A PROGRAMMING LANGUAGE TO FACILITATE THE

TRANSITION FROM RAPID PROTOTYPING TO EFFICIENT

SOFTWARE PRODUCTION

Francisco Ortin, Daniel Zapico and Miguel Garcia

Computer Science Department, University of Oviedo, Calvo Sotelo s/n, Oviedo, Spain

Keywords:

Dynamic languages, Rapid prototyping, Separation of concerts, Union types, Alias analysis, Type inference.

Abstract:

Dynamic languages are becoming increasingly popular for developing different kinds of applications, being

rapid prototyping one of the scenarios where they are widely used. The dynamism offered by dynamic lan-

guages is, however, counteracted by two main limitations: no early type error detection and fewer opportunities

for compiler optimizations. To obtain the beneﬁts of both dynamically and statically typed languages, we have

designed the StaDyn programming language to provide both approaches. Our language implementation keeps

gathering type information at compile time, even when dynamic references are used. This type information

is used to offer compile-time type error detection, direct interoperation between static and dynamic code, and

better runtime performance. Following the Separation of Concerns principle, dynamically typed references

can be easily turned into statically typed ones without changing the application source code, facilitating the

transition from rapid prototyping to efﬁcient software production. This paper describes the key techniques

used in the implementation of StaDyn to obtain these beneﬁts.

1 INTRODUCTION

Dynamic languages have recently turned out to be re-

ally suitable for speciﬁc scenarios such as Web devel-

opment, application frameworks, game scripting, in-

teractive programming, dynamic aspect-oriented pro-

gramming, and any kind of runtime adaptable or

adaptive software. Common features of dynamic lan-

guages are meta-programming, reﬂection, mobility,

and dynamic reconﬁguration and distribution. One

of the scenarios where they are widely used is the

rapid development of software prototypes. Their abil-

ity to address quickly changing software requirements

and their fast interactive edit-debug-test development

method make dynamic languages ideal for the rapid

creation of prototypes.

Due to the recent success of dynamic languages,

other statically typed ones –such as Java or C#– are

gradually incorporating more dynamic features into

their platforms. Taking Java as an example, the plat-

form was initially released with introspective and

low-level dynamic code generation services. Ver-

sion 2.0 included dynamic methods and the

CodeDom

namespace to model and generate the structure of a

high-level source code document. The Dynamic Lan-

guage Runtime (DLR), ﬁrst announced by Microsoft

in 2007, adds to the .NET platform a set of services

to facilitate the implementation of dynamic languages

(Hugunin, 2007). Finally, Microsoft has just included

a dynamic typing feature in C# 4.0, as part of the Vi-

sual Studio 2010. This new feature of C# 4.0 is the

Microsoft response to the emerging use of dynamic

languages such as Python or Ruby. C# 4.0 offers a

new

dynamic

keyword to support dynamically typed

C# code. When a reference is declared as

dynamic

the compiler performs no static type checking, mak-

ing all the type veriﬁcations at runtime. With this new

characteristic, C# 4.0 will offer direct access to dy-

namically typed code in IronPython, IronRuby and

the JavaScript code in Silverlight. Dynamic code in

C# 4.0 makes use of the DLR services (Hugunin,

2007).

The great suitability of dynamic languages for

rapid prototyping is, however, counteracted by lim-

itations derived by the lack of static type checking.

This deﬁciency implies two major drawbacks: no

early detection of type errors, and commonly a con-

siderable runtime performance penalty. Static typ-

ing offers the programmer the detection of type er-

rors at compile time, making possible to ﬁx them

immediately rather than discovering them at runtime

–when the programmer’s efforts might be aimed at

Ortin F., Zapico D. and Garcia M. (2010).

A PROGRAMMING LANGUAGE TO FACILITATE THE TRANSITION FROM RAPID PROTOTYPING TO EFFICIENT SOFTWARE PRODUCTION.

In Proceedings of the 5th International Conference on Software and Data Technologies, pages 40-50

DOI: 10.5220/0002978500400050

 SciTePress

some other task, or even after the program has been

deployed (Pierce, 2002). Moreover, since runtime

adaptability of dynamic languages is mostly imple-

mented with dynamic type systems, runtime type in-

spection and checking commonly involves a signiﬁ-

cant performance penalty.

Twitter can be seen as a practical example of how

dynamic languages are suitable for rapid prototyping

but they are not as appropriate as static ones for scal-

able, robust and efﬁcient software production. Twit-

ter began its life as a Ruby on Rails application but,

in 2008 the Twitter developers started replacing the

back-end Ruby services with applications running on

the JVM written in Scala (Venners, 2009). They

changed to Scala because, in their opinion, the Ruby

language lacks some things that contribute to reliable,

high performance code, and they want their code to be

correct and maintainable (Venners, 2009).

Since translating an implementation from one pro-

gramming language to another is not a straightfor-

ward task, there have been former works on provid-

ing both typing approaches in the same language (see

Section 6). Meijer and Drayton maintained that in-

stead of providing programmers with a black or white

choice between static or dynamic typing, it could

be useful to strive for softer type systems (Meijer

and Drayton, 2004). Static typing allows earlier de-

tection of programming mistakes, better documenta-

tion, more opportunities for compiler optimizations,

and increased runtime performance. Dynamic typ-

ing languages provide a solution to a kind of com-

putational incompleteness inherent to statically-typed

languages, offering, for example, storage of persistent

data, inter-process communication, dynamic program

behavior customization, or generative programming

(Abadi et al., 1991). Hence, there are situations in

programming when one would like to use dynamic

types even in the presence of advanced static type

systems (Abadi et al., 1994). That is, static typing

where possible, dynamic typing when needed (Meijer

and Drayton, 2004).

Our work breaks the programmers’ black or white

choice between static or dynamic typing. The pro-

gramming language presented in this paper, called

StaDyn, supports both static and dynamic typing.

This programming language permits the rapid devel-

opment of dynamically typed prototypes, and the later

conversion to the ﬁnal application with a high level of

robustness and runtime performance. The program-

mer indicates whether high ﬂexibility is required (dy-

namic typing) or correct

execution (static) is pre-

ferred. It is also possible to combine both approaches,

We use correct to indicate programs without runtime

type errors.

making parts of an application more ﬂexible, whereas

the rest of the program maintains its robustness and

runtime performance. The result is that StaDyn allows

the separation of the dynamism concern (H¨ursch and

Lopes, 1995). This feature facilitates turning rapidly

developed prototypes into a ﬁnal robust and efﬁcient

application.

In this paper, we present an overview of the tech-

niques we haveused to design and implement our pro-

gramming language in order to facilitate the transition

from rapid prototyping to efﬁcient software produc-

tion. The rest of this paper is structured as follows. In

the next section, we provide the motivation and back-

groundof dynamic and static languages. Section 3 de-

scribes the features of the StaDyn programming lan-

guage and a brief identiﬁcation of the techniques em-

ployed. Section 4 presents the key implementation

decisions, and the results of a runtime performance

assessment is presented in Section 5, and Section 6

discusses related work. Finally, Section 7 presents the

conclusions and future work.

2 STATIC AND DYNAMIC

TYPING

2.1 Static Typing

A language is said to be safe if it produces no exe-

cution errors that go unnoticed and later cause arbi-

trary behavior (Tucker, 1997), following the notion

that well-typed programs should not go wrong (i.e.,

reach a stuck state on its execution) (Pierce, 2002).

Statically typed languages ensure type safety of pro-

grams by means of static type systems. However,

these type systems do not compile some expressions

that do not produce any type error at runtime (e.g., in

.NET and Java it is not possible to pass the

mes-

sage to an

Object

reference, although the object ac-

tually implements a public

method). This happens

because their static type systems require ensuring that

compiled expressions do not generate any type error

at runtime.

In order to ensure that no type error is pro-

duced at runtime, statically typed languages employ

a pessimistic policy regarding to program compila-

tion. This pessimism causes compilation errors in

programs that do not produce any error at runtime.

C# code shown in Figure 1 is an example program of

this scenario. Although the program does not produce

any error at runtime, the C# type system does not rec-

ognize it as a valid compilable program.

This intend of validating the correctness of a pro-

A PROGRAMMING LANGUAGE TO FACILITATE THE TRANSITION FROM RAPID PROTOTYPING TO

EFFICIENT SOFTWARE PRODUCTION

public class Test {

public static void Main() {

object[] v = new object[10];

int summation = 0;

for (int i = 0; i < 10; i++) {

v[i] = i+1;

summation += v[i];

// Compilation error

}

Figure 1: Not compilable C# program that would not pro-

duce any runtime error.

gram before its execution makes statically typed lan-

guages to be less appropriate for rapid prototyping.

Almost every programming language that supports

interactive development environments (those where

code can be evaluated, tested, modiﬁed and reeval-

uated while the application is running) implements a

dynamic type system.

2.2 Dynamic Typing

The approach of dynamic languages is the opposite

one. Instead of making sure that all valid expres-

sions will be executed without any error, they make

all the syntactic valid programs compilable. This is

a too optimistic approach that causes a high number

of runtime type errors (commonly throwing runtime

exceptions) that might have been detected at compile

time. This approach compiles programs that might

have been identiﬁed as erroneous statically. The C#

4.0 source code in Figure 2 is an example of this

too optimistic approach. C# 4.0 has just included the

dynamic

type to permit the use of dynamically typed

references. This erroneous program is compilable, al-

though a static type system might have detected the

error before its execution.

public class Test {

public static void Main() {

dynamic myObject = "StaDyn";

// No compilation error

System.Console.Write(myObject*2);

}

Figure 2: Compilable C# 4.0 program that generates run-

time type errors.

2.3 The StaDyn Hybrid Approach

The StaDyn programming language performs type in-

ference at compile time, even over dynamic refer-

ences. The type information gathered statically is

used to both increase the robustness of the program-

ming language (notifying type error at compile time)

and improve its runtime performance. Type-checking

over dynamic references is more lenient in order to

facilitate the rapid development of prototypes. How-

ever, if the type-checker detects that a type error is

undoubtedly going to be produced at runtime, an error

message is shown and compilation is stopped. Type-

checking over static references is performed the same

as in C#.

For both typing approaches, we use the very same

programming language, letting the programmer move

from an optimistic, ﬂexible and rapid development

(dynamic) to a more robust and efﬁcient one (static).

This change can be done maintaining the same source

code, only changing the compiler settings. We sepa-

rate the dynamism concern (i.e., ﬂexibility vs. robust-

ness and performance) from the functional require-

ments of the application (its source code).

3 THE STADYN PROGRAMMING

LANGUAGE

This section presents the features of the StaDyn pro-

gramming language, identifying the techniques em-

ployed. A formal description of its type system is de-

picted in (Ortin and Perez-Schoﬁeld, 2008) and (Or-

tin, 2009). Implementation issues are presented in

Section 4.

The StaDyn programming language is an exten-

sion of C# 3.0. Although our work could be applied

to any object-oriented statically-typed programming

language, we have used C# 3.0 to extend the behav-

ior of its implicitly typed local references. In StaDyn,

the type of references can still be explicitly declared,

while it is also possible to use the

var

keyword to

declare implicitly typed references. StaDyn includes

this keyword as a new type (it can be used to declare

local variables, ﬁelds, method parameters and return

types), whereas C# 3.0 only provides its use in the

declaration of initialized local references. Therefore,

var

references in StaDyn are much more powerful

than implicitly typed local variables in C# 3.0.

The dynamic property of

var

references is speci-

ﬁed in a separate ﬁle (an XML document). The pro-

grammer does not need to manipulate these XML

documents directly, leaving this task to the IDE.

When changes the dynamism of a

var

reference, the

IDE transparently modiﬁes the corresponding XML

ﬁle. Depending on the dynamism of a

var

refer-

ence, type checking and type inference is performed

pessimistically (for static references) or optimistically

(for dynamic ones). Since the dynamism concern is

not explicitly stated in the source code, StaDyn facili-

tates the conversion of dynamic references into static

ones, and vice versa. This separation facilitates the

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

process of turning rapidly developed prototypes into

ﬁnal robust and efﬁcient applications (this is the rea-

son why we did not include a new

dynamic

reserved

word, like C# 4.0). It is also possible to make parts

of an application more adaptable, maintaining the ro-

bustness and runtime performance of the rest of the

program.

3.1 Single Static Assignment

Existing statically typed languages force a variable of

type T to have the same type T within the scope in

which it is bound to a value. Even languages with

static type inference (type reconstruction) such as ML

(Milner et al., 1990) or Haskell (Hudak et al., 1991)

do not permit the assignment of different types to the

same polymorphic reference in the same scope.

However, dynamic languages provide the use of

one reference to hold different types in the same

scope. This is easily implemented at runtime with a

dynamic type system. However, StaDyn offers this

feature statically, taking into account the concrete

type of each reference. The StaDyn program shown in

Figure 3 is an example of this capability. The

number

reference has different types in the same scope. It

is initially set to a string, and a double is later as-

signed to it. The static type inference mechanism im-

plemented in StaDyn detects the error in the last line

of code. Moreover, a better runtime performance is

obtained because it is not necessary to use reﬂection

to discover types at runtime.

using System;

class Test {

public static void Main() {

Console.Write("Enter a number, please: ");

var number = Console.In.ReadLine();

Console.WriteLine("Number of digits: {0}.",

number.Length);

number =

Math.Pow(Convert.ToInt32(number), 2);

Console.WriteLine("The square is {0}.", number);

int digits = number.Length; // * Compilation error

}

Figure 3: A reference with different types in the same scope.

In order to obtain this behavior, we have devel-

oped an implicit parametric polymorphic type sys-

tem (Cardelli, 1988) that provides type reconstruc-

tion when a

var

reference is used. We have imple-

mented the Hindley-Milner type inference algorithm

to infer types of local variables (Milner, 1978). This

algorithm has been modiﬁed to perform type recon-

struction of

var

parameters and attributes (ﬁelds) –

described in sections 3.4 and 3.5.

The uniﬁcation algorithm used in the Hindley-

Milner type system provides parametric polymor-

phism, but it forces a reference to have the same

static type in the scope it has been declared. To over-

come this drawback we have developed a version of

the SSA (Single Static Assignment) algorithm (Cytron

et al., 1991). This algorithm guarantees that every

reference is assigned exactly once by means of creat-

ing new temporary references. Since type inference

is performed after the SSA algorithm, we have imple-

mented it as a previous AST (Abstract Syntax Tree)

transformation. The implementation of this algorithm

follows the Visitor design pattern.

Figure 4 shows the corresponding program after

applying the AST transformation to the source code

in Figure 3. The AST represented by the source code

in Figure 4 is the actual input to the type inference

system. Each

number

reference will be inferred to a

single static type –in our example, string and double,

respectively.

using System;

class Test {

public static void Main() {

Console.Write("Enter a number, please: ");

var number0 = Console.In.ReadLine();

Console.WriteLine("Number of digits: {0}.",

number0.Length);

var number1 = Math.Pow(Convert.ToInt32(number0), 2);

Console.WriteLine("The square is {0}.", number1);

int digits = number1.Length; // * Compilation error

}

Figure 4: Corresponding program after the SSA transfor-

mation.

3.2 Static Duck Typing

Duck typing

is a property offered by most dynamic

languages that means that an object is interchangeable

with any other object that implements the same dy-

namic interface, regardless of whether those objects

have a related inheritance hierarchy or not. One of

the outcomes of duck typing is that it supports poly-

morphism without using inheritance. Therefore, the

role of the abstract methods and interface as a mech-

anism to specify a contract is made redundant. Since

it is not necessary to deﬁne polymorphic inheritance

hierarchies, software can be developed more quickly.

There exist statically typed programming lan-

guages such as Scala (Odersky et al., 2002) or OCaml

(R´emy and Vouillon, 1998) that offer structural typ-

ing, providing part of the beneﬁts of duck typing.

However, the structural typing implementation of

Scala is not implicit, forcing the programmer to ex-

plicitly declare part of the structure of types. In ad-

dition, intersection types should be used when more

than one operation is applied to a variable, making

programming more complicated. Although OCaml

If it walks like a duck and quacks like a duck, it must be

a duck.

A PROGRAMMING LANGUAGE TO FACILITATE THE TRANSITION FROM RAPID PROTOTYPING TO

EFFICIENT SOFTWARE PRODUCTION

provides implicit structural typing, variables should

only have one type in the same scope, and this type

is the most general possible (principal) type (Freeman

and Pfenning, 1991). Principal types are more restric-

tive than duck typing, because they do not consider all

the possible (concrete) values a variable may hold.

The StaDyn programming language offers static

duck typing. The beneﬁt provided by StaDyn is not

only that it supports (implicit) duck typing, but also

that it is provided statically. Whenever a

var

ref-

erence may point to a set of objects that implement

a public

method, the

message could be safely

passed. These objects do not need to implement a

common interface or an (abstract) class with the

method. Since this analysis is performed at compile

time, the programmer beneﬁts from both early type

error detection and runtime performance.

We have implemented static duck typing making

the static type system of StaDyn ﬂow-sensitive. This

means that it takes into account the ﬂow context of

each

var

reference. It gathers concrete type infor-

mation (opposite to classic abstract type systems)

(Plevyak and Chien, 1994) knowing all the possible

types a

var

reference may hold. Instead of declar-

ing a reference with an abstract type that embraces all

the possible concrete values, the compiler infers the

union of all possible concrete types a

var

reference

may point to. Notice that different types depending

on ﬂow context could be inferred for the same refer-

ence, using the type inference mechanism mentioned

above.

Code in Figure 5 shows this feature. The reference

reference

may point to either an

StringBuilder

String

object. Both objects have the

Length

prop-

erty and, therefore, it is statically safe to access to this

property. It is not necessary to deﬁne a common inter-

face or class to pass this message –in fact, their only

common superclass is

Object

. Since type inference

system is ﬂow-sensitive and uses concrete types, the

programmer obtains a safe static duck-typing system.

public static int f(bool condition) {

var reference;

if (condition)

reference =

new StringBuilder("ICSOFT");

else

reference = "ICSOFT'2010";

return reference.Length;

}

Figure 5: Static duck typing.

The key technique we have used to obtain

this concrete-type ﬂow-sensitiveness is union types

(Pierce, 1992). Concrete types are ﬁrst obtained by

the abovementioned uniﬁcation algorithm (applied in

assignments and method calls). Whenever a branch is

detected, a union type is created with all the possible

concrete types inferred. Type checking of union types

depends on the dynamism concern (next section).

3.3 From Dynamic to Static Typing

StaDyn permits the use of both static and dynamic

var

references. Depending on their dynamism con-

cern, type checking and type inference would be

more pessimistic (static) or optimistic (dynamic), but

the semantics of the programming language is not

changed (i.e., program execution does not depend

on its dynamism). This idea follows the pluggable

type system approachdescribed in (Bracha, 2004) and

(Haldiman et al., 2009). Since the dynamism concern

is not explicitly stated in the source code, it is possi-

ble to customize the trade-off between runtime ﬂex-

ibility of dynamic typing, and runtime performance

and robustness of static typing. It is not necessary

to modify the application source code to change its

dynamism. Therefore, dynamic references could be

converted into static ones, and vice versa, without

changing the application source code.

using System;

using System.Text;

public class Test {

public static int g(string str) {

var reference;

switch(Random.Next(1,3)) {

case 1: reference=new StringBuilder(str);

break;

case 2: reference = str;

break;

default: reference=new Exception(str);

}

return reference.Lenght;

}

Figure 6: Static

var

reference.

The source code in Figure 6 deﬁnes a

method,

where

reference

may point to a

StringBuilder

String

Exception

object. If we want to compile

this code to rapidly develop a prototype, we can pass

the compiler the everythingDynamic option. How-

ever, although we are compiling the code in the op-

timistic conﬁguration, the compiler shows the follow-

ing error message:

Error No Type Has Member (Semantic error).

The dynamic type ‘

([Var(8)=StringBuilder]

,[Var(7)=String] ,[Var(6)=Exception])’ has

no valid type type with ‘Lenght’ member.

The error is produced because no public

Lenght

property (it has been misspelled) is implemented in

the

String

StringBuffer

Exception

classes.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

This message shows how type-checking is performed

at compile time even in dynamic scenarios, providing

early type error detection. This feature improves the

way most dynamic languages work. As an example,

in the erroneous program in Figure 2 that C# compiles

without any error, StaDyn detects the error at compile

time.

It is worth noting that setting a reference as dy-

namic does not imply that every message could be

passed to that reference; static type-checking is still

performed. The major change is that the type sys-

tem is more optimistic when dynamic

var

references

are used. The dynamism concern implies a modiﬁca-

tion of type checking over union types. If the implic-

itly typed

var

reference inferred with a union type is

static, type checking is performed over all its possible

concrete types. However, if the reference is dynamic,

type checking is performed over those concrete types

that do not produce a type error; if none exists, then a

type error is shown.

Once the programmer has found out the mis-

spelling error, she will modify the source code to cor-

rectly access the

Length

property. If the program is

once again compiled with the everythingDynamic op-

tion, the executable ﬁle is generated. In this case, the

compiler accepts passing the

Length

message, be-

cause both

String

and

StringBubuilder

(but not

Exception

) types offer that property. With dynamic

references, type checking succeeds if at least one of

the types that compose the union type is valid. The

actual type will be discovered at runtime, checking

that the

Length

property can be actually accessed, or

throwing

MissingMethodException

otherwise.

Actually, the programmer does not need to set all

the

var

references in a compilation unit as dynamic.

It is possible to specify the dynamism of each sin-

gle reference by means of a XML ﬁle. As discussed

above, the programmer does not manipulate these

XML documentsdirectly, leaving this task to the IDE.

Each StaDyn source code ﬁle may have a correspond-

ing XML document specifying its dynamism concern.

The generated

function program will not pro-

duce any runtime type error because the random num-

ber that is generated will always be 1 or 2. How-

ever, if the programmer, once the prototype has been

tested, wants to generate the application using the

static type system, she may use the everythingStatic

option. When this option is used, no XML dynamism

ﬁle is analyzed and static typing is performed over

every

var

reference in that compilation unit. In this

case, the compilation of the

method will produce

an error message telling that

Length

is not a property

Exception

. The programmer should then mod-

ify the source code to compile this program with the

robustness and efﬁciency of a static type system, but

without requiring to translate the source code to a new

programming language.

3.4 Constraint-based Type System

Concrete type reconstruction is not limited to local

variables. StaDyn performs a global ﬂow-sensitive

analysis of implicit

var

references. The result is an

implicit parametric polymorphism (Cardelli, 1988)

more straightforward for the programmer than the

one offered by Java, C# (F-bounded) and C++ (un-

bounded) (Canning et al., 1989).

Implicitly typed parameter references cannot be

uniﬁed to a single concrete type. Since they repre-

sent any actual type of an argument, they cannot be

inferred the same way as local references. This ne-

cessity is shown in the source code of Figure 7. Both

methods require the parameter to implement a spe-

ciﬁc method, returning its value. In the

getString

method, any object could be passed as a parameter be-

cause every object accepts the

ToString

message. In

the

upper

method, the parameter should be any ob-

ject capable of responding to the

ToUpper

message.

Depending on the type of the actual parameter, the

StaDyn compiler generates the corresponding compi-

lation error.

public static var upper(var parameter) {

return parameter.ToUpper();

}

public static var getString(var parameter) {

return parameter.ToString();

}

Figure 7: Implicitly typed parameters.

For this purpose we have enhanced the StaDyn

type system to be constraint-based (Odersky et al.,

1999). Types of methods in our object-oriented lan-

guage have an ordered set of constraints specifying

the set of restrictions that must be fulﬁllled by the

parameters. In our example, the type of the

upper

method is:

∀αβ.α → β|α :Class(

ToUpper

: void → β)

This means that the type of the parameter (α)

should implement a public

ToUpper

method with no

parameters (void), and the type returned by

ToUpper

(β) will be also returned by

upper

. Therefore, if an in-

teger is passed to the

upper

method, a compiler error

is shown. However, if a string is passed instead, the

compiler reports not only no error, but it also infers

the resulting type as a string. Type constraint fulﬁl-

llment is, thus, part of the type inference mechanism

(the concrete algorithm could be consulted in (Ortin,

2009)).

A PROGRAMMING LANGUAGE TO FACILITATE THE TRANSITION FROM RAPID PROTOTYPING TO

EFFICIENT SOFTWARE PRODUCTION

3.5 Assignment Constraints

Using implicitly typed attribute references, it is possi-

ble to create the generic

Node

class shown in Figure 8.

The

Node

class can hold any data of any type. Each

time the

setData

method is called, the new concrete

type of the parameter is saved as the

data

ﬁeld type.

By using this mechanism, the two lines with com-

ments report compilation errors. This coding style is

polymorphic and it is more legible that the parametric

polymorphism used in C++ and much more straight-

forward than the F-bounded polymorphism offered

by Java and C#. At the same time, runtime perfor-

mance is equivalent to explicit type declaration (see

Section 5). Since possible concrete types of

var

ref-

erences are known at compile time, the compiler has

more opportunities to optimize the generated code,

improving runtime performance.

public class Node {

private var data;

private var next;

public Node(var data, var next) {

this.data = data;

this.next = next;

}

public var getData() { return data; }

public void setData(var data) {

this.data=data;

}

public class Test {

public static void Main() {

var node = new Node(1, 0);

int

n =

node.getData

();

int

n =

node.getData

();

bool b = node.getData(); // * Error

node.setData(true);

int n = node.getData(); // * Error

bool b = node.getData();

}

Figure 8: Implicitly typed attributes.

Implicitly typed attributes extend the constraint-

based behavior of parameter references in the sense

that the concrete type of the implicit object param-

eter (the object used in every non-static method in-

vocation) could be modiﬁed on a method invocation

expression. In our example, the type of the

node

attribute is modiﬁed each time the

setData

method

(and the constructor) is invoked. This does not imply

a modiﬁcation of the whole

Node

type, only the type

of the single

node

object –thanks to the concrete type

system employed.

For this purpose we have added a new kind of as-

signment constraint to the type system (Ortin, 2009).

Each time a value is assigned to a

var

attribute, an

assignment constraint is added to the method being

analyzed. This constraint postpones the uniﬁcation

of the concrete type of the attribute to be performed

later, when an actual object is used in the invocation.

Therefore, the uniﬁcation algorithm is used to type-

check method invocation expressions, using the con-

crete type of the actual object (a detailed description

of the uniﬁcation algorithm can be consulted in (Or-

tin, 2009)).

3.6 Using both Static and Dynamic

References

StaDyn performs static type checking of both dy-

namic and static

var

references. This makes possi-

ble the combination of static and dynamic code in the

same application, because the compiler gathers type

information in both scenarios.

Code in Figure 9 uses the

getString

and

upper

methods of Figure 7.

reference

may point to a

string or integer. Therefore, it is safe to invoke the

getString

method, but a dynamic type error might

be obtained when the

upper

method is called.

Since type-checking of dynamic and static code

is different, it is necessary to describe interoperation

between both types of references. In case

reference

had been set as a dynamic, the question of whether or

not it could have been passed as an argument to the

upper

getString

methods (Figure 7) arises. That

is, how optimistic (dynamic) code could interoperate

with pessimistic (static) one. An example is shown in

Figure 9.

var reference;

string aString;

if (new Random().NextDouble() < 0.5)

reference =

"String";

else

reference = 3;

aString = getString(reference);

aString = upper(reference);

// * Error

// (correct if we set parameter to dynamic)

Figure 9: Dynamic and static code interoperation.

The ﬁrst invocation is correct regardless of the dy-

namism of

parameter

. Being either optimistic or

pessimistic, the argument responds to the

ToString

method correctly. However, it is not the same in the

second scenario. By default, a compilation error is

obtained, because the parameter

reference

is static

and it may point to an integer, which does not imple-

ment a public

ToUpper

method. However, if we set

the parameter of the

upper

method as dynamic, the

compilation will succeed.

This type-checking is obtained taking into consid-

eration the dynamism of references in the subtyping

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

relation of the language. A dynamic reference is a

subtype of a static one when all the concrete types of

the dynamic reference promote to the static one (Or-

tin, 2009). Promotion of static references to dynamic

ones is more ﬂexible: static references should fulﬁll

at least one constraint from the set of alternatives.

3.7 Type-based Alias Analysis

The problem of determining if a storage location may

be accessed in more than one way is called Alias Anal-

ysis (Landi and Ryder, 1992). Two references are

aliased if they point to the same object. Although

alias analysis is mainly used for optimizations, we

have used it to know the concrete types of the objects

a reference may point to.

Code in Figure 10 uses the

Node

class previously

shown. Initially, the

list

reference points to a node

whose data is an integer. If we get the

data

inside the

Node

object inside the

List

object, we get an integer.

Then a new

Node

that holds a

bool

value is inserted

at the beginning of the

list

. Repeating the previous

access to the

data

inside the

Node

object inside the

List

object, a

bool

object is then obtained.

public class List {

private var list;

public List(var data) {

this.list = new Node(data, 0);

}

public void insert(var data) {

this.list = new Node(data, this.list);

}

public static void Main() {

var aList = new List(1);

int n1 = aList.list.getData();

aList.insert(

true);

int

n2 =

aList.list.getData

();

// * Error

int

n2 =

aList.list.getData

();

// * Error

bool b = aList.list.getData();

}

Figure 10: Alias analysis.

The alias analysis algorithm implemented is type-

based (uses type information to decide alias) (Di-

wan et al., 1991), inter-procedural (makes use of

inter-procedural ﬂow information) (Landi and Ryder,

1992), context-sensitive (differentiates between dif-

ferent calls to the same method) (Emami et al., 1994),

and may-alias (detects all the objects a reference may

point to; opposite to must point to) (Appel, 1998).

Alias analysis is an important tool for our type-

reconstructive concrete type system, and it is the key

technique to implement the next (future) stage: struc-

tural reﬂective type evolution.

4 IMPLEMENTATION

All the programming language features described in

this paper have been implemented over the .NET

Framework 3.5 platform, using the C# 3.0 program-

ming language. Our compiler is a multiple-pass lan-

guage processor that follows the Pipes and Filters

architectural pattern. We have used the AntLR lan-

guage processor tool to implement lexical and syn-

tactic analysis (Parr, 2007). Abstract Syntax Trees

(ASTs) have been implemented following the Com-

posite design pattern and each pass over the AST im-

plements the Visitor design pattern.

Currently we have developed the following AST

visits: two visitors for the SSA algorithm; two visitors

to load types into the types table; one visitor for sym-

bol identiﬁcation and another one for type inference;

and two visitors to generate code. Once the ﬁnal com-

piler is ﬁnished, the number of AST visits will be re-

duced to optimize the implementation. The type sys-

tem has been implemented following the guidelines

described in (Ortin et al., 2007).

We generate .NET intermediate language and then

assemble it to produce the binaries. At present, we use

the CLR 2.0 as the unique compiler’s back-end. How-

ever,we havedesigned the code generator module fol-

lowing the Bridge design pattern to add both the DLR

(Dynamic Language Runtime) (Hugunin, 2007) and

the zROTOR (Redondo and Ortin, 2008) back-ends in

the future.

5 RUNTIME PERFORMANCE

We have evaluated the performance beneﬁts obtained

with the inclusion of dynamic and static typing in the

same programming language. In this paper we only

summarize the results –detailed information can be

consulted in (Ortin et al., 2010). We have compared

C# 4.0 Beta 2, Visual Basic 10 (VB) and current ver-

sion of StaDyn. These have been the results:

• Tests with explicit type declaration revealed that

the three implementations offer quite similar run-

time performance. C# offers the best runtime per-

formance, being VB almost as fast as C# (C# is

only 0.64% better than VB). Finally, runtime per-

formance of StaDyn, when variables are explic-

itly typed, is 9.22% lower than VB, and 9.92%

in comparison with C#. This difference may be

caused by the greater number of optimizations

that these production compilers perform in rela-

tion to our implementation.

• The performance assessment of StaDyn when the

exact single type of a

var

reference is inferred

A PROGRAMMING LANGUAGE TO FACILITATE THE TRANSITION FROM RAPID PROTOTYPING TO

EFFICIENT SOFTWARE PRODUCTION

shows the repercussion of our approach. Runtime

performance is the same as when using explicitly

typed references (in fact, the code generated is ex-

actly the same). In this special scenario, StaDyn

shows a huge performance improvement: StaDyn

is more than 2,322 and 3,195 times faster than VB

and C# respectively. This vast differenceis caused

by the lack of static type inference of both VB and

C#. When a reference is declared as dynamic, ev-

ery operation over that reference is performed at

runtime using reﬂection. Since the usage of re-

ﬂective operations in the .NET platform has an

important performance cost (Ortin et al., 2009),

the execution time is signiﬁcantly incremented.

• While the number of possible types inferred by

our compiler increases, execution time shows a

linear raising regarding to the number of types

inferred by the compiler. However, C# and VB

maintain their runtime performance almost con-

stant. Therefore, the performance beneﬁt drops

while the number of possible types increases. As

an example, the runtime performance beneﬁt of

StaDyn drops to 40 and 56 times better than VB

and C# respectively, when the compiler infers 100

possible types for a

var

reference.

• The ﬁnal comparison to be established is when

the compiler gathers no static type information

at all. In this case, runtime performance is the

worst in the three programming languages, be-

cause method invocation is performed using re-

ﬂection. However, StaDyn requires 33.85% and

22.65% the time that VB and C#, respectively,

employ to run the same program.

Differences between our approach and both C#

and VB are justiﬁed by the amount of type informa-

tion gathered by the compiler. StaDyn continues col-

lecting type information even when references are set

as dynamic. Nevertheless, both C# and VB perform

no static type inference once a reference has been de-

clared as dynamic. This is the reason why StaDyn of-

fers the same runtime performance with explicit type

declaration and inference of the exact single type, in-

volving a remarkable performance improvement.

6 RELATED WORK

Strongtalk was one of the ﬁrst programming language

implementation that included both dynamic and static

typing in the same programminglanguage. Strongtalk

is a major re-thinking of the Smalltalk-80 program-

ming language (Bracha and Griswold, 1993). It re-

tains the basic Smalltalk syntax and semantics, but a

type system is added to provide more reliability and

a better runtime performance. The Strongtalk type

system is completely optional, following the idea of

pluggable type system (Bracha, 2004). This feature

facilitates the transition from rapid prototyping to ef-

ﬁcient software production.

Dylan is a high-level programming language, de-

signed to allow efﬁcient compilation of features com-

monly associated with dynamic languages (Shalit,

1996). Dylan permits both explicit and implicit vari-

able declaration. It also supports two compilation sce-

narios: production and interactive. In the interactive

mode, all the types are ignored and no static type

checking is performed. When the production con-

ﬁguration is selected, explicitly typed variables are

checked using a static type system.

Boo is a recent object-oriented programming lan-

guage that is both statically and dynamically typed

(Codehaus Foundation, 2006). In Boo, references

may be declared without specifying its type and the

compiler performs type inference. However, refer-

ences could only have one unique type in the same

scope. Moreover, ﬁelds and parameters could not

be declared without specifying its type. The Boo

compiler provides the ducky option that interprets the

Object

type as if it was

duck

, i.e. dynamically typed.

The Visual Basic .Net programming language in-

corporates both dynamic and static typing. Com-

piled applications run over the .NET platform using

the same virtual machine. The main beneﬁt of its

dynamic type system is that it supports duck typing.

However, there are interoperation lacks between dy-

namic and static code because no static type inference

is performed over dynamic references.

As mentioned, C# 4.0 includes the support of dy-

namically typed objects. A new

dynamic

keyword

has been added as a new type. The compiler performs

no static type checking over any

dynamic

reference,

making all the type veriﬁcations at runtime.

There are some theoretical research works on hy-

brid dynamic and static typing as well. Soft Typing

(Cartwright and Fagan, 1991) was one of the ﬁrst the-

oretical works that applied static typing to a dynami-

cally typed language such as Scheme. However, soft

typing does not control which parts in a program are

statically checked, and static type information is not

used to optimize the generated code either. The ap-

proach in (Abadi et al., 1991) adds a

Dynamic

type

to lambda calculus, including two conversion oper-

ations (

dynamic

and

type-case

), producing a ver-

bose code deeply dependent on its dynamism. The

works of Quasi-Static Typing (Thatte, 1990), Hybrid

Typing (Flanagan et al., 2006) and Gradual Typing

(Siek and Taha, 2007) perform implicit conversion

ICSOFT 2010 - 5th International Conference on Software and Data Technologies

between dynamic and static code, employing subtyp-

ing relations in the case of quasi-static and hybrid

typing, and a consistency relation in gradual typing.

None of them separates the dynamism concern. Grad-

ual typing already identiﬁed uniﬁcation-based con-

straint resolution as a suitable approach to integrate

both dynamic and static typing (Siek and Vachhara-

jani, 2008). However, with gradual typing a dynamic

type is implicitly converted into static without any

static type-checking, because type inference is not

performed over dynamic references.

7 CONCLUSIONS

The StaDyn programming language includes both dy-

namic and static typing in the same programming lan-

guage, improving the runtime ﬂexibility and simplic-

ity of the statically typed languages, and robustness

and performance of the static ones. StaDyn allows

both dynamic and static references in the same pro-

gram, facilitating the transition from rapid prototyp-

ing to efﬁcient software production. Each compila-

tion unit can be built in a dynamic or static conﬁgura-

tion, and the dynamism of each single reference can

be also speciﬁed without changing the semantics of

the whole program.

Dynamic and static code can be seamlessly inte-

grated because they share the same type system. Type

inference is performed over dynamic and static ref-

erences, facilitating the interoperation between dy-

namic and static code.

StaDyn performs type inference over dynamic and

static references, improving runtime performance and

robustness. A runtime performance assessment has

conﬁrmed how performing type inference over dy-

namic references involves an important performance

beneﬁt. Although this beneﬁt decreases as the number

of possible inferred types increases, runtime perfor-

mance of StaDyn is still signiﬁcantly better than C#

and VB when no type information of

var

references

is inferred at all.

Future work will be centered on integrating Sta-

Dyn in a visual IDE suitable for both rapid prototyp-

ing and ﬁnal efﬁcient application development. Our

idea is to extend Visual Studio 2010 to offer services

such as interactive code evaluation, substitution of im-

plicitly typed dynamic references with explicit static

ones, refactoring facilities to make dynamic code be-

come statically typed, and showing type errors and

warnings even over dynamic code.

Current release of the StaDyn programming lan-

guage and its source code are freely available at

http://www.reﬂection.uniovi.es/stadyn. A formal de-

scription of the StaDyn type system is detailed in (Or-

tin, 2009).

ACKNOWLEDGEMENTS

This work has been funded by Microsoft Research,

under the project entitled Extending dynamic fea-

tures of the SSCLI, awarded in the Phoenix and SS-

CLI, Compilation and Managed Execution Request

for Proposals, 2006. It has been also funded by the

Department of Science and Technology (Spain) under

the National Program for Research, Development and

Innovation; project TIN2008-00276 entitled Improv-

ing Performance and Robustness of Dynamic Lan-

guages to develop Efﬁcient, Scalable and Reliable

Software.

REFERENCES

Abadi, M., Cardelli, L., Pierce, B., and Plotkin, G. (1991).

Dynamic typing in a statically typed language. ACM

Transactions on Programming Languages and Sys-

tems, 13(2):237–268.

Abadi, M., Cardelli, L., Pierce, B., R´emy, D., and Taylor,

R. W. (1994). Dynamic typing in polymorphic lan-

guages. Journal of Functional Programming, 5:92–

103.

Appel, A. (1998). Modern Compiler Implementation in ML.

Cambridge University Press.

Bracha, G. (2004). Pluggable type systems. In OOPSLA

workshop on revival of dynamic languages.

Bracha, G. and Griswold, D. (1993). Strongtalk: Type-

checking Smalltalk in a production environment. In

Proceedings of the Conference on Object-Oriented

Programming Systems, Languages, and Applications

(OOPSLA), pages 215–230, New York, NY, USA.

ACM.

Canning, P., Cook, W., Hill, W., Olthoff, W., and Mitchell,

J. (1989). F-bounded polymorphism for object-

oriented programming. In Press, A., editor, Proceed-

ings of the fourth international conference on Func-

tional programming languages and computer archi-

tecture, pages 273–280.

Cardelli, L. (1988). Basic polymorphic typechecking. Sci-

ence of Computer Programming, (8):147–172.

Cartwright, R. and Fagan, M. (1991). Soft Typing. In Pro-

ceedings of the SIGPLAN Conference on Program-

ming Language Design and Implementation (PLDI

’91), pages 278–292.

Codehaus Foundation (2006). Boo, a wrist friendly lan-

guage for the CLI. http://boo.codehaus.org.

Cytron, R., Ferrante, J., Rosen, B. K., Wegman, M. N.,

and Zadeck, F. K. (1991). Efﬁciently computing

A PROGRAMMING LANGUAGE TO FACILITATE THE TRANSITION FROM RAPID PROTOTYPING TO

EFFICIENT SOFTWARE PRODUCTION

static single assignment form and the control depen-

dence graph. ACM Transactions on Programming

Languages and Systems, 13(4):451–490.

Diwan, A., McKinley, K., and Moss, J. (1991). Type-based

alias analysis. In Proceedings of the SIGPLAN Con-

ference on Programming Language Design and Im-

plementation (PLDI ’91), pages 106–117.

Emami, M., Ghiya, R., and Hendren, L. (1994). Context-

sensitive inter-procedural points-to analysis in the

presence of function pointers. In Proceedings of ACM

SIGPLAN’94 Conference on Programming Language

Design and Implementation, pages 224–256.

Flanagan, C., Freund, S., and Tomb, A. (2006). Hy-

brid types, invariants, and reﬁnements for impera-

tive objects. In International Workshop on Foun-

dations and Developments of Object-Oriented Lan-

guages (FOOL).

Freeman, T. and Pfenning, F. (1991). Reﬁnement types for

ML. In Proceedings of the ACM SIGPLAN Confer-

ence on Programming Language Design and Imple-

mentation (PLDI), pages 268–277.

Haldiman, N., Denker, M., and Nierstrasz, O. (2009). Prac-

tical, pluggable types for a dynamic language. Com-

puter Languages, Systems & Structures, 35:48–62.

Hudak, P., Jones, S., , and Wadler, P. (1991). Report on the

programming language haskell version 1.1. Technical

report, Departments of Computer Science, University

of Glasgow and Yale University.

Hugunin, J. (2007). Just glue it! Ruby and the DLR in

Silverlight. In MIX Conference.

H¨ursch, W. and Lopes, C. (1995). Separation of concerns.

Technical Report UN-CCS-95-03, Northeastern Uni-

versity, Boston, USA.

Landi, W. and Ryder, B. (1992). A safe approximate algo-

rithm for interprocedural pointer aliasing. In Confer-

ence on Programming Language Design and Imple-

mentation, pages 473–489.

Meijer, E. and Drayton, P. (2004). Dynamic typing when

needed: The end of the cold war between program-

ming languages. In Proceedings of the OOPSLA

Workshop on Revival of Dynamic Languages.

Milner, R. (1978). A theory of type polymorphism in pro-

gramming. Journal of Computer and System Sciences,

17:348–375.

Milner, R., Tofte, M., and Harper, R. (1990). The Deﬁnition

of Standard ML. The MIT Press.

Odersky, M., anb C. R¨ockl, V. C., and Zenger, M. (2002).

A nominal theory of objects with dependent types. In

European Conference on Object-Oriented Program-

ming (ECOOP), pages 201–224.

Odersky, M., Sulzmann, M., and Wehr, M. (1999). Type

inference with constrained types. Theory and Practice

of Object Systems, 5(1):35–55.

Ortin, F. (2009). The StaDyn core type system. Technical

report, Computer Science Department, University of

Oviedo, Spain.

Ortin, F. and Perez-Schoﬁeld, J. B. G. (2008). Supporting

both static and dynamic typing. In Programming and

Languages Conference (PROLE), pages 215–232.

Ortin, F., Redondo, J. M., and Perez-Schoﬁeld, J. B. G.

(2009). Efﬁcient virtual machine support of runtime

structural reﬂection. Science of Computer Program-

ming, 74.

Ortin, F., Zapico, D., and Cueva, J. M. (2007). Design pat-

terns for teaching type checking in a compiler con-

struction course. IEEE Transactions on Education,

50(3):273–283.

Ortin, F., Zapico, D., Perez-Schoﬁeld, J. B. G., and Garcia,

M. (2010). Including both static and dynamic typing

in the same programming language. IET Software, (to

be published).

Parr, T. (2007). The Deﬁnitive ANTLR Reference: Building

Domain-Speciﬁc Languages. Pragmatic Bookshelf.

Pierce, B. C. (1992). Programming with intersection types

and bounded polymorphism. Technical Report CMU-

CS-91-106, School of Computer Science, Pittsburgh,

PA, USA.

Pierce, B. C. (2002). Types and Programming Languages.

The MIT Press.

Plevyak, J. and Chien, A. (1994). Precise concrete type in-

ference for object-oriented languages. In SIGPLAN

Notices 29, 10, Proceeding of the OOPSLA Confer-

ence.

Redondo, J. M. and Ortin, F. (2008). Optimizing reﬂec-

tive primitives of dynamic languages. International

Journal of Software Engineering and Knowledge En-

gineering, 18(6):759–783.

R´emy, D. and Vouillon, J. (1998). Objective ML: ‘An ef-

fective object-oriented extension to ML’. Theory And

Practice of Object Systems, 4(1):27–50.

Shalit, A. (1996). The Dylan reference manual: the deﬁni-

tive guide to the new object-oriented dynamic lan-

guage. Addison Wesley Longman Publishing Co.

Siek, J. G. and Taha, W. (2007). Gradual typing for objects.

In Proceedings of the 21st European Conference on

Object-Oriented Programming (ECOOP).

Siek, J. G. and Vachharajani, M. (2008). Gradual typing

with uniﬁcation-based inference. In Dynamic Lan-

guages Symposium.

Thatte, S. (1990). Quasi-static typing. In Proceedings of the

17th ACM SIGPLAN-SIGACT symposium on Princi-

ples of programming languages (POPL), pages 367–

381, New York, NY, USA. ACM.

Tucker, A. B. (1997). Type Systems. The Computer Science

and Engineering Handbook. CRC Press.

Venners, B. (2009). Twitter on Scala. a conversation with

Steve Jenson, Alex Payne, and Robey Pointer. Artima

Developer.

ICSOFT 2010 - 5th International Conference on Software and Data Technologies
