QUALITY MEASUREMENT MODEL FOR

REQUIREMENTS ENGINEERING FLOSS TOOLS

María Pérez, Edumilis Méndez, Kenyer Domínguez and Luis E. Mendoza

Processes and Systems Department, LISI, Simón Bolívar University, PO Box 89000, Caracas 1080-A, Venezuela

Keywords: Software Quality, Requirements Engineering, FLOSS, Quality Model.

Abstract: The goal of delivering a suitable or quality software product increases the properly definition of system

requirements. Requirements Engineering (RE) is the process of discovering, refining, modeling and

specifying software requirements. In addition to the trend of using Free/Libre Open Source Software

(FLOSS) tools, we should consider their strengths and weaknesses towards in the light of a suitable RE.

This article is aimed at proposing a quality measurement model for RE FLOSS tools and supporting their

selection process. Characteristics selected for its evaluation include Functionality, Maintainability and

Usability. This model was applied to four FLOSS tool and assessed for completeness, accuracy and

relevance to establish which FLOSS tools support RE, either totally or partially, thus making it useful for

Small and Medium-sized Enterprises.

1 INTRODUCTION

Selecting FLOSS tools that support for

Requirements Engineering (RE) is challenging, as

tools must support all RE stages and validate that the

features characterizing this type of software are fully

met. Such premise has led us to evaluate the tools

quality by means of a quality model that allows

determining the fulfillment of requirements.

For this research, we used and instantiated the

systemic quality model (MOSCA) (Mendoza et. al,

2005). This model is based on ISO 9126 (ISO/IEC

9126, 2001), the Dromey Quality Model (Dromey,

1995), and the Goal-Question-Metrics (GQM)

paradigm (Basili et. al, 2001). The instantiation

proposed herein includes software attributes, such as

Functionality, Usability and Maintainability, and

establishes 129 new metrics for a total of 210

metrics, to evaluate FLOSS tools supporting RE.

Four tools were selected: Open Source Requirement

Management Tool (OSRMT), StarUML, Use Case

Maker (UCM) and OpenOME; the four being open

tools with Free Software licenses.

This article consists of 7 sections. First and

second sections present the introduction and the

methodology applied in this research, respectively.

Third section describes MOSCA. Fourth section

introduces the quality model proposed for FLOSS

tools supporting RE. Fifth section describes the

model application and results obtained. Lastly, sixth

section presents our conclusions and

recommendations.

2 METHODOLOGY

For this work, we used the Systemic Methodological

Framework for Information Systems research (Pérez

et. al, 2004), based on DESMET (Kitchenham,

1996) methodology and the research-action method

(Baskerville, 1999). The action-research method is

developed in five phases: diagnosing, action

planning, taking action, evaluating, and specifying

learning (Baskerville, 1999), whereas DESMET

methodology is used to supplement the model

evaluation. This methodology suggests 9 evaluation

methods, among which the case study feature

analysis (Kitchenham, 1996) was applied herein. In

addition, the GQM approach was included, in order

to evaluate software in a quality improvement

context (Basili et. al, 2001).

3 SYSTEMIC QUALITY MODEL

The purpose of the systemic quality model is to

measure systemic quality at a software developing

organization (Rincón et. al, 2005) and assess

Information Systems quality by integrating the

249

Pérez M., Méndez E., Dominguez K. and Mendoza L. (2010).

QUALITY MEASUREMENT MODEL FOR REQUIREMENTS ENGINEERING FLOSS TOOLS .

In Proceedings of the 12th International Conference on Enterprise Information Systems - Information Systems Analysis and Speciﬁcation, pages

249-254

DOI: 10.5220/0002905402490254

 SciTePress

Table 1: Functionality characteristics.

Characteristic Definition and Rationale

Suitability

(FUN 1)

The capability of a software product to provide an adequate group of functions according to

user specific tasks and objectives. In this research, tool functions should be adapted to satisfy

RE needs. The tool must cover all functional needs.

Interoperability

(FUN 3)

The capability of a software product to interact with one or more specified systems. The RE

tool can use or provide functionalities from/to other systems. Also, it must relate to

subsequent stages in the Software Engineering process.

Correctness

(FUN 5)

It is divided into three categories related to computing, completeness and consistency

capabilities. The violation of any of such properties may generate software without the

functionality level expected. Tools supporting RE must generate complete and consistent

requirements.

Table 2: Sub-characteristics proposed for Functionality of FLOSS tools supporting RE.

Sub-characteristic Description

Diagrams

(FUN 1.1)

The capability of the tool to represent RE related models through diagrams associated with a

modeling language, such as UML.

Documentation

(FUN 1.2)

The capability of the tool to provide mechanisms necessary to generate related documentation.

Classification

(FUN 1.3)

The capability of the tool to classify requirements associated with a software project.

Phase support

(FUN 1.4)

The capability of the tool to provide support to the different RE phases.

Consistent

(FUN 5.1)

The capability of the tool to verify that dependency relations among requirements, diagrams

generated from others, change traceability, among other characteristics, be consistent.

quality models of the product and development

process (Alfonso et al, 2008). MOSCA consists of

four levels, namely:

• Level 0. Dimensions. Includes the internal

and contextual aspects of the process, and the

internal ad contextual aspects of the product.

• Level 1: Categories. Consists of eleven (11)

categories, six (6) belonging to the product

and five (5) to the development process.

• Level 2: Characteristics. Each category has

a set of characteristics that define key areas to

achieve, assure and control product and

process quality.

• Level 3: Metrics. For each characteristic,

there is a series of metrics to measure

systemic quality; total metrics are 715.

MOSCA evaluates the software product in

accordance with international standards, given that

the aforementioned categories agree with the

characteristics of ISO 9126 (ISO/IEC 9126, 2001),

established to assure the quality of the software

product to be evaluated.

Mendoza et. al (2005) introduced an algorithm to

evaluate software quality using MOSCA, which will

be instantiated in the context of SQM for the

purpose of this research.

4 QUALITY MODEL PROPOSAL

The Systemic quality model (MOSCA) established

the selection of three out of the 6 Product

Perspective categories, one being Functionality. The

other two categories selected are Usability, because

the tool enables requirements management in a

simple and easy manner and provides an interface

that is appealing to users; and Maintainability,

because this a FLOSS tool and should allow

obtaining documentation to get access to

information required for making changes and

maintenance. Based on prior works of Pessagno et.

al (2008) and Alfonso et. al (2008), a sub-group of

characteristics was selected for each category; also,

a sub-set of metrics was selected for this sub-group,

and in certain cases, it was necessary to add new

metrics. Find below an explanation to each category

and criteria used for selecting these characteristics.

4.1 Functionality

Functionality is the capability of the software

product to provide functions which meet stated and

implied needs when the software is used under

specified conditions (ISO/IEC 9126, 2001). It is

essential that a RE tool meet the functional

requirements expected from a software product. The

characteristics selected for this category are

described in Table 1.

To fulfill the requisites necessary to represent

RE phases, new sub-characteristics were added, and

are presented in Table 2.

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

250

Table 3: Usability characteristics.

Characteristic Definition and Rationale

Understandability

(USA 1)

The capability of a software product to enable the user software understanding and use. The RE

supporting tool must provide the required use easiness to the team in charge of eliciting and

managing requirements.

Learnability

(USA 2)

The capability of a software product to enable the user learning and performance of basic

operations. The RE tool must provide the user with use forms and enable it to learn how to operate

them.

Graphic interface

(USA 3)

The capability of a software product to be appealing to users. The RE tool interface must be

comfortable enough to manage requirements in a user-friendly environment.

Operability

(USA 4)

The capability of a software product to enable the user operation and control thereof. The user

should count on all facilities to operate and control the RE tool.

Self-descriptive

(USA 11)

A structural form is deemed self descriptive when its purpose is evidenced in the name of the

modules and when labels have meanings that refer to the application context. If the RE tool is self-

descriptive, the tool-user interaction will be easily achieved.

Table 4: Sub-characteristics proposed for Usability of FLOSS tools supporting RE.

Sub-characteristics Description

Ergonomics

(USA 1.1)

The capability of a tool interface to enable tool-user interaction.

Error control

(USA 4.1)

The capability of a tool to enable user recovery from system errors.

Documentation

(USA 4.2)

The tool’s documented functionalities.

Table 5: Maintainability characteristics.

Characteristic Definition and Rationale

Analyzability

(MAB 1)

The capability of a software product to be diagnosed for software error or

failure. The RE tool should be easy to diagnosed, as this will determine the

selection of parts susceptible of upgrades.

Changeability

(MAB 2)

The capability of a software product to enable the implementation or

improvement of new/existing functionalities. Changeability is an essential

characteristic of the RE tool subject to modifications; it allows adding

modifications suggested by developers.

Stability

(MAB 3)

The capability of a software product to avoid unexpected effects upon

functionality modifications. The RE tool subject to modifications must keep its

stability upon change implementation.

Coupling

(MAB 5)

The lowest possible coupling level is pursued as it enables software changes.

The RE tool is required to count on simple module interconnection to make

code modification much easier.

Cohesive

(MAB 6)

It is desirable that all elements be closely linked to each other and contributes

to meet the objective. The RE tool should have all its elements duly linked to

achieve simple and desirable operation.

Software maturity attributes

(MAB 8)

The group of features associated to age and use of the tool. The RE tool must

ensure that all modifications made in the future will not affect its quality.

4.2 Usability

Usability is the capability of the software product to

be understood, learned, used and attractive to the

user, when used under specified conditions

(ISO/IEC 9126, 2001), The RE tool should enable

requirements management in a simple and easy

manner and provide an interface that is appealing to

users. Table 3 shows the characteristics selected for

this category.

Table 4 shows the sub-characteristics added to

the original model and their corresponding

description.

4.3 Maintainability

Maintainability is the capability of the software

product to be modified. Modifications may include

corrections, improvements or adaptation of the

software to changes in environment, and in

requirements and functional specifications (ISO/IEC

9126, 2001), Because the tool subject to

modification is a FLOSS tool, it should enable the

obtaining of documentation to get access to the

information required to make changes and

maintenance. The characteristics selected for this

QUALITY MEASUREMENT MODEL FOR REQUIREMENTS ENGINEERING FLOSS TOOLS

251

Table 6: Sub-characteristics proposed for Maintainability of FLOSS tools supporting RE.

Sub-characteristic Description

Code readability

(MAB 1.1)

The capability of the source code to be read by any developer, even if not belonging to the project team.

Modification

(MAB 1.2)

The capability of the source code to be modified.

License

(MAB 2.1)

It refers to the tool license properties. A FLOSS tool license should count on 4 user freedoms, freedom to

have access to the source code, freedom to modify the code, freedom to copy the code, and freedom to

distribute the code.

Services

(MAB 3.1)

The support, consulting, and training services provided by the tool development community.

Adoption

(MAB 8.1)

The level of tool acceptance at the market among individuals and companies.

Table 7: The results obtained from the evaluation.

Category Feature Sub-feature StarUML OSRMT UCM OpenOME

Functionality

Suitability Suitability 60% 100% 60% 60%

Diagrams 40% 0% 0% 80%

Documentation 50% 0% 18.75% 11.11%

Classification 40.90% 69.69% 62.50% 47.82%

Phase support 43.75% 30.76% 28.57% 26.66%

Interoperability Interoperability 16.66%% 0% 37.50% 20%

Correctness Consistent 37.50% 71.42% 57.14% 14.28%

Functionality percentage 0% 14.29% 0% 14.29%

Usability

Understandability Understandability 100% 83.33% 100% 100%

Ergonomics 100% 100% 100% 100%

Learnability Learnability 50% 0% 100% 0%

Graphic interface Graphic interface 100% 100% 100% 100%

Operability Operability 80% 90% 80% 100%

Error control 100% 100% 0% 100%

Documentation 100% 100% 20% 100%

Self-descriptive Self-descriptive 100% 100% 100% 100%

Usability percentage 87.50% 87.50% 75.00% 87.50%

Maintainability

Analyzability Analyzability 100% 100% 100% 100%

Code readability 100% 100% 100% 100%

Modification 100% 100% 100% 100%

Changeability Changeability 100% 100% 100% 100%

License 100% 100% 83.33% 100%

Stability Stability 100% 100% 100% 100%

Services 50% 50% 50% 100%

Coupling Coupling 100% 100% 100% 100%

Cohesive Cohesive 100% 100% 100% 100%

Software maturity

attributes

Software maturity attributes 66.66% 50% 83.33% 66.66%

Adoption 100% 80% 60% 80%

Maintainability percentage 81.82% 81.82% 81.82% 90.91%

Quality level

Null Null Null Null

category are described in Table 5.Table 6 shows all

sub-characteristics added to this category. MOSCA

instantiation for FLOSS tools supporting

Requirements Engineering presents 210 metrics, of

which 129 are new metrics (127 for Functionality, 1

for Usability, and 1 for Maintainability).

5 INSTATIATION APPLICATION

AND RESULTS ANALYSIS

MOSCA instantiation was applied to four tools:

Open Source Requirement Management Tool

(OSRMT), StarUML, Use Case Maker (UCM) and

OpenOME, the four being open tools with Free

Software licenses. From these tools, StarUML is

considered and Analysis and Design tool, but may

also show other characteristics such as RE supply.

Also, StarUML allows for automatic generation of

the use case specification document.

OpenOME incorporates an improved version of

OME (a modeling and analysis tool oriented towards

goals and agents that provides connection between

requirements/specifications development and

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

252

architectonic design, and i*modeling support, which

is a framework suggesting an approach oriented

towards RE goals and agents), with other RE

supporting tools oriented to goals, agents, and

aspects. The results obtained from the evaluation are

detailed in the Table 7.

In sum, approximately 64 hours were incurred for

instantiation application. The process was performed

as follows: the tools’ most recent versions were

downloaded from the corresponding development

community website and installed. Then, applications

were run one by one and verified for metrics

compliance. For evaluation of Maintainability

metrics, we reviewed current information and

documentation at the official tool website.

Information required for software qualification could

not be found for some metrics; therefore in these

cases, a minimum punctuation was awarded (1).

For the Stability feature in the Maintainability

category, where no security patches were founds, the

formula was deemed a ratio (patches solved/patches

found) expressed in percentage values; 100% was

awarded.

The results obtained for the Functionality category:

StarUML obtained 0%, OSRMT 14.29%, UCM 0%,

and OpenOME 14.29%. According to the MOSCA

algorithm, none met the level of acceptance

required, which is 75%. Regarding results obtained

for Usability, all four tools exceeded the 75%

required. OpenOME, StarUML and OSRMT

obtained the highest punctuation at 87.50%,

followed by UCM with 75%. Lastly, for

Maintainability, all 4 tools exceeded 75%,

OpenOME with 90.91%, followed by StarUML,

OSRMT and UCM with 81.82%.

Given that none of the 4 tools met the minimum

satisfaction percentage required for Functionality,

they qualified as null quality tools. Nevertheless,

these four tools are above 75% for Usability and

Maintainability. According to the MOSCA

algorithm, when Functionality results do not reach

75%, the evaluation is suspended, but in this case, as

we are evaluating FLOSS tools, there is the

possibility of adding new functionalities to the tools,

as opposed to proprietary software tools, which do

not allow for modifications. Therefore, we are free

to choose a tool and subject it to any improvement

relating to the characteristics deemed appropriate for

our research. The selected tool was UCM, a tool

developed in C# language. It should be noted that

results presentation goes beyond the scope of this

article and will be addressed in future works.

6 CONCLUSIONS

This work proposes an instantiation of the MOSCA

model to measure the quality of FLOSS-based

software engineering tools supporting RE, which

should be easy to use and modify. This model was

applied to Open Source Requirement Management

Tool (OSRMT), StarUML, Use Case Maker (UCM)

and OpenOME, to prove the model usability and

select the most suitable tool to be modified in the

near future. In this case, the tool selected was Use

Case Maker. MOSCA may be adapted to any RE

tools with specific characteristics and may be used

by Small and Medium-sized Enterprises (SMEs) for

tool evaluation purposes.

ACKNOWLEDGEMENTS

This research has been financed by FONACIT

Venezuela, Project G-2005000165. Special thanks

to A. Sevilla.

REFERENCES

Alfonso, O., Domínguez, K, Rivas, L., Perez, M.,

Mendoza, L., & Ortega, M. (2008). Quality

Measurement Model for Analysis and Design Tools

based on FLOSS. 19th Australian Software

Engineering Conference (ASWEC 2008). Libro:

"Proceedings of the 19th Australian Software

Engineering Conference (ASWEC 2008)". Vol. 1. pp.

258 - 267

Perth, Australia. Basili, V., Caldiera, G. y Rombach, H.,

“The Goal Question Metric Approach”, en: Marciniak,

J. J. (ed.), Encyclopedia of Software Engineering,

Wiley, pp. 528–532, 2001.

Baskerville, R., “Investigating Information Systems with

Action Research”, Communications of the Association

for Information Systems, vol. 2, nº 19, pp. 1-32, 1999.

Dromey, G., “A Model for Software Product Quality”,

IEEE Transactions on Software Engineering, vol. 21,

nº 2, pp. 146-162, 1995.

ISO/IEC 9126-1, Software Engineering. Product Quality.

Part 1: Quality Model, ISO, 2001.

Kitchenham, B., “Evaluating Software Engineering

Methods and Tools. Part 1: The Evaluation Context

and Evaluation Methods”, ACM Software Engineering

Notes, vol. 21, nº 1, pp. 11- 14, 1996.

Mendoza, L., Pérez, M. y Grimán, A., “Prototipo de

modelo sistémico de calidad (MOSCA) del software”,

Computación y Sistemas, vol. 8, nº 3, pp. 196-217,

2005.

Pessagno, L., Domínguez, K., Rivas, L., Pérez, M.,

Mendoza, L., & Mendez, E. (2008). Modelo de

calidad para herramientas FLOSS que dan apoyo al

modelado de procesos del negocio. X Jornadas sobre

QUALITY MEASUREMENT MODEL FOR REQUIREMENTS ENGINEERING FLOSS TOOLS

253

Innovación y Calidad del Software (JICS), September.

Madrid.

Pérez, M., Grimán, A., Mendoza, L. y Rojas, T., “A

Systemic Methodological Framework for IS

Research”, Proceedings of the Tenth Americas

Conference on Information Systems AMCIS. New

York (USA), pp. 4.374-4.383, 2004.

Rincón, G., Mendoza, L. & Pérez, M. 2004. Guía para la

Adaptación de un Modelo Genérico de Calidad de

Software. IV Jornadas Iberoamericanas en Ingeniería

de Software e Ingeniería del Conocimiento - JIISIC,

Madrid, España.

ICEIS 2010 - 12th International Conference on Enterprise Information Systems

254
