PARALLELISM, ADAPTATION AND FLEXIBLE DATA ACCESS IN

ON-DEMAND ERP SYSTEMS

Vadym Borovskiy

, Wolfgang Koch

and Alexander Zeier

Hasso-Plattner-Institute, Potsdam, Germany

SAP AG, Walldorf, Germany

Keywords:

ERP system architecture, ERP data provisioning, Business object query language.

Abstract:

On-premise enterprise resource planning (ERP) systems are costly to maintain and adapt to speciﬁc needs.

To lower the cost of ERP systems an on-demand consumption model can be employed. This requires ERP

systems to support multi-tenancy and multi-threading to enable consolidation of multiple businesses onto the

same operational system. To simplify the adaptation of ERP systems to customer-speciﬁc requirements the

former must natively support extensions, meaning that customer-speciﬁc behavior must be factored out from a

system and placed into an extension module. In this paper we propose the architecture of an ERP system that

i) exploits parallelism and ii) is able to accommodate custom requirements by means of enterprise composite

applications. We emphasize the importance of ERP data accessibility and contribute with a concept of business

object query language that allows building ﬁne-grained queries. All suggestions made in the paper have been

prototyped.

1 INTRODUCTION

To effectively manage information and automate busi-

ness processes companies use enterprise resource

planning (ERP) systems. ERP systems are always as-

sociated with high cost and force companies to com-

mit themselves to speciﬁc software for quite long

time, which is not desirable. In fact, businesses re-

quire the opposite: low cost, ﬂexible, and scalable

ERP systems, which require no special skills to use

them and are capable of delivering ERP data on both

desktop computers and mobile devices. Because clas-

sical on-premise ERP systems (e.g. SAP R/3 and

SAP Business Suite) cannot fulﬁll such expectations,

the concept of software as a service (SaaS) pene-

trated ERP sector. Although offering clear advan-

tages over existing on-premise systems, turning the

later into SaaS proved to be a difﬁcult exercise. The

main reason for this is systems’ architecture consist-

ing of tightly coupled elements and based on propri-

etary protocols.

The current work contributes with the architecture

of an ERP system that suits the SaaS model. This goal

is achieved by decoupling the components of an ERP

system, employing parallelism and providing ﬂexible

data access API. The importance of the last element

is highly emphasized. The corner stone of the API is

the business object query language (BOQL) offering

both the ﬂexibility of SQL and encapsulation of SOA.

In addition to architecture of an on-demand ERP sys-

tem, the paper address the issue of adapting a sys-

tem to customer-speciﬁc needs, which has proved to

be one of the hottest topics in ERP systems develop-

ment. The adaptation is achieved by leveraging the

suggested data access API with enterprise compos-

ite applications (ECAs). ECA is a means of adding

customer-speciﬁc features on top of data and func-

tionality of an ERP system.

1.1 ERP as a Service

SaaS gains more and more momentum. Subscribing

to applications over the Internet and using them via

industry-standard browsers or Web services clients

proved to be efﬁcient from both economic and com-

putational points of view (Jacobs, 2005). In the SaaS

model, a provider develops an application and oper-

ates the servers that host it. The provider’s beneﬁts

stems from the economies of scale. The provider

aggregates many users and can share all aspects of

the IT infrastructure, including hardware, software,

stafﬁng, and the data center itself among a number

of subscribers. From a subscriber’s point of view the

beneﬁt comes from converting the ﬁxed cost of own-

Borovskiy V., Koch W. and Zeier A. (2010).

PARALLELISM, ADAPTATION AND FLEXIBLE DATA ACCESS IN ON-DEMAND ERP SYSTEMS.

In Proceedings of the 5th International Conference on Software and Data Technologies, pages 16-22

DOI: 10.5220/0002932800160022

 SciTePress

ing and maintaining on-premise infrastructure into the

variable cost of renting it on demand. On average on-

premise infrastructure is underutilized, because its ca-

pacity is driven by systems’ peak load. But peak loads

account for a small part of systems’ operating time.

For example, Amazon’s infrastructure has been de-

signed to guarantee an appropriate service level dur-

ing the Christmas week, but the workload during the

rest of the year is signiﬁcantly lower. Therefore, most

of the time Amazon’s infrastructure is idle. Compa-

nies make large investments in infrastructure and ﬁnd

it idle for most of the time. Hence, by subscribing to

SaaS companies pay only for actual usage, whereas

with on-premise hardware the amount of resources

they pay for is driven not by actual, but peak work-

load. The usage-based pricing model not only re-

duces capital expense, but also lowers an entry barrier

to computing intensive businesses. By subscribing to

on-demand services companies minimize risks of en-

tering a business and avoid sunk cost.

Despite the clear cost advantage SaaS has a num-

ber of drawbacks. Most of them have to do with the

principle of infrastructure sharing. In this regard SaaS

generates privacy and security concerns, because not

only a company’s data are stored outside of the com-

pany, but also the company has no inﬂuence on how

its ERP provider manages the data. Another draw-

back of infrastructure sharing is having the possibility

of different subscribers affecting each other (mySql,

2007). Nevertheless, the attractiveness of the SaaS

concept and the efforts of ERP software vendors out-

weigh the challenges and SaaS gradually enters ERP

sector.

The shift to SaaS model automatically implies that

existing ERP systems’ architecture must be revised in

order to meet new requirements. The section 2 of this

paper deﬁnes what it means to an ERP system to be

on-demand and how this is achieved.

2 ON-DEMAND ERP SYSTEM

What does it mean for an ERP system to be on-

demand? To answer this question we need to ad-

dress the cornerstone principle of on-demand systems

- infrastructure sharing. According to this principle

a system must be able to consolidate a big number

(tens or even hundreds) of subscribers. This implies

multi-tenancy in database layer and parallelism in ap-

plication server layer. Multi-tenancy is basically map-

ping a number of single-tenant logical schemas in one

multi-tenant physical schema in the database. Be-

cause the topic of multi-tenancy has received high at-

tention in the database research community we redi-

rect the reader to (Aulbach et al., 2008), (Jacobs et al.,

2009), (mySql, 2007). The topic of parallelization is

addressed in the following subsection.

2.1 Parallelism in ERP System

Because an on-demand system serves a big number of

subscribers increasing the throughput of the system

becomes an important goal when designing the sys-

tem. In our opinion, the increase of throughput must

be achieved by parallelization of request processing.

To enable efﬁcient parallel execution of requests

the later must be independent from each other, that is

no task should require the results of other tasks’ ex-

ecution. In addition no task should compete for the

system’s resources with others. Task independence

implies no synchronization among the threads of the

system, which in turn allows to execute the threads

on different processors/cores at the same time with-

out blocking. In this case a system can dynamically

increase and decrease its throughput by acquiring and

releasing computational resources depending on the

workload placed on the system by its users.

To minimize the number of tasks that need syn-

chronization the principle of separation of concerns

must be applied. According to this principle an in-

formation system is separated into distinct elements

that overlap in functionality as little as possible. All

ERP systems that we are aware of use three-tier ar-

chitecture. The three-tier architecture scales well and

can exploit the potential of massive parallelism. Each

of the three tiers can accomplish its tasks in separate

threads/processes, which will not be blocked by each

other. When a tier receives a request it can spawn a

child thread to process the request independently of

other tasks in the system. To improve responsiveness

and availability of a system asynchronous communi-

cation between the tiers can be employed.

The separation of tiers from each other rises a

challenge of interfacing them. The interfaces among

the tiers should enable efﬁcient data access, meaning

that the system must be able to satisfy data requests

of any granularity. Efﬁcient data access is an indica-

tor of an ERP system’s openness and plays a crucial

role in enterprise composite application development.

Therefore, the next two sections address this issue in

details. The goal of the discussion in the sections is

to understand how internals of an ERP system must

be organized in order to enable efﬁcient data access

to ERP data.

PARALLELISM, ADAPTATION AND FLEXIBLE DATA ACCESS IN ON-DEMAND ERP SYSTEMS

2.2 Flexible Data Access

Data access API of an ERP system highly depends on

internal details of the system. Not all architectures

can efﬁciently support data access from outside of the

system. In fact, most of the systems never allow such

access.

2.2.1 State of the Art

A straightforward approach to data access can be

to use SQL. Since ERP systems rely on relational

databases, SQL statements could be issued directly

against the databases to retrieve required data. Al-

though SQL is natively supported by the underlying

databases, this approach is unlikely to deliver the ex-

pected results. SQL statements need to be written

against an actual schema of a database. The problem

with this approach is that it violates the data encapsu-

lation principle. Basically SQL exposes too much of

control over the underlying database and greatly in-

creases the risk of corrupting data in the system. An

ERP system is not only a collection of structured data,

but also a set of business rules that apply to the data.

Generally these rules are not a part of the system’s

database. Direct access to the database circumvents

the rules and implies data integrity violation. There-

fore, to enforce the rules the direct access to data by

any means is strictly prohibited.

An alternative to SQL can be data as a service ap-

proach. In this case a system exposes a number of

Web services with strictly deﬁned semantics. This ap-

proach has an advantage of hiding internal organiza-

tion of data. Instead of a data schema a set of oper-

ations that return data are exposed by a system. By

choosing operations and calling them in an appropri-

ate sequence required data can be retrieved. Because

of using Web services this approach is platform inde-

pendent. However, this method has a serious disad-

vantage: lack of ﬂexibility. Although an ERP system

vendor can deﬁne many data accessing operations,

they will never cover all possible combinations of data

pieces of an ERP system. Often these operations are

limited to one business object. ECAs on the other

hand address very speciﬁc or ﬁne-granular needs and

deliver value by assembling information coming from

different locations of a system. Therefore, the granu-

larity of data services does not match the granularity

of ECAs’ operations and the services cannot provide

adequate support for the ECAs. For this reason ECAs

need to issue multiple service calls and combine a re-

sult set on their own. This greatly complicates the

development of ECAs and undermines their perfor-

mance. This situation clearly demonstrates the ad-

vantage of the SQL approach. The ability to construct

ﬁne-granular queries that fully match the information

needs of ECAs makes SQL a much more ﬂexible API

than data as a service.

As one can see both approaches have advantages

and disadvantages. SQL as a data access API gives

great ﬂexibility by allowing to construct queries that

match the granularity of a user’s information needs.

However, SQL exposes too much control over the

database, circumvents business logic rules and binds

ECAs to a speciﬁc implementation platform. The data

as a service approach on the other hand enforces busi-

ness rules by exposing a set of Web operations which

encapsulate data access and hide data organization.

However, the granularity of the exposed operations

does not match that of a user’s needs, which creates

inﬂexibility and hits performance.

2.2.2 Business Object Query Language

In this subsection we contribute with an idea of

how to combine the advantages of discussed ap-

proaches while eliminating their disadvantages and

propose a concept called business object query lan-

guage (BOQL).

It is clear that accessing raw data directly and

circumventing business logic contradicts with data

encapsulation. For this reason business objects ap-

peared. They fully control the access to the data and

protect the integrity of data. From external perspec-

tive business objects are simply a collection of seman-

tically related data, e.g. invoice, bill of material, pur-

chase order, and a number of business operations that

can be performed on the data, e.g. read, create, etc. A

business object can be represented as set of data ﬁelds

or attributes, e.g. id, count, name, and associations or

links with other business objects, e.g. a SalesOrder

is associated with a Customer and Product business

objects.

Despite the diverse semantics of business objects

they all have the same structure (an array of attributes

and associations) and behavior (a set of operations).

After a number of experiments we have found that

the most important operations to support by a busi-

ness object are Create, Retrieve, RetrieveByAssocia-

tionChain, Delete and Update. Therefore, all busi-

ness objects can be derived from the same base class

featuring the mentioned arrays and operations. Such

uniform behavior and structure allow to introduce a

query language for business objects very much like

SQL for relational entities. We propose the following

scenario:

1. A programmer composes a query, the description

of what to retrieve from the system, according to

some SQL-like grammar and sends the query as

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

a string to the system via a generic service opera-

tion, for example Execute.

2. The system parses the string to detect present

clauses (from, select, where, etc.) and builds an

abstract syntax tree - an internal representation of

the query. The tree is then passed for further pro-

cessing to a query execution runtime.

3. Using the from clause the runtime obtains refer-

ences to the business objects from which the re-

trieval must be performed: source business ob-

jects. Then the runtime traverses the tree in a spe-

ciﬁc order and converts recognized query tokens

to appropriate operation calls on the source busi-

ness objects. For example, tokens from a select

clause are converted to Retrieve or RetrieveByAs-

sociationChain operations.

4. Having extracted the values from the query string,

the runtime executes the operations with the ex-

tracted values passed as input parameters and

composes the result. After that the result is for-

matted in XML and sent back to the calling pro-

gramm.

In its essence the query language performs an or-

chestration of calls to objects’ operations based on

user-deﬁned queries. These queries are transformed

to a sequence of operation calls that yield the required

data. Business object query language has an advan-

tage of supporting ﬁne-grained queries as in the case

of SQL without circumventing business rules as in

the case of the data as a service approach. Such an

approach is allowed by a uniform representation of

business objects (in terms of the structure and behav-

ior).

This method of accessing data can be used by

both an ERP system itself and ECAs. In the later

case a problem of communicating ERP data model

arises. In order to develop ECAs users must have a

strong understanding of the system’s business object

model. In other words, they need to know what busi-

ness objects are in the system, what attributes the ob-

jects have and how the objects are linked among each

other. To communicate this information we use ori-

ented graphs. The vertices of a graph denote business

objects and oriented edges denote associations. A set

of attributes is attached to every vertex (see Figure 2).

For the sake of compactness we will not list the at-

tributes on diagrams. The graph plays the same role

for business objects as the schema for a database. It

depicts the structure of business data and is essential

to know to compose queries.

2.3 System’s Architecture

The current subsection demonstrates a possible im-

plementation of an ERP system built according to the

principles discussed in earlier in this section in a way

that uses massive parallelism. The Figure 1 sketches

the architecture of a prototyped system. It has ﬁve

elements: user interface, a user request handing and

dispatching layer, a query engine, a business object

engine and a storage.

In our prototype we used Silverlight as a UI-

building technology, but any other technology capable

of executing Web service calls can be used. The main

responsibility of the user interface it to render forms

based on the information in a user’s conﬁguration pro-

ﬁle and the actual data returned by the backend sys-

tem. Note that there can be two types of client appli-

cation: (i) those that connect directly the backend sys-

tem and proﬁle storage and execute BOQL queries on

their own and (ii) those that use intermediary request

handling and dispatching layer. The applications of

ﬁrst type are so called fat clients and provide richer

functionality and put less workload of the backend

system, but are more complex. The later ones are thin

clients that essentially are terminals via which users

access the system. A good example of a thin client is

an application running on a mobile device. For long

time thin clients have been considered to be easier to

deploy. With the technology like Silverlight this is

no longer the case. A Silverlight application is essen-

tially a .Net application running inside a Web browser.

In other words this is a fully-ﬂedged desktop applica-

tion (fat client) running on the client side and hosted

by a Web browser. Every time a user opens a web

page with a Silverlight application the browser down-

loads the application and executes it. Hence with Sil-

verlight we can achieve the power of a fat client for

the deployment price of a thin client.

To effectively support thin clients (like mobile

phones and Web pages with server-side logic like

ASP.NET and PHP) we had to develop a scalable user

request handling and dispatching layer. The point is

that the Web service to which thin clients connect

can easily become a bottleneck in the system. There-

fore we factored out the actual BOQL query execut-

ing from the Web service to reduce its workload and

thus improve the responsiveness and performance of

the overall system. For this we run so called work-

ing processes (each process can be run on any physi-

cal server to which the Web service hosting machine

can establish a tcp connection). This allowed us to

avoid blocks of the Web service caused by waiting

for results from the query engine. Now if a block oc-

curs (because of long query execution time) none of

PARALLELISM, ADAPTATION AND FLEXIBLE DATA ACCESS IN ON-DEMAND ERP SYSTEMS

the other working processes is affected. To minimize

the thread and connection management overhead ev-

ery working process has two objects instantiated at a

process’s start up time, namely the thread pool and

connection pool. We encapsulate thread management

related code inside a separate component in order to

make threading transparent for the rest of the system.

Whenever our system needs a thread it simply picks

up one from the pool. The same motivation is be-

hind the connection pool: whenever the system needs

a connection it acquires one from the pool. Because

pool pattern is a very well know approach we redi-

rect the reader to other works ((Richter, 2008) for the

thread pool, (Kircher and Jain, 2004) for the connec-

tion pool) for more details on it.

The business object engine manages business ob-

jects and the query engine provides access to them

from outside of the owning process via a query-like

interface. These two elements are instances of Bo-

Engine and QueryEngine classes respectively. Both

are created at the system’s startup time. Business

object engine is instantiated ﬁrst to assemble busi-

ness objects and store references to them in a pool.

Because business objects are independent from each

other they can be instantiated in parallel. This will

greatly improve the system’s start up time. Then the

instance of the query engine is created. It has ac-

cess to the pool and thus can manipulate the objects.

Query engine is another potential bottleneck of the

system. Because all BOQL queries go through this

element of the system it may become overloaded and

slow down the work of the system for this reason we

used the same approach as with the Web service: we

factored out query parsing and service call execution

from query engine to independent processes.

Every business object encapsulates an in-memory

table to cache data. The in-memory table is populated

with data taken from a private database. Every ob-

ject also encapsulates logic to synchronize/backup its

in-memory table with the database. To improve the

responsiveness of the system the synchronization is

done independently for every business object and in a

separate execution thread in the background mode. To

the query execution runtime an object is seen through

its interface: a collection of attributes and associations

to other objects and CRUD (Create, Retrieve, Update,

Delete) operations. How those are implemented is

completely hidden inside the object. Typically, at-

tributes and associations are bound to data ﬁelds and

relations of the underlying physical storage or local

in-memory cache. In this prototype we concentrate

on only read operations (accessors) from the inter-

face: Retrieve to get attributes of a given object and

RetrieveByAssociationChain to navigate from one ob-

Figure 1: The architecture of the test system.

ject to another via speciﬁed associations. These oper-

ations retrieve data from the underlying physical stor-

age or the local cache according to internal business

logic. By default the accessors assume one-to-one

correspondence between a business object’s logical

and physical schemas. For example, if an attribute

Attr1 of a business object Bo1 is queried the query

runtime looks for data ﬁeld named Attr1 in a table

corresponding to a given business object; if an associ-

ation Assoc1 of a Bo1 is queried the runtime looks for

a foreign key relationship corresponding to the asso-

ciation and constructs a join.

Neither a business object nor its in-memory cache

nor database tables can be directly accessed outside

of the owning process. The direct access to the data

is prohibited to enforce integrity rules and internal

business logic implemented by business objects. To

access the business data an external application must

use the standardized query-like interface exposed by

the query engine. When the latter receives a query it

acquires a thread object from the thread pool, parses

the query and transforms recognized tokens to cor-

responding operation invocations. Then the work is

handed over to the runtime engine that is responsible

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

for performing actual service calls and constructing

the result set. Whenever is possible the service calls

are done in parallel. To ﬁgure out what calls to exe-

cute at the same time we analyze the abstract syntax

tree built by the parser for a given query and issue ev-

ery call, which does not rely on yet not retrieved data,

in a separate thread. The result of these invocations is

assembled in a single XML document and sent back

to a client application.

As an implementation platform for the prototype

we chose .NET. The system is implemented as a Win-

dows service and the query interface is published as

a Web service hosted by Internet Microsoft Informa-

tion Services (IIS). The Web service is meant to dis-

patch a query to the system and serves as a request

entry point. There is no other way to invoke or ac-

cess the system except for issuing a call to the Web

service. The physical data storage is implemented as

a Microsoft SQL Server 2005 database.

2.4 Enterprise Composite Applications

as Extension Modules

A composite application is an application generated

by combining content, presentation, or application

functionality from desperate Web sources. CAs aim

at combining these sources to create new useful ap-

plications or services (Yu et al., 2008). An enterprise

composite application is a CA application which has

an ERP system as one of its sources

. CA access

their sources via thoroughly speciﬁed application pro-

gramming interface (API). The key characteristics of

a CA are its limited/narrowed scope and straightfor-

ward result set. CAs often address situational needs

and provide replies to ﬁne-grained information re-

quests. They are not intended to provide complex so-

lutions for general problems rather they offer compact

answers to clear-cut questions.

CAs create value by pulling all data and services a

user needs to perform a task on a single screen. These

data and services can potentially come from many

sources, including an ERP system. Very often users

are confronted with a problem of having necessary

information and functionality distributed across many

forms. By creating a CA that assembles them on the

same screen users can substantially increase the pro-

ductivity of their work. Additional beneﬁt here is that

a CA can present information in a way that meets per-

sonal preferences of a user.

From now on we consider only enterprise composite

applications. The terms ”CA” and ”ECA” for the sake of

brevity are considered to mean the same in the rest of the

paper.

The architecture we suggest natively supports CA.

The main enabler of composite applications is the

BOQL, which basically provides a mechanism for

query-like invocation of business objects’ services.

BOQL allows CAs to manipulate ERP data from out-

side of a system without violating internal business

logic. Because the query engine supports SOAP pro-

tocol, CAs can be developed and executed on any

platform that is suitable for a user and has support for

XML.

The process of developing CAs we see as follows.

1. A user

ﬁgure out on which business objects they

want to perform custom operations. This depends

on the actual task and application domain. Then

the user composes BOQL queries that will return

the data from the business objects. To compose

the queries the user can use Object Explorer and

Schema Explorer tools described earlier.

2. Using SOAP interface of the query engine the user

executes the queries and retrieves ERP data.

3. Using selected programming language the user

develops code that operates on the selected data

and performs the required operations.

4. In case the CA needs to change the data in the

source ERP system it composes BOQL queries

that do so and executes the queries using the same

SOAP interface of the query engine.

2.4.1 Business Case

In this section we present a business case, which ben-

eﬁts from the ﬂexible data access of the suggested

approach. Consider a Web retailer that sells items

on-line and subcontracts a logistics provider to ship

sold products to customers. The retailer operates in

a geographically large market (e.g. the US or Eu-

rope

). In this situation the consolidated shipment of

items can generate considerable savings in delivery

and thus increase the proﬁt of the retailer. Consolida-

tion means that a number of sold items is grouped in a

single bulk and sent as one shipment. The bigger the

shipment size, the higher the bargaining power of the

retailer when negotiating the shipment with a logis-

tics provider. The savings come from price discounts

gained from higher transportation volume

. In this

way the retailer can lower the transportation cost per

sold product. The consolidation of shipment is done

anyway by all logistics providers in order to minimize

their operating costs. By controlling the delivery of

power user or application programmer

The greater the territory and the higher the sales vol-

ume, the more relevant the case.

So called economies of scale in transportation

PARALLELISM, ADAPTATION AND FLEXIBLE DATA ACCESS IN ON-DEMAND ERP SYSTEMS

Figure 2: Schema of the Web retailer’s CRM.

sold items explicitly, the retailer captures the savings

that otherwise go to a logistics provider.

Let the retailer use a system with a business ob-

ject graph as Figure 2 presents to manage their sales.

We assume that the system exposes a query-like Web

service interface as described in the section 2.3. The

query returning the shipping address for all sales or-

der items that are to be delivered looks as follows:

SELECT

SO˜id, SO.Contact.Customer˜name,

SO.Contact.Address˜FormattedAddress

FROM

SalesOrder As SO

WHERE

SO.Status = "ToDeliver"

GROUP BY

SO.Contact.Address˜city

By invoking the query-liked Web service and

passing the above query to it, a third-party applica-

tion consolidates the items by their destination. The

next step for the application is to submit a request for

quote to a logistics provider and get the price of trans-

porting each group of items. Many logistics providers

have a dedicated service interface for this, so the ap-

plication can complete this step automatically. Once

the quote has been obtained and the price is appropri-

ate the products can be packaged and picked up by the

logistics provider.

To enable applications like the one just described

the system must expose a ﬂexible data access API.

That is, the system must be able to return any piece

of data it stores and construct the result set in a user-

deﬁned way. As mentioned in the section 2.2.1 tradi-

tional APIs cannot completely fulﬁll this requirement:

SQL against views circumvents the business rules en-

forced outside the database; Web services limit the

retrievable data to a ﬁxed, predeﬁned set. The archi-

tecture suggested in the current work overcomes the

existing limitations and offer the necessary degree of

data access ﬂexibility.

3 CONCLUSIONS

On-demand model offers a better pricing option for

enterprises than the traditional on-premise approach.

For ERP software vendors a shift to ERP as a service

implies challenge of making an ERP system able to

consolidate multiple business customers. The chal-

lenge is intensiﬁed by the need of adapting standard

ERP software to speciﬁc needs of customers.

The current work contributes with an architecture

of an ERP system that exploit massive parallelism in

order to cope with high workload put onto a system by

many concurrent users and argues in favor of ECAs

as an adaptation tool. The ability to support ECAs

comes from the high accessibility of a system’s data,

which is achieved with the help of business object

query language. We outlined the major components

of the architecture and prototyped the system using

Microsoft platform. We also demonstrated how an

ECA can be developed.

REFERENCES

Aulbach, S., Grust, T., Jacobs, D., Kemper, A., and Rit-

tinger, J. (2008). Multi-tenant databases for soft-

ware as a service: schema-mapping techniques full.

In Proceedings of the 2008 ACM SIGMOD inter-

national conference on Management of data, pages

1195–1206.

Jacobs, D. (2005). Enterprise software as service. Queue,

3(6):36 – 42.

Jacobs, D., Aulbach, S., Kemper, A., and Seibold, M.

(2009). A comparison of ﬂexible schemas for software

as a service. In Proceedings of the 35th SIGMOD in-

ternational conference on Management of data, pages

881–888.

Kircher, M. and Jain, P. (2004). Pattern-Oriented Software

Architecture: Patterns for Resource Management. Wi-

ley.

mySql (2007). Anatomy of mysql on the grid.

http://blog.mediatemple.net/weblog/2007/01/19/

anatomy-of-mysql-on-the-grid/.

Richter, J. (2008). Windows Via C/C++. Microsoft Press.

Yu, J., Benatallah, B., Casati, F., and Daniel, F. (2008).

Understanding mashup development. IEEE Internet

Computing, pages 44–52.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies
