
Elloumi W., Treuillet S., Leconge R. and Fonte A. (2010).
PERFORMANCE EVALUATION OF POINT MATCHING METHODS IN VIDEO SEQUENCES WITH ABRUPT MOTIONS.
In Proceedings of the International Conference on Computer Vision Theory and Applications, pages 427-430
DOI: 10.5220/0002823304270430
Copyright
c
SciTePress
adjustable velocity. This prototype allows us to
capture video sequences with rotations, translations
and combined motions including zoom effect and
abrupt motions.
Experiments data set consists of nine video
sequences acquired at 30 fps frame rate in a real
scene with brightness changes. We have chosen
rotation, translation in the y-direction to create a
zoom effect, and combined motion with rotation and
translation, to compare the different operators,
because these kinds of motions are the most
disturbing for matching process. Table 1 give details
on the video sequences related to 3 types of motion:
number of frame, shift or rotation angle between
frames. Several velocities of the robot arm were
tested during acquisition: low, medium, or high
velocity. Furthermore, to simulate more abrupt
motions and considerable transformations, we
matched distant key frames. Velocities of motions
present in these video sequences are faster than
normal motions of a human being. For example, the
lowest velocity of translation is 45 cm per second
and the lowest velocity of rotation 100 degrees per
second.
Based on the state of art presented in the
previous section, we have chosen to compare SIFT
because it’s the most robust, cross correlation with
Harris corner detector because it’s the fastest and
SURF descriptor which is considered as a good
compromise between computation time and
robustness. To have well distributed Harris points,
we have divided the images in buckets of size 15×15
pixels. The ZNCC correlation score is applied in
11×11 pixels ROI, with a minimum threshold of 0.8.
The cross correlation is used with Harris and also
with SURF detector to highlight the influence of the
detector on matching process.
For evaluation, we observe the robustness and
the computation time. The most popular metrics for
robustness are ROC and Recall-Precision curves.
Both are based on the number of correct matches
and the number of false matches obtained for an
image pair. We use the total number of correct
matches (inliers) and the percentage of inliers
compared to the total number of matched points
(inliers and outliers), described by the equation (1).
esfalsematchchescorrectmat
chescorrectmat
inliers
%
(1)
The number of correct matches and false
matches is determined with Least Median of Square
algorithm (Zhang, 1998) by estimating the
fundamental matrix in the image pair. The maximum
distance from point to epipolar line, beyond which
the point is considered an outlier and is not used for
computing the final fundamental matrix is equal to 1
pixel. The desirable level of confidence that the
matrix is correct is equal to 99%. The only
constraint of this method is that we must have at
least eight matched features. The computation of the
two-view geometry requires that the matches
originate from a 3D scene and that the motion is
more than a pure rotation. That is respected as the
camera is fixed slightly out of the rotation axis on
the robot clip.
To develop our comparative study, we perform
the following process for each video sequence:
1. Fix the number of frames to skip (frame jump)
between images to match.
2. Extract distinctive features in images and match
them using the different descriptors.
3. Select inliers from these candidates by estimating
the fundamental matrix using LMedS method.
3 RESULTS
In this section, we present in Figure 1 and Table 2 an
extract of the results for all carried experiments and
discuss the performance of the tested descriptors.
3.1 Image Rotation
Matching is tested between images with a rotation
angle between 7 and 120 degrees by varying
velocity and image jump. The number of inliers
clearly decreases for higher rotation velocity. SIFT
descriptor is the most robust to rotation followed by
SURF, which fails in fast rotation. Harris based
matching is more disturbed than SURF based
detector.
3.2 Image Scale Change
Scale change is achieved by a translation up to 1370
mm. All descriptors have a similar robustness, (% of
inliers), slightly lower for cross correlation. SURF
presents the lowest number of inliers for all
velocities. The number of inliers decreases when
increasing velocity of robot arm but much less than
for the rotation case.
3.3 Combined Motion
Combined motion is performed by simultaneously
rotating and translating the robot arm (between 4
and 92 degrees with 1370 mm shift). The performan-
VISAPP 2010 - International Conference on Computer Vision Theory and Applications
428
Table 1: Video sequences data set.
Motion Video sequences Number of frames Motion range per frame
Translation (scale
change)
Translation_v25 90 frames 15.22 mm
Translation_v50 49 frames 27.96 mm
Translation_v100 32 frames 42.81 mm
Rotation
Rotation180_v25 55 frames 3.39 degrees
Rotation180_v50 24 frames 8.18 degrees
Rotation180_v100 11 frames 20 degrees
Combined
Combined_v25 47 frames 8.51 mm and 4 degrees
Combined_v50 27 frames 14.81 mm and 7.2 degrees
Combined_v100 14 frames 28.57 mm and 15 degrees
a/
0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,9
7 10,5 14 17,5 21 24,5 28 31,5 35 38,5 42 45,5 49 52,5 56 59,5 63 66,5 70 73,5 77 80,5
% inliers
Angle rotation
SIFT
SURF
cross correlation with Harris detector
cross correlation with SURF detecto r
0
20
40
60
80
100
120
140
160
180
200
7 10,5 14 17,5 21 24,5 28 31,5 35 38,5 42 45,5 49 52,5 56 59,5 63 66,5 70 73,5 77 80,5
Number of inliers
Angle rotation
SIFT
SURF
cross correlation with Harris det ector
cross correlation with SURF det ector
b/
0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,9
2345678910152025
% inliers
Ima ge jump
SIFT
SURF
cros s correlatio n with Ha rris d etector
cros s correlatio n with SURF detector
0
20
40
60
80
100
120
140
160
2345678910152025
Nbre in liers
Image jump
SIFT
SURF
cross correlation with Harris detector
cross correlation with SURF detecto
r
c/
0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,9
15 22,5 30 37,5 45 52,5 60 67,5 75 82,5 90
% inliers
Angle rotation
SIFT
SURF
cros s correlatio n with Ha rris d etector
cros s correlatio n with SURF detector
0
20
40
60
80
100
120
140
160
15 22,5 30 37,5 45 52,5 60 67,5 75 82,5 90
Nbre inliers
Angle rotation
SIFT
SURF
cross correlation with Harris detector
cross correlation with SURF detecto
r
Figure 1: Evaluation of the robustness: % of inliers (left) and number of inliers (right).
a/ Rotation180_v25 (first line) b/ Scaling Translation _v100 (second line) c/ Combined _v50 (third line).
Table 2: Computation time for an Intel
dual core, 3 GHz, and 2GB memory (in milliseconds).
SIFT SURF Cross correlation
with Harris
Cross correlation
with SURF
Datasets Min Max Mean Min Max Mean Min Max Mean Min Max Mean
Trans_v25 1382 2065 1724 778 1411 1064 646 1817 918 718 1818 944
Rot180_v50 1433 2302 1706 610 1503 853 591 1229 888 564 1307 792
Comb_v100 1279 2354 1782 530 1732 886 604 1389 850 545 1327 814
PERFORMANCE EVALUATION OF POINT MATCHING METHODS IN VIDEO SEQUENCES WITH ABRUPT
MOTIONS
429
mance of all operators is worse than for simple
transformation. SIFT clearly outcomes other
descriptors in number of inliers. SURF is better than
cross correlation based descriptor only for low
velocity (v25) and even fails for large rotation
velocity. Rotation is more disturbing than scale
changes.
4 CONCLUSIONS
An experimental comparison of the famous
matching descriptors is proposed to identify the most
appropriate to estimate camera motion. To be as
close as possible to our application, we have used
several real video sequences with abrupt motions
(rotation, scale change, and combined). SIFT
performs the best results in terms of number of
inliers, but it can not be used for real time
applications. SURF and cross correlation are worse
than SIFT but can be improved in order to be
applied for real time applications. SURF is
interesting in the case of scale change. However, its
performance becomes similar to the cross correlation
in the case of large rotations. In our tests, the
matching process is achieved around one second for
the best in half VGA images. This matching time
remains too high for localizing a person in real time
with a body-mounted camera. To overcome this
issue, we can use the GPU programming for
additional speed up. We also plan to exploit the
extra capabilities of the latest smart phones to
improve performance. New smart phones contains
fast camera which can be combined with
accelerometer and a GPS receiver, and future
devices will contain magnetic compasses and
gyroscopes.
REFERENCES
Bay, H., Tuytelaars, T., Van Gool, L., 2006. SURF:
Speeded Up Robust Features, ECCV.
Carneiro, G., Jepson, A. D., 2002. Phase-Based Local
Features. ECCV, 282-296.
Harris, C., Stephens, M., 1988. A combined corner and
edge detector. In Alvey Vision Conf., 147–151.
Ke, Y., Sukthankar, R., 2004. PCA-SIFT: A More
Distinctive Representation for Local Image
Descriptors. CVPR'04, vol. 2, 506-513.
Lowe, D., 2004. Distinctive Image Features from Scale-
Invariant Keypoints. In Int. J. of Computer Vision,
vol.2, 91-110.
Mikolajczyk, K., Schmid, C., 2005. A performance
evaluation of local descriptors. In IEEE Trans. on
PAMI, 27(10), 1615–1630.
Zhang, Z., 1998. Determining the Epipolar Geometry and
its Uncertainty. A Review in International Journal of
Computer Vision, volume 27, n° 2, pages 161-198.
VISAPP 2010 - International Conference on Computer Vision Theory and Applications
430
