AUTOMATIC BEHAVIOUR-BASED ANALYSIS AND

CLASSIFICATION SYSTEM FOR MALWARE DETECTION

Jaime Devesa, Igor Santos, Xabier Cantero, Yoseba K. Penya and Pablo G. Bringas

Lab, Deusto Technological Foundation, Bilbao, Spain

Keywords:

Security, Malware detection, Machine learning, Data-mining.

Abstract:

Malware is any kind of program explicitly designed to harm, such as viruses, trojan horses or worms. Since

the amount of malware is growing exponentially, it already poses a serious security threat. Therefore, every

incoming code must be analysed in order to classify it as malware or benign software. These tests commonly

combine static and dynamic analysis techniques in order to extract the major amount of information from

distrustful ﬁles. Moreover, the increment of the number of attacks hinders manually testing the thousands of

suspicious archives that every day reach antivirus laboratories. Against this background, we address here an

automatised system for malware behaviour analysis based on emulation and simulation techniques. Hence,

creating a secure and reliable sandbox environment allows us to test the suspicious code retrieved without risk.

In this way, we can also generate evidences and classify the samples with several machine-learning algorithms.

We have developed the proposed solution, testing it with real malware. Finally, we have evaluated it in terms

of reliability and time performance, two of the main aspects for such a system to work.

1 INTRODUCTION

Malware is any kind of code explicitly designed with

harmful intentions, such as viruses, trojan horses or

worms. Malware represents a high-priority issue to

security researchers and poses a major threat to the

privacy of computer users and their information.

Still, the traditional approach to analyse malware

requires that a human analyst manually performs the

tests and extracts the information in order to classify

the sample (Moser et al., 2007). Unfortunately,due to

the tremendous growth of malicious code, antivirus

companies receive everyday thousands of suspicious

ﬁles that have to be analysed and classiﬁed as mal-

ware or benign software. Hence, a reliable and fast

automation of the analysis and classiﬁcation is a cru-

cial point to be able to cope with this threat.

With this scenario in mind, there are two mal-

ware analysis approaches: static analysis (Carrera

and Erd´elyi, 2004) which is performed without ac-

tually executing the ﬁle, only observing the binary

looking for suspicious patterns, and dynamic analy-

sis (Christodorescu et al., 2007; Rieck et al., 2008)

which implies running the sample in an isolated and

controlled environment monitoring its behaviour.

Against this background, we propose here an au-

tomatic system for malware behaviour analysis based

on emulation and simulation techniques. We advance

the state of the art in three main ways. First, we pro-

pose a sandbox to monitor program executions within

a contained environment. Second, we present and de-

scribe a method for feature extraction from behaviour

reports, and we train different machine-learning clas-

siﬁers in order to provide detection of unknown mal-

ware instances. Last but not least, we evaluate the

system in terms of reliability and time performance.

2 SYSTEM ARCHITECTURE

2.1 System Manager

The System Manager is the main process of the en-

tire system, and it is responsible for orchestrating the

other components.

When the System Manager starts, it launches n

Qemu virtual machines and creates a TCP server

in order to establish communications and synchro-

nise other processes. Moreover, the suspicious ﬁles

and the generated behaviour trace logs are exchanged

with the sandboxes via these communication chan-

nels. Once any of the sandboxes ﬁnishes the analysis

of a ﬁle, the behaviour trace is copied into a net share

395

Devesa J., Santos I., Cantero X., K. Penya Y. and G. Bringas P. (2010).

AUTOMATIC BEHAVIOUR-BASED ANALYSIS AND CLASSIFICATION SYSTEM FOR MALWARE DETECTION.

In Proceedings of the 12th International Conference on Enterprise Information Systems - Artiﬁcial Intelligence and Decision Support Systems, pages

395-399

DOI: 10.5220/0002895203950399

 SciTePress

folder. Then, the System Manager is informed and

negotiates the extraction of features with the regular

expression parser. Finally, the information gathered

is stored in a database with the aim of further classiﬁ-

cation.

2.2 Behaviour Monitoring

Behaviour monitoring is a dynamic analysis tech-

nique in which the suspicious ﬁle is executed inside

a contained and secure environment, called sandbox,

in order to get a complete and detailed trace of the

actions performed in the system.

Besides, as 87.9 % of users work with MS-based

platforms, most of the malware is aimed at these oper-

ating systems. Therefore, we have developed a sand-

box with the purpose of dynamically analyse Win-

dows Portable Executable (PE) ﬁles (Pietrek, 1994).

To this extent, the suspicious ﬁles are executed inside

an emulated environment, and relevant Windows API

calls are logged, showing the program’s behaviour.

Therefore, we propose a new approach of sandbox

using both emulation (Qemu) and simulation (Wine)

techniques, with the aim of achieving the greatest

transparency possible without interfering with the

system. In this way, we describe now the two main

platforms of our sandbox solution.

First, Wine is an open-source and complete re-

implementation (simulation) of the Win-32 Applica-

tion Programming Interface (API). Hence, it allows

Windows PE ﬁles to run as-if-natively under Unix-

based operating systems. Moreover, the main reason

of our choice, is that as being open-source we can

modify and improve the code to adjust it to our needs,

and therefore we can log any call to the Win-32 API

done by the malware.

Second, Qemu is an open-source pure software

virtual machine emulator that works by performing

equivalent operations in software for any given CPU

instruction. Unfortunately,there are several malicious

executables aware of being executed in a contained

environment exploiting different bugs within this vir-

tual machine. Plus, they can be ﬁxed easily (Ferrie,

2006).

To this extent, we have made several improve-

ments in Wine. First, we have modiﬁed Wine’s

source-code to write every call done by a process

(identiﬁed by its PID) to the Windows API (divided

in families, i.e. registry, memory or ﬁles) into a log,

specifying parameters’ state before and after the func-

tions body. Thereby, we can obtain a complete and

homogenous trace with all processes behaviour, with-

out any interference with the system.Second, we have

made several modiﬁcations to the basic Wine installa-

tion by adding various Windows XP system dlls and

creating additional registry keys and folder structures.

In this way, we have obtained the most transparent

and similar system to a Windows O.S. as possible in

order to be able to execute the largest possible variety

of programs.

2.3 Feature Extraction

Wheneverthe input data to machine learning and clas-

siﬁcation methods is too large and complex, it is nec-

essary to transform this data into a reduced represen-

tation set of carefully chosen features (feature vector),

a process known as feature extraction.

Furthermore, for each malware sample analysed

in the sandbox, we may obtain a complete in-raw

trace with its detailed behaviour. These reports are

not suitable for machine learning applications as these

usually work with vectorial data. Hence, with the

aim of automatically extracting relevant information

in vector format from the traces, we developed reg-

ular expression rules and a parser to identify them.

This approach is a powerful and fast tool for identify-

ing patterns of characters within a text (Friedl, 2006),

in our case, the detailed trace log.

To this end, we have deﬁned different speciﬁc ac-

tions taken by the program as regular expression rules,

with the help of an expert, in order to conform the

knowledge base. In this way, the creation of new rules

becomes very simple and intuitive and the system is

easily improvable.

Moreover, most of the actions deﬁned are char-

acteristic of malware but there are both benign and

malicious behaviour rule deﬁnitions.

Therefore, we have converted all the information

achieved in a vector, parsing the behaviour reports

with the deﬁned regular expressions.

To this extent, we deﬁned a program behaviour

as a vector made up of the aforementioned charac-

teristics. More speciﬁcally, we represented an ex-

ecutable as a vector ~v that is composed by binary

characteristics c, where c can be either 1 (true) or 0

(false), ~v = (c

,...,c

n−1

) and n is the num-

ber of monitored actions.

In this way, we have characterised the vector in-

formation as binary digits, called features, each one

representing the corresponding characteristic of the

behaviour. When parsing a report, if one of the de-

ﬁned actions is detected by a rule, the corresponding

feature is activated. The resulting vector for each pro-

gram’s trace is a ﬁnite sequence of bits, a proper infor-

mation for classiﬁers to effectively recognize patterns

and correlate similarities across a huge amount of in-

stances (Lee and Mody, 2006). Likewise, both in-raw

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

396

trace log and feature sequence for each analysed exe-

cutable are stored in a database for further treatment.

3 EXPERIMENTS AND RESULTS

3.1 Datasets

For the following experiments, we have used two

different datasets for testing the system: a malware

dataset and a benign software dataset. First, we have

downloaded a big malware collection from VxHeav-

ens website (VX-Heavens, 2009) conformed by dif-

ferent malicious code such as trojan horses, virus or

worms. Even though they were already named with

their family and variant names, we have scanned them

using AVG Anti-virus to guarantee the correctness of

the labelling.

Hereafter, we have analysed the whole malware

dataset in our system. Table 1 details the number of

ﬁles per family,the number of ﬁles that have been cor-

rectly analysed by our system and the correctly anal-

ysed percentage. We have considered a correct anal-

ysis when at least one of the features was activated,

this is, when at least one action covered in the rules

was performed. In summary, the average success rate

was 85,16%, which is a good result taking into ac-

count that our system relies in a single execution and

that some of the malware executables can detect that

they are being executed in an emulated environment

(Ferrie, 2006). Further, we have removed from the

dataset the 379 malware ﬁles that were not correctly

analysed, since no features were activated.

Table 1: Results for the malware analysed in the system.

Families Files Correctly analysed Rate (%)

Agobot 340 250 73.53

Bagle 127 124 97.64

MyDoom 47 43 91.49

Rbot 1161 950 81.83

Sdbot 879 808 91.92

TOTAL 2554 2175 85.16

In addition, we have collected diverse executable

ﬁles from a recent installation of a Windows XP sys-

tem without internet connection, in order to conform

the benign software dataset. In this way, we have

ensured that there were not infected ﬁles. For a fur-

ther assurance, we have also scanned them using AVG

Anti-virus. The whole benign software dataset has

been correctly labelled as legitimate executables.

Finally, we have created a 1500 balanced dataset

conformed by 750 random malware ﬁles chosen

within the 2175 correctly analysed malware samples,

and 750 non-malware ﬁles. It is proven that this bal-

ancing renders the evaluation of the machine learning

methods more reliable (Batista et al., 2004).

3.2 Time Performance

In order to evaluate the system’s time performance,

we have analysed a corpus of 500 ﬁles from the mal-

ware dataset using three differentconﬁgurations: with

one to four sandboxes being executed simultaneously

in the same machine. The default analysis timeout

for each ﬁle was initially estimated at 20 seconds, but

most of them ﬁnished their execution before reaching

this limit.

In this way, Table 2 shows the obtained results us-

ing the four conﬁgurations. Note that the improve-

ment percentage has been calculated based on the sin-

gle sandbox conﬁguration.

As we increment the amount of computers de-

voted to the analysis, the performance grows as well,

in a geometrical progression.

Table 2: Analysis of 500 ﬁles time performance results.

VM Total time Time per ﬁle Improvement

(sec) (sec/ﬁle) percentage

1 9555 19.11 -

2 4640 9.28 51.44

3 3390 6.78 64.53

4 2815 5.63 70.54

In conclusion, we had an excellent time perfor-

mance running4 sandbox instances for each computer

dedicated to execute these components.

3.3 Malware Detection Experiments

We have conducted an experiment focused on clas-

sifying generic malware without taking into account

which family of malware belonged to. Therefore,

we can provide detection of unknown malicious in-

stances.

In particular, we have trained and tested N¨aive

Bayes, Decision Trees and Support Vector Machine

classiﬁers in order to evaluate them. Choosing these

machine-learning classiﬁers was not a trivial decision

since they have already been widely applied to mal-

ware detection (Ye et al., 2008). To this extent, we

have performed the following steps:

• Cross Validation. Despite the small dataset, we

had to use as much of the available information in

order to obtain a proper representation of the data.

To this end, K-fold cross validation is usually used

in machine-learning experiments (Bishop, 2006).

AUTOMATIC BEHAVIOUR-BASED ANALYSIS AND CLASSIFICATION SYSTEM FOR MALWARE DETECTION

397

Thereby, for each classiﬁer we tested, we per-

formed a k-fold cross validation (Kohavi, 1995)

with k = 10. In this way, our dataset was 10 times

split into 10 different sets of learning (66% of the

total dataset) and testing (34% of the total data).

• Learning and Testing the Model. We made a

learning phase where each classiﬁer acquires the

required knowledge using the learning dataset.

Hereafter, the algorithm classiﬁed the rest of the

dataset. We used different conﬁgurations for each

machine-learning classiﬁer:

1. N

aive Bayes: We employed EM parametrical

learning for training the Bayesian network.

2. Random Forest: We run the training algorithm

with a number of random trees of 100.

3. J48: We trained this classiﬁer with a conﬁdence

factor of 0.25 and a minimal number of objects

of 2.

4. SMO: We used the Weka implementation of

SVM trained with a polynomial kernel and a

complexity factor of 1.

• Evaluation of the Model. In order to evaluate

each classiﬁer’s capability we measured the True

Positive Ratio (TPR) that is the number of mal-

ware instances correctly detected, divided by the

total amount of malware ﬁles.

Moreover, we measured the False Positive Ratio

(FPR), that is the number of benign executables

that were misclassiﬁed as malware divided by the

total number of benign ﬁles Note that keeping this

measure low is highly important in commercial

antivirus for user satisfaction.

Furthermore, we measured Total Accuracy, that is

the total number of the classiﬁer’s hits divided by

the number of instances in the whole dataset.

Table 3 shows the obtained results. In this way,

every classiﬁer that we tested, achieved overall good

results in accuracy, malware detection (TPR) and low

false alarms (FPR).

Speciﬁcally, both of the decision tree algorithms

that we tested outperformed the rest of the classiﬁers

in terms of TPR and total accuracy. These two algo-

rithms, J48 and random forest, achieved a very high

accuracy (more than 96%) and high detection ratio

(more than 0.94).

Still, if we focus on false positive ratio, random

forest presented the best results. Therefore, it seems

to be the best option for detecting generic malware.

Furthermore, the good results obtained of the pro-

posed system renders it a very good approach for de-

tecting unknown malware. In this way, we think that

this system can help to identify faster the malware

Table 3: Results per classiﬁer.

Classiﬁers T. Accuracy (%) TPR FPR

Naive Bayes 91.6 0.852 0.02

Random Forest 96.2 0.937 0.013

J48 96 0.943 0.023

SMO 95.4 0.931 0.023

Average 94.8 0.915 0.019

variants for further analysis and creation of their sig-

natures.

4 RELATED WORK

Due to the great growth of malware in the last few

years, an extensive work to cope with this malicious

code plague has been published.

To deal with obfuscation techniques, various dy-

namic analysis solutions based in sandbox environ-

ments have been developed, using different tech-

niques for monitoring the malware’s behaviour: TT-

Analyze (Bayer et al., 2006) like our sandbox, uses

the Qemu PC emulator, but it runs a Window oper-

ating system combined with the API hooking tech-

nique. On the other hand, CWSandbox (Willems

et al., 2007) relies in DLL injection to trace and

monitor all relevant system calls, and to generate a

machine-readable report.

Further, two different approaches for malicious

executables classiﬁcation have been proposed (Rieck

et al., 2008): discrimination between families of mal-

ware, and discrimination between speciﬁc malware

instances and benign software.

First, recent work has focused in discrimination

between different malware families using clustering

of behaviour reports (Lee and Mody, 2006), trans-

forming reports into sequences for later grouping

them into clusters, which ﬁnally represent different

families of malicious programs. Nevertheless there

are some limitations taking into account that cluster-

ing methods have unsupervised nature, with its in-

herent problems. Another recent approach (Rieck

et al., 2008) monitors the suspicious ﬁle execution and

builds a vector space model with the frequencies of

the contained strings as features to classify malicious

behaviour into malware families with Support Vector

Machines (SVM). Second, in (Christodorescu et al.,

2007) it is presented an approach to discriminate be-

tween malware and benign software based on mining

differences between malicious programs and benign

executables behaviour reports.

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

398

5 CONCLUSIONS AND FUTURE

WORK

In this paper we have presented a distributed and auto-

matic system for malware detection based on the dy-

namic analysis of suspicious ﬁles and the later clas-

siﬁcation into malware and benign software groups.

For the behaviour analysis we have developed a new

sandbox based in Qemu and Wine.

Focusing on the obtained results, we consider that

the features extracted from the behaviour logs are

suitable for training classiﬁers in order to detect mal-

ware. Hence, we have achieved a high detection rate

(94.8 %) and a low percentage of false positive ratio

(0.019). On the other hand, we have shown that the

system presents a great time performance. Still, our

system also presents some limitations, as follows.

First, in order to take advantage over antivirus re-

searchers, malware writers have included diverse eva-

sion techniques (Ferrie, 2006) based on bugs on the

virtual machines implementation to ﬁght back. Nev-

ertheless, with the aim of reducing the impact of these

countermeasures, we can improve the Qemu’s source

code in order to solve the bugs and not to be vulnera-

ble to the above-mentioned techniques.

Second, it is possible that some malicious actions

are only triggered under speciﬁc circumstances de-

pending on the environment, so the rely on a single

program execution will not manifest all its behaviour.

This is solved with a technique called multiple exe-

cution path (Moser et al., 2007), making the system

able to obtain different behaviours displayed by the

suspicious executable.

Finally, as Wine is not a completed project, it

does not perfectly simulate a Windows operating sys-

tem. Moreover, it grows fast, improving its own re-

implementation of the Win-32 API in each published

version. In conclusion, we might install the last stable

version available in order to maintain the system up-

to-date and to have a greater capacity of emulation.

As future lines of work, we plan to expand the fea-

tures identiﬁed by the system until now. This is, deﬁn-

ing more regularexpression rules to perceiveboth ma-

licious and legitimate behaviour since, in this way, the

classiﬁcation will give better results. Moreover, com-

bining our approach with static analysis techniques

may improve the obtained results.

REFERENCES

Batista, G., Prati, R., and Monard, M. (2004). A study of

the behavior of several methods for balancing machine

learning training data. ACM SIGKDD Explorations

Newsletter, 6(1):20–29.

Bayer, U., Kruegel, C., and Kirda, E. (2006). TTAnalyze:

A tool for analyzing malware. In Proceedings of the

Annual Conference of EICAR.

Bishop, C. (2006). Pattern recognition and machine learn-

ing. Springer New York.

Carrera, E. and Erd´elyi, G. (2004). Digital genome

mapping–advanced binary malware analysis. In Pro-

ceedings of the 14

Virus Bulletin Conference, pages

187–197.

Christodorescu, M., Jha, S., and Kruegel, C. (2007). Mining

speciﬁcations of malicious behavior. In Proceedings

of the the 6

joint meeting of the ESEC and the ACM

SIGSOFT symposium on The foundations of software

engineering, pages 5–14.

Ferrie, P. (2006). Attacks on virtual machine emulators. In

Proc. of AVAR Conference, pages 128–143.

Friedl, J. (2006). Mastering regular expressions. O’Reilly

Media, Inc.

Kohavi, R. (1995). A study of cross-validation and boot-

strap for accuracy estimation and model selection.

In Proceedings of the 14

International Joint Con-

ference on Artiﬁcial Intelligence, volume 14, pages

1137–1145.

Lee, T. and Mody, J. (2006). Behavioral classiﬁcation. In

Proceedings of the 15

European Institute for Com-

puter Antivirus Research (EICAR) Conference.

Moser, A., Kruegel, C., and Kirda, E. (2007). Exploring

multiple execution paths for malware analysis. In Pro-

ceedings of the 28

IEEE Symposium on Security and

Privacy, pages 231–245.

Pietrek, M. (1994). Peering Inside the PE: A Tour of the

Win32 (R) Portable Executable File Format. Microsoft

Systems Journal, 3.

Rieck, K., Holz, T., Willems, C., Dussel, P., and Laskov,

P. (2008). Learning and Classiﬁcation of Mal-

ware Behavior. Lecture Notes in Computer Science,

5137:108–125.

VX-Heavens (2009). VX heavens. Online:

http://vx.netlux.org/.

Willems, C., Holz, T., and Freiling, F. (2007). Toward au-

tomated dynamic malware analysis using cwsandbox.

IEEE Security & Privacy, 5(2):32–39.

Ye, Y., Wang, D., Li, T., Ye, D., and Jiang, Q. (2008).

An intelligent PE-malware detection system based on

association mining. Journal in Computer Virology,

4(4):323–334.

AUTOMATIC BEHAVIOUR-BASED ANALYSIS AND CLASSIFICATION SYSTEM FOR MALWARE DETECTION

399
