FROGLINGO

A Monolithic Alternative to DBMS, Programming Language, Web Server

and File System

Kevin H. Xu, Jingsong Zhang and Shelby Gao

Bigravity Business Software LLC, U.S.A.

Keywords: Total recursive functions, Computability, Productivity, Data model, Programming language, DBMS, Data

exchange, Access control, Web server, File system.

Abstract: Application software started with a monolithic architecture in the 1960s, i.e., a single executable file for the

entire application. For better productivity in software development, software application in a typical

corporate environment today consists of multiple components including off-the-shelf products. Froglingo is

a unified solution for database management and programming language. It is an alternative to the

combination of software technologies including DBMS, programming language, web server, and file

system. The Enterprise-Participant (EP) data model, Froglingo without variables, is a computer language

equivalent to a class of total recursive functions. It brings the monolith back to application software. In this

paper, we show that Froglingo is a monolith and demonstrate that this monolith with the EP data model

improves the productivity in both software development and software maintenance.

1 INTRODUCTION

A typical database application system in a corporate

environment today needs DBMS (such as Oracle and

MySQL), programming language (such as Java and

C#), and middleware components including web

servers (such as Websphere and WebLogic), data

exchange tools (such as Hibernate and LINQ), and

centralized authentication tools for multiple web

applications (such as IBM TAM and RSA

ClearTrust). With the combination of the current

technologies, we have made limited progress in

effectively and efficiently developing and

maintaining software applications (Loucopoulos et

al., 2006).

Froglingo (Xu and Zhang, 2010) is a unified

solution for software development and maintenance,

and an alternative to DBMS, programming

language, file system, and web server. It is a

“database management system (DBMS)” to store

and to query business data; a "programming

language" to support business logic; a "file system"

to store and to share files; and a "web server" to host

multiple applications and to interact with users

across network. It does more than combine existing

technologies. It is a single language that uniformly

expresses both data and application logic, and it is a

system supporting integrated applications without

using application-based data exchange component

and data access control mechanism.

The EP (Enterprise-Participant) data model is at

the centre of Froglingo. It is semantically equivalent

to a class of total recursive functions (Xu et al.,

2010). The equivalence for a data model dictates that

the EP data model is nothing but high-order

functions and the ordering relations among the

functions (Xu et al., 2010).

Representing software applications in high-order

functions and their ordering relations is not only

applied to business data, i.e., finite data, by using the

EP data model, but also applied to business logic,

i.e., infinite data, by using Froglingo, the extended

system having variables beyond the EP data model

(Xu, 1999).

It is not surprising that Froglingo is a

programming language, i.e., a Turing-machine

equivalent system reaching the full capacity of what

a computer can do (Xu, 1999). What makes

Froglingo unique is the high-order functions as the

sole objects in representing software applications.

The uniformness of the managed objects leads to

Froglingo’s opportunity of being a monolith in

software architecture. Being claimed as a monolith,

247

H. Xu K., Zhang J. and Gao S. (2010).

FROGLINGO - A Monolithic Alternative to DBMS, Programming Language, Web Server and File System.

In Proceedings of the Fifth International Conference on Evaluation of Novel Approaches to Software Engineering, pages 247-252

DOI: 10.5220/0002923202470252

 SciTePress

Froglingo is an off-the-shelf product, i.e., a single

executable file, and is self-sufficient in software

development and maintenance. Being worth as an

alternative, Froglingo is expected to be more

productive than the traditional technologies.

In this paper, we analyze the individual

components of the traditional technologies, identify

how the equivalent functions of the components are

supported in Frolingo, and conclude with the

feasibility of the monolithic architecture of

Froglingo.

To facilitate the discussion in this paper, we

briefly introduce Froglingo in Section 2. From

Section 3 to Section 7, we discuss the components of

the traditional technologies and identify where the

equivalent functions of the components go in

Froglingo. Through the discussion, we demonstrate

that Froglingo is monolithic in system architecture

and suggest that it is more productive in software

development and maintenance. In the conclusion, we

reiterate an objective view on the easiness of

computer language to strengthen the suggestion that

the monolith Froglingo is more productive.

2 FROGLINGO

In traditional data models, an entity is either

dependent on one and only one other entity, or

independent from the rest of the world. The

functional dependency in relational data model and

the child-parent relationships in hierarchical data

model are the typical examples. This restriction,

however, doesn’t reflect the complexities of the real

world that are manageable using a computer. The EP

(Enterprise-Participant) data model suggests that if

an entity is dependent on others, it precisely depends

on two other entities. Drawing the terminologies

from the structure of an organization or a party, one

depended entity was called enterprise (such as

organization and party), the other called participant

(such as employee and party participant), and the

dependent entity called participation. An enterprise

consists of multiple participations. Determined by its

enterprise and its participant, a participation yields a

value, and this value in turn is another enterprise.

The EP data model is the core of Froglingo. It

establishes the entire semantic space for practical

software applications. Variable is a way of using

finite expressions for the (infinite) semantics

established in the EP data model. It is intended to be

a supplement semantically to the EP data model

although it unfortunately brings non-termination

processes into Froglingo (Xu et al., 2010).

2.1 EP Data Model

The core concepts are terms, assignment, database,

normal form, and reduction.

A term is a constant, an identifier, or a pair of

parenthesized terms, i.e.,

• If T is a constant, then T is a term,

• If T is an identifier, then T is a term,

• If T1 and T2 are terms, then (T1 T2) is a

term.

Integers, real numbers, timestamps, and strings are

constants. In addition, files, as long as not

embedding Froglingo expressions, are also

constants. For example,

3.14, ‘5/2/2009’,

“any strings”, and a file content at operating

system level are all constants. Identifiers are the

tokens to represent high-order functions. The

examples are an_id, salary, Mike, and

www.aclient.com.

A term is used to express data, to embed

relationships between data, and to serve as a name in

data communications. The examples are 3.14,

Mike, (Mike Salary), ((country state)

county), and (tax (Mike salary)).

When a term consists of an ordered pair of two

other terms, it is called a combinatory term,

abbreviated as comb-term. The first term of a comb-

term is called the left-term; and the second term the

right-term. For example, the comb-term (Mike

salary) has Mike as the left-term and salary

as the right-term.

If the right-term of a comb-term is not another

comb-term, the parentheses surrounding the term

don't have to be written. For example, ((country

state) county) is equivalent to (country

state county); and ((a b) (c d)) is

equivalent to (a b (c d)).

A term can be assigned with a value. An

assignment is a state that a term takes another term

as its value. For example, (Mike salary) =

2000, 2 = 3, and a = b. Given an assignment,

the term at the left side of the symbol ‘=’ is the

assignee; and the term at the right side the assigner

(also called value).

A database is a finite set of terms and

assignments. To make a database meaningful, the

terms and the assignments in a database must satisfy

the following conditions:

• A constant cannot be an assignee, and cannot be

a left-term,

• The right-term of a comb-term appeared in an

assignee must not have an assigner; and

ENASE 2010 - International Conference on Evaluation of Novel Approaches to Software Engineering

248

• Assignments cannot form a circle, i.e., if there is

a sequence of assignments: M

= M

, M

, …, M

n-1

= M

, M

must not be identical

to M

As an example, we may have the following database

for a school administration:

SSD John SSN = 123456789;

SSD John birth = ‘6/1/1990’;

SSD John photo.jpg = …;

/* a file is a binary stream*/;

College admin (SSD John) enroll =

‘9/1/2008’;

College admin (SSD John) Major =

College CS;

College CS CS100 (College admin (SSD

John)) grade = “F”;

The normal form of a term is the final form, i.e.,

the value, reducible from the term. An arbitrary term

can be reduced to its normal form. Here are a few

examples of the reduction process:

SSD John SSN Æ 123456789;

College CS CS100 (College admin (SSD

John)) grade Æ “F”;

College CS CS100 Æ College CS CS100;

College admin (SSD John) Major CS100 Æ

College CS CS100;

In EP data model, we say that a comb-term

functionally depends on its left-term because the

existence of the comb-term depends on the existence

of its left-term in a database. Similarly, we say that a

comb-term argumentatively depends on its right-

term. A database is ordered as a tree structure either

under the functional dependency or under the

argumentative dependency.

The EP data model has built-in operators for the

dependencies. For example, we have

SSD {=+

SDD, SSD John {+ SSD

(or equivalently SSD

John {=+ SSD

), and SSD John birth {=+

SSD

Pre-ordering relations (Xu et al., 2010) are the

additional relations existing among high-order

functions and lead to the corresponding built-in

operators in the EP data model, e.g., (=+, (=-, and

(=, which are not further explained here.

2.2 Variables

A variable in Froglingo is represented by an

identifier preceded with the symbol $. For example,

$a_variable, and $student. A variable is a term too.

To be in a database, a variable must satisfy the two

conditions:

• If a variable appears in an assigner, it must

appear in assignee;

• A variable cannot be a left-term in an assignee.

With the addition of variables, we can have the

following valid assignments in database:

fac 0 = 1;

fac $n = ($n * (fac ($n - 1)));

Syntactically, the first assignment is for finite

data and the second for infinite data. However, they

are managed together, i.e., both are stored physically

together in the same data structure; and both can be

updated with the same manner. For example, one

can issue the expression:

delete fac;, which

removes both assignments from database.

Semantically, the two assignments represent the

factorial function and they are equivalent to a

database having infinite assignments in the EP data

model:

fac 0 = 1; fac 1 = 1; fac 2 = 2;

fac 3 = 6; …;

A variable can have a range to prevent unwanted

data from being the instances of the variable. For

example, the factorial function can be redefined to

allow integers only being the instances of the

variable $n:

fac 0 = 1;

fac $n:[$n isa integer] =

($n * (fac ($n - 1)));

Data, having variables or not, is equally

applicable to the built-in operators in Froglingo, and

produces the meaningful values according to the

semantics of the data. Here is an example: select all

the integers that are less than

7 and applicable to the

factorial function

fac:

select $x where fac $x != null

and $x < 7;

Please note that variables bring non-termination

process to Froglingo. It is users’ responsibility to

avoid it.

To express the multiple actions triggered by a

single event, Froglingo adopts the sequential order

of the statements in a traditional programming

language, i.e., a statement is not executed until its

preceding statement is executed in a procedure of an

application program. For example, transferring

money between bank accounts is expressed in

Froglingo as:

transfer $m =

(update acnt2 = (acnt2 - $m)),

(update acnt1 = (acnt1 + $m));

provided that the two accounts were established

earlier:

acnt1 = 100;, and acnt2 = 300;.

FROGLINGO - A Monolithic Alternative to DBMS, Programming Language, Web Server and File System

249

3 DBMS AND DATA MODELING

The relational data model and the hierarchical data

model, and the conceptual Entity-Relationship

model, from which the traditional commercial

database management systems (DBMS) are

established, are the special cases of the EP data

model. In this section, we use examples to

demonstrate it.

The employees table in the relational data model:

Employees

ID Name salary

1 “Jone” 50000

2 “Mary” 60000

can be presented in Froglingo as:

employees 1 name = “Jone”;

employees 1 salary = 50000;

employees 2 name = “Mary”;

employees 2 salary = 60000;

The query of finding all the employees whose

salary is greater than 55000 is expressed in

Froglingo as:

select $e name, $e salary where

where $e salary > 55000;

A car consisting for its body and its engine (and

the engine further consisting for its piston and its

cylinder), that is traditonaly managed by using the

hierarchical data model, can be expressed in

Frogingo as:

car body;

car engine piston;

car engine cylinder;

The query: retrieve all the parts and assembles

under the car is expressed in Frogling:

select $p where $p {=+ car;

The network-oriented data is the favourite of the

conceptual model: Entity-Relationship model. It can

also be presented in Froglingo. Given the directed

graph: G = {A->B, B->A, B->C, C->D}, as an

example, one has a Froglingo presentation:

A B = B;

B A = A;

B C = C;

C D = D;

A database in the EP data model is a high-order

function, and all the total recursive (high-level)

functions can be expressed by the EP data model.

This is not the case for the relational and the

hierarchical models. The relational can only express

functions of level 3 (Hillebrand and Kanellakis,

1994); and the hierarchy data model can express

only those functions expressed in the EP data model

where the right-terms are not comb-term. For

example, the term

College admin (SSD John)

cannot be expressed in the hierarchical data model.

4 APPLICATION PROGRAM

The main function of application programs, i.e.,

application-oriented executable files in a traditional

programming language, is to express infinite data in

finite expressions. Froglingo has its variables to

counter this function as discussed in Section 2.2.

A traditional programming language is also used

to express finite data and the queries on the finite

data. A typical example is to express the following

query: Is there a path from vertices A to vertices D

in the directed graph given in Section 3. The EP data

model has the following expression for it:

D <=+

Placing data access controls and generating web

page contents are also application-specific. We will

discuss them in Sections 7 and 5 correspondingly

and conclude that all of them are managed as data in

Froglingo.

Historically, many efforts have been made to

couple DBMS and programming together as

discussed in Section 2. However, it was concluded

that there was a difficulty, called “impedance

mismatch”, when one wanted to manage relational

data model and programming language together

(Ohori et al, 1989). In other words, the clear obstacle

is the lower expressive power of traditional data

models and the lower productivity of traditional

programming languages in representing finite data

(Xu et al., 2010). A stored procedure in relational

DBMSs appears to be a “monolith” physically. But

it retains two exclusive languages, i.e., a data model

and a programming language. There are many other

attempts for a monolith with high productivity.

Without a data model equivalent to a class of total

recursive functions, however, none of them can get

rid of the issues raised from the traditional

technologies. Please reference (Xu et al., 2009) for

more discussion on this topic.

5 WEB SERVER

In addition to DBMSs, application programs also

need web servers to communicate with web

browsers on networks. A web server is to perform

the common task of software applications: parsing

ENASE 2010 - International Conference on Evaluation of Novel Approaches to Software Engineering

250

HTTP requests and generating HTTP responses. A

web server as a off-the-shelf product is at the front-

end facing the networks while a DBMS as another

off-the-shelf product is at the back-end.

When the functions of the application programs

are expressed as data and the physical executable

files for the application programs disappear from the

architecture of Frogingo, the function of web servers

is further supported by Froglingo itself, and

therefore the web servers as off-the-shelf products

are also eliminated from the architecture of

Froglingo . See a graphical view of the evolution in

the diagram of Section 8 that compares the software

architectures of the traditional technologies and

Froglingo.

When we conclude that the application programs

and the web servers are eliminated from the

architecture of Froglingo, we assume that the

function of generating web page contents, that is

application-specific, is expressed as data in

Froglingo as well. Here is an example to show how

Froglingo stores and generates web pages. Froglingo

accepts a HTML file (named as store.html)

embedded with Froglingo expressions:

<html>

<body>

Welcome to my store

The price of apple is

<frog>storage apple price</frog>

The price of milk is

<frog>storage milk price</frog>

</body>

</html>;

The contents between the pairs of tags <frog>

and </frog> are Froglingo expressions. When the

file is uploaded to Froglingo database, it is stored as

a set of assignments:

store.html 1 = “<html>

<body>

Welcome to my store

The price of apple is ”;

store.html 2 = storage apple price;

store.html 3 =”

The price of milk is “;

store.html 4 = storage milk price;

store.html 5 =”

</body>

</html>”;

When the HTML file is sent to the web clients as the

responses, the terms originally between the pairs of

tags <frog> and </frog> are evaluated and

replaced with their normal forms.

A HTML file embedded with Froglingo

expression in database is uniformly stored as data

and can be as complex as a business application

needs. For other relevant features including

recursively set-oriented query expressions and

parameters passing with HTML files, please see the

reference (Xu and Zhang, 2010).

6 DATA EXCHANGE AGENT

A typical application software in the traditional

technologies stores data in a relational DBMS,

processes data with the objects (user-defined data

structures) of programming language, and transfers

data in a third format (data communication protocol,

such as XML). Years ago, the data parsing and

conversions between the different data formats were

done by writing code as a part of application

program. Now, we utilize off-the-shelf data

exchange agents (such as Hibernate) to do the

common task: message parsing and data conversion

based on application-specific conversion rules

defined by developers.

Froglingo uses the single format – the EP data

model for data storage, data process, and data

transformation. Therefore, there is no need to

perform data conversion using an agent. Here is a

sample data communication in Froglingo by using

the built-in operator

print:

Print College Æ

College admin (SSD John) enroll =

‘9/1/2008’;

College admin (SSD John) Major =

College CS;

College CS CS100 (College admin (SSD

John)) grade = “F”;

7 ACCESS CONTROL

An application program, where a relational DBMS is

used, also needs to specify data access controls (or

called user entitlements) against the relational data.

This is necessary because the data access control, in

the correspondence of total recursive functions,

cannot be expressed by the relational data model, but

by programming language. This becomes no issue in

Froglingo due to its equivalence to a class of total

recursive functions. In addition, Froglingo offers a

set of built-in operators, stemming from the

dependent relationships, to specify data access

FROGLINGO - A Monolithic Alternative to DBMS, Programming Language, Web Server and File System

251

controls as if a file system specified file access

controls.

In an integrated environment such as at a

corporate level with multiple applications, an off-

the-shelf security product, such as Microsoft Active

Directory for Windows-based applications, IBM

Tivoli Access Manager or RSA ClearTrust for web-

based applications, is utilized to coordinate

corporate level security policies. Given the

traditional technologies, it simplifies the

management of data access controls among the

multiple applications by utilizing a centralized

database. When the applications in an integrated

environment establish a trusted relationship and

communicate with each other in Froglingo, the off-

the-shelf security products don’t have a place in the

architecture of Frolingo either.

Application

Business Logic

Access Control

Webpage generator

Web Server

HTTP Parser

APIs

Business

Data

DBMS

Froglingo

DBMS

HTTP Parser

Business Data

Business Logic

Access Control

Webpage generator

Data Exchange

Agent

Froglingo System Architecture

Traditional Software Architecture

Legends:

A on-shelf tool

Application Program

Data Storage

Figure 1.

8 CONCLUSIONS

The functions of the multiple software components

in the architecture of the traditional technologies

have never been segregated. In addition to the

primary copy in DBMS, for example, an employee

ID discussed in Section 3 may need to be duplicated

and re-processed in almost every other component,

i.e., application program, data exchange agent, and

data access controls.

Froglingo is a monolith powered by nothing but

high-order functions. It is a monolith for every

software application. It is a monolith consolidating

the multiple components of the traditional

technologies.

The consolidation itself improves the

productivity of software development and

maintenance. In addition, we have concluded in the

article (Xu et al., 2010) that Froglingo reaches the

greatest possible ease when we assumed that 1) a

data model is easier to use than a programming

language in the development and maintenance of

those applications expressible in the data model; 2)

if one data model is more expressive than another

data model, the former is easier than the latter in the

development and maintenance of those applications

where a programming language is involved. The

easiness further suggests that Froglingo improves

the productivity.

REFERENCES

G. Hillebrand, P. C. Kanellakis, “Functional Database

Query Languages as Typed Lambda Calcluli of Fixed

Order”, ACM SIGMOD/PODS 94.

P. Loucopoulos, K. Lyytinen, K. Liu, T. Gilb, L.A.

Maciaszek. “Project Failures: Continuing Challenges

for Sustainable Information Systems”, Enterprise

Information Systems VI, 1-8, 2006 Springer.

A. Ohori, P. Buneman, V. Breazu-Tannen. “Database

Programming in Machiavelli – a polymorphic

language with static type inference”. In ACM

SIGMOD, 1989, page 46 – 57.

K. H. Xu, J. Zhang, S. Gao. “High-Ordering Functions and

their Ordering relations”. The Fifth International

Conference on Digital Information Management,

2010.

K. H. Xu, J. Zhang, S. Gao. “An Assessment on the

Easiness of Computer Languages”. The Journal of

Information Technology Review, 2010.

K. H. Xu, S. Gao, J. Zhang, R. R. McKeown. “Let a Data

Model be equivalent to a Class of Total Recursive

Functions”. The International Conference on

Theoretical and Mathematical Foundations of

Computer Science (TMFCS-10), 2010.

K. H. Xu, J. Zhang, S. Gao. “Assessing Easiness with

Froglingo”. The Second International Conference on

the Application of Digital Information and Web

Technologies, 2009.

K. H. Xu, J. Zhang. “A User’s Guide to Froglingo, An

alternative to DBMS, Programming language, Web

Server, and File System”.

http://www.froglingo.com/froglingoguide10.pdf,

January 2010.

K. H. Xu. “EP Data Model, a Language for Higher-Order

Functions”. Manuscript unpublished, March 1999.

http://www.froglingo.com/ep99.pdf.

K. H. Xu and B. Bhargava. “An Introduction to

Enterprise-Participant Data Model”. The Seventh

International Workshop on Database and Expert

Systems Applications, September, 1996, Zurich,

Switzerland, page 410 - 417.

ENASE 2010 - International Conference on Evaluation of Novel Approaches to Software Engineering

252
